MXL 990 User Manual
Marshall Electronics
1910 East Maple Ave.
El Segundo, CA 90245
http://www.mxl-usb.com
Marshall Electronics
1910 East Maple Ave.
El Segundo, CA 90245
http://www.mxl-usb.com
Warranty
Marshall microphones are guaranteed against defects in material and workmanship for one year
from date of purchase. Should you encounter any problem with this unit, promptly contact the
company you purchased it from for assistance. The original dated sales receipt will be necessary
for any warranty claim. Do not send any unit directly to us without prior authorization from our
service department! Warranty coverage is limited to repair or replacement (at our option) of the
microphone, and does not cover incidental damages due to use of this unit, nor damage caused by
accidental misuse of this product.
MXL 990 USB Manual
Congratulations on your purchase of the MXL model 990 USB Cardioid Condenser microphone. MXL microphones are the result of world-class engineering
and manufacturing capabilities. They are designed to provide you with outstanding performance and exceptional value. While we encourage you to review this
entire manual, there are a few key points about handling this microphone that
we want you to familiarize yourself with right from the start.
The MXL 990 USB is a professional quality, cardioid condenser studio micro-
phone designed specically for recording. Unlike microphones designed for live
performance or lesser dynamic model microphones, this instrument requires
careful handling. Hence, you should observe the following...
ALWAYS… handle the microphone carefully, avoiding sudden shocks such as
dropping or bumping the microphone into other objects.
ALWAYS… maintain a distance of approximately 4 – 6 inches when speaking
or singing into the microphone. You are encouraged to use a pop
lter for added protection of the sensitive capsule and to shield
the instrument from saliva and sudden bursts of air.
NEVER… tap the microphone to check if it’s working. The MXL logo is the
correct side to speak into.
NEVER… blow into the microphone to check if it’s working.
7. Then select the Audio/MIDI icon in the top row. From the drop down menu
under Audio Input, select the MXL 990 USB as shown in Figure #13 below.
By following these few basic handling procedures, you can expect a long and
Figure #13
trouble-free relationship with your new microphone. Again, thank you for your
purchase of this outstanding MXL microphone.
8. You will then be asked if you really want to change the driver. Select Yes.
The computer will then say it is initializing the audio driver. Wait until this is
A Little Background Information
MXL condenser microphones use what is known as a cardioid pickup pattern,
which is more sensitive to sound waves arriving at the front of the microphone
as opposed to those arriving from the sides or rear. Unlike other MXL models,
done, then close the window.
9. At this point, you should see the meter move when you speak into the micro-
phone. You can now click on the Record button and record your vocals or
dialog using your microphone.
this microphone benets from being a USB (Universal Serial Bus) device—
meaning this is a plug and play microphone that will interface with Windows
and Macintosh computers without the need for any special drivers. As a USB
device, it carries the added benet of not requiring an external microphone preamp, as is the case with most cardioid condenser microphones.
We’ve already mentioned the importance of proper handling, but should you
nd yourself recording an outdoor performance, you would be well advised to
use a windscreen as protection for your microphone.
PLEASE NOTE: As long as the microphone is plugged in when Garage Band is
started, the audio input source settings in Garage Band will be saved until you
change them again, even if you close the program or start a new project.
For More Information
For additional information about your MXL 990 USB microphone, how to contact technical support, as well as information on other products manufactured by
MXL, please visit us online at www.mxlmics.com.
Unpack Your Microphone
Begin by examining the contents of your MXL 990 USB system.
2 11
