MultiConnect®rCell 500 Series Router User Guide5
PRODUCT OVERVIEW
Product Overview
Thank you for purchasing the MultiConnect rCell 500 Series. The MultiConnect rCell 500 offers secure data
communication between different types of devices. It features redundant power supplies and dual SIM capability
for a more reliable connection
6MultiConnect®rCell 500 Series Router User Guide
Package Contents
ContentsDescription
One MultiConnect rCell 500
Two 4G Antennas
Two WiFi Antennas
One Power Adapter (DC12/2A). The maximum power consumption is 15.5W.
PACKAGE CONTENTS
One RJ-45 Cable
One Console Cable
Two Wall Mount Kits
One DIN-Rail Bracket
MultiConnect®rCell 500 Series Router User Guide7
PACKAGE CONTENTS
ContentsDescription
Power Port
Four Rubber Feet
8MultiConnect®rCell 500 Series Router User Guide
System Requirements
Network Requirements■ An Ethernet RJ-45 cable or DSL modem
■ 4G cellular service subscription
■ 802.11b/g/n wireless clients
■ 10/100 Ethernet adapter
Configuration Utility Requirements■ Operating System Requirements
■ Windows®XP with SP2 or higher
■ Macintosh
■ Linux-based operating system
■ Browser Requirements
■ Internet Explorer 9.0 or higher
■ Chrome 2.0 or higher
■ Firefox 3.0 or higher
■ Safari 3.0 or higher
SYSTEM REQUIREMENTS
MultiConnect®rCell 500 Series Router User Guide9
LED INDICATORS
LED Indicators
IndicatorLabelDescription
Power Source 1Continuously ON: Device is powered by source 1.
Power Source 2Continuously ON: Device is powered by source 2.
Note: If both power source 1 and 2 are connected, the
device will choose power source 1 first. In this instance,
the LED for power source 2 will remain OFF.
WLAN (WiFi)WIFIContinuously ON: Wireless radio is enabled.
Flashing: Data packets are being transferred.
OFF: Wireless radio is disabled.
SIM AContinuously ON: SIM A is in use.
SIM BContinuously ON: SIM B is in use.
LAN1 - LAN 4E1 - E4Continuously ON: Ethernet connection is established.
Flashing: Data packets are being transferred.
High 4G SignalHIGHContinuously ON: Strong 4G signal strength.
Low 4G SignalLOWContinuously ON: Weak 4G signal strength.
USBUSB CELLContinuously ON: USB device is attached.
Serial PortSER.Flashing: Serial data is being transferred.
Two Mini-SIM, standard 1.8 V and 3 V SIM receptacle
9 V to 48 V DC
Dimensions are shown in the section “Dimensions” that follows.
TBD
-10° C to +60° C
Relative humidity 15% to 93% non-condensing
SPECIFICATIONS
CategoryDescription
Certifications, Compliance, Warranty
EU Compliance
Safety Compliance
Network Compliance
Warranty
R&TTE
IEC 60950-1
GCF
Two years
Note: The radio’s performance may be affected at the temperature extremes. This is considered normal. There
is no single cause for this function. It is the result of an interaction of several factors, such as the ambient
temperature, the operating mode, and the transmit power.
The SIM card slots are located on the bottom of the device.
Note: Before installing or changing the SIM card, make sure the device is turned OFF and power is
disconnected.
1.Unscrew and remove SIM card cover.
2.Slide SIM card socket toward hinge to unlock.
3.Lift up SIM holder and insert SIM card, making sure notch is lined up correctly.
4.Lay SIM holder down.
5.Slide SIM socket away from hinge to lock.
6.Replace SIM card cover.
14MultiConnect®rCell 500 Series Router User Guide
Attaching Cables and Antennas
INSTALLING AND USING THE ROUTER
1.Attach 4G antennas to the device's front panel by screwing them into the designated connectors.
2.Attach WiFi antennas to the device's side panel by screwing them into the designated connectors.
3.Attach cables to their corresponding ports on the device's front panel.
Note: During configuration use ports E2 to E4 only. DO NOT attach Ethernet cable to E1/WAN port.
4.Attach red wire on the power cable to PWR1 and the black wire to the GND for PWR1 on the power port
on the device's side panel.
Using Setup Wizard
Configure this device using the web UI. To access the web UI, enter the IP Address into your browser. The default
IP Address is 192.168.2.1. If this has been changed, type in the new IP Address. On the login page, type the
administrator password and click Login.
Note: The default administrator username and password is admin.
MultiConnect®rCell 500 Series Router User Guide15
INSTALLING AND USING THE ROUTER
After logging in, select the appropriate language. From the menu on the left, click Wizard.
1.To start the Wizard, click Next.
2.Change the login password of the web UI. Click Next.
3.Select the correct Time Zone. Click Next.
4.Select the WAN type and address. Click Next.
5.Setup the LAN address and Subnet Mask. Click Next.
6.Setup WiFi connection. Click Next.
7.Verify that the Wifi Router Network setup summary is correct. Click Apply.
8.Apply and Restart.
16MultiConnect®rCell 500 Series Router User Guide
Basic Network
WAN Setup
This device has three WAN interfaces to support different WAN connections. Configure these individually to
maximize Internet connection setup.
■ Ethernet WAN 1: You can configure the fourth Ethernet port as a WAN. To setup, plug in the Ethernet cable
from an external modem and follow UI setup.
■ 3G/4G WAN 2:There is one 3G/4G built in modem. To setup, insert SIM card and follow UI setup.
■ 3G/4G WAN 3: There is one USB port that supports a 3G/4G dongle. To setup, plug in the dongle and follow
UI setup.
Physical Interface
Click Edit for each WAN interface to view the detailed physical interface settings. This interface allows you to
configure the settings.
WAN 1: This interface is in Always On mode and is the primary Internet connection. Click Edit to configure
interface settings.
BASIC NETWORK
WAN 2: This interface is disabled by default. Click Edit to configure. There are three operation options for this
interface.
WAN 3: This interface is disabled by default. Click Edit to configure. There are three operation options for this
interface.
Operation ModeDescription
Always-OnWAN 1 and 2 connect at the same time. Two internet connections are established
simultaneously and outgoing data is transferred through both based on load balance
policies.
FailoverIf the WAN 1 connection is broken, the device will failover to WAN 2 automatically.
When the WAN 1 connection is reestablished, the connection automatically switches
back to WAN 1.
DisableDisables WAN 2.
Internet Setup
There are three 3G/4G WAN interfaces that you can setup individually. These interfaces support an ISP that
provides LTE, HSPA+, HSPA, WCDMA, EDGE, GPRS data services, and xDSL or Cable connections with Dynamic IP,
Static IP, PPPoE, PPTP, and L2TP connection types.
WAN TypeDescription
4GSupports LTE/3G/2G depending on specifications.
Dynamic IP AddressIP Address is different each connection.
Static IP AddressIP Address is the same each connection.
MultiConnect®rCell 500 Series Router User Guide17
Note: If the data plan is not a flat rate, set the Connection Control mode
to Connect-on-Demand or Manual.
