MSI W20 3M User Manual

Preface

Tablet PC

User’s Manual

Preface

Contents

Chapter 1: Preface

Content ............................................................................ 1-2

Regulations and Statements ......................................... 1-4

FCC-B Radio Frequency Interference Statement ....... 1-4

FCC Conditions ........................................................... 1-4

FCC ............................................................................. 1-5

IC ................................................................................. 1-5

CE Conformity ............................................................. 1-5

Battery Regulations ..................................................... 1-6

WEEE Statement ........................................................ 1-6

Safety Instructions ......................................................... 1-7

Trademarks ..................................................................... 1-9

Reversion History........................................................... 1-9

Chapter 2: Introductions

Manual Map ..................................................................... 2-2

Unpacking ....................................................................... 2-2

Product Overview ........................................................... 2-3

Top-Open View ............................................................ 2-3

Specification ................................................................... 2-6

Chapter 3: Getting Started

Power Management ....................................................... 3-2

AC Power .................................................................... 3-2

Connecting the AC Power ........................................... 3-2

Battery Power .............................................................. 3-3

Powering ON ............................................................... 3-4

Power Management in Windows OS .......................... 3-5

Basic Operations ............................................................ 3-7

Inserting a Micro-SD Card or SIM Card to Your Tablet

PC ............................................................................... 3-8

1-2

Knowing the Display Features..................................... 3-9

Using the Fingerprint Reader .................................... 3-11

Wireless Activation for Windows 8 ............................ 3-13

Connecting the External Devices ............................... 3-14

Peripheral Devices .................................................... 3-14

Wireless / Bluetooth / Camera Functions .................. 3-15

1-3

Preface

 Regulations and Statements

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and radiates radio frequency energy, and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

 Consult the dealer or an experienced radio TV technician for help.

NOTE

 The changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

 Shield interface cables and AC power cord, if any, must be used in order to comply

with the emission limits.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

 This device may not cause harmful interference.

 This device must accept any interference received, including interference that may cause

undesired operation.

1-4

FCC

FCC RF Radiation Exposure Statement:

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled

environment. This device was tested for typical lap held operations with the device contacted

directly to the human body to the back side of the notebook computer. To maintain compliance

with FCC RF exposure compliance requirements, avoid direct contact to the transmitting

antenna during transmitting SAR information 1.56 W/kg@1g (body).

The product comply with the Canada portable RF exposure limit set forth for an uncontrolled

environment and are safe for intended operation as described in this manual. The further RF

exposure reduction can be achieved if the product can be kept as far as possible from the user

body or set the device to lower output power if such function is available.

SAR information: 1.56 W/kg@1g (body)

Industry Canada

This Class B digital apparatus complies with Canadian ICES-003. To reduce potential radio

interference to other users, the antenna type and its gain should be so chosen that the

equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful

communication. This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) This device may not cause interference,

and (2) This device must accept any interference, including interference that may cause

undesired operation of the device.

Cet appareil numerique de la classe B est conforme a la norme NMB-003 Canada.

Pour réduire le risque d'interférence aux autres utilisateurs, le type d'antenne et son gain

doivent être choisis de façon que la puissance isotrope rayonnée équivalente (PIRE) ne

dépasse pas ce qui est nécessaire pour une communication réussie.

Cet appareil est conforme aux normes d'exemption de licence RSS d'Industry Canada. Son

fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer

d'interférence et (2) ce dispositive doit accepter toute interference reçue, y compris les

interférences qui peuvent causer un mauvais fonctionnement du dispositif.

CE Conformity

This device is in compliance with the essential safety requirements and other

relevant provisions set out in the European Directive.

1-5

Preface

Battery Regulations

European Union:

Batteries, battery packs, and accumulators should not be disposed of

as unsorted household waste. Please use the public collection system

to return, recycle, or treat them in compliance with the local

regulations.

Taiwan:

For better environmental protection, waste batteries should be

collected separately for recycling or special disposal.

California, USA: The button cell battery may contain perchlorate material and requires special

handling when recycled or disposed of in California.

For further information please visit: http://www.dtsc.ca.gov/hazardouswaste/perchlorate/

Safety Guideline for Using Lithium-ion Battery

Danger of explosion if battery is incorrectly replaced. Replace only with the same or

equivalent type recommended by the equipment manufacturer. Discard used batteries

according to manufacturer’s instructions.

WEEE Statement

Under the European Union ("EU") Directive on Waste Electrical and Electronic

Equipment, Directive 2002/96/EC, which takes effect on August 13, 2005,

products of "electrical and electronic equipment" cannot be discarded as

municipal waste anymore and manufacturers of covered electronic equipment

will be obligated to take back such products at the end of their useful life.

1-6

 Safety Instructions

Read the safety instructions carefully and thoroughly. All cautions and

warnings on the equipment or user’s manual should be noted.

Keep this equipment away from humidity and high temperature.

Lay this equipment on a stable surface before setting it up.

The openings on the enclosure are used for air convection and to

prevent the equipment from overheating. Do not cover the openings.

 Do not leave the equipment in an unconditioned environment with a

storage temperature above 60

which may damage the equipment.

 This unit should be operated under maximum ambient temperature

of 40

C (120OF).

 Make sure the power voltage is within safety range and has been

adjusted properly to the value of 100~240V before connecting the

equipment to the power outlet.

 Always unplug the AC power cord before installing any add-on card

or module to the equipment.

 Always disconnect the AC power cord or uninstall the battery pack

or switch off the wall socket if the equipment would be left unused

for a certain time to achieve zero energy consumption.

Never pour liquid into the opening that could damage the equipment or

cause an electrical shock.

Place the power cord in a way that people are unlikely to step on it. Do

not place anything on top of the power cord.

C (140OF) or below 0OC (32OF),

1-7

Preface

Always keep the strong magnetic or electrical objects away from the

equipment.

When installing the coaxial cable to the TV Tuner, it is necessary to

ensure that the metal shield is reliable connected to protective earthing

system of the building.

Cable distribution system should be grounded (earthed) in accordance

with ANSI/NFPA 70, the National Electrical Code (NEC), in particular

Section 820.93, Grounding of Outer Conductive Shield of a Coaxial

Cable.

If any of the following situations arises, get the equipment checked by a

service personnel:

 The power cord or plug is damaged.

 Liquid has penetrated into the equipment.

 The equipment has been exposed to moisture.

 The equipment has not worked well or you can not get it work

according to User’s Manual.

 The equipment was dropped and damaged.

 The equipment has obvious signs of breakage.

Green Product Features

 Reduced energy consumption during use and stand-by

 Limited use of substances harmful to the environment and health

 Easily dismantled and recycled

 Reduced use of natural resources by encouraging recycling

 Extended product lifetime through easy upgrades

 Reduced solid waste production through take-back policy

Environmental Policy

 The product has been designed to enable proper reuse of parts and

recycling and should not be thrown away

 Users should contact the local authorized point of collection for

recycling and disposing of their end-of-life products.

1-8

 Trademarks

 All trademarks are the properties of their respective owners.

 SRS Premium Sound, SRS and the symbol are trademarks of SRS Labs, Inc.

 THX and THX TruStudio Pro are trademarks of THX Ltd. which may be registered in some

 Revision History

Version Revision History Date

1.0 First Released 01, 2014

1-9

Introductions
