Transparency Adapter

Deutschsprachige Fassung auf der Rückseite

Features

• Positive or negative, slide and X-ray films

• Low power consumption

• Light and compact

• Film guide tools included

Transparency scanning

Mustek transparency scanning solution fulfills scanner users’
need in scanning positive, negative, slide, and X-ray films.
Mustek has developed the optional transparency adapters as
slide kits for the scanners. Combining with Mustek flatbed
scanner with this adapters lets users scan a wide range of target
materials to meet their different applications and demands.

Compact or large scale

Different tools are available for different demands. Mustek
provides the optional TA IV for transparency scanning on the
traditional and flexible A4 size scanners. TA IV is ideal tool for
compact scanners, such as ScanExpress 1200 USB plus or 2400
USB scanners. Mustek has developed the slide kit specifically for
the Paragon 1200 SP Pro. For large scale transparency scanning,
there are the A3 size transparency adapters available.

Reliability

In addition to the quality scanning and the on-line help-system,
this scanning package also includes an interactive Tutorial/
Scanning Tips application, detailed on-line manual and its global
access to Mustek’s technical support department. It features a
standard warranty, outstanding technical support and is
manufactured under strict ISO-9001 guidelines.

About Mustek

Mustek was established in 1988 and made the very first and
unique hand-held scanner with a PCMCIA interface for PCs and
Notebooks. This innovative and dynamic scanner pioneer has
matured and diversified their products offerings from scanners
to digital still cameras , LCD projectors, DVD players and UPS
systems for the global market. All production follows ISO 9001,
9002 regulation and adheres to most international industry
standard. They serve the IT community with headquarter in
Taiwan and offices in the USA, China, Japan and Germany.

Technical specifications

Scan Object ....................... Transparency (positive or negative)

................................................. Slide and X-ray films

Scan Area

A3T for A3 PRO .....................................................300 x 430 mm

A3 IIT for ScanExpress A3 ..................................254 x 355,6 mm

TA for 1200 SP ......................................................203 x 254 mm

TA III for 1200 SP Pro / Power Pro ....................... 203 x 254 mm

TA IV for A4 scanners (CCD) ................................ 178 x 152 mm

TA 5 for Be@rPaw 1200F / 2400 .......................... 151 x 106 mm

Dimensions

A3 T for A3 PRO ............................................ 616 x 493 x 70 mm

A3 IIT for ScanExpress A3 ..................... 555,6 x 356,5 x 48,4 mm

TA for 1200 SP .............................................. 545 x 335 x 55 mm

TA III for 1200 SP Pro / Power Pro ................ 545 x 335 x 55 mm

TA IV for A4 scanners (CCD) ......................... 275 x 217 x 13 mm

TA 5 for Be@rPaw 1200F / 2400 ................... 410 x 256 x 40 mm

Minimum System
Requirements

• A respective Mustek scanner
with the optional interface

• At least 16 MB of RAM
(32 MB recommended)

• Recommended 32 MB
free hard drive space

• SVGA video card

Subject to error and technical modification. The actual products supplied may differ in technical features and design from the ones shown here.
