Dear customer,

Congratulations and thank you for purchasing this high quality product. Please read the instruction manual carefully so that you will be able to make the
best possible use of the 3D SMART TV. Have fun watching.

IMPORTANT SAFETY IN STRUCTION S

• Incorrect usage will cause fire or electric shock. To prevent this, please do as required when you are installing, using and cleaning this machine.
To insure your safety and extend the life span of LED-TV, please read the following items carefully before using:

• The On/Off key on this product does not fully disconnect the TV from the main power supply. Unplug the power cord from the AC outlet
before connecting any Audio / Video cables to the LED TV.

• Do not place the LED TV on any unstable surface or furniture. Which may cause the product to fall, resulting in serious personal injuries and
damage the product. Only place on stable furniture, recommended for LED TV by its manufacturer.

• The LED panel used in this product is made of glass. Do not drop or impact the product with other objects, it may cause the panel broken. Be
careful with the broken glasses in case the panel is broken.

• The vents and openings at the back of the products are designed for ventilation. Do not cover or block these vents and openings. Insufficient
ventilation may cause overheating and / or shorten the life of the product. Do not insert any foreign objects (metals or flammable objects) into
the TV, which may cause electric shock or fire.

• Do not place the LED TV close to other furniture, furnishing or electronic products.

• This product is not designed for built-in installation; do not place in an enclosed place without proper ventilation.

• Keep this product away from direct sunlight or any heat sources such as radiator, heaters,stoves,and other heat generating products (including
adaptors and amplifiers).

• Do not use this product in wet and moist area or near water, such as kitchen sink, bathtub, washbasin, laundry tub, swimming pool or a wet basement.

• Do not place any water container on top of this product. The water may spill onto the product causing electric shock or fire.

• Do not place any type of candle or naked flames on the top or near the LED TV, which may cause fire.

• To clean the cabinet and LED panel, unplug the Power cord, use only a clean soft moistened cloth and gently wipe the display panel. Hard cloth
may scratch the panel surface. Never use dirty cloth, liquid cleaners or chemical cloth to clean it; such materials may damage the LED panel.

• Do not remove cover; there are no serviceable parts inside. Refer servicing to qualified services personnel only.

INSTALLIN G THE TV

Package Contents

Before installing your new TV, take a moment to inspect the package contents. Use the images below to ensure nothing is missing or damaged.
When you have completed your inspection, install the TV.

TABLE OF CON TENTS

• Welcome and safety notes

• Important safety instruc tions

• Installing the TV

• Package contents

• Installing the TV

• Installing the TV with a wall bracket

• Controls and connections

• Bottom and aside terminals

• Back side function keys

• Remote controller

• Replacing the batteries

• Connecting your devices

• Connecting your devices

• Setting up your network connection

• Description of operation

• Operation menu

• Channel Menu

• Picture Menu

• Sound Menu

• Time Menu

• Lock Menu

• Setup Menu

• PVR File System

• PC screen menu

• Media operation

• Install Internet and Apps

• Welcome page

• Settings

• Applications

• System restore

• How to view 3D

• Important safety information for viewing 3D content

• How 3D works

• 3D viewing distance and angle

• Troubleshooting & Technical support

• Technical specifications

For more information please visit http://mtlogic.com/le-427118mt

3
3
3
3
4
4
5
5
5
6
7
7
7
8
8
8
8
9
10
10
11
11
11
12
12
14
14
16
17
18
18
18
18
19
20
21

3D LED LCD HDTV with Stand

Remote Control with Batteries

4x 3D Glasses

Wireless keyboard

4 5

INSTALLIN G THE TV

After removing the TV from the box and inspecting the package contents you can begin installing the TV. Your TV can be installed in two ways:

• On a flat surface, using the included stand

• On a wall, using a VESA-standard wall mount (not included) to install the TV stand:

INSTALLIN G THE TV ON A WALL

To mount your TV on a wall, you will need a wall mount. Consult the information below to find the appropriate mount for your TV model:

Model LE-427118MT

Screw Size: M6
Screw Length: 14mm
Hole Pattern: 400mm (V) x 400mm (H)

Installing a TV on a wall requires lifting. To prevent injury or damage to the TV, ask someone to help you. Be sure the mount you choose is capable
of supporting the weight of the TV. After you have determined that you have the correct mount for your TV, you can begin the installation.

To install your TV on a wall:

1. Place the TV screen-down on a clean, flat surface. To prevent
scratches or damage to the screen, place the TV on a soft surface,
such as carpet, rug, or blanket.

2. Using a Phillips-head screwdriver, attach the base to the TV by
inserting and tightening the included screws.

3. Move the TV with attached stand into an upright position and place
on a flat, level, and stable surface.

4. To ensure proper ventilation, leave at least 1" of space between the
back of the TV and any other objects (walls, etc).

1. Disconnect any cables connected to your TV.

2. Place the TV face- down on a clean, flat, stable surface. Be sure the
surface is clear of debris that can scratch or damage the TV.

3. Remove the base stander by loosening and removing the screws

4. Attach your TV and wall mount to the wall, carefully following the
instructions that came with your mount. Use all mount bracket
rated for the weight/load of this TV. See the product specifications
for the weight of this TV.

CONTROL S AND CONNEC TIONS

Bottom and side terminals

VGA IN: Connect RGB cable from computer.
PC AUDIO In: Connect 3. 5mm connector from computer.
LAN: Connect Ethernet cable from home network.
AV IN: Connect S-video/audio in.
RF(DVB-T/C): Connect RF/Coaxial connector from cable or antenna.
Digital out: 2 channel digital audio.
YPBPR: Connect component (RGB) video.
HDMI (1,2,3): Connect HDMI devices.
USB: Connect a USB drive to play movies, music or photos.
APP USB(1,2): Connect a USB drive to play movies, music or photos or apps and for the wireless keyboard adapter.

BACK SID E FUNCTION KEYS

Menu: Display on-screen menu.
Channel Up/Down: Change the channel.
Volume Left/Right: Increase or decrease the loudness of the TVs audio.
SOURCE: Change the input device. With each press of the button, the TV will display a different input source.
STANDBY: Turn the TV on or off.

Digital out USB HDMI3 SD Card

LAN

recovery key

USB2
USB1

CI Slot

AV / YPbPr

HDMI 1 HDMI 2 SCART PC Audio VGA RF

STANDBY

VOL +

VOL -

CH +

CH -

MENU

SOURCE

en

Instruction Ma nual Instruction Ma nual

6 7

REMOTE CO NTROLLER

1. STANDBY : Turn the TV on or off.

2. MUTE: Press to turn ON/OFF the speaker output.

3. SOURCE: Input source conversion button.

4. PMODE: Press to change the current picture mode.

5. SMODE: Select the different sound mode directly.

6. SLEEP: Press to shift sleep time mode.

7. WWW.: In Smart TV mode quickly input letters "ww w.".

8. COM: In Smart TV mode quickly input letters ".com".

9. CHAR/NUM: In Smart TV mode switches between Letter and Number input modes.

10. DEL: In Smart TV mode deletes letters and numbers.

11. ALPHAN UMERIC BUT TONS: Enters letters and numbers.

12. -/--: Figures 0-99 are used to directly key in channel number.

13. RECALL: Press to return to the channel last viewed.

14.

: In Smart TV mode press to access the Home menu.

15. : Press to pop-up main menu, and press again to exit menu.

16. NAVIGATION buttons: Scrolls through menus or options.

17. OK: Selects menus or options and confirms your input.

18. MENU: Press to pop-up main menu, and press again to exit menu.

19. / EXIT: Press this button to return function or returns to the previous level.

20.

: In Smart TV mode press display the information of notice.

21. : In Smart TV mode press Into the list of programs.

22. : Search.

23.

/

: In Smart TV mode press Turn on/off Mouse Mood.

24. INFO: in TV mode press to Views the information of the current program and screen.

25. FAV: In TV mode press to displays Favorite program list.

26. AUTO: Press this button to auto adjust the screen.

27. TV/RADIO: Selects TV or Radio modes.

28. VOL +/-: Adjust the volume.

29. CH+/-: Change the channel up and down.

30. RED: Press this button to into the red item or page.

31. GREEN/3D: Press this button to into the green item or page; Activate 3D content.

32. YELLOW/L/R: Press this button to into the yellow item or
page + Adjust 3D movie L/R images to achieve best 3D effect.

33. BLUE: Press this button to into the blue item or page.

34. PVR: Press this button to record the current program.

35. EPG: Press this button to display Electronic Program Guide menu.

36. SUBTITLE: Press this button to show subtitles for the program you are watching, if available.

37. AUDIO / / : Press this button to select the audio language, if available.

38. TEXT/ : In TV mode press to switch TV into text mode or press text to quit text mode; Zoom out.

39. HOLD/ :Press this button to freeze or unfreeze the screen of text you are viewing; Zoom in.

40. REVEAL: Press this button to show or hide the TEXT.

41. SUBPAGE: In the mode of text, press this key to select subpage, Subpage can be select by directly
enter a4-digit number or pressing red, green or / " keys press this key again to return to normal text mode.

42. T.SHIFT/ : Press this button to select the time shift function; Play/Pause in PVR and MEDIA mode.

43. : Stop in PVR and MEDIA mode.

44. INDEX: Press this key to return to the index page directly.

45. SIZE: In the mode of text, it is used text to change the display scale.

46. : Fast reverse key in MEDIA mode.

47. : Fast forward key in MEDIA mode.

48. : Jump to previous track in MEDIA mode.

49. : Jump to next track in MEDIA mode.

21

63

5

10

7

94

8

21

25

31

35

39

43

47

1312

11

1514

1716

1918

2320

22

2724

26

2928

3330

32

3734

35

4138

40

4542

44

4946

48

REPLACI NG THE BATTERIE S

1. Open the battery cover.

2. Insert two AA batteries into the remote control. Make sure that the (+) and (-) symbols on the batteries match the (+) and (-) symbols inside
the battery compartment.

3. Close the battery cover.

• Use only good quality batteries.

• Inserting the batteries incorrectly may result in cracking or leakage that may cause a fire or result in injury.

• Dispose of old or dead batteries in accordance with local hazardous waste regulations.

• Keep batteries away from children and pets.

CONNEC TING YOUR DEVIC ES

Once you have determined the best available connection type on both your device and the TV, ensure you have the corresponding cable.
To connect a device to the TV:

1. Ensure both the TV and your device are off.

2. Connect the device and the TV Use the best available connection. See the "Device Connection Chart" shown below. Ensure each end of the
cable is securely connected.

3. Turn the TV on by pressing the Power/Standby button on the remote.

4. Turn your device on.

5. When you are ready to use your newly connected device, press the SOURCE button on the remote and select the connection type (HDMI, RGB,
etc) from the on-screen menu. Press OK.

6. Check the list of devices/connection types below for special instructions:

• Cable TV (without cable box/directly from wall) Perform a channel scan.

• RGB Make sure the desktop resolution on the PC is set to 1920 x 1080. Set the Screen Mode to Normal.

• DVD Player with DVI Connect left (white) and right (red) audio cables to the L and R ports next to the HDMI ports on the TV we strongly
recommend you to connect other devices with TV by HDMI cable which create the best result for quality of video/audio

SETT ING UP YOUR NET WORK CONNEC TION

Your TV is internet-ready and can be connected to your home network in two ways:

• Ethernet, using the RJ45 (LAN) connector on the left panel .

• Wireless, using your home wireless network.

Once you have connected to your home network and the Internet, you can use Apps to deliver popular online content to your TV.

en

Instruction Ma nual Instruction Ma nual
