MSI R7850-2GD5OC User Manual

GPU ReactorGPU Reactor

Getting StartedGetting Started

Quick InstallationQuick Installation

1. Find the GPU Reactor card, and have the obverse side of the card turned upward as illustrated to check the correct installation orientation first.

2. Turnover the GPU Reactor card, and align the GPU Reactor card and the VGA card precisely before rejoining the GPU Reactor card onto the VGA card.

Be noted that any improper installation to the GPU Rector card may cause damage to the graphic card and the GPU Rector card. Contact the local dealer for detailed information, if needed.

3. Locate the power cable of the VGA card, and plug it to the power connector on the GPU Reactor card.

4. Align and fasten the four retention clips of the covering cap onto the VGA card to shelter the GPU Reactor card.

GRAPHICS CARD

R7970

PoweR Edition

PoWER Edition

∙

PCI Express 3.0 X16 bus interface

∙

OpenGL 4.2 support

∙

AMD Eyefinity multi-display technology

- Up to 6 displays supported with DisplayPort 1.2 Multi-Stream Transport.

- Independent resolutions, refresh, rates, color controls, and video overlays.

- Display grouping: Combine multiple displays to behave like a single large display.

∙

AMD HD3D technology

- Stereoscopic 3D display/glasses support.

- Blu-ray 3D support.

- Stereoscopic 3D gaming.

- 3rd party Stereoscopic 3D middleware software support.

∙

AMD App Acceleration

- OpenCL 1.2 Support

- Microsoft C++ AMP

- DirectCompute 11

- Double Precision Floating Point

- AMD HD Media Accelerator

∙

Integrated HD audio controller

- Output protected high bit rate 7.1 channel surround sound over HDMI with no additional cables required.

- Support AC-3, AAC, Dolby TrueHD and DTS Master Audio formats.

∙

AMD Power Tune Technology

- Intelligent TDP management technology

- Dynamic colockspeed/performance enhancement for games.

∙

AMD CatalystTM graphics and HD Video configuration software

- Software support for Windows 7, Windows Vista, and Windows XP.

- AMD Catalyst and accessing features of AMD Radeon products.

- Unified Graphics display driver - AMD Catalyst advanced graphics, video, and features of AMD Radeon

∙

AMD PowerPlay™ power management technology

- Automatic power management with low power idle states.

Center - AMD CatalystTM software application and user interface for setup, configuration,

software enabling other PC programs and devices to use

products.

Hardware

Follow the instructions below to install the VGA card:

1. Remove the computer case.

2. Locate the expansion slot on your mainboard. Warning: Inserting the VGA card into a wrong slot may damage your card (refer to your mainboard manual for further Information).

15V 1

Installing the VGA card... Attaching the power cable... Connecting the monitor...

3. Put the card directly over the expansion slot and press one end of the card into the slot first. Gently but firmly press the other end until the card is fully seated in the slot.

4. Secure the card with a bracket screw.

5. Attach the power cable of the power supply with recommended wattage to the VGA card, if necessary.

6. Install all other cards and devices and connect all the cables, and then re-install the computer case.

7. Connect the monitor. Now, you are ready to install the driver and software on your computer.

Fan Connectors

8-pin Power Connectors

V-Check Points

3G GDDR5 memory 2G GDDR5 memory (optionally supported)

AMD Radeon HD7900 series

PCI Express Interface

BIOS Switch

CrossFire Interface

Mini Display Port

DVI-D / DVI-I Port

- HDMI supported

- HDCP supported

- Single-link DVI output supported

The VGA card shown here is for reference only, and may vary from the actual card.

For further information, please visit MSI website at www.msi.com

Part NO: G52-V2782X2

OverviewOverview

FunctionsFunctions

LIVE UPDATE 5

MSI Live Update 5 offers users with brand-new update service experience, which can significantly save your time while searching files. Live Update 5 is capable to automatically analyze and list drivers, BIOS, and utilities you need. With the easy-to-use updating approaches, you can increase the performance of your system easily and quickly. Follow the instructions below, with a few mouse clicks, you can acquire the related files for the system updating.

1. Insert the driver disk into the optical device drive, and start the Setup program.

2. Click the Utility tab on the setup screen.

3. Click the MSI Live Update 5. Follow the on-screen nstructions to complete the installation.

4. Launch MSI Live Update utility to proceed the updating function.

WARNING!!

DO NOT touch the cooling system since it may produce a certain heat while processing tasks.

CAUTION!!

Do not force the GPU cooler against the fragile GPU to avoid damage to the GPU.
