MXR M299 User manual

®

Carbon Copy
Mini Analog Delay

M299

This pedal packs the organic analog warmth and
ease of use of the original Carbon Copy Analog
Delay into an MXR mini housing with added sonic
versatility so that you can make the most out of
your pedalboard real estate.

jimdunlop.com/m299

External Controls

3

2

4

1

5

6

1 MOD switch toggles modulation on/off (orange LED indicates on)

2 REGEN knob sets number of repeats

3 MIX knob controls blend of wet and dry signals

4 DELAY knob sets time between repeats

5 FOOTSWITCH toggles effect on/bypass (blue LED indicates on)

6 BRIGHT switch accentuates delay signal's high end frequencies (blue LED indicates on)

M299 | Carbon Copy® Mini Analog Delay 2

Basic Operation

Power

The Carbon Copy® Mini Analog Delay is powered by the
Dunlop ECB003 9-volt adapter or the DC Brick™, Iso-Brick™,
and Mini Iso-Brick™ power supplies. This pedal cannot be
powered by a battery.

Directions

1 Run a cable from your guitar to M299’s INPUT jack and another

cable from M299’s OUTPUT jack to your amplifier.

2 Start with all knobs set to 12 o’clock.

3 Turn effect on by depressing the footswitch.

4 Rotate REGEN knob clockwise to increase number of repeats or

counterclockwise to decrease it.

5 Rotate MIX knob clockwise to increase ratio of wet to dry signal

or counterclockwise to decrease it. Fully clockwise results in
half wet/half dry mix while fully counterclockwise results in
100% dry signal.

6 Rotate DELAY knob clockwise to increase delay time or

counterclockwise to decrease it.

7 Use a jeweler’s flathead screwdriver to flip the BRIGHT switch

toward heel of pedal to accentuate delay signal’s high end
frequencies (indicated by blue LED).

8 Push in MOD switch to add modulation to your delay signal.

Modulation width and speed can be adjusted internally (remove
bottom plate) with a 3mm slotted screwdriver (see Diagram A).

DIAGRAM A

M299 | Carbon Copy® Mini Analog Delay 3

Specifications

Input Impedance 1MΩ

Output Impedance 1kΩ

Max Input Level

Max Output Level +8 dBV

Noise Floor**

Mix at Max CW -96 dBV

Mix at Max CCW -104 dBV

Delay Distortion <1%, 1 kHz -5 dBV Input

Delay Time 20 ms to 600 ms

Noise Reduction 2:1 ratio

Modulation Speed 0.2 Hz to 2.2 Hz

Bypass True Hardwire

Current Draw 26 mA

Power Supply 9 volts DC

*Regen at max CCW, A-weighted

+5 dBV, 500 Hz
