Munro sonic EGG 150 User Manual

Operation Manual

EGG 150

MONITORING SYSTEM

EGG 150 MONITORING SYSTEM Operation Manual

EGG 150 Monitoring System

Contents

EGG 150 MONITORING SYSTEM

Dual Input Amplier (Control Panel) Back Pg 5

SETTING UP YOUR SYSTEM

Setup and Operation Pg 6

Positioning Pg 6
Equalisation Pg 7
Midrange Balance Pg 7
Control Unit Pg 7
Protection Pg 7
Running In Pg 8

Dual Input Amplier (Control Panel) Front Pg 4

TECHNICAL INFORMATION Pg 9

SAFETY NOTICE Pg 10

3

EGG 150 MONITORING SYSTEM Operation Manual

EGG 150 Monitoring System

Thank you for purchasing your Munro Sonic EGG 150 Monitoring System, designed by Mr Andy Munro, one of the
world’s leading acousticians and monitor experts, and manufactured in the UK. Your system has been constructed using
the nest quality components and extensively tested to ensure years of trouble free operation.

If something goes wrong, you won’t get left without your speaker system.

If you register your product at www.munrosonic.com/product-registration, your standard 1 year free replacement
warranty (excluding drivers) will be extended free of charge to 2 years. This is unique in the world of studio monitors, and
means that if there is a technical fault caused by a manufacturing defect within the rst 2 years from date of purchase,
then we’ll replace the entire system free of charge, immediately. We only ask for you to cover the cost of returning your
system to us – the rest, we take care of for you. No other company goes this far. We’re able to do this because this system
is so well built.

DUAL INPUT AMPLIFIER (CONTROL UNIT)

FRONT PANEL

7

6

12 345

1

MAIN SWITCH

An illuminated switch for the entire system allows safe power up and shut down without having to access the rear of each

individual Egg monitor.

2

MAIN VOLUME
A precision potentiometer allows continuous listening level control of the main input channel without the need to access the

individual speakers.

3

AUX VOLUME
Independent control of the Aux Input volume provides a useful record/playback comparator (or any other

alternate source input).

4

SOURCE
Source select allows the comparison of two independent inputs. Input sensitivity of the main input can be selected on the rear

panel.

5

MID EQ
This three way switch allows instant comparison of the ‘at’ reference response with a slightly harder mid range or a softer ‘HiFi’

setting. See page 7 for more information.

6

HEADPHONE SOCKET
An independent headphone amplier is used to listen to whichever input is selected. Inserting the headphone jack mutes the

power ampliers.

7

HEADROOM INDICATOR
An LED indicator designed to help protect your Egg system from overload. See Page 7 for more information.

4
