Multi-Tech Systems MTS2BTA User Manual

MultiConnect



Adapter

Serial-to-Bluetooth Adapter

MTS2BTA

MTS2BTA-R

User Guide

User Guide MTS2BTA and MTS2BTA-R MultiConnect Serial-to-Bluetooth Adapter S000370A Rev. A

Multi-Tech Systems, Inc. makes no representations or warranty with respect to the contents hereof and specifically disclaims any implied warranty of merchantability or fitness for any particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.

Revision Date Description

A 03/31/05 Initial release.

Patents

This device is covered by one or more of the following patents: 6,031,867; 6,012,113; 6,009,082; 5,905,794; 5,864,560; 5,815,567; 5,815,503; 5,812,534; 5,809,068; 5,790,532; 5,764,628; 5,764,627; 5,754,589; 5,724,356; 5,673,268; 5,673,257; 5,644,594; 5,628,030; 5,619,508; 5,617,423; 5,600,649; 5,592,586; 5,577,041; 5,574,725; 5,559,793; 5,546,448; 5,546,395; 5,535,204; 5,500,859; 5,471,470; 5,463,616; 5,453,986; 5,452,289; 5,450,425; D353,598; 5,355,365; 5,309,562; 5,301,274. Other patents pending.

Trademarks

Multi-Tech, the Multi-Tech logo, and MultiConnect are registered trademarks of Multi-Tech Systems, Inc. All other brand and product names mentioned in this publication are trademarks or registered trademarks of their respective companies.

Technical Support Country By Email By Phone

France: support@multitech.fr (33) 1-64 61 09 81 India: support@multitechindia.com 91 (124) 6340778 U.K.: support@multitech.co.uk (44) 118 959 7774 U.S. and Canada: support@multitech.com (800) 972-2439 Rest of the World: support@multitech.com (763) 717-5863

Internet Address:

World Headquarters

Multi-Tech Systems, Inc. 2205 Woodale Drive Mounds View, Minnesota 55112 U.S.A. (763) 785-3500 or (800) 328-9717 Fax (763) 785-9874 http://www.multitech.com

http://www.multitech.com

Multi-Tech Systems, Inc. Serial-to-Bluetooth Adapter User Guide (S000370A) 2

Table of Contents

Contents

Chapter 1 – Description and Specifications ..............................................................................................................4

Product Description ....................................................................................................................................................4

Applications ................................................................................................................................................................4

Features .....................................................................................................................................................................4

Product Build Options.................................................................................................................................................5

MultiConnect Package Contents ................................................................................................................................5

AT Commands............................................................................................................................................................5

Handling Precautions .................................................................................................................................................5

General Safety............................................................................................................................................................6

Vehicle Safety........................................................................................................................................................6

Maintenance of the Serial-to-Bluetooth Adapter ....................................................................................................6

Technical Specifications .............................................................................................................................................7

LED Indicators ............................................................................................................................................................8

Chapter 2 – Installation and Cabling ..........................................................................................................................9

Step 1 – Attaching the Adapter to a Fixed Location....................................................................................................9

Step 2 – Connect the Adapter to Your System.........................................................................................................10

Setup Example ....................................................................................................................................................10

Connections for the MultiModem Using AC Power..............................................................................................10

Connections for the MultiModem Using DC Power..............................................................................................10

Chapter 3 – AT Commands .......................................................................................................................................11

AT Command Reference Guide ...............................................................................................................................11

Using AT Commands ...............................................................................................................................................11

Default Settings / Changing Configuration...........................................................................................................11

Setting Parameters..............................................................................................................................................12

Test Procedures Using AT Commands ....................................................................................................................13

Disabling Flow Control Using AT Commands...........................................................................................................14

Configuring to Use DTR for Resetting the MTS2BTA Using AT Commands...........................................................14

Chapter 4 – Peripheral Devices.................................................................................................................................15

Antenna Requirements.............................................................................................................................................15

Pin Assignments for the Serial Port ..........................................................................................................................15

Appendix A – Regulatory Compliance .....................................................................................................................16

Regulatory Compliance Statements .........................................................................................................................16

EMC, Safety, and R&TTE Directive Compliance.................................................................................................16

International Adapter Restrictions........................................................................................................................16

Telecom Requirements for the United States......................................................................................................16

Industry Canada ..................................................................................................................................................16

New Zealand Telecom Warning Notice ...............................................................................................................17

South African Statement......................................................................................................................................17

Other ...................................................................................................................................................................17

Appendix B – Multi-Tech Warranty Statement and Product Repair.......................................................................18

Warranty...................................................................................................................................................................18

Product Repair..........................................................................................................................................................18

Repair Procedures for U.S. and Canadian Customers ........................................................................................18

Repair Procedures for International Customers (Outside U.S.A. and Canada) ...................................................19

Repair Procedures for International Distributors..................................................................................................19

Replacement Parts ..............................................................................................................................................19

Index............................................................................................................................................................................20

Multi-Tech Systems, Inc. Serial-to-Bluetooth Adapter User Guide (S000370A) 3

Chapter 1 – Description and Specifications

Chapter 1 – Description and

Specifications

Product Description

The MultiConnect Serial-to-Bluetooth adapter enables communication between an installed host serial device and a peripheral wireless device. The serial side of the MultiConnect provides transparent serial data-to-Internet protocol conversion, eliminating the need for any hardware modifications. The embedded Bluetooth wireless technology of the MultiConnect provides a secure, standards-based wireless connection between the host and the peripheral device. Bluetooth provides wireless data transfer up to 100 meters, completely eliminating the need for a serial cable connection.

Applications

The MultiConnect adapters will IP-enable any device to provide remote monitoring, control and configuration of any system. The solution is ideal for the following applications:

• Retail Environment ∗ POS (Point of Sale) Devices ∗ Bar Code Scanners ∗ Credit Card Reader

• Restaurant Environment ∗ Order Printer ∗ Receipt Printer ∗ Credit Card Reader

• Outdoor Signs

• Gas pumps

• Security Systems / Surveillance Cameras

• Emergency Vehicles

• Delivery Trucks

• Home Health Care

• Connecting to Other Bluetooth-enabled Devices ∗ Modem ∗ Mobile Phone ∗ Headset ∗ Computer ∗ PDA

Features

Instant Serial Cable Replacement

Running serial cabling can be expensive and sometimes problematic especially if it is in an outdoor environment. With the SocketWireless, you can eliminate the cable and connect your peripheral devices effortlessly with a Bluetooth wireless network. In a point-to-point connection, one SocketWireless is embedded in a host device, such as a PC; the other is attached to a serial peripheral device such as a barcode scanner, receipt printer or scale. Now you can use the wireless network to transfer information between the host and the device for up to 100 meters.

Wireless Host Connection

SocketWireless Bluetooth can also connect to any other Bluetooth-enabled device, such as a PDA or WAN radio increasing user mobility in mission-critical applications such as emergency vehicles, delivery trucks, medical monitoring, and point-of-sale environments. SocketWireless Bluetooth is operating system independent and can be seamlessly embedded in any peripheral device. No application software is needed.

Secure, Robust Communication

SocketWireless Bluetooth complies with the Bluetooth specifications for security which includes 128-bit encryption and 10 alphanumeric Personal Identification Number (PIN) authentication. It utilizes FHSS (Frequency Hopping Spread Spectrum) technology. In addition, SocketWireless Bluetooth uses error correction schemes for guaranteed packet delivery.

Multi-Tech Systems, Inc. Serial-to-Bluetooth Adapter User Guide (S000370A) 4

Chapter 1 – Description and Specifications

Product Build Options

Product Description Region MTS2BTA MTS2BTA-R

Serial-to-Bluetooth Adapter AC-Powered North America and Europe Serial-to-Bluetooth Adapter DC-Powered North America and Europe

MultiConnect Package Contents

AC-Powered Version

• One Serial-to-Bluetooth Adapter

• One antenna

• One mounting bracket

• RS-232 serial cable

• One universal power supply with power cord

• A set of four self-adhesive plastic feet

• One printed Quick Start Guide

• One Serial-to-Bluetooth Adapter product CD containing the adapter drivers, User Guide, Quick Start

Guide, AT Commands Reference Guide, Global Wizard software, PhoneTools (a data communications program), and Acrobat Reader

DC-Powered Version

• One Serial-to-Bluetooth Adapter

• One antenna

• One mounting bracket

• RS-232 serial cable

• One fused power cable

• A set of four self-adhesive plastic feet

• One printed Quick Start Guide

• One Serial-to-Bluetooth Adapter product CD containing the adapter drivers, User Guide, Quick Start

Guide, AT Commands Reference Guide, Global Wizard software, PhoneTools (a data communications program), and Acrobat Reader

Note: Part Supplied by User

Mounting screws (screw shaft diameter =.17" maximum)

AT Commands

AT commands for the Serial-to-Bluetooth Adapter are published in a separate Reference Guide included on the product CD and posted on the Multi-Tech Web site.

Handling Precautions

All devices must be handled with certain precautions to avoid damage due to the accumulation of static charge. Although input protection circuitry has been incorporated into the devices to minimize the effect of this static buildup, proper precautions should be taken to avoid exposure to electrostatic discharge during handing and operation.

Multi-Tech Systems, Inc. Serial-to-Bluetooth Adapter User Guide (S000370A) 5

Chapter 1 – Description and Specifications

General Safety

The adapter is designed and intended to be used in either fixed or mobile applications. In the “Fixed” application, the device is physically secured at one location and not easily moved to another location. In the “Mobile” application, the device may be regularly moved to different locations.

Caution! Maintain a separation distance of at least 20 cm (8 inches) between the transmitter’s antenna and the body of the user or nearby persons. The adapter is not designed for, nor intended to be, used in applications within 20 cm (8 inches) of the body of the user. Such uses are strictly prohibited.

Avoid possible radio frequency (RF) interference by carefully following the safety guidelines below.

• Switch OFF the Adapter when in an aircraft. The use of cellular telephones in aircraft is illegal. It may

endanger the operation of the aircraft and/or disrupt the cellular network. Failure to observe this instruction may lead to suspension or denial of cellular telephone services to the offender, legal action, or both.

• Switch OFF the Adapter in the vicinity of gasoline or diesel-fuel pumps or before filling a vehicle with fuel.

• Switch OFF the Adapter in hospitals and any other place where medical equipment may be in use.

• Respect restrictions on the use of radio equipment in fuel depots, chemical plants, or where blasting

operations are in progress.

• There may be a hazard associated with the operation of your Adapter in the vicinity of inadequately protected

personal medical devices such as hearing aids and pacemakers. Consult the manufacturers of the medical device to determine if it is adequately protected.

• Operation of the Adapter in the vicinity of other electronic equipment may cause interference if the equipment

is inadequately protected. Observe any warning signs and manufacturers’ recommendations.

Vehicle Safety

• Do not use your Adapter while driving.

• Respect national regulations on the use of cellular telephones in vehicles. Road safety always comes first.

• If incorrectly installed in a vehicle, the operation of adapter could interfere with the correct functioning of

vehicle electronics. To avoid such problems, be sure that the installation has been performed by qualified personnel. Verification of the protection of vehicle electronics should be part of the installation.

• The use of an alert device to operate a vehicle’s lights or horn on public roads is not permitted.

Maintenance of the Serial-to-Bluetooth Adapter

Your adapter is the product of advanced engineering, design and craftsmanship and should be treated with care. The suggestions below will help you to enjoy this product for many years.

• Do not expose the adapter to any extreme environment where the temperature or humidity is high.

• Do not attempt to disassemble the adapter. There are no user serviceable parts inside.

• Do not expose the adapter to water, rain or spilled beverages. It is not waterproof.

• Do not abuse your adapter by dropping, knocking, or violently shaking it. Rough handling can damage it.

• Do not place the adapter alongside computer discs, credit or travel cards, or other magnetic media. The

information contained on discs or cards may be affected by the phone.

• The use of accessories not authorized by Multi-Tech or not compliant with Multi-Tech’s accessory

specifications may invalidate the warranty of the MultiConnect Adapter.

• In the unlikely event of a fault in the adapter, contact Multi-Tech Technical Support.

Multi-Tech Systems, Inc. Serial-to-Bluetooth Adapter User Guide (S000370A) 6
