Page 1
PROFESSIONAL
Push-in Pop-out Video Wall Mount
For 37” to 60” + (94-152.4cm) LCD, LED and Plasma Displays
Universal Design/VESA Compatible
Fits any hole pattern up to 400x600mm.
Extendable
Extends up to 10.69” for easy access and wiring.
Screen Size Variety
Fits most 37” to 60” at panel screens weighing up to 200lb (91kg).
Adjustment
Features lateral, vertical, horizontal and plumb adjustments that
enables easy operation and simple maintenance.
MPVWP-L46U-PP (BLACK)
Portrait Orientation
Professional Solutions - Unrivaled Value
Mustang’s best value in class Video Wall Mount System features lateral,
vertical, horizontal, and plumb adjustments that enable quick installation,
easy operation and simple maintenance. Our proprietary Push in - Pop out™
Technology allows a single display to be accessed without any disruption to
the rest of the matrix, and the entire grid can be laid out by a single installer.
37”-60” / 94cm-152.4cm 200 LB / 91 KG
Functional Specications
Depth from wall: 3.39” (86mm)
Extension: 10.69” (271mm)
Mounting Surfaces: Wood stud, concrete &
cinder block (with included hardware). Metal Stud
(requires accessories).
Lateral Adjustment
Left to right lateral adjust at
wall plate.
Max Mounting Pattern:
400mm (31.5”) width
600mm (15.7”) height
Push-in Pop-out Technology
Display can be accessed without disrupting
the rest of the matrix.
Easy Installation
Multiple adjustment points make installation fast and easy.
Cable Management
Integrated cable management for a clean look.
Included Hardware
Pre-sorted hardware pack for easy component selection and
installation (hardware for installation to wood studs or concrete
surfaces included).
Load Capacity: 200 LB / 91 KG
Warranty: Limited 10 Years
Vertical Adjustment
One inch of vertical adjustment.
Plumb Adjustment
Adjusts pitch of the screen.
www.mustangav.com
Lock
One touch lock and key system for added
security.
Page 2
PROFESSIONAL
Push-in Pop-out Video Wall Mount
For 37” to 60” (94-152.4cm) LCD, LED and Plasma Displays
MPVWP-L46U-PP (BLACK)
Portrait Orientation
Product Specications
PRODUCT WEIGHT
15lb (6.8kg) 21” x 13” x 5”200lb (91kg) 16.8lb (7.6kg)Scratch resistant
LOAD CAPACITY SHIP WEIGHTFINISH UPC CODECOLORS PACKAGE CONTENTS
Black
Mounting Interface
Max Mounting Pattern
400mm (W) x 600mm (H)
Visit mustangav.com to see the full line of vidamounts LCD/plasma, projector and TV/monitor mounts.
powder coating
100mm
W
X
H
100mm
www.mustangav.com
Package Specications
PACKAGE SIZE
(WxHxD)
200mm
100mm
200mm
X
200mm
300mm
X
200mm
(Black)
MPVWP-L46U-PP
300mm
X
300mm
400mm
X
X
300mm
Mount, wall and screen
mounting hardware,
product manual.
400mm
X
400mm
600mm
X
400mm
