MPT-M44UA
www.mustangav.com
Flat
Tilt
Flat and Tilt Universal Wall Mounts
With Post-Installation Leveling
For 26” to 100”+ LCD, LED and Plasma TVs
MPF-L65UA
MPF-X85UA
MPF-X106UA
MPF-M44UA
MPF-L65UA
MPF-X85UA
26”-55”
32”-75”
37”-90”
446x402mm
660x502mm
832x601mm
150lb
200lb
Click in place installation
Includes optional locking bolt
200lb
MPF-X106UA 46”-100” 1096x601mm 300lb
Model TV Sizes
Max Mounting
Pattern (WxH)
Load
Rating
MPT-L65UA
MPT-X85UA
Model
MPT-M44UA
MPT-L65UA
MPT-X85UA
T80A
TV Sizes
26”-55”
32”-80”+
37”-90”+
Max Mounting
Pattern (WxH)
452x401mm
660x501mm
838x501mm
150lb
200lb
200lb
Load
Rating
Installation
Quick, easy, and ecient installation. Monitor clicks in place when
installed. No need to turn screws that are dicult to see and
reach, unless you feel the need for aditional security, in which case
securing screws are there as well. Post-installation leveling
feature allows ne-tuning when walls are not perfectly straight.
Tilt
Pre-tentioned tilt mechanism with ratcheting handle benets
bottom-heavy displays.
Heavy duty leveling mechanism
Installation Surfaces
Double or triple wood stud structures, depending on model. Also
mounts to structural concrete and cinder block surfaces. For metal
stud installation, use Mustang toggle bolt hardware.
VESA Compatible Universal Design
Series covers all VESA patterns to 1000x600mm. Maximum
universal mounting pattern 1105x629mm in the tilt series and
1096x601mm in the at series.
Construction
Fabricated from high-grade cold rolled steel with durable epoxy
powder coat nish. Includes a complete array of high-grade
fasterners, in a pre-sorted hardware pack for easy selection.
UL Listed.
26”-100”+
MPF-M44UA
POST-INSTALLATION
LEVELING
MPT-X116A
MPT-X116A 46”-90”+ 1105x629mm 300lb
PROFESSIONAL
