Multi-Tech Systems ISI3334-4, ISI3334-8 User Manual

Models ISI3334/4

ISI3334/8

Intelligent Serial Interface

Card with Integrated

Data/Fax Modems

Hardware/Driver

Installation Manual

Owner's Manual

P/N 82062600 Revision A

MultiModemISI (Hardware and Driver Installation)

This publication may not be reproduced, in whole or in part, without prior expressed
written permission from Multi-Tech Systems, Inc. All rights reserved.

Copyright © 1997 by Multi-Tech Systems, Inc.

Multi-Tech Systems, Inc., makes no representation or warranties with respect to the contents
hereof and specifically disclaims any implied warranties of merchantability or fitness for any
particular purpose. Furthermore, Multi-Tech Systems, Inc., reserves the right to revise this
publication and to make changes from time to time in the content hereof without obligation of
Multi-Tech Systems, Inc., to notify any person or organization of such revisions or changes.

Record of Revision

Revision Description
A Manual released at Revision A.

(1/20/97)

TRADEMARKS

Trademarks of Multi-Tech Systems, Inc. are as follows:
Multi-Tech, MultiModemISI, MultiExpress, and the Multi-Tech logo: Multi-Tech Systems,
Inc.
UNIX: X/Open Co. Ltd.
SCO: The Santa Cruz Operation, Inc.
Pentium: Intel Corporation
PC-DOS: International Business Machines Corporation
Novell, NetWare, NetWare Connect and UNIXWare: Novell Corporation
Xenix: Xerox Corporation
Windows® and WindowsNT® are registered trademarks of Microsoft
All brand names mentioned in this publication are trademarks or registered trademarks of
their respective companies.

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112 U.S.A.

[phone] or [phone]

U. S. FAX [phone]

Fax-Back Service 612-717-5888

Technical Support [phone]

BBS [phone] or [phone]

Internet Address: http://www.multitech.com

Technical Writer: [e-mail]

Contents

Chapter 1 - Introduction and Description

1.1 Introduction to the IntelligentSerialInterface .................................. 6

1.2 Product Description .......................................................................6

1.3 How to Use This Manual................................................................ 7

1.4 T echnical Specifications ................................................................ 8

Chapter 2 - Hardware Installation

2.1 Safety Warnings .......................................................................... 12

2.2 MultiModemISI Installation........................................................... 12

2.3 Determining Current System Settings ......................................... 13

2.4 Hardware Installation Procedure ................................................. 14

Chapter 3 - MultiModemISI Driver Installation

3.1 Introduction..................................................................................20

3.2 Installing the ISI Driver in Windows NT ....................................... 20

3.2.1 Removing the ISI Drivers in Windows NT 3.51...............22

3.2.2 Removing the ISI Drivers in Windows NT 4.0................. 23

3.3 Installing the ISI Driver in Windows 95 ........................................ 23

3.3.1 Removing the ISI Drivers in Windows 95 ....................... 26

3.4 Installation in SCO Open Server 5 .............................................. 27

3.5 The Multi-T ech Installation Script.................................................29

3.6 Activating Ports in SCO Open Server 5....................................... 33

3.6.1 Removing the Driver (SCO Open Server 5) ...................34

3.7 Multi_Setup Utility........................................................................35

3.8 Multi_View Utility Installation .......................................................37

3.8.1 Description File Format................................................... 39

3.8.2 Hot Key Entries............................................................... 39

3.8.3 Terminal Escape Sequences .......................................... 40

3.8.4 Timing Specification........................................................ 40

3.9 Administration Utility .................................................................... 43

iii

Chapter 4 - Service, Warranty and Technical Support

4.1 Software User License Agreement.............................................. 46

4.2 Limited Warranty..........................................................................48

4.2.1 On-line Warranty Registration.........................................48

4.3 Tech Support ............................................................................... 49

4.3.1 Recording MultiModemISI Information............................ 49

4.3.2 Service............................................................................ 50

4.4 About the Multi-Tech BBS............................................................ 51

4.4.1 How to Use the Multi-Tech BBS...................................... 51

4.5 About CompuServe/Internet ........................................................ 52

4.6 About the Multi-Tech Fax-Back Service....................................... 53

Appendixes

Appendix A - Base I/O Address Switch Settings ................................... 56

Appendix B - ISI Testing Utilities ........................................................... 59

iv

Chapter 1 - Introduction and Description

ISI3334/4 Hardware/Driver Installation Manual

1.1 Introduction to the IntelligentSerialInterface

The new IntelligentSerialInterface card, the MultiModemISI, is a
hardware solution for adding fast serial ports to communication
servers and async hosts that have 16-bit ISA-bus architecture. Serial
ports are essential to communication servers, which pool modems
and other communication devices for users on a LAN, and to
asynchronous hosts that provide user access through serial ports.
The MultiModemISI integrates ISI mutiport and
modem technology on a single board. It is a "full sized" add-on card
which supports a high-speed interface up to 115.2K bps per port.
This card has multiple
bps) fax modems providing high speed buffering for multiple serial
ports.

This manual contains product specification, installation instructions,
and technical support information which will assist you in the
installation process. It is assumed that you have basic PC skills at
the very least. Therefore, we have not included step-by-step
instructions for such basic operations as logging in and file editing,
etc.

Enhanced

V.34 (33.6K bps) data/V.17 (14.4K

Enhanced

V.34

1.2 Product Description

The MultiModemISI is ideally suited to use in PC networks
environments because it provides an integrated hardware solution
for remote access for both Windows NT and Novell-based LANs. In
particular, to ensure smooth Novell network integration, the
MultiModemISI ships with a NetWare Loadable Module for NetWare
ConnectTM communication servers that enable it to support state-of­the-art features such as remote dialing and modem pooling. And,
the MultiModemISI easily integrates into the Windows NT platform
since it fully supports Microsoft's Remote Access Server software.
This allows it to comfortably operate with popular network protocols
such as TCP/IP and NetBIOS. The MultiModemISI ships with drivers
for other multiuser operating systems such as SCO® UNIX®, SCO
XenixTM, and SCO UNIXWare®.

The MultiModemISI includes an Intel 16 MHz 80186 proccesor and
256K of RAM that work dynamically to allocate resources to the
most active modems.

6

Chapter 1 - Introduction and Description

Simple to install, the MultiModemISI can be used to add multiport,

Enhanced

as easily as plugging in an expansion card, running the driver
software, and connecting the phone lines.

Network managers have the option of starting with the base four
modem configuration (model #ISI334/4), and then adding four more
modems at a later date without having to use another PC expansion
slot.

This is accomplished by pairing one MultiModemISI with an auxiliary
module (model #ISI3334/EC) interfacing both with on-board
connectors.

Some MultiModemISI on-board components include one jumper
block for activating the number of ports in increments of 4 or 8. One
bank of 8 DIP-Switches for I/O address selection and one IRQ
jumper block, that control both the MultiModemISI and auxiliary
module I/O addressing and IRQ values.

When installing a single MultiModemISI in your PC, the installation
scripts create 8 devices. The first 4 devices are active, however, the
4 devices on the auxiliary module are not active until connected to
the MultiModemISI.

V.34 modem communications to a network host or server

1.3 How to Use This Manual

This chapter begins with a short introduction, followed by a guide
(which you are now reading) to the use of this manual. This manual
contains both hardware and operating system(s) driver installation
procedures, technical support, warranty and BBS information and a
number of appendices for additional information on selected topics.
Hardware configuration and installation procedures are described in
Chapter 2. Chapter 3 describes driver installation procedures
specific to your operating system.

7

ISI3334/4 Hardware/Driver Installation Manual

1.4 Technical Specifications

Tradename

MultiModemISI

TM

Model Numbers

ISI3334/4--Server/Host expansion card with
8 intelligent serial interface (ISI) ports and 4
modems on one ISA-bus expansion card
(shipped with 4 ISI ports and 4 modems
active).

ISI3334/EC--4-modem expansion module
ISI3334/8--Server/Host expansion card with

8 intelligent serial interface (ISI) ports and 8
modems on one ISA-bus expansion card
(shipped with 8 ISI ports and 8 modems
active).

Computer Requirements

· 386, 486, or Pentium®- based PC or
compatible with ISA Bus Architecture

· Microsoft Windows NT 3.5x, SCO's UNIX
System V/386 (Version 3.2, Release 2.0 or
later), SCO's XENIX System V/386 (Version

2.3.2C or later), or UNIXWare (Release 1.1
or later), Novell's Netware

· At least one floppy drive

· 800 blocks of hard disk space for UNIX;
100 K bytes for Windows NT; 50 K bytes for
Novell

8

Chapter 1 - Introduction and Description

Physical/Electrical/Environmental

Dimensions: 13.3" x 4.8" x .6"

33.3 cm x 12.2 cm x 1.5 cm

Baud Rates: 300 to 115.2K bps per port
Bus Type: ISA or EISA
Connectors: Eight RJ-11 for phone connection

Temperature: 32° to 120°F (0° to 50°C)
Power: 1.5 amps @ +5v DC
Base I/O One 16-byte address space per card.

Address: Valid options range from 100h to 3F0h (DIP-

switch setting)

Interrupt One IRQ per card. Valid options
Request: include 2, 3, 4, 5, 7, 10, 11, 12, & 15

(Jumper setting)
Warranty: Two years
Manufactured in Mounds View, MN, U.S.A.

9

ISI3334/4 Hardware/Driver Installation Manual

10

Chapter 2 - Hardware Installation

ISI3334/4 Hardware/Driver Installation Manual

2.1 Safety Warnings

1. Never install telephone wiring during a lightning storm.

2. Never install telephone jacks in wet locations unless the jack is
specifically designed for wet locations.

3. This product is to be used with UL and

4. Never touch uninsulated telephone wires or terminals unless the
telephone line has been disconnected at the network interface.

5. Use caution when installing or modifying telephone lines.

6. Avoid using a telephone (other than a cordless type) during an
electrical storm. There may be a remote risk of electrical shock
from lightning.

7. Do not use the telephone to report a gas leak in the vicinity of
the leak.

2.2 MultiModemISI Installation

This chapter provides you with procedures for installing the
MultiModemISI card(s) in your ISA or EISA bus personal computer
(or compatible with 16 bit ISA slot).

Hardware installation involves:

1) Opening your PC.

2) Setting card configuration (determining I/O address DIP-Switch
setting and IRQ jumper setting).

CUL

listed computers.

12

3) Installing the card into the PC.

Chapter 2 - Hardware Installation

2.3 Determining Current System Settings

When you install a device into your computer, the processor must
have a means of routing information to and from the device and the
device must have a means of gaining the processor's attention.
These are called Input/Output (
Requests
I/O addresses and one IRQ value which are not used by any other
device in your system. When selecting a unique base I/O address,
be sure that the next address is also unused. To determine your
MultiModemISI's current settings, refer to Appendix A and B.

If you are certain that these settings are not already in use, continue
with the hardware configuration and installation. You can install up to
four MultiModemISI cards into your system. Each card is shipped
with its IRQ set at level 10 and a base I/O address of 210 hex.
Check your system’s device settings to see if these values can be
used. If the defaults are already in use, select a unique IRQ and I/O
address and record those values for the hardware and software
installation sections that follow.

Note: If you choose IRQ 3 or 4, you may have to disable a COM
device from your BIOS setup. Also, most 386 or higher compatible
computers will not be able to assign IRQ2 to the MultiModemISI card
because IRQ2 is used for slave interrupt control.

(IRQs

), respectively. The MultiModemISI card requires 16

I/O

) addresses and Interrupt

13

ISI3334/4 Hardware/Driver Installation Manual

2.4 Hardware Installation Procedure

Perform the procedures in Table 2-1 to install the MultiModemISI
card(s) into your PC-ISA bus computer. Installation procedures
include setting the I/O address switch block and the IRQ jumper.
This section may be skipped if the defaults: I/O Address 210 Hex
and IRQ 10 are the values you have selected. However, if you are
installing multiple cards, step 4a of Table 2-1 describes how to
configure your card(s).

Table 2-1

MultiModemISI Installation Procedure

Step Procedure
1 Make sure your computer and any peripheral equipment

connected to it are turned off. Failure to do so may damage both
your ISI card(s) and your PC. The MultiModemISI may be
installed in a PC-AT, 386, 486, or Pentium equivalent ISA or
EISA bus computer.

2 Remove the cover of your computer as instructed in your

computer’s documentation.

14

3 Locate the unused slot(s) which you will be using for your

MultiModemISI card(s), and remove the slot cover(s) per the
instructions in your computer’s documentation.

4 Check the settings of the I/O address switch and the IRQ jumper

to ensure that they are set properly for your installation.

Note: One MultiModemISI can be paired with an auxiliary
module (model #ISI3334/EC) when it interfaces with on-board
connectors attaching both cards; effectively providing 8 modem
functionality.

Chapter 2 - Hardware Installation

Figure 2-1. MultiModemISI/Auxiliary Module Attachment

This installation involves:
i) Changing the

"Modems 4 - 8"

berg jumper to the 8 modem

position on the MultiModemISI (see Figure 2-2).

ii) Attaching both the MultiModemISI and the auxiliary module. This

is accomplished by mating the pin-out connectors to the
MultiModemISI to the auxiliary module; and fastening the
mounting connections (four screws) of the auxiliary module to

the MultiModemISI (see Figure 2-1).
iii) Plugging the MultiModemISI into an available PC slot.
iv) Your installed drivers automatically recognizes the additional 4

modems and allocates your system's resources appropriately.

See Chapter 3 for driver installation procedures.

15

ISI3334/4 Hardware/Driver Installation Manual

16

Figure 2-2. MultiModemISI/Auxiliary Module Components

Step Procedure

4a The default setting for the MultiModemISI’s base I/O address is

210 hex. The default value for the IRQ jumper is IRQ 10.
Choose the IRQ value by covering the appropriate pins with the
shorting plug (supplied). If your system requires a different
setting or if you are installing multiple cards, refer to Appendix B
for a table of valid address settings.

Note: Record any changes you make to these settings and keep
them handy for the software installation section in Chapter 3.

Chapter 2 - Hardware Installation

Step Procedure

5 Install the MultiModemISI card(s) into the selected expansion

slot(s) in the same manner as any other add-on card, as

instructed in your computer’s documentation.
6 Fasten the retaining bracket to the computer chassis and

replace the cover.
7 Your MultiModemISI card(s) requires a modular

LINE JACK

.
This is typically an RJ11C or RJ11W jack, but could also be an
RJ12 or RJ13 jack. To connect the modem(s) to the PSTN
line(s), plug one end of the RJ11 cable(s) that is provided with
the modem into the LINE JACK connector(s) and the other end
into the phone-company-provided RJ11C or RJ11W modular
phone jack(s).

Note: Any cables connected to the computer must be shielded
to reduce interference.

8 Turn power on to the computer and refer to the manual that was

provided with the software you will be using with the
MultiModemISI in order to perform software installation
procedures.

17

ISI3334/4 Hardware/Driver Installation Manual

18

Chapter 3 - MultiModemISI Driver Installation

ISI3334/4 Hardware/Driver Installation Manual

3.1 Introduction

The MultiModemISI ships with a NetWare® Loadable Module
(aioisix.nlm) for NetWare Connect communication Servers, and
drivers for Windows® 95/NT and SCO® Open Server 5®. This chapter
will guide you through the installation of these drivers. Section 3.9
details the Multi-Tech Installation Script, which is executed by a
UNIX operating system.

As with all software, you should make a backup copy of the diskette
you received and use the copy for the installation. If you received a
3½" diskette, the capacity is 720KB. Consult your system manual for
instructions on disk copying. Also, if you have a numeric keypad,
and you intend to use it for the installation process, make sure you
have

"Num Lock"

The process of installing a device driver consists of a modification to
your system. For this reason, only the "
administrator) is allowed to perform the installation. If you cannot
login as the root, you must find the person in your organization who
has this authorization (i.e., password). To begin the driver
installation, login as root. Then proceed with the appropriate section.

on.

super user

" (system

3.2 Installing the ISI Driver in Windows NT

The following procedure describes how to install the ISI in a system
running Microsoft Windows NT 3.51 or NT 4.0, for use with Remote
Access Service (RAS) server, and other communications/fax server
type applications. Unless otherwise noted, these procedures refer to
both NT 3.51 and NT 4.0.

Table 3-1
ISI Driver Installation for Windows NT

Step Procedure

1 Configure and install the ISI Card in an available ISA slot as

described in the installation section of your Owner’s Manual.
2 Power up the NT system.
3 Insert the

20

Multi Modem ISI Driver for Windows NT

diskette.

Chapter 3 - MultiModemISI Driver Installation

Table 3-1 (cont'd)

Step Procedure

4 Run the Setup Utility

Windows NT 3.51 Users

:

In the Program Manager, click on File | Run. In the command
line field, type A:\setup.

Follow the on-screen prompts to complete the installation of the
driver.

Windows NT 4.0 Users

:

Click on Start | Settings | Control Panel and then double click
on Add/Remove Programs. The

Properties

When the

dialog box appears. Click on Install.

Install Program From Floppy Disk or CD-ROM

Add/Remove Programs

box appears, insert the installation diskette into your floppy drive
and click on Next. In the
field, type A:\SETUP.EXE and click on Finish. The

Wizard

loads and the

Command line for installation program

Installation

Welcome

dialog box appears.

After you have read the license information, click on Next to
continue with the installation.

5 The

Destination Directory

accept the default

dialog box appears. Click on Next to

Destination Folder

, or click on

Browse to choose another location.

6 The following message appears:

dialog

The ISICOM Driver is installed successfully. You
can add the ISI cards.

Click on OK to add and configure the ISI card(s).

7 The

ISI Cards

dialog box appears. To add and configure new

cards, click on Add.

21

ISI3334/4 Hardware/Driver Installation Manual

Table 3-1 (cont'd)
Step Procedure

8 The

9 The

Add Card

parameters:

Number of Ports

Depending on the card you are installing, click on the correct

Number of Ports. Factory Default setting is 8 Ports).

I/O Base Address and IRQ

The software defaults to a setting of I/O Address = 200, IRQ = 3.

However, the factory default setting for all ISI Cards is I/O

Address = 210 and IRQ = 10. Click on the drop-down menus for

both parameters and choose I/O Address = 210 and IRQ = 10.

Click on Map Ports to configure and map individual ports.

ISI Port Mappings

as desired. When finished, click on Done to complete the

installation.

At this time your installation in Windows NT 4.0 is complete.

The following icon is created and placed in the

dialog box appears. Configure the following

dialog box appears. Configure each port

Control Panel

:

22

In the future, just double click on this icon to add or configure ISI

cards on your system.

3.2.1 Removing the ISI Drivers in Windows NT 3.51

To remove the ISI drivers in Windows NT 3.51, open the Program
Manager and double click on ISICOM Driver and then double click
on Uninstall ISICOM. Follow the on-screen prompts to complete
the uninstall.

Note: In order to complete an uninstall, you must reboot your
system. Until you do so, certain elements, such as the

Icon

, will still remain.

ISI Cards

Chapter 3 - MultiModemISI Driver Installation

3.2.2 Removing the ISI Drivers in Windows NT 4.0

To remove the ISI drivers in Windows NT, click on Start | Settings |

Control Panel and then double click on Add/Remove Programs.

In the list of programs available for an uninstall, highlight ISICOM

Driver and click on the Add/Remove button. Follow the on-screen

prompts to complete the uninstall.

Note: In order to complete an uninstall, you must reboot your

system. Until you do so, certain elements, such as the

Icon

, will still remain.

3.3 Installing the ISI Driver in Windows 95

The following procedure describes how to install the ISI in a system

running Microsoft Windows 95, for use with Remote Access Service

(RAS) server, and other communications/fax server type

applications.

Table 3-2

ISI Driver Installation for Windows 95

Step Procedure

ISI Cards

1 Configure and install the ISI Card in an available ISA slot as

described in the installation section of your Owner’s Manual.
2 Power up the Windows 95 system.
3 Insert the
4 Run the Setup Utility:

Click on Start | Settings | Control Panel and then double click

on Add/Remove Programs. The

Properties

When the

box appears, insert the installation diskette into your floppy drive

and click on Next. In the

field, type A:\WIN95\SETUP.EXE and click on Finish. The

Installation Wizard

After you have read the Welcome notes, click on Next to

continue with the installation.

Multi Modem ISI Driver for Windows 95

diskette.

Add/Remove Programs

dialog box appears. Click on Install.

Install Program From Floppy Disk or CD-ROM

Command line for installation program

loads and the

Welcome

dialog box appears.

dialog

23

ISI3334/4 Hardware/Driver Installation Manual

Table 3-2 (cont'd)
Step Procedure

5 The

ISI Card Port Count

dialog box appears. Click on the

number of ports you are installing, and then click on Next.

6 The

Destination Directory

accept the default

dialog box appears. Click on Next to

Destination Folder

, or click on Browse to
choose another location. When you are finished, click on Next
to continue with the installation.

7 The

Start Copying Files

menu appears. Click on Next to proceed
with the installation, or click on Back to go back and change the
parameters you have set.

8 The following message appears:

Adding ISI Ports. This will take a few minutes.
Click on OK to proceed.

Click on OK to proceed.

9 The following message appears:

ISI card was successfully installed. You need to
set the base address and IRQ for the card. Please
select the MultiTech ISI Card under MultiPort, in
Device Manager and then select the Properties to
change the settings.

Click on OK to continue.

24

10 The

System Properties

menu is displayed. Highlight MultiTech

ISI Card and click on Properties.

11 In the

MultiTech ISI Card Properties

menu, click on Resources |

Set Configuration Manually.

12 The software defaults to a setting of I/O Address = 200, IRQ = 3.

However, the factory default setting for all ISI Cards is I/O
Address = 210 and IRQ = 10.

Highlight Input/Output Range and click on Change Setting.
Select the proper I/O range from the drop-down value list
(choose 210-217 to match the default setting for the ISI card)
and click OK.

Chapter 3 - MultiModemISI Driver Installation

Table 3-2 (cont'd)

Step Procedure

Highlight Interrupt Request and click on Change Setting.
Select the proper IRQ value from the drop-down value list
(choose 10 to match the default setting for the ISI card) and click

OK.
13 Click on OK.
14 The following message appears (Note: although this message

appears, the settings you just entered match the defaults for the

ISI card. If you used the default settings, you must still power

the unit off):

You have made changes to your hardware settings.

Before your device will work properly, you must

shut down Windows, turn off your computers power,

and then change the settings on the hardware device

to match the settings you selected. For

information about changing settings, see your

hardware documentation.

Do you want to shut down now?

Remove the Installation diskette from your floppy drive and click

on Yes.
15 Power the unit off and then on again and then restart Windows

95.

16 Click on Start | Control Panel and then double click on the

Modems icon. Click on Add | Next.

Windows begins to detect the new Ports. When the detection is

complete, click on Next to accept the

Standard Modem

setting
for the selected port. The same screen will appear for each new
port detected. Click on Next to accept each port setting.

25

ISI3334/4 Hardware/Driver Installation Manual

Table 3-2 (cont'd)
Step Procedure

17 The following message appears:

Your modem has been installed successfully.

Click on Finish and you are returned to the

Properties

menu.

Note: It is recommended that at this time you change the default
speed for each port from 19,200 bps to 115,200 bps to enhance
performance.

At this time your installation in Windows 95 is complete.

3.3.1 Removing the ISI Drivers in Windows 95

To remove the ISI drivers in Windows NT, click on Start | Settings |
Control Panel and then double click on Add/Remove Programs.
In the list of programs available for an uninstall, highlight ISICOM
Driver and click on the Add/Remove button. Follow the on-screen

prompts to complete the uninstall.
Note: In order to complete an uninstall, you must reboot your

system.

26

Chapter 3 - MultiModemISI Driver Installation

3.4 Installation in SCO Open Server 5

The installation utility provided by SCO is called

custom

. This section
is a brief guideline for invoking the utility and installing the driver. The
instructions contained in the following table should only be used on
SCO Open Server 5 systems. When you have completed the steps
in Table 3-3, you will be directed to the Installation Script section of
this chapter for a discussion of the Multi-Tech Installation Script.

Table 3-3
ISI Driver Installation for SCO Open Server 5

Step Procedure

1 If you are installing the driver from your default floppy drive, type

custom and press <Enter> to invoke the

custom

utility. If you
are using a non-default drive, you must inform your system of
the disk drive from which you will be doing the installation and
the size and capacity of the diskette(s).

2 Highlight Software and press <Enter>
3 The main menu displays a screen with options. The Install

option should be highlighted, so press <Enter>. You can move
around the screen by using the cursor keys (e.g., up/down
arrows). If the option you are instructed to select is not
highlighted, use these keys to position the highlight bar over the
appropriate option, and then press <Enter..

4 Highlight From comsco and press <Enter>
5 Be sure that the driver diskette is in the floppy drive and then hit

"Enter" to select the highlighted (default) selection, Floppy Disk
Drive 0. The following message is displayed:

Examining media. Please wait ...

27

ISI3334/4 Hardware/Driver Installation Manual

Table 3-3 (cont'd)
Step Procedure

6 At this point, your system recognizes that you are installing the

Multi-Tech Serial Card Driver and prompts you to select the type
of installation.

Select Full Installation and press <Enter> to continue. As the
installation progresses, the screen displays the following
messages:

Extracting Files...

Executing Multi-Tech Serial Card Driver Init
Script...

7 When the installation has finished, you are prompted with the

following :

Do you wish to continue ? (y/n/q): ?

Type Y and press <Enter>

28

At this point, please proceed with the next section, the

Installation Script

.

Multi-Tech

Chapter 3 - MultiModemISI Driver Installation

3.5 The Multi-Tech Installation Script

This section guides you through the Multi-Tech Installation Script for
SCO and UNIXWare systems. The script requests such information
as how many boards you want to install, what I/O address and IRQ
values (interrupt request) you have selected and how many pseudo
devices you want to create for Multi_View utility. This information
extracts the necessary drivers, which will be linked with your
system's kernel.

Table 3-4
Multi-Tech Installation Script

Step Explanation

1 The first screen requests the number of ISIs you are installing.

If you have more than one ISI, we recommend using the chart in
Table 2-1 in Chapter 2, so that you input the appropriate values
for each card.

Input the number of cards, and press <Enter>.

2 The second screen requests the following:

Enter Number of ports for ISI Board 1 (8 or 16):

Enter 8 and press <Enter>

3 The third screen requests the base I/O address you have

selected for the first card you are installing.
It is important to verify that the address you select for each ISI

does not overlap with existing devices or with another ISI. The

ISI cards use the base I/O address and the next fifteen
addresses.

Note: If the I/O address you select conflicts with an existing

device in your system, you must remove the ISI driver and re­install it.

Supply the base I/O address, and press <Enter>.
For additional information, return toChapter 2 and/or to Appendix

A.

29

ISI3334/4 Hardware/Driver Installation Manual

Table 3-4 (cont'd)
Step Explanation

4 The fourth screen requests the IRQ value for this card.

It is important to verify that the IRQ you select for each ISI does
not overlap with existing devices or with another ISI. Type the
desired IRQ value, and press <Enter>.

Note: if you entered a number greater than “1” at the first
screen, the previous three screens reappear in sequence for
each card you are installing. When you have entered the
necessary information, the installation will continue.

5 The fifth screen requests the following:

Enter the number of pseudo devices to be created
for the use of Multi_View Utility. (1-256):

Note: at this prompt, you must enter a minimum of 8 for each
board installed (i.e., 8 for one card, 16 for two cards, etc.)

Enter the proper value and press <Enter>.

6 The /dev directory holds device-information files used by the

kernel to access the hardware. When you add an ISI, you must
give the ISI ports unique names, so they do not conflict with
existing ports or other devices known to your system. If you use
an existing device name to identify your new ISI ports, the
existing device is “deleted” when the ISI port using its name is
created.

30

The default base name for ISI ports is “
name for printer ports is "

prnl

". If this is acceptable, type Y and

ttyl

”; and the default base

press <Enter>. Proceed to Step 10.
If the default base name is unacceptable, go on to Step 7.

Chapter 3 - MultiModemISI Driver Installation

Table 3-4 (cont'd)
Step Explanation

7 To change the name type N and provide a prefix of less than 5

characters. The base name you select will be used for all ports
on each card you install.

The following information describes the format used in naming
the ISI ports:

Default device name and format: ttyl

ttyl BASENAME

This prefix is applied to all ISI ports on all boards. Base names
are 1-4 characters

b BOARD NUMBER

Values of 1 through 4, depending on the number of ISIs
installed.

x PORT LETTER

Values of A-H for ISI ports. (SCO UNIX/XENIX values A-H
indicate modem ports.)

Device Base Name Selected: _________________

8 Once you have selected a device base name, you are prompted

for a printer base name. This prefix is used to identify each port
that supports a terminal with a printer attached to its auxiliary
port (for transparent printing). You can select a unique base
name, or you can accept the default of “

prnl

” (printer parameters

are outlined in the Multi_Setup Utility section in this chapter).
Printer Base Name Selected: _________________

9 The Multi_View utility initializes the multiple-page capability of

terminals with multiple pages of memory. You are asked how
many pseudo devices (which is the total number of pseudo
devices you wish to make available to the Multi_View utility) to
create. This is the total number of devices available to all Multi­Tech's terminals. You can have a maximum of 256 pseudo
devices in your system.

31

ISI3334/4 Hardware/Driver Installation Manual

Table 3-4 (cont'd)
Step Explanation

10 The confirmation screen lists the values you have selected. If

these values are all correct, type Y and press <Enter> to
continue the installation process.

If there is an error in any of the values displayed, type N and the
first screen is re-displayed. You must then re-enter all of the
information for each card. Please refer to your notes if you have
multiple ISI cards to install.

When you accept the confirmation list (by pressing Y), a series
of messages are displayed while the driver is being installed and
the kernel rebuilt. When control returns to you, press <Enter> to
continue. The following message is displayed:

Installation complete

Press <Enter>.

11 Highlight Host and press <Enter>.

Remove the diskette from the floppy drive.

32

Highlight Exit and press <Enter>.
Type the following commands to reboot the system:
Type sync and press "Enter"
Type sync again and press "Enter"
Type haltsys and press "Enter"

At this time ISI Driver installation is complete.

Chapter 3 - MultiModemISI Driver Installation

3.6 Activating Ports in SCO Open Server 5

SCO Open Server 5 provides a device database which monitors the
activity of serial ports through which users can log onto the host. If
your ISI ports are used by terminals (i.e., to allow users to log onto
your host), you must create an entry in the system's device
database, which furnishes specific information for the terminals that
will be used on each ISI port. The database is referenced each time
a user attempts to login. If there is no database entry for a particular
terminal, access to the host is denied.

Table 3-5
Creating Device Entries with SCO's sysadmsh

Step Procedure

1 Power up your system and take note that the firmware for each

ISI gets loaded successfully. If the firmware for a given ISI card
does not get loaded, none of its ports will be accessible (should
this happen, see the Multi-Tech's Administrative Utility section in
this chapter).

2 The device database can be modified in two ways. To create

terminal accounts with default settings, type /tcb/bin/
ttys_update. To customize the terminal entries, you must create
them individually by entering the system administrator's shell
(which means you must be logged in as the root user). You can
enter the administrator's shell by typing: sysadmsh press
<Enter>

3 You can create device entries for each port of your ISI card(s) by

selecting the following options from the database menu:

Accounts | Terminal | Create

4 Enter the complete name of the first device you want to create,

substituting the base name, board number and port letter for the
parameters: ttylbx. (Use a lower case x value for local DTE-­terminal--support, an upper case X value for modem control for
each port you want to enable). The port status can be altered
later; however, one setting must be selected at this time.

33

ISI3334/4 Hardware/Driver Installation Manual

Table 3-5 (cont'd)
Step Procedure

5 Repeat this process for each port on each board you have

installed. Record the settings you select for each port.

6 Using the device names created in the previous section, type the

following command for each port you wish to activate at this
time:

enable

7 Repeat this command for each port you wish to activate, using

the lower case letter for local terminal usage or upper case for
modem control.

Note: Only one of the options (i.e., modem control or local
terminal access) should be enabled for any port at one time. For
example, you cannot enable ttyl1a and then enable ttyl1A. To
change the status of a port, disable the current status (disable
ttyl1a) and then enable it for the desired status (enable ttyl1A).

ttylbx

3.6.1 Removing the Driver (SCO Open Server 5)

If you find it necessary to remove the Multi-Tech Serial Card Driver,
you should enter the configuration utility (i.e., custom for SCO Open
Server 5) and follow the instructions to remove the entire driver and
to rebuild the kernel without the ISI driver. If it is necessary to re­install the driver, due to I/O address or IRQ overlap, you must
remove the driver first.

34

3.7 Multi_Setup Utility

This section guides you through the Multi-Tech Setup Utility for SCO
Open Server 5.0 systems. The Multi_Setup utility lets you set
various parameters for Multi-Tech's ISI card ports; such as,
transparent printing options, high baud settings (above 38400 bps),
and hardware flow control. All the changes made by the Multi_Setup
utility are in effect until the system is rebooted or until the option is
changed using Multi_Setup.

Multi_Setup has a database of “on” and “off” strings for the
transparent printing option through commonly-used terminal
emulations. If terminal type in use is not recognized by Multi_Setup,
Multi_Setup checks the
escape sequences for transparent printing through that terminal
type.

Multi_Setup options are provided in Table 3-7.

Table 3-6. Multi_Setup Options
Command-line

Options Feature

Chapter 3 - MultiModemISI Driver Installation

termcap

database to extract the “po” and “pf”

-h Prints the Help file.

-a Displays current setting for printer

configuration options.

-c cps Specifies the printer speed in characters per
second. Default value of 100 cps.

-b bufsize Specifies the buffer size for transparent
printing. Valid range is any integer greater
than 0, as specified by your printer. The
default value is 250 characters.

-T term Sets the transparent printing escape
sequences to that of the terminal specified
by term. This parameter has access to the
look-up table in the terminal database built
into Multi_Setup. If the terminal is not
recognized by Multi_Setup, then the
termcap database is used to find the On and
Off escape sequences for transparent
printing.

35

ISI3334/4 Hardware/Driver Installation Manual

Table 3-6 (cont’d)
Command-line

Options Feature

-n tty Specifies the tty port. If tty is not specified,

then the operation is carried on the standard
input terminal.

-B high/low “-B high” sets the ISI port baud rate to the
high settings (see the conversion table
below). “-B low” returns the ISI port to
standard UNIXWare baud settings.

UNIX Specifies Port Hardware Operates at:

300 bps 57600 bps
1200 bps 115200 bps

-f cts/nocts “-f cts” forces hardware flow control on the
ISI port, overruling application software
settings where applicable. “-f nocts” allows
the hardware flow control setting to be
determined by the application software.

36

-s string Sets the “on” and “off” strings for

transparent printing. These strings must be
specified in the same order and both strings
must be specified. Unprintable control
characters must be entered as three octal
digits with padded zeros, if necessary, and
be preceded by a "\".

For example, the escape character can b
entered as \033. The “on” and “off” strings
can be specified within the quotes as a
string or as two strings separated by a
comma.

-s “\022\011C \022\011\D
or

-s “\022\011C”, “\022\011\D”

Chapter 3 - MultiModemISI Driver Installation

3.8 Multi_View Utility Installation

This section guides you through the Multi_View Utility for SCO and
UNIXWare systems. During the installation of the ISI4608 drivers,
you will also install the Multi_View utility for multiple-page terminals.
This section profiles the Multi_View utility and gives you the
necessary information to create a Multi_View information file.

Once installed, Multi_View can be invoked by typing the following
command:

Multi_View [ options]

The Multi_View initializes the multiple-page capability of terminals
with multiple pages of memory. While Multi_View works even on a
dumb terminal (without multiple pages of memory), your terminal(s)
should have multiple pages of memory and be capable of retaining
the position of the cursor on each page to get the proper effect.

Most state-of-the-art terminals have multiple pages of memory,
which allow them to switch between sessions. Each page of
memory available on the terminal allows its user to establish another
session on the host. The multiscreen capability of the terminal
stores the screen information and the cursor position for each
session to a different page of memory.

Multi_View allows the host to process the session-switching hot keys
and issue the necessary escape sequence to the terminal so that the
appropriate page is displayed on screen. Multi_View treats each
new screen opened by the user as a virtual screen and maintains
mapping between each virtual screen created and a page of memory
on the terminal. The number of virtual screens and pages of memory
available are dependent on the terminal emulation, the particular
terminal being used, and the number of pseudo devices created by
the system administrator during installation.

In an ideal case, there can be as many virtual screens as there are
pages of memory on the terminal. If there are more virtual screens
specified than there are pages of memory, then two virtual screens
may be mapped to a single page of memory, in which case, both
sessions’ screens are displayed when that page of memory is
recalled.

37

ISI3334/4 Hardware/Driver Installation Manual

Once Multi_View is successfully able to read the terminal description
and initialize the terminal, it comes up with a message displaying the
hot-key sequence for “help”.

The following hot keys are defined:

• Go to nth virtual screen

• Create new virtual screen

• Switch between current and previous screens

• Provides help on hot keys

• Quits Multi_View with an exit status of zero

• Ends Multi_View with a non-zero exit status

To define your own terminal capability database, refer to the
Description File Format section below.

The following options are defined:

Options Description

-h Prints the help file. Multi_View uses the

environment variable MTDSPLY to choose
the utility to display this file. If no such
variable is found in the environment, then
Multi_View uses the “pg” utility.

38

-t This option is used to inform Multi_View to

use a terminal description that is different
from the one specified by the TERM variable
in the user environment.

-f This option lets the user instruct Multi_View
to read the terminal descriptions from a
different file than the default description file.
The default description file is “

msfile

”.

usr/bin/

Chapter 3 - MultiModemISI Driver Installation

3.8.1 Description File Format

A description file may contain descriptions for multiple terminal
types. Each terminal entry should be separated by a blank line. The
first line for each terminal contains the various names by which that
terminal is known. There are three types of entries for each terminal
emulation: 1) hot key entries, 2) terminal escape sequences, and 3)
timing specifications.

3.8.2 Hot Key Entries

These entries have three columns. The first column specifies a
mnemonic. Each mnemonic is associated with a specific action
taken by Multi_View. The mnemonics are as follows:

Mnemonic Description
vs Identified the virtual screen entry. An entry

will be present for each virtual screen that
needs to be opened by Multi_View.

sw Identifies the hot key sequence for switching

between two virtual screens.

cm Identifies the hot key sequence that

instructs Multi_View to create a new virtual
screen.

lm Identifies the hot key sequence for

displaying help on the hot keys.

qm Identifies the hot key sequence to exit

Multi_View with a zero exit status.

em Identifies the hot key sequence to exit

Multi_View with a non-zero exit status.

The second column contains the keystroke sequence that needs to
be pressed to make the action described by the mnemonic in the
first column to take place.

The third column specifies the escape sequence sent by the terminal
to Multi_View when the key combination specified in column two is
pressed.

39

ISI3334/4 Hardware/Driver Installation Manual

In other words, these entries tell Multi_View that the terminal sends
the escape sequence specified in column three to Multi_View when
the keystrokes specified in column two are pressed and that
Multi_View should take the action specified in column one whenever
it receives the characters specified in column three.

3.8.3 Terminal Escape Sequences

The terminal escape sequence entries describe the escape
sequence that needs to be sent to the terminal. The first column
contains a mnemonic. The mnemonics are described below:

Mnemonic Description
ps Describes the escape sequence that needs

to be sent to the terminal to switch to the
appropriate physical page. The physical
pages are numbered in the order they are
specified in the description file.

clear Specifies the escape sequence to clear the

screen.

The second column has the character sequence that needs to be
sent to the terminal by Multi_View.

40

3.8.4 Timing Specification

The timing specification is the interval in tenths of a second that the
utility waits before checking for an escape sequence. The timing
specification is defined below:

Mnemonic Description
time Specifies the interval, in units of 0.1

seconds, Multi_View will wait while reading
characters before checking for escape
sequences.

Chapter 3 - MultiModemISI Driver Installation

A sample file for the Wyse50 terminal is provided in the following
example:

wy50 wyse50 w50 ; line 1

vs Shift_F1 \001' \015 ; line 2
vs Shift_F2 \001a\015 ; line 3
sw Shift_F3 \001b\015 ; line 4
cm Shift_F4 \001c\015 ; line 5
cm Shift_F5 \001d\015 ; line 6
lm Shift_F6 \001e\015 ; line 7
qm Shift_F7 \001f\015 ; line 8
ps \033w0 ; line 9
ps \033w1 ; line 10
clear \033+ ; line 11
time 1 ; line 12

Line 1 Gives all the different names that the Wyse50 terminal is

known.

Line 2 Specifies the virtual screen 0 settings. When the help

screen is displayed, <Shift>+<F1> is displayed for the
virtual screen 0. The entry means that the terminal is
going to send a string with the first ASCII character
being start of header (01 Hex), second character a
hyphen (-), and the last character a carriage return
<CR> when <Shift>+<F1> is entered on the terminal
and that Multi_View is switched to the shell/process

associated with virtual screen 0.
Line 3 Specifies the entry for virtual screen 1.
Lines 4-8 Describes the hot keys to switch between the current

and previous virtual screens, create a new virtual

screen, display the help on the hot keys, quit Multi_View

with a zero exit status and end Multi_View with a non-

zero status respectively.
Lines 9,10 Describes the physical pages on the terminal. The

second string on each line gives the escape sequence

that needs to be sent out to the terminal to switch to the

appropriate physical page.
Line 11 Clear string to clear the screen.
Line 12 Specifies at least a 0.1 second wait in reading data

before going ahead and check for hot keys.

41

ISI3334/4 Hardware/Driver Installation Manual

Each character in the escape sequence or hot key can be specified
as an ASCII character if it is printable. If not printable, then it should
be specified in an octal format with leading 0's, if needed, and
preceded by a “\”. For example, an ASCII escape character can be
specified as “\033”.

Do not switch the screen while outputting as it may break the escape
sequence sent to the terminal. When there is more than one virtual
screen, all outputs from the inactive virtual screens will be blocked.
The virtual screen the user is currently working on is the only active
screen.

The fullest potential of Multi_View is realized on a multiscreen
terminal; however, Multi_View can be used on a dumb terminal that
has only a single page of memory. When there is only one page, the
screen output is unavoidably garbled from different virtual screen
outputs.

Some important ASCII unprintable characters and their octal values
are listed below.

SOH (^a) \001 STX (^b) \002
ETX (^c) \003 EOT (^d) \004
ENQ (^e) \005 ACK (^f) \006
ESC (^[) \033 Newline (NL) \012
Carriage
Return (CR) \015

42

Some known limitations are presented in the following listing:

• No null characters are allowed in the hot keys.

• No hot key can be a complete substring of another hot key.

Chapter 3 - MultiModemISI Driver Installation

3.9 Administration Utility

Multi-Tech also provides an administrative utility called
"

Multi_Admin

boards. This section guides you through the Administration Utility for
SCO and UNIXWare systems. This interactive menu utility displays
various types of Multi-Tech's multiport boards that may be installed
in your system. You can specifically observe the status and
statistics of any installed multiport board or any of its ports (e.g.,
MultiClusterU, MutliModemISI or ISI4608).

This utility periodically updates the statistics and status information
for selected board and/or ports. The displayed statistics are self­explanatory.

The -v option provides detailed information and can be used to
analyze problems when calling Multi-Tech's technical support:

While you can view statistics and status on-screen, you can also
store them to a log file and fax the log to a technical support member
at Multi-Tech to troubleshoot.

" which aids in troubleshooting Multi-Tech's multiport

Usage: Multi_Admin [ -v ]

43

ISI3334/4 Hardware/Driver Installation Manual

44

Chapter 4 - Service, Warranty and

Technical Support

ISI3334/4 Hardware/Driver Installation Manual

4.1 Software User License Agreement

The ISI drivers and firmware are licensed by Multi-Tech Systems,
Inc. to the original end-user purchaser of the product, hereafter
referred to as “Licensee.” The License includes the distribution
diskette, other accompanying programs, and the documentation.

The ISI drivers and firmware, hereafter referred to as “Software,”
consists of the computer program files included on the original
distribution diskette.

Licensee agrees that by purchase and/or use of the Software, he
hereby accepts and agrees to the terms of this License Agreement.

In consideration of mutual covenants contained herein, and other
good and valuable considerations, the receipt and sufficiency of
which is acknowledged, Multi-Tech Systems, Inc. does hereby grant
to the Licensee a non-transferrable and non-exclusive license to use
the Software and accompanying documentation on the following
conditions and terms:

The software is furnished to the Licensee for execution and use on a
single computer system only and may be copied (with the inclusion
of the Multi-Tech Systems, Inc. copyright notice) only for use on that
computer system.
The Licensee hereby agrees not to provide or otherwise make
available any portion of this software in any form to any third party
without the prior express written approval of Multi-Tech Systems,
Inc.

46

Licensee is hereby informed that this Software contains confidential,
proprietary, and valuable trade secrets developed by or licensed to
Multi-Tech Systems, Inc. and agrees that sole ownership shall
remain with Multi-Tech Systems, Inc.

The Software is copyrighted. Except as provided herein, the
Software and documentation supplied under this agreement may not
be copied, reproduced, published, licensed, sub-licensed,
distributed, transferred, or made available in any form, in whole or in
part, to others, without expressed written permission of Multi-Tech
Systems, Inc. Copies of the Software may be made to replace worn
or deteriorated copies for archive or back-up procedures.

Chapter 4 - Service, Warranty and Tech Support

Licensee agrees to implement sufficient security measures to protect
Multi-Tech Systems’, Inc. proprietary interests and not to allow the
use, copying or transfer by any means, other than in accordance
with this agreement.

Licensee agrees that any breach of this agreement will be damaging
to Multi-Tech Systems, Inc.

Licensee agrees that all warranties, implied or otherwise, with regard
to this Software, including all warranties of merchantability and
fitness for any particular purpose are expressly waived, and no
liability shall extend to any damages, including consequential
damages, whether known to Multi-Tech Systems, Inc. It is hereby
expressly agreed that Licensee’s remedy is limited to replacement or
refund of the license fee, at the option of Multi-Tech Systems, Inc.
for defective distribution media. There is no warranty for misused
materials.

If this package contains both 3.5" and 5.25" disks, they are provided
only to facilitate use on a single computer. Neither this Software nor
the accompanying documentation may be modified or translated
without the written permission of Multi-Tech Systems, Inc.

This agreement shall be governed by the laws of the State of
Minnesota. The terms and conditions of this agreement shall prevail
regardless of the terms of any other submitted by the Licensee. This
agreement supersedes any proposal or prior agreement. Licensee
further agrees that this License Agreement is the complete and
exclusive Statement of Agreement, and supersedes oral, written, or
any other communications between Multi-Tech Systems, Inc. and
Licensee relating to the subject matter of this agreement is not
assignable without written permission of an authorized agent of
Multi-Tech Systems, Inc.

47

ISI3334/4 Hardware/Driver Installation Manual

4.2 Limited Warranty

Multi-Tech Systems, Inc. (
free from defects in material or workmanship for a period of ten
years from the date of purchase, or if proof of purchase is not
provided, ten years from date of shipment. MTS MAKES NO
OTHER WARRANTY, EXPRESSED OR IMPLIED, AND ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED.
This warranty does not apply to any products which have been
damaged by lightning storms, water, or power surges or which have
been neglected, altered, abused, used for a purpose other than the
one for which they were manufactured, repaired by the customer or
any party without MTS’s written authorization, or used in any manner
inconsistent with MTS’s instructions.

MTS’s entire obligation under this warranty shall be limited (at MTS’s
option) to repair or replacement of any products which prove to be
defective within the warranty period, or, at MTS’s option, issuance of
a refund of the purchase price. Defective products must be returned
by Customer to MTS’s factory transportation prepaid.

MTS WILL NOT BE LIABLE FOR CONSEQUENTIAL DAMAGES
AND UNDER NO CIRCUMSTANCES WILL ITS LIABILITY EXCEED
THE PURCHASE PRICE FOR DEFECTIVE PRODUCTS.

“MTS”

) warrants that its products will be

4.2.1 On-line Warranty Registration

48

If you wish to register your modem on-line, you can do so at the
following address:

http://www.multitech.com/support/register.htm

4.3 Tech Support

Multi-Tech has an excellent staff of technical support personnel
available to help you get the most out of your Multi-Tech product. If
you have any questions about the operation of this unit(s), call 1­800-972-2439. Please fill out the information (below), and have it
available when you call. If you require service, the tech support
specialist will advise you in Multi-Tech's service procedure (Section

4.3.2).

4.3.1 Recording MultiModemISI Information

Please fill in the following information on your Multi-Tech product.
This will help tech support in answering your questions.

Model No.: _________________________________
Serial No.: _________________________________

Firmware Version: _________________________________
Driver Version: _________________________________

Operating System: _________________________________
COM Port #: _________________________________
IRQ Setting: _________________________________

Chapter 4 - Service, Warranty and Tech Support

Please note the status of your MultiModemISI before calling tech
support (e.g., screen messages, diagnostic test results, problems
with a specific application, etc). Use the space below to note status:

49

ISI3334/4 Hardware/Driver Installation Manual

4.3.2 Service

If your tech support specialist decides that service is required, your
unit may be sent (freight prepaid) to our factory. Return shipping
charges will be paid by Multi-Tech Systems (within North America).

Include the following with this product:

• a description of the problem.

• return billing and return shipping addresses.

• contact name and phone number.

• check or purchase order number for payment if the
MultiModemISI is out of warranty. (The standard repair charge is
$95. This price is valid at the time of this publication but could
change in the future. Check with your technical support
specialist.)

• if possible, note the name of the technical support specialist with
whom you spoke.

If you need to inquire about the status of the returned product, be
prepared to provide the serial number of the product sent (see
Section 4.3.1).

50

Send MultiModemISI to this address:

MULTI-TECH SYSTEMS, INC.

2205 WOODALE DRIVE

MOUNDS VIEW, MINNESOTA 55112

ATTN: SERVICE OR REPAIRS

Chapter 4 - Service, Warranty and Tech Support

4.4 About the Multi-Tech BBS

Multi-Tech Systems maintains a Bulletin Board Service (
customers. The information available via the BBS includes: new
product information, product upgrade data, problem solving tips, and
a message service for you to leave questions for which you would
like additional information. The phone number for the Multi-Tech
BBS is [phone] or [phone] (U.S.A. and Canada).

The BBS can be accessed by any asynchronous modem operating
at speeds of 28,800-1200 bps (V.34 and downward compatible) with
a setting of word length of 8 bits, 1 stop bit, and no parity.

BBS

) for its

4.4.1 How to Use the Multi-Tech BBS

To use Multi-Tech's BBS, perform the following steps.

1. Dial our BBS at 1-800 392-2432 (U.S.A. and Canada) or 612-

785-3702 (International).

2. Set your computer or communications program to "8N1", and to

emulate ANSI (e.g., with MultiExpress software, press ALT-S
and choose "ANSI").

3. At the prompt, type your first name, last name, password, then

hit RETURN. If you are a first time caller, after you hit RETURN
the BBS asks if your name is spelled correctly. If you say yes,
our questionnaire is displayed. You can use our BBS on your
first call.

4. There are four BBS areas: the Main Menu, the Files Menu,

Bulletins (from the main Menu), and the Message Menu. All
Bulletins are Menu-driven. To read the Bulletins, enter the
number of the bulletin you wish to read.

5. File Menu: from the Main Menu, type F: and the Files are

displayed. If you want a list of directories, type L (list directory)
and then type L again for a list of all directories. If you do not
type the second L, you will list all of the files on the BBS. At the
list of the directories, select the number of directories required. A
list of files and a description for each of the files is displayed.
Select a file that you would like to download; if you already know
the file name, type D at the Files Menu to download the selected
file(s). Press V to view a text file.

51

ISI3334/4 Hardware/Driver Installation Manual

6. At the Message Menu, you can leave a message to the Sysop
(you can not read messages at this point). The BBS will tell you
if you have a personal message (mail). At the prompt

you like to read it now?),

your message(s) when you first access the BBS.

type R for read now. You must read

4.5 About CompuServe/Internet

In addition to the BBS, Multi-Tech provides support through
CompuServe's Modem Vendor Forum (

MULTITECH

operating procedures.
Multi-Tech is a commercial provider on the Internet, and we retrieve

e-mail messages from the following mailboxes on a periodic basis:

. Refer to your CompuServe documentation for special

GOMODEMVEN

(would

) under

GO

[e-mail]
[e-mail]
[e-mail]
[e-mail]

If you prefer to receive support via the Internet, you can contact
Tech Support via e-mail at:

http://www.multitech.com/_forms/email_tech_support.htm

Multi-Tech's presence includes a Web site at:

http://www.multitech.com

and an ftp site at:

ftp://ftp.multitech.com

Marketing Dept.
Sales Dept.
International Marketing & Sales
Publications Dept.

52

Chapter 4 - Service, Warranty and Tech Support

4.6 About the Multi-Tech Fax-Back Service

Multi-Tech's fax-back system provides 24-hour access to sales,
marketing, and technical literature. Dial 612-717-5888, follow the
voice prompts, and request document number 10 for a catalog of
available documents.

For convenience, have your fax number handy:________________ .
From the catalog of available documents, you can order newsletters,
white papers, press releases, etc. from the sales and marketing
index (pages 1-4), or order basic modem operation and
troubleshooting guides from the technical support and engineering
index. Just enter the applicable FB Doc. # from the left column of
the catalog.

53

ISI3334/4 Hardware/Driver Installation Manual

54

Appendixes

ISI3334/4 Hardware/Driver Installation Manual

Appendix A - Base I/O Address Switch Settings

The table below provides the DIP-Switch settings for valid base I/O
addresses of the ISI4608. The switches can be set to "OPEN" (O in
the table below) or to "CLOSED" (C in the table below). Holding the
board with the switch facing you (reading numbers 1-8 left to right),
the "UP" position for the switch is OPEN, and the "DOWN" position
is CLOSED. "S1" below is labeled as "1" on the left side of the
switch and so on, through S8. For an example, turn to page B-2 and
compare the default switch settings with the address 200h listing.

Table A-1 Address Switch Settings
I/O Addr. DIP-Switch Settings

(hex) S1 S2 S3 S4 S5 S6 S7 S8

100 CCCCCO CC
108 O CCCCO CC
110 C O CCCO CC
118 OOCCCO CC
120 C C O CCO CC
128 O C O CCO CC
130 C OOCCO CC
138 OOOCCO CC
140 C C C O C O CC
148 O CCO C O CC
150 C O C O C O CC
158 OOC O C O CC
160 C C OOC O CC
168 O C OOC O CC
170 C OOOC O CC
178 OOOOC O CC
180 CCCCOOCC
188 O CCCOOCC
190 C O CCOOCC
198 OOCCOOCC
1A0 C C O C OOCC
1A8 O C O C OOCC
1B0 C OOC OOCC
1B8 OOOC OOCC
1C0 C C C OOOCC
1C8 O CCOOOCC

56

Appendix A - Base I/O Address Switch Settings

Table A-1 (cont'd)

(hex) S1 S2 S3 S4 S5 S6 S7 S8

1D0 C O C OOOCC
1D8 OOC OOOCC
1E0 C C OOOOCC
1E8 O C OOOOCC
1F0 C OOOOOCC
1F8 OOOOOOCC
*200 CCCCCCO C

208 O CCCCCO C
210 C O CCCCO C
218 OOCCCCO C
220 C C O CCCO C
228 O C O CCCO C
230 C OOCCCO C
238 OOOCCCO C
240 C C C O CCO C
248 O CCO CCO C
250 C O C O CCO C
258 OOC O CCO C
260 C C OOCCO C
268 O C OOCCO C
270 C OOOCCO C
278 OOOOCCO C
280 CCCCO C O C
288 O CCCO C O C
290 C O CCO C O C
298 OOCCO C O C
2A0 C C O C O C O C
2A8 O C O C O C O C
2B0 C OOC O C O C
2B8 OOOC O C O C
2C0 C C C OOC O C
2C8 O CCOOC O C
2D0 C O C OOC O C

* Denotes default setting

57

ISI3334/4 Hardware/Driver Installation Manual

Table A-1 (cont'd)

(hex) S1 S2 S3 S4 S5 S6 S7 S8

2D8 OOC OOC O C
2E0 C C OOOC O C
2E8 O C OOOC O C
2F0 C OOOOC O C
2F8 OOOOOC O C
300 CCCCCOO C
308 O CCCCOO C
310 C O CCCOO C
318 OOCCCOO C
320 C C O CCOO C
328 O C O CCOO C
330 C OOCCOO C
338 OOOCCOO C
340 C C C O C OO C
348 O CCO C OO C
350 C O C O C OO C
358 OOC O C OO C
360 C C OOC OO C
368 O C OOC OO C
370 C OOOC OO C
378 OOOOC OO C
380 CCCCOOO C
388 O CCCOOO C
390 C O CCOOO C
398 OOCCOOO C
3A0 C C O C OOO C
3A8 O C O C OOO C
3B0 C OOC OOO C
3B8 OOOC OOO C
3C0 C C C OOOO C
3C8 O CCOOOO C
3D0 C O C OOOO C
3D8 OOC OOOO C
3E0 C C OOOOO C
3E8 O C OOOOO C
3F0 C OOOOOO C
3F8 OOOOOOO C

58

Appendix B - ISI Testing Utilities

This disk contains two files that are to be used in conjunction with ISI
boards. These files are described in two sections: 1) Operation with
factory default settings, and 2) Operation with other than the factory
default settings. These files are:

ISI3334.BIN
3334TERM.EXE

Note: This program is a DOS utility.

1. OPERATION WITH FACTORY DEFAULT SETTINGS

The 3334TERM.EXE program is a utility program that emulates a
terminal to test the connection from PC keyboard to ISI board to
Modem to ISI board to PC display. Prior to executing 3334TERM the
program must be executed to initialize the ISI board (when the ISI
board’s factory settings are unchanged).

The following screen is displayed:

ISI3334 Terminal Utility Version 1.00
Copyright (C), 1990-94 Multi-Tech Systems, Inc
Loading Firmware to ISI3334 located at address 200h
Loading default file: ISI3334.BIN

ISI3334 loading firmware.....

ISI3334 verifying firmware.....Verify OK.

ISI3334 firmware loaded successfully.

ISI firmware loaded successfully...
Enter 1 to 8 for eight ports ISI.
Enter port number ?

Appendix B - ISI Testing Utilities

Note: This program must be run anytime the PC is powered down

or rebooted.

59

ISI3334/4 Hardware/Driver Installation Manual

The first step in this utility is to identify the port to be tested. In order
for the test to function, the selected port must be connected to an
activated modem. The valid entries for the ISI are 1 through 8.
Once a port is selected, the following is displayed:

Enter 8 = 1200 baud
Enter 11 = 2400 baud
Enter 15 = 9600 baud
Enter 16 = 19200 baud
Enter 17 = 38400 baud
Enter 18 = 57600 baud
Enter 19 = 115200 baud

Enter the baud rate you wish to run ?

This step allows selection of a baud rate for testing. Once a baud
rate is selected, the following is displayed:

ISI Terminal Utility is ready. Press F10 to Exit.

This message indicates that keyboard entry can now be performed;
any characters typed on the keyboard will be sent through the ISI
board to the modem and then returned to be displayed on the PC’s
screen. When operation has been verified the utility can be exited by
pressing the F10 key.

60

2. OPERATION WITH SETTINGS OTHER THAN FACTORY

DEFAULTS

The 3334TERM.EXE program is a utility program that emulates a
terminal to test the connection from PC keyboard to ISI board to
Modem to ISI board to PC display. Prior to executing 3334TERM,
the program must be executed to initialize the ISI board.

Enter 3334TERM -h <CR> to display the 3334TERM program
requirements. The following screen is displayed:

A:\>3334TERM -h
Usage is:
IsIterm-I<2 to 7, 10 to 12 and 15> for specifying IRQ

level.

-A<address> for specifying base address.

-H this help screen.

Note: This program must be run anytime the PC has been powered
down or rebooted.

Appendix B - ISI Testing Utilities

Whenever the Base IO Address and/or the IRQ values have been
changed, a parameter string must be added to the command line.
The string takes the form of [-Axxxx], where xxxx represents the new
Base IO Address value and [-Iy], where y represents the IRQ value
selected. Three potential combinations exist for the formatting of the
command line:

1) Changing only the Base IO Address setting the

command line takes the form:

3334TERM [-Axxxx]

2) Changing only the IRQ setting the command line takes

the form:

3334TERM [-Iy]

3) Changing both the Base IO Address and the IRQ settings

the command line takes the form:

3334TERM [-Axxxx] [-Iy]

For example, if the Base IO Address switch setting were changed to
2C0h, then the new command line would be:

A:\>3334TERM -A2C0

The following screen is displayed:

A:\>3334TERM -A2C0

Loading Firmware to ISI3334 located at address 2C0h
Loading default file: ISI3334.BIN

ISI3334 loading firmware.....

ISI3334 verifying firmware.....Verify OK.

ISI3334 afirmware loaded successfully.

ISI firmware loaded successfully...
Enter 1 to 8 for Eight ports ISI.
Enter port number ?

61

ISI3334/4 Hardware/Driver Installation Manual

The first step in this utility is to identify the port to be tested. In order
for the test to function, the selected port must be connected to a
modem that is switched on. The valid entries for the ISI are 1
through 8. Once a port has been selected, the following is
displayed:

Enter 8 = 1200 baud
Enter 11 = 2400 baud
Enter 15 == 9600 baud
Enter 16 == 19200 baud
Enter 17 == 38400 baud
Enter 18 == 57600 baud
Enter 19 == 115200 baud
Enter the baud rate you wish to run?

This step allows selection of a baud rate for testing. Once a baud
rate has been selected, the following is displayed:

ISI Terminal Utility is ready. Press F10 to Exit.

This message indicates that keyboard entry can now be performed;
any characters typed on the keyboard will be sent through the ISI
board to the modem and then returned to be displayed on the PC’s
screen. When operation has been verified, the utility can be exited
by pressing the F10 key).

62
