• 6 front and 6 rear outlets on 15A
version
• Rear outlets on back rotated for large
power packs
• 2 front and 10 rear outlets on 20A
version
• All outlets are switched
• LED indicators
• Resettable circuit breaker
• EMI/RFI filtering
• UL 1449 Recognized Component
• Lifetime warranty
technical datasheet
RackPro
19 inch rack mounted, 12 outlet AC surge suppressor
The RackPro is a twelve (12) outlet rack
mounted surge protector that provides
superior surge protection in a compact 1U
enclosure. The RackPro Series is constructed
with an all steel case and designed with
competitive specifications to cover all rack
mount surge needs.
Equipped with status indicator lights,
the RackPro continually monitors making
sure that the suppressor is protecting the
equipment. The amber LED indicator assures
that the power is being distributed to the
outlets, the green LED indicates a ground
is present and the red LED indicates surge
protection is present. These lights provide
peace of mind for all equipment plugged into
the RackPro.
Complete facility/site protection can be
achieved by using our wide range of AC and
DC power surge protection devices to prevent
surges entering equipment via their power
supply. The ZoneMaster range of protectors
combine a high level of protection and when
used in conjunction with the ZoneBarrier data
protection modules, provide the highest level
of protection available.
901-125 Rev I 170210
www.mtl-inst.com enquiry@mtl-inst.com
SPECIFICATION
All figures typical at 77°F (25°C) unless otherwise stated
Maximum surge current
50kA
Load current
15A or 20A
Working voltage
120V 50/60 Hz
Let-through voltage
400V, L-N, L-G, N-G
UL 1449 rating
400V
Joule rating
1800 joules
Response time
Instantaneous
Switch
Lighted on / off
Operating humidity
0% to 95% non-condensing
Maximum operating elevation
10,000 ft (3,000m)
Operating/storage temperature
-40°F to +185°F (-40°C to +85°C)
Power cord
15’ (457.2cm)
Dimensions
Length 19” (483mm)
Depth 4.25” (108mm)
Height 1.7” (43mm)
Weight 5 lbs. 8 oz. (2.63kg)
Model Outlets Maximum
surge
current
(kA)
Maximum
line
current
(A)
Working
voltage
(V)
Let-through
voltage
(V)
Connectors
RP35326 12 50 15 120 400 NEMA 5-15
RP35327 12 50 20 120 400 NEMA 5-20
Figure 1 Dimensions
ORDERING INFORMATION
Model number as per specification table
Figure 2 RackPro 15A features
Figure 3 RackPro 20A features
APPROVALS
Country Standard/Authority Approved for Product
United States
Canada
UL 1449 Recognized
Component
AC power product RP35326, RP35327
The give n data is o nly inte nded as a p roduc t descr iption a nd shou ld not be r egard ed as a leg al war ranty o f prope rtie s
or guarantee. In the interest of further technical developments, we reserve the right to make design changes.
