Musio B User Manual
MUSIO
User’s Guide
themusio.com
Software Version 1.1.5
TABLE OF CONTENTS
1. Read before using
2. Hello
a. Overview
i. Getting to know Musio
ii. Bundled Accessories
iii. Musio Homepage
iv. Musio Mobile App
b. Getting Started
i. Setting up Musio
ii. Connecting Musio to Wi-Fi
iii. Login
iv. Activation
v. User Registration
vi. Waking Musio up
c. Basics
i. Power On / Off
ii. Screen On / Off
iii. Keyboard
iv. Touch Interactions
v. Waking Musio Up
vi. Talking with Musio
vii. Entering/Using Tutor Mode
d. Musio’s Facial Expressions
i. Expressions of Feelings (Joy, Fear, etc.)
ii. Expressions of States (Idle, Asleep, etc.)
e. Modes
i. Normal Mode
ii. Idle Mode
iii. Sleep Mode
iv. Zen Mode
v. Annoyed Mode
vi. Dizzy Mode
vii. Upside-down Mode
themusio.com
TABLE OF CONTENTS
themusio.com
f. Launcher(App Menu)
g. Settings
i.Display Brightness
ii.Volume
iii.Wi-Fi
iv.Other Settings
v.Sophy
vi.System
h. Users
i. Update
j. Japanese to English Dictionary
3. Warranty Provision
Read before using
Read before using
READ BEFORE USING
In order to minimize the risk of property damage and avoid personal injury, please
read the following information before using Musio.
Handling
Do not hit, crush, or handle Musio roughly. Musio hates to get wet, so keep him away
from Water. Stop using Musio if he got damaged.
Temperature and Environment
Use Musio in an environment between 5 and 35 degrees Celsius (40 and 95 degrees
Fahrenheit). Keep Musio away from heat sources such as open flames and heaters
and avoid direct sunlight. Do not store Musio in extreme heat or cold.
Joints and Moving Parts
Do not forcibly bend or rotate Musio’s moving parts. Doing so may result in damages
and/or breakages.
Assembly
Be careful to avoid injuries to fingers when assembling Musio. In cases where parts
seem difficult to assemble, avoid using excessive force as this can result in damages
and/or breakages.
Connector and Connector Port
Carefully insert the connector into the port on Musio. Do not use excessive force, as
this can result in damages and/or breakages.
Use of the Product by Children
Care is needed when children are using Musio. There is a danger of choking if small
parts are swallowed.
If Irregularities Occur
If you notice abnormal smells or sounds, or see smoke or other irregularities, turn off
Musio and disconnect all cables.
Repair
Do not attempt to repair Musio. Instead, please contact the Musio Support Center
with requests for repairs.
Read before using
READ BEFORE USING
Battery
Do not attempt to replace Musio’s battery. Instead, please contact the Musio Support
Center with requests for repairs.
Tampering
Do not attempt to disassemble or rebuild Musio.
Charging
Do not use a cable or adapter which has been damaged or cut. Do not attempt
to charge Musio in wet or damp places. Avoid touching the power cable more than
necessary when it is plugged in.
Hearing Loss
Do not place the speaker closer than necessary to your ears. There is the risk of
hearing loss.
Interference With Other Devices
Be aware of and obey any notices, directions, and prohibitions when using Musio near
other electronics. Keep Musio a safe distance from medical devices as there is a risk
of interference.
Environments Containing Flammable/Explosive Materials
Do not use Musio in environments where flammable or explosive materials are
present.
Cleaning
If Musio gets dirty, turn off the power and disconnect all cables prior to gently cleaning
with a soft cloth. Avoid getting Musio wet when cleaning.
Disposal
Dispose of Musio in accordance with local waste disposal policies.
Inquiries
For any product-related issues, questions, or for repair requests, please contact
Musio Support Center.
Prolonged heat exposure
Sustained contact with warm surfaces, especially Musio’s heart, for long periods of
time may cause discomfort or injury.
“Hello! I’m Musio!”
Congratulations for adopting Musio, the
robot that wants to be your friend and
learn English together.
Overview
GETTING TO KNOW MUSIO
Front
REAR
Camera
Upper Body
Hands
Lower Body
Heart
Face
Connectors
Power Button
Musio Specifications
Size & weight
Width: 174 mm
Depth: 83 mm
Height: 218 mm
Weight: 850 g
Technical Specifications
Android OS
ARM Coretex quad core
Wi-Fi 802.11b / g / n /
Bluetooth 4.0 Low Energy
Overview
GETTING TO KNOW MUSIO
BACK PANEL
Reset Button
Arduino Pinheads
Arduino Connector
Power Button
Body Lock Switch
USB 2.0 Charging Port
USB 3.0 Charging Port
Tip
!
*Do not force to bend or rotate Musio’s arms. They may be
at risk of getting damaged.
Overview
BUNDLED ACCESSORIES
Connector Cable
USB Power Adapter
Metal Dock
MUSIO HOMEPAGE
Visit the URL: https://themusio.com to register your Musio and use our support
services.
themusio.com
MUSIO MOBILE APP
It is a Musio-only mobile application that can provide Musio’s registration access
and various functions for Friend Plan subscribers.
You can download ｢Musio’s App from the App Store (iOS 8.0 or higher) or Google Play
Store (Android 4.3 or higher).
themusio.com
Getting Started...
SETTING UP MUSIO
Make sure to have a good Wi-Fi connection before setting up Musio. Assist children to
setup as necessary. To turn on Musio, open the flap at the back and press the button
located under it. Afterwards, proceed with the steps below to perfom the initial
setup.
Getting Started
Musio came a long way to Earth and lost a bit of battery
power. Please let Musio charge for 10 hours for full battery.
This is for first time to prolong the battery’s life span.
!
Connect Musio to Wi-Fi
1
Connect Musio to Wi-Fi when the Wi-Fi icon appears in
the center of Musio’s Face Multi-touch Display. Available
Wi-Fi networks will be displayed in order of signal strength.
Choose a network by scrolling through the available
networks by touching the left and right arrows.
Connect to the desired network.
Log in
2
After the Wi-Fi connection is completed and the login
screen is displayed Musio’s face, please log in according to
how you purchased Musio.
If purchased Musio from the Musio homepage
Please login to Musio with ID (mail address) and password
registered when registering as a member on the Musio
homepage.
