INSTRUCTION MANUAL

WIRELESS TOWER LIGHT

(small size, 60 mm dia., Modbus-RTU transparent 900MHz band wireless

device (child), 1 - 5 lay

BEFORE USE ....

Thank you for choosing M-System. Before use, please check
contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System’s Sales Office or representatives.

■ PACKAGE INCLUDES:

Tower Light .........................................................................(1)

Antenna ...............................................................................(1)

■ MODEL NO.

Confirm Model No. marking on the product to be exactly
what you ordered.

■ INSTRUCTION MANUAL

This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
For information on the introduction of wireless device, refer
to the 900 MHz band wireless device operating manual
(EM-9085-B).
For information on Modbus specification, refer to the Mod­bus Protocol Reference Guide (EM-5650).
These manuals are downloadable at M-System’s web site
(http://www.m-system.co.jp).

POINTS OF CAUTION

■ POWER INPUT RATING & OPERATIONAL RANGE

• Locate the power input rating marked on the product and
confirm its operational range as indicated below:

24 V DC rating: 24 V ±10%, approx. 7W

ers)

• How to change antenna angle: Rotate the antenna after
loosening the connector nut (refer to the next drawing).
Tighten the nut with torque (0.98 N·m) while holding the
antenna pointing to the intended direction. Otherwise,
tight manually the nut, and assure it turning 10° to 15°
more with a wrench.

■ INGRESS PROTECTION (IP65)

• The IP code is conformable when the unit is mounted ver­tically, antenna is installed and the control panel cover is
locked. The compartment, where connectors are located,
is not protected.

• When opening the control panel cover, avoid humidity
and dust penetration. Dry and clean it if condensation is
formed, and close the cover locking tightly.

• Install the antenna and tighten the connector nut tightly.

• In order to protect ingress of water or dust into the bot­tom compartment, mount the unit on the flat plane, and
be sure that the gasket does not roll back or dust is not
on the gasket.

PATLABOR

MODEL

™

IT60SW6F

Connector Nut

■ GENERAL PRECAUTIONS

• Before you remove the unit or mount it, turn off the power
supply and input signal for safety.

• The unit must not be subjected to external force.

• Do not rub the unit with organic solvent such as paint
thinner.

■ ENVIRONMENT

• Indoor use.

• Attach the antenna to the unit.

• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.

• Environmental temperature must be within -10 to +55°C
(14 to 131°F) with relative humidity within 10 to 90% RH
in order to ensure adequate life span and operation.

• Mount the unit on a flat and robust plate.

• Lamps are omnidirectional.

• The buzzer sound is directional in front of the unit.

• This unit communicates by radio waves. Do not install the
unit where it could be exposed to radio waves obstacles or
strong electric fields.

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]

■ WIRING

• Do not install cables close to noise sources (relay drive
cable, high frequency line, etc.).

• Do not bind these cables together with those in which
noises are present. Do not install them in the same duct.

• Cables to the unit must be wired indoor.

■ AND ....

• The unit is designed to function as soon as power is sup­plied, however, a warm up for 10 minutes is required for
satisfying complete performance described in the data
sheet.

EM-2436 P. 1 / 8

CAUTION REGARDING RADIO FREQUENCY

■ FCC NOTICE

• This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.

■ FCC CAUTION

• Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.

■ NOTE

• This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at his own expense.

• This transmitter must not be co-located or operated in
conjunction with any other antenna or transmitter.

■ FCC RF EXPOSURE INFORMATION

• This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment and
meets the FCC radio frequency (RF) Exposure Guidelines.
This equipment should be installed and operated keeping
the radiator at least 20 cm or more away from person’s
body.

FCC ID : 2AOTF-0000007 (24V DC)
Contains FCC ID: 2AKGW-1TD3016A1

IT60SW6F

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]

EM-2436 P. 2 / 8

COMPONENT IDENTIFICATION

IT60SW6F

■ FRONT VIEW (with the cover open)

Lamp 1

Lamp 2

Power

Run

SD

920LinkRD920ERR

920Run

Lamp 3

Lamp 4

Mode

Lamp 5

Status Indicator LED

Operating Mode Setting
DIP SW

Connector for
Maintenance/Configurator

5

6

4

7

3

8

2

9

1

0

5

6

4

7

3

8

2

9

1

0

5

6

4

7

3

8

2

9

1

0

Antenna

Buzzer Aperture

Gasket

■ TERMINAL ASSIGNMENT

• Connector for Power Supply

Unit side connector: MC1,5/5-GF-3,5 (Phoenix Contact)
Cable side connector: FMC1,5/5-STF-3,5 (Phoenix Contact)

ID FUNCTION

DA
DB
DG
SLD
FE

DA DA
DB DB
DG DG
SLD Shield
FE Functional earth

■ STATUS INDICATOR LED

ID COLOR FUNCTION

Power Green On when power is supplied.

Blinks when the IP Reset SW is on.
Off when power is not supplied or an

abnormality occurs in the unit.

Run Green On when Modbus communication is in

normal status.
Off at Modbus communication error or

during no Modbus communication.
SD Green On in sending data via RS-485
RD Green On in receiving data via RS-485
920Link Green On when wireless link is working.

Blinks with 0.5 Hz in establishing wire-

less link.

Off when wireless link stops working.
920Run Green On when wireless communication with

child device is in normal status.

Off at a wireless communication error

or during no communication.
920ERR Red On when there is no detour route.

Blinks at network authentication

failure.

Off in normal status.

■ BOTTOM VIEW

FRONT

Te rminator SW

→

RS-485

ON

Connector

■ OPERATING MODE

(*) Factory setting

• Lamp Blinking Frequency: Mode-1

Mode-1 LAMP BLINKING FREQUENCY

OFF Approx. 2 Hz (*)

ON Approx. 10 Hz

• Buzzer Intermittent Frequency: Mode-2

Mode-2 BUZZER INTERMITTENT FREQUENCY

OFF Approx. 2 Hz (*)

ON Approx. 10 Hz

• Buzzer Volume: Mode-3, Mode-4

Mode-3 Mode-4 BUZZER VOLUME

OFF OFF Quiet (*)
OFF ON Middle

ON OFF Loud
ON ON Maximum

• Output at the Loss of Communication: Mode-6

Mode-6 OUTPUT AT THE LOSS OF COMMUNICATION

OFF Reset the output (turned off) (*)

ON

Hold the output (maintains the last data
received normally)

Available for Modbus communication.

• Output Logic Reverse: Mode-7

Mode-7 OUTPUT LOGIC REVERSE

OFF Non-inverted (*)

ON Inverted
Available for discrete input.
Not available with blink (BLINK) or intermittence (BUZZ­ER2), be sure to turn it off.

• Input Select: Mode-8

Mode-8 INPUT SELECT

OFF Modbus/TCP (*)

ON Discrete input
Selects the input signal of lamp and buzzer control.

Note: Be sure to set unused Mode-5 to OFF.

■ TERMINATOR

To enable the terminator, turn ON the terminator SW. To
disable the terminator, turn OFF the terminator SW.
(Factory set to OFF)

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]

EM-2436 P. 3 / 8

CONFIGURATOR SOFTWARE SETTING

With configurator software, settings shown below are available.
Refer to the software manual of ITCFG for detailed operation.

■ WIRELESS SETTING

ITEM SETTING RANGE DEFAULT

Preferred PAN ID (group number) 0000 – FFFE (hexadecimal, 4 digits) 0000

Radio channel number 1 – 43 (selectable up to 10 channels) None

Short address 0000 – FFFD (hexadecimal, 4 digits) 0000

Network name English one-byte characters within 16 characters

(one-byte space, “-” , “_” , “ . ” , “@” are usable.)

Encryption key 0000...0 – FFFF...F

(hexadecimal, 32 digits)

Transmitter power output 0.16 mW / 1 mW / 20 mW 20 mW

Low-speed moving mode No / Yes No

Device type in a network,
Number of devices in a network

Set network quality Standard (recommended) /

Network join mode V3-compatible mode / Fast join mode V3-compatible mode

Fixed route No / Yes No

Destination short address 0000 – FFFD (hexadecimal, 4 digits) 0000

Temporary detour No / Yes Yes

Packet filtering None / Yes (polling type) Yes (polling type)

Filter timeout on polling 1.0 – 60.0 (sec.) 1.0 (sec.)

920Run timeout 1.0 – 60.0 (sec.) 3.0 (sec.)

Modbus node address 1 – 247 1

Retry times before route switching Once / Twice / Three times Three times

Child (fixed), 1 to 30 devices /
Child (fixed), 31 to 60 devices /
Child (fixed), 61 to 100 devices /
Child (fixed) + child (moving)

Frequency of route switching and delay (higher) /
Frequency of route switching and delay (highest)

Note: For version confirmation of communication module, refer to the software manual of ITCFG.

Blank

0000...0

Child (fixed), 1 to 30 devices

Standard (recommended)

IT60SW6F

■ MODBUS SETTING

ITEM SETTING RANGE DEFAULT

Transfer rate 38400 / 19200 / 9600 / 4800 bps 38400 bps

Parity bit Odd / Even / None Odd

Stop bit 1 bit / 2 bits 1 bit

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]

EM-2436 P. 4 / 8

TERMINAL CONNECTIONS

compartment.

Connect the unit as in the diagram below.

■ EXTERNAL DIMENSIONS unit: mm

60±1.5dia.

IT60SW6F

A±4

1– 6 lengths*

3 Bolts and Nuts (M4)

Control Panel Cover

Approx. 1500

(60)

43 ±1.5 dia.

Antenna

(85)

Lead wires

Lamp Layers

0
1
2
3
4
5

R165

A
192
224
256
288
320
352

(30 dia.)

■ MOUNTING REQUIREMENTS unit: mm

Wiring Hole 30 dia.*

43 dia.

3 Holes (5 dia.)

120°

Front

* Protect wires to prevent scratching them at the edge of the

*1. Consult M-System for other bolt length.

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]

EM-2436 P. 5 / 8

■ CONNECTION DIAGRAM

To other Modbus devices

LAMP 1 INPUT

LAMP 2 INPUT

LAMP 3 INPUT

LAMP 4 INPUT

INPUT

LAMP 5 INPUT

Red

Amber

Green

Blue

White

2

*

*

*

2

*

2

*

Antenna Connector

DA
DB
DG

SLD

FE

1

*

LAMP1

2

2

LAMP2

LAMP3

LAMP4

LAMP5

1

*

1

*

1

*

1

*

IT60SW6F

BUZZER INP 1 Continuance

BUZZER INP 2 Intermittence

LAMP BLINK

COM

POWER

FE Green/Amber

Connector for Maintenance/Configurator

*1. Example of 5 layers in order: red, yellow, green, blue and white.
Lamp and wire color are the same.
*2. When selecting the same color for more than one layer, cable colors
comply with ordering information sheet.

• WIRING TO INPUT SIGNAL

Contact input e.g.

BLINK

ON

Purple

Cyan

Brown

Orange

Gray

Black

USB Connector

TOWER LIGHT

LAMP1

LAMP2

LAMP3

BUZZER1

BUZZER2

BLINK

COM

+

–

FE1

NPN input e.g.

BLINK

ON

TOWER LIGHT

LAMP1

LAMP2

LAMP3

LAMP4

LAMP5

BUZZER1

BUZZER2

BLINK

COM

LAMP4

LAMP5

BUZZER1

BUZZER2

BLINK

COM

Note: If “On” and “Blink” are set simultaneously for a single lamp, “Blink” is disabled.
At this time, if other lamps are being set to "Blink", they are also affected and work in the same manner.

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]

EM-2436 P. 6 / 8

COMMUNICATION CABLE CONNECTIONS

■ WIRING CONNECTION WITH SLAVE DEVICES

■ WIRING CONNECTION WITH SLAVE DEVICES

IT60SW6F

Remote UnitRemote Unit

TERMINATOR

*

*

The Unit

DA
DB
DG

SLD

FE

DA
DB
DG

SLD

FE

*1. Connect SLD and FE for reducing noise interference if necessary.
*2. For units at both ends of communication line, “DA” and “DB” must be connected with a terminator,

however, for the unit, it is possible to set it by turning Terminator SW ON instead.

■ TENSION CLAMP TERMINAL BLOCK

Applicable wire size: 0.2 – 1.5 mm

2

Stripped length: 10mm
Recommended solderless terminal

2

• AI0,25-10YE 0.25 mm

• AI0,34-10TQ 0.34 mm

• AI0,5-10WH 0.5 mm

• AI0,75-10GY 0.75 mm

(Phoenix Contact)

2

(Phoenix Contact)

2

(Phoenix Contact)

2

(Phoenix Contact)

MODBUS FUNCTION CODES & SUPPORTED CODES

■ DATA AND CONTROL FUNCTIONS

CODE NAME

01 Read Coil Status Digital output from the slave (read/write)
02 Read Input Status Status of digital inputs to the slave (read only)
03 Read Holding Registers General purpose register within the slave (read/write)
04 Read Input Registers Collected data from the field by the slave (read only)
05 Force Single Coil Digital output from the slave (read/write)
06 Preset Single Registers General purpose register within the slave (read/write)
15 Force Multiple Coils Digital output from the slave (read/write)
16 Preset Multiple Registers General purpose register within the slave (read/write)

DA
DB
DG

SLD

FE

TERMINATOR

*

■ EXCEPTION CODES

CODE NAME

01 Illegal Function Function code is not allowable for the slave.
02 Illegal Data Address Address is not available within the slave.
03 Illegal Data Value Data is not valid for the function.
04 Slave Device Failure
05 Acknowledge
06 Slave Device Busy
07 Negative Acknowledge

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]

EM-2436 P. 7 / 8

MODBUS I/O ASSIGNMENTS

ADDRESS DATA TYPE D ATA

Coils (0X) 1 – 16 Digital Output (lamp, buzzer)
Inputs (1X) 1 – 16 Digital Input (lamp, buzzer)
Input Registers (3X) ---- ---- Unused
Holding Registers (4X) ---- ---- Unused

Note: DO NOT access addresses other than the above. Such access may cause problems such as inadequate operation.

IT60SW6F

■ OUTPUT DATA

Output 0

Output 1

Output 2

Output 3

Output 4

Output 5

Output 6

Output 7

Output 8

Output 9

Output 10

Output 11

Output 12

Output 13

Output 14

Output 15

015

Output 0
Output 1

•

•

•

Output 15

Lamp 1 0: Off, 1: On Input 0 Lamp 1 0: Off, 1: On

Lamp 2 0: Off, 1: On Input 1 Lamp 2 0: Off, 1: On

Lamp 3 0: Off, 1: On Input 2 Lamp 3 0: Off, 1: On

Lamp 4 0: Off, 1: On Input 3 Lamp 4 0: Off, 1: On

Lamp 5 0: Off, 1: On Input 4 Lamp 5 0: Off, 1: On

Buzzer 0: Off, 1: Continuous Input 5 Buzzer 0: Off, 1: Continuous

– – Input 6 – –

– – Input 7 – –

Lamp 1 0: Off, 1: Blinking Input 8 Lamp 1 0: Off, 1: Blinking

Lamp 2 0: Off, 1: Blinking Input 9 Lamp 2 0: Off, 1: Blinking

Lamp 3 0: Off, 1: Blinking Input 10 Lamp 3 0: Off, 1: Blinking

Lamp 4 0: Off, 1: Blinking Input 11 Lamp 4 0: Off, 1: Blinking

Lamp 5 0: Off, 1: Blinking Input 12 Lamp 5 0: Off, 1: Blinking

Buzzer 0: Off, 1: Intermittent Input 13 Buzzer 0: Off, 1: Intermittent

– – Input 14 – –

– – Input 15 – –

■ INPUT DATA

015

Input 0
Input 1

•

•

•

Input 15

Note: If “On” (Continuous) and “Blinking” (Intermittent) are set simultaneously for a single lamp (buzzer), “Blinking” is disabled.

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]

EM-2436 P. 8 / 8
