MT Logic CL-1489MT User Manual

Instruction Manual

Gebruiksaanwijzing

Clock radio

Weather indication - hi-lo dimmer CL-1489MT

Instruction Manual

FRONT VIEW

1. ALARM 1

2. ALARM 2

3. TIME

4. PM INDICATOR

5. SLEEP

6. NAP TIMER

7. MEMORY

8. Weather forecast

TOP VIEW

9. DOWN

10. SET/MEMORY

11. ALARM 1-2

12. NAP/UP

13. VOLUME

14. SNOOZE/DIMMER

15. RADIO/SLEEP

BACK VIEW

16. BATTERY DOOR

17. DC SOCKET

CARE OF YOUR PRODUCT

• Place your clock radio on a stable surface, away from sources of direct sunlight or excessive heat or moisture.

• Protect your furniture when placing your units on a natural wood and lacquered finish by using a cloth or protective material between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger agents such as Benzine, thinner or similar materials can damage the surface of the unit. Make sure the unit is unplugged before cleaning.

• Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.

9 1113

15 1214

• If the unit is not to be used for a prolonged period, such as a month or longer, remove the batteries to prevent possible corrosion. Should the battery compartment become corroded or dirty, clean the compartment thoroughly and replace the batteries.

INSTALLATION

Plug the AC/DC adaptor to an AC household outlet, and then plug the DC jack to the back of the unit. Your clock radio is ready to work for you. For power saving purpose, the LED digits are preset at low brightness, press SNOOZE.DIMMER once to turn LED digits to high brightness if need.

BACKUP BATTERY INSTALLATION

Your clock radio requires one fresh CR2032 lithium battery (not included) to provide backup power to the clock in the event of a temporary power interruption.

1. Place your unit face down on a flat surface.

2. Slide and remove the battery cover at the bottom of your unit.

3. Insert one CR2032 lithium battery into the battery compartment with the “+”

side facing up as indicated.

4. Replace the battery cover.

Note this battery is only for backup if the AC power is interrupted. A fresh CR2032 battery could backup your clock continuously for around 3 days.

Instruction Manual

SETTING TIME, 12/24HR TIME AND THE SNOOZE DURATION

1. Press SET once, the hour digits flash. Press or to set the current hour (hold to advance rapidly).

2. Press SET again, the minute digits flash. Press

3. Press SET again, the display shows “24Hr” and flashes, Press “12Hr” or “24Hr” time format.

4. Press SET again, the display shows “05” and flashes, Press your snooze time from 5 to 60 minutes.

5. Press SET again or if no key pressed for approx. 10 seconds to exit the setting mode.

Note: when 12-hour time format is selected, the P (PM) icon will appear on the lower middle time display to indicate the afternoon time; there is no AM indicator.

or to set minutes.

or to select

SETTING THE ALARMS

1. Press AL 1.2 once, the A1 icon and the hour digits flash. Press or to set the alarm 1 hour.

2. Press AL 1.2 again to adjust minutes. Press

3. Press AL 1.2 again, LED displays “OFF” (alarm off). To select wake to sound sources, press

rd = wake-by-radio bu = wake-by-buzzer OFF = alarm off

4. Press AL 1.2 again, the A2 icon and the hour digits flash. Press or to set the alarm 2 hour. Repeat step 2) and 3) to set alarm 2.

5. Press AL1.2 again or no button around 10 seconds to exit alarm setting mode. When wake-to-radio or wake-to-buzzer is selected, the related alarm is turned on, indicated by apperance of the A1 and / or the A2 icon on the left side of the display.

or to select :-

or to set the alarm 1 minutes.

6. Press AL1.2 again or if no key pressed for approx. 10 seconds to exit the alarm setting mode.

STOPPING AND RESETTING THE ALARM TO COME ON THE NEXT DAY

When alarm 1 or 2 is sounding, the related A1 or A2 icon flashes. Press the AL 1.2 once to stop the alarm and reset it to come on the following day. After that A1 or A2 icon keep lighting up on the display.

Note: When alarm is sounding, press thes the nap timer or the radio and stop the alarm for the day.

SNOOZE OPERATION (default snooze duration is 5 minutes)

When alarm is sounding, presses come on again after the set snooze duration.

Note: if your second alarm activates while the first alarm is sounding or it is in the snooze mode, the second alarm overrides the first alarm (the first alarm is reset to come on the next day).

USING THE HI-LO DIMMER

Press done when the radio is off or the unit is not sounding.

USING THE NAP TIMER

The NAP Timer allows you to rest and automatically wake up in 5, 15, 30, 45, 60,75 or 90 minutes.

1. Press

2. Press

3. The nap icon lights up when the nap timer is counting. When the nap timer

to adjust the brightness of the LED time display. This can only be

/ NAP once, the display shows the nap icon and the default naptime

“05” (5 minutes).

/ NAP again to select your desired naptime. It will exit to time display

if no button pressed for around 5 seconds.

reaches 0, the alarm will sound and the nap icon will flash. Press once to stop the nap alarm , the nap icon will go off.

/ NAP or RADIO / SLEEP will activate

once, the alarm will be silenced and

/ NAP
