ESD Monitored Workstation Kit
Kit Includes:
• 1x ESD Matting (600x900mm) with 10mm
stud in each corner
• 1x ESD Caution Sign
(150 x 300mm self adhesive)
• 1x Earth Facility Bracket with M5 Binding Post
• 1x UK Earth Bonding Point 2x10mm Studs and
built in tester
• 1x Power Supply Unit for EBP
• 1x10mm Fabric Adjustable Wrist Strap Hypo
Allergenic
• 1x10mm Coiled Earth Lead
• 1x10mm Straight Lead
• 1x Instruction Leaet
Matting Features:
• Reection breaking surface to reduce glare and improve operator comfort
• Protection against small collisions
• Prevention of sliding of delicate components thanks to excellent friction coecient
• Heating resistance: does not melt or burn coming into contact with hot metal parts or soldering debris
• Oil resistance: this product resists most oils
• Suitable for loose laying: does not require application with adhesive
• Good resistance to scratches and excellent exibility and comfort
Matting Details
Material Static dissipative
Thickness 2mm
Surface Reection breaking surface
Tester ETS 406C Static Decay Meter, 3M Model 701 Test Kit for Static
Control Surfaces
Hardness (ISO 7619) 75±5 shore A
Abrasion Resistance (ISO 4649, method A) ≤200mm
3
Indentation (EN433) ≤0,20mm
Cigarette burning resistance (EN1399) No burn
Chemical resistance (EN423) Resistant to chemical agents normally used for maintenance
Dimensional Stability (EN424 - 6h/80oC) ≤0.4%
Surface Resistance Top Layer (EN 100015.1-IEC61340) About 108Ω
Surface Resistance Bottom Layer (EN 100015.1-IEC61340) About 105Ω
Disclaimer This data sheet and its contents (the "Information") belong to the Premier Farnell Group (the "Group") or are licensed to it. No licence is granted for the use of it other than for information purposes
in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change without notice and replaces all data sheets previously supplied.
The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, a ny error in or omission from it or for any use made of it. Users of this data
sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted. Liability for loss or damage
resulting from any r eliance o n the Information or use o f it ( including liability resulting from negligence o r where the Group was a ware o f the possibility of such loss o r damage a rising) is excluded.
This will not operate to limit or restrict the Group's liability for death or personal injury resulting from its negligence. SPC Multicomp is the registered trademark of the Group. © Premier Farnell plc 2008.
http://www.farnell.com
http://www.newark.com
http://www.cpc.co.uk
1.1V 80/01/22>1< egaP
ESD Monitored Workstation Kit Contents:
ESD Caution Sign
• Antistatic coating
• Self adhesive: 0.4mm thick PVC
• 300 x 150mm
Economy Wrist Strap Set
• A comfortable, fully adjustable wristband incorporating a 10mm press stud.
• Supplied complete with a durable coiled earth lead, with a 10-10mm press stud.
Straight Earth Lead
• Excellent quality for use with any kind of Field Service Kit or Table Mat
• Strong connection between the cord and 10mm stud
• Special conductive wire each containing 10 special conductive wires
• Outer covered with non-conductive PU
• Length: 12ft
• Diameter of cord: 2.4 mm
• Resistivity : 1M Ohm +/- 10%
Earth Bonding Point with 2x10mm Studs with
Built In Tester
• Earth Bonding Point Boxes designed to be mounted on bench
• Black cord 3m long, can exit towards left or right
• 1 MΩ (1x10E6 ohms) 1/2 Watt resistor for each connector
Power Supply Unit for EBP
Earth Facility Bracket with M5 Binding Post
• Serves as a grounding hub for earth bonding points, can receive several wires
• Supplied with mounting screws - easy to mount
• Size: 40 x 45 x 12mm
Supplied with instruction leaet.
Product Code: Description: Size: Additional Notes:
1762466 Monitored Workstation Kit Mat 600 x 900mm Blue (Ref: 069-0009)
