IDEAL 4850-95 EP /

5221-95 EP / 6550-95

EP Guillotine

Instruction Manual

IDEAL 4850-95 EP
IDEAL 5221-95 EP
IDEAL 6550-95 EP

Betriebsanleitung

l

Operating Instructions
Mode d'emploi
Gebruiksaanwijzing
Manuale d'istruzione
Instrucciones para el uso

IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP

3 01-01-23 B5221G1A doc

Table of contents

1. General..................................................4

1.1 Application .............................................4

2. Installation..............................................5

2.1 Preparing for installation.........................5

2.2 Power supply..........................................5

3. Operation...............................................6

Checklist................................................6

3.1 Operating elements................................6

3.2 Start machine.........................................7

Cutting to specified dimensions..............7

Cut according to markings......................7

Eject functio n..........................................7

Repeat cutting........................................7

Repeat dimension function completed....7

Cutting activation....................................7

Cutting stop or interruption.....................7

3.3 Programming..........................................8

Entering a program ................................8

Eject functio n :.........................................8

Programming of repeat cut dimension....8

Cancel a program...................................8

Working with programs...........................9

General.................................................. 9

Escape the program mode.....................9

Program keys

¢ and £:........................9

Display in cm or inch..............................9

Adjust the eject-dimension.....................9

4. Maintenance ........................................10

Safety check ........................................10

4.1 Cutting stick replacement.....................10

Setting the cutting depth.......................10

Turning resp. replacing the cutting stick10

Cutting test...........................................10

4.2 Blade replacement ...............................11

Blade demounting................................11

Blade mounting.................................... 11

4.3 Maintenance all 7 days.........................12

4.4 Maintenance all 6 months ....................12

Lubricant and grease gun.....................12

5. Trouble shooting ..................................13

6. Technical data......................................14

7. Accessories..........................................14

EG-declaration of confor m it y

IDEAL 4850-95 EP

IDEAL 5221-95 EP

IDEAL 6550-95 EP

IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP

4 01-01-23 B5221G1A doc

1. General

s Danger!

Non-compliance with the instructions may
endanger persons.

l Warning!

Non-compliance with the instructions may
cause damage to the machine.

This instruction manual helps you to learn the
safe and comfortable operat ion with this
machine. Before working with the machine
please read this instruction carefully and
consider the safety regulations.

The operating instructions must be always
available for the operator.

Machine is proved by GS- and CE.

s Danger

Only instructed persons are allowed to
operate the machine.
No operation by children.

All components which may endanger the
operator are covered by a quard. This

machine is only designed for “one-man
operation”. The cutting action which is dange-

rous to the operator is protected thr ough a
guard (1) and a two-handed control system (2)

1.1 Application

The machine is designed for cutting reams of
paper to a specified dimension. Dimension
setting may be performed via keys or manually
at the rotary control. The cutt ing takes place
through the "two-handed control system".

l Warning!

The machine may only be used for cutting
paper or similar materials. Clips etc. will
damage the cutting blade.

s Danger!

The cutting of hard material or material
which might splinter is forbidden.

IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP

5 01-01-23 B5221G1A doc

2. Installation

The machine must be installed on a sturdy,dry
and leveled floor.

s Danger!

- The machine must not be located out side.

- Do not use in the vicinity of inflammable
liquids or gases.

- Do not use in humid environments.

- Protect mains cable against heat , oil and
sharp edges.

Use 4 strong people to lift the machine from the
pallet.

IDEAL 5221 - For further tr anspor t ation
For further transportation it is possible to use a

pallet truck. Wooden covers on front and back
must be removed to transport with pallet truck .
For transport through narrow doors:

- Remove the wooden side covers.

- Remove machine from the base (4 screws).

- The machine can be transported on it s side.

- Mount the machine on the base.

- Fix the side covers.

2.1 Preparing for installation

IDEAL 5221
The machine will be delivered ready for

operation.

As an option side tables, left and right ar e
available. These should be mounted so that the
surfaces are flush with the main table.

IDEAL 4850 and 6550

- Place the machine on the enclosed stand (8)
and secure with the 4 screws.

- Place the shelf (9) in the st and.

2.2 Power supply

The name plate is located at the rear of the
machine.

- Data stated on the rating plat e

- Voltage “ V “,

- Frequency “Hz”,

- Power consumption “A”
must correspond to the values of the power
supply unit.

- Earth wire must be available.

- Connect the machine with the mains.

Standard machines are factory-set as follows:
Voltage 220 - 240V (110V - 120V) 1 phase
Frequency 50Hz (60Hz)
