Chokes
1000V 360Hz
DC
Inductance mHMTE
Amps
1 35.00 1RB001 1 25 0.45 25RB001 1 80 0.75 80RB004 3 300 0.08 300RB001 3
1 60.00 1RB002 1 25 1.00 25RB002 2 80 1.25 DCA008005 3 300 0.135 300RB002 3
1 80.00 1RB003 1 25 1.275 DCA002504 2 92 0.20 DCA009201 3 300 0.32 300RB003 3
2 10.00 2RB001 1 25 1.75 DCA002503 2 92 0.60 DCA009202 3 450 0.055 450RB001 4
2 15.00 2RB002 1 25 4.00 DCA002505 2 92 1.00 DCA009203 3 450 0.11 450RB002 4
2 20.00 2RB003 1 32 0.85 DCA003201 2 110 0.25 110RB001 3 450 0.14 450RB003 4
2 50.00 DCA000204 1 32 1.62 DCA003202 2 110 0.30 DCA011002 3 450 0.25 450RB004 4
4 5.00 4RB001 1 32 2.68 DCA003203 2 110 0.45 DCA011003 3 500 0.043 500RB001 4
4 12.00 DCA000402 1 40 0.50 DCA004001 2 125 0.11 125RB001 3 500 0.09 500RB002 4
4 15.00 DCA000403 1 40 0.75 DCA004002 2 125 0.22 DCA012502 3 500 0.14 500RB003 4
4 25.00 DCA000404 2 40 1.00 DCA004003 2 125 0.50 125RB003 3 500 0.19 500RB004 4
9 2.00 9RB001 1 40 2.50 DCA004004 2 125 0.85 125RB004 3 600 0.04 600RB001 4
9 3.22 DCA000902 1 50 0.625 DCA005001 2 150 0.15 150RB001 3 600 0.11 600RB002 4
9 7.50 DCA000903 2 50 0.97 50RB002 2 150 0.22 DCA015002 3 600 0.18 600RB003 4
9 11.50 DCA000904 2 50 1.35 DCA005003 2 150 0.32 150RB003 3 700 0.044 700RB001 4
12 1.00 DCA001201 1 50 2.0 DCA005004 3 150 0.65 DCA015004 3 700 0.06 700RB002 4
12 2.10 DCA001202 2 62 0.35 DCA006201 3 200 0.12 200RB001 3 700 0.15 700RB003 4
12 4.00 DCA001203 2 62 0.61 DCA006202 3 200 0.21 DCA020002 3 850 0.036 850RB001 4
12 6.00 DCA001204 2 62 0.67 62RB003 3 200 0.40 200RB003 3 850 0.065 850RB002 4
18 0.65 DCA001801 1 62 1.20 62RB004 3 200 0.50 200RB004 3 850 0.11 850RB003 4
18 1.375 DCA001802 2 62 1.50 62RB005 3 240 0.09 240RB001 3 1000 0.02 1000RB001 4
18 2.75 DCA001803 2 80 0.31 80RB001 3 240 0.25 240RB002 3 1000 0.042 1000RB002 4
18 3.75 DCA001804 2 80 0.40 DCA008002 3 240 0.35 240RB003 3 1000 0.10 1000RB003 4
18 6.00 DC
Part Number
A001805 2 80 0.50 80RB003 3
Ref
Fig
DC
Amps
Inductance
mH
MTE
Part Number
Ref
Fig
DC
Inductance mHMTE
Amps
Part Number
Ref
Fig
DC
Inductance mHMTE
Amps
Part Number
Ref
Fig
