Page 1

For Parts Call 606-678-9623 or 606-561-4983

Safety • Assembly • Operation • Tips & Techniques • Maintenance • Troubleshooting • Parts Lists • Warranty

OPERATOR’S MANUAL

* Shown with Optional Electric Start

21-inch Self-Propelled Rotary Mower — Model Series 440

IMPORTANT

READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATION

Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-

covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-0019.

PRINTED IN U.S.A.

Troy-Bilt LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019

www.mymowerparts.com

FORM NO. 769-02166A

12/05 /2006

Page 2

www.troybilt.com

TROY-BILT LLC P. O. BOX

36 1 13 1

CLEVELAND, OH 44136

866-840-6483

330-558-7220

For Parts Call 606-678-9623 or 606-561-4983

This Operator’s Manual is an important part of your new lawn mower. It will help you assemble,

prepare, and maintain the unit for best performance. Please read and understand what it says.

Table of Contents

Slope Gauge........................................................ 3

Safe Operation Practices ................................... 4

Setup and Adjustment ....................................... 6

Operating Your Lawn Mower .............................. 8

Troy-Bilt LLC reserves the right to change product specifications, designs, and equipment without notice and without incurring obligation.

Maintaining Your Lawn Mower ......................... 10

Troubleshooting ................................................ 14

Off-Season Storage and Safety Labels .......... 15

Parts List ........................................................... 16

Finding and Recording Model Number

BEFORE ASSEMBLING YOUR NEW EQUIPMENT, please locate the model plate on the equipment and copy the information to the sample model plate provided to the right. You can locate the model plate by standing at the operating position and looking down at the rear of the deck. This information will be necessary to use the manufacturer’s web site, to obtain assistance from the Customer Support Department, or when contacting an authorized service dealer.

Customer Support

Please do

purchased, without ﬁrst contacting Customer Support.

If you have difficulty assembling this product or have any questions regarding the controls, operation, or maintenance of this unit, you can seek help from the experts. Choose from the options below:

• Visit

• Phone a Customer Support Representative at

• The engine manufacturer is responsible for all engine-related issues with regard to performance, power-rating, specifications,

www.troybilt.com

warranty, and service. Please refer to the engine manufacturer’s Owner’s/Operator’s Manual, packed separately with your unit, for more information.

NOT

return the unit to the retailer from which it was

1-866-840-6483.

www.mymowerparts.com

Page 3

3IGHTANDHOLDTHISLEVELWITHAVERTICALTREE

ORACORNEROFABUILDING

ORAFENCEPOST

&OLDALONGDOTTEDLINEREPRESENTSASLOPE



For Parts Call 606-678-9623 or 606-561-4983

Use this page as a guide to determine slopes where you may not operate safely.

Do not operate your lawn mower on such slopes.

Slope

Gauge

WARNING

Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet).

Operate WALK-BEHIND mowers across the face of slopes, never up and down slopes.

www.mymowerparts.com

Page 4

For Parts Call 606-678-9623 or 606-561-4983

WARNING: Engine Exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to State of California to cause cancer and birth defects or other reproductive harm.

Safe

Operation

Practices

WARNING

This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. When you see this symbol.

HEED ITS WARNING!

Your Responsibility

Restrict the use of this power machine to persons who read, understand and follow the warnings and instructions in this manual and on the machine.

DANGER: This machine was built to be operated according to the rules for safe operation in this manual. As with any type of power equipment, carelessness or error on the part of the operator can result in serious injury. This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death.

Children

Tragic accidents can occur if operator is not alert to presence of children. Children are often attracted to mower and mowing activity. They do not understand the dangers. Never assume that children will remain where you last saw them.

1. Keep children out of the mowing area and under watchful care of a responsible adult other than the operator.

2. Be alert and turn mower off if a child enters the area.

3. Before and while moving backwards, look behind and down for small children.

4. Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that may obscure your vision of a child who may run into the mower.

5. Keep children away from hot or running engines. They can suffer burns from a hot muffler.

6. Never allow children under 14 years old to operate a power

mower. Children 14 years old and over should read and

understand operation instructions and safety rules in this

manual and should be trained and supervised by a parent.

General Operation

1. Read this operator’s manual carefully in its entiret y before

attempting to assemble this machine. Read, understand,

and follow all instructions on the machine and in the

manual(s) before operation. Be completely familiar with

the controls and the proper use of this machine before

operating it. Keep this manual in a safe place for future

and regular reference and for ordering replacement parts.

2. This machine is a precision piece of power equipment,

not a plaything. Therefore, exercise extreme caution at all

times. Your unit has been designed to perform one job: to

mow grass. Do not use it for any other purpose.

3. Never allow children under 14 years old to operate this

machine. Children 14 years old and over should read and

understand the instructions in this manual and should

be trained and supervised by a parent. Only responsible

individuals who are familiar with these rules of safe

operation should be allowed to use this machine.

4. Thoroughly inspect the area where the equipment is to

be used. Remove all stones, sticks, wire, bones, toys

and other foreign objects, which could be tripped over or

picked up and thrown by the blade. Thrown objects can

cause serious personal injury. Plan your mowing pattern

to avoid discharge of material toward roads, sidewalks,

bystanders and the like. Also, avoid discharging material

against a wall or obstruction, which may cause discharged

material to ricochet back toward the operator.

5. To help avoid blade contact or a thrown object injury,

stay in operator zone behind handles and keep children,

bystanders, helpers and pets at least 75 feet from mower

while it is in operation. Stop machine if anyone enters

area.

6. Always wear safety glasses or safety goggles during opera

tion and while performing an adjustment or repair to protect

your eyes. Thrown objects which ricochet can cause serious

injury to the eyes.

7. Wear sturdy, rough-soled work shoes and close-fitting

slacks and shirts. Shir ts and pants that cover the arms and

legs and steel-toed shoes are recommended. Never operate

this machine in bare feet, sandals, slippery or light-weight

(e.g. canvas) shoes.

8. Do not put hands or feet near rotating parts or under cutting

deck. Contact with blade can amputate hands and feet.

9. A missing or damaged discharge cover can cause blade

contact or thrown object injuries.

10. Many injuries occur as a result of the mower being pulled

over the foot during a fall caused by slipping or tripping.

Do not hold on to the mower if you are falling; release the

handle immediately.

11. Never pull the mower back toward you while you are

walking. If you must back the mower away from a wall or

obstruction first look down and behind to avoid tripping and

then follow these steps:

a. Step back from mower to fully extend your arms.

b. Be sure you are well balanced with sure footing.

c. Pull the mower back slowly, no more than half way

toward you.

d. Repeat these steps as needed.

12. Do not operate the mower while under the influence of

alcohol or drugs.

13. Do not engage the self-propelled mechanism on units so

equipped while starting engine.

14. The blade control handle is a safety device. Never attempt

to bypass its operation. Doing so makes the safety device

inoperative and may result in personal injury through

contact with the rotating blade. The blade control handle

must operate easily in both directions and automatically

return to the disengaged position when released.

15. Never operate the mower in wet grass. Always be sure of

your footing. A slip and fall can cause serious personal

injury. If you feel you are losing your footing, release the

blade control handle immediately and the blade will stop

rotating within three seconds.

16. Mow only in daylight or good artificial light. Walk, never run.

17. Stop the blade when crossing gravel drives, walks or roads.

18. If the equipment should start to vibrate abnormally, stop the

engine and check immediately for the cause. Vibration is

generally a warning of trouble.

www.mymowerparts.com

Page 5

For Parts Call 606-678-9623 or 606-561-4983

19. Shut the engine off and wait until the blade comes to a

complete stop before removing the grass catcher or unclog-

ging the chute.

The cutting blade continues to rotate for a few seconds after

the engine is shut off. Never place any part of the body in

the blade area until you are sure the blade has stopped

rotating.

20. Never operate mower without proper trail shield, discharge

cover, grass catcher, blade control handle or other safety

protective devices in place and working. Never operate

mower with damaged safety devices. Failure to do so can

result in personal injury.

21. Muffler and engine become hot and can cause a burn. Do

not touch.

22. Only use parts and accessories made for this machine by

manufacturer. Failure to do so can result in personal injury.

23. If situations occur which are not covered in this manual,

use care and good judgment. Contact your dealer for

assistance.

Slope Operation

Slopes are a major factor related to slip and fall accidents, which can result in severe injury. Operation on slopes requires extra caution. If you feel uneasy on a slope, do not mow it. For your safety, use the slope gauge included as part of this manual to measure slopes before operating this unit on a sloped or hilly area. If the slope is greater than 15 degrees, do not mow it.

Do:

1. Mow across the face of slopes; never up and down. Exercise

extreme caution when changing direction on slopes.

2. Watch for holes, ruts, rocks, hidden objects, or bumps

which can cause you to slip or trip. Tall grass can hide

obstacles.

3. Always be sure of your footing. A slip and fall can cause

serious personal injury. If you feel you are losing your

balance, release the blade control handle immediately, and

the blade will stop rotating within 3 seconds.

Do Not:

1. Do not mow near drop-offs, ditches or embankments, you

could lose your footing or balance.

2. Do not mow slopes greater than 15 degrees as shown on

the slope gauge.

3. Do not mow on wet grass. Unstable footing could cause

slipping.

Service

Safe Handling Of Gasoline:

1. To avoid personal injury or property damage use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors are explosive. Serious personal injury can occur when gasoline is spilled on yourself or your clothes, which can ignite. Wash your skin and change clothes immediately.

2. Use only an approved gasoline container.

3. Never fill containers inside a vehicle or on a truck or trailer bed with a plastic liner. Always place containers on the ground away from your vehicle before filling.

4. Remove gas-powered equipment from the truck or trailer and refuel it on the ground. If this is not possible, then refuel such equipment on a trailer with a portable container, rather than from a gasoline dispenser nozzle.

5. Keep the nozzle in contact with the rim of the fuel tank or

container opening at all times until fueling is complete. Do

not use a nozzle lock-open device.

6. Extinguish all cigarettes, cigars, pipes and other sources

of ignition.

7. Never fuel machine indoor because flammable vapors will

accumulate in the area.

8. Never remove gas cap or add fuel while engine is hot or

running. Allow engine to cool at least two minutes before

refueling.

9. Never over fill fuel tank. Fill tank to no more than ½ inch

below bottom of filler neck to provide for fuel expansion.

10. Replace gasoline cap and tighten securely.

11. If gasoline is spilled, wipe it off the engine and equipment.

Move unit to another area. Wait 5 minutes before starting

engine.

12. Never store the machine or fuel container near an open

flame, spark or pilot light as on a water heater, space

heater, furnace, clothes dryer or other gas appliances.

13. To reduce fire hazard, keep mower free of grass, leaves,

or other debris build-up. Clean up oil or fuel spillage and

remove any fuel soaked debris.

14. Allow a mower to cool at least 5 minutes before storing.

General Service:

1. Never run an engine indoors or in a poorly ventilated area. Engine exhaust contains carbon monoxide, an odorless and deadly gas.

2. Before cleaning, repairing, or inspecting, make certain the blade and all moving parts have stopped. Disconnect the spark plug wire and ground against the engine to prevent unintended starting.

3. Check the blade and engine mounting bolts at frequent intervals for proper tightness. Also, visually inspect blade for damage (e.g., bent, cracked, worn) Replace blade with the original equipment manufacture’s (O.E.M.) blade only, listed in this manual. “Use of parts which do not meet the original equipment specifications may lead to improper performance and compromise safety!”

4. Mower blades are sharp and can cut. Wrap the blade or wear gloves, and use extra caution when servicing them.

5. Keep all nuts, bolts, and screws tight to be sure the equip ment is in safe working condition.

6. Never tamper with safety devices. Check their proper operation regularly.

7. After striking a foreign object, stop the engine, discon nect the spark plug wire and ground against the engine. Thoroughly inspect the mower for any damage. Repair the damage before starting and operating the mower.

8. Never attempt to make a wheel or cutting height adjust

ment while the engine is running.

9. Grass catcher components, discharge cover, and trail

shield are subject to wear and damage which could

expose moving par ts or allow objects to be thrown. For

safety protection, frequently check components and re-

place immediately with original equipment manufacturer’s

(O.E.M.) par ts only, listed in this manual. “Use of parts

which do not meet the original equipment specifications

may lead to improper performance and compromise

safety!”

10. Do not change the engine gover nor setting or over-rev the engine. The governor controls the maximum safe operating speed of the engine.

11. Maintain or replace safety labels, as necessar y.

12. Observe proper disposal laws and regulations. Improper

disposal of fluids and materials can harm the environment.

Safe

Operation

Practices

WARNING

This symbol points out important safety instructions, which if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all

instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. When you see this symbol.

HEED IT’S WARNING!

Your Responsibility

Restrict the use of this power machine to persons who read, understand and follow the warnings and instructions in this manual and on the machine.

www.mymowerparts.com

Page 6

Setup and

Adjustment

NOTE: Stand behind the mower as if you were going to operate it. Your right hand corresponds to the right side of the mower; your left hand corresponds to the left side of the mower.

IMPORTANT: For shipping purposes your mower is set with the wheels in a low cutting height position. For best results raise the cutting position until it is determined which height is best for your lawn, refer to Adjustment section for instructions.

For Parts Call 606-678-9623 or 606-561-4983

NOTE: This Operator’s Manual covers several models. Lawn Mower features vary by model. Not all features

Figure 3-1: Unfold handle and tighten hardware.

Hardware Pack

Wing Nuts (2)

Figure 3-2: Secure handle to handle mounting brackets.

Carriage Bolts (2)

discussed (or engines pictured) in this manual are applicable to all Lawn Mower models.

1. Follow the steps below to position the handle.

a. Lift the upper handle up from the folded position

and pull it back to the extended position. See Figure 3-1. Do not crimp cables. The handle should click into this position.

b. Make sure the carriage bolt is seated properly in

the handle. Tighten star knobs to secure upper handle to the lower handle.

2. Follow these steps to secure the handle. See Figure 3-2.

a. Remove the hairpin clip from the pivot rod. Using a

pair of pliers, insert hairpin clip into the other hole on the rod. Repeat on other side.

b. Insert a carriage bolt from the hardware pack into

the upper hole on the handle mounting bracket. Secure with one plastic wing nut, also included in the hardware pack. Repeat on other side.

3. The rope guide is attached to the right side of the upper handle. Loosen the wing nut which secures the rope guide. See Figure 3-3.

a. Hold the blade control against upper handle.

b. Pull starter rope out of the engine. Release the

blade control.

c. Slip starter rope into rope guide.

d. Tighten wing nut.

4. Secure cables to the lower handle using the cable ties. See Figure 3-4. Insert posts on cable ties into holes provided on the lower handle. Pull cable ties tight and trim excess.

NOTE: This Operator’s Manual covers several models. Lawn Mower features vary by model. Not all features discussed (or engines pictured) in this manual are applicable to all Lawn Mower models.

Figure 3-3: Pull recoil starter through rope guide and tighten.

www.mymowerparts.com

Figure 3-4: Use cable ties to secure cables to lower handle.

Page 7

For Parts Call 606-678-9623 or 606-561-4983

5. Follow steps below to assemble the grass catcher:

a. Place bag over frame so that its black plastic side

is at the bottom. Check that the bag is turned right side out before assembling (warning label will be on the outside).

b. Slip plastic channel of grass bag over hooks on

the frame. See Figure 3-5. All the plastic channels except center top of bag attach from outside of bag.

c. Attach center top of bag from inside of bag.

6. To attach the grass catcher. See Figure 3-6.

a. Lift rear discharge door.

b. Place grass catcher on the pivot rod. Let go

of discharge door so that it rests on the grass catcher.

Adjustments

Cutting Height

An adjusting plate and thumb lever at each wheel provides cutting height adjustment. Each lever must be moved to the same position to ensure an even cut.

1. Pull the lever out and away from the mower. See Figure 3-7.

2. Move the lever forward or back for desired cutting height.

3. Release lever towards mower deck.

Figure 3-5: Assemble the grass catcher (if needed)

Setup and

Adjustment

WARNING

Never operate mower

unless the hooks on

the grass catcher are

firmly seated on the

pivot rod and the rear

discharge door rests

firmly against top of

the grass catcher.

Figure 3-6: Attach the grass catcher.

Figure 3-7: Use lever at each wheel to adjust cutting height.

IMPORTANT: This unit is shipped without gasoline or oil in the engine. Fill up gasoline and oil as instructed in the accompanying engine manual BEFORE operating your mower.

www.mymowerparts.com

Page 8

Operating

Your Lawn

Mower

For Parts Call 606-678-9623 or 606-561-4983

Know Your Lawn Mower

Blade Control

Drive

Control

Recoil

Starter

Electric Starter

Cutting Height Adjustment Lever (one at each wheel)

WARNING

The blade control

mechanism is a

safety device. Never

attempt to bypass its

operations.

Use extreme care

when handling gasoline. Gasoline is extremely flammable

and the vapors are

explosive. Never fuel

the machine indoors

or while the engine

is hot or running.

Extinguish cigarettes,

cigars, pipes and

other sources of

ignition.

* Shown with Optional Electric Starter

Figure 4-1

Now that you have setup your lawn mower for operation, it’s important to become acquainted with its controls and features. This knowledge will allow you to use your new equipment to its fullest potential.

Blade Control

The blade control is attached to the upper handle of the mower. Depress and squeeze it against the upper handle to operate the unit. Release it to stop engine and blade.

WARNING: This blade control mechanism is a safety device. Never attempt to bypass its operations.

Drive Control

The drive control is located on the underside of the upper handle and is used to engage the drive. Squeeze it against the upper handle to engage the drive; release it to slow down or stop mower from propelling. See Figure 4-1.

Cutting Height Adjustment Levers

One adjustment lever is located on each wheel and is used to adjust the cutting height. All four levers have to be at the same relative position to ensure a uniform cut.

Recoil Starter

The recoil starter is attached to the right lower handle. Stand behind the unit and pull the recoil starter rope to start the unit.

Electric Start Ignition Switch (If

Equipped)

The ignition switch is located on the left side of the handle panel. It is used only for the electric starter.

Gas and Oil Fill-Up

1. Check oil level and add oil if necessary. Follow engine manual for this.

2. Service the engine with gasoline as instructed in the engine manual. See Engine manual for location of oil and gas fill.

WARNING: Use extreme care when handling gasoline. Gasoline is extremely flammable and the vapors are explosive. Never fuel the machine indoors or while the engine is hot or running. Extinguish cigarettes, cigars, pipes and other sources of ignition.

www.mymowerparts.com

Page 9

For Parts Call 606-678-9623 or 606-561-4983

WARNING: The operation of any lawn mower can result in foreign objects being thrown into the eyes, which can damage your eyes severely. Always wear safety glasses while operating the mower, or while performing any adjustments or repairs on it.

Starting Engine

WARNING: Be sure no one other than the operator is standing near the lawn mower while starting engine or operating mower. Never run engine indoors or in enclosed, poorly ventilated areas. Engine exhaust contains carbon monoxide, an odorless and deadly gas. Keep hands, feet, hair and loose clothing away from any moving parts on engine and lawn mower.

1. Push primer (if equipped) three times. Wait about two seconds between each push. See Figure 4-2. In temperature around 55° F or below, prime five times. Do not prime to restart a warm engine.

2. Standing behind the mower, squeeze the blade control against upper handle. See Figure 4-2.

3. Recoil Start: Grasp recoil starter handle and pull rope out with a rapid, continuous, full arm stroke. See Figure 4-2. Keeping a firm grip on the starter handle, let the rope rewind slowly. Repeat until engine cranks. Let the rope rewind each time slowly.

Electric Start (If Equipped): Turn ignition key to the

right to start the engine. Release the key after the engine starts.

Stopping Engine

1. Release blade control to stop the engine and blade.

2. Disconnect spark plug wire from spark plug and ground against the engine.

WARNING: Wait for the blade to stop completely before doing any work on the mower or to remove the grass catcher.

Using Your Lawn Mower

WARNING: Never operate your mower without either the rear door or the entire grass catcher assembly firmly secured.

Be sure lawn is clear of stones, sticks, wire, or other objects which could damage lawn mower or engine. Such objects could be accidently thrown by the mower in any direction and cause serious personal injury to the operator and others.

Figure 4-2

WARNING: If you strike a foreign object, stop the engine. Remove wire from the spark plug, thoroughly inspect mower for any damage, and repair damage before restarting and operating. Extensive vibration of mower during operation is an indication of damage. The unit should be promptly inspected and repaired.

1. Once the engine is running, squeeze the drive control against the upper handle to propel mower.

2. For best results, do not cut wet grass.

3. For a healthier lawn, never cut off more than onethird of the total length of the grass.

Using as Mulcher

For mulching grass, remove the grass catcher from the mower. The rear discharge door should be closed.

1. For effective mulching, do not cut wet grass.

2. New or thick grass may require a narrower cut. Adjust ground speed according to condition of lawn.

3. If the grass has been allowed to grow in excess of 4 inches, mulching is not recommended. Use the grass catcher to bag clippings instead.

Using Grass Catcher

You can use the grass catcher to collect clippings while you are operating the mower.

1. Attach grass catcher following instructions on page

7. Grass clippings will automatically collect in bag as you run mower. Operate mower till grass bag is full.

2. Stop engine completely by releasing the blade control. Make sure that the unit has come to a complete stop.

3. Lift discharge door and pull grass bag up and away from the mower to dispose of the grass clippings.

Operating

Your Lawn

Mower

WARNING

The operation of any

lawn mower can result

in foreign objects being thrown into

the eyes, which can

damage your eyes

severely. Always wear

safety glasses while

operating the mower,

or while performing

any adjustments or

repairs on it.

Be sure no one other

than the operator is

standing near the lawn

mower while starting

engine or operating

mower. Never run engine indoors or

in enclosed, poorly

ventilated areas. En-

gine exhaust contains

carbon monoxide, an

odorless and deadly

gas. Keep hands, feet,

hair and loose clothing

away from any moving

parts on engine and

lawn mower.

www.mymowerparts.com

Page 10

For Parts Call 606-678-9623 or 606-561-4983

Maintaining

Your Lawn

Mower

*Shown w/ Optional Electric Start

Lubrication

1. Lubricate pivot points on the blade control at least once a season with light oil. The blade control must operate freely in both directions. See Figure 5-1.

2. Lubricate the wheels at least once a season with light oil (or motor oil). If wheels are removed for any reason, lubricate surface of the pivot arm and inner surface of the wheel with light oil. See Figure 5-1.

3. Lubricate the torsion spring and pivot point on the rear discharge door periodically with light oil to prevent rust. See Figure 5-1.

4. The transmission is pre-lubricated and sealed at the factory and does not require lubrication.

5. Follow the accompanying engine manual for lubrication schedule and instruction for engine lubrication.

WARNING

Always stop engine,

disconnect spark

plug, and ground

against engine before

cleaning, lubricating

or doing any kind of

maintenance on your

machine.

We do not recommend

the use of pressure

washers or garden

hose to clean your

unit. These may cause

damage to electric

components, spindles,

pulleys, bearings, or

the engine. The use

of water will result in

shortened life and

reduce serviceability.

Figure 5-1

Figure 5-2

General Recommendations

1. Always observe safety rules when performing any maintenance.

2. The warranty on this lawn mower does not cover items that have been subjected to operator abuse or negligence. To receive full value from warranty, operator must maintain the lawn mower as instructed here.

3. Changing of engine-governed speed will void engine warranty.

4. All adjustments should be checked at least once each season.

5. Periodically check all fasteners and make sure these are tight.

WARNING: Always stop engine, disconnect spark plug, and ground against engine before cleaning, lubricating or doing any kind of maintenance on your machine.

Deck Care

1. Disconnect spark plug wire. Drain gasoline from lawn mower, or place a piece of plastic under the gas cap.

2. Tip mower so that it rests on the housing. Keep the side with the air cleaner facing up. Hold mower firmly.

WARNING: Never tip the mower more than 90 degrees in any directions and do not leave the mower tipped for any length of time. Oil can drain into the upper part of the engine causing a starting problem.

3. Scrape and clean the underside of the deck with a suitable tool. Do not spray with water.

4. Put the mower back on its wheels on the ground. If you had put plastic under the gas cap earlier, make sure to remove it now.

Engine Care

1. Maintain oil level as instructed in engine manual.

2. Service air cleaner every 25 hours under normal conditions. Clean every few hours under extremely dusty conditions. Refer to engine manual.

3. Clean spark plug and reset the gap once a season. Check engine manual for correct plug type and gap specifications.

4. Clean engine regularly with a cloth or brush. Keep the cooling system (blower housing area) clean to permit proper air circulation. Remove all grass, dirt and combustible debris from muffler area.

Replacing Rear Flap

1. To remove rear flap, lift rear door, and press flap in on either side to remove from hole. See Figure 5-2.

2. Remove flap from opposite hole and replace with new flap in the opposite order and manner of removal.

www.mymowerparts.com

Page 11

Blade Care

WARNING: When removing cutting blade for sharpening or replacement, protect your hands with a pair of heavy gloves or use a heavy rag to hold blade.

For Parts Call 606-678-9623 or 606-561-4983

1. Disconnect spark plug wire from spark plug. Turn mower on its side making sure that the air filter and the carburetor are up.

2. Remove bolt, blade bell support, blade, and blade adapter from the engine crankshaft. See Figure 5-3.

3. The blade can be sharpened with a file or on a grinding wheel. Do not attempt to sharpen the blade while it is still on the mower. When sharpening blade, follow original angle of grind. Grind cutting edges equally to keep blade balanced.

4. Remove blade from the adapter for testing balance. Balance the blade on a round shaft screwdriver to check. Remove metal from the heavy side until it balances evenly.

WARNING: An unbalanced blade will cause excessive vibration when rotating at high speeds. It may cause damage to mower, and could break causing personal injury.

5. Lubricate the engine crankshaft and the inner surface of the blade adapter with light oil. Slide the blade adapter onto the engine crankshaft. Place the blade on the adapter such that the side of the blade marked “Bottom” (or with part number) faces the ground when the mower is in the operating position. Make sure that blade is aligned and seated on blade adapter flanges.

6. Place blade bell support on the blade. Align notches on the blade bell support with small holes in blade. Replace hex bolt and tighten hex bolt to torque: 450 in. lbs. min., 600 in. lbs. max.

To ensure safe operation of your mower, periodically check the blade bolt for correct torque.

Belt Care

1. Remove two shoulder screws securing front drive cover to mower deck. See Figure 5-4. Press inward on sides of front drive cover and release tabs that secure it to the height adjuster brackets. Remove drive cover from mower.

2. Loosen screw holding belt tension spring to transmis sion. See Figure 5-4 inset. Do not remove screw completely. As you loosen it, tension on the belt will be released.

3. Push transmission up slightly and slide belt off the transmission pulley. Lift mower to access belt from underside of mower. Slide belt off of engine pulley and around the blade. See Figure 5-5.

Figure 5-3

Figure 5-4

Figure 5-5

4. Replace with new belt, working around blade. Make sure belt is firmly seated on engine pulley while pulling from the other side and sliding it around the transmission pulley. Tighten screw loosened earlier to secure belt tension spring to the transmission. Reassemble front drive cover.

Maintaining

Your Lawn

Mower

WARNING

When removing

the cutting blade

for sharpening or

replacement or

when sliding the belt

around it, protect

your hands with a

pair of heavy gloves

or use a heavy rag to

hold the blade.

An unbalanced blade

will cause excessive vibration when rotating at high speeds. It

may cause damage

to mower, and could

break causing per-

sonal injury.

www.mymowerparts.com

Page 12

For Parts Call 606-678-9623 or 606-561-4983

Maintaining

Your Lawn

Mower

WARNING

Batteries contain

sulfuric acid which

may cause burns.

Do not short circuit

or mutilate batteries

in any way. Do not put batteries in fire as these may burst

or release toxic

materials.

Replacing Battery (If Equipped)

WARNING: Batteries contain sulfuric acid which may cause burns. Do not short circuit or mutilate batteries in any way. Do not put batteries in fire as these may burst or release toxic materials.

1. Loosen star knobs securing upper and lower handles and carefully fold the upper handle down toward the lower handle as shown in Figure 5-6.

2. Remove the two screws securing battery cover to battery housing and place them to the side. See Figure 5-6.

3. Open battery cover, remove positive and negative leads from battery, remove and replace with new battery. Connect the positive lead to the positive side of the battery pack, then connect the negative side.

NOTE: The battery you have may differ slightly from the one shown in Figure 5-7. Refer to the Parts List.

IMPORTANT: When replacing battery pack in handle panel, battery pack must be positioned with the positive terminal to the left side and the negative terminal to the right side of panel (Positive terminal is closest to the key switch). See Figure 5-7. Replacing battery pack incorrectly will cause serious damage.

4. Reattach battery cover to battery housing by securing with the two screws removed earlier, making sure to snap the wire conduit on the left into place on the housing.

5. Fold handles back up and tighten star knobs.

Charging Battery (If Equipped)

Figure 5-6

Figure 5-7

The battery contains

corrosive fluid and

toxic material; handle

with care and keep

away from children.

Do not puncture,

disassemble, mutilate

or incinerate the

battery. Explosive

gases could be

vented during charg-

ing or discharging.

Use in a well venti-

lated area, away from

sources of ignition.

Use only the battery

charger supplied with

this mower.

WARNING: The battery contains corrosive fluid and toxic material ; handle with care and keep away from children. Do not puncture, disassemble, mutilate or incinerate the battery. Explosive gases could be vented during charging or discharging. Use in a well ventilated area, away from sources of ignition.

NOTE: The special designed plug on the charger will only fit into the plug on the battery box.

1. Plug the battery charger into the port on the underside of the battery housing. See Figure 5-8.

2. Insert the battery charger plug into a standard 120 volt household outlet. Charge battery for 8 to 10 hours before initial use. Do not charge longer than 12 hours. The battery should only need to be charged upon initial setup and after any other extended periods of non-use.

3. After charging, disconnect charger plug from outlet first, then disconnect charger lead from battery.

Figure 5-8

IMPORTANT: Do not remove the battery pack from the electric starter housing for any reason other than replacement.

IMPORTANT: Always plug charger lead into battery pack lead first, and then insert battery charger plug into 120 volt standard household outlet. Follow this order of action every time you charge the battery.

www.mymowerparts.com

Page 13

For Parts Call 606-678-9623 or 606-561-4983

Replacing Fuse (If Equipped)

The electric starter circuit and battery are protected by a 40 ampere fuse. If the fuse burns out, the electric starter will not operate. If the unit fails to start with the electric starter, perform the following steps to check the fuse inside the battery housing:

1. Open the battery cover as described in Replacing Battery. See Figure 5-6.

2. Remove fuse from socket and inspect as shown in Figure 5-9. If it is burned out, replace with standard automotive 40 ampere fuse.

3. Carefully place wiring back into housing, close battery cover, and fold upper handle back into place.

NOTE: The engine can be started manually if the fuse burns out.

Maintaining

Your Lawn

Mower

Off-Season Storage

The following steps should be taken to prepare your lawn mower for storage.

• Clean and lubricate mower thoroughly as described in the lubrication instructions.

• We do not recommend the use of a pressure washer or garden hose to clean your unit.

• Refer to engine manual for correct engine storage instructions.

• Coat mower’s cutting blade with chassis grease to prevent rusting.

• Store mower in a dry, clean area. Do not store next to corrosive materials, such as fertilizer.

When storing any type of power equipment in a poorly ventilated or metal storage shed, care should be taken to rust-proof the equipment. Using a light oil or silicone, coat the equipment, especially cables and all moving parts of your lawn mower before storage.

Battery (If Equipped)

The battery must be stored with a full charge. Extended storage of a discharged battery will reduce life and capacity of the battery.

Figure 5-9

WARNING

Do not remove the

battery pack from the

electric starter housing

for any reason other

than replacement.

The engine can be

started manually if the

fuse burns out.

www.mymowerparts.com

Page 14

For Parts Call 606-678-9623 or 606-561-4983

Trouble

Shooting

For repairs beyond

the minor adjust-

ments listed here,

contact an authorized

service dealer.

Problem

Engine fails to start

Engine runs erratic

Engine overheats

Cause

1. Blade control disengaged.

2. Spark plug wire disconnected.

3. Fuel tank empty or stale fuel.

4. Engine not primed (if equipped).

5. Faulty spark plug.

6. Blocked fuel line.

7. Engine flooded.

8. Burnt fuse. (Electric Start Only)

1. Spark plug wire loose.

2. Blocked fuel line or stale fuel.

3. Vent in gas cap plugged.

4. Water or dirt in fuel system.

5. Dirty air cleaner.

6. Carburetor out of adjustment.

1. Engine oil level low.

2. Air flow restricted.

3. Carburetor not adjusted properly.

Remedy

1. Engage blade control.

2. Connect wire to spark plug.

3. Fill tank with clean, fresh gasoline.

4. Prime engine as instructed in “Operating Your Lawn Mower”.

5. Clean, adjust gap, or replace.

6. Clean fuel line.

7. Wait a few minutes to restart, but do not prime.

8. Replace fuse (see Maintenance section)

1. Connect and tighten spark plug wire.

2. Clean fuel line; fill tank with clean, fresh gasoline.

3. Clear vent.

4. Drain fuel tank. Refill with fresh fuel.

5. Refer to engine manual.

6. Refer to engine manual.

1. Fill crankcase with proper oil.

2. Remove blower housing and clean.

3. Refer to engine manual.

Occasional skips

(hesitates) at

high speed

Idles poorly

Excessive

Vibration

Mower will not

mulch grass

Uneven cut

Mower will not

self propel

1. Spark plug gap too close.

2. Carburetor idle mixture adjustment improperly set.

1. Spark plug fouled, faulty or gap too wide.

2. Carburetor improperly adjusted.

3. Dirty air cleaner.

1. Cutting blade loose or unbalanced.

2. Bent cutting blade.

1. Wet grass.

2. Excessively high grass.

3. Dull blade.

1. Belt not installed properly

2. Debris clogging drive operation.

3. Damaged or worn belt.

1. Adjust gap to .030”.

2. Refer to engine manual.

1. Reset gap to .030” or replace spark plug.

2. Refer to engine manual.

3. Refer to engine manual.

1. Tighten blade and adapter. Balance blade.

2. See an authorized service dealer.

1. Do not mow when grass is wet; wait until later to cut.

2. Mow once at a high cutting height, then mow again at desired height or make a narrower cutting path.

3. Sharpen or replace blade.

1. Sharpen or replace blade.1. Dull blade.

1. Check belt for proper pulley installation and movement.

2. Stop engine, disconnect spark plug wire, and clean out debris.

3. Inspect and replace belt.

www.mymowerparts.com

Page 15

N OD

,YR

KSIR EHT ECUDER O

ELNU ETARE

REVOC EGRAH

CSI

SSARG

P R

EPOR

P STI N

I SI RE

.YL

ETAIDEMMI EC

ALPER

MAD F

A TEE

dna SDN

PEE

PEEK • MORF YAWA TEEF DNA SDNAH

.STRAP GNITATOR

NWORHT EB NAC TAHT STCEJBO EVOMER •

.NOITCERID YNA NI EDALB EHT YB

SALG YT

EFAS

EHTO RO

NERDL

NEHW

M TON OD

• .DN

ORA ERA

TON

OD .SEPOLS

O NOITUAC ARTXE ES

•

NAH

T RETAER

G S

EPOLS WOM

REVEN

.NW

PU REVEN ,SSO

OL .TE

F RUOY OT ESOLC REWOM LLUP

ELI

DNA

EROF

EB DNI

DNA NWOD

.SDRAWKCAB GN

VOM

HTAE

RO YRUJN

I SUO

IRE

S D

,DLEIHS GNIL

ART

,LORTNOC

( SECIVE

YTEFAS PEEK LAUNAM S'ROTA

O DAER

.YLETAIDEMMI ECALPER ,DEGAMAD FI .GNIKROW DNA ECALP NI )CTE ,REVOC EGRAHCSID

1 XA

123S

TO REDUCE THE RISK OF INJURY, DO NOT

OPERATE UNLESS DISCHARGE COVER OR GRASS CATCHER IS IN ITS PROPE R PLA CE. IF DAMAGED, REPLACE IMMEDIATELY.

For Parts Call 606-678-9623 or 606-561-4983

Safety Labels Found On Your Lawn Mower

Safety

Labels

WARNING

DO NOT remove safety (or any) labels from mower for any reason.

www.mymowerparts.com

Page 16

For Parts Call 606-678-9623 or 606-561-4983

Model Series 440

www.mymowerparts.com

Page 17

For Parts Call 606-678-9623 or 606-561-4983

Ref. Part No. Description

1 747-1161A Blade Control

2 749-1092A Upper Handle

749-1233D† Upper Handle

3 747-04080 Grass Catcher Frame

4 749-0928A Lower Handle

5 720-0279 Wing Nut

6 710-1205 Rope Guide

7 710-1174 Carriage Bolt ,5/16-18 x 2

8 664-04011 Grass Bag Assembly

9 720-04072 Hand Knob

10 750-04595 Sleeve Spacer - LH

11 726-0240 Cable Tie

12 710-0703 Carriage Bolt ,1/4-20

13 731-04134A Rear Discharge Door

14 710-04531 Screw 1/4-20

15 731-04204 Bail Cover

16 732-04090A Torsion Spring - RH

17 734-04014B Rear Wheel, 8” x 2.125”

18 731-04150C Rear Baffle

19 736-0474 Washer, 1.5” OD

20 787-01277 Deck - 21”

21 716-0102 Snap Ring

22 782-5002B Front Baffle

23 748-04015A Blade Adapter w/ Pulley

24 742-0741 21” Standard Cut Blade

25 710-1257 Hex Bolt , 3/8-24 x 2.5

26 687-02044 Pivot Plate Assembly

27 736-0524B Blade Bell Support

28 787-01298 Height Adjustment Plate - RH

787-01299 Height Adjustment Plate - LH

29 720-0426 Adjustment Lever Knob

30 732-0706 Front Lever - RH

732-0707 Front Lever - LH

31 738-0507B Shoulder Screw

32 734-04018A Front Wheel, 8” x 2.125”

33 710-1241 Screw, 1/4-15 x 1.000

34 746-1132 Control Cable - 40.75”

35 750-04594 Sleeve Spacer - RH

36 731-05642 Trailshield

37 782-7551A Wheel Dust Cap

Ref. Part No. Description

38 712-0397 Wing Nut, 1/4-20

39 747-04587 Rear Door Pivot Rod

40 732-04175 Spring Lever

41 687-02071A Pivot Arm Assembly - RH

687-02070A Pivot Arm Assembly - LH

42 710-1652 AB Screw

43 712-04065 Flange Lock Nut, 3/8-16

44 714-0104 Hairpin Clip

45 710-0654A TT Sems Screw, 3/8-16 x 1.00

46 687-02193 Ht. Adj. Assy. Front - LH

687-02194 Ht. Adj. Assy. Front - RH

47 687-02270 Rear Handle Bracket Assy. - LH

687-02271 Rear Handle Bracket Assy. - RH

48 747-1214 Drive Control

49 710-1650 Shoulder Screw

50 746-04203 Drive Cable

746-04282† Drive Cable

51 754-0637A V-Belt

52 618-04376A Transmission Assembly

53 731-05020A Front Drive Cover

54 732-1043 Belt Tension Spring

55 682-0015 Bearing Assembly

56 736-0447 Wave Washer

57 710-0216 Hex Screw

58 715-0221 Dowel Pin

59 717-1762 Gear, 14T - RH

717-1761 Gear, 14T - LH

60 725-0157† Cable Tie

61 725-04293† Electric Starter Harness Assembly

62 725-04329† Battery Charger 12V

63 725-0201† Key

64 710-1667A† Screw, #10-16 x .75

65 725-04323† 12 Volt Battery

66 728-0199† Plastic Rivet

67 725-04347† Key Switch

68 710-0136† Screw, 1/4-20 x 1.75

69 736-0270† Bell Washer

70 731-05459† Electric Start Battery Housing

71 712-04064† Flange Lock Nut 1/4-20

† Electric Start Models

Parts List

For parts and/or

accessories

please call

1-866-840-6483, or

1-330-558-7220.

www.troybilt.com

IMPORTANT

For a proper working

machine, use Factory

Approved Parts.

V-BELTS are specially

designed to engage

and disengage safely.

A substitute (non OEM)

V-Belt can be danger-

ous by not disengaging

completely.

www.mymowerparts.com

Page 18

For Parts Call 606-678-9623 or 606-561-4983

MANUFACTURER’S LIMITED WARRANTY FOR

The limited warranty set forth below is given by Troy-Bilt LLC with respect to new merchandise purchased and used in the United States, its possessions and territories.

“Troy-Bilt” warrants this product against defects in material and workmanship for a period of two (2) years commencing on the date of original purchase and will, at its option, repair or replace, free of charge, any part found to be defective in materials or workmanship. This limited warranty shall only apply if this product has been operated and maintained in accordance with the Operator’s Manual furnished with the product, and has not been subject to misuse, abuse, commercial use, neglect, accident, improper maintenance, alteration, vandalism, theft, fire, water, or damage because of other peril or natural disaster. Damage resulting from the installation or use of any part, accessory or attachment not approved by Troy-Bilt for use with the product(s) covered by this manual will void your warranty as to any resulting damage.

Normal wear parts are warranted to be free from defects in material and workmanship for a period of thirty (30) days from the date of purchase. Normal wear parts include, but are not limited to items such as: batteries, belts, blades, blade adapters, grass bags, rider deck wheels, seats, snow thrower skid shoes, shave plates, auger spiral rubber and tires.

HOW TO OBTAIN SERVICE : Warranty service is available, WITH PROOF OF PURCHASE, through yo ur local authorized service dealer. To locate the dealer in your area, check your Yellow Pages, or contact Troy- Bi lt LLC at P.O. Box 3 61131, Cl eveland, Ohio 441360019, or call 1-866-8 40- 648 3 or 1-330-558 -7220, or log on to our Web site at w w w.troybilt.com.

This limited warranty does not provide coverage in the following cases:

a. The engine or component parts thereof. These items may

carry a separate manufacturer’s warranty. Refer to applicable manufacturer’s warranty for terms and conditions.

b. Log splitter pumps, valves, and cylinders have a separate one

year warranty.

c. Routine maintenance items such as lubricants, filters, blade

sharpening, tune-ups, brake adjustments, clutch adjustments, deck adjustments, and normal deterioration of the exterior finish due to use or exposure.

d. Service completed by someone other than an authorized service

dealer.

e. Troy-Bilt does not extend any warranty for products sold or

exported outside of the United States, its possessions and territories, except those sold through Troy-Bilt’s authorized

channels of export distribution. f. Replacement parts that are not genuine Troy-Bilt parts. g. Transportation charges and service calls.

No implied warranty, including any implied warranty of merchantability of fitness for a particular purpose, applies after the applicable period of express written warranty above as to the parts as identified. No other express warranty, whether written or oral, except as mentioned above, given by any person or entity, including a dealer or retailer, with respect to any product, shall bind Troy-Bilt. During the period of the warranty, the exclusive remedy is repair or replacement of the product as set forth above.

The provisions as set forth in this warranty provide the sole and exclusive remedy arising from the sale. Troy-Bilt shall not be liable for incidental or consequential loss or damage including, without limitation, expenses incurred for substitute or replacement lawn care services or for rental expenses to temporarily replace a warranted product.

Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above exclusions or limitations may not apply to you.

In no event shall recovery of any kind be greater than the amount of the purchase price of the product sold. Alteration of safety features of the product shall void this warranty. You assume the risk and liability for loss, damage, or injury to you and your property and/or to others and their property arising out of the misuse or inability to use the product.

This limited warranty shall not extend to anyone other than the original purchaser or to the person for whom it was purchased as a gift.

HOW STATE LAW RELATES TO THIS WARRANTY: This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

IMPORTANT: Owner must present Original Proof of Purchase to obtain warranty coverage.

TROYBILT LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019; Phone: 1(866) 840-6483, 1-330-558-7220
