Mustang EFG502BOD, PA-HOWSW Specifications
Mustang Pro Audio Bundles
Small House Of Worship Solution:
Wall Mount
PA-HOWSW - WALL MOUNT 4 SPEAKERS, 1 MIXER, 1 POLE MOUNT AMPLIFER, 2 MICS., 1 WIRELESS MIC.
Mustang Qty. 4
EFG502BOD • Foreground Speaker
5” 70V
• Built-in Transformers
• U-mount Brackets Included
• “Ferrouid” Cooled Tweeters
• Two -way Plastic Sealed Box
• Injected ABS Cabinet
Atlas Qty. 1
PA702 • Pole Mount Amplifer
2x 70 watts
• Recessed Screwdriver Adjustable Tone & Level Controls
• 30Hz – 20kHz Frequency Response
• 70 watts per channel (2) @ 8 ohms
• 30Hz – 20kHz Frequency Response
• Class AB Amplier
AKG Qty. 2
D5 • Dynamic Vocal Mic
Supercardiod
• Polar pattern: supercardioid
• Frequency range: 70 Hz to 20 kHz
• Connector: 3-pin XLR
• Sensitivity: 2.6 mV/Pa (-52 dBV)
Soundcraft Qty. 1
RW5678US • Soundcraft Compact 10
Channel Mixer
• Incredibly easy to use for recording
• Multiple input sources handle any type of mic or instrument
• 3-band input EQ, phantom power, balanced/unbalanced I/O,
dual headphone outs and other pro-grade features
• Flexible true stereo monitoring allows blending live input
and prerecorded tracks
AKG Qty. 1
WMS40PRO/55 • Wireless Lavalier
Microphone
SR40 FLEXX- Diversity Reciever
• Audio Outputs: bal. XLR and
unbal. 1/4” jack, output level
adjustable, at rated deviation:
500 mV rms.
• Modulation: FM
•
Audio Bandwidth: 35 to 20,000 Hz
• Signal/noise ratio: 120/230 V AC
• THD: typ. 0.8% (at rated 1 kHz)
Microphone SR 40 Single: Diversity Reciever, SR 40 Dual: Diversity
Reciever, PT 40 Pro: Microphone,HT 40 Pro: Microphone, CK 55 L:
Clip-on Microphone
PT 40 FLEXX- Microphone
• Modulation: FM
• Signal/Noise Ratio: typ. 110 dB (A)
• RF Output: typ. 10 mW (ERP)
• Battery Life: typ. 30 h
(for 2200 mAh)
• Dimensions: 2.4 x 2.9 x 1.2 in.
• THD: typ. 0.8% (at 1 kHz)
Includes: Options CK 55 L: Clip-on
