When using your telephone
equipment, basic safety
precautions should always be
followed to
reduce the risk of
fire, electric shock and
injury
to persons, including the
following:
1. Read and understand
all
instructions.
2. Follow
all
warnings and
instructions marked
on
the
product.
3. Unplug this product from
4. Do not use this product
near water, for example,
near a bathtub, wash bowl,
kitchen sink, or laundry tub,
in
a wet basement, or near
a swimming pool.
5. Do not place this product
the wall outlet
before
cleaning. Do not use liquid
cleaners or aerosol
cleaners. Use a damp cloth
for cleaning.
6
2
on an
unstable
cart,
stand,
or table. The product may
fall,
causing serious
damage
to the product.
This product should never
be placed near or
over
a
radiator or heat register.
This product should not be
placed
in
a
built-in
installation unless proper
ventilation
is
provided.
7. This product should be
8.
operated only from the type
of power source indicated
on
the marking
label.
If
you
are not
sure
of the type of
power supply to your home,
consult
your dealer or local
power company.
Do not allow anything to
rest on the power
cord.
Do
not
locate
this product
where the
cord will
be
abused by persons walking
on
it.
9. Do not overload wall outlets
and extension
cords
as this
can result
in
the risk of fire
or electrical shock.
10. Never push objects of
any
kind into this product
through cabinet slots as
they may touch dangerous
voltage
points or short out
parts that could result
in
a
risk of fire or electric shock.
Never
spill
liquid of
any
kind on this product.
Page 4
11
.
To reduce the risk of
electric shock, do not
disassemble
this
product,
but take it to a qualified
serviceman when service
or
repair work is required.
Opening or removing
covers may
expose you
to
dangerous
voltages or
other risks.
Incorrect
reassembly can cause
electric shock when the
appliance
is
subsequently
used.
12.
Unplug this product from
the
wall
outlet and refer
servicing to qualified
service personnel under
the following conditions:
A.
B.
C.
D.
When the power
supply
cord or
plug
is
damaged or frayed.
If
liquid
has
been
spilled into the product.
If
the product has
been
exposed to rain
or
water.
If the product
does
not
operate
normally by
following the operating
instructions. Adjust
only those controls,
that are covered by the
operating instructions
because
improper
adjustment of other
controls
may result
in
damage
and
will
often
require
extensive work
by a qualified
technician to
restore
the product to normal
operation.
E.
If the product has
been
dropped or the cabinet
has
been
damaged.
F.
If the product exhibits a
distinct
change in
performance.
13. Avoid using a telephone
(other than a cordless type)
during an electrical storm.
There may be a
remote
risk
of electrical shock from
lightning.
14. Do not use the telephone to
report
a gas leak in the
vicinity of the leak.
SAVE’THESE INSTRUCTIONS!!!
INSTALLATION
PRECAUTIONS
1. Never
install
telephone wiring during a lightning storm.
2. Never
install
telephone
jacks in
wet locations unless the
jack is
specially designed for wet locations.
3. Never touch uninsulated telephone wires or terminals unless the
telephone line has
been
disconnected at the network interface.
4. Use caution when installing or modifying telephone lines.
3
Page 5
To simplify this installation
products is identical
manual,
all
graphical
concerning interface
on
the
representations of ACP
existing phone wiring. The ACP
product
in
wiring schematics is designed to
process
and
are of the 3-port model.
You
route
all
incoming
calls
to data
may be installing
an
ACP-5, and telephone equipment
which
is
a
5-port device.
The connected through the ACP to
installation procedure for both
the phone line.
WARNING
The key to proper operation of the ACP
is
CORRECT
installation. It
is
VITALLY IMPORTANT that
you install
the
ACP unit between the telephone wiring demarcation point
and
all
station equipment (including KEY systems).
Before
installing the ACP
on
(supplied) and plug it into a 110
the telephone line, it
is
a good
VAC,
50-60 Hz electrical outlet.
idea to
check
for functionality Next, plug the power line
by “powering up” the unit. Take
(attached to the transformer)
the
AC
power transformer into the rear of the
ACP, here:
4
Page 6
At this time, the LED on the be
lit
indicating that power
is
front panel of the ACP should
supplied.
To connect the ACP to the
phone line, a RJ-31X modular
walljack
will
need to be
installed
on
to the existing
telephone wiring
in
front of
all
telephone/data
equipment.
The installation for the RJ-31X
will
be identical to a standard
alarm system reporting
application. The following
diagram denotes the proper
wiring of telephone cable to the
RJ-31 X walljack.
RJ-31X Walljack Wiring
Diagram
Series
Modular
To ACP
“Line/Phone” Device Port
5
Page 7
WARNING
The
“Tip”
and "Ring" labeling is important when attaching
wire pairs to the numbered pins. There should be no
deviation from the diagram
on
page 5.
Any
deviation would
result
in
reverse polarity problems for the phone system
and data equipment
used on
the
ACP.
The “shorting
bars”
in
the RJ-31 X walljack
allow
for continuation of
voice
service
to the phone system when the 8-wire line
cord is
unplugged.
If
the
line cord is
unplugged from the ACP and
still
left attached
to the walljack,
calls will
not get through to the phone system.
In this section, we
will detail
the most common types of
wiring configurations found
in
a
business location. The proper
installation point for the
RJ-31X walljack
in each
wiring
configuration
is
represented by
a black box labeled “31X”.
Installing the RJ-31X at that
point or
before on
the incoming
phone line should guarantee
correct
operation of the ACP
unit.
Single
Line
Installation
RJ-31X placement in a
singleline wiring configuration occurs
before all
existing phone
equipment. The wiring
configuration is characterized by a
single incoming phone line
with single or multiple
RJ-11
walljacks.
Incoming Phone Line
+
II
1
1
PHONE
PHONE
1
RJ-11 Walljacks
Page 8
Two
Line
Installation
RJ-31X installation on a two
line
phone system is basically
the
same
as a single line
installation, but with a few
exceptions.
A) If “Rollover” is present,
install
the RJ-31 X walljack
on
the last line of the
“Rollover” sequence.
B) If the existing wiring
is in
a
RJ-14 configuration, the two
phone lines
will
need to be
separated for installation of
the RJ-31X walljack
on
the
chosen
line.
RJ-11 Walljacks
I
Last Line
of
Rollover
53
piCq
KEY/PBX
two-line installations-
install
System Installation
the RJ-31X walljack on the
This type of installation
is
simple and should be a rarity.
The
same
rule applies for
Key/PBX phone system
installation as with single and
incoming phone
line before all
telephones and telephone
equipment! In this case,
installation occurs on the trunk
side
of the phone system.
To Phone
Extensions
SYSTEM
I
I
Note: The RJ-31X is installed on the last íncoming line
of this diagram because of
“Rollover”
sequence.
7
Page 9
When installing the ACP on a
This T-connector, when
inserted
single phone
line
where only in a regular RJ-ll C
jack, ex-
one RJ-11 walljack is present, it
pands the interface to support
may be advantageous to use a
RJ-11
C/RJ-31
X modular
4-pin/8-pin
series T-connector. connectors.
4/8 Series
T-Connector
Wiring Diagram
123456
--’
I
I
I
1
I
I
I 1
I
’
1 2 3 4
5'\6 71 0
123456
RJ-11C
RJ-31X
~Shorting
Bar
(Short Removed
on Plug
Insertion)
By utilizing a
4/8 pin
series
T-connector
on
a regular
RJ-11
C walljack, the ACP can
be connected to the existing
phone line without installing a
RJ-31X walljack. The ACP line
cord
plugs into the
8-pin side
of
the T-connector and the phone
can be plugged into the
4-pin
side.
Note:
If
more than one
RJ-11 C
jack
is present on the existing
phone wiring, the
4/8 pin
series
T-connector should be inserted
8
on
the first incoming walljack
on
the phone line. The phone
line wire running to the next
walljack should be discon-
nected at the first walljack. This
will
ensure that
all
incoming
calls will
be routed through the
ACP. If the additional RJ-1
1 C
walljacks are needed for phone
extensions, simply crimp
an
RJ-11 C modular plug on the
end of the disconnected
line
and plug it in to the RJ-11 C
side
of the
4/8 pin
T-connector.
Page 10
Listed below are part numbers
them to another
manufacturer’s
for the
4/8 pin
series T-connector.
part
number.
If
your telephone accessories
retailer
does
not
have
the part
numbers listed
in
his
catalogs,
ask him to
cross
reference
Part No.
AT 267 SB
304A
Manufacturer
Allen
Tel
AT&T
Functions/
Operations Check
After installing the ACP on the
phone line, it
is
wise to make a
“functions check” of the unit
and the phone system wiring.
To
check the phone system
wiring:
1.
Check
all
telephones for dial
tone. If
none is
present,
unplug the 8-wire line
cord
(which connects the ACP to
the phone line) from the
RJ-
31X walljack. If dial tone
is
returned to the phones after
unplugging the line
cord,
check
the line
cord
connection at the
LINE/DEVICE
1”
port
of the
ACP
3/5.
Reconnect the line
cord
to the RJ-31X walljack.
Dial tone should be returned
to the phone system.
2. If dial tone
is
present but
you
can not dial out on the line,
the phone
line
polarity may
need to be reversed. This
can be done by switching
the “tip and ring” wires
on
the incoming line at the
RJ-
31 X walljack.
3. After connecting the
specified data equipment to
the
device
ports at the rear
of the ACP (DEVICE
2/DEVICE
3 for the ACP
3-DEVICE
2/DEVICE
3/DEVICE 4/DEVICE
5 for
the ACP
5),
the unit should
be tested for
call
routing
capability. This can be done
by contacting the central
office
or location that
will
be
polling such
equipment and
give them the location phone
number and
device
selection
codes
(if known).
TO THE INSTALLER: If the
ACP 3 or 5 fails to
operate
at
any
time after installation
please
contact
the location
supervisor or corporate MIS
Manager.
9
Page 11
Input Power Requirements:
At
AC
Transformer: 110-125
Volts AC
Only, 50-60 Hz
At Power
Jack On
ACP: 12-15
Volts AC
Only
Power Consumption Idle: 8 Watts
Ringing A Device: 10 Watts
CO Interface:
REN
1.1B
DOC
(Canada): Load No. 22.6
Input Ring Detection: 40-150
Volts AC,
15-68 Hz
Device Interface:
Battery: Nominal-45 Volt DC To
All
Ports.
Off-Hook Detection: 8-150
mA
Ringer Frequency: 33 Hz Pseudo-Sine Wave
Ringing No Load: Approximately 105
Volts AC
Ringing 8000 Ohm Impedance
(REN
1.0): Approximately 76
VAC
Ringing 4000 Ohm Impedance
(REN
2.0): Approximately 59
VAC
Ringing 2667 Ohm Impedance
(REN
3.0): Approximately 45
VAC
Ringing Short
Circuit:
Current Limited to 30mA
(Impedances of
less
than 2667 ohms not recommended)
DOC
Registration
equipment. This certification
The Department of
Communi-
cations
label
identifies certified
means
that the equipment
meets certain telecommunica-
tions network protective,
10
Page 12
operational and safety
require-
ments. The Department
does
not guarantee the equipment
will operate
to the user’s
satisfaction.
Before
installing
this equipment, users should
ensure that it
is
permissible to
be connected to the
facilities
of
the local telecommunications
company. The equipment must
also
be installed using
an
accepted method of connection.
In
some
cases, the company’s
inside wiring associated with a
single
line
individual service
may be extended by
means
of
a
certified
connector assembly
(telephone extension
cord).
The
customer should be aware that
compliance with the
above
conditions may not prevent
degradation of service
in some
situations.
Repairs to certified equipment
should be made by
an
author-
ized Canadian maintenance
facility designated by the
supplier.
Any
repairs or
alterations made by the
user
to
this equipment, or equipment
malfunctions, may give the
telecommunications company
cause to request the
user
to
disconnect the equipment.
Users should ensure for their
own protection that the
electrical ground connections
of the power
utility,
telephone
lines and
internal
metallic water
pipe system, if present, are
connected together. This
precaution may be particularly
important
in
rural
areas.
Caution:
Users should not
attempt to make
such connections themselves, but
should
contact
the
appro-
priate
electric
inspection
authority, or electrician, as
appropriate.
The Load Number (LN)
assigned to
each
terminal
device
denotes the percentage
of the total load to be
connected to a telephone loop
which is
used
by the
device,
to
prevent overloading. The
termination on a loop may
consist
of
any
combination of
devices subject only to the
requirement that the total of
the Load Numbers of
all
the
devices
does
not
exceed
100.
Notice:
This product has
been
tested and meets the Class B
limits
for radio noise emissions
set out by the Radio
Interference Regulations of the
Canadian Department of
Communications.
FCC Registration
This equipment
complies
with
Part
68 of the FCC rules.
On
the bottom of this equipment
is
ll
Page 13
a
label
that contains, among
other information, the FCC
Registration Number and
Ringer Equivalence Number
(REN)
for this equipment.
You
must,
upon
request,
provide
this information to your
telephone company.
The
REN is used
to determine
the quantity of devices
you
may connect to your telephone
line and
still have all
of those
devices ring when your
telephone number
is called.
In
most, but not
all areas,
the
sum of the
RENs
of
all
devices
connected to one line should
not
exceed
five (5.0). To be
certain of the number of
devices
you
may connect to
your line, as determined by the
REN,
you should contact your
local telephone company to
determine the maximum
REN
for your calling
area.
If your telephone equipment
causes harm to the telephone
network, the telephone
company may discontinue your
service temporarily. If possible,
they
will
notify
you in
advance.
But if advance
notice
isn’t
practical,
you will
be notified as
soon as possible.
You will
be
informed of your right to
file
a
complaint with the FCC.
Your telephone
company may
make
changesin its
facilities,
equipment, operations or
procedures
that could affect
the proper functioning of your
equipment. If they do,
you will
be notified in advance to give
you an
opportunity to maintain
uninterrupted telephone
service.
If
you
experience trouble with
this telephone equipment,
please contact your
PolNet
dealer or Multi-Link, Inc. for
information
on
obtaining
service or repairs. The
telephone company may ask
that
you
disconnect this
equipment from the network
until the problem has
been
corrected or until
you
are
sure
that the equipment is not
malfunctioning.
This equipment may not be
used on coin
service provided
by the telephone company,
and
is
not intended for use with
party line service. This
equipment is intended for use
only
on
loop-start service, and
will
not
operate on
a
ground-
start central o
ffice
line.
Limited Warranty
We warrant that if this
PolNet
ACP
3/5 product, manu-
factured
by Multi-Link, Inc. and
purchased by
you, proves
to
be
defective in
material or
12
Page 14
workmanship, we
will provide retail seller’s original
bill
of sale,
without
charge,
for a period of your
charge
or credit receipt, or
two (2) years, the labor and the other satisfactory proof of the
parts
necessary to remedy
any date of the original retail
such
defect.
Warranty period
purchase of the product, to
any
commences on the date of
of the authorized
PolNet
purchase by the original retail
service centers.
consumer.
Any
postage,
insurance or
The duration of
any
implied
warranty of merchantability,
fitness for a particular purpose,
or otherwise,
on
this product
shall
be limited to the duration
of the
applicable
express
warranty set forth
above.
In no
event
shall
we be
liable
for
any
loss, inconvenience
or
damage
whether
direct,
incidental,
consequential or otherwise
resulting from
breach
of
any
express or implied warranty, of
merchantability, fitness for a
particular purpose, or other-
wise with
respect
to this
product,
except
as set
forth
herein.
Some
states do not
allow limitations
on
how long
an
implied warranty lasts and
some
states do not allow the
exclusion
or limitation of
incidental or consequential
damages,
so the
above
limitations or
exclusion
may
not apply to
you.
To obtain service under this
warranty,
you
must present or
send your ACP
3/5
product,
together with a copy of the
shipping
cost incurred in
presenting or sending your
ACP
3/5
product for service
is
your responsibility. However,
Multi-Link
will
pay for normal
return freight expenses.
The
AC
adaptor
used
with this
product
is
covered under this
warranty. This warranty
does
not
cover damage
which
results from
accident, misuse,
abuse, improper
line voltage,
lightning strike, fire, flood or
damage
resulting from repairs
or alterations performed other
than by
PolNet
authorized
service stations. This warranty
gives
you
specific legal rights,
and
you
may
also have
other
rights which vary from
state
to
state.
Service Information
Your
machine
has
been
registered with the Federal
Communications Commission,
and under this program,
in
the
event of equipment malfunction,
all
repairs
will
be performed by
13
Page 15
Multi-Link, Inc. or a warranty
repair
center
that we
have
authorized. The owner
is
restricted from performing
any
maintenance operation other
than those specified within this
instruction manual.
If
you
require service, please
contact
your Polnet dealer or
Multi-Link, Inc.
Multi-Link, Inc.
225 Industty Parkway
Nicholasville, KY 40356
(859) 885-6363
14
Page 16
The
PolNet
ACP 3/5 contains patented and otherwise
proprietary circuits and software algorithms. This installation
manual describes the operation and function of
some
of these
circuits and algorithms. Unauthorized duplication of this
manual
is
a violation of U.S. and other copyright laws, and
unauthorized use of
all
or part of this manual may result
in
patent infringement. Therefore, THIS MANUAL IS TO BE
USED
ONLY WITH OR ASA MARKETING TOOL FOR THE POLNET
ACP
3/5.
Duplication of
all
or
part
of this manual without the
permission of Multi-Link, Inc.
is
prohibited.
Printed in the U.S.A.
Multi-Link, Inc.
225 Industry Parkway
Nicholasville, KY 40356
(859) 885-6363
Loading...
