MXL STUDIO 1 User manual

Marshall Electronics

1910 East Maple Ave.

El Segundo, CA 90245

http://www.mxl-usb.com

1

USB Microphone

Warranty

Marshall microphones are guaranteed against defects in material and workmanship for one year
from date of purchase. Should you encounter any problem with this unit, promptly contact the
company you purchased it from for assistance. The original dated sales receipt will be necessary
for any warranty claim. Do not send any unit directly to us without prior authorization from our
service department! Warranty coverage is limited to repair or replacement (at our option) of the
microphone, and does not cover incidental damages due to use of this unit, nor damage caused by
accidental misuse of this product.

Congratulations on your purchase of the MXL® Studio 1 USB microphone.
MXL® microphones are the result of world-class engineering and manufactur­ing capabilities. They are designed to provide you with outstanding performance
and exceptional value. While we encourage you to review this entire manual,
there are a few key points about handling this microphone that we want you to
familiarize yourself with right from the start.

The MXL® USB mics are a professional quality, cardioid condenser studio
microphone designed specifi cally for recording. Unlike microphones designed
for live performance or lesser dynamic model microphones, this instrument

requires careful handling. Hence, you should observe the following…

ALWAYS… handle the microphone carefully, avoiding sudden shocks such as

dropping or bumping the microphone into other objects.
ALWAYS… maintain a distance of approximately 4 – 6 inches when speaking
or singing into the microphone. You are encouraged to use a pop
fi lter for added protection of the sensitive capsule and to shield
the instrument from saliva and sudden bursts of air.
NEVER… tap the microphone to check if it’s working. The RED LED
behind the microphone’s protective grill will tell you it’s on and
that the correct side is facing you.
NEVER… blow into the microphone to check if it’s working. The RED LED
behind the microphone’s protective grill will tell you it’s on and
that the correct side is facing you.

By following these few basic handling procedures, you can expect a long and
trouble-free relationship with your new microphone. Again, thank you for your
purchase of this outstanding MXL® microphone.

3. Click on the Output tab then select the device named USB Audio CODEC.
You can adjust the headphone volume by moving the fader labeled Output

volume.

4. Next click on the Input tab and select the device named USB Audio
CODEC. You can adjust the microphone volume by moving the Input Volume

fader. The gain of the microphone is very sensitive. For most applications the
fader will be set more towards the left.

A Little Background Information

MXL® condenser microphones use what is known as a cardioid pickup pattern,
which is more sensitive to sound waves arriving at the front of the microphone
as opposed to those arriving from the sides or rear. Unlike other MXL® models,
this microphone benefi ts from being a USB (Universal Serial Bus) device—
meaning this is a plug and play microphone that will interface with Windows
and Macintosh computers without the need for any special drivers. As a USB
device, it carries the added benefi t of not requiring an external microphone

Your computer is now setup to use the MXL® Studio 1 USB microphone with
most recording applications. Some applications will require additional settings
to be changed within the program. Please see your recording software’s manual
for proper setup.

preamp, as is the case with most condenser microphones.

We’ve already mentioned the importance of proper handling, but should you
fi nd yourself recording an outdoor performance, you would be well advised to
use a windscreen as protection for your microphone.

For More Information

For additional information about your MXL® USB microphone, how to contact
technical support, as well as information on other products manufactured by
MXL®, please visit us online at www.mxl-usb.com.

2 11

www.mxl-usb.com
