MSV - N1250 IP Camera
Hardware User Manual
-Contents-
Statement and Declaration
CHAPTER 1. SAFETY INSTRUCTION ........................................................................................6
CHAPTER 2. INTRODUCTION .....................................................................................................8
CHAPTER 3. PACKAGE CONTENTS ..........................................................................................9
CHAPTER 4. PHYSICAL DESCRIPTION..................................................................................10
4.1 F
RONT VIEW
.......................................................................................................................................................... 10
4.2 B
OTTOM VIEW
....................................................................................................................................................... 11
CHAPTER 5. BASIC CONNECTION ..........................................................................................12
5.1 W
IRE CONNECTION
............................................................................................................................................... 12
5.2 W
IRELESS CONNECTION
........................................................................................................................................ 12
CHAPTER 6. APPLICATION........................................................................................................13
2
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The
following test methods have been applied in order to prove presumption of conformity with the
essential requirements of the R&TTE Directive 1999/5/EC:
Clause Description
EN 60950-1: 2001
Safety of Information Technology Equipment
EN 50392: 2004
Generic standard to demonstrate the compliance of electronic and
electrical apparatus with the basic restrictions related to human
exposure to electromagnetic fields (0 Hz - 300 GHz)
EN 300 328 V1.6.1
(2004-11)
Electromagnetic compatibility and Radio spectrum Matters (ERM);
Wideband transmission systems; Data transmission equipment
operating in the 2,4 GHz ISM band and using wide band modulation
techniques; Harmonized EN covering essential requirements under
article 3.2 of the R&TTE Directive
EN 301 489-17 V1.2.1
(2002-08) and EN 301
489-1 V1.5.1 (2004-11)
Electromagnetic compatibility and Radio spectrum Matters (ERM);
ElectroMagnetic Compatibility (EMC) standard for radio equipment
and services; Part 17: Specific conditions for 2,4 GHz wideband
transmission systems and 5 GHz high performance RLAN equipment
This device is a 2.4 GHz wideband transmission system (transceiver), intended for use in all EU
member states and EFTA countries, except in France and Italy where restrictive use applies.
In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain
authorization to use the device for setting up outdoor radio links and/or for supplying public access
to telecommunications and/or network services.
This device may not be used for setting up outdoor radio links in France and in some areas the RF
output power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For
detailed information the end-user should contact the national spectrum authority in France.
3
Česky
[Czech]
[Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se základními
požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk
[Danish]
Undertegnede [fabrikantens navn] erklærer herved, at følgende udstyr [udstyrets
typebetegnelse] overholder de væsentlige krav og øvrige relevante krav i direktiv
1999/5/EF.
Deutsch
[German]
Hiermit erklärt [Name des Herstellers], dass sich das Gerät [Gerätetyp] in
Übereinstimmung mit den grundlegenden Anforderungen und den übrigen
einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab [tootja nimi = name of manufacturer] seadme [seadme tüüp =
type of equipment] vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist
tulenevatele teistele asjakohastele sätetele.
English Hereby, [name of manufacturer], declares that this [type of equipment] is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente [nombre del fabricante] declara que el [clase de equipo]
cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o
exigibles de la Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ [name of manufacturer] ∆ΗΛΩΝΕΙ ΟΤΙ [type of equipment]
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ
ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/ΕΚ.
Français
[French]
Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est conforme
aux exigences essentielles et aux autres dispositions pertinentes de la directive
1999/5/CE.
Italiano
[Italian]
Con la presente [nome del costruttore] dichiara che questo [tipo di apparecchio] è
conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla
direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo [name of manufacturer / izgatavotāja nosaukums] deklarē, ka [type of
equipment / iekārtas tips] atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem
ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian]
Šiuo [manufacturer name] deklaruoja, kad šis [equipment type] atitinka esminius
reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in
overeenstemming is met de essentiële eisen en de andere relevante bepalingen van
richtlijn 1999/5/EG.
4
Malti
[Maltese]
Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott] jikkonforma
mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva
1999/5/EC.
Magyar
[Hungarian]
Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym [nazwa producenta] oświadcza, że [nazwa wyrobu] jest zgodny z
zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy
1999/5/EC.
Português
[Portuguese]
[Nome do fabricante] declara que este [tipo de equipamento] está conforme com os
requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
[Ime proizvajalca] izjavlja, da je ta [tip opreme] v skladu z bistvenimi zahtevami in
ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky
[Slovak]
[Meno výrobcu] týmto vyhlasuje, že [typ zariadenia] spĺňa základné požiadavky a
všetky príslušné ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish]
[Valmistaja = manufacturer] vakuuttaa täten että [type of equipment = laitteen
tyyppimerkintä] tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä
koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse med de
väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv
1999/5/EG.
5
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
FCC Caution:
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
6
Hardware User Manual
Chapter 1. Safety Instruction
Before you use this product
This product has been designed with safety in mind. However, the electrical products can cause
fires which may lead to serious body injury if not used properly. To avoid such accidents, be sure to
heed the following.
Legal Caution
Video and audio surveillance can be forbidden by laws that vary from country to country. Check the
laws in your local region before using this product for surveillance purposes.
Don't open the housing of the product
Don't try to open the housing or remove the covers which may expose yourself to dangerous voltage
or other hazards.
Don't use the accessories not recommend by the manufacturer
Heed the safety precautions
Be sure to follow the general safety precautions and the “Operation Notice.”
Operation Notice - Operating or storage location
Avoid operating or storing the camera in the following locations:
•
Extremely hot or cold places
(Operating temperature: 0 °C to + 50 °C [32 °F to 122°F] )
•
Exposed to direct sunlight for a long time, or close to heating equipment (e.g., near heaters)
•
Close to water (e.g.,near a bathtub, kitchen sink, laundry tub)
•
Close to sources of strong magnetism
•
Close to sources of powerful electromagnetic radiation, such as radios or TV transmitters
•
Locations subject to strong vibration or shock
7
In case of a breakdown
In case of system breakdown, discontinue use and contact your authorized dealer.
In case of abnormal operation
•
If the unit emits smoke or an unusual smell,
•
If water or other foreign objects enter the cabinet, or
•
If you drop the unit or damage the cabinet:1 Disconnect the cable and the connecting cables. 2
Contact your authorized dealer or the store where you purchased the product.
Transportation
When transporting the camera, repack it as originally packed at the factory or in materials of equal
quality.
Ventilation
To prevent heat buildup, do not block air circulation around the device.
Cleaning
•
Use a soft, dry cloth to clean the external surfaces of the device. Stubborn stains can be
removed using a soft cloth dampened with a small quantity of detergent solution, then wipe dry.
•
Do not use volatile solvents such as alcohol, benzene or thinners as they may damage the
surface.
8
Chapter 2. Introduction
The N1250 is an ultra-compact IP Camera equipped with a high sensitivity progressive scan CMOS
sensor, achieving high image quality and superior low-light performance. N1250 also supports
802.11b/g wireless connection and night-vision capability even in complete darkness through 6 high
power LEDs.
Key Features:
•
Maximum Resolution 640x480 (VGA) provides superior image quality
•
Simultaneous MPEG-4 and Motion JPEG video stream
•
Excellent Image Quality up to flexible 30 fps in all resolution for optimum bandwidth use
•
Superior Low-Light Performance with 6 Night-Vision LEDs down to 0 Lux
•
Wireless( IEEE 802.11g/b) Networks Connection
•
Two-way Audio with Built-In Microphone
•
Optimal Synchronization of Audio and Video
•
Support Live Video Viewing on Windows Live Messenger (WLM )
•
Control panel add-in, i.e. snapshot and image setup
•
Support Mac OS with Safari Browser
•
Support iPhone through Safari Browser
•
Mobile Phone Streaming Live Video through 3GPP / ISMA / RTSP
•
Mobile Phone Live Image through 2.5 WAP
•
Multi-level Password Protection for Restricting Camera Access
•
Built-In Multi-Window Motion Detection (3 detection areas)
•
Video Buffer makes the Streaming Smoother
•
UPnP and Bonjour for Fast and Easy Installation
•
DDNS Supported
•
Bundled 16 Channel Surveillance Software
•
User-friendly & Multi-lingual UI
9
Chapter 3. Package Contents
Camera
– N1250 IP Camera
Quick Installation Guide
- To provide brief product information and quick installation and
wireless setting
Software CD
- To provide IP Surveillance Software, Intelligence IP Installer, User Manuals, and
Language Packs
Mounting Bracket
– There are three components including lock ring, brace, and base plate to
compose a bracket and three applied screws to fix the base plate to a flat surface (horizontal or
vertical)
Antenna
- For connection of IEEE 802.11 b / g wireless network
Adaptor
- 5V DC, max 5W
10
Chapter 4. Physical Description
4.1 Front View
Focus Adjustment Ring - Adjust focus manually to achieve the best image quality
Night-Vision White LEDs - LEDs will light up when the environment is too dark.
Power LED indicator - Power LED will light up after the IP Camera completed the boot
process
Network LED indicator - Network LED will light up after the IP Camera connected with
network.
Built-In Microphone - Built-In Microphone for Two-way Audio
Wireless Antenna - For connection of IEEE 802.11 b / g wireless network.
11
4.2 Bottom View
Power Connector - For connection of 5V DC input.
Reset – When the device is empowered, press the Reset Button to reboot the device, or
hold the Reset Button for 10 seconds to set the device settings back to factory default
Audio Out (Speaker) - To support audio out with earphones or speakers
Network Connector - For connection to the Ethernet via RJ-45 standard
12
Chapter 5. Basic Connection
N1250 is for both wire and wireless connection. You can follow the procedure below to connect the
IP Camera with power and Ethernet for both wire and wireless connection.
5.1 Wire Connection
1. Connect the power adaptor to IP Camera.
2. Connect IP Camera’ Ethernet port to your Hub/ Switch / Router
5.2 Wireless connection
1. Connect the power adaptor to IP Camera.
3. Connect to Wi-Fi
Wire Connection
Wireless Connection
13
Chapter 6. Application
Loading...
