OPERATION AND PARTS MANUAL
MODELS
DA7000SS-DA7000SSA
DA700SSW-DA7000WGH
PORTABLE GENERATORS
(KUBOTA Z482 SERIES DIESEL ENGINES)
Revision #5 (01/20/11)
To fi nd the latest revision of this
publication, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
PROPOSITION 65 WARNING
Diesel engine exhaust and some of
PAGE 2 — DA7000 SERIES GENERATORS• OPERATION AND PARTS MANUAL — REV. #5 (01/20/11)
REPORTING SAFETY DEFECTS
If you believe that your vehicle has a defect that could cause a crash or could cause
injury or death, you should immediately inform the National Highway Traffic Safety
Administration (NHTSA) in addition to notifying Multiquip at 1-800-421-1244.
If NHTSA receives similar complaints, it may open an investigation, and if it finds
that a safety defect exists in a group of vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot become involved in individual problems
between you, your dealer, or Multiquip.
To contact NHTSA, you may either call the Vehicle Safety Hotline toll-free at 1-888327-4236 (TTY: 1-800-424-9153), go to http://www.nhtsa.dot.gov; or write to:
Administrator
NHTSA
1200 New Jersey Avenue S.E.
Washington, DC 20590
You can also obtain information about motor vehicle safety from
http://www.safecar.gov.
DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 3
TABLE OF CONTENTS
DA7000 SERIES GENERATOR
Proposition 65 Warning .................................................. 2
Reporting Safety Defects ................................................ 3
Table Of Contents ........................................................... 4
Parts Ordering Procedures ............................................. 5
Safety Information .....................................................6-11
Specifi cations (Generator) ............................................ 12
Specifi cations (Engine) ................................................. 13
Dimensions ................................................................... 14
Installation ............................................................... 16-17
General Information ...................................................... 18
Components (Generator) ......................................... 19-20
Components (Engine) ................................................... 21
Load Applications ......................................................... 22
Inspection/Setup ...................................................... 23-27
Operation ................................................................. 28-30
Shutdown ...................................................................... 30
Preparation For Long Term Storage ............................. 31
Maintenance ............................................................ 32-35
Maintenance (Trailer) ............................................... 36-37
Trailer Guidelines ..................................................... 38-51
Trailer Wiring Digram ................................................... 52
Generator Wiring Digram ............................................. 53
Engine Wiring Digram .................................................. 54
Troubleshooting (Engine and Generator) ................ 55-56
Troubleshooting (Engine) ......................................... 57-58
Explanation Of Code In Remarks Column.................... 60
Suggested Spare Parts ................................................ 61
Component Drawings
Nameplate and Decals Assembly ............................ 62-63
Generator Assembly ................................................ 64-65
Control Panel Assembly .......................................... 66-67
Electric Parts Assembly ........................................... 68-69
Engine And Radiator Assembly ............................... 70-73
Battery Assembly..................................................... 74-75
Muffl er Assembly ..................................................... 76-77
Fuel Tank Assembly ................................................. 78-79
Oil Filter Retrofi t Assembly ...................................... 80-81
Enclosure Assembly ................................................ 82-85
Rubber Seals Assembly .......................................... 86-87
NOTICE
KUBOTA Z482-EB/E2B/E3B Diesel Engines
Crankcase Assembly .............................................. 88-89
Oil Pump Assembly ................................................ 90-91
Oil Pan Assembly ................................................... 92-93
Cylinder Head Assembly ........................................ 94-95
Gear Case Assembly .............................................. 96-97
Head Cover Assembly .......................................... 98-101
Oil Filter Assembly .............................................. 102-103
Dipstick and Guide Assembly ............................. 104-105
Main Bearing Case Assembly ............................106-107
Camshaft and Idle Gear Assembly ..................... 108-109
Piston and Crankshaft Assembly ....................... 110-111
Flywheel Assembly ............................................ 112-113
Fuel Camshaft and Gov. Shaft Assembly ......... 114-115
Engine Stop Lever Assembly ............................. 116-117
Stop Solenoid Assembly ................................... 118-119
Injection Pump Assembly ................................. 120-121
Injection Pump Components Assembly ........... 122-123
Speed Control Plate Assembly ............................ 124-125
Nozzle Holder And Glow Assembly ..................... 126-127
Nozzle Holder Assembly ...................................128-129
Fork Lever Assembly .......................................... 130-131
Fuel Filter Assembly ........................................... 132-133
Fuel Pump Assembly .......................................... 134-135
Dynamo and Pulley Assembly ........................... 136-137
Dynamo Assembly .............................................. 138-139
Starter Assembly ................................................ 140-141
Starter Components Assembly .......................... 142-143
Oil Switch Assembly ........................................... 144-145
Water Flange and Thermostat Assembly ........... 146-147
Water Pump Assembly ....................................... 148-149
Water Pipe Assembly ......................................... 150-151
Fan Assembly ..................................................... 152-153
Valve and Rocker Arm Assembly ....................... 154-155
Inlet Manifold Assembly ...................................... 156-157
Exhaust Manifold Assembly ................................158-159
Glow Plug/Lamp and Timer Assembly .............. 160-161
Starter Switch Assembly .................................. 162
Air Cleaner Assembly ....................................... 164-165
Accessories ......................................................... 166-167
Piston Kit (Option) ...............................................168-169
Terms and Conditions Of Sale — Parts ...................... 170
-163
Specifi cations and part numbers are subject to change
without notice.
PAGE 4 — DA7000 SERIES GENERATORS• OPERATION AND PARTS MANUAL — REV. #5 (01/20/11)
PARTS ORDERING PROCEDURES
r
Ordering parts has never been easier!
Choose from three easy options:
January 1
Effective:
st
, 2006
Best Deal!
Order via Internet (Dealers Only):
Order parts on-line using Multiquip’s SmartEquip website!
■ View Parts Diagrams
■ Order Parts
■ Print Specification Information
Goto www.multiquip.com and click on
Order Parts
Order via Fax (Dealers Only):
All customers are welcome to order parts via Fax.
Domestic (US) Customers dial:
1-800-6-PARTS-7 (800-672-7877)
Non-Dealer Customers:
Contact your local Multiquip Dealer for
parts or call 800-427-1244 for help in
locating a dealer near you.
to log in and save!
Order via Phone:
If you have an MQ Account, to obtain a Username
and Password, E-mail us at: parts@multiquip.
com.
To obtain an MQ Account, contact you
District Sales Manager for more information.
Use the internet and qualify for a 5% Discount
on Standard orders for all orders which include
complete part numbers.*
Fax your order in and qualify for a 2% Discount
on Standard orders for all orders which include
complete part numbers.*
Domestic (US) Dealers Call:
1-800-427-1244
International Customers should contact
their local Multiquip Representatives for
Parts Ordering information.
Note: Discounts Are Subject To Change
Note: Discounts Are Subject To Change
When ordering parts, please supply:
❒ Dealer Account Number
❒ Dealer Name and Address
❒ Shipping Address (if different than billing address)
❒ Return Fax Number
❒ Applicable Model Number
❒ Quantity, Part Number and Description of Each Part
NOTICE
All orders are treated as Standard Orders and will
ship the same day if received prior to 3PM PST.
❒ Specify Preferred Method of Shipment:
✓ UPS/Fed Ex ✓ DHL
■ Priority One ✓ Tr uck
■ Ground
■ Next Day
■ Second/Third Day
www.multiquip.com
WE ACCEPT ALL MAJOR CREDIT CARDS!
DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 5
