Carts and Stands
Collapsible Floor Stand (optional casters)
Mobile Carts and Floor Stands
For 32” to 70” LCD, LED and Plasma TVs
MPM-L751U-G MPS-L751U-G
MPM-L751U-G
MPS-L751U-G
37”-70”
37”-70”
70.75”
68”
150lb
150lb
Optional tempered glass or metal shelf that
easily installs after TV is attached
Model TV Sizes
Max Height
Adjustment
723x501mm
723x501mm
Max Mounting
Pattern (WxH)
Load
Rating
MPS-M44VP MPM-M44VP
MPS-M44VP
32”-55”+ Stand 48”-64.5” 100lb
Model TV Sizes Type
Height
Adjustment
400x400mm
MPM-M44VP 32”-55”+ Cart 48”-64.5” 100lb400x400mm
Max Mounting
Pattern (WxH)
Load
Rating
MPMS-G MPMS-M
Fully Adjustable
Height of display may be continuously adjusted vertically, post-in-
stallation. MPS-M44VP completely collapses to a 6”x34”
footprint.
Variety of Solutions
Portable and semi-portable solutions for a variety of applications.
Expandable Functionality
Compatible with narrow, extended landscape displays in Digital
Signage applications. Optional accessories provide expanded
screen compatibility and functionality.
Installation
Ships completely pre-assembled (MPS-M44VP) or as subassem-
blies that easily and intuitively bolt together. Optional shelves
easily attach pre-or post-installation, without removing the
display.
Heavy Duty Components
Heavy duty joints and casters provide extensive eld durability.
VESA Compatible
Series covers all VESA patterns to 700x500mm (expandable).
Construction
Fabricated from high-grade cold rolled steel and aluminum with
durable epoxy powder coat nish. Includes a complete array of
high-grade fasteners, in a pre-sorted hardware pack for easy
selection .
32”-70”
