MSI MS-7C51 Schematics

5

4

3

2

1

MS-7C51 Ver:1.1

CPU:

AMD AM4

D D

System Chipset:

Promontory A320
(Value DIY or System Builder)

Main Memory:

DDR IV * 2 MAX:64 GB

VRM

RT8894 3+2

On Board Chipset:

LPC Super I/O --NCT5565

C C

LAN RTL8111H
Azalia CODEC - Realtek ALC887

Expansion Slots:

From CPU

KBD
MOUSE

PCI Express X16 Slot * 1
PCI Express X1 Slot * 1

B B

FUSION BLOCK DIAGRAM

HDMI & DVI CON

PCIE x16 GEN3

PCIE x1 *1 GEN3

REAR USB *4

ALC887

SPI ROM 64M

NCT5565

JUSB1

JUSB2

LAN+USB

JUSB3

USB2.0 & USB3.1 GEN1

DP0~1

PCIEx16

GPP_PCIE

AUDIO

SPI Bus

LPC

USB2.0

USB3.1 GEN1

AM4

Bristol Ridge

&

Summit Ridge

CLOCK

HUB *4

Promontory

PROM1
Chipset

A320 Only

PCIE SLOT & PROM

GEN3

CLOCK 100MHz

USB 3.0

GPP_PCIE GEN2

DDRIV 2400

DDRIV 2400

CHA

CHB

PCIE_E1

PCIE_E2

USB X6

RTL8111H

UNBUFFERED
DDRIV DIMM1

UNBUFFERED
DDRIV DIMM2

00

01

SATA [4:1]

A A

MICRO-START INT'L CO.,LTD.

MICRO-START INT'L CO.,LTD.

Title

Title

Title

Block Diagram

Block Diagram

Block Diagram

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

5

4

3

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

MS-7C51 1.1

MS-7C51 1.1

MS-7C51 1.1

150Thursday, July 04, 2019

150Thursday, July 04, 2019

150Thursday, July 04, 2019

of

of

1

of

1

AMD

01 Block Diagram

02 Cover Sheet

AM4

03 FM4 DDR4 I/F

04 AM4 PCIE/SATAE

05 AM4 Display/Audio

06 AM4 SVI/ACPI/GPIO

07 AM4 LPC/SPI/USB/CLK/STRAP

08 AM4 Power/RTC Power/ 09 AM4 GND

10,11 DDR4-DIMM CH-A/B

12,13 DDR4-POWER/GND

14 Promontory-PCIE/SATA/SATAE

15 Promontory-USB/OC

16 Promontory-CLK/ACPI/GPIO

17 Promontory-Power / 18 Promontory-GND

A A

19 PCIE X16(X1*2) SLOT

36 CPU Power VDDP-RT8125E

37 CPU Power Connector/PWRGD

38 CPU Power uP9505 3+2 Phase

39 CPU Power Phase 1-3

40 CPU Power NB Phase 1-2

41 CPU Power NB Switch/NCT3933

42 UP6273 CURRENT SENSE

43 ATX/Front Panel

44 ALL LED Control

45 BOM Option

46 RTC Circuit/Moat Cap

47 History

48 Power Sequence

49 Power Delivery

50 GPIO MAP

20 SIO NCT5565

21 CPU/SYS FAN Control TYPE K

22 LAN-RTL8111H

23 / 24 Audio ALC887

25 USB Rear PS2+USB2.0

26 USB Rear LAN+USB3.1 GEN1

27 USB Front Side

28 SATA Connector

29 DVI Connector

30 DP to VGA ITE6516

31 ACPI uPI-5VDIMM&3VSB

32 PM-NB681-1.05V/GS7133-2.5V

33 DDR PWR VPP25/VTT-MP2143

MICRO-START INT'L CO.,LTD.

MICRO-START INT'L CO.,LTD.

34 DDR Power-RT8231AGQW

35 CPU Power 1P8V-MP2147

Title

Title

Title

COVER SHEET

COVER SHEET

COVER SHEET

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

1

Date: Sheet

MICRO-START INT'L CO.,LTD.

MS-7C51 1.1

MS-7C51 1.1

MS-7C51 1.1

250Thursday, July 04, 2019

250Thursday, July 04, 2019

250Thursday, July 04, 2019

of

of

of

5

4

3

2

1
