ARENA 5000
2.1CH Wired Soundbar & Subwoofer
2
Important Safety Instruction
Thank you for purchasing the ARENA 5000 Soundbar. Please read this user manual carefully and keep for future
reference.
Warning
Caution:
To reduce the risk of electric shock, do not dismantle the product and do not expose the apparatus
to rain or moisture. No user-serviceable parts inside.
Refer servicing to qualified personnel only
The lightning flash within an equilateral triangle is intended to alert you to the presence
of uninsulated dangerous voltage within the product’s enclosure that may be of
sufficient magnitude to constitute an electric shock to a person or persons.
Important! This symbol alerts you to read and observe important warnings and
instructions on the unit or in this manual.
Notice:
This appliance is not intended for use by persons (including children) with lack of experience and
knowledge, unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
1. To prevent possible hearing damage, do not listen at high
volume levels for long time periods or a sudden high volume level.
2. Never use the device unsupervised! Switch off the device whenever you are not using it, even if
not using it only for a short while.
3. The appliance is not intended to be operated by means of an external timer or separate remote
control system.
4. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
5. Before operating this system, check the voltage of this system to see if it is identical to the
voltage of your local power supply.
3
6. The unit should not be impeded by covering the ventilation opening with items such as
newspaper, table-cloths, curtains etc. Make sure that there are at least 20 cm of space above and at
least 5 cm of space on each side of the unit.
7. The apparatus must not be exposed to dripping or splashing and that objects filled with liquids,
such as vases, must not be placed on the apparatus.
8. To prevent fire or shock hazard, do not expose this equipment to direct heat, rain, moisture
or dust.
9. Do not locate this unit near any water sources e.g. taps, bathtubs, washing machines or
swimming pools. Ensure that you place the unit on a dry, stable surface.
10. Do not place this unit close to a strong magnetic field.
11. Do not place the unit on a amplifier or receiver.
12. Do not place this unit in a damp area as the moisture will affect the life of electric components.
13. Do not attempt to clean the unit with chemical solvents as this might damage the finish. Wipe
with a clean, dry or slightly damp cloth.
14. When removing the power plug from the wall outlet, always pull directly on the plug, never pull
on the cord.
15. Depending on the electromagnetic waves used by a television broadcast, if a TV is turned on
near this unit while it is also on, lines might appear on the TV screen. Neither this unit nor the TV is
malfunctioning. If you see such lines, keep this unit well away from the TV set.
16. The mains plug is used to disconnect the device, the disconnected device should remain
readily operable.
Important Safety Instructions
1. Read these instructions. Keep these instructions. Follow all instructions. Heed all warnings.
2. Do not use this apparatus near water.
3. Clean only with dry cloth.
4. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
5. Do not install near any heat sources such as radiators, heaters, stoves, or other apparatus
(including amplifiers) that produce heat.
6. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other.
7. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles or at the point where they exit from the apparatus.
8. Only use attachments/accessories specified by the manufacturer.
9. Unplug this apparatus during lightning storms or when unused for long periods of time.
4
10. Refer all servicing to qualified service personal. Servicing is required when the apparatus has
been damage in any way, for example, when the power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
11. The AC plug is used to disconnect the device, the disconnected device should remain readily
operable. In order to disconnect the apparatus from the AC power completely, the AC plug must be
removed from the AC outlet completely.
Preparation for Use
Unpacking and Set Up
•Remove the Sound bar from the carton and remove all packing material from the Sound bar. Save
the packing material, if possible, in case the Sound bar ever needs to be serviced or transported.
The original carton and packing material is the only safe way to pack your Sound bar to protect it
from damage in transit.
•Remove any descriptive labels or stickers on the front or top of the cabinet. Do not remove any
labels or stickers from the back or bottom of the cabinet.
•Place your Sound bar on a level surface such as a table, desk or shelf, convenient to an AC outlet,
out of direct sunlight, and away from sources of excess heat, dirt, dust, moisture, humidity, or
vibration.
•Unwind the Line cord connecting the AC adapter and extend it to its full length.
Protect Your Furniture
This model is equipped with non-skid rubber 'feet' to prevent the product from moving when you
operate the controls. These 'feet' are made from non-migrating rubber material specially formulated
to avoid leaving any marks or stains on your furniture. However certain types of oil based furniture
polishes, wood preservatives, or cleaning sprays may cause the rubber 'feet' to soften, and leave
marks or a rubber residue on the furniture. To prevent any damage to your furniture we strongly
recommend that you purchase small self-adhesive felt pads, available at hardware stores and home
improvement center everywhere, and apply these pads to the bottom of the rubber 'feet' before you
place the unit.
Power Source
This sound bar is designed to operate on normal AC Power source. Do not attempt to operate the
Sound bar on any other power source. You could cause damage to the Sound bar that is not
covered by your warranty.
5
Important Notes
• This sound bar was especially developed for LED/LCD/Plasma TV's: It should not be used in
combination with CRTTV's (Cathode Ray Tube TV's) in order to avoid image interference.
• Safety and operating instruction manual should be retained for future reference.
• The apparatus should not be exposed to dripping, splashing or placed in a humid atmosphere
such as a bathroom.
• Do not install the product in the following areas:
• Places exposed to direct sunlight or close to radiators.
• On top of other stereo equipment that radiate too much heat -Blocking ventilation or in a dusty
area.
• Areas where there is constant vibration.
• Humid or moist places.
• Do not place near candles or other flames.
• Operate the product only as instructed in this manual.
• Before turning on the power for the first time, make sure the sound bar is plugged to power outlet.
• For safety reasons, do not remove any covers or attempt to gain access to the inside of the
product. Refer any servicing to qualified personnel.
• Do not attempt to remove any screws, or open the casing of the unit; there are no user
serviceable parts inside. Refer all servicing to qualified service personnel.
6
Product Diagram
LED
LINE IN
SW OUTPUT
AC IN
Power/Multi-function
VOL+:lncrease Volume
VOL-:Decrease Volume
USB input
Cable
7
Remote Control
1. Standby mode for power on/o.
2. PAIR: Connect or disconnect to the pairing device.
(Press the button more than 2 seconds).
3. LUM: Brightness control. This button can’t work under
standby status.
4. Loop playback (only work under USB mode).
5. Volume +
6. Pre button: Previous song (only work under BT mode).
7. Volume -
8. -10: Backwards ten songs (only work under USB mode).
9. Treble -
10. Bass -
11. MUSIC: Select the MUSIC EQ eect.
12. NEWS: Select the MUSIC EQ eect.
13. MUTE mode.
14. INPUT: AUX/USB/BT selection
15. RESET: Reset all sound bar volume levels and switch
EQ back to music setting. Press and hold button for 2 seconds.
16. Stop button: Press to stop. (Only work under USB mode).
17. Next button: Next song. (Only work under USB and BT mode).
18. +10: Forwards ten songs. (Only work under USB mode).
19. Treble +.
20. Bass +
21. MOVIE: Select the MOVIE EQ eect.
22. 3D: Select the 3D EQ eect.
23. Play/Pause (Only work under USB and BT mode).
Positioning the Sound Bar
Place on a flat Surface
Place the sound bar horizontally on a flat surface such as a TV unit or shelves and align it centrally
with the TV screen. Allow some space between the speaker and the wall. Don’t place inside a
cabinet or an a walled shelf. Follow this guidance for best sound output and good airflow around the
sound bar.
×√
8
Mount on the wall
WARNING: If you don’t feel confident to correctly and securely wall-mount the sound bar, Seek the
assistance of an experienced person of professional.
Install the speaker on a vertical, fast, reinforced area of wall. For plaster walls, it is recommended to
screw into wall studs for greater security. For optimum performance, allow at least 25mm/1’’distance
between the sound bar and the TV.
25mm / 1”
25mm / 1”
Follow below steps to mount the sound bar on the wall
1. Make 2 holes on the wall with distance same as the wall bracket on the soundbar
2. Put the plastic anchors onto the wall and secure the screws to the plastic clip, do not tighten
the screws all the way make sure leave some space
3. Attached the 2 EVA pads onto the wall mount backet. This will make sure that there is enough
room between the wall and the soundbar outlet, minimum 15mm
4. Once the screws securely fastened, hang the sound bar over by inserting the screws onto the
wall mount bracket
9
OPERATE INSTRUCTIONS
Setting the Soundbar
1: Plug in the power cord and the LED indicator will light up in red color (Standby mode)
2: Switch on the sound bar by using power button on sound bar of by using STANDBY button on remote.
After switching on, the default input mode will appear indicated by LED indicator light.
3: lnput mode can be changed by pressing the power button again or by using the INPUT button on remote
4:The following are the input modes that appear in the LED indicator light display:
Red light-standby mode, Blue light-Bluetooth Pairing mode, Green light-AUX mode,
Powering On/Off
5. Plug the sound bar into a wall outlet, it will automatically enter standby mode
6. Short-press the multi-function button to turn on the sound bar
7. To turn off, press and hold the multi-function button for 2 seconds or unplug from wall outlet
Playing Audio via Bluetooth
1 Turn on the sound bar and then short-press the multi-function button to switch to Bluetooth mode and the LED
.
indicator will start blinking as blue light.
2. Activate the pairing function on your phone or any other compatible Bluetooth device and select “ARENA 5000”
3. When successfully paired, you will hear a tone and the LED indicator will stop blinking and will maintain as
blue light
4. The remote control includes Bluetooth mode playback controls
Notes:
• The above pairing procedure doesn’t need to be repeated with the same connected device once paired
• If your paired device is switched off or manually disconnected, the sound bar will automatically enter pairing mode
• If the connected device is moved away from wireless range (10 meters) of the sound bar then it will get
disconnected, and the connection will be will be re-established once you re-enter the wireless range.
• There is no automatic shutdown in pairing mode. The sound bar will remain in pairing mode even if no
device is paired, so switch it off when not in use
Playing Audio via AUX
Connect the sound bar to your PC, tablet, smartphone, TV, of other device using either of the two AUX cables
provided. To switch to AUX mode, short-press the multi-function button till the LED indicator color turns green
(playback can only be controlled from your connected device)
Note:
For some computers, you may need to access the audio control panel to manually set the
sound bar as below picture
When using DTH connection with TV, please refer below connection process diagram:
1. Using 2 RCA to AUX Cable
2. Using AUX To AUX Cable
Playing Audio via USB
When USB flash drive is inserted, press the input key of the sound bar to switch to USB input mode (in case
it doesn’t change automatically) with the LED indicator lighting up as purple (this mode isn't selectable on the
sound bar or remote control unless a USB flash drive is connected).
1. Ensure that your USB flash drive contains MP3 or WMA audio files (other file types not supported)
2. Connect the USB flash drive to the USB port on the sound bar (or your own USB extension cable
connected to the USB port); music will automatically play
3. The remote control includes USB input mode playback controls
10
ISSUES
SOLUTIONSPROBLEMS
No sound from
Sound
Bluetooth
SoundBar speakers
Distorted sound or echo
A device cannot connect
with the SoundBar
Quality of audio play from
a connected Bluetooth
device is poor.
The connected Bluetooth
device connects and
disconnects constantly
Specifications
Model
Technology
Drivers
Audio Output Power
Frequency Response
Signal-to-Noise Ratio
Adjust the Volume and make sure that the device and sound bar are connected properly.
On the remote control, select the correct audio input source.
lf you play audio from the TV through the SoundBar, make sure that the TV is muted.
Restart the soundbar and try pairing again
You have not enabled the Bluetooth function of the device. See the user manual of the device on
how to enable the function.
The device is not correctly connected.
The SoundBar is already connected with another Bluetooth device. Disconnect the connected device,
then try again.
The Bluetooth reception is poor. Move the device closer to the SoundBar, or remove any obstacle
between the device and the SoundBar.
The Bluetooth reception is poor. Move the device closer to the SoundBar, or remove any obstacle
between the device and the SoundBar.
ARENA 5000
BT/USB/AUX
2inch*2 SB + 4inch SW
10W*2+25W=45W R.M.S.
55Hz-20KHz
72dB
lmpedance
Power lnput
Bluetooth Operating Range
Dimensions
4Ω*2+8Ω
SMPS 110V-240V~50Hz/60Hz
Version: 4.2+EDR Range:up to 10m
Sound bar:68.5H*42D*750L mm
Subwoofer: 155W*300H*200D mm
Package Contents
Sound bar X 1
User Manual X 1
RCA to AUX Cable X 1 AUX to AUX Cable X 1
Mount Screws X 2
Wall Mount EVA Pads X 2Subwoofer X 1
Remote Control X 1
For any query or support, please reach out to us at:
Phone: +91-33-24162244 (Mon-Fri, 10 AM-7 PM)
WhatsApp: +91-8777281759
E-mail: customercare@mulo.in
Loading...
