PageTITLE
Cover Sheet 1
Block Diagram
CPU-Memory//PEG/Display
CPU-Control/MISC/CFG/Audio
D D
Power/GND
DDR4 SLOT-DIMM1~4
DDR4-POWER/GND
PCH-USB/PCIE/DMI/SATA
PCH-Audio/Display/Clock
PCH-GPIO/USBOC#/SATASTRAP
PCH-LPC/SPI/SMBUS/MISC
PCH-Power/GND/Strap
PCIE X16/X1/X4
PCIE to PCI-ASM1083
C C
M.2/SATA Express/SATA
USB POWER/PS2/USB2.0/USB3.0
PCIE to USB3.1-ASM1142
PCIE to LAN-I219V
VGA/DVI/HDMI Connector
Audio-ALC1150
SIO-NCT6793D
CPU FAN/SYSTEM FAN
ATX Power/F_Panel
ACPI-UPI Power
B B
OV-NCT3933
+12VIN/VRM_EN&PGD
IMVP8-PWM-ISL95858 VCORE+VGT
CPU PWR_VCCIO-NB685
CPU PWR_ST/PLL-GS7166/GS7116
CPU PWR_SA-RT8125C
DDR4 Power-RT8125C
DDR4 Power-VPP25
PCH Core Power-RT8125C
BIOS &Clear CMOS
A A
Manual parts/XDP/EMI CAP
GPIO MAP
Power Map
Power Sequence
Revision History
5
2
3~4
5
6~7
8~9
10~11
12
13
14
15
16~18
19~21
22~23
24~25
16~29
30~31
32
33~35
36~38
39~40
41~42
43
44
45
46
47~49
50
51
52
53
54
55
56
57~59
60
61
62
63
4
Intel -Skylake plamform
Z170
CPU:
Skylake-S
Onboard Chip:
HD Audio Codec:ALC892
LAN:RTL 8111H
SIO:Nuvoton 6793D
Flash ROM: SPI 64MB /128MB(For
H170/B150)
Main
Memory:
DDRIV (800/1066/1333/1600/2133MHz) * 4 (Dual
Channel)
ACPI:
NIKO/UPI
Expansion
Slots:
PCI Express (X16) Slot *1 REAR USB2.0 *2
PCI Express (X4) Slot * 1
PCI Express (X1 ) Slot * 3
PCI Slot * 3
M2 * 1
3
ATX
Ver:
1.1
System Chipset:
Z170 TOMAHAWK
B150 TOMAHAWK
Z170A G43
PWM:
IMVP8 -ISL95858
Other:
SATA3.0 x6 (PCH)
FRONT USB2.0 *4
FRONTUSB3.0 *4
REAR USB3.0 *2
REAR USB3.1 *2
2
MICRO-STAR INT'L CO.,LTD
MICRO-STAR INT'L CO.,LTD
MICRO-STAR INT'L CO.,LTD
MS-7970
MS-7970
Cover Sheet
Cover Sheet
Cover Sheet
MS-7970
1
MSI
MSI
MSI
Size Document Description Rev
Size Document Description Rev
Size Document Description Rev
Custom
Custom
Custom
Date:
Thursday, July 23, 2015
Date:
Thursday, July 23, 2015
Date:
Thursday, July 23, 2015
Sheet of
Sheet of
Sheet of
163
163
163
1.1
1.1
1.1
5
MS-7978 Block Diagram
4
3
2
1
PCIE*X16 Slot2
D D
HDMI
DVI
VGA
RGB
IT6515
PS2_USB1
C C
HDMI_USB1
USB1
LAN_USB1
JUSB1
JUSB2
JUSB3
Lane0~16
PORT B
PORT C
PORT D
P9&P10
P3&P4
P11&P12
P5&P6
P13&P14
P7&P8
P1&P2
DISPLAY
INTEL
Skylake LGA1151
DMI
Z170
DDRIII 1333,1666
DDRIII 1333,1666
Lane3/Lane4
Lane7/Lane8
Lane5/Lane6
Lane11
Lane12
Lane9/Lane10
SATA0/SATA1
Lane13/Lane14
SATA0/SATA1
UNBUFFERED
DDRIII DIMM1 2
UNBUFFERED
DDRIII DIMM3 4
ASM1142
ASM1480
E2205 LAN
ASM1083
SATA_EX1
(Bottom Layer)
Lane7
Lane8
Lane7/Lane8
USB3.1*2
PCIE*X1 SLOT1
PCIE*X1 SLOT3
PCIE*X4 SLOT4
PCI SLOT1~3
M2_1
B B
ALC1150
SPI ROM
HD AUDIO I/F
SPI I/F
LPC I/F
Slot Sequence:
Print Port
SIO NTC6793
Lane15/Lane16
SATA2/SATA3
Lane17/Lane18
SATA5/SATA6
COM1
TPM 1.2
ASM1480
SATA_EX1
(Top Layer)
Lane15/Lane16
SATA2/SATA3
SATA1_2
PCIE X1
PCIE X16
A A
PCIE X1
PCIE X1
PCIE X4
PCI
PCI
5
4
KBD
MOUSE
MICRO-STAR INT'L CO.,LTD
MICRO-STAR INT'L CO.,LTD
MICRO-STAR INT'L CO.,LTD
MS-7970
MS-7970
MSI
MSI
MSI
Size Document Description Rev
Size Document Description Rev
Size Document Description Rev
Custom
Custom
Custom
Date:
Thursday, July 23, 2015
Date:
Thursday, July 23, 2015
Date:
3
2
Thursday, July 23, 2015
MS-7970
Block Diagram
Block Diagram
Block Diagram
1
Sheet of
Sheet of
Sheet of
263
263
263
1.1
1.1
1.1
5
4
3
2
1
SOCKET PN N12-151A010-L06
