Multiblitz PROFILUX ECO 250, PROFILUX ECO 500 Quick Start Manual

EN

2

QUICK START GUIDE.

IR receiver/
Slave cell

Output Setting

Radio trigger
channel selection

Beep/Lamp
Ready indicator

Test button

Activates radio trigger

Sync Socket

Display

Output, wireless receiver “active”

and “stand-by” indication

IR receiver /Slave

Cell On-Off

Modeling Lamp

On (prop x)-Off

Power On-Off

Modeling Lamp 100%

On-Off

Power socket/

Fuse box/Spare fuse

Thank you for choosing MULTIBLITZ, we hope you enjoy working with this high quality
product. MULTIBLITZ flash units are without exception designed and manufactured
in Germany.

IMPORTANT CARE & MAINTENANCE INFORMATION!

Please read the instruction manual carefully before using this product.

Flash-/ and halogen tubes as well as metal parts can become very warm
during operation and may cause burns if not handled properly.

Opening the unit could be extremely dangerous! Do not open the unit by yourself!
Service should only be executed by an authorized MULTIBLITZ service location.

Do not obstruct the venting slots.

Do not place filters, diffusing materials, or any other obstructions directly
onto the flash-/ and halogen tubes.

Do not expose the unit to water, nor

spray-/or dripping water.

Do not run the unit with unregulated gasoline-/or diesel generators.

When permanently in use, this unit should be serviced once a year by an authorized
MULTIBLITZ service location.

The crossed out wheeled bin label that can be found on your product indicates
that this product should not be disposed of via the normal household waste stream.
To prevent possible harm to the environment or human health please separate this
product from other waste streams to ensure that it can be recycled in an environmen­tally sound manner.

For more details on available collection facilities pl

ease contact your
local government office or the retailer where you purchased
this product.

EN

LED´s

Function On-Off indication
