MSI MS-7872 Schematic 0A

1

Cover Sheet BLOCK DIAGRAM

Clock Distribution PWRGD&RESET Map GPIO/MSIC TABLE VRM Intersil 6277/6377 3+1 PHASE AMD FM2

DDR3 DIMM CH-A

DDR3 DIMM CH-B DDR REF POWER AND CAPS

AMD HUDSON D2/3 HDMI CONN.

Display CONN VGA CONN. PCIE X16 SLOT

A A

PCIE X1 SLOTs Mini PCIE SLOT PCI SLOT LAN-RTL8111GN Azalia CODEC ALC892/662 USB 2.0 CONN. USB 3.0 CONN. USB POWER/DISCHARGE SATA//eSATA/ FAN TPM SUPER I/O NCT5533D VCC3 & VCC5 ACPI UPI & SYS POWER FCH CORE & DDR POWER ATX/F_Panel/EMI/LED Auto BOM manual History

1 2 3 Power Deliver Chart 4 5 6 7 8 ~ 11 12 13 14

15~19

20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40

(MS-7872L2 Ver:0A)

CPU:

AMD FM2+ colay FM2(Trinity/Richland/Kaveri (auto detect))

System Chipset:

AMD - Bolton D3 colay Hudson D3/D2

On Board Chipset:

CLOCK GEN --FCH internal clock gen LPC Super I/O --NCT5533D LAN-Realtek 8111GN Azalia CODEC - Realtek ALC892/662

Main Memory:

DDR III * 4 (max 32G)

Expansion Slots:

PCI Express X16 Slot * 1 PCI Express X1 Slot * 2 Mini PCI Express X1 Slot *1 for wifi LAN

PCI Slot *1

VRM

Controller - Intersil 62773+6208/4+2 Phase

1

mATX: 244mm * 244mm

MICRO-START INT'L CO.,LTD.

Title

COVER SHEET

Size Document Number Rev

Custom

Date: Sheet

MICRO-START INT'L CO.,LTD.

Kaveri-VC 0A

140Monday, June 17, 2013

of

Kaveri-VC

5

4

3

2

1

VGA CONNECTOR

D D

BoltonD3

C C

VGA

18

10/100/Giga bit ETHERNET 8111GN

23

DP CON

22

VGA MAIN LINK

HDMI CON

PCIE GFX x16

21

24

PCIE INTERFACE

28

USB REAR

/HDR

USB REAR

Only D3 support USB3.0

Kaveri-VC BLOCK DIAGRAM

DP2

DP 1

DP0

PCIE x16

30

31

FM2+

8~11

UMI

USB 2.0

USB 3.0

BoltonD3,

DDRIII 1333~1866

AZALIA

SERIAL ATA 3.0

CHA

CHB

ALC662/892

i-SATA [4:1]

33

UNBUFFERED DDRIII DIMM1 2

UNBUFFERED DDRIII DIMM3 4

29

12

13

HUDSON D3/D2

F_USB_30

Only D3 support USB3.0

B B

PCIE x1 SLOT1,2

PCIE INTERFACE

MINI PCIe x1 slot

25

USB 3.0

31

16~20

GPIO

SPI Bus

TPM

34

26

e-SATA 5

33

SPI ROM 32Mb

18

35

NFC

CPU CORE POWER NB CORE POWERACPI CONTROLLER Intersil ISL62773 Intersil ISL6208

GPIO

7

38

CPU VDDP Power CPU VDDR Power CPU VDDA Power DUAL POWER

A A

DDR3 DRAM POWER FCH CORE POWER

ATX CON

5

39

38

39

40

4

SUPER I/O NCT5533D

FAN

PS2

33

36

SERIAL PORT

36

3

LPC

36

2

Title

BLOCK Diagram

Size Document Number Rev

Custom

Date: Sheet

MICRO-START INT'L CO.,LTD.

Kaveri-VC 0A

240Monday, June 17, 2013

of

1

of

5

4

3

2

1

Power Deliver Chart

ATX P/S WITH 1A STBY CURRENT

5VSB +/-5%

D D

NCP81038 SWITCH

-12V

12V

+/-5%

VCC3VCC5

CPU PW 12V +/-5%

5VDIMM Linear REGULATOR

1.5V VDD SW REGULATOR

2.5V Shunt Regulator

VRM SW REGUALTOR

1.2V VDDR REGULATOR

CPU_VDD (S0, S1)

0.75V VTT_DDR REGULATOR

1.1V VCCP SW REGULATOR

DDRIII DIMM X4

VDD MEM VTT_DDR

VCC3 (S0, S1)

C C

VCC5_SB FET REGULATOR

VCC3_WAKE Linear REGULATOR

VCC3_SB SW REGULATOR

VCC5_SB

VCC3_SB (S0, S1, S3, S5)

1.1V_SB Linear REGULATOR

VDDA25 (S0, S1)

VCCP (S0, S1) / VCC_NB (S0, S1)

CPU_VDDR (S0, S1)

0R

CPU_VDDP (S0, S1)

0R

VCC_DDR (S0, S1, S3)

15A 2 A

NB_VCC1P1 (S0, S1)

+1.1VDUAL(S0,S1,S3,S5)

AMD FM1 CPU

VDDA FM2+:1.8V ;FM2:2.5V VDDCORE

0.8-2V VDDNBCORE

1.2V CPU_VDDR

FM2+:1.05V;FM2:1.2A

CPU_VDDP FM2+:1.05V;FM2:1.2A

DDR3 MEM I/F 1.5V VCC_DDR

0.8~2.3V

TBD A

HUDSON 2/3

VDDPL_11_DAC

VDDAN_11_ML

100 mA

VDDCR_11

500 mA

VDDAN_11_SATA

700 mA

VDDAN_11_CLK

400 mA

VDDAN_11_PCIE

900 mA

VDDIO_33_PCIGP 3.3V

300 mA

(S0, S1) VDDPL_33_*_RUN

320 mA

VDDPL_33_*_ALW

34 mA

VDDIO_33_GBE_S

1 mA

VDDAN_33_USB_S

130 mA

VDDXL_33_S

6 mA

VDDIO_33_S

30 mA

VDDCR/AN_11_SUSB_S

500 mA

VDDCR/AN_11_USB_S

52 mA

VDDCR_11_GBE_S

100 mA

VDDCR_11_S

100 mA

0.5A

120A

20A 5A

5A

20 mA

Mini PCIE per VCC3_SB

1.5V

AUDIO CODEC

3.3V CORE

5V ANALOG

SUPER I/O

+3.3V (S0, S1)

+3.3VDUAL (S3)

VBAT

0.1A

0.01A

1.5V Linear REGULATOR

VCC3

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Date: Sheet

MICRO-START INT'L CO.,LTD.

Power Deliver Chart ci20313

Power Deliver Chart

Custom

Kaveri-VC 0A

1

of

340Monday, June 17, 2013

VCC3 (S0, S1)

+5VA Linear

B B

SVCC Linear REGULATOR

SVCC(S0,S3)

REGULATOR

+5VA (S0, S1)

VCC3 (S0, S1)

VCC3_WAKE (S0, S1, S3, S5)

COM Port

VCC5 +12V

0.1A

-12V

A A

5

X1 PCIE per

3.3V 12V

3.3Vaux

X16 PCIE per

3.0A

0.5A

0.1A

4

3.3V 12V

3.3VDual

3.0A

5.5A

0.3A

USB 2.0 X2 FR

VDD 5VDual

1.0A

USB 3.0 X2 FR

VDD 5VDual

1.8A 1.8A

USB 2.0 X2 RL 2XPS/2

VDD

5VDual

0.5A

1.0A

USB 3.0 X2 RL

VDD 5VDual

3

+LAN_3VSB REGULATOR

ENTHENET

3.3V 1.05V

70mA

+LAN_3VSB

300mA

2

5

4

3

2

1

INTERNAL CLOCK MODE

D D

CH A CH B

DIMM1

DIMM2

DIMM3

DIMM4

AMD BoltonD3 , colay HudsonD3/D2

MEM_MA_CLK_H0/L0

MEM_MA_CLK_H3/L3

MEM_MA_CLK_H2/L2

C C

MEM_MA_CLK_H1/L1

AMD

FM2+ APU

MEM_MB_CLK_H0/L0

MEM_MB_CLK_H3/L3

MEM_MB_CLK_H1/L1

MEM_MB_CLK_H2/L2

APU_CLKP/N

DISP_CLKP/N

FCH_APU_CLKP

FCH_DISP_CLKP 100MHZ (NO SPREAD)

LPCCLK0 LPCCLK1

AZ_BITCLK

FCH_GFX_CLKP/N

FCH_GPP_CLK0P/N

FCH_GPP_CLK1P/N

FCH_GPP_CLK2P/N

USBCLK

14M_25M_48M_OSC

FCH_GPP_CLK3P/N

FCH_GPP_CLK4P/N

32K_X1

SATA_X1

FOR SATA DNI

25M Hz

SATA_X2

25M_X2

B B

25M_X1

25MHZ RTC CLOCK

32K_X2

32.768K Hz

PCICLK0

PCICLK1 PCICLK3

PCICLK2

PCICLK4

RTCCLK

SPI_CLK

PCICLK0

33MHZ

PCI_CLK3PCI_CLK1

33MHZ

PCICLK2

33MHZ

PCICLK4

33MHZ

LPC_CLK0

LPCCLK1

33MHZ

AZ_BIT_CLK

24MHZ

SPI_CLK

xxHZ

PE16_GXF_CLK/PE16_GXF_CLK#

100MHZ

PE1_GPP_CLK0/PE1_GPP_CLK0#

100MHZ

PE1_GPP_CLK1/PE1_GPP_CLK1#

100MHZ

PE_MINI_CLK/PE_MINI_CLK#

100MHZ

PE_LAN_CLK/PE_LAN_CLK#

100MHZ

SIO NCT5533D

STRAPS SETTING,

UNUSED CLOCKS

LPC header

PCI SLOT STRAPS SETTING,

RESERVE TP

HD AUDIO

SPI ROM & HEADER

PCIE GFX SLOT (FM2+, 16 LANES)

PCIE GPP SLOT1 (BoltonD3, 1 LANE)

PCIE GPP SLOT2 (BoltonD3, 1 LANE)

PCIE GPP SLOT3 (BoltonD3, 1 LANE)

PCIE LAN (FM2+, 1 LANE)

reserve LAN_CLKREQ#

PCIEX16 SLOT

PCIE X1 SLOT

Mini PCIE X1 SLOT

PCIE LAN

A A

MICRO-START INT'L CO.,LTD.

Title

Clock Distribution

Size Document Number Rev

C

Date: Sheet

5

4

3

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

Kaveri-VC 0A

1

440Monday, June 17, 2013

of

5

FM2+

PWROK(Pin AF14)

BoltonD3, HUDSON D3/D2

APU_PG(Pin E26)

D D

PWR_BTN#(Pin J4)

SLP_S3#(Pin T3)

SLP_S5#(Pin W2)

APU_PWRGD

FCH_PWRGDPWR_GD(Pin N7)

4

PWRGD MAP

3

2

1

POWER ON SEQUENCE

NCT 5533D

SLP_S5#

SLP_S5#(Pin 38)

SUSB#(Pin 31)SLP_S3#

PSOUT# (Pin 28)PSOUT#

ATX_POWER

U35

NCP1579

VRM U1

ISL62773

VDDPWRGD(Pin 23)

EN(Pin 9)

PWROK(Pin 10)

PS_ON#

VRM_PWRGD

Pin13

ATX_PWROK U29 (UP7501) 5VDIMM

Pin12

F_PANEL1PSIN#

VCC_DDR

U35 (uP0105) VDDA_25

PSON# (Pin 30)

PSIN# (Pin 29)

C C

ATX_PWROK

SLP_S5#

ATX_PWROK APU_FM2R1 VCC_DDR

DDR_EN

VCORE_EN

VRM_PWROK

FCH_PWRGD_R

U36

NCP1579

*

D80

VRM_PWRGD

B B

ATX_PWROK NB_VCC1P1 FP_RST# SLP_S3#

CPU_VDDP_VDDR_EN

NBCORE_EN

D81

CPU_VDD

U37

VCC3

NCP102

U41

FCH_PWRGD

CPU_VDDP CPU_VDDR

NB_VCC1P1

MEANS OPTION

*

RESET MAP

FM2+

RESET_L(Pin AF10)

PCIE 16X slot PCIE 1X slot 1 PCIE 1X slot 2 PCIE LAN Mini PCIE TPM

A A

LPC debug

Reserve TP Reserve TP

BoltonD3, HUDSON D3/D2

PCIE_RST#(Pin AE2)

A_RST#(Pin AD5)Super IO

PCIE_RST2#(Pin AB6) PCIRST#(Pin AB5)

5

APU_RST#(Pin F26)

SYS_RESET#(Pin U4)

FP_RST#

APU_RST#

F_PANEL

RESET#(Pin 12)

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Custom

Date: Sheet

4

3

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

PWRGD/RESET MAP

Kaveri-VC 0A

1

540Monday, June 17, 2013

of

5

4

3

2

1

DDR DIMM Config.

SIO NCT6776F GPIO Config

D D

50 GP60 VSB

78 GP36 VSB SIO_VDUAL_EN

GPIO Power Rail Function descriptionPin

GP4638 VSB SIO_WAKE

YLW_LED/GP4539 VSB

GRN_LED/GP4440 VSB PWR_LED

GP6742 VSB

GP6544

GP6445 VSB

GP6347 VSB

GP6248 VSB

GP6149 VSB

VSB

SUS_LED

USB_EN

MB_ID0

MB_ID1

MB_ID2

COM_GPIO2

CHASSIS_ID1

CHASSIS_ID2

Comment

OD

GPI

reserved

DEVICE

DIMM 1

10100000B

CH-A

10100010B A4H

CH-A MEM_MA_CLK_H3/L3

DIMM 3

10100001B

CH-B

DIMM 4

10100011B A6H

CH-B

CLOCKADDRESS

MEM_MA_CLK_H1/L1

A0H

MEM_MA_CLK_H2/L2

MEM_MA_CLK_H0/L0DIMM 2

MEM_MB_CLK_H1/L1

A2H

MEM_MB_CLK_H2/L2

MEM_MB_CLK_H0/L0 MEM_MB_CLK_H3/L3

SMBus TABLE

FCH HUDSON D3/D2GPIO Config

AJ3

C C

B B

AD22 SATA_ACT#/GPIO67 SATA_LED#:SATA Channel Active

M6

V3 SPI_CLK/GPIO162 SPI Clock

V6 SPI_DI/GPIO164 SPI Data In

V5 SPI_DO/GPIO163 SPI Data Output

T6 SPI_CS1#/GPIO165 SPI Chip Select1#

Y6 SPI_HOLD#/GEVENT9# SPI HOLD#. Assert low to hold the SPI transaction.

J7 USB_OC1#/TDI/GEVENT13# OC#1:USB2.0 port 4,5

P5 USB_OC2#/TCK/GEVENT14#

P5 USB_OC3#/

P6 USB_OC4#/IR_RX0/

T1 OC#5:USB2.0 port 2,3

R8 OC#6:USB2.0 port 0,1

M7 OC#7:USB 3.0 port 2,USB 2.0 port12BLINK/USB_OC7#/

pin Name Function description

AD0/GPIO0 CLEAR_CMOS

IR_LED#/LLB#/GPIO184 MINI_PWRONJ2

TEMPIN3/TALERT#/ GPIO174

ROM_RST#/SPI_WP#/GPIO161V1 SPI write protect (active low)

USB_OC0#/SPI_TPM_CS#/ TRST#/GEVENT12#

AC_PRES/TDO/GEVENT15#

GEVENT16# USB_OC5#/IR_TX0/ GEVENT17# USB_OC6#/IR_TX1/ GEVENT6#

GEVENT18#

GPIO[171::173];GPIO[175::182]; GPIO[193::194]

FCH_TALERT#:Thermal Alert. The FCH can be programmed to generate an SMI, SCI, or IRQ13 through GPE, or generate an SMI without GPE in response to the signal’s assertion.

OC#0:USB 3.0 port 3,USB 2.0 port 13T8

OC#2:USB2.0 port 8,9

OC#3:USB 3.0 port 0,USB 2.0 port 10

OC#4:USB 3.0 port 1,USB 2.0 port 11

Configure as one of the following: 10-kΩ 5% pull-up resistor to +3.3V_S5. 10-kΩ 5% pull-down resistor.

SOURCE

DP0_AUXP_C /DP0_AUXN_C

APU

DP1_AUXP_C /DP1_AUXN_C

SCLK0/SDATA0

FCH

SCLK1/SDATA1 LAN,PCIE SLOTs,MINI_PCIE

SCLK3/SDATA3 TP

RESET TABLE

SOURCE

PCIE_RST# PCIe 16X,1X,LAN,MINI_PCIE

FCH

FRONT PANEL

A_RST# SIO,LPC debug PCIE_RST2# RESERVE TP LDT_RST# APU AZ_RST# AZALIA CODEC DDR3_RST# NC FC_RST# DEBUG BUS ROM_RST# NC FP_RST# FCH,CLOCK GEN

LINKED DEVICESINGLE NAME

HDMI

Hudson D2/3 DP to VGA translator

DIMMs,CLOCK GEN ,SIO

LINKED DEVICESINGLE NAME

A A

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

C

Date: Sheet

5

4

3

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

GPIO/MSIC TABLE

Kaveri-VC 0A

1

640Monday, June 17, 2013

of

5

VID Override Circuit

D D

C C

B B

APU_SVC10

APU_SVD10

APU_SVT10

APU_PWRGD10,15

SVC SVD

00 0

COREFB+10

COREFB-10

VRM_PWRGD_R

1 01 11

Pre_PWROK Metal VID

ATX_PWROK25,30,34,36,37,38 APU_FM2R110,37

VCORE_EN_R34,37

R1 X_1KR0402R1X_1KR0402

1.1

1.0

0.9

0.8

R42

R46 0R0402R46 0R0402

NB_SENSE+10

NB_SENSE-10

VCCP

123

A A

VCC_DDRVCC_DDR

R2

X_1KR0402R2X_1KR0402

R10 0R0402R10 0R0402 R11 0R0402R11 0R0402 R12 33R0402R12 33R0402 SP1SP1

R5

R6

R4

X_1KR0402R5X_1KR0402

X_1KR0402R4X_1KR0402

R19

R18

R20

X_220R

BOOT VOLTAGE

C15

VCCP

10R0402

10R0402 0R0402

0R0402

R95

R95 X_1KR0402

X_1KR0402

R96 X_10KR0402R96 X_10KR0402

ATX_12V

GND GND

C15

C1000p50X0402

R40

3.83KR1%0402

R41

R47

5

3.83KR1%0402

C330p16N0402-RH-1

C24

C26

C330p16N0402-RH-1

C27

10R0402

C1000p50X0402

CPU_VDDNB

R60

C36

10R0402

R62

0R0402

R65

0R0402

R66

C1000p50X0402

10R0402

VSUM+ NB_VSUM+

2.61KR1%0402

R74

C42

C0.33u6.3X50402-RH

R81

C0.22u50X_0805

11KR0.5%0402-RH

RT1

10KRT1%

CLOSE to CHOKE1

C48

C0.1u16X0402

VCC5

R93

R93 X_10KR0402

X_10KR0402

Q14

C

B

E

X_N-SST3904_SOT23

D1 S-RB751V-40_SOD323-RHD1 S-RB751V-40_SOD323-RH D2 S-RB751V-40_SOD323-RHD2 S-RB751V-40_SOD323-RH

VCORE_EN_R

+12VIN

4

12V

C60

12V

PWRCONN4P_WHITE-RH-3

C0.1u16X50402-2

R16

X_1KR0402

X_1KR0402R6X_1KR0402

SVC SVD SVT VRM_PWROK

R21

X_220R

VRM_PWRGD37

TP1TP1

VCC_DDR

R36 301R1%0402R36 301R1%0402

C32

R55

C470p50X0402

R59

5.6KR1%0402

C330p16N0402-RH-1

C38

C41 C0.33u6.3X50402-RHC41 C0.33u6.3X50402-RH

R75

C43

649R1%0402

R84

X_100R0402

VRM_PWRGD

DS

C51

Q13

G

VCC5 +12VIN

X_N-2N7002P_SOT23-3-HF

R98

R98 10KR0402

10KR0402

DS

Q17

G

N-2N7002P_SOT23-3-HF

CHOKE5

CH-1.2u15A1.7m-RH-2

1 2

VRM_PWRGD_R VRM_PWROK VCORE_EN

VCC5

R14

R13

1KR1%0805

X_1KR1%0805

R23 0R0402R23 0R0402

SVC SVD SVT

C12 C100p50N0402C12 C100p50N0402

C13

R31

137KR1%0402

R38 33KR1%0402-RHR38 33KR1%0402-RH

C25 C1000p50X0402C25 C1000p50X0402

R43

3.83KR1%0402

R52

499R1%0402

C37

C330p16N0402-RH-1

RT2

10KRT1%

NB_VSUM-VSUM-

CLOSE to CHOKE3

X_C0.1u16X50402-2

VCC5 VCC5

C330p50N0402

143KR1%0402

R61

2.61KR1%0402

G

VIN

C1 X_C0.1u16X50402-2C1 X_C0.1u16X50402-2 C2 X_C0.1u16X50402-2C2 X_C0.1u16X50402-2 C3 C2.2u6.3X50402C3 C2.2u6.3X50402

R15

X_1KR1%0805

PG_NB

VRM_PWROK

C11

C17 C10p25N0402-RH-2C17 C10p25N0402-RH-2

C28 C100p50N0402C28 C100p50N0402

C30

R57

X_32.4KR1%0402

5.62KR1%0402

R76

C44

11KR0.5%0402-RH

C0.1u50X0805

R82

C49

C0.1u16X0402

Make sure +12VIN connector plug in

R99

10.7KR1%0402

DS

Q18

Q18 N-2N7002P_SOT23-3-HF

N-2N7002P_SOT23-3-HF

4

VCORE_EN

VRM_PWRGD_R

R24 X_0R0402R24 X_0R0402

X_C0.1u16X0402

R30

X_24.9KR1%0402

C470p50X0402

C34 C1500p50X0402C34 C1500p50X0402

C45

R86 X_100R0402R86 X_100R0402

C0.33u25X0805

R102

3.3KR0402

C46 C0.33u6.3X50402-RHC46 C0.33u6.3X50402-RH

C1u6.3X70603-HFC6C1u6.3X70603-HF

9

ENABLE

23

PGOOD

42

PGOOD_NB

10

PWROK

4

SVC

6

SVD

8

SVT

5

VR_HOT_L

7

VDDIO

22

COMP

20

FB2

21

FB

18

VSEN

19

RTN

43

COMP_NB

44

FB_NB

45

VSEN_NB

16

ISUMP

17

ISUMN

47

ISUMP_NB

46

ISUMN_NB

R83 422R1%0402R83 422R1%0402

ISL62773HRZ_QFN48-HFISL62773HRZ_QFN48-HF

VCORE_EN

C57

C57 C2.2u6.3X5

C2.2u6.3X5

C6

R7

2.2R0805R72.2R0805

VCC5 VCC5

C4

C1u6.3X70603-HFC4C1u6.3X70603-HF

29

VDD

R8

1R0805R81R0805

30

VDDP

PAD GND

49

+12VIN

R9

0R0805R90R0805

C5 C0.22u16XC5 C0.22u16X

35

xinhai@schmatic update(2011/10/07)

VIN

FCCM_NB

BOOT1

UGATE1

PHASE1

LGATE1

BOOT2

UGATE2

PHASE2

LGATE2

PWM_Y

BOOTX

UGATEX

PHASEX

LGATEX

PWM2_NB

ISNE1 ISNE2 ISEN3

ISNE1_NB ISEN2_NB

NTC

NTC_NB

IMON

IMON_NB

C1000p50X0402

C1u6.3X50402-HF

3

VIN

X_C10u16X50805-HFC8X_C10u16X50805-HF

C1u16X5-RHC7C1u16X5-RH

+

12

C8

C7

EC10

C270u16SO-HF-1

+

12

EC9

C470u2.5SO-HF

4 3 2 1

N-PK516BA_PDFN8-HF

5

Q4

4 3 2 1

5

Q6

4 3 2 1

5

Q7

4 3 2 1

5

Q10

4 3 2 1

N-PK510BA_PDFN8-HF

X_10KR0402

RT3

R100

10KR0402

UG3

PH3

N-PK510BA_PDFN8-HF

1 8

LGATE5GND

C470u2.5SO-HF

5

Q1

R25

2.2R1206

C10

C1000p50N

VSUM+

ISEN1

R108

X_10KR0402

VSUM-

C1u16X5-RH

C19

C20

X_C10u16X50805-HF

R45

2.2R1206

C29

C1000p50N

VSUM+ ISEN3

ISEN2

R114

X_10KR0402

VSUM-

C1u16X5-RH

12

+

C35

EC12

C270u16SO-HF-1

5

Q11

R68

2.2R1206

C39

C1000p50N

R79

VIN

5

Q15

4 3 2 1

N-PK516BA_PDFN8-HF

5

Q20

4

3

2

1

N-PK510BA_PDFN8-HF

R113

10KR0402

R118 0R0805R118 0R0805

UG2_NB PH2_NB

LG2_NB

N-PK510BA_PDFN8-HF

5

Q2

R3210KR0402 R3210KR0402

4 3 2

R17 0R0805R17 0R0805

1

N-PK516BA_PDFN8-HF

R22

118KR1%0402

C1000p50X0402

R26

R37

PWMY

R53

PWM2_NB

ISEN1 ISEN2 ISEN3

NB_ISEN1 NB_ISEN2

C58

0R0805

UG1_NB

PH1_NB

LG1_NB

R67

R67 R69

R69

R72 X_0R0402R72 X_0R0402

R89

C50

R94

118KR1%0402

VCC5

R22

X_41.2KR1%

C9

C0.22u16XC9C0.22u16X

UG1

PH1

LG1

C16

C0.22u16X

UG2

PH2

LG2

C31

C0.22u16X

VCC5

X_0R0402

X_0R0402 X_0R0402

X_0R0402

R77

X_0R0402

R85

0R0402

R87

X_0R0402

R90

18.2KR1%0402-RH

X_27.4KR1%0402-RH

100KRT1%0402

R92

BOOT3 PH3

R101

BOOT3

0R0805

R104 0R0805R104 0R0805

PWMY

VCC5

N-PK510BA_PDFN8-HF

VIN

10KR0402

R39

4 3 2 1

R44 0R0805R44 0R0805

N-PK516BA_PDFN8-HF

N-PK510BA_PDFN8-HF

VIN

R63

10KR0402

4 3 2

R64 0R0805R64 0R0805

1

N-PK516BA_PDFN8-HF

VCC5

N-PK510BA_PDFN8-HF

ISEN4

R78

X_0R0402

RT4

ERT-J0EV474J

CLOSE Q1 or Q13

R97

C56

0R0805

C0.22u16X

ISL6208BCRZ_QFN8-HF

U2

2

BOOT

7

FCCM

6

VCC

3

PWM

4

BOOT2_NB PH2_NB

R115

R115 0R0805

0R0805

BOOT2_NB

R119 0R0805R119 0R0805

PWM2_NB

C68

C1u6.3X50402-HF

4 3 2 1

5

Q5

4 3 2 1

5

Q9

X_27.4KR1%0402-RH

UGATE

PHASE

LGATE5GND

GND_P

9

R112

0R0805

2 7 6 3 4

5

Q3

N-PK510BA_PDFN8-HF

N-PK516BA_PDFN8-HF

5

Q8

N-PK510BA_PDFN8-HF

N-PK516BA_PDFN8-HF

5

Q12

4 3 2 1

R88

18.2KR1%0402-RH

100KRT1%0402

R91

ERT-J0EV474J

CLOSE Q7 or Q8

R103 0R0805R103 0R0805

1 8

LG3

C65

C0.22u16X

ISL6208BCRZ_QFN8-HF

U3

BOOT

UGATE

FCCM

PHASE VCC PWM

GND_P

9

41

24

25

26

27

34

33

32

31

28

36

37

38

39

40

15 14 13

48 1

12 2

11 3

C47

+

12

EC1

C560u6.3SO-RH

C14

C0.22u16X0402-HF

+

12

EC11

C270u16SO-HF-1

C33

C0.22u16X0402-HF

NB_VSUM+

NB_ISEN1

R116

X_10KR0402

NB_VSUM-

EC17

X_C470u2.5SO-HF

4 3 2 1

N-PK516BA_PDFN8-HF

5

Q19

R117

X_10KR0402

N-PK516BA_PDFN8-HF

4 3 2 1

12

R28 3.65KR1%0402R28 3.65KR1%0402

R29 10KR0402R29 10KR0402

R34 1R1%0402R34 1R1%0402

R50 3.65KR1%0402R50 3.65KR1%0402

R54 10KR0402R54 10KR0402

R58 1R1%0402R58 1R1%0402

C40

C0.22u16X0402-HF

12

VSUM+

ISEN3

VSUM-

4 3 2 1

5

Q26

2

+

EC2

C560u6.3SO-RH

CP1CP1

CP3CP3

R70 3.65KR1%0402R70 3.65KR1%0402

R73 10KR0402R73 10KR0402

R80 1R1%0402R80 1R1%0402

+

C1u16X5-RH

5

Q16

R105

2.2R1206

C59

C1000p50X0402

R1093.65KR1%0402R1093.65KR1%0402

R110 10KR0402R110 10KR0402

C61

C0.22u16X0402-HF

VIN

5

Q21

N-PK516BA_PDFN8-HF

4 3 2 1

N-PK510BA_PDFN8-HF

NB_ISEN2

NB_VSUM-

12

CP6CP6

+

12

EC18

X_C470u2.5SO-HF

C54

CP8CP8

R1111R1%0402R1111R1%0402

4 3 2 1

5

Q27

CHOKE1

CH-0.3u50A0.6m-HF

1 2

CP2CP2

CHOKE2

CH-0.3u50A0.6m-HF

1 2

CP4CP4

1 2

12

C55

X_C10u16X50805-HF

CHOKE4

CH-0.3u50A0.6m-HF

1 2

12

5

Q22

NB_VSUM+

R120

X_10KR0402

+

12

EC4

C560u6.3SO-RH

12

CHOKE3

CH-0.3u50A0.6m-HF

12

CP5CP5

+

12

EC19

X_C470u2.5SO-HF

12

CP7CP7

C1u16X5-RH

C62

R122

2.2R1206

C70

C1000p50X0402

R127 3.65KR1%0402R127 3.65KR1%0402

R129 10KR0402R129 10KR0402

C72

C0.22u16X0402-HF

+

12

+

12

EC6

EC7

C560u6.3SO-RH

VCCP

R27 X_10KR0402R27 X_10KR0402

ISEN2

R33 X_10KR0402R33 X_10KR0402

ISEN3

R35 X_10KR0402R35 X_10KR0402

ISEN4

C22u6.3X50805-RH

C18

C22

VCCP

R48 X_10KR0402R48 X_10KR0402

ISEN1

R51 X_10KR0402R51 X_10KR0402

R56 X_10KR0402R56 X_10KR0402

ISEN4

CPU_VDDNB

R71 X_10KR0402R71 X_10KR0402

NB_ISEN2

+

12

+

12

EC14

EC13

C560u6.3SO-RH

VCCP

+

12

EC20

C66

C270u16SO-HF-1

X_C10u16X50805-HF

CHOKE6

CH-0.3u50A0.6m-HF

CP9CP9

R1321R1%0402R1321R1%0402

1 2

12

CPU_VDDNB

12

CP10CP10

R124 X_10KR0402R124 X_10KR0402

NB_ISEN1

Title

FM1 PCIE I/F

Size Document Number Rev

Custom

Kaveri-VC 0A

Date: Sheet

1

VCCP

+

12

EC8

C560u6.3SO-RH

VCCP

C22u6.3X50805-RH

C21

C23

R49

X_10KR0402

+

12

+

12

EC15

EC16

C560u6.3SO-RH

CPU_VDDNB

C22u6.3X50805-RH

C52

C53

MICRO-START INT'L CO.,LTD.

of

740Tuesday, June 18, 2013

5

4

3

2

1

5

4

3

2

1

FM1 PCIE I/F

D D

CPU1A

GFX_RX0P23 GFX_RX0N23 GFX_RX1P23 GFX_RX1N23 GFX_RX2P23 GFX_RX2N23 GFX_RX3P23 GFX_RX3N23 GFX_RX4P23 GFX_RX4N23 GFX_RX5P23 GFX_RX5N23 GFX_RX6P23 GFX_RX6N23 GFX_RX7P23 GFX_RX7N23 GFX_RX8P23 GFX_RX8N23

C C

B B

CPU_VDDP

GFX_RX9P23 GFX_RX9N23 GFX_RX10P23 GFX_RX10N23 GFX_RX11P23 GFX_RX11N23 GFX_RX12P23 GFX_RX12N23 GFX_RX13P23 GFX_RX13N23 GFX_RX14P23 GFX_RX14N23 GFX_RX15P23 GFX_RX15N23

LAN_RXP27 LAN_RXN27

UMI_RX0P15 UMI_RX0N15 UMI_RX1P15 UMI_RX1N15 UMI_RX2P15 UMI_RX2N15 UMI_RX3P15 UMI_RX3N15

R134 196R1%R134 196R1% R135 196R1%R135 196R1%

LAN_RXP LAN_RXN

APU_P_ZVDDP

Layout: Place within 1.5'' of APU

AD8

P_GFX_RXP0

AD9

P_GFX_RXN0

AC7

P_GFX_RXP1

AC8

P_GFX_RXN1

AB5

P_GFX_RXP2

AB6

P_GFX_RXN2

AB8

P_GFX_RXP3

AB9

P_GFX_RXN3

AA7

P_GFX_RXP4

AA8

P_GFX_RXN4

Y5

P_GFX_RXP5

Y6

P_GFX_RXN5

Y8

P_GFX_RXP6

Y9

P_GFX_RXN6

W7

P_GFX_RXP7

W8

P_GFX_RXN7

V5

P_GFX_RXP8

V6

P_GFX_RXN8

V8

P_GFX_RXP9

V9

P_GFX_RXN9

U7

P_GFX_RXP10

U8

P_GFX_RXN10

T5

P_GFX_RXP11

T6

P_GFX_RXN11

T8

P_GFX_RXP12

T9

P_GFX_RXN12

R7

P_GFX_RXP13

R8

P_GFX_RXN13

P5

P_GFX_RXP14

P6

P_GFX_RXN14

P8

P_GFX_RXP15

P9

P_GFX_RXN15

AF5

P_GPP_RXP0

AF6

P_GPP_RXN0

AF8

P_GPP_RXP1

AF9

P_GPP_RXN1

AE7

P_GPP_RXP2

AE8

P_GPP_RXN2

AD5

P_GPP_RXP3

AD6

P_GPP_RXN3

AJ8

P_UMI_RXP0

AJ7

P_UMI_RXN0

AH6

P_UMI_RXP1

AH5

P_UMI_RXN1

AH9

P_UMI_RXP2

AH8

P_UMI_RXN2

AG8

P_UMI_RXP3

AG7

P_UMI_RXN3

AJ2

P_ZVDDP

ZIF-SOCKET906-HF

PCI EXPRESS

UMI GPP GRAPHICS

P_GFX_TXP0 P_GFX_TXN0 P_GFX_TXP1 P_GFX_TXN1 P_GFX_TXP2 P_GFX_TXN2 P_GFX_TXP3 P_GFX_TXN3 P_GFX_TXP4 P_GFX_TXN4 P_GFX_TXP5 P_GFX_TXN5 P_GFX_TXP6 P_GFX_TXN6 P_GFX_TXP7 P_GFX_TXN7 P_GFX_TXP8 P_GFX_TXN8 P_GFX_TXP9 P_GFX_TXN9

P_GFX_TXP10

P_GFX_TXN10

P_GFX_TXP11

P_GFX_TXN11

P_GFX_TXP12

P_GFX_TXN12

P_GFX_TXP13

P_GFX_TXN13

P_GFX_TXP14

P_GFX_TXN14

P_GFX_TXP15

P_GFX_TXN15

P_GPP_TXP0

P_GPP_TXN0

P_GPP_TXP1

P_GPP_TXN1

P_GPP_TXP2

P_GPP_TXN2

P_GPP_TXP3

P_GPP_TXN3

P_UMI_TXP0 P_UMI_TXN0 P_UMI_TXP1 P_UMI_TXN1 P_UMI_TXP2 P_UMI_TXN2 P_UMI_TXP3 P_UMI_TXN3

P_ZVSS

AC2 AC1 AC4 AC5 AB2 AB3 AA2 AA1 AA4 AA5 Y2 Y3 W2 W1 W4 W5 V2 V3 U2 U1 U4 U5 T2 T3 R2 R1 R4 R5 P2 P3 N2 N1

AF2 AF3 AE2 AE1 AE4 AE5 AD2 AD3

UMI_TX0P_APU

AJ5

UMI_TX0N_APU

AJ4

UMI_TX1P_APU

AH3

UMI_TX1N_APU

AH2

UMI_TX2P_APU

AG1

UMI_TX2N_APU

AG2

UMI_TX3P_APU

AG5

UMI_TX3N_APU

AG4

APU_P_ZVSS

AJ1

GFX_TXP0 GFX_TXN0 GFX_TXP1 GFX_TXN1 GFX_TXP2 GFX_TXN2 GFX_TXP3 GFX_TXN3 GFX_TXP4 GFX_TXN4 GFX_TXP5 GFX_TXN5 GFX_TXP6 GFX_TXN6 GFX_TXP7 GFX_TXN7 GFX_TXP8 GFX_TXN8 GFX_TXP9 GFX_TXN9 GFX_TXP10 GFX_TXN10 GFX_TXP11 GFX_TXN11 GFX_TXP12 GFX_TXN12 GFX_TXP13 GFX_TXN13 GFX_TXP14 GFX_TXN14 GFX_TXP15 GFX_TXN15

LAN_TXP LAN_TXN

C74 C0.22u6.3X70402C74 C0.22u6.3X70402 C75 C0.22u6.3X70402C75 C0.22u6.3X70402 C76 C0.22u6.3X70402C76 C0.22u6.3X70402 C77 C0.22u6.3X70402C77 C0.22u6.3X70402 C78 C0.22u6.3X70402C78 C0.22u6.3X70402 C79 C0.22u6.3X70402C79 C0.22u6.3X70402 C80 C0.22u6.3X70402C80 C0.22u6.3X70402 C81 C0.22u6.3X70402C81 C0.22u6.3X70402 C82 C0.22u6.3X70402C82 C0.22u6.3X70402 C83 C0.22u6.3X70402C83 C0.22u6.3X70402 C84 C0.22u6.3X70402C84 C0.22u6.3X70402 C85 C0.22u6.3X70402C85 C0.22u6.3X70402 C86 C0.22u6.3X70402C86 C0.22u6.3X70402 C87 C0.22u6.3X70402C87 C0.22u6.3X70402 C88 C0.22u6.3X70402C88 C0.22u6.3X70402 C89 C0.22u6.3X70402C89 C0.22u6.3X70402 C90 C0.22u6.3X70402C90 C0.22u6.3X70402 C91 C0.22u6.3X70402C91 C0.22u6.3X70402 C92 C0.22u6.3X70402C92 C0.22u6.3X70402 C93 C0.22u6.3X70402C93 C0.22u6.3X70402 C94 C0.22u6.3X70402C94 C0.22u6.3X70402 C95 C0.22u6.3X70402C95 C0.22u6.3X70402 C96 C0.22u6.3X70402C96 C0.22u6.3X70402 C97 C0.22u6.3X70402C97 C0.22u6.3X70402 C98 C0.22u6.3X70402C98 C0.22u6.3X70402 C99 C0.22u6.3X70402C99 C0.22u6.3X70402 C100 C0.22u6.3X70402C100 C0.22u6.3X70402 C101 C0.22u6.3X70402C101 C0.22u6.3X70402 C102 C0.22u6.3X70402C102 C0.22u6.3X70402 C103 C0.22u6.3X70402C103 C0.22u6.3X70402 C104 C0.22u6.3X70402C104 C0.22u6.3X70402 C105 C0.22u6.3X70402C105 C0.22u6.3X70402

C106 C0.1u10X0402C106 C0.1u10X0402 C107 C0.1u10X0402C107 C0.1u10X0402

C108 C0.1u10X0402C108 C0.1u10X0402 C109 C0.1u10X0402C109 C0.1u10X0402 C110 C0.1u10X0402C110 C0.1u10X0402 C111 C0.1u10X0402C111 C0.1u10X0402 C112 C0.1u10X0402C112 C0.1u10X0402 C113 C0.1u10X0402C113 C0.1u10X0402 C114 C0.1u10X0402C114 C0.1u10X0402 C115 C0.1u10X0402C115 C0.1u10X0402

Layout: Place within 1.5'' of APU

GFX_TXC_0P 23 GFX_TXC_0N 23 GFX_TXC_1P 23 GFX_TXC_1N 23 GFX_TXC_2P 23 GFX_TXC_2N 23 GFX_TXC_3P 23 GFX_TXC_3N 23 GFX_TXC_4P 23 GFX_TXC_4N 23 GFX_TXC_5P 23 GFX_TXC_5N 23 GFX_TXC_6P 23 GFX_TXC_6N 23 GFX_TXC_7P 23 GFX_TXC_7N 23 GFX_TXC_8P 23 GFX_TXC_8N 23 GFX_TXC_9P 23 GFX_TXC_9N 23 GFX_TXC_10P 23 GFX_TXC_10N 23 GFX_TXC_11P 23 GFX_TXC_11N 23 GFX_TXC_12P 23 GFX_TXC_12N 23 GFX_TXC_13P 23 GFX_TXC_13N 23 GFX_TXC_14P 23 GFX_TXC_14N 23 GFX_TXC_15P 23 GFX_TXC_15N 23

LAN_TXC_P 27 LAN_TXC_N 27

UMI_TX0P 15 UMI_TX0N 15 UMI_TX1P 15 UMI_TX1N 15 UMI_TX2P 15 UMI_TX2N 15 UMI_TX3P 15 UMI_TX3N 15

A A

MICRO-START INT'L CO.,LTD.

Title

FM1 PCIE I/F

Size Document Number Rev

B

Date: Sheet

5

4

3

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

Kaveri-VC 0A

1

of

840Tuesday, June 18, 2013

5

4

3

2

1

FM1DDR3 I/F

MEM_MA_DQS_L[7..0]12 MEM_MA_DQS_H[7..0]12

MEM_MA_DM[7..0]12

D D

MEM_MA_ADD0 MEM_MA_ADD1 MEM_MA_ADD2 MEM_MA_ADD3 MEM_MA_ADD4 MEM_MA_ADD5 MEM_MA_ADD6 MEM_MA_ADD7 MEM_MA_ADD8 MEM_MA_ADD9 MEM_MA_ADD10 MEM_MA_ADD11 MEM_MA_ADD12 MEM_MA_ADD13

MEM_MA_ADD[15..0]12

MEM_MA_BANK012 MEM_MA_BANK112 MEM_MA_BANK212

C C

mach@CLOCK assignment can be changed

MEM_MA_CLK_H012 MEM_MA_CLK_L012 MEM_MA_CLK_H112 MEM_MA_CLK_L112 MEM_MA_CLK_H212 MEM_MA_CLK_L212 MEM_MA_CLK_H312 MEM_MA_CLK_L312

MEM_MA_CKE012 MEM_MA_CKE112

MEM_MA0_ODT012 MEM_MA0_ODT112 MEM_MA1_ODT012 MEM_MA1_ODT112

MEM_MA0_CS_L012 MEM_MA0_CS_L112 MEM_MA1_CS_L012

APU_MA_VREFDQ14

MEM_MA1_CS_L112 MEM_MA_RAS_L12

MEM_MA_CAS_L12 MEM_MA_WE_L12

MEM_MA_RESET#12 MEM_MA_HOT#12

APU_M_VREF

VCC_DDR

B B

MEM_MA_ADD14 MEM_MA_ADD15

MEM_MA_BANK0 MEM_MA_BANK1 MEM_MA_BANK2

MEM_MA_DM0 MEM_MA_DM1 MEM_MA_DM2 MEM_MA_DM3 MEM_MA_DM4 MEM_MA_DM5 MEM_MA_DM6 MEM_MA_DM7

MEM_MA_DQS_H0 MEM_MA_DQS_L0 MEM_MA_DQS_H1 MEM_MA_DQS_L1 MEM_MA_DQS_H2 MEM_MA_DQS_L2 MEM_MA_DQS_H3 MEM_MA_DQS_L3 MEM_MA_DQS_H4 MEM_MA_DQS_L4 MEM_MA_DQS_H5 MEM_MA_DQS_L5 MEM_MA_DQS_H6 MEM_MA_DQS_L6 MEM_MA_DQS_H7 MEM_MA_DQS_L7

MEM_MA_CLK_H0 MEM_MA_CLK_L0 MEM_MA_CLK_H1 MEM_MA_CLK_L1 MEM_MA_CLK_H2 MEM_MA_CLK_L2 MEM_MA_CLK_H3 MEM_MA_CLK_L3

MEM_MA_CKE0 MEM_MA_CKE1

MEM_MA0_ODT0 MEM_MA0_ODT1 MEM_MA1_ODT0 MEM_MA1_ODT1

MEM_MA0_CS_L0 MEM_MA0_CS_L1 MEM_MA1_CS_L0 MEM_MA1_CS_L1

MEM_MA_RAS_L MEM_MA_CAS_L MEM_MA_WE_L

MEM_MA_RESET# MEM_MA_HOT#

APU_MA_VREFDQ

R137 39.2R1%0402R137 39.2R1%0402

MA_ZVDDIO

CPU1B

V27

MA_ADD0

P27

MA_ADD1

R25

MA_ADD2

P26

MA_ADD3

R24

MA_ADD4

P24

MA_ADD5

P23

MA_ADD6

N26

MA_ADD7

N23

MA_ADD8

M25

MA_ADD9

V24

MA_ADD10

N25

MA_ADD11

M24

MA_ADD12

Y23

MA_ADD13

L27

MA_ADD14

L24

MA_ADD15

W26

MA_BANK0

V25

MA_BANK1

L26

MA_BANK2

E17

MA_DM0

H21

MA_DM1

F25

MA_DM2

G29

MA_DM3

AF29

MA_DM4

AE25

MA_DM5

AG21

MA_DM6

AF17

MA_DM7

H17

MA_DQS_H0

G17

MA_DQS_L0

F21

MA_DQS_H1

E21

MA_DQS_L1

G26

MA_DQS_H2

G25

MA_DQS_L2

F30

MA_DQS_H3

E30

MA_DQS_L3

AE28

MA_DQS_H4

AE29

MA_DQS_L4

AG24

MA_DQS_H5

AG25

MA_DQS_L5

AF20

MA_DQS_H6

AF21

MA_DQS_L6

AE16

MA_DQS_H7

AD16

MA_DQS_L7

U27

MA_CLK_H0

U26

MA_CLK_L0

T23

MA_CLK_H1

U23

MA_CLK_L1

T25

MA_CLK_H2

T26

MA_CLK_L2

R27

MA_CLK_H3

R28

MA_CLK_L3

L23

MA_CKE0

K26

MA_CKE1

AA24

MA0_ODT0

AC27

MA0_ODT1

AA25

MA1_ODT0

AC26

MA1_ODT1

Y27

MA0_CS_L0

AB26

MA0_CS_L1

W23

MA1_CS_L0

AB25

MA1_CS_L1

W25

MA_RAS_L

Y24

MA_CAS_L

Y26

MA_WE_L

J25

MA_RESET_L

U24

MA_EVENT_L

K22

M_VREF

E15

MA_VREFDQ(FM2:VSS)

J24

MA_ZVDDIO(FM2:M_ZVDDIO)

ZIF-SOCKET906-HF

MA_DATA0 MA_DATA1 MA_DATA2 MA_DATA3 MA_DATA4 MA_DATA5 MA_DATA6 MA_DATA7

MA_DATA8

MA_DATA9 MA_DATA10 MA_DATA11 MA_DATA12 MA_DATA13 MA_DATA14 MA_DATA15

MA_DATA16 MA_DATA17 MA_DATA18 MA_DATA19 MA_DATA20 MA_DATA21 MA_DATA22 MA_DATA23

MA_DATA24 MA_DATA25 MA_DATA26 MA_DATA27 MA_DATA28 MA_DATA29 MA_DATA30 MA_DATA31

MA_DATA32 MA_DATA33 MA_DATA34 MA_DATA35 MA_DATA36 MA_DATA37 MA_DATA38 MA_DATA39

MA_DATA40 MA_DATA41 MA_DATA42 MA_DATA43 MA_DATA44 MA_DATA45 MA_DATA46 MA_DATA47

MA_DATA48 MA_DATA49 MA_DATA50 MA_DATA51 MA_DATA52 MA_DATA53 MA_DATA54 MA_DATA55

MA_DATA56 MA_DATA57 MA_DATA58 MA_DATA59 MA_DATA60 MA_DATA61 MA_DATA62 MA_DATA63

MEM_MA_DATA0

F16

MEM_MA_DATA1

G16

MEM_MA_DATA2

H18

MEM_MA_DATA3

F19

MEM_MA_DATA4

F15

MEM_MA_DATA5

H15

MEM_MA_DATA6

E18

MEM_MA_DATA7

F18

MEM_MA_DATA8

G20

MEM_MA_DATA9

H20

MEM_MA_DATA10

E23

MEM_MA_DATA11

G23

MEM_MA_DATA12

G19

MEM_MA_DATA13

E20

MEM_MA_DATA14

F22

MEM_MA_DATA15

G22

MEM_MA_DATA16

F24

MEM_MA_DATA17

H24

MEM_MA_DATA18

E27

MEM_MA_DATA19

F27

MEM_MA_DATA20

H23

MEM_MA_DATA21

E24

MEM_MA_DATA22

E26

MEM_MA_DATA23

H26

MEM_MA_DATA24

G28

MEM_MA_DATA25

E29

MEM_MA_DATA26

H29

MEM_MA_DATA27

H30

MEM_MA_DATA28

H27

MEM_MA_DATA29

F28

MEM_MA_DATA30

F31

MEM_MA_DATA31

G31

MEM_MA_DATA32

AD30

MEM_MA_DATA33

AF30

MEM_MA_DATA34

AG27

MEM_MA_DATA35

AF27

MEM_MA_DATA36

AD31

MEM_MA_DATA37

AE31

MEM_MA_DATA38

AG28

MEM_MA_DATA39

AD28

MEM_MA_DATA40

AF26

MEM_MA_DATA41

AD25

MEM_MA_DATA42

AF23

MEM_MA_DATA43

AE23

MEM_MA_DATA44

AD27

MEM_MA_DATA45

AE26

MEM_MA_DATA46

AF24

MEM_MA_DATA47

AD24

MEM_MA_DATA48

AG22

MEM_MA_DATA49

AD21

MEM_MA_DATA50

AE19

MEM_MA_DATA51

AG19

MEM_MA_DATA52

AD22

MEM_MA_DATA53

AE22

MEM_MA_DATA54

AE20

MEM_MA_DATA55

AD19

MEM_MA_DATA56

AG18

MEM_MA_DATA57

AE17

MEM_MA_DATA58

AF15

MEM_MA_DATA59

AG15

MEM_MA_DATA60

AD18

MEM_MA_DATA61

AF18

MEM_MA_DATA62

AG16

MEM_MA_DATA63

AD15

MEM_MA_DATA[63..0] 12

MEM_MB_ADD[15..0]13

MEM_MB_BANK013 MEM_MB_BANK113 MEM_MB_BANK213

MEM_MB_CLK_H013 MEM_MB_CLK_L013 MEM_MB_CLK_H113 MEM_MB_CLK_L113 MEM_MB_CLK_H213 MEM_MB_CLK_L213 MEM_MB_CLK_H313 MEM_MB_CLK_L313

MEM_MB_CKE013 MEM_MB_CKE113

MEM_MB0_ODT013 MEM_MB0_ODT113 MEM_MB1_ODT013 MEM_MB1_ODT113

MEM_MB0_CS_L013 MEM_MB0_CS_L113 MEM_MB1_CS_L013 MEM_MB1_CS_L113

MEM_MB_RAS_L13 MEM_MB_CAS_L13 MEM_MB_WE_L13

MEM_MB_RESET#13 MEM_MB_HOT#13

APU_MB_VREFDQ14

VCC_DDR

R136 39.2R1%0402R136 39.2R1%0402

MEM_MB_ADD0 MEM_MB_ADD1 MEM_MB_ADD2 MEM_MB_ADD3 MEM_MB_ADD4 MEM_MB_ADD5 MEM_MB_ADD6 MEM_MB_ADD7 MEM_MB_ADD8 MEM_MB_ADD9 MEM_MB_ADD10 MEM_MB_ADD11 MEM_MB_ADD12 MEM_MB_ADD13 MEM_MB_ADD14 MEM_MB_ADD15

MEM_MB_BANK0 MEM_MB_BANK1 MEM_MB_BANK2

MEM_MB_DM0 MEM_MB_DM1 MEM_MB_DM2 MEM_MB_DM3 MEM_MB_DM4 MEM_MB_DM5 MEM_MB_DM6 MEM_MB_DM7

MEM_MB_DQS_H0 MEM_MB_DQS_L0 MEM_MB_DQS_H1 MEM_MB_DQS_L1 MEM_MB_DQS_H2 MEM_MB_DQS_L2 MEM_MB_DQS_H3 MEM_MB_DQS_L3 MEM_MB_DQS_H4 MEM_MB_DQS_L4 MEM_MB_DQS_H5 MEM_MB_DQS_L5 MEM_MB_DQS_H6 MEM_MB_DQS_L6 MEM_MB_DQS_H7 MEM_MB_DQS_L7

MEM_MB_CLK_H0 MEM_MB_CLK_L0 MEM_MB_CLK_H1 MEM_MB_CLK_L1 MEM_MB_CLK_H2 MEM_MB_CLK_L2 MEM_MB_CLK_H3 MEM_MB_CLK_L3

MEM_MB_CKE0 MEM_MB_CKE1

MEM_MB0_ODT0 MEM_MB0_ODT1 MEM_MB1_ODT0 MEM_MB1_ODT1

MEM_MB0_CS_L0 MEM_MB0_CS_L1 MEM_MB1_CS_L0 MEM_MB1_CS_L1

MEM_MB_RAS_L MEM_MB_CAS_L MEM_MB_WE_L

MEM_MB_RESET# MEM_MB_HOT# APU_MB_VREFDQ

MB_ZVDDIO

MEM_MB_DQS_L[7..0]13 MEM_MB_DQS_H[7..0]13

MEM_MB_DM[7..0]13

V31 N28 P29 N29 N31 M30 M31 M28 M27 L30

W31

L29 K28

AB28

K31

J31

W29

V30 K29

D16 B20 A25 D29

AL29 AH25 AK21

AJ17

A17 B17 B21 C21 D25 C25 B29 A29

AJ29 AH29 AK25

AL25

AJ20

AJ21

AL16

AL17

U30 U29 T29 T28 R31 T31 P30 R30

J30 J28

AA30 AC30 AA31 AC29

Y29

AB29

Y30

AB31

W28 AA27 AA28

J27 V28 D14 K25

CPU1C

MEMORY CHANNEL B

MB_ADD0 MB_ADD1 MB_ADD2 MB_ADD3 MB_ADD4 MB_ADD5 MB_ADD6 MB_ADD7 MB_ADD8 MB_ADD9 MB_ADD10 MB_ADD11 MB_ADD12 MB_ADD13 MB_ADD14 MB_ADD15

MB_BANK0 MB_BANK1 MB_BANK2

MB_DM0 MB_DM1 MB_DM2 MB_DM3 MB_DM4 MB_DM5 MB_DM6 MB_DM7

MB_DQS_H0 MB_DQS_L0 MB_DQS_H1 MB_DQS_L1 MB_DQS_H2 MB_DQS_L2 MB_DQS_H3 MB_DQS_L3 MB_DQS_H4 MB_DQS_L4 MB_DQS_H5 MB_DQS_L5 MB_DQS_H6 MB_DQS_L6 MB_DQS_H7 MB_DQS_L7

MB_CLK_H0 MB_CLK_L0 MB_CLK_H1 MB_CLK_L1 MB_CLK_H2 MB_CLK_L2 MB_CLK_H3 MB_CLK_L3

MB_CKE0 MB_CKE1

MB0_ODT0 MB0_ODT1 MB1_ODT0 MB1_ODT1

MB0_CS_L0 MB0_CS_L1 MB1_CS_L0 MB1_CS_L1

MB_RAS_L MB_CAS_L MB_WE_L

MB_RESET_L MB_EVENT_L MB_VREFDQ(FM2:VSS) MB_ZVDDIO(FM2:RSVD5)

ZIF-SOCKET906-HF

MB_DATA0 MB_DATA1 MB_DATA2 MB_DATA3 MB_DATA4 MB_DATA5 MB_DATA6 MB_DATA7

MB_DATA8

MB_DATA9 MB_DATA10 MB_DATA11 MB_DATA12 MB_DATA13 MB_DATA14 MB_DATA15

MB_DATA16 MB_DATA17 MB_DATA18 MB_DATA19 MB_DATA20 MB_DATA21 MB_DATA22 MB_DATA23

MB_DATA24 MB_DATA25 MB_DATA26 MB_DATA27 MB_DATA28 MB_DATA29 MB_DATA30 MB_DATA31

MB_DATA32 MB_DATA33 MB_DATA34 MB_DATA35 MB_DATA36 MB_DATA37 MB_DATA38 MB_DATA39

MB_DATA40 MB_DATA41 MB_DATA42 MB_DATA43 MB_DATA44 MB_DATA45 MB_DATA46 MB_DATA47

MB_DATA48 MB_DATA49 MB_DATA50 MB_DATA51 MB_DATA52 MB_DATA53 MB_DATA54 MB_DATA55

MB_DATA56 MB_DATA57 MB_DATA58 MB_DATA59 MB_DATA60 MB_DATA61 MB_DATA62 MB_DATA63

MEM_MB_DATA0

A16

MEM_MB_DATA1

C16

MEM_MB_DATA2

B18

MEM_MB_DATA3

A19

MEM_MB_DATA4

C15

MEM_MB_DATA5

B15

MEM_MB_DATA6

D17

MEM_MB_DATA7

C18

MEM_MB_DATA8

D20

MEM_MB_DATA9

A20

MEM_MB_DATA10

D22

MEM_MB_DATA11

D23

MEM_MB_DATA12

C19

MEM_MB_DATA13

D19

MEM_MB_DATA14

A22

MEM_MB_DATA15

C22

MEM_MB_DATA16

C24

MEM_MB_DATA17

B24

MEM_MB_DATA18

B26

MEM_MB_DATA19

C27

MEM_MB_DATA20

A23

MEM_MB_DATA21

B23

MEM_MB_DATA22

D26

MEM_MB_DATA23

A26

MEM_MB_DATA24

C28

MEM_MB_DATA25

D28

MEM_MB_DATA26

C31

MEM_MB_DATA27

D31

MEM_MB_DATA28

B27

MEM_MB_DATA29

A28

MEM_MB_DATA30

B30

MEM_MB_DATA31

C30

MEM_MB_DATA32

AJ30

MEM_MB_DATA33

AK30

MEM_MB_DATA34

AH28

MEM_MB_DATA35

AJ27

MEM_MB_DATA36

AG30

MEM_MB_DATA37

AH31

MEM_MB_DATA38

AK28

MEM_MB_DATA39

AL28

MEM_MB_DATA40

AJ26

MEM_MB_DATA41

AH26

MEM_MB_DATA42

AH23

MEM_MB_DATA43

AJ23

MEM_MB_DATA44

AK27

MEM_MB_DATA45

AL26

MEM_MB_DATA46

AJ24

MEM_MB_DATA47

AK24

MEM_MB_DATA48

AK22

MEM_MB_DATA49

AH22

MEM_MB_DATA50

AL19

MEM_MB_DATA51

AK19

MEM_MB_DATA52

AL23

MEM_MB_DATA53

AL22

MEM_MB_DATA54

AH20

MEM_MB_DATA55

AL20

MEM_MB_DATA56

AJ18

MEM_MB_DATA57

AH17

MEM_MB_DATA58

AJ15

MEM_MB_DATA59

AK15

MEM_MB_DATA60

AH19

MEM_MB_DATA61

AK18

MEM_MB_DATA62

AK16

MEM_MB_DATA63

AH16

MEM_MB_DATA[63..0] 13

VCC_DDR

R138

1KR1%

C116

R139

1KR1%

A A

C1000p50X0402

5

APU_M_VREF

C117

C0.1u10X0402

C118

Layout: Place within 1.0'' of APU

C1000p50X0402

VCC_DDR

R140 1KR0402R140 1KR0402 R141 1KR0402R141 1KR0402

4

3

MEM_MA_HOT# MEM_MB_HOT#

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

C

Date: Sheet

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

FM1 DDR3 I/F

Kaveri-VC 0A

1

940Tuesday, June 18, 2013

of

5

FM1 DISPLAY I/F

Note: Several vias on the DP0 interface violate the minimum distance rules for via to via spacing between diff pairs. These violations have been reviewed and approved on an individual basis, and pose no significant singal integrity issues for this implementation since the route lengths are under the maximum allowed spec, and the via distance violations are not severe.

DP0_TX0P20

FCH_THERMTRIP# 16

FCH_TALERT# 17

DP0_TX0N20 DP0_TX1P20

DP0_TX1N20 DP0_TX2P20

DP0_TX2N20 DP0_TX3P20

DP0_TX3N20 DP1_TX0P17

DP1_TX0N17 DP1_TX1P17

DP1_TX1N17 DP1_TX2P17

DP1_TX2N17 DP1_TX3P17

DP1_TX3N17

APU_SIC

C122

X_C10p50N0402

D D

APU_RST# APU_PWRGD

APU_THERMTRIP#

C C

APU_ALERT#

B B

X_C10p50N0402

Layout: Place within 1.5'' of APU

C136

C137

C180p50N0402

VCC_DDR

R152

2

10KR0402

61

Q30A

NN-CMKT3904_SOT363-6-RH

VCC3_SBVCC_DDR

R162

5

10KR0402

34

Q30B

NN-CMKT3904_SOT363-6-RH

R163

10KR0402

C119 C0.1u10X0402C119 C0.1u10X0402 C120 C0.1u10X0402C120 C0.1u10X0402

C121 C0.1u10X0402C121 C0.1u10X0402 C123 C0.1u10X0402C123 C0.1u10X0402

C124 C0.1u10X0402C124 C0.1u10X0402 C125 C0.1u10X0402C125 C0.1u10X0402

C126 C0.1u10X0402C126 C0.1u10X0402 C127 C0.1u10X0402C127 C0.1u10X0402

C128 C0.1u10X0402C128 C0.1u10X0402 C129 C0.1u10X0402C129 C0.1u10X0402

C130 C0.1u10X0402C130 C0.1u10X0402 C131 C0.1u10X0402C131 C0.1u10X0402

C132 C0.1u10X0402C132 C0.1u10X0402 C133 C0.1u10X0402C133 C0.1u10X0402

C134 C0.1u10X0402C134 C0.1u10X0402 C135 C0.1u10X0402C135 C0.1u10X0402

DP2_TX0P_APU21 DP2_TX0N_APU21

DP2_TX1P_APU21 DP2_TX1N_APU21

DP2_TX2P_APU21 DP2_TX2N_APU21

DP2_TX3P_APU21 DP2_TX3N_APU21

APU_CLK15 APU_CLK#15

DISP_CLK15 DISP_CLK#15

APU_SVC7 APU_SVD7 APU_SVT7

APU_SIC34

APU_SID

APU_SID34

APU_RST#

APU_RST#15

APU_PWRGD7,15

APU_PROCHOT#15

APU_PWRGD

PULL UP

VCC_DDR

R176 1KR0402R176 1KR0402 R177 1KR0402R177 1KR0402

R180 300R0402R180 300R0402 R181 300R0402R181 300R0402

R182 1KR0402R182 1KR0402 R183 1KR0402R183 1KR0402 R184 1KR0402R184 1KR0402

R185 1KR0402R185 1KR0402 R186 1KR0402R186 1KR0402

VCC3_ALW

A A

R187 10KR0402R187 10KR0402

TEST2, TEST3, TEST6, TEST10, TEST23, TEST28_H TEST28_L, and any RSVD pins have no connections. TEST4, TEST5, TEST[17:14], TEST25_H/L,TEST30_H/L, and TEST32_H/L have onboard test points.

APU_SIC_R APU_SID

APU_RST#

APU_PWRGD

APU_PROCHOT# APU_ALERT# APU_THERMTRIP#

FCH_DMA_ACTIVE#

LDTSTOP_L

APU_FM2R1

5

CORETYPE0 CORETYPE1

TN/RD

KV TBD TBD

11

0 1

R166 10R0402R166 10R0402

APU_PROCHOT# APU_THERMTRIP# APU_ALERT#

1 0 00

4

DP0_TX0P_APU DP0_TX0N_APU

DP0_TX1P_APU DP0_TX1N_APU

DP0_TX2P_APU DP0_TX2N_APU

DP0_TX3P_APU DP0_TX3N_APU

DP1_TX0P_APU DP1_TX0N_APU

DP1_TX1P_APU DP1_TX1N_APU

DP1_TX2P_APU DP1_TX2N_APU

DP1_TX3P_APU DP1_TX3N_APU

DP2_TX0P_APU DP2_TX0N_APU

DP2_TX1P_APU DP2_TX1N_APU

DP2_TX2P_APU DP2_TX2N_APU

DP2_TX3P_APU DP2_TX3N_APU

APU_SVC APU_SVD APU_SVT

APU_SIC_RAPU_SIC

CPU_TDI CPU_TDO CPU_TCK CPU_TMS CPU_TRST_L CPU_DBRDY CPU_DBREQ_L

4

ROUTE PCIE AS 85OHM +/-10% PLACE CAPS WITH APU < 1 INCH

Trace length within 10"

CPU1D

ANALOG/DISPLAY/MISC

N4

DP0_TXP0

N5

DP0_TXN0

M2

DP0_TXP1

M3

DP0_TXN1

L2

DP0_TXP2

L1

DP0_TXN2

L4

DP0_TXP3

L5

DP0_TXN3

K2

DP1_TXP0

K3

J2 J1

J4 J5

H2 H3

L7 L8

K5 K6

K8 K9

J7 J8

N7 N8

M5 M6

M8 M9

AL12

AK12 AG12

AF12

C1 C2 D1

AK14

AL14

AF10 AF14

AE10 AH14

AJ14

G11

E10 E11 F11 F10

G10

E9

ZIF-SOCKET906-HF

DP1_TXN0 DP1_TXP1

DP1_TXN1 DP1_TXP2

DP1_TXN2 DP1_TXP3

DP1_TXN3 DP2_TXP0

DP2_TXN0 DP2_TXP1

DP2_TXN1 DP2_TXP2

DP2_TXN2 DP2_TXP3

DP2_TXN3 DP2_TXP4

DP2_TXN4 DP2_TXP5

DP2_TXN5 DP2_TXP6

DP2_TXN6

CLKIN_H CLKIN_L

DISP_CLKIN_H DISP_CLKIN_L

SVC SVD SVT

SIC SID

RESET_L PWROK

PROCHOT_L THERMTRIP_L ALERT_L

TDI TDO TCK TMS TRST_L DBRDY DBREQ_L

DISPLAY PORT 0

DISPLAY PORT 2 DISPLAY PORT 1

SER. CLK

MISC

CORETYPE0(FM2:RSVD1) CORETYPE1(FM2:RSVD2)

RSVD1(FM2:CORETYPE)

JTAG CTRL

SENSE RSVD

For FM2+ colay

DP1_AUXN_C

R178

1.8KR0402

Q32

D

N-2N7002

D

G

S

VCC3

R194 0R0402R194 0R0402

R195 0R0402R195 0R0402

VOLT_SELECT VOLT_SELECT

CORETYPE0

CORETYPE1

DP_AUX_ZVSS

DP_BLON

DP_DIGON

DP_VARY_BL

DP0_AUXP DP0_AUXN

DP1_AUXP DP1_AUXN

DP2_AUXP DP2_AUXN

DP3_AUXP DP3_AUXN

DISPLAY PORT MISC.

DP4_AUXP DP4_AUXN

DP5_AUXP DP5_AUXN

DP0_HPD DP1_HPD DP2_HPD DP3_HPD DP4_HPD DP5_HPD

TEST4 TEST5 TEST6

TEST9 TEST10 TEST14 TEST15 TEST16 TEST17 TEST18

TEST

TEST19 TEST20 TEST24

TEST25_H

TEST25_L

TEST28_H

TEST28_L

TEST30_H

TEST30_L

TEST31

TEST32_H

TEST32_L

TEST35

FM2R2(FM2:FM2R1)

DMAACTIVE_L

LDTSTOP_L

BP5/IDLEEXIT_L

RSVD3 RSVD4

RSVD6 RSVD7 RSVD8

VDDP_SENSE

VDDNB_SENSE

VDDIO_SENSE

VDD_SENSE

VDDR_SENSE

VSS_SENSE

Q33

N-2N7002

R188 20KR0402-2R188 20KR0402-2

DP_AUX_ZVSS

G9

APU_BLON

F8

APU_DIGON

G8

APU_BLPWM

E8 E1

E2 F1

F2 G1

G2 E5

E6 F5

F6 G5

G6 E3

F3 G3 E7 F7 G7

APU_TEST4

T21

APU_TEST5

U21

APU_TEST6

AD14

APU_TEST9

P21

APU_TEST10

R21

APU_TEST14

F12

APU_TEST15

E12

APU_TEST16

F13

APU_TEST17

E13

APU_TEST18

G13

APU_TEST19

G14

APU_TEST20

F14

APU_TEST24

E14

APU_TEST25_H

AJ11

APU_TEST25_L

AH11

APU_TEST28_H

H10

APU_TEST28_L

J10

APU_TEST30_H

T22

APU_TEST30_L

U22

APU_TEST31

AG31

APU_TEST32_H

V22

APU_TEST32L

R22

APU_TEST35

AE14 AC10

AG14 AD10 G12

CORETYPE0

AJ13

CORETYPE1

AH13 F9

AD12 K23

AB23 AC24 AG10

C3 A3 A4 B3 C4

R174 0R0402R174 0R0402

B4

R175 0R0402R175 0R0402

DP1_AUXP_C

R179

1.8KR0402

D

G

S

CORE TYPE LOGIC

R189 10KR0402R189 10KR0402

5

2

Q34

Q34 NN-CMKT3904_SOT363-6-RH

NN-CMKT3904_SOT363-6-RH

4

6

1

3

Jenny@DP0 for HDMI Jenny@DP1 for CRT Jenny@DP2 for DP

Layout: Place within 1.5'' of APU

R142 150R1%0402R142 150R1%0402

DP0_AUXP_C 20 DP0_AUXN_C 20

DP1_AUXP_C 17 DP1_AUXN_C 17

DP2_AUXP_C 21 DP2_AUXN_C 21

DP3_HPD DP4_HPD DP5_HPD

FCH_DMA_ACTIVE#

APU_FM2R1

LDTSTOP_L FM_IDLEEXIT_L

VDDP_SENSE

VDDR_SENSE

3

R147 100KR0402R147 100KR0402 R148 100KR0402R148 100KR0402 R149 100KR0402R149 100KR0402

TP2TP2 TP3TP3 TP4TP4 TP5TP5 TP6TP6

R701 X_1KR0402R701 X_1KR0402

TP8TP8

R776 X_1KR0402R776 X_1KR0402 R662 X_1KR0402R662 X_1KR0402 R154 1KR0402R154 1KR0402 R156 1KR0402R156 1KR0402 R157 1KR0402R157 1KR0402 R158 1KR0402R158 1KR0402 R159 511R1%0402R159 511R1%0402

R160 511R1%0402R160 511R1%0402 TP11TP11 TP12TP12 TP13TP13 TP14TP14

R161 39.2R1%0402R161 39.2R1%0402

TP15TP15 TP16TP16

R164 300R0402R164 300R0402

R165 X_300R0402R165 X_300R0402

NB_SENSE+ 7 VDDIOFB+ 37 COREFB+ 7

COREFB- 7

NB_SENSE- 7

VCC3

VOLT_SELECT

DP0_HPD_HDMI_C 20

DP1_HPD_VGA_C 17

DP2_HPD_DP_C 21

APU_FM2R1 7,37

FCH_DMA_ACTIVE# 15

LDTSTOP_L 15

TP17TP17

TP18TP18

Sabine HDMI Design Guidance HDMI enable strapping: TEST35 PU TO VCC_DDR thru 300R

R193

R193 10KR0402

10KR0402

VOLT_SELECT 14,20,21,36,37

CPU_VDDP

VCC_DDR

H:HDMI ENABLE

CPU_TRST_L

FM_IDLEEXIT_L

2

R167

R167 1KR0402

1KR0402

X_N-SST3904_SOT23

HDT+ Connector

VCC_DDR

J1

1

CPU_VDDIO

3

GND

5

GND

7

R143 X_0R0402R143 X_0R0402 R144 X_10KR0402R144 X_10KR0402 R145 X_10KR0402R145 X_10KR0402 R146 X_10KR0402R146 X_10KR0402

Q29A

X_NN-CMKT3904_SOT363-6-RH

VCC_DDR

B

Q31

GND CPU_TRST_L9CPU_PWROK_BUF CPU_DBRDY311CPU_RST_L_BUF CPU_DBRDY213CPU_DBRDY0 CPU_DBRDY115CPU_DBREQ_L

17

GND CPU_VDDIO19CPU_PLLTEST1

X_H2X10SM-1.27PITCH_BLUE-RH

VCC3 VCC3

R150

2

X_10KR0402

APU_PWROK_BUFAPU_PWRGD APU_LDT_RST_BUF

61

R168

X_10KR0402

CE

FCH_IDLEEXIT_L 16

SCAN Conn,

APU_TEST18 APU_TEST19

APU_TEST24 APU_TEST20

WARM RESET

APU_RST#

GPU DEBUG

APU_BLON APU_DIGON APU_BLPWM DP1_HPD_VGA_C

TP28TP28 TP29TP29

Title

Size Document Number Rev

C

Date: Sheet

1

CPU_TCK

2

CPU_TCK CPU_TMS

CPU_TDI

CPU_TDO

CPU_PLLTEST0

APU_RST#

R155

R155 X_0R0402

X_0R0402

VCC_DDR

VDDIOFB+ COREFB+

FM1 DISPLAY/MSIC

Kaveri-VC 0A

CPU_TMS

4

CPU_TDI

6

CPU_TDO

8

APU_PWROK_BUF

10

APU_LDT_RST_BUF

12

CPU_DBRDY

14

CPU_DBREQ_L

16

APU_TEST19

18

APU_TEST18

20

R151

5

X_10KR0402

34

Q29B

X_NN-CMKT3904_SOT363-6-RH

Layout: Place close to HDT header

R169 1KR0402R169 1KR0402 R170 1KR0402R170 1KR0402 R171 1KR0402R171 1KR0402 R172 1KR0402R172 1KR0402 R173 1KR0402R173 1KR0402

TP19TP19 TP20TP20

TP21TP21 TP22TP22

TP23TP23

TP24TP24 TP25TP25 TP26TP26 TP27TP27

MICRO-START INT'L CO.,LTD.

1

CPU_TDI CPU_TCK CPU_TMS CPU_TRST_L CPU_DBREQ_L

10 40Tuesday, June 18, 2013

of

5

4

3

2

1

BOTTOM SIDE DECOUPLING

VCCP

C697,C700,C705,C710 change to ASM-5010

C154

C144

C22u6.3X50805-RH

C161

C10u6.3X50805

C615

C180p50N0402

C175

C22u6.3X50805-RH

C199

C22u6.3X50805-RH

C195

C22u6.3X5-HF

C211

C10u6.3X50805

C139

C22u6.3X50805-RH

C162

C10u6.3X50805

C618

C0.1u16X50402-2

C176

C22u6.3X50805-RH

C207

C22u6.3X50805-RH

C196

C10u6.3X5-HF

C212

C10u6.3X50805

C188

C145

C22u6.3X50805-RH

C163

C10u6.3X50805

VCCP

C184

C143

C22u6.3X50805-RH

VCC_DDR

C201

C200

C22u6.3X50805-RH

C197

C171

C10u6.3X5-HF

C214

C213

C0.22u16X

VDDA_25VDDA25

FB1

30L3A-40_0805-RH

C22u6.3X50805-RH

C164

C10u6.3X50805

C673

C0.1u16X50402-2

C22u6.3X50805-RH

C10u6.3X50805

C0.22u16X

C185

C172

C215

C138

D D

C22u6.3X50805-RH

VCCP

C160

C10u6.3X50805

VCCP

C619

C180p50N0402

CPU_VDDNB

C C

C174

C22u6.3X50805-RH

VCC_DDR

C192

C22u6.3X50805-RH

CPU_VDDP

Layout: Place close to Pins

B B

AH10,AJ10,AK10,AL10

C194

C22u6.3X5-HF

CPU_VDDR

Layout: Place close to Pins AH11,AJ11,AK11,AL11

C210

C22u6.3X50805-RH

C186

C187

C149

C150

C148

C22u6.3X50805-RH

C165

C166

C10u6.3X50805

C676

C620

C0.1u16X50402-2

CPU_VDDNB CPU_VDDNB CPU_VDDNB CPU_VDDNB CPU_VDDNB CPU_VDDNB CPU_VDDNB

C216

C22u6.3X50805-RH

C191

C0.22u16X

C1000p50X0402

CPU_VDDR

C222

C0.22u16X

C22u6.3X50805-RH

C443

C10u6.3X50805

C685

C0.1u16X50402-2

C177

C10u6.3X50805

C206

C1000p50X0402

C223

C180p50N0402

C22u6.3X50805-RH

C447

C10u6.3X50805

C686

X_C180p50N0402

C10u6.3X50805

C180p50N0402

C151

C22u6.3X50805-RH

C453

C10u6.3X50805

C688

C180p50N0402

C178

C10u6.3X50805

VCC_DDR

CPU_VDDP

C218

C146

C147

C145

C152

C22u6.3X50805-RH

C457

C10u6.3X50805

C190

C4.7u6.3X50805

C180p50N0402

C153

C22u6.3X50805-RH

C179

C4.7u6.3X50805

C193

C4.7u6.3X50805

C219

C180p50N0402

C154

C796

C220

VCCP

C158

C157

VCCP

C167

C0.22u16X

C156

X_C22u6.3X50805-RH

C458

X_C10u6.3X50805

C181

C0.22u16X

C168

C0.22u16X

C157

X_C22u6.3X50805-RH

C459

X_C10u6.3X50805

C202

X_C22u6.3X50805-RH

C460

X_C10u6.3X50805

C182

C182 C180p50N0402

C180p50N0402

C203

C0.22u16X

C155

C22u6.3X50805-RH

C180

C0.22u16X

Place across each VDDIO-GND plane seam

VCC_DDR VCC_DDR

C786

C4.7u6.3X50805

C221

C180p50N0402

C0.22u16X

C159

X_C22u6.3X50805-RH

C183

C183 C180p50N0402

C180p50N0402

C204

C180p50N0402

C205

C180p50N0402

C169

C180p50N0402

C170

C180p50N0402

VCCP VCCP

CPU1E

VDD

AA11

AA13 AA21

AB10 AB14 AB16 AB18

AC11 AC13 AC19 AC21

AC17

AB22 AB24 AB27 AB30 AC23 AC25 AC28 AC31

AA26

AA23 AA29 MEC1 MEC2 MEC3 MEC4

AB7

Y20

M10

P10 T20

W11

AA3 AA6 AB1

AB4

AD1 AE3 AF4 AF7 AG6 AH7 H12 H14

H8 J11 J13 J15 J17 J19 J21

J9 K10 K12 K14

U13

K16 Y18

K18 K20

K4

L3 L11 L15

K27 J29

U25

T30 V29 L28 L31

M22 M23 M26 N24 N27 N30

P22

U31

W24

V23 V26

U28

P25 P28 P31

R23 R26 R29

T24

W27

L25

W30

Y22 Y25 Y28 K24

K30 Y31

J26

M29

T27

VDD-1 VDD-2 VDD-3 VDD-4 VDD-5 VDD-6 VDD-7 VDD-8 VDD-9 VDD-10 VDD-11 VDD-12 VDD-13 VDD-14 VDD-15 VDD-16 VDD-17 VDD-18 VDD-19 VDD-20 VDD-21 VDD-22 VDD-23 VDD-24 VDD-25 VDD-26 VDD-27 VDD-28 VDD-29 VDD-30 VDD-31 VDD-32 VDD-33 VDD-34 VDD-35 VDD-36 VDD-37 VDD-38 VDD-39 VDD-40 VDD-41 VDD-42 VDD-43 VDD-44 VDD-45 VDD-46 VDD-47 VDD-48 VDD-49 VDD-50

ZIF-SOCKET906-HF

CPU1F

VDDIO-1 VDDIO-2 VDDIO-3 VDDIO-4 VDDIO-5 VDDIO-6 VDDIO-7 VDDIO-8 VDDIO-9 VDDIO-10 VDDIO-11 VDDIO-12 VDDIO-13 VDDIO-14 VDDIO-15 VDDIO-16 VDDIO-17 VDDIO-18 VDDIO-19 VDDIO-20 VDDIO-21 VDDIO-22 VDDIO-23 VDDIO-24 VDDIO-25 VDDIO-26 VDDIO-27 VDDIO-28 VDDIO-29 VDDIO-30 VDDIO-31 VDDIO-32 VDDIO-33 VDDIO-34 VDDIO-35 VDDIO-36 VDDIO-37 VDDIO-38 VDDIO-39 VDDIO-40 VDDIO-41 VDDIO-42 VDDIO-43 VDDIO-44 VDDIO-45 VDDIO-46 VDDIO-47 VDDIO-48 VDDIO-49 MEC1 MEC2 MEC3 MEC4

ZIF-SOCKET906-HF

VDD-100(FM2:KEY)

VDD-51 VDD-52 VDD-53 VDD-54 VDD-55 VDD-56 VDD-57 VDD-58 VDD-59 VDD-60 VDD-61 VDD-62 VDD-63 VDD-64 VDD-65 VDD-66 VDD-67 VDD-68 VDD-69 VDD-70 VDD-71 VDD-72 VDD-73 VDD-74 VDD-75 VDD-76 VDD-77 VDD-78 VDD-79 VDD-80 VDD-81 VDD-82 VDD-83 VDD-84 VDD-85 VDD-86 VDD-87 VDD-88 VDD-89 VDD-90 VDD-91 VDD-92 VDD-93 VDD-94 VDD-95 VDD-96 VDD-97 VDD-98 VDD-99

VDDA-1 VDDA-2

VDDNB-1 VDDNB-2 VDDNB-3 VDDNB-4 VDDNB-5 VDDNB-6 VDDNB-7 VDDNB-8

VDDNB-9 VDDNB-10 VDDNB-11 VDDNB-12 VDDNB-13 VDDNB-14 VDDNB-15 VDDNB-16 VDDNB-17 VDDNB-18 VDDNB-19 VDDNB-20 VDDNB-21 VDDNB-22 VDDNB-23 VDDNB-24 VDDNB-25 VDDNB-26 VDDNB-27 VDDNB-28 VDDNB-29 VDDNB-30

VDDNB_CAP-1 VDDNB_CAP-2

VDDR-1 VDDR-2 VDDR-3 VDDR-4 VDDR-5 VDDR-6

VDDP-1 VDDP-2 VDDP-3 VDDP-4 VDDP-5 VDDP-6 VDDP-7 VDDP-8 VDDP-9

L17 L21 M12 M16 M18 M20 N6 N11 N19 N3 P1 P12 P20 T1 P4 P7 R11 R13 R19 T10 T12 U11 V20 U3 U6 V1 V10 V12 V4 V7 W13 W19 J6 N21 U19 AE6 AC15 W21 Y1 Y10 Y12 Y14 AA15 AA17 AA19 Y16 AH1 AF1 K7 AB12

AE13 AD13

A7 A6 A5 A9 C6 A10 A11 A12 A13 A14 B5 B6 B7 B8 B9 B10 B11 B12 B13 B14 C5 C14 C13 C12 C11 C10 C9 C8 C7 A8 M14 N13

AL10 AK8 AK9 AL8 AL9 AK10

AK4 AK5 AL5 AL3 AL4 AL6 AK3 AK6 AK2

VDDA25VCC_DDR

TP30TP30

CPU_VDDNB

VDDNB = 0.8V (Variable)

Layout: Place close to Pins M14,M13 inside the backplate cavity openning

VDDNB_CAP

C208 C22u6.3X50805-RHC208 C22u6.3X50805-RHC191 C209 C22u6.3X50805-RHC209 C22u6.3X50805-RH C698 C22u6.3X50805-RHC698 C22u6.3X50805-RH C856 C10u6.3X5-HFC856 C10u6.3X5-HF

CPU_VDDR

CPU_VDDP

FM2DECOUPLING CAPS

VSS

VDD

232

99

/ / /

7 /

3

2

/

4

/ /

/

31

/

Layout: Place close to Pins

H1,H2,H3,H4

VDDNB

30

2 2 1 2 / / / /

/

TOTLE POWER PINS

430 2

VALUE/SIZE/ MATERIAL

22U/1206/X5R 10U/0805/X5R

4.7U/0805/X5R

0.22U/0603/X5R

0.1U/0603/X5R

0.01U/0603/X5R

3.3 nF/0603/X5R 1 nF/0603/X5R 1 nF/0603/X5R 180 pF/0603/X5R

VDDR = 1.2V VDDPCIE = 1.2V ONLY ONE SIDE OF VDDPCIE & VDDR MUST CONNECTED ON THE PCB.CONNECTING BOTH SIDES IS ACCEPTABLE BUT NOT REQUIRED. BOTH SIDES MUST BE DECOUPLED.

VDDIO

VDDNBCAP

4 1 4

2+2

/ / / / / 2+2

2

VDDP

COMB

SPLIT

49

9

NEAR

//1

/ 2+1(B)

1

2

2+2

2

2+2

2 /

/

//

/

4

/

//

2+2

2

/

SPLIT

VDDR

6

FAR

/ / 2 2 / / / / / /

VDDA

CPU1H

AK29

VSS-115

R10

VSS-116

R12

VSS-117

R20

VSS-118

T4

Mvref

1

/

1 1

/ /

/

1

/ 1

/

1 / /

/

T7 T11 T13 T19

U9 U10 U12 U20 V11 V13 V19 V21

W3 W6

W9 W10 W12 W20 W22

Y4

Y7 Y11 Y13 Y15 Y17 Y19 Y21 AA9

AA10 AA14 AA16 AA18 AA20 AA22 AB13 AB15 AB17 AB19 AB21

AC3 AC6 AC9

AC12 AC14 AC16 AC18 AC22

AD4 AD7

AD11 AK20 AK23 AF19 AK26

A18 A21 A24 A27 B16 B19 B22 N22 B25 B28 C17 C20 C23 C26 C29

D2

D3

D4

D5

D6

D7

D8

D9 D10 D11 D12 D13

D15 D18 D21 D24 D27 D30

E4 E16

E19 E22 E25 E28 E31

F4 F17 F20 F23 F26 F29 G15 G18 G21 G24

R6

AL21 AL24 AL18

P11

VSS-119 VSS-120 VSS-121 VSS-122 VSS-123 VSS-124 VSS-125 VSS-126 VSS-127 VSS-128 VSS-129 VSS-130 VSS-131 VSS-132 VSS-133 VSS-134 VSS-135 VSS-136 VSS-137 VSS-138 VSS-139 VSS-140 VSS-141 VSS-142 VSS-143 VSS-144 VSS-145 VSS-146 VSS-147 VSS-148 VSS-149 VSS-150 VSS-151 VSS-152 VSS-153 VSS-154 VSS-155 VSS-156 VSS-157 VSS-158 VSS-159 VSS-160 VSS-161 VSS-162 VSS-163 VSS-164 VSS-165 VSS-166 VSS-167 VSS-168 VSS-169 VSS-170 VSS-171 VSS-172 VSS-173

VSS-233(FM2:KEY)

ZIF-SOCKET906-HF

CPU1G

VSS-1 VSS-2 VSS-3 VSS-4 VSS-5 VSS-6 VSS-7 VSS-8 VSS-9 VSS-10 VSS-11 VSS-12 VSS-13 VSS-14 VSS-15 VSS-16 VSS-17 VSS-18 VSS-19 VSS-20 VSS-21 VSS-22 VSS-23 VSS-24 VSS-25 VSS-26 VSS-27

VSS-29 VSS-30 VSS-31 VSS-32 VSS-33 VSS-34 VSS-35

VSS-37 VSS-38 VSS-39 VSS-40 VSS-41 VSS-42 VSS-43 VSS-44 VSS-45 VSS-46 VSS-47 VSS-48 VSS-49 VSS-50 VSS-51 VSS-52 VSS-53 VSS-54 VSS-55 VSS-56 VSS-57

ZIF-SOCKET906-HF

AF16

VSS-174

VSS

AF13

VSS-175

AF11

VSS-176

AF22

VSS-177

AF25

VSS-178

AF28

VSS-179

AF31

VSS-180

AG3

VSS-181

AG9

VSS-182

AG11

VSS-183

AG13

VSS-184

AG17

VSS-185

AG20

VSS-186

AG23

VSS-187

AG26

VSS-188

AG29

VSS-189

AH4

VSS-190

AH10

VSS-191

AH12

VSS-192

AH15

VSS-193

AH18

VSS-194

AH21

VSS-195

AH24

VSS-196

AH27

VSS-197

AH30

VSS-198

AJ3

VSS-199

AJ6

VSS-200

AJ9

VSS-201

AJ10

VSS-202

AJ12

VSS-203

AJ16

VSS-204

AJ19

VSS-205

AD17

VSS-206

AD20

VSS-207

AD23

VSS-208

AD26

VSS-209

AD29

VSS-210

AK7

VSS-211

AJ31

VSS-212

AJ28

VSS-213

AJ25

VSS-214

AJ22

VSS-215

AE9

VSS-216

AE11

VSS-217

AE12

VSS-218

AE15

VSS-219

AE18

VSS-220

AE21

VSS-221

AE24

VSS-222

AE27

VSS-223

AE30

VSS-224

AK11

VSS-225

AK13

VSS-226

K1

VSS-227

G4

VSS-228

M1

VSS-229

H1

VSS-230

J22

VSS-231

AB11

VSS-232

K19

P13

VSS-58

VSS

P19

VSS-59

R3

VSS-60

M4

VSS-61

R9

VSS-62

G27

VSS-63

G30

VSS-64

H4

VSS-65

H5

VSS-66

H6

VSS-67

H7

VSS-68

H9

VSS-69

H11

VSS-70

H13

VSS-71

H16

VSS-72

H19

VSS-73

H22

VSS-74

H25

VSS-75

H28

VSS-76

H31

VSS-77

M7

VSS-78

M11

VSS-79

M15

VSS-80

M17

VSS-81

M21

VSS-82

N9

VSS-83

N10

VSS-84

N12

VSS-85

N20

VSS-86

J12

VSS-87

J14

VSS-88

J16

VSS-89

J18

VSS-90

J20

VSS-91

J23

VSS-92

K11

VSS-93

K13

VSS-94

K15

VSS-95

K17

VSS-96

K21

VSS-97

J3

VSS-98

L6

VSS-99

L9

VSS-100

L10

VSS-101

L12

VSS-102

L14

VSS-103

L16

VSS-104

L18

VSS-105

L20

VSS-106

L22

VSS-107

AL7

VSS-108

AL27

VSS-109

A15

VSS-110

AK17

VSS-111

AL11

VSS-112

AL15

VSS-113

AL13

VSS-114

C0.22u16X

A A

C0.22u16X

C4.7u6.3X50805

C3300p50X0402-RH-1

5

4

3

2

Title

Size Document Number Rev

Custom

Date: Sheet

Date: Sheet of

MICRO-START INT'L CO.,LTD.

FM1 POWER&DECOUPLING

Kaveri-VC 0A

1

11 40Wednesday, June 19, 2013

of

5

VCC3

VCC_DDR

MEM_MA_DQS_H[7..0]9 MEM_MA_DQS_L[7..0]9

MEM_MA_DATA[63..0]9

D D

C C

B B

MEM_MA_DATA0 MEM_MA_DATA1 MEM_MA_DATA2 MEM_MA_DATA3 MEM_MA_DATA4 MEM_MA_DATA5 MEM_MA_DATA6 MEM_MA_DATA7 MEM_MA_DATA8 MEM_MA_DATA9 MEM_MA_DATA10 MEM_MA_DATA11 MEM_MA_DATA12 MEM_MA_DATA13 MEM_MA_DATA14 MEM_MA_DATA15 MEM_MA_DATA16 MEM_MA_DATA17 MEM_MA_DATA18 MEM_MA_DATA19 MEM_MA_DATA20 MEM_MA_DATA21 MEM_MA_DATA22 MEM_MA_DATA23 MEM_MA_DATA24 MEM_MA_DATA25 MEM_MA_DATA26 MEM_MA_DATA27 MEM_MA_DATA28 MEM_MA_DATA29 MEM_MA_DATA30 MEM_MA_DATA31 MEM_MA_DATA32 MEM_MA_DATA33 MEM_MA_DATA34 MEM_MA_DATA35 MEM_MA_DATA36 MEM_MA_DATA37 MEM_MA_DATA38 MEM_MA_DATA39 MEM_MA_DATA40 MEM_MA_DATA41 MEM_MA_DATA42 MEM_MA_DATA43 MEM_MA_DATA44 MEM_MA_DATA45 MEM_MA_DATA46 MEM_MA_DATA47 MEM_MA_DATA48 MEM_MA_DATA49 MEM_MA_DATA50 MEM_MA_DATA51 MEM_MA_DATA52 MEM_MA_DATA53 MEM_MA_DATA54 MEM_MA_DATA55 MEM_MA_DATA56 MEM_MA_DATA57 MEM_MA_DATA58 MEM_MA_DATA59 MEM_MA_DATA60 MEM_MA_DATA61 MEM_MA_DATA62 MEM_MA_DATA63

54

DIMM4

3

DQ0

VDD51VDD

4

DQ1

9

DQ2

10

DQ3

122

DQ4

123

DQ5

128

DQ6

129

DQ7

12

DQ8

13

DQ9

18

DQ10

19

DQ11

131

DQ12

132

DQ13

137

DQ14

138

DQ15

21

DQ16

22

DQ17

27

DQ18

28

DQ19

140

DQ20

141

DQ21

146

DQ22

147

DQ23

30

DQ24

31

DQ25

36

DQ26

37

DQ27

149

DQ28

150

DQ29

155

DQ30

156

DQ31

81

DQ32

82

DQ33

87

DQ34

88

DQ35

200

DQ36

201

DQ37

206

DQ38

207

DQ39

90

DQ40

91

DQ41

96

DQ42

97

DQ43

209

DQ44

210

DQ45

215

DQ46

216

DQ47

99

DQ48

100

DQ49

105

DQ50

106

DQ51

218

DQ52

219

DQ53

224

DQ54

225

DQ55

108

DQ56

109

DQ57

114

DQ58

115

DQ59

227

DQ60

228

DQ61

233

DQ62

234

DQ63

2

VSS

5

VSS

8

VSS

11

VSS

14

VSS

17

VSS

20

VSS

23

VSS

26

VSS

29

VSS

32

VSS

35

VSS

38

VSS

41

VSS

44

VSS

47

VSS

80

VSS

83

VSS

86

VSS

89

VSS

92

VSS

95

VSS

98

VSS

101

VSS

104

VSS

107

110

113

116

170

VDD57VDD60VDD62VDD65VDD66VDD69VDD72VDD75VDD78VDD

VSS

119

121

124

127

130

133

136

139

142

DIMM4(CHANNEL-A A0) SM ADDRESS=A0

173

176

179

182

183

VDD

DDR3

VSS

145

148

151

154

157

VTT_DDR

186

189

191

194

197

120

240

236

VTT

VDD

VSS

160

VTT

VDD

VDDSPD

VSS

163

166

199

202

205

208

211

214

217

4

MEM_MA_HOT#

48

187

198

53

167

68

79

RSVD

FREE1

NC/TEST4

NC/PAR_IN

NC/ERR_OUT

DM0/DQS9

NC/DQS9# DM1/DQS10 NC/DQS10# DM2/DQS11 NC/DQS11# DM3/DQS12 NC/DQS12# DM4/DQS13 NC/DQS13# DM5/DQS14 NC/DQS14# DM6/DQS15 NC/DQS15# DM7/DQS16 NC/DQS16# DM8/DQS17 NC/DQS17#

CK1#(NU)

VSS

220

223

226

229

232

235

239

188

A0

181

A1

FREE249FREE3

FREE4

61

A2

180

A3

59

A4

58

A5

178

A6

56

A7

177

A8

175

A9

70

A10/AP

55

A11

174

A12

196

A13

172

A14

171

A15

39

CB0

40

CB1

45

CB2

46

CB3

158

CB4

159

CB5

164

CB6

165

CB7

7

DQS0

6

DQS0#

16

DQS1

15

DQS1#

25

DQS2

24

DQS2#

34

DQS3

33

DQS3#

85

DQS4

84

DQS4#

94

DQS5

93

DQS5#

103

DQS6

102

DQS6#

112

DQS7

111

DQS7#

43

DQS8

42

DQS8#

125 126 134 135 143 144 152 153 203 204 212 213 221 222 230 231 161 162

195

ODT0

77

ODT1

50

CKE0

169

CKE1

193

CS0#

76

CS1#

71

BA0

190

BA1

52

BA2

73

WE#

192

RAS#

74

CAS#

168

RESET#

184

CK0

185

CK0#

63

CK1(NU)

64 1

VREFDQ

67

VREFCA

118

SCL

238

SDA

237

SA1

117

SA0

VSS

MEC1

MEC2

MEC3

DDRIII-240P_GREEN-RH-6

MEC1

MEC2

MEC3

MEM_MA_ADD0 MEM_MA_ADD1 MEM_MA_ADD2 MEM_MA_ADD3 MEM_MA_ADD4 MEM_MA_ADD5 MEM_MA_ADD6 MEM_MA_ADD7 MEM_MA_ADD8 MEM_MA_ADD9 MEM_MA_ADD10 MEM_MA_ADD11 MEM_MA_ADD12 MEM_MA_ADD13 MEM_MA_ADD14 MEM_MA_ADD15

MEM_MA_DQS_H0 MEM_MA_DQS_L0 MEM_MA_DQS_H1 MEM_MA_DQS_L1 MEM_MA_DQS_H2 MEM_MA_DQS_L2 MEM_MA_DQS_H3 MEM_MA_DQS_L3 MEM_MA_DQS_H4 MEM_MA_DQS_L4 MEM_MA_DQS_H5 MEM_MA_DQS_L5 MEM_MA_DQS_H6 MEM_MA_DQS_L6 MEM_MA_DQS_H7 MEM_MA_DQS_L7

MEM_MA_DM0 MEM_MA_DM1 MEM_MA_DM2 MEM_MA_DM3 MEM_MA_DM4 MEM_MA_DM5 MEM_MA_DM6 MEM_MA_DM7

MEM_MA0_ODT0 MEM_MA0_ODT1 MEM_MA_CKE0 MEM_MA_CKE1 MEM_MA0_CS_L0 MEM_MA0_CS_L1 MEM_MA_BANK0 MEM_MA_BANK1 MEM_MA_BANK2

MEM_MA_WE_L MEM_MA_RAS_L MEM_MA_CAS_L MEM_MA_RESET#

MEM_MA_CLK_H1 MEM_MA_CLK_L1 MEM_MA_CLK_H2 MEM_MA_CLK_L2

MEM_VREF_DQ_A MEM_VREF_CA MEM_SCLK MEM_SDATA

MEM_MA_HOT# 9

MEM_MA_ADD[15..0] 9

MEM_MA_DM[7..0] 9

MEM_MA0_ODT0 9 MEM_MA0_ODT1 9 MEM_MA_CKE0 9 MEM_MA_CKE1 9 MEM_MA0_CS_L0 9 MEM_MA0_CS_L1 9 MEM_MA_BANK0 9 MEM_MA_BANK1 9 MEM_MA_BANK2 9

MEM_MA_WE_L 9 MEM_MA_RAS_L 9 MEM_MA_CAS_L 9 MEM_MA_RESET# 9

MEM_MA_CLK_H1 9 MEM_MA_CLK_L1 9 MEM_MA_CLK_H2 9 MEM_MA_CLK_L2 9

MEM_VREF_CA

C228

C228 C0.1u25X

C0.1u25X

3

VCC_DDR VCC3

54

DIMM3

MEM_MA_DATA0 MEM_MA_DATA1 MEM_MA_DATA2 MEM_MA_DATA3 MEM_MA_DATA4 MEM_MA_DATA5 MEM_MA_DATA6 MEM_MA_DATA7 MEM_MA_DATA8 MEM_MA_DATA9 MEM_MA_DATA10 MEM_MA_DATA11 MEM_MA_DATA12 MEM_MA_DATA13 MEM_MA_DATA14 MEM_MA_DATA15 MEM_MA_DATA16 MEM_MA_DATA17 MEM_MA_DATA18 MEM_MA_DATA19 MEM_MA_DATA20 MEM_MA_DATA21 MEM_MA_DATA22 MEM_MA_DATA23 MEM_MA_DATA24 MEM_MA_DATA25 MEM_MA_DATA26 MEM_MA_DATA27 MEM_MA_DATA28 MEM_MA_DATA29 MEM_MA_DATA30 MEM_MA_DATA31 MEM_MA_DATA32 MEM_MA_DATA33 MEM_MA_DATA34 MEM_MA_DATA35 MEM_MA_DATA36 MEM_MA_DATA37 MEM_MA_DATA38 MEM_MA_DATA39 MEM_MA_DATA40 MEM_MA_DATA41 MEM_MA_DATA42 MEM_MA_DATA43 MEM_MA_DATA44 MEM_MA_DATA45 MEM_MA_DATA46 MEM_MA_DATA47 MEM_MA_DATA48 MEM_MA_DATA49 MEM_MA_DATA50 MEM_MA_DATA51 MEM_MA_DATA52 MEM_MA_DATA53 MEM_MA_DATA54 MEM_MA_DATA55 MEM_MA_DATA56 MEM_MA_DATA57 MEM_MA_DATA58 MEM_MA_DATA59 MEM_MA_DATA60 MEM_MA_DATA61 MEM_MA_DATA62 MEM_MA_DATA63

MEM_VREF_DQ_A MEM_VREF_DQ_A

C229

C1000p50X0402

C229

C1000p50X0402

DIMM3

3

DQ0

VDD51VDD

4

DQ1

9

DQ2

10

DQ3

122

DQ4

123

DQ5

128

DQ6

129

DQ7

12

DQ8

13

DQ9

18

DQ10

19

DQ11

131

DQ12

132

DQ13

137

DQ14

138

DQ15

21

DQ16

22

DQ17

27

DQ18

28

DQ19

140

DQ20

141

DQ21

146

DQ22

147

DQ23

30

DQ24

31

DQ25

36

DQ26

37

DQ27

149

DQ28

150

DQ29

155

DQ30

156

DQ31

81

DQ32

82

DQ33

87

DQ34

88

DQ35

200

DQ36

201

DQ37

206

DQ38

207

DQ39

90

DQ40

91

DQ41

96

DQ42

97

DQ43

209

DQ44

210

DQ45

215

DQ46

216

DQ47

99

DQ48

100

DQ49

105

DQ50

106

DQ51

218

DQ52

219

DQ53

224

DQ54

225

DQ55

108

DQ56

109

DQ57

114

DQ58

115

DQ59

227

DQ60

228

DQ61

233

DQ62

234

DQ63

2

VSS

5

VSS

8

VSS

11

VSS

14

VSS

17

VSS

20

VSS

23

VSS

26

VSS

29

VSS

32

VSS

35

VSS

38

VSS

41

VSS

44

VSS

47

VSS

80

VSS

83

VSS

86

VSS

89

VSS

92

VSS

95

VSS

98

VSS

101

VSS

104

VSS

107

110

113

116

170

VDD57VDD60VDD62VDD65VDD66VDD69VDD72VDD75VDD78VDD

VSS

119

121

124

127

130

133

136

139

142

DIMM3(CHANNEL-A A1) SM ADDRESS=A4

173

176

179

182

183

VDD

DDR3

VSS

145

148

151

154

157

2

VTT_DDR

186

189

191

194

197

53

68

120

240

236

VTT

VDD

VSS

160

VTT

VDD

VDDSPD

NC/PAR_IN

NC/ERR_OUT

VSS

163

166

199

VSS

202

205

208

211

214

217

220

223

226

167

79

RSVD

NC/TEST4

VSS

229

232

48

187

FREE1

FREE249FREE3

DM0/DQS9

NC/DQS9# DM1/DQS10 NC/DQS10# DM2/DQS11 NC/DQS11# DM3/DQS12 NC/DQS12# DM4/DQS13 NC/DQS13# DM5/DQS14 NC/DQS14# DM6/DQS15 NC/DQS15# DM7/DQS16 NC/DQS16# DM8/DQS17 NC/DQS17#

RESET#

CK1(NU)

CK1#(NU)

VREFDQ VREFCA

VSS

235

239

MEC1

198

A10/AP

DQS0

DQS0#

DQS1

DQS1#

DQS2

DQS2#

DQS3

DQS3#

DQS4

DQS4#

DQS5

DQS5#

DQS6

DQS6#

DQS7

DQS7#

DQS8

DQS8#

ODT0 ODT1 CKE0 CKE1

RAS# CAS#

MEC1

MEC2

MEM_MA_HOT#

MEM_MA_ADD0

188

A0

MEM_MA_ADD1

181

A1

FREE4

MEM_MA_ADD2

61

A2

MEM_MA_ADD3

180

A3

MEM_MA_ADD4

59

A4

MEM_MA_ADD5

58

A5

MEM_MA_ADD6

178

A6

MEM_MA_ADD7

56

A7

MEM_MA_ADD8

177

A8

MEM_MA_ADD9

175

A9

MEM_MA_ADD10

70

MEM_MA_ADD11

55

A11

MEM_MA_ADD12

174

A12

MEM_MA_ADD13

196

A13

MEM_MA_ADD14

172

A14

MEM_MA_ADD15

171

A15

39

CB0

40

CB1

45

CB2

46

CB3

158

CB4

159

CB5

164

CB6

165

CB7

MEM_MA_DQS_H0

7

MEM_MA_DQS_L0

6

MEM_MA_DQS_H1

16

MEM_MA_DQS_L1

15

MEM_MA_DQS_H2

25

MEM_MA_DQS_L2

24

MEM_MA_DQS_H3

34

MEM_MA_DQS_L3

33

MEM_MA_DQS_H4

85

MEM_MA_DQS_L4

84

MEM_MA_DQS_H5

94

MEM_MA_DQS_L5

93

MEM_MA_DQS_H6

103

MEM_MA_DQS_L6

102

MEM_MA_DQS_H7

112

MEM_MA_DQS_L7

111 43 42

MEM_MA_DM0

125 126

MEM_MA_DM1

134 135

MEM_MA_DM2

143 144

MEM_MA_DM3

152 153

MEM_MA_DM4

203 204

MEM_MA_DM5

212 213

MEM_MA_DM6

221 222

MEM_MA_DM7

230 231 161 162

195 77 50 169 193

CS0#

76

CS1#

71

BA0

190

BA1

52

BA2

MEM_MA_WE_L

73

WE#

MEM_MA_RAS_L

192

MEM_MA_CAS_L

74

MEM_MA_RESET#

168

MEM_MA_CLK_H0

184

CK0

MEM_MA_CLK_L0

185

CK0#

MEM_MA_CLK_H3

63

MEM_MA_CLK_L3

64

MEM_VREF_DQ_A

1

MEM_VREF_CA

67

MEM_SCLK

118

SCL

MEM_SDATA

238

SDA

237

SA1

117

SA0

MEC2

MEC3

DDRIII-240P_BLUE-RH-13

MEC3

MEM_MA1_ODT0 MEM_MA1_ODT1 MEM_MA_CKE0 MEM_MA_CKE1 MEM_MA1_CS_L0 MEM_MA1_CS_L1 MEM_MA_BANK0 MEM_MA_BANK1 MEM_MA_BANK2

VCC3

MEM_MA1_ODT0 9 MEM_MA1_ODT1 9 MEM_MA_CKE0 9 MEM_MA_CKE1 9 MEM_MA1_CS_L0 9 MEM_MA1_CS_L1 9 MEM_MA_BANK0 9 MEM_MA_BANK1 9 MEM_MA_BANK2 9

MEM_MA_WE_L 9 MEM_MA_RAS_L 9 MEM_MA_CAS_L 9

MEM_MA_CLK_H0 9 MEM_MA_CLK_L0 9 MEM_MA_CLK_H3 9 MEM_MA_CLK_L3 9

MEM_VREF_CA

1

C231

C1000p50X0402

C231

C1000p50X0402

C230

C230 C0.1u25X

C0.1u25X

MEM_SCLK13 MEM_SDATA13

A A

Vref-DQ : Reference voltage for DQ0–DQ63, CB0–CB7 and PAR_IN. When in single ended mode used for DQS0–DQS7. Vref-CA : Reference voltage for A0-A15, BA0–BA2, RAS#, CAS#, WE#, S0#, S01#, CKE0, CKE1, ODT0 and ODT1.

RESET#(Output) : A synchronously forces all registered output LOW when RESET# is LOW. This signal can be used during power up to ensure that CKE is LOW and DQs are High-Z.

5

4

MEM_SCLK MEM_SDATA

R196 15R0402R196 15R0402 R197 15R0402R197 15R0402

SCLK0 16 SDATA0 16

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Custom

Date: Sheet

3

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

DDR CH-A

Kaveri-VC 0A

1

12 40Tuesday, June 18, 2013

of

5

4

3

2

1

VCC_DDR VCC3

MEM_MB_DQS_H[7..0]9 MEM_MB_DQS_L[7..0]9

MEM_MB_DATA[63..0]9 MEM_MB_ADD[15..0] 9

D D

C C

B B

MEM_MB_DATA0 MEM_MB_DATA1 MEM_MB_DATA2 MEM_MB_DATA3 MEM_MB_DATA4 MEM_MB_DATA5 MEM_MB_DATA6 MEM_MB_DATA7 MEM_MB_DATA8 MEM_MB_DATA9 MEM_MB_DATA10 MEM_MB_DATA11 MEM_MB_DATA12 MEM_MB_DATA13 MEM_MB_DATA14 MEM_MB_DATA15 MEM_MB_DATA16 MEM_MB_DATA17 MEM_MB_DATA18 MEM_MB_DATA19 MEM_MB_DATA20 MEM_MB_DATA21 MEM_MB_DATA22 MEM_MB_DATA23 MEM_MB_DATA24 MEM_MB_DATA25 MEM_MB_DATA26 MEM_MB_DATA27 MEM_MB_DATA28 MEM_MB_DATA29 MEM_MB_DATA30 MEM_MB_DATA31 MEM_MB_DATA32 MEM_MB_DATA33 MEM_MB_DATA34 MEM_MB_DATA35 MEM_MB_DATA36 MEM_MB_DATA37 MEM_MB_DATA38 MEM_MB_DATA39 MEM_MB_DATA40 MEM_MB_DATA41 MEM_MB_DATA42 MEM_MB_DATA43 MEM_MB_DATA44 MEM_MB_DATA45 MEM_MB_DATA46 MEM_MB_DATA47 MEM_MB_DATA48 MEM_MB_DATA49 MEM_MB_DATA50 MEM_MB_DATA51 MEM_MB_DATA52 MEM_MB_DATA53 MEM_MB_DATA54 MEM_MB_DATA55 MEM_MB_DATA56 MEM_MB_DATA57 MEM_MB_DATA58 MEM_MB_DATA59 MEM_MB_DATA60 MEM_MB_DATA61 MEM_MB_DATA62 MEM_MB_DATA63

122 123 128 129

131 132 137 138

140 141 146 147

149 150 155 156

200 201 206 207

209 210 215 216

100 105 106 218 219 224 225 108 109 114 115 227 228 233 234

101 104

3 4 9

10

12 13 18 19

21 22 27 28

30 31 36 37

81 82 87 88

90 91 96 97

99

2 5

8 11 14 17 20 23 26 29 32 35 38 41 44 47 80 83 86 89 92 95 98

DIMM2

DQ0 DQ1 DQ2 DQ3 DQ4 DQ5 DQ6 DQ7 DQ8 DQ9 DQ10 DQ11 DQ12 DQ13 DQ14 DQ15 DQ16 DQ17 DQ18 DQ19 DQ20 DQ21 DQ22 DQ23 DQ24 DQ25 DQ26 DQ27 DQ28 DQ29 DQ30 DQ31 DQ32 DQ33 DQ34 DQ35 DQ36 DQ37 DQ38 DQ39 DQ40 DQ41 DQ42 DQ43 DQ44 DQ45 DQ46 DQ47 DQ48 DQ49 DQ50 DQ51 DQ52 DQ53 DQ54 DQ55 DQ56 DQ57 DQ58 DQ59 DQ60 DQ61 DQ62 DQ63

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

54

VDD51VDD

VDD57VDD60VDD62VDD65VDD66VDD69VDD72VDD75VDD78VDD

VSS

107

110

113

116

119

121

170

VSS

124

127

130

133

136

139

142

DIMM2(CHANNEL-B B0) SM ADDRESS=A2

173

176

179

182

VDD

DDR3

VSS

145

148

151

154

VTT_DDR

183

186

189

191

194

197

236

VDD

VDDSPD

VSS

157

160

163

166

199

202

205

208

48

53

167

68

120

240

79

VTT

RSVD

FREE1

FREE249FREE3

NC/TEST4

NC/PAR_IN

NC/ERR_OUT

DM0/DQS9

NC/DQS9# DM1/DQS10 NC/DQS10# DM2/DQS11 NC/DQS11# DM3/DQS12 NC/DQS12# DM4/DQS13 NC/DQS13# DM5/DQS14 NC/DQS14# DM6/DQS15 NC/DQS15# DM7/DQS16 NC/DQS16# DM8/DQS17 NC/DQS17#

CK1#(NU)

VSS

211

VSS

214

217

220

223

226

229

232

235

239

187

198

188

A0

181

A1

FREE4

61

A2

180

A3

59

A4

58

A5

178

A6

56

A7

177

A8

175

A9

70

A10/AP

55

A11

174

A12

196

A13

172

A14

171

A15

39

CB0

40

CB1

45

CB2

46

CB3

158

CB4

159

CB5

164

CB6

165

CB7

7

DQS0

6

DQS0#

16

DQS1

15

DQS1#

25

DQS2

24

DQS2#

34

DQS3

33

DQS3#

85

DQS4

84

DQS4#

94

DQS5

93

DQS5#

103

DQS6

102

DQS6#

112

DQS7

111

DQS7#

43

DQS8

42

DQS8#

125 126 134 135 143 144 152 153 203 204 212 213 221 222 230 231 161 162

195

ODT0

77

ODT1

50

CKE0

169

CKE1

193

CS0#

76

CS1#

71

BA0

190

BA1

52

BA2

73

WE#

192

RAS#

74

CAS#

168

RESET#

184

CK0

185

CK0#

63

CK1(NU)

64 1

VREFDQ

67

VREFCA

118

SCL

238

SDA

237

SA1

117

SA0

MEC1

MEC2

MEC3

DDRIII-240P_GREEN-RH-6

MEC1

MEC2

MEC3

MEM_MB_HOT#

MEM_MB_ADD0 MEM_MB_ADD1 MEM_MB_ADD2 MEM_MB_ADD3 MEM_MB_ADD4 MEM_MB_ADD5 MEM_MB_ADD6 MEM_MB_ADD7 MEM_MB_ADD8 MEM_MB_ADD9 MEM_MB_ADD10 MEM_MB_ADD11 MEM_MB_ADD12 MEM_MB_ADD13 MEM_MB_ADD14 MEM_MB_ADD15

MEM_MB_DQS_H0 MEM_MB_DQS_L0 MEM_MB_DQS_H1 MEM_MB_DQS_L1 MEM_MB_DQS_H2 MEM_MB_DQS_L2 MEM_MB_DQS_H3 MEM_MB_DQS_L3 MEM_MB_DQS_H4 MEM_MB_DQS_L4 MEM_MB_DQS_H5 MEM_MB_DQS_L5 MEM_MB_DQS_H6 MEM_MB_DQS_L6 MEM_MB_DQS_H7 MEM_MB_DQS_L7

MEM_MB_DM0 MEM_MB_DM1 MEM_MB_DM2 MEM_MB_DM3 MEM_MB_DM4 MEM_MB_DM5 MEM_MB_DM6 MEM_MB_DM7

MEM_MB0_ODT0 MEM_MB0_ODT1 MEM_MB_CKE0 MEM_MB_CKE1 MEM_MB0_CS_L0 MEM_MB0_CS_L1 MEM_MB_BANK0 MEM_MB_BANK1 MEM_MB_BANK2

MEM_MB_WE_L MEM_MB_RAS_L MEM_MB_CAS_L MEM_MB_RESET#

MEM_MB_CLK_H1 MEM_MB_CLK_L1 MEM_MB_CLK_H2 MEM_MB_CLK_L2

MEM_VREF_DQ_B MEM_VREF_CA MEM_SCLK MEM_SDATA

MEM_MB_HOT# 9

MEM_MB_DATA0 MEM_MB_DATA1 MEM_MB_DATA2 MEM_MB_DATA3 MEM_MB_DATA4 MEM_MB_DATA5 MEM_MB_DATA6 MEM_MB_DATA7 MEM_MB_DATA8 MEM_MB_DATA9 MEM_MB_DATA10 MEM_MB_DATA11 MEM_MB_DATA12 MEM_MB_DATA13 MEM_MB_DATA14 MEM_MB_DATA15 MEM_MB_DATA16 MEM_MB_DATA17 MEM_MB_DATA18 MEM_MB_DATA19 MEM_MB_DATA20 MEM_MB_DATA21 MEM_MB_DATA22 MEM_MB_DATA23 MEM_MB_DATA24 MEM_MB_DATA25 MEM_MB_DATA26 MEM_MB_DATA27 MEM_MB_DATA28 MEM_MB_DATA29 MEM_MB_DATA30 MEM_MB_DATA31 MEM_MB_DATA32 MEM_MB_DATA33 MEM_MB_DATA34 MEM_MB_DATA35 MEM_MB_DATA36 MEM_MB_DATA37 MEM_MB_DATA38 MEM_MB_DATA39 MEM_MB_DATA40 MEM_MB_DATA41 MEM_MB_DATA42 MEM_MB_DATA43

MEM_MB_DM[7..0] 9

MEM_MB0_ODT0 9 MEM_MB0_ODT1 9 MEM_MB_CKE0 9 MEM_MB_CKE1 9 MEM_MB0_CS_L0 9 MEM_MB0_CS_L1 9 MEM_MB_BANK0 9 MEM_MB_BANK1 9 MEM_MB_BANK2 9

MEM_MB_WE_L 9 MEM_MB_RAS_L 9 MEM_MB_CAS_L 9 MEM_MB_RESET# 9

MEM_MB_CLK_H1 9 MEM_MB_CLK_L1 9 MEM_MB_CLK_H2 9 MEM_MB_CLK_L2 9

MEM_VREF_CA

MEM_SCLK 12 MEM_SDATA 12

VCC3 VCC3

MEM_VREF_DQ_B

C224

C224 C0.1u16X

C0.1u16X

C225

C1000p50X0402

C225

C1000p50X0402

MEM_MB_DATA44 MEM_MB_DATA45 MEM_MB_DATA46 MEM_MB_DATA47 MEM_MB_DATA48 MEM_MB_DATA49 MEM_MB_DATA50 MEM_MB_DATA51 MEM_MB_DATA52 MEM_MB_DATA53 MEM_MB_DATA54 MEM_MB_DATA55 MEM_MB_DATA56 MEM_MB_DATA57 MEM_MB_DATA58 MEM_MB_DATA59 MEM_MB_DATA60 MEM_MB_DATA61 MEM_MB_DATA62 MEM_MB_DATA63

VCC_DDR VCC3

54

DIMM1

3

DQ0

VDD51VDD

VDD57VDD60VDD62VDD65VDD66VDD69VDD72VDD75VDD78VDD

4

DQ1

9

DQ2

10

DQ3

122

DQ4

123

DQ5

128

DQ6

129

DQ7

12

DQ8

13

DQ9

18

DQ10

19

DQ11

131

DQ12

132

DQ13

137

DQ14

138

DQ15

21

DQ16

22

DQ17

27

DQ18

28

DQ19

140

DQ20

141

DQ21

146

DQ22

147

DQ23

30

DQ24

31

DQ25

36

DQ26

37

DQ27

149

DQ28

150

DQ29

155

DQ30

156

DQ31

81

DQ32

82

DQ33

87

DQ34

88

DQ35

200

DQ36

201

DQ37

206

DQ38

207

DQ39

90

DQ40

91

DQ41

96

DQ42

97

DQ43

209

DQ44

210

DQ45

215

DQ46

216

DQ47

99

DQ48

100

DQ49

105

DQ50

106

DQ51

218

DQ52

219

DQ53

224

DQ54

225

DQ55

108

DQ56

109

DQ57

114

DQ58

115

DQ59

227

DQ60

228

DQ61

233

DQ62

234

DQ63

2

VSS

5

VSS

8

VSS

11

VSS

14

VSS

17

VSS

20

VSS

23

VSS

26

VSS

29

VSS

32

VSS

35

VSS

38

VSS

41

VSS

44

VSS

47

VSS

80

VSS

83

VSS

86

VSS

89

VSS

92

VSS

95

VSS

98

VSS

101

VSS

104

VSS

107

110

VSS

113

116

119

121

124

127

130

133

136

139

170

173

176

179

182

VDD

DDR3

VSS

142

145

148

151

154

DIMM1(CHANNEL-B B1) SM ADDRESS=A6

VTT_DDR

183

186

189

191

194

197

236

VDD

VSS

157

160

163

166

199

202

205

208

120

VDDSPD

VSS

211

214

48

53

167

68

240

79

VTT

RSVD

FREE1

FREE249FREE3

NC/TEST4

NC/PAR_IN

NC/ERR_OUT

DM0/DQS9

NC/DQS9# DM1/DQS10 NC/DQS10# DM2/DQS11 NC/DQS11# DM3/DQS12 NC/DQS12# DM4/DQS13 NC/DQS13# DM5/DQS14 NC/DQS14# DM6/DQS15 NC/DQS15# DM7/DQS16 NC/DQS16# DM8/DQS17 NC/DQS17#

CK1#(NU)

VSS

217

220

223

226

229

232

235

239

187

198

A0 A1

FREE4

A2 A3 A4 A5 A6 A7 A8 A9

A10/AP

A11 A12 A13 A14 A15

CB0 CB1 CB2 CB3 CB4 CB5 CB6 CB7

DQS0

DQS0#

DQS1

DQS1#

DQS2

DQS2#

DQS3

DQS3#

DQS4

DQS4#

DQS5

DQS5#

DQS6

DQS6#

DQS7

DQS7#

DQS8

DQS8#

ODT0 ODT1 CKE0 CKE1

CS0# CS1#

BA0 BA1 BA2

WE# RAS# CAS#

RESET#

CK0

CK0#

CK1(NU)

VREFDQ VREFCA

SCL SDA SA1 SA0

MEC1

MEC2

MEC3

DDRIII-240P_BLUE-RH-13

MEC1

MEC2

MEC3

188 181 61 180 59 58 178 56 177 175 70 55 174 196 172 171

39 40 45 46 158 159 164 165

7 6 16 15 25 24 34 33 85 84 94 93 103 102 112 111 43 42

125 126 134 135 143 144 152 153 203 204 212 213 221 222 230 231 161 162

195 77 50 169 193 76 71 190 52

73 192 74 168

184 185 63 64

1 67 118 238 237 117

MEM_MB_HOT#

MEM_MB_ADD0 MEM_MB_ADD1 MEM_MB_ADD2 MEM_MB_ADD3 MEM_MB_ADD4 MEM_MB_ADD5 MEM_MB_ADD6 MEM_MB_ADD7 MEM_MB_ADD8 MEM_MB_ADD9 MEM_MB_ADD10 MEM_MB_ADD11 MEM_MB_ADD12 MEM_MB_ADD13 MEM_MB_ADD14 MEM_MB_ADD15

MEM_MB_DQS_H0 MEM_MB_DQS_L0 MEM_MB_DQS_H1 MEM_MB_DQS_L1 MEM_MB_DQS_H2 MEM_MB_DQS_L2 MEM_MB_DQS_H3 MEM_MB_DQS_L3 MEM_MB_DQS_H4 MEM_MB_DQS_L4 MEM_MB_DQS_H5 MEM_MB_DQS_L5 MEM_MB_DQS_H6 MEM_MB_DQS_L6 MEM_MB_DQS_H7 MEM_MB_DQS_L7

MEM_MB_DM0 MEM_MB_DM1 MEM_MB_DM2 MEM_MB_DM3 MEM_MB_DM4 MEM_MB_DM5 MEM_MB_DM6 MEM_MB_DM7

MEM_MB1_ODT0 MEM_MB1_ODT1 MEM_MB_CKE0 MEM_MB_CKE1 MEM_MB1_CS_L0 MEM_MB1_CS_L1 MEM_MB_BANK0 MEM_MB_BANK1 MEM_MB_BANK2

MEM_MB_WE_L MEM_MB_RAS_L MEM_MB_CAS_L MEM_MB_RESET#

MEM_MB_CLK_H0 MEM_MB_CLK_L0 MEM_MB_CLK_H3 MEM_MB_CLK_L3

MEM_VREF_DQ_B MEM_VREF_CA MEM_SCLK MEM_SDATA

MEM_MB1_ODT0 9 MEM_MB1_ODT1 9 MEM_MB_CKE0 9 MEM_MB_CKE1 9 MEM_MB1_CS_L0 9 MEM_MB1_CS_L1 9 MEM_MB_BANK0 9 MEM_MB_BANK1 9 MEM_MB_BANK2 9

MEM_MB_WE_L 9 MEM_MB_RAS_L 9 MEM_MB_CAS_L 9

MEM_MB_CLK_H0 9 MEM_MB_CLK_L0 9 MEM_MB_CLK_H3 9 MEM_MB_CLK_L3 9

MEM_VREF_CA

MEM_VREF_DQ_B

C226

C226 C0.1u16X

C0.1u16X

C227

C1000p50X0402

C227

C1000p50X0402

A A

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Custom

Date: Sheet

5

4

3

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

DDR CH-B

Kaveri-VC 0A

1

13 40Tuesday, June 18, 2013

of

A

2

DDR REF POWER & CAPS

B

C

D

E

VCC_DDR

4 4

3 3

VCC_DDR

R198

1KR1%

R199

1KR1%

R200

1KR1%

R201

1KR1%

C247

C0.1u10X0402

C248

C0.1u10X0402

C252

C0.1u10X0402

MEM_VREF_CA

C249

C250

C1000p50X0402

MEM_VREF_DQ

C251

C1000p50X0402

VCC3

C232

C0.1u16X50402-2

C233

C233 C1u10X5-RH

C1u10X5-RH

C234

C234 C1u10X5-RH

C1u10X5-RH

C235

C235 C1u10X5-RH

C1u10X5-RH

De-coupling Caps For DIMMs

C236

C236 C1u10X5-RH

C1u10X5-RH

C237

C237 C1u10X5-RH

C1u10X5-RH

C238

C238 C1u10X5-RH

C1u10X5-RH

C239

C239 C1u10X5-RH

C1u10X5-RH

C240

C240 C1u10X5-RH

C1u10X5-RH

C242

X_C0.1u16X50402-2

VTT_DDR

C243

X_C4.7u6.3X50805

C244

C245

C245 C1u10X5-RH

C1u10X5-RH

X_C4.7u6.3X50805

C246

C246 C1u10X5-RH

C1u10X5-RH

VCC_DDRVCC_DDR

C241

C0.1u16X50402-2

2D writing training switcher

2 2

ATX_5VSB

R202

R202 10KR0402

10KR0402

Q36

G

ATX_5VSB

R203

R203 10KR0402

10KR0402

Q37

D

G

VOLT_SELECT

1,36,37

1 1

N-2N7002

A

G

S

2D_W_T#

N-2N7002

G

MEM_VREF_DQ_A

2D_W_T

D

S

MEM_VREF_DQ

Q35

Q35 NN-2N7002DW-7-F_SOT363-6-RH

NN-2N7002DW-7-F_SOT363-6-RH

G2 D1 G1

S1

Q38

Q38 NN-2N7002DW-7-F_SOT363-6-RH

NN-2N7002DW-7-F_SOT363-6-RH

G2 D1 G1

S1

B

D2

S2

D2

APU_MB_VREFDQ

S2

APU_MA_VREFDQ

MEM_VREF_DQ_B

APU_MB_VREFDQ 9

APU_MA_VREFDQ 9

C

MICRO-START INT'L CO.,LTD.

Title

DDR REF POWER & CAPS

Size Document Number Rev

B

Date: Sheet

D

Date: Sheet

MICRO-START INT'L CO.,LTD.

Kaveri-VC 0A

E

of

14 40Tuesday, June 18, 2013

5

4

3

2

1

HUDSON PCIE/PCI/APU/LPC/CLK

U5E

?

C326

C326 C0.1u25X

C0.1u25X

PCI EXPRESS INTERFACES

CLOCK GENERATOR

VBAT

U5E

Part 1 of 5

PCI CLKS

PCI INTERFACE

LPC

APU

S5 PLUS

D3

1N4148W-F_SOD123-RH

C327

C1u10X

PCICLK0 PCICLK1/GPO36 PCICLK2/GPO37 PCICLK3/GPO38

PCICLK4/14M_OSC/GPO39

PCIRST#

AD0/GPIO0 AD1/GPIO1 AD2/GPIO2 AD3/GPIO3 AD4/GPIO4 AD5/GPIO5 AD6/GPIO6 AD7/GPIO7 AD8/GPIO8

AD9/GPIO9 AD10/GPIO10 AD11/GPIO11 AD12/GPIO12 AD13/GPIO13 AD14/GPIO14 AD15/GPIO15 AD16/GPIO16 AD17/GPIO17 AD18/GPIO18 AD19/GPIO19 AD20/GPIO20 AD21/GPIO21 AD22/GPIO22 AD23/GPIO23 AD24/GPIO24 AD25/GPIO25 AD26/GPIO26 AD27/GPIO27 AD28/GPIO28 AD29/GPIO29 AD30/GPIO30 AD31/GPIO31

CBE0# CBE1# CBE2# CBE3#

FRAME#

DEVSEL#

TRDY#

STOP# PERR# SERR# REQ0#

REQ1#/GPIO40 REQ2#/CLK_REQ8#/GPIO41 REQ3#/CLK_REQ5#/GPIO42

GNT0#

GNT1#/GPO44

GNT2#/SD_LED/GPO45

GNT3#/CLK_REQ7#/GPIO46

CLKRUN#

LOCK#

INTE#/GPIO32 INTF#/GPIO33

INTG#/GPIO34

INTH#/GPIO35

LPCCLK0 LPCCLK1

LFRAME#

LDRQ0#

LDRQ1#/CLK_REQ6#/GPIO49

SERIRQ/GPIO48

DMA_ACTIVE#

PROCHOT#

APU_PG

LDT_STP#

APU_RST#

32K_X1

32K_X2

S5_CORE_EN

RTCCLK

INTRUDER_ALERT#

VDDBT_RTC_G

R234 1KR0402R234 1KR0402

IRDY#

PAR

LAD0 LAD1 LAD2 LAD3

AF3 AF1 AF5 AG2 AF6

AB5

AJ3 AL5 AG4 AL6 AH3 AJ5 AL1 AN5 AN6 AJ1 AL8 AL3 AM7 AJ6 AK7 AN8 AG9 AM11 AJ10 AL12 AK11 AN12 AG12 AE12 AC12 AE13 AF13 AH13 AH14 AD15 AC15 AE16 AN3 AJ8 AN10 AD12 AG10 AK9 AL10 AF10 AE10 AH1 AM9 AH8 AG15 AG13 AF15 AM17 AD16 AD13 AD21 AK17 AD19 AH9

AF18 AE18 AC16 AD18

B25

R237 22R0402R237 22R0402

D25 D27 C28 A26 A29 A31 B27 AE27 AE19

G25 E28 E26 G26 F26

G2 G4 H7

F1 F3 E6

BAT1

BAT2P_BLACK-RH

A_RST# for LPC device; PCIE_RST# for APU PCIE device; PCIE_RST#2 FCH PCIE device

FCH_PCIE_RST#_R

D D

FCH_A_RST#_R

R204 33R0402R204 33R0402

R208 33R0402R208 33R0402

To PCIEX16,X1,Mini-PCIE,LAN

C312

C150p25N0402

A_RST#

To SIO,LPC debug

C316

C150p25N0402

PCIE_RST# 23,27

A_RST# 33,34

UMI_RX0P8 UMI_RX0N8 UMI_RX1P8 UMI_RX1N8 UMI_RX2P8 UMI_RX2N8 UMI_RX3P8 UMI_RX3N8

UMI_TX0P8 UMI_TX0N8 UMI_TX1P8 UMI_TX1N8 UMI_TX2P8 UMI_TX2N8 UMI_TX3P8 UMI_TX3N8

FCH_VDD11_RUN

GPP_TXC_0P24 GPP_TXC_0N24 GPP_TXC_1P24 GPP_TXC_1N24

MINI_TXC_P25 MINI_TXC_N25

C C

DISP_CLK10

For external clock generator mode: 100-MHz reference clock for the FCH. Spreadcapable. For internal clock generator mode: Not used. Left unconnected. The function is selected by the pin strap “CLKGEN” (pin LPCCLK1).

B B

C323 X_C10p50N0402C323 X_C10p50N0402

SIO_48M_CLK

DISP_CLK#10

Fusion Mode:100Mhz Non-Fusion Mode:200Mhz

APU_CLK10 APU_CLK#10

PE16_GXF_CLK23 PE16_GXF_CLK#23

PE1_GPP_CLK024 PE1_GPP_CLK0#24

PE1_GPP_CLK124 PE1_GPP_CLK1#24

PE_LAN_CLK27 PE_LAN_CLK#27

PE_MINI_CLK25 PE_MINI_CLK#25

SIO_48M_CLK34

FCH_VDD11_RUN

MACH@bios porting to 48M clock output

C308 C0.1u10X0402C308 C0.1u10X0402 C309 C0.1u10X0402C309 C0.1u10X0402 C310 C0.1u10X0402C310 C0.1u10X0402 C304 C0.1u10X0402C304 C0.1u10X0402 C311 C0.1u10X0402C311 C0.1u10X0402 C313 C0.1u10X0402C313 C0.1u10X0402 C314 C0.1u10X0402C314 C0.1u10X0402 C315 C0.1u10X0402C315 C0.1u10X0402

R209 590R1%0402R209 590R1%0402

Layout: Place within 1 inch

R212 2KR1%0402R212 2KR1%0402

R213 0R0402R213 0R0402 R214 0R0402R214 0R0402

INT

R215 0R0402R215 0R0402 R216 0R0402R216 0R0402

R217 0R0402R217 0R0402 R218 0R0402R218 0R0402

R219 0R0402R219 0R0402 R220 0R0402R220 0R0402

R221 0R0402R221 0R0402 R222 0R0402R222 0R0402

R223 0R0402R223 0R0402 R224 0R0402R224 0R0402

R225 0R0402R225 0R0402 R226 0R0402R226 0R0402

MACH@???DG:Leave NC if not used; CRB reserve 49.9R to GND

R231 22R0402R231 22R0402

C324 C22p50N0402C324 C22p50N0402

Y1

Y1 25MHZ18P_D-4

25MHZ18P_D-4

C325 C22p50N0402C325 C22p50N0402

1 2

Layout:Place x'tal within 1.5 inch of FCH

FCH_25M_X119 FCH_25M_X219

R210 2KR1%0402R210 2KR1%0402

C317 C0.1u10X0402C317 C0.1u10X0402 C318 C0.1u10X0402C318 C0.1u10X0402 C319 C0.1u10X0402C319 C0.1u10X0402 C320 C0.1u10X0402C320 C0.1u10X0402

C321 C0.1u10X0402C321 C0.1u10X0402 C322 C0.1u10X0402C322 C0.1u10X0402

GPP_RX0P24 GPP_RX0N24 GPP_RX1P24 GPP_RX1N24

MINI_RXP25 MINI_RXN25

FCH_DISP_CLKP_R FCH_DISP_CLKN_R

FCH_APU_CLKP_R FCH_APU_CLKN_R

FCH_GFX_CLKP_R FCH_GFX_CLKN_R

FCH_GPP_CLK0P_R FCH_GPP_CLK0N_R

FCH_GPP_CLK1P_R FCH_GPP_CLK1N_R

FCH_GPP_CLK3P_R FCH_GPP_CLK3N_R

FCH_MINI_CLKP_R FCH_MINI_CLKN_R

FCH_48M

R232

R232 1MR

1MR

FCH_25M_X1 FCH_25M_X2

FCH_PCIE_RST#_R FCH_A_RST#_R

UMI_RX0P_FCH UMI_RX0N_FCH UMI_RX1P_FCH UMI_RX1N_FCH UMI_RX2P_FCH UMI_RX2N_FCH UMI_RX3P_FCH UMI_RX3N_FCH

PCIE_CALRP PCIE_CALRN

GPP_TX0P GPP_TX0N GPP_TX1P GPP_TX1N

MINI_TXP MINI_TXN

CLK_CALRN

FCH_25M_X1

FCH_25M_X2

AE30 AE32 AD33 AD31 AD28 AD29 AC30 AC32

AB33 AB31 AB28 AB29

AF29 AF31

AB26 AB27 AA24 AA23

AA27 AA26

AE2 AD5

Y33 Y31 Y28 Y29

V33

V31 W30 W32

W27

V27

V26 W26 W24 W23

F27

G30 G28

R26

T26 H33

H31

T24

T23

J30

K29 H27

H28

J27

K26

F33

F31

E33

E31 M23

M24 M27

M26 N25

N26 R23

R24 N27

R27

J26

C31

C33

Layout:Place x'tal within 1.5 inch of FCH

PCIE_RST# A_RST#

UMI_TX0P UMI_TX0N UMI_TX1P UMI_TX1N UMI_TX2P UMI_TX2N UMI_TX3P UMI_TX3N

UMI_RX0P UMI_RX0N UMI_RX1P UMI_RX1N UMI_RX2P UMI_RX2N UMI_RX3P UMI_RX3N

PCIE_CALRP PCIE_CALRN

GPP_TX0P GPP_TX0N GPP_TX1P GPP_TX1N GPP_TX2P GPP_TX2N GPP_TX3P GPP_TX3N

GPP_RX0P GPP_RX0N GPP_RX1P GPP_RX1N GPP_RX2P GPP_RX2N GPP_RX3P GPP_RX3N

CLK_CALRN

PCIE_RCLKP PCIE_RCLKN

DISP_CLKP DISP_CLKN

DISP2_CLKP DISP2_CLKN

APU_CLKP APU_CLKN

SLT_GFX_CLKP SLT_GFX_CLKN

GPP_CLK0P GPP_CLK0N

GPP_CLK1P GPP_CLK1N

GPP_CLK2P GPP_CLK2N

GPP_CLK3P GPP_CLK3N

GPP_CLK4P GPP_CLK4N

GPP_CLK5P GPP_CLK5N

GPP_CLK6P GPP_CLK6N

GPP_CLK7P GPP_CLK7N

GPP_CLK8P GPP_CLK8N

14M_25M_48M_OSC

25M_X1

25M_X2

VBAT

HUDSON-2

FCH_32K_X1

Y2

32.768KHZ12.5P_D-1

A A

FCH_32K_X2

12

4

3

R236 20MRR236 20MR

C329

C328

C18p50N

mach@CRB use 22pF

5

C18p50N

PLACE THESE COMPONENTS CLOSE TO U600, AND USE GROUND GUARD FOR 32K_X1 AND 32K_X2

C329

C18p50N

4

3

Layout: Place close to FCH

PCI_CLK_SIO_R PCI_CLK_SIO

R235 22R0402R235 22R0402

PCI_CLK2_R PCI_CLK4_R PCIRST#

AD0 AD1 AD2 AD3 AD4 AD5 AD6 AD7 AD8 AD9 AD10 AD11 AD12 AD13 AD14 AD15 AD16 AD17 AD18 AD19 AD20 AD21 AD22 AD23 AD24 AD25 AD26 AD27 AD28 AD29 AD30 AD31 C_BE#0 C_BE#1 C_BE#2 C_BE#3 FRAME# DEVSEL# IRDY# TRDY# PAR STOP# PERR# SERR# PREQ0# MINI_CLKREQ#

PREQ3# PGNT0#

PGNT#3 CLKRUN# LOCK#

PCI_INTE# PCI_INTF# PCI_INTG# PCI_INTH#

LPC_CLK0 LPC_AD0

LPC_AD1 LPC_AD2 LPC_AD3 LPC_FRAME#

SERIRQ

APU_PG_R LDTSTOP_L_R APU_RST#_R

FCH_32K_X1 FCH_32K_X2 S5_CORE_EN

RTC_CLK

VBAT

R206 22R0402R206 22R0402

R207 22R0402R207 22R0402

FRAME# 26 DEVSEL# 26 IRDY# 26 TRDY# 26 PAR 26 STOP# 26 PERR# 26 SERR# 26

PREQ0# 26

MINI_CLKREQ# 25

TP58TP58

PGNT0# 26

TP64TP64 TP63TP63

CLKRUN# 33

LOCK# 26

PCI_INTE# 26 PCI_INTF# 26 PCI_INTG# 26 PCI_INTH# 26

LPC_CLK0 19

TPM_CLK 19,33 LPC_AD[3..0] 33,34

R228 0R0402R228 0R0402 R229 X_0R0402R229 X_0R0402 R230 0R0402R230 0R0402

TP31TP31

PCIRST# 26

PREQ3# 19

PGNT#3 19

RTC_CLK 19

2

PCI_CLK_DEBUG

AD[31..0] 26

C_BE#[3..0] 26

LPC_AD[3..0]

LPC_FRAME# 33,34

SERIRQ 33,34

FCH_DMA_ACTIVE# 10 APU_PROCHOT# 10

APU_PWRGD 7,10 LDTSTOP_L 10 APU_RST# 10

PCI_CLK_SIO 34 PCI_CLK1 19 PCI_CLK_DEBUG 34 PCI_CLK3 19 PCI_CLK4 19,26

PCI_CLK_SIO PCI_CLK_DEBUG PCI_CLK4

C305 X_C10p50N0402C305 X_C10p50N0402 C306 X_C10p50N0402C306 X_C10p50N0402 C307 X_C10p50N0402C307 X_C10p50N0402

VCC3

SERIRQ

R227 X_10KR0402R227 X_10KR0402

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

C

Date: Sheet

MICRO-START INT'L CO.,LTD.

HUDSON PCIE/PCI/APU/LPC/CLK

Kaveri-VC 0A

1

15 40Tuesday, June 18, 2013

of

5

HUDSON ACPI/USB/AZ/GPIO

4

3

2

1

FCH_RST2#_R

VCC3_SB

D D

C C

R242 10KR0402R242 10KR0402

Layout:Place close to FCH ASAP

FCH_PWRGD

VCC3

mach@DG???PU to VCC3 rail and leave unconnected

R243 300R0402R243 300R0402

VCC3_SB

R245 X_22KR0402R245 X_22KR0402

VCC3

R251 2.2KR0402R251 2.2KR0402 R252 2.2KR0402R252 2.2KR0402

VCC3_SB

R253 2.2KR0402R253 2.2KR0402 R254 2.2KR0402R254 2.2KR0402

+3VAUX_WLAN

R255 10KR0402R255 10KR0402

VCC3_SB

R627 10KR0402R627 10KR0402

AZ_SDOUT28 AZ_BIT_CLK28

AZ_SYNC28 AZ_RST#28

AZ_SDIN

B B

A A

FCH_WAKE#

C331 X_C1000p50X0402C331 X_C1000p50X0402

WD_PWRGD

FCH_RSMRST#

C330

C330 C1000p50X0402

C1000p50X0402

SCLK0 SDATA0

SCLK1 SDATA1

MINI_PWRON

OC#7

Layout: Place close to FCH

R259 33R0402R259 33R0402 R260 33R0402R260 33R0402 R261 33R0402R261 33R0402 R262 33R0402R262 33R0402

C338 C15p50N0402-HF-1C338 C15p50N0402-HF-1

5

SLP_S3#30,34,36,37 SLP_S5#31,34,36,37

PSOUT#34

FCH_PWRGD34,37

A20GATE34

KBRST#34

Inte-grated PU

Rise time ≤ 50-ms +3.3V_S5 voltage rails ramp up at least 10-ms before RSMRST# is deasserted

VCC3

R256 10KR0402R256 10KR0402

RSRMT# should be asserted when system power is being applied for the first time. RSMRST# should be deasserted sometime after S5 power is up, and should stay deasserted until system power is removed.

S0 POWER DOMAIN

ROUTE TO DIMMs,SIO

S5 POWER DOMAIN

ROUTE TO LAN,PCIE,Mini_PCIE

FCH_IDLEEXIT_L

PCI_PME#26

0R0402

SIO_GP41_SMI#34

0R0402

FP_RST#37,38

PE_WAKE#23,24,25,27,34

FCH_THERMTRIP#10

IO_RSMRST#34

SPKR38 SCLK012 SDATA012 SCLK123,24,25,26,27 SDATA123,24,25,26,27

MINI_PWRON25

SPI_HOLD#_R17

FCH_IDLEEXIT_L10

USB Overcurrent Implemented: Connect to overcurrent signal from USB connector (note that these are programmable and can be flexibly assigned as needed). Configure for a

3.3-V swing (i.e. not 5-V) and use low-pass filter to prevent glitches during plug/unplug events. If USB ports are not powered in S4/S5 states and the FCH’s internal pullups are enabled, provide a diode between the FCH and overcurrent circuit (cathode towards the FCH) to prevent leakage from the FCH internal pullups in S4/S5 states.

AZ_SDATA_OUT_R AZ_BITCLK_R AZ_SYNC_R AZ_RST_R

Inte-grated PU

AZ_SDIN28

4

mach@verify the ports being used

OC#631 OC#530,31 OC#430,31 OC#319,30,31 OC#219,31 OC#119,31 OC#019,31

FOR GPIO[226:209] KBC Not Implemented: Use for alternate available function or leave not connected.

R205 33R0402R205 33R0402

SLP_S3#

R247 15R0402R247 15R0402

SLP_S5#

R248 15R0402R248 15R0402

FCH_TEST019 FCH_TEST119 FCH_TEST219

PCI_PME# LPC_SMI#

R249

R244 X_0R0402R244 X_0R0402

R250 0R0402R250 0R0402

SCLK0 SDATA0 SCLK1 SDATA1

FCH_IDLEEXIT_L

OC#7

AZ_BITCLK_R AZ_SDATA_OUT_R

AZ_SDIN AZ_SYNC_R AZ_RST_R

MEM_1V35#37

DP2_CAB_DP_HDMI#21

CHASSIS_ID234 CHASSIS_ID134 MB_ID134 MB_ID034

Wake On Modem Header

R273 10KR0402R273 10KR0402

N_RI34

FCH_RST2#_R

SLP_S3#_R

SLP_S5#_R PSOUT# FCH_PWRGD

FCH_TEST0 FCH_TEST1 FCH_TEST2

FCH_WAKE#

WD_PWRGD FCH_RSMRST#

CLR_CMOS

MINI_PWRON

SPI_HOLD#_R

MEM_1V35#

TP33TP33

CHASSIS_ID2 CHASSIS_ID1

MB_ID1 MB_ID0

N_RI RI#

+12VActive Low

R274

R274 10KR0402

10KR0402

C577

C150p25N0402

RI#

HighNormal -12V

AE22 AG19

AF19

AG24 AE24 AE26 AF22 AH17 AG18 AF24 AD26 AD25

AG25 AG22

AG26

AF25

AB6

R2

W7

T3

W2

J4

N7 T9

T10

V9

R9

C26

T5 U4 K1 V7

R10

U2

T7 R7

J2

V8

W8

Y6

V10

AA8

M7 R8 T1 P6

F5

P5

J7

T8

AB3 AB1 AA2

Y5 Y3

Y1 AD6 AE4

K19 J19 J21

D21 C20 D23 C22

F21 E20 F20 A22 E18 A20

J18 H18 G18

B21

K18 D19

A18 C18

B19

B17

A24 D17

PCIE_RST2# 24,25

To PCIEXX1,Mini-PCIE

PCIE_RST2#/GEVENT4# RI#/GEVENT22# SPI_CS3#/GBE_STAT1/GEVENT21# SLP_S3# SLP_S5# PWR_BTN#

HUDSON-2

PWR_GOOD

TEST0 TEST1/TMS TEST2 GA20IN/GEVENT0# KBRST#/GEVENT1# PME#/GEVENT3# LPC_SMI#/GEVENT23# LPC_PD#/GEVENT5# SYS_RESET#/GEVENT19# WAKE#/GEVENT8# IR_RX1/GEVENT20# THRMTRIP#/SMBALERT#/GEVENT2# WD_PWRGD

RSMRST#

CLK_REQ4#/SATA_IS0#/GPIO64 CLK_REQ3#/SATA_IS1#/GPIO63 SMARTVOLT1/SATA_IS2#/GPIO50 CLK_REQ0#/SATA_IS3#/GPIO60 SATA_IS4#/FANOUT3/GPIO55 SATA_IS5#/FANIN3/GPIO59 SPKR/GPIO66 SCL0/GPIO43 SDA0/GPIO47 SCL1/GPIO227 SDA1/GPIO228 CLK_REQ2#/FANIN4/GPIO62 CLK_REQ1#/FANOUT4/GPIO61 IR_LED#/LLB#/GPIO184 SMARTVOLT2/SHUTDOWN#/GPIO51 DDR3_RST#/GEVENT7#/VGA_PD GBE_LED0/GPIO183 SPI_HOLD#/GBE_LED1/GEVENT9# GBE_LED2/GEVENT10# GBE_STAT0/GEVENT11# CLK_REQG#/GPIO65/OSCIN/IDLEEXIT#

BLINK/USB_OC7#/GEVENT18# USB_OC6#/IR_TX1/GEVENT6# USB_OC5#/IR_TX0/GEVENT17# USB_OC4#/IR_RX0/GEVENT16# USB_OC3#/AC_PRES/TDO/GEVENT15# USB_OC2#/TCK/GEVENT14# USB_OC1#/TDI/GEVENT13# USB_OC0#/SPI_TPM_CS#/TRST#/GEVENT12#

AZ_BITCLK AZ_SDOUT AZ_SDIN0/GPIO167 AZ_SDIN1/GPIO168 AZ_SDIN2/GPIO169 AZ_SDIN3/GPIO170 AZ_SYNC AZ_RST#

PS2_DAT/SDA4/GPIO187 PS2_CLK/CEC/SCL4/GPIO188 SPI_CS2#/GBE_STAT2/GPIO166

PS2KB_DAT/GPIO189 PS2KB_CLK/GPIO190 PS2M_DAT/GPIO191 PS2M_CLK/GPIO192

KSO_0/GPIO209 KSO_1/GPIO210 KSO_2/GPIO211 KSO_3/GPIO212 KSO_4/GPIO213 KSO_5/GPIO214 KSO_6/GPIO215 KSO_7/GPIO216 KSO_8/GPIO217 KSO_9/GPIO218 KSO_10/GPIO219 KSO_11/GPIO220 KSO_12/GPIO221 KSO_13/GPIO222 KSO_14/XDB0/GPIO223 KSO_15/XDB1/GPIO224 KSO_16/XDB2/GPIO225 KSO_17/XDB3/GPIO226

Part 4 of 5

?

INT 10k PU

CE

Q39

B

C342

C342 X_C1u16X5

X_C1u16X5

N-SST3904_SOT23

U5A

HD AUDIO

EMBEDDED CTRL

RI#RI#

C341

C341 X_C1000p50X0402

X_C1000p50X0402

3

USB MISCUSB 1 . 1

ACPI / WAKE UP EVENTS

USB 2.0

GPIO

USB OC

USB 3.0

EC_PWM0/EC_TIMER0/GPIO197 EC_PWM1/EC_TIMER1/GPIO198

EC_PWM2/EC_TIMER2/WOL_EN/GPIO199

EC_PWM3/EC_TIMER3/GPIO200

USBCLK/14M_25M_48M_OSC

USB_RCOMP

USB_FSD1P/GPIO186

USB_FSD1N

USB_FSD0P/GPIO185

USB_FSD0N

USB_HSD13P USB_HSD13N

USB_HSD12P USB_HSD12N

USB_HSD11P USB_HSD11N

USB_HSD10P USB_HSD10N

USB_HSD9P USB_HSD9N

USB_HSD8P USB_HSD8N

USB_HSD7P USB_HSD7N

USB_HSD6P USB_HSD6N

USB_HSD5P USB_HSD5N

USB_HSD4P USB_HSD4N

USB_HSD3P USB_HSD3N

USB_HSD2P USB_HSD2N

USB_HSD1P USB_HSD1N

USB_HSD0P USB_HSD0N

USBSS_CALRP USBSS_CALRN

USB_SS_TX3P USB_SS_TX3N

USB_SS_RX3P USB_SS_RX3N

USB_SS_TX2P USB_SS_TX2N

USB_SS_RX2P USB_SS_RX2N

USB_SS_TX1P USB_SS_TX1N

USB_SS_RX1P USB_SS_RX1N

USB_SS_TX0P USB_SS_TX0N

USB_SS_RX0P USB_SS_RX0N

SCL2/GPIO193

SDA2/GPIO194 SCL3_LV/GPIO195 SDA3_LV/GPIO196

KSI_0/GPIO201

KSI_1/GPIO202

KSI_2/GPIO203

KSI_3/GPIO204

KSI_4/GPIO205

KSI_5/GPIO206

KSI_6/GPIO207

KSI_7/GPIO208

14M_25M_48M_OSC

G8

USB_RCOMP

B9 H1

H3 H6

H5 H10

G10 K10

J12 G12

F12 K12

K13 B11

D11 E10

F10 C10

A10 H9

G9 A8

C8 F8

E8 C6

A6 C5

A5 C1

C3 E1

E3 C16

A16 A14

C14 C12

A12 D15

B15 E14

F14 F15

G15 H13

G13 J16

H16 J15

K15

H19 G19 G22 G21 E22 H22 J22 H21

K21 K22 F22 F24 E24 B23 C24 F18

R246 11.8KR1%0402R246 11.8KR1%0402

Layout: Place within 1'' of FCH

USB13+ 30 USB13- 30

USB12+ 30 USB12- 30

USB11+ 30 USB11- 30

USB10+ 30 USB10- 30

USB6+ 25 USB6- 25

USB5+ 29 USB5- 29

USB4+ 29 USB4- 29

USB3+ 29 USB3- 29

USB2+ 29 USB2- 29

USB1+ 29 USB1- 29

USB0+ 29 USB0- 29

USBSS_CALRP

R257 1KR1%0402R257 1KR1%0402

USBSS_CALRN

R258 1KR1%0402R258 1KR1%0402

USB_SS_TX3P

USB_SS_TX2N USB_SS_TX2N_C

USB_SS_TX1N USB_SS_TX1N_C

USB_SS_TX0N USB_SS_TX0N_C

FCH_GPO193 FCH_GPO194 SCLK3 SDATA3 FCH_GPI197 FCH_GPI198

FCH_GPO200

C332 C0.1u10X0402C332 C0.1u10X0402 C333 C0.1u10X0402C333 C0.1u10X0402

USB_SS_RX3P 30 USB_SS_RX3N 30

C334 C0.1u10X0402C334 C0.1u10X0402 C335 C0.1u10X0402C335 C0.1u10X0402

USB_SS_RX2P 30 USB_SS_RX2N 30

C336 C0.1u10X0402C336 C0.1u10X0402 C337 C0.1u10X0402C337 C0.1u10X0402

USB_SS_RX1P 30 USB_SS_RX1N 30

C339 C0.1u10X0402C339 C0.1u10X0402 C340 C0.1u10X0402C340 C0.1u10X0402

USB_SS_RX0P 30 USB_SS_RX0N 30

TP34TP34 TP35TP35

FCH_GPIO199 19

ILIM_SEL_1 30 CTL1_1 30 CTL2_1 30 CTL3_1 30 ILIM_SEL_2 30 CTL1_2 30 CTL2_2 30 CTL3_2 30

TP32TP32

mach@Rerouting the USB pairs follow layout

USB_SS_TX3P_C USB_SS_TX3N_CUSB_SS_TX3N

USB_SS_TX2P_CUSB_SS_TX2P

USB_SS_TX1P_CUSB_SS_TX1P

USB_SS_TX0P_CUSB_SS_TX0P

2

CLEAR CMOS

USB11 FRONT PANEL USB10 FRONT PANEL USB9 FRONT PANEL USB8 FRONT PANEL USB7 FRONT PANEL USB6 FRONT PANEL

USB3 USB2 BOTTOM USB2 USB2 TOP USB1 LAN USB BOTTOM USB0 LAN USB TOP

FCH_VDD_11_SSUSB_S

FOR Pin H19,G19 Use as GPIO or configure as one of the following: 10-kΩ 5% pull-up resistor to +3.3V_S5. 10-kΩ 5% pull-down resistor.

FOR GPIO[208:197] KBC Not Implemented: Use for alternate available function or leave not connected.

FCH_GPO_CTRL

USB_SS_TX3P_C 30 USB_SS_TX3N_C 30

USB_SS_TX2P_C 30 USB_SS_TX2N_C 30

USB_SS_TX1P_C 30 USB_SS_TX1N_C 30

USB_SS_TX0P_C 30 USB_SS_TX0N_C 30

R265 X_0R0402R265 X_0R0402 R267 0R0402R267 0R0402

VCC3

R211

CLR_CMOS

R211 10KR0402

10KR0402

CLR_CMOS

1 2 3

H1X3M_RED-RH

CLR_CMOS_X1

JUMP1X2A_RED-RH

CMOS CLEAR JUMPER CLR_COMS Clear CMOS

1 - 2

Normal Clear CMOS2 - 3

6.0

VCC3_SB

ILIM_SEL_1 CTL1_1 CTL2_1 CTL3_1 ILIM_SEL_2 CTL1_2 CTL2_2 CTL3_2

R31310KR0402 R31310KR0402 R57810KR0402 R57810KR0402 R57910KR0402 R57910KR0402 R87510KR0402 R87510KR0402 R87710KR0402 R87710KR0402 R87810KR0402 R87810KR0402 R87910KR0402 R87910KR0402 R88010KR0402 R88010KR0402

VCC3_SB

FCH_GPO193 FCH_GPO194 FCH_GPI197 FCH_GPI198 FCH_GPO200

SCLK3 SDATA3

R26610KR0402 R26610KR0402 R26810KR0402 R26810KR0402 R26910KR0402 R26910KR0402 R27010KR0402 R27010KR0402 R27110KR0402 R27110KR0402

Mode Postion

R27210KR0402 R27210KR0402 R50810KR0402 R50810KR0402

COOL AUTO TUROR RESERVED

Note:Must can trap SMI/SCI.

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

C

Date: Sheet

MICRO-START INT'L CO.,LTD.

HUDSON ACPI/USB/AZ/GPIO

Kaveri-VC 0A

1

GP0/GP1 0/0

0/1 1/0 1/1

16 40Tuesday, June 18, 2013

of

5

HUDSON SATA/VGA/SPI/HWM

4

3

2

1

D D

SATA[3::0]Route to iSATA GEN III 6.0 Gbit/S

SATA[5::4]Route to e-SATA

C C

GEN II 3.0 Gbit/S

FCH_VDD11_RUN

External Clock Generator Mode: Connect to 25.000-MHz XTAL or connect SATA_X1/X2 balls to 100MHz differential clock from external clock generator. Integrated Clock Mode: Leave unconnected.

B B

A A

LAYOUT: ROUTE SATA TX DIFF PAIR @ 100 OHM+/-10% RX DIFF PAIR @ 90 OHM+/-10%

TP36TP36

TP37TP37

SATA_TX0+ SATA_TX0-

SATA_RX0SATA_RX0+

SATA_TX1+ SATA_TX1-

SATA_RX1SATA_RX1+

SATA_TX2+ SATA_TX2-

SATA_RX2SATA_RX2+

SATA_TX3+ SATA_TX3-

SATA_RX3SATA_RX3+

SATA_TX4+ SATA_TX4-

SATA_RX4SATA_RX4+

SATA_LED#

FCH_SATA_X1

FCH_SATA_X2

SATA_TX0+32 SATA_TX0-32

SATA_RX0-32 SATA_RX0+32

SATA_TX1+32 SATA_TX1-32

SATA_RX1-32 SATA_RX1+32

SATA_TX2+32 SATA_TX2-32

SATA_RX2-32 SATA_RX2+32

SATA_TX3+32 SATA_TX3-32

SATA_RX3-32 SATA_RX3+32

SATA_TX4+32 SATA_TX4-32

SATA_RX4-32 SATA_RX4+32

Layout: Place within 1'' of FCH

R288 1KR1%0402R288 1KR1%0402 R289 931R1%0402R289 931R1%0402

SATA_LED#38

FANOUT019

PIN K3,K5,K6: Use as GPIO182 or configure as one of the following: 10-kΩ 5% pull-up resistor to +3.3V_S5. 10-kΩ 5% pull-down resistor.

FCH_TALERT#10

GPIO171 GPIO173 GPIO172

FCH_TALERT#

1

2

3

4

5

6

7

8

RN23 8P4R-10KR0402RN23 8P4R-10KR0402

SATA_CALRP SATA_CALRN

GPIO171 GPIO172 GPIO173

AK19 AM19

AL20

AN20 AN22

AL22

AH20

AJ20 AJ22

AH22 AM23

AK23 AH24

AJ24

AN24

AL24 AL26

AN26

AJ26

AH26 AN29

AL28

AK27 AM27

AL29

AN31

AL31 AL33

AH33 AH31

AJ33 AJ31

AF28 AF27

AD22

AF21

AG21

AH16 AM15

AJ16

AK15 AN16

AL16

K6 K5 K3 M6

SATA_TX0P SATA_TX0N

SATA_RX0N SATA_RX0P

SATA_TX1P SATA_TX1N

SATA_RX1N SATA_RX1P

SATA_TX2P SATA_TX2N

SATA_RX2N SATA_RX2P

SATA_TX3P SATA_TX3N

SATA_RX3N SATA_RX3P

SATA_TX4P SATA_TX4N

SATA_RX4N SATA_RX4P

SATA_TX5P SATA_TX5N

SATA_RX5N SATA_RX5P

NC6 NC7

NC8 NC9

NC10 NC11

NC12 NC13

SATA_CALRP SATA_CALRN

SATA_ACT#/GPIO67

SATA_X1

SATA_X2

FANOUT0/GPIO52 FANOUT1/GPIO53 FANOUT2/GPIO54

FANIN0/GPIO56 FANIN1/GPIO57 FANIN2/GPIO58

TEMPIN0/GPIO171 TEMPIN1/GPIO172 TEMPIN2/GPIO173 TEMPIN3/TALERT#/GPIO174

HUDSON-2

?

SERIAL ATA

HW MONITOR

U5B

Part 2 of 5

SD CARD

SPI ROM

VGA DAC

VGA MAINLINK

Part 2 of 5

GBE LAN

SD_CLK/SCLK_2/GPIO73

SD_CMD/SLOAD_2/GPIO74

SD_CD#/GPIO75

SD_WP/GPIO76

SD_DATA0/SDATI_2/GPIO77

SD_DATA1/SDATO_2/GPIO78

SD_DATA2/GPIO79 SD_DATA3/GPIO80

GBE_COL GBE_CRS

GBE_MDCK

GBE_MDIO

GBE_RXCLK

GBE_RXD3 GBE_RXD2 GBE_RXD1 GBE_RXD0

GBE_RXCTL/RXDV

GBE_RXERR

GBE_TXCLK

GBE_TXD3 GBE_TXD2 GBE_TXD1 GBE_TXD0

GBE_TXCTL/TXEN

GBE_PHY_PD

GBE_PHY_RST#

GBE_PHY_INTR

SPI_DI/GPIO164

SPI_DO/GPIO163

SPI_CLK/GPIO162

SPI_CS1#/GPIO165

ROM_RST#/SPI_WP#/GPIO161

VGA_RED

VGA_GREEN

VGA_BLUE

VGA_HSYNC/GPO68 VGA_VSYNC/GPO69

VGA_DDC_SDA/GPO70

VGA_DDC_SCL/GPO71

VGA_DAC_RSET

AUX_VGA_CH_P AUX_VGA_CH_N

AUXCAL

ML_VGA_L0P ML_VGA_L0N ML_VGA_L1P ML_VGA_L1N ML_VGA_L2P ML_VGA_L2N ML_VGA_L3P ML_VGA_L3N

ML_VGA_HPD/GPIO229

VIN0/GPIO175 VIN1/GPIO176

VIN2/SDATI_1/GPIO177

VIN3/SDATO_1/GPIO178

VIN4/SLOAD_1/GPIO179

VIN5/SCLK_1/GPIO180

VIN6/GBE_STAT3/GPIO181

VIN7/GBE_LED3/GPIO182

FCH_GPIO73

AL14

FCH_GPIO74

AN14 AJ12 AH12 AK13 AM13 AH15 AJ14

GBE_COL

AC4

GBE_CRS

AD3 AD9

GBE_MDIO

W10 AB8 AH7 AF7 AE7 AD7 AG8

GBE_RXERR

AD1 AB7 AF9 AG6 AE8 AD8 AB9 AC2 AA7

GBE_PHY_INTR

NC1 NC2 NC3 NC4 NC5

W9

V6 V5 V3 T6 V1

L30 L32 M29

M28 N30

M33 N32

K31 V28

V29 U28 T31

T33 T29 T28 R32 R30 P29 P28

C29 N2

M3 L2 N4 P1 P3 M1 M5

AG16 AH10 A28 G27 L4

GPIO181 GPIO176 GPIO182 GPIO177

GPIO179 GPIO180 GPIO178 GPIO175

Layout:For SPI Trace length within 4''

SPI_DATAIN SPI_DATAOUT_R SPI_CLK_R SPI_CS#_R SPI_WP#_R

HUDSON_VGA_R

R285 150R1%0402R285 150R1%0402

HUDSON_VGA_G

R286 150R1%0402R286 150R1%0402

HUDSON_VGA_B

R287 150R1%0402R287 150R1%0402

Layout: R within 1''

DAC_RSET AUX_VGA_CH_P

AUX_VGA_CH_N AUXCAL

R291 100R1%0402R291 100R1%0402

ML_VGA_HPD

GPIO175 GPIO176 GPIO177 GPIO178 GPIO179 GPIO180 GPIO181 GPIO182

PIN N2,M3,L2,N4,P1,P3,M1,M5 Use as GPIO182 or configure as one of the following: 10-kΩ 5% pull-up resistor to +3.3V_S5. 10-kΩ 5% pull-down resistor.

1

2

3

4

5

6

7

8

RN24 8P4R-10KR0402RN24 8P4R-10KR0402

1

2

3

4

5

6

7

8

RN25 8P4R-10KR0402RN25 8P4R-10KR0402

FCH_GPIO73 33 FCH_GPIO74 33

TP59TP59 TP60TP60

TP61TP61

TP62TP62

R275 10KR0402R275 10KR0402

R281 0R0402R281 0R0402 R282 0R0402R282 0R0402 R283 0R0402R283 0R0402

R290 715R1%0402R290 715R1%0402

SPI_DATAOUT SPI_CLK SPI_CS#

HUDSON_VGA_R 22 HUDSON_VGA_G 22 HUDSON_VGA_B 22

HUDSON_VGA_HSYNC 22 HUDSON_VGA_VSYNC 22

HUDSON_VGA_SDAT 22 HUDSON_VGA_SCLK 22

FCH_VDD11_RUN

DP1_TX0P 10 DP1_TX0N 10 DP1_TX1P 10 DP1_TX1N 10 DP1_TX2P 10 DP1_TX2N 10 DP1_TX3P 10 DP1_TX3N 10

SPI ROM & DEBUG HEADER

VCC3_SB VCC3_ROM

D4

B140-13-F_SMA-RH

SPI_CS# SPI_WP#_R

MACH@Reserve 0R serial resisters for SI overshoot/undershoot debug

SPI_CS# SPI_DATAIN_R SPI_HOLD#SPI_HOLD# SPI_WP#

+

EC21 CD10u16EL5

1 2

C344 C0.1u16X50402-2C344 C0.1u16X50402-2

R276

10KR0402

R279 0R0402R279 0R0402 R280 X_0R0402R280 X_0R0402

1

CS

VCC

2

DO

HLOD

3

WP

CLK

GND4DI

U33

U33 SPI FLASH-8P_BLACK-RH

SPI FLASH-8P_BLACK-RH

R277

10KR0402

SPI_DATAIN_R SPI_WP# SPI_CLK

SPI_HOLD#

VCC3_ROM

8 7

SPI_CLK

6

SPI_DATAOUT

5

VGA HPD

VCC3

R292

R292 X_10KR0402

X_10KR0402

R296 X_100KR0402R296 X_100KR0402

AUX_VGA_CH_P AUX_VGA_CH_N

R297 X_100KR0402R297 X_100KR0402

ML_VGA_HPD

C346 C0.1u10X0402C346 C0.1u10X0402 C347 C0.1u10X0402C347 C0.1u10X0402

VCC3

R293 X_10KR0402R293 X_10KR0402

R294 0R0402R294 0R0402

32M

U6

1

CS

2

DO(IO1)

3

WP(IO2)

4

GND

W25Q32BVSSIG-HF

R284 X_0R0402R284 X_0R0402

VCC_DDR

B

DP1_AUXP_C 10 DP1_AUXN_C 10

VCC

HOLD(IO3)

CLK

DI(IO0)

SPI_DATAIN SPI_CS#

SPI_HOLD#

CE

Q40

X_N-SST3904_SOT23

R295

R295 100KR0402

100KR0402

HUDSON_VGA_R HUDSON_VGA_G HUDSON_VGA_B

SPI_DATAOUT

SPI_CLK

VCC3_ROMVCC3_ROM

R278

R278 10KR0402

10KR0402

8 7 6 5

SPI_HOLD#_R 16

VCC3_ROM

SPI_DEBUG1

1 2 3 4 5 7 8 9

DP1_HPD_VGA_C 10

C348 X_C10p50N0402C348 X_C10p50N0402

C349 X_C10p50N0402C349 X_C10p50N0402

C350 X_C10p50N0402C350 X_C10p50N0402

C343

X_C10p50N0402

C345

X_C10p50N0402

SPI_HOLD#SPI_DATAIN SPI_DATAOUT

SPI_DATAOUT

SPI_CLK

6

H2X5[10]M-2PITCH_BLACK-RH-2

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

C

Date: Sheet

5

4

3

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

HUDSON SATA/VGA/SPI/HWM

Kaveri-VC 0A

1

17 40Tuesday, June 18, 2013

of

5

4

3

2

1

HUDSON POWER&DECOUPLING

Connected directly to the power plane with

U5C

VCC3

D D

mach@???if VGA translater is not used, power rails tied to GND. (VDDPL_33_DAC,VDDPL_33_ML,VDDAN_33_DAC)

mach@Internally generated 1.8V supply for the RGB outputs???

C C

+1.1VDUAL

+1.1VDUAL_D3

R303 0R0805R303 0R0805

Hudson-2 design:Tie to GND (preferred) VDDPL_33_SSUSB_S VDDAN_11_SSUSB_S_[5:1] VDDCR_11_SSUSB_S_[4:1]

B B

LAYOUT: ROUTE THE POWER TRACES 15MILS WIDTH AT LEAST PLACE THE DECOUPING CAPS CLOSE TO FCH ASAP PLACE FB<=1" ,CAPS <=0.2"

VCC3

VDDPL_3.3V FCH_VDDPL_33_MLDAC

L4 220L200mA-300-RHL4 220L200mA-300-RH

C399

C2.2u6.3X50402

VCC3_SB

mach@ CRB DNI???

FCH_VDDPL_33_USB_S VDDPL_3.3V_PCIE

L11 220L200mA-300-RHL11 220L200mA-300-RH

C408

C409

A A

C409

C2.2u6.3X50402

C1u6.3X50402-HF

5

+3.3V_FCH_R

R298 0R0805R298 0R0805

FCH_VDD11_RUN

mach@???GbE MAC is not enalbed, power rails tied to GND. (VDDIO_33_GBE_S,VDDIO_GBE_S,VDDCR_11_GBE_S)

VCC3_SB AVDD33_USB

L2

220L2A-50L2220L2A-50

L3 220L2A-50L3 220L2A-50

C356

C351

C1u6.3X50402-HF

C22u6.3X50805-RH

VDDPL_3.3V

FCH_VDDPL_33_MLDAC

FCH_VDDAN_33_DAC_R

FCH_VDDPL_33_SSUSB_S

FCH_VDDPL_33_USB_S

VDDPL_3.3V_PCIE VDDPL_3.3V_SATA

L1

220L200mA-300-RH

C378

AVDD11_USB

C385

C354

C363 X_C2.2u6.3X50402C363 X_C2.2u6.3X50402

C22u6.3X50805-RH

20mils

C386

FCH_VDD_11_SSUSB_S

C10u6.3X50805

C393

C395

C391

C2.2u6.3X50402

C392

C10u6.3X50805

C394

C1u6.3X50402-HF

C395

C396

C0.1u10X0402

VCC3

L5 220L200mA-300-RHL5 220L200mA-300-RH

VCC3

L12 220L200mA-300-RHL12 220L200mA-300-RH

C352

C1u6.3X50402-HF

15mils 15mils

VDDPL_11_DAC FCH_VDD11_RUN

C370

C2.2u6.3X50402

60mils

C380

C379

C1u6.3X50402-HF

C387

C0.1u10X0402

C2.2u6.3X50402

C397

C398

C0.1u10X0402

C1u6.3X50402-HF

Pankor

C355

C1u6.3X50402-HF

470 mA

C388

C0.1u10X0402

C400

C414

VDDIO_33_PCIGP_3

AE9

VDDIO_33_PCIGP_4

AD10

VDDIO_33_PCIGP_5

AG7

VDDIO_33_PCIGP_6

AC13

VDDIO_33_PCIGP_7

AB12

VDDIO_33_PCIGP_8

AB13

VDDIO_33_PCIGP_9

AB14

VDDIO_33_PCIGP_10

AB16

VDDPL_33_SYS

H24

47 mA

VDDPL_33_DAC

V22

20 mA

VDDPL_33_ML

U22

12 mA

VDDAN_33_DAC

T22

30 mA

VDDPL_33_SSUSB_S

L18

11 mA

VDDPL_33_USB_S

D7

14 mA

VDDPL_33_PCIE

AH29

11 mA

VDDPL_33_SATA

AG28

12 mA

LDO_CAPLDO_CAP

LDO_CAP

M31

VDDPL_11_DAC

V21

7 mA

VDDAN_11_ML_1

Y22

226 mA

VDDAN_11_ML_2

V23

VDDAN_11_ML_3

V24

VDDAN_11_ML_4

V25

VDDIO_33_GBE_S

AB10

VDDCR_11_GBE_S_1

AB11

VDDCR_11_GBE_S_2

AA11

VDDIO_GBE_S_1

AA9

VDDIO_GBE_S_2

AA10

VDDAN_33_USB_S_1

G7

VDDAN_33_USB_S_2

H8

VDDAN_33_USB_S_3

J8

VDDAN_33_USB_S_4

K8

VDDAN_33_USB_S_5

K9

VDDAN_33_USB_S_6

M9

VDDAN_33_USB_S_7

M10

VDDAN_33_USB_S_8

N9

VDDAN_33_USB_S_9

N10

VDDAN_33_USB_S_10

M12

VDDAN_33_USB_S_11

N12

VDDAN_33_USB_S_12

M11

VDDAN_11_USB_S_1

U12

140 mA

VDDAN_11_USB_S_2

U13

VDDCR_11_USB_S_1

T12

42 mA

VDDCR_11_USB_S_2

T13

VDDAN_11_SSUSB_S_1

P16

282 mA

VDDAN_11_SSUSB_S_2

M14

VDDAN_11_SSUSB_S_3

N14

VDDAN_11_SSUSB_S_4

P13

VDDAN_11_SSUSB_S_5

P14

VDDCR_11_SSUSB_S_1

N16

424 mA

VDDCR_11_SSUSB_S_2

N17

VDDCR_11_SSUSB_S_3

P17

VDDCR_11_SSUSB_S_4

M17

C401

C0.1u10X0402

C2.2u6.3X50402

For low current PLL, analog and IO power rails, a minimum trace width of 15 mils must be used, even if the formula above shows that a thinner trace is acceptable. The 15 mil minimum trace width is required to minimize noise coupling; if necessary, thinner trace can be used but not for more than 300 mils of trace length

It is recommended that each power supply or regulator

C2.2u6.3X50402

on the motherboard be located within 3.0" of its respective load to minimize voltage drop and potential noise issues. To calculate the minimum power delivery trace width, use the formula: Vdroop = I*R, where R=ρ*L/A (ρ = resistivity of material, L = trace length, A = trace cross-sectional area). Vdroop must be < 2.5% of the nominal power rail voltage under maximum current conditions

VDDIO_33_PCIGP_1

AB17

102 mA

VDDIO_33_PCIGP_2

AB18

C355

HUDSON-2

4

U5C

Part 3 of 5

VDDCR_11_1 VDDCR_11_2 VDDCR_11_3 VDDCR_11_4 VDDCR_11_5 VDDCR_11_6 VDDCR_11_7

CORE S0

PCI/GPIO I/O

PCI EXPRESS

MAIN LINK

GBE LAN

SERIAL ATA

POWER

?

VCC3

VDDCR_11_8 VDDCR_11_9

VDDAN_11_CLK_1 VDDAN_11_CLK_2 VDDAN_11_CLK_3 VDDAN_11_CLK_4 VDDAN_11_CLK_5 VDDAN_11_CLK_6 VDDAN_11_CLK_7

CLKGEN I/O

VDDAN_11_CLK_8

VDDAN_11_PCIE_1 VDDAN_11_PCIE_2 VDDAN_11_PCIE_3 VDDAN_11_PCIE_4 VDDAN_11_PCIE_5 VDDAN_11_PCIE_6 VDDAN_11_PCIE_7 VDDAN_11_PCIE_8

VDDAN_11_SATA_1 VDDAN_11_SATA_4 VDDAN_11_SATA_2 VDDAN_11_SATA_3 VDDAN_11_SATA_5 VDDAN_11_SATA_6 VDDAN_11_SATA_7 VDDAN_11_SATA_8 VDDAN_11_SATA_9

VDDAN_11_SATA_10

VDDIO_33_S_1 VDDIO_33_S_2 VDDIO_33_S_3 VDDIO_33_S_4 VDDIO_33_S_5 VDDIO_33_S_6 VDDIO_33_S_7

3.3V_S5 I/O

VDDIO_33_S_8

USB

VDDXL_33_S

VDDCR_11_S_1 VDDCR_11_S_2

VDDPL_11_SYS_S

VDDAN_33_HWM_S

VDDIO_AZ_S

USB SS

L6

220L2A-50L6220L2A-50

VCC3

L13 220L200mA-300-RHL13 220L200mA-300-RH

width ≥ 100 mils with area fill under the FCH.

T14

1120mA

T17 T20 U16 U18 V14 V17 V20 Y17

H26 J25 K24 L22 M22 N21 N22 P22

AB24 Y21 AE25 AD24 AB23 AA22 AF26 AG27

AA21 Y20 AB21 AB22 AC22 AC21 AA20 AA18 AB20 AC19

N18 L19 M18 V12 V13 Y12 Y13 W11

G24

N20 M20

J24

M8

AA4

340 mA

1088 mA

1337 mA

59 mA

5 mA

272 mA

70 mA

5 mA

26 mA

C364

C1u6.3X50402-HF

C357

C2.2u6.3X50402

C365

C1u6.3X50402-HF

C371

C1u6.3X50402-HF

C381

C1u6.3X50402-HF

FCH_VDDAN_33_DAC_R

C402

C407

C0.1u10X0402

C2.2u6.3X50402

VDDPL_3.3V_SATA

C415

C2.2u6.3X50402

C353

C2.2u6.3X50402

C360

C1u6.3X50402-HF

C366

C1u6.3X50402-HF

C372

C1u6.3X50402-HF

20mils

C382

VDDXL_3.3V

15mils

C1u6.3X50402-HF

VDDCR_1.1V

20mils

VDDPL_1.1V

VDDAN_3.3V_HWM

20mils

VCC3_SB

3

FCH_VDD11_RUN

C358

C359

FCH_VDD11_RUN

C22u6.3X50805-RH

C361

C362

C1u6.3X50402-HF

C22u6.3X50805-RH

C368

C367

C373

C383

C1u6.3X50402-HF

+3.3VALW_R

C1u6.3X50402-HF

C374

C384

C1u6.3X50402-HF

C369

C1u6.3X50402-HF

C375

C1u6.3X50402-HF

R301 0RR301 0R

VDDIO_AZ

R302 0RR302 0R

C389

C390

X_C0.1u10X0402

C1u6.3X50402-HF

L7 220L200mA-300-RHL7 220L200mA-300-RH

R300 0R0805R300 0R0805 R299 0R0805R299 0R0805

VDDAN_11_CLK

FCH_VDD11_RUN

C376

C1u6.3X50402-HF

VCC3_SB

FCH_VDDPL_33_SSUSB_S

NB_VCC1P1

C377

C1u6.3X50402-HF

C403

Pankor

C2.2u6.3X50402

Power Rails Hudson D3 Hudson D2

NB_VCC1P1

VDDCR_11_[9:1]

VDDAN_11_CLK_[8:1]

VDDAN_11_PCIE_[8:1]

VDDAN_11_SATA_[10:1]

VDDAN_11_ML_[4:1]

VDDPL_11_DAC

VCC3

VDDIO_33_PCIGP_[10:1]

VDDPL_33_SYS

VDDPL_33_DAC

VDDPL_33_ML

VDDPL_33_PCIE

VDDPL_33_SATA

VDDAN_33_DAC

VCC3_SB

VDDIO_33_S_[8:1]

VDDIO_AZ_S

VDDXL_33_S

VDDAN_33_HWM_S

VDDIO_GBE_S[2:1]

VDDIO_33_GBE_S

VDDPL_33_USB_S

VDDAN_33_USB_S_[12:1]

VDDPL_33_SSUSB_S

+1.1VDUAL

VDDCR_11_S_[2:1]

VDDCR_11_GBE_S[2:1]

VDDPL_11_SYS_S

VDDAN_11_USB_S_[2:1]

VDDCR_11_USB_S_[2:1]

VDDAN_11_SSUSB_S_[5:1]

VDDCR_11_SSUSB_S_[4:1]

VCC3_SB

L8 220L200mA-300-RHL8 220L200mA-300-RH

FCH_VDD11_RUN

+1.1VDUAL

VDDPL_11_SYS_S should be tied to +1.1V_S5 rail if Wake on LAN or USB 3.0 Wake (Hudson-D3 only) is supported; otherwise, it can be tied to +1.1V_S0 rail.

max

4412 mA

1120 mA 1414 mA

340 mA 1088 mA 1337 mA 226 mA

7 mA

max

102 mA 47 mA 20 mA 12 mA 11 mA 12 mA 30 mA

max

59 mA 26 mA 5 mA 12 mA 145 mA 2 mA 14 mA 470 mA

11 mA 0 mA

max

1293 mA 272 mA 63 mA 70 mA 140 mA 42 mA

282 mA 424 mA

L9 X_220L200mA-300-RHL9 X_220L200mA-300-RH

Pankor

L14 220L200mA-300-RHL14 220L200mA-300-RH

2

319 mA

659 mA

GND

0 mA 0 mA

C404

VDDXL_3.3V

C2.2u6.3X50402

C417

VDDPL_1.1V

C2.2u6.3X50402

U5D

Part 5 of 5

GROUND

C405

C2.2u6.3X50402

C412

C2.2u6.3X50402

C406

C1u6.3X50402-HF

VDDAN_3.3V_HWM

C413

C0.1u10X0402

1

U5D

VSSPL_DAC VSSAN_DAC

VSSANQ_DAC

VSSIO_DAC

VDDCR_1.1V

VSS

T25

VSS

T27

VSS

U6

VSS

U14

VSS

U17

VSS

U20

VSS

U21

VSS

U30

VSS

U32

VSS

V11

VSS

V16

VSS

V18

VSS

W4

VSS

W6

VSS

W25

VSS

W28

VSS

Y14

VSS

Y16

VSS

Y18

VSS

AA6

VSS

AA12

VSS

AA13

VSS

AA14

VSS

AA16

VSS

AA17

VSS

AA25

VSS

AA28

VSS

AA30

VSS

AA32

VSS

AB25

VSS

AC6

VSS

AC18

VSS

AC28

VSS

AD27

VSS

AE6

VSS

AE15

VSS

AE21

VSS

AE28

VSS

AF8

VSS

AF12

VSS

AF16

VSS

AF33

VSS

AG30

VSS

AG32

VSS

AH5

VSS

AH11

VSS

AH18

VSS

AH19

VSS

AH21

VSS

AH23

VSS

AH25

VSS

AH27

VSS

AJ18

VSS

AJ28

VSS

AJ29

VSS

AK21

VSS

AK25

VSS

AL18

VSS

AM21

VSS

AM25

VSS

AN1

VSS

AN18

VSS

AN28

VSS

AN33 T21

L28 K33 N28

EFUSE

R6

18 40Tuesday, June 18, 2013

of

HUDSON-2

VSS

A3

VSS

A33

VSS

B7

VSS

B13

VSS

D9

VSS

D13

VSS

E5

VSS

E12

VSS

E16

VSS

E29

VSS

F7

VSS

F9

VSS

F11

VSS

F13

VSS

F16

VSS

F17

VSS

F19

VSS

F23

VSS

F25

VSS

F29

VSS

G6

VSS

G16

VSS

G32

VSS

H12

VSS

H15

VSS

H29

VSS

J6

VSS

J9

VSS

J10

VSS

J13

VSS

J28

VSS

J32

VSS

K7

VSS

K16

VSS

K27

VSS

K28

VSS

L6

VSS

L12

VSS

L13

VSS

L15

VSS

L16

VSS

L21

VSS

M13

VSS

M16

VSS

M21

VSS

M25

VSS

N6

VSS

N11

VSS

N13

VSS

N23

VSS

N24

VSS

P12

VSS

P18

VSS

P20

VSS

P21

VSS

P31

VSS

P33

VSS

R4

VSS

R11

VSS

R25

VSS

R28

VSS

T11

VSS

T16

VSS

T18

VSSAN_HWM

N8

VSSXL

K25

VSSPL_SYS

H25

?

Layout: VSSPL_SYS;VSSAN_HWM CONNECT TO GND WITH A SEPREATED VIA

+1.1VDUAL

R304 0RR304 0R

VCC3_SB

L10 220L200mA-300-RHL10 220L200mA-300-RH

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

C

Date: Sheet

MICRO-START INT'L CO.,LTD.

HUDSON POWER&DECOUPLING

Kaveri-VC 0A

5

4

3

2

1

FCH REQUIRED STRAPS

D D

C C

RTC_CLK15 PCI_CLK115 PCI_CLK315 PCI_CLK415,26 TPM_CLK15,33

LPC_CLK015

FCH_GPIO19916

MACH@All power must be removed after changing S5_PLUS_MODE strap value.

RTCCLK

PULL HIGH

PULL LOW

S5 PLUS MODE DISABLED

DEFAULT

S5 PLUS MODE ENABLED

VCC3_SB VCC3 VCC3_ALW

R307

R306

R306 10KR0402

10KR0402

PCI_CLK1

ALLOW PCIE GEN2

DEFAULT

FORCE PCIE GEN1

R307 10KR0402

10KR0402

R312

R312 X_10KR0402

X_10KR0402

PCI_CLK3

USE DEBUG STRAPS

IGNORE DEBUG STRAPS

DEFAULT

R308

R308 X_10KR0402

X_10KR0402

R881

R882

10KR0402

PCI_CLK4

Reserved

Required setting for intergrated CLOCk MODE

DEFAULT

VCC3_SB VCC3_SBVCC3

R624

R624 10KR0402

10KR0402

LPC_CLK0

EC ENABLED

EC DISABLED

DEFAULT

R309

R309 X_10KR0402

X_10KR0402

R314

R314 10KR0402

10KR0402

LPC_CLK1

INTERNAL CLOCK GEN ENABLED

DEFAULT

INTERNAL CLOCK GEN DISABLED

R311

R311 X_2.2KR0402

X_2.2KR0402

R316

2.2KR0402

GPIO199

LPC ROM

SPI ROM

DEFAULT

FCH DEBUG STRAPS

FCH XOR CHAIN TEST

B B

A A

TP39TP39 TP41TP41 TP42TP42

FCH ICE DEBUG /JTAG TEST PINS

TP45TP45 TP46TP46 TP47TP47 TP48TP48 TP49TP49

FCH PCIE EEPROM STRAPS

PREQ3# FCH_25M_X1 PGNT#3

FCH_JTAG_TMS

FCH_TEST1

FCH_JTAG_TRST#

OC#0

FCH_JTAG_TDI

OC#1

FCH_JTAG_TCK

OC#2

FCH_JTAG_TDO

OC#3

5

PREQ3# 15 PGNT#3 15

OC#0 16,31 OC#1 16,31 OC#2 16,31 OC#3 16,30,31

TP38TP38

TP40TP40

TP43TP43 TP44TP44

VCC3_SB

4

FCH_25M_X2

FCH_TEST0 FCH_TEST2

R317 X_2.2KR0402R317 X_2.2KR0402

FANOUT0 17

FCH_25M_X1 15 FCH_25M_X2 15

FCH_TEST0 16 FCH_TEST2 16

1

2

XOR_TEST1

X_H1X2M_BLACK-RH

FCH XOR CHAIN OUTPUT

FCH XOR CHAIN REF CLOCK

FCH_TEST1 16

3

TEST1 TEST0TEST2

0 1 X Enable test mode

Description

XOR_TEST_X1

SHORTING PLUG

X_JUMP1X2A_RED-RH

6.0

MICRO-START INT'L CO.,LTD.

Title

HUDSON STRAPS

Size Document Number Rev

B

Date: Sheet

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

Kaveri-VC 0A

1

of

19 40Monday, June 17, 2013

5

7

HDMI CONN,

4

3

2

1

R318 665R1%0402R318 665R1%0402 R319 665R1%0402R319 665R1%0402

R320 665R1%0402R320 665R1%0402

D D

VCC5

C418

C418 C0.1u16X50402-2

C0.1u16X50402-2

VOLT_SELECT

VOLT_SELECT14,21,36,3

C C

B B

R321 665R1%0402R321 665R1%0402 R327 665R1%0402R327 665R1%0402

R322 665R1%0402R322 665R1%0402 R324 665R1%0402R324 665R1%0402

R325 665R1%0402R325 665R1%0402

DS

Q42

G

N-2N7002P_SOT23-3-HF

R336 6.65KR1%0402-RHR336 6.65KR1%0402-RH R338 6.65KR1%0402-RHR338 6.65KR1%0402-RH

R339 6.65KR1%0402-RHR339 6.65KR1%0402-RH R340 6.65KR1%0402-RHR340 6.65KR1%0402-RH

R341 6.65KR1%0402-RHR341 6.65KR1%0402-RH R342 6.65KR1%0402-RHR342 6.65KR1%0402-RH

R343 6.65KR1%0402-RHR343 6.65KR1%0402-RH R344 6.65KR1%0402-RHR344 6.65KR1%0402-RH

DS

Q43

G

N-2N7002P_SOT23-3-HF

DP0_TX0P DP0_TX0N

DP0_TX1P DP0_TX1N

DP0_TX2P DP0_TX2N

DP0_TX3P DP0_TX3N

DP0_TX0P DP0_TX0N

DP0_TX1P DP0_TX1N

DP0_TX2P DP0_TX2N

DP0_TX3P DP0_TX3N

DP0_HDMI_CLK DP0_HDMI_DATA

DP0_HPD_HDMI

D5

DP0_TX0P_HDMI DP0_TX0N_HDMI

DP0_TX2P_HDMI DP0_TX2N_HDMI DP0_TX2N_HDMI

D5

1 2

4 5

X_C10p50N0402

10

NC

9

NC

7

NC

6

NC

X_ESD-PDY050003-2510-RH

3

8

R334 33R0402R334 33R0402 R335 33R0402R335 33R0402

R337 33R0402R337 33R0402

C419

X_C10p50N0402

DP0_TX0P_HDMI DP0_TX0N_HDMI

DP0_TX2P_HDMI

C420

DP CONOFIGERATION TABLE

INTERFACE

DP HDMI

DP0_TX0P10 DP0_TX0N10

DP0_TX1P10 DP0_TX1N10

DP0_TX2P10 DP0_TX2N10

DP0_TX3P10 DP0_TX3N10

C421

X_C10p50N0402

DP0_TX3N_HDMI DP0_TX3P_HDMI

DP0_TX1N_HDMI DP0_TX1P_HDMI

DP PORT OF FM1

R328 X_0R0402R328 X_0R0402 R323 X_0R0402R323 X_0R0402

R329 X_0R0402R329 X_0R0402 R326 X_0R0402R326 X_0R0402

R330 X_0R0402R330 X_0R0402 R331 X_0R0402R331 X_0R0402

R332 X_0R0402R332 X_0R0402 R333 X_0R0402R333 X_0R0402

DP0_HDMI_CLK_CN DP0_HDMI_DATA_CN

DP0_HPD_HDMI_CN

VDD_VGA_HDMI

DP0_HDMI_CLK

DP0_HDMI_DATA

DP0_TX0P_HDMI DP0_TX0N_HDMI

DP0_TX1P_HDMI DP0_TX1N_HDMI

DP0_TX2P_HDMI DP0_TX2N_HDMI

DP0_TX3P_HDMI DP0_TX3N_HDMI

C422

C423

C0.1u16X50402-2

X_C10u10X50805-HF-2

D6

1 2

4 5

3

VDD_VGA_HDMI

5

261

0123

Ch 2Ch 1Ch 0ChannelClock

HDMI_DP1B

H1

D2+

H2

D2 Shield

H3

D2-

H4

D1+

H5

D1 Shield

H6

D1-

H7

D0+

H8

D0 Shield

H9

D0-

H10

CK+

H11

CK Shield

H12

CK-

H13

CE Remote

H14

NC

H15

DDC CLK

H16

DDC DATA

H17

GND

H18

+5V

H19

HP DET

X

N5Y-19M0231-L06

DP0_TX3N_HDMI

10

NC

DP0_TX3P_HDMI

9

NC

DP0_TX1N_HDMI

7

NC

DP0_TX1P_HDMI

6

NC

X_ESD-PDY050003-2510-RH

8

C424 X_C0.1u16X50402-2C424 X_C0.1u16X50402-2

DP0_HPD_HDMI

4

D7

X_ESD-AOZ8902CIL-HF

3

X3

X4

LEVEL SHIFT using I2C Repeater

+3VDP

TRINITY

DP0_AUXP_C10

DP0_AUXN_C10

A A

DP0_AUXP_C

DP0_AUXN_C

5

R349

R351

2.2KR0402

+3VDP

R3500RR350

0R

VDD_VGA_HDMI

G2D1G1

Q44

S1

Q44 NN-2N7002D

NN-2N7002D

S2

D2

G2D1G1

Q47

Q47 NN-2N7002D

NN-2N7002D

S2

D2

R354

4.7KR0402

VDD_VGA_HDMI

R357

4.7KR0402

DP0_HDMI_CLK

DP0_HDMI_DATA

4

DP0_HPD_HDMI

R355 10KR0402R355 10KR0402

R356

R356 100KR0402

100KR0402

C427

+3VDP

R352

R352 10KR0402

10KR0402

CE

Q45

B

N-SST3904_SOT23

X_C0.1u16X50402-2

3

B

+3VDP

CE

R353

R353 10KR0402

10KR0402

DP0_HPD_HDMI_C 10

Q46

Q46 N-SST3904_SOT23

N-SST3904_SOT23

HDMI footprint(HDMI_D19_4)_Colay

HDMI

DP0_TX0P_HDMI DP0_TX0N_HDMI

DP0_TX1P_HDMI DP0_TX1N_HDMI

DP0_TX2P_HDMI DP0_TX2N_HDMI

DP0_TX3P_HDMI DP0_TX3N_HDMI

DP0_HDMI_CLK_CN DP0_HDMI_DATA_CN

VDD_VGA_HDMI

DP0_HPD_HDMI_CN

L12-9008054-M09/L12-9008044-T34/L12-9008054-M09

L16

DP0_TX2P DP0_TX2P_HDMI DP0_TX1N_HDMI DP0_TX2N DP0_TX2N_HDMI

DP0_TX0P DP0_TX0P_HDMI DP0_TX0N DP0_TX0N_HDMI

2

4

1

3

2

CMC-L12-9008044-RH

L18

4

1

3

2

CMC-L12-9008044-RH

DP0_TX0P_HDMI DP0_TX1N_HDMI

DP0_TX0N_HDMI

DP0_TX2P_HDMI

DP0_TX2N_HDMI

HDMI

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19

R345

X_180R0402-RH

R347

X_180R0402-RH

Title

Size Document Number Rev

C

Date: Sheet

21

SHELL1

D2+

D2+ D2 Shield

D2 Shield D2-

D2-

23

D1+

D1+ D1 Shield

D1 Shield D1-

D1D0+

D0+ D0 Shield

D0 Shield

MEC1

D0-

D0CK+

CK+ CK Shield

CK Shield CK-

CKCE Remote

CE Remote

NC

NC DDC CLK

DDC CLK DDC DATA

DDC DATA

22

GND

GND +5V

+5V HP DET

HP DET

20

SHELL2

HDMI_D19_6

L17

DP0_TX1N

1

DP0_TX1P

2

CMC-L12-9008044-RH

L19

DP0_TX3N

1

DP0_TX3P

2

CMC-L12-9008044-RH

DP0_TX1P_HDMI

DP0_TX3N_HDMI

DP0_TX3P_HDMI

VDD_VGA_HDMI VDD_VGA_HDMI

C425

C0.1u16X50402-2

MICRO-START INT'L CO.,LTD.

SWITCH&DP/HDMI CONN.

Kaveri-VC 0A

1

4

DP0_TX1P_HDMI

3

DP0_TX3N_HDMI

4

DP0_TX3P_HDMI

3

C426

C0.1u16X50402-2

R346

X_180R0402-RH

R348

X_180R0402-RH

20 40Wednesday, June 19, 2013

of

5

Display Port

4

3

2

1

EMI solution

DP2_TX0P_APU10 DP2_TX0N_APU10

D D

DP2_TX1P_APU10 DP2_TX1N_APU10

DP2_TX2P_APU10 DP2_TX2N_APU10

DP2_TX3P_APU10 DP2_TX3N_APU10

DP2_AUXP_C10 DP2_AUXN_C10

C C

DP2_TX0P_APU DP2_TX0N_APU

DP2_TX1P_APU DP2_TX1N_APU

DP2_TX2P_APU DP2_TX2N_APU

DP2_TX3P_APU DP2_TX3N_APU

DP2_AUXP_C DP2_AUXN_C

C428 C0.1u16X0402C428 C0.1u16X0402 C429 C0.1u16X0402C429 C0.1u16X0402

C430 C0.1u16X0402C430 C0.1u16X0402 C431 C0.1u16X0402C431 C0.1u16X0402

C433 C0.1u16X0402C433 C0.1u16X0402 R359 0R0402R359 0R0402 C432 C0.1u16X0402C432 C0.1u16X0402

C434 C0.1u16X0402C434 C0.1u16X0402 C435 C0.1u16X0402C435 C0.1u16X0402

DPC_LINE0_DP DPC_LINE0_DN

DPC_LINE1_DP DPC_LINE1_DN

DPC_LINE2_DP DPC_LINE2_DN

DPC_LINE3_DP DPC_LINE3_DN

DPC_LINE1_DP DPC_LINE1_DN

DPC_LINE0_DP DPC_LINE0_DN

DPC_LINE3_DP DPC_LINE3_DN

DPC_LINE2_DP DPC_LINE2_DN

R358 0R0402R358 0R0402

L20

4

1

3

2

X_CMC-L12-9008100-HF

R360 0R0402R360 0R0402

L21

4

1

3

2

X_CMC-L12-9008100-HF

R361 0R0402R361 0R0402 R362 0R0402R362 0R0402

L22

4

1

3

2

X_CMC-L12-9008100-HF

R366 0R0402R366 0R0402 R368 0R0402R368 0R0402

L23

4

1

3

2

X_CMC-L12-9008100-HF

R369 0R0402R369 0R0402

DPC_LINE1_DP_C DPC_LINE1_DN_C

DPC_LINE0_DP_C DPC_LINE0_DN_C

DPC_LINE3_DP_C DPC_LINE3_DN_C

DPC_LINE2_DP_C DPC_LINE2_DN_C

D8

D9

DPC_LINE0_DP_C DPC_LINE0_DN_C

DPC_LINE1_DP_C DPC_LINE1_DN_C DPC_LINE3_DN_C

DP_AUX_CH_MUX_P_R DP_AUX_CH_MUX_N_R

DP_HPD_R DP_HPD_R DP_CBL_DET_R DP_CBL_DET_R

D9

1 2

4 5

D10

1 2

4 5

10

NC

9

NC

7

NC

6

NC

X_ESD-PDY050003-2510-RH

3

8

10

NC

9

NC

7

NC

6

NC

X_ESD-PDY050003-2510-RH

3

8

DPC_LINE0_DP_C DPC_LINE0_DN_C

DPC_LINE1_DP_C DPC_LINE1_DN_C

DP_AUX_CH_MUX_P_R DP_AUX_CH_MUX_N_R

DPC_LINE2_DP_C DPC_LINE2_DN_C

DPC_LINE3_DP_C DPC_LINE3_DN_C

DP_AUX_CH_MUX_P DP_AUX_CH_MUX_P_R DP_AUX_CH_MUX_N DP_HPD DP_CBL_DET

D8

1 2

4 5

3

R363 0R0402R363 0R0402

R364 0R0402R364 0R0402

R365 0R0402R365 0R0402

R367 0R0402R367 0R0402

10

NC

9

NC

7

NC

6

NC

X_ESD-PDY050003-2510-RH

8

EMC request

DP_AUX_CH_MUX_N_R DP_HPD_R DP_CBL_DET_R

DPC_LINE2_DP_C DPC_LINE2_DN_C

DPC_LINE3_DP_C

+12V

HDMI_DP1A

+3VDP

R371

R371 10KR0402

10KR0402

DP2_CAB_DP_HDMI#16

D

DP_CBL_DET

+3VDP

R373

D11

D12

VOLT_SELECT

VOLT_SELECT,20,36,37

B B

D12

R373

1N4148W-F_SOD123-RH

10KR0402

1N4148W-F_SOD123-RH

N-2N7002P_SOT23-3-HF

D

Q49

G

N-2N7002P_SOT23-3-HF

S

R372

1MR0402

G

S

D

Q52

G

S

D

Q54

Q54 N-2N7002P_SOT23-3-HF

N-2N7002P_SOT23-3-HF

R370

R370 10KR0402

10KR0402

D

Q48

G

N-2N7002P_SOT23-3-HF

S

DP2_AUXP_C

R376 1.8KR0402R376 1.8KR0402

R377 1.8KR0402R377 1.8KR0402

DP2_AUXN_C

12V_DP2_CAB_DP#_HDMI

C436 C0.1u16X0402C436 C0.1u16X0402

S2

D2

S1

G2D1G1

S1

S2

D2

Q50

Q50 NN-2N7002DW-7-F_SOT363-6-RH

NN-2N7002DW-7-F_SOT363-6-RH

DP_AUX_CH_MUX_P

C437 C0.1u16X0402C437 C0.1u16X0402

DP_AUX_CH_MUX_N

NN-2N7002DW-7-F_SOT363-6-RH

NN-2N7002DW-7-F_SOT363-6-RH Q53

Q53

VCC3

C470p16X0402-RH

+12V

N-P8503BMG_SOT23-3-RH

C438

R378

10KR0402

Q51

S

C439

C0.1u16X0402

Q42_G

DPC_LINE0_DP_C DPC_LINE0_DN_C

DPC_LINE1_DP_C DPC_LINE1_DN_C

DPC_LINE2_DP_C DPC_LINE2_DN_C

DPC_LINE3_DP_C DPC_LINE3_DN_C

+3VDP

F1

D

1 2

G

R379

100KR0402

F-MICROSMD110F-RH

R374 5.1MR0402R374 5.1MR0402

R375 100KR0402R375 100KR0402

C440

X_C10u6.3X5-HF

DP_CBL_DET_R DP_AUX_CH_MUX_P_R DP_AUX_CH_MUX_N_R

DP_HPD_R

+DP_PWR

C441

C0.1u16X0402

HDMI_DP1A

D1

ML_LANE_0P

D2

GND

D3

ML_LANE_0N

D4

ML_LANE_1P

D5

GND

D6

ML_LANE_1N

D7

ML_LANE_2P

D8

GND

D9

ML_LANE_2N

D10

ML_LANE_3P

D11

GND

D12

ML_LANE_3N

D13

GND

D14

GND

D15

AUX_CHP

D16

GND

D17

AUX_CHN

D18

HOT PLUG DETECT

D19

RETURN DP_PWR

D20

DP_PWR

X

X1

X2

C442 C0.1u16X0402C442 C0.1u16X0402

+3VDP

VCC3

R380

R380 100KR0402

100KR0402

R385

R385 X_100KR0402

A A

5

4

X_100KR0402

R381

R381 X_100KR0402

X_100KR0402

DP_AUX_CH_MUX_PDP_AUX_CH_MUX_N

R386

R386 100KR0402

100KR0402

R382

R382 10KR0402

DP2_HPD_DP_C10

N-SST3904_SOT23

3

2

10KR0402

CE

Q55

B

N-SST3904_SOT23

Title

Size Document Number Rev

Date: Sheet of

Date: Sheet

VCC3

R383

R383 10KR0402

10KR0402

CE

Q56

Display Port/HDMI Port

R384 10KR0402R384 10KR0402Q56

B

MICRO-START INT'L CO.,LTD.

Kaveri-VC

1

DP_HPD

21 40Monday, June 17, 2013

0A

of

8

7

6

5

4

3

2

1

VGA CONNECTOR

R932-R934 CLOSE TO CRT CONNECTOR, THE

D D

R387 4.7KR0402R387 4.7KR0402

+12V

G

S

D

VCC5

C C

HUDSON_VGA_SDAT17

HUDSON_VGA_SCLK17

HUDSON_VGA_VSYNC17

B B

HUDSON_VGA_HSYNC17

D

Q57

N-P8503BMG_SOT23-3-RH

R393R393

R394R394

AHCT1G126GV_SOT23-5-RH

FS1

1 2

F-MICROSMD110

VDD_VGA_HDMI

R390

4.7KR0402

VCC5

1 2

VCC5

1 2

VDD_VGA_HDMI

C448

C10u10X50805-HF-2

R391

4.7KR0402

DDCDATA_5V

DDCCLK_5V

C462 C0.1u16X50402-2C462 C0.1u16X50402-2

53

4

U7

C468 C0.1u16X50402-2C468 C0.1u16X50402-2

53

4

U8

C449

C0.1u16X50402-2

VSYNC_5V

C463

C463 X_C100p50N0402

X_C100p50N0402

HSYNC_5V

C469

C469 X_C100p50N0402

X_C100p50N0402

HUDSON_VGA_R17

HUDSON_VGA_G17

HUDSON_VGA_B17

TRACE IMPEDANCE BETWEEN NB AND 150OHM RESISTOR SHOULD BE 37OHM+/-15%, THE TRACE IMPEDANCE BETWEEN THE 2 150OHM

RESISTOR SHOULD BE 50 OHM +/-15%, THE IMPEDANCE BETWEEN THE 2ND RESISTOR

TO THE CONNECTOR SHOULD BE 75OHM+/-15%

mach@The value of L,C refer to demo board,maybe adjusted for test Layout:PLACE L 90 DEGREE

R388

R388 150R1%0402

150R1%0402

R389

R389 150R1%0402

150R1%0402

R392

R392 150R1%0402

150R1%0402

DDCCLK_5V

R396 33R0402R396 33R0402

VSYNC_5V

R395 27R0402R395 27R0402

HSYNC_5V

R397 27R0402R397 27R0402

DDCDATA_5V

R398 33R0402R398 33R0402

VCC5

C140 C0.1u10X0402C140 C0.1u10X0402

52

U44

RED_CONN HSYNC_CONN

6 1

ESD-AOZ8902CIL-HF

BLUE_CONN DDCDATA_CONN

4

GREEN_CONN

3

DDCCLK_CONN VSYNC_CONN

FROM EACH OTHER

L250RL25

0R

C444

X_C1p50N0402-RH

L270RL27

0R

C450

X_C1p50N0402-RH

L290RL29

0R

C454

X_C1p50N0402-RH

VDD_VGA_HDMI

52

U45

6 1

ESD-AOZ8902CIL-HF

VGA_R

C445

C3.3p50N0402-HF

VGA_G

C451

C3.3p50N0402-HF

VGA_B

C455

C3.3p50N0402-HF

C613 C0.1u10X0402C613 C0.1u10X0402

4 3

L26

68n300mA

L28

68n300mA

L30

68n300mA

DDCCLK_CONN VSYNC_CONN HSYNC_CONN DDCDATA_CONN

CLOSE TO VGA Connector

C446

C5.6p25N0402

C452

C5.6p25N0402

C456

C5.6p25N0402

C465

C466

C464

X_C100p50N0402

X_C18P50N0402

C467

X_C100p50N0402

X_C18P50N0402

15 14 13 12 11

VDD_VGA_HDMI

DSUB-VGAF_BLUE-RH-2

5 10 4 9 3 8 2 7 1 6

VGA

16 17

PLACE ESD PROTECTION DIODES

1. CLOSE TO CONNECTOR PINS

2. DIRECTLY ON SIGNAL TRACES

3. +5V & GND TRACE TO DIODE SHOULDBE LESS THAN 100MILS AND 20MILS WIDE

4. THE ESD DIODE SHOULD BE THE FIRST DEVICE FROM CONNECTOR

C461

C461 C0.1u16X50402-2

C0.1u16X50402-2

BLUE_CONN GREEN_CONN RED_CONN

A A

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Custom

Date: Sheet

8

7

6

5

4

3

Date: Sheet

2

MICRO-START INT'L CO.,LTD.

TRAVIS & VGA CONN.

Kaveri-VC 0A

22 40Tuesday, June 18, 2013

1

of

8

7

6

5

4

3

2

1

PCI Express Slot x16

VCC3

R399 X_4.7KR0402R399 X_4.7KR0402 R400 X_4.7KR0402R400 X_4.7KR0402 R401 X_4.7KR0402R401 X_4.7KR0402

D D

C C

B B

A A

R402 X_4.7KR0402R402 X_4.7KR0402

PE_JTAG_TDI PCIE_RST# PE_JTAG_TMS PE_JTAG_TCK PE_JTAG_TRST#

VCC3_SB

PE_WAKE#16,24,25,27,34

GFX_TXC_15P

GFX_TXC_15P8

GFX_TXC_15N

GFX_TXC_15N8

GFX_TXC_14P

GFX_TXC_14P8

GFX_TXC_14N

GFX_TXC_14N8

GFX_TXC_13P

GFX_TXC_13P8

GFX_TXC_13N

GFX_TXC_13N8

GFX_TXC_12P

GFX_TXC_12P8

GFX_TXC_12N

GFX_TXC_12N8

GFX_TXC_11P

GFX_TXC_11P8

GFX_TXC_11N

GFX_TXC_11N8

GFX_TXC_10P

GFX_TXC_10P8

GFX_TXC_10N

GFX_TXC_10N8

GFX_TXC_9P

GFX_TXC_9P8

GFX_TXC_9N

GFX_TXC_9N8

GFX_TXC_8P

GFX_TXC_8P8

GFX_TXC_8N

GFX_TXC_8N8

GFX_TXC_7P

GFX_TXC_7P8

GFX_TXC_7N

GFX_TXC_7N8

GFX_TXC_6P

GFX_TXC_6P8

GFX_TXC_6N

GFX_TXC_6N8

GFX_TXC_5P

GFX_TXC_5P8

GFX_TXC_5N

GFX_TXC_5N8

GFX_TXC_4P

GFX_TXC_4P8

GFX_TXC_4N

GFX_TXC_4N8

GFX_TXC_3P

GFX_TXC_3P8

GFX_TXC_3N

GFX_TXC_3N8

GFX_TXC_2P

GFX_TXC_2P8

GFX_TXC_2N

GFX_TXC_2N8

GFX_TXC_1P

GFX_TXC_1P8

GFX_TXC_1N

GFX_TXC_1N8

GFX_TXC_0P

GFX_TXC_0P8

GFX_TXC_0N

GFX_TXC_0N8

SCLK1

SCLK116,24,25,26,27

SDATA1

SDATA116,24,25,26,27

VCC3

PE_JTAG_TRST#

PE_WAKE#

PCI EXPRESS x16 Slot

+12V

PCIE16X

X2

B1

12V#B1

B2

12V#B2

B3

RSVD#B3

B4

GND#B4

B5

SMCLK

B6

SMDAT

B7

GND#B7

B8

3.3V#B8

B9

JTAG1

B10

3.3VAUX

B11

WAKE#

B12

RSVD#B12

B13

GND#B13

B14

HSOP0

B15

HSON0

B16

GND#B16

B17

PRSNT2#

B18

GND#B18

B19

HSOP1

B20

HSON1

B21

GND#B21

B22

GND#B22

B23

HSOP2

B24

HSON2

B25

GND#B25

B26

GND#B26

B27

HSOP3

B28

HSON3

B29

GND#B29

B30

RSVD#B30

B31

PRSNT2##B31

B32

GND#B32

B33

HSOP4

B34

HSON4

B35

GND#B35

B36

GND#B36

B37

HSOP5

B38

HSON5

B39

GND#B39

B40

GND#B40

B41

HSOP6

B42

HSON6

B43

GND#B43

B44

GND#B44

B45

HSOP7

B46

HSON7

B47

GND#B47

B48

PRSNT2##B48

B49

GND#B49

B50

HSOP8

B51

HSON8

B52

GND#B52

B53

GND#B53

B54

HSOP9

B55

HSON9

B56

GND#B56

B57

GND#B57

B58

HSOP10

B59

HSON10

B60

GND#B60

B61

GND#B61

B62

HSOP11

B63

HSON11

B64

GND#B64

B65

GND#B65

B66

HSOP12

B67

HSON12

B68

GND#B68

B69

GND#B69

B70

HSOP13

B71

HSON13

B72

GND#B72

B73

GND#B73

B74

HSOP14

B75

HSON14

B76

GND#B76

B77

GND#B77

B78

HSOP15

B79

HSON15

B80

GND#B80

B81

PRSNT2##B81

B82

RSVD#B82

X1

SLOT-PCI164P_BLACK-2PITCH-RH-21

PRSNT1#

12V#A3

JTAG2 JTAG3 JTAG4 JTAG5

3.3V#A10 PWRGD

GND#A12 REFCLK+ REFCLKGND#A15

HSIP0 HSIN0

GND#A18

RSVD

GND#A20

HSIP1

HSIN1 GND#A23 GND#A24

HSIP2

HSIN2 GND#A27 GND#A28

HSIP3

HSIN3 GND#A31

RSVD#A32

RSVD#A33

GND#A34

HSIP4

HSIN4 GND#A37 GND#A38

HSIP5

HSIN5 GND#A41 GND#A42

HSIP6

HSIN6 GND#A45 GND#A46

HSIP7

HSIN7 GND#A49

RSVD#A50

GND#A51

HSIP8

HSIN8 GND#A54 GND#A55

HSIP9

HSIN9 GND#A58 GND#A59

HSIP10

HSIN10 GND#A62 GND#A63

HSIP11

HSIN11 GND#A66 GND#A67

HSIP12

HSIN12 GND#A70 GND#A71

HSIP13

HSIN13 GND#A74 GND#A75

HSIP14

HSIN14 GND#A78 GND#A79

HSIP15

HSIN15 GND#A82

+12V

A1 A2

12V

A3 A4

GND

3.3V

PE_JTAG_TCK

A5

PE_JTAG_TDI

A6 A7

PE_JTAG_TMS

A8 A9 A10

PCIE_RST#

A11

A12

PE16_GXF_CLK

A13

PE16_GXF_CLK#

A14 A15

GFX_RX15P

A16

GFX_RX15N

A17 A18

A19 A20

GFX_RX14P

A21

GFX_RX14N

A22 A23 A24

GFX_RX13P

A25

GFX_RX13N

A26 A27 A28

GFX_RX12P

A29

GFX_RX12N

A30 A31 A32

A33 A34

GFX_RX11P

A35

GFX_RX11N

A36 A37 A38

GFX_RX10P

A39

GFX_RX10N

A40 A41 A42

GFX_RX9P

A43

GFX_RX9N

A44 A45 A46

GFX_RX8P

A47

GFX_RX8N

A48 A49

A50 A51

GFX_RX7P

A52

GFX_RX7N

A53 A54 A55

GFX_RX6P

A56

GFX_RX6N

A57 A58 A59

GFX_RX5P

A60

GFX_RX5N

A61 A62 A63

GFX_RX4P

A64

GFX_RX4N

A65 A66 A67

GFX_RX3P

A68

GFX_RX3N

A69 A70 A71

GFX_RX2P

A72

GFX_RX2N

A73 A74 A75

GFX_RX1P

A76

GFX_RX1N

A77 A78 A79

GFX_RX0P

A80

GFX_RX0N

A81 A82

C470 X_C0.1u16X50402-2C470 X_C0.1u16X50402-2

VCC3

From Clock Gen

PE16_GXF_CLK 15 PE16_GXF_CLK# 15

GFX_RX15P 8 GFX_RX15N 8

GFX_RX14P 8 GFX_RX14N 8

GFX_RX13P 8 GFX_RX13N 8

GFX_RX12P 8 GFX_RX12N 8

GFX_RX11P 8 GFX_RX11N 8

GFX_RX10P 8 GFX_RX10N 8

GFX_RX9P 8 GFX_RX9N 8

GFX_RX8P 8 GFX_RX8N 8

GFX_RX7P 8 GFX_RX7N 8

GFX_RX6P 8 GFX_RX6N 8

GFX_RX5P 8 GFX_RX5N 8

GFX_RX4P 8 GFX_RX4N 8

GFX_RX3P 8 GFX_RX3N 8

GFX_RX2P 8 GFX_RX2N 8

GFX_RX1P 8 GFX_RX1N 8

GFX_RX0P 8 GFX_RX0N 8

PCIE_RST# 15,27

Placement Close To PCIE16_X1

EC22

+

12

VCC3+12V +12V

C473

C472

C471

VCC3_SB

C476

C475

C474

MICRO-START INT'L CO.,LTD.

Title

CD470u16EL11.5-RH

C0.1u16X50402-2

8

7

6

X_C0.1u16X50402-2

C0.1u16X50402-2

5

X_C0.1u16X50402-2

C0.1u16X50402-2

X_C0.1u16X50402-2

4

3

2

Title

Size Document Number Rev

Custom

Date: Sheet

MICRO-START INT'L CO.,LTD.

PCI EXPRESS X16

Kaveri-VC 0A

23 40Tuesday, June 18, 2013

1

of

8

7

6

5

4

3

2

1

PCI EXPRESS X1 Slot-1

D D

SCLK116,23,25,26,27 SDATA116,23,25,26,27

PE_WAKE#16,23,25,27,34

GPP_TXC_0P15 GPP_TXC_0N15

C C

SCLK1 SDATA1

VCC3_SB

PE_WAKE#

+12V +12V

PCIE1X_1

VCC3

PCIE1X_1

B1

12V

B2

12V#B2

B3

RSVD

B4

GND

B5

SMCLK

B6

SMDATA

B7

GND#B7

B8

3.3V

B9

JTAG1

B10

3.3VAUX

B11

WAKE_#

B12

RSVD#B12

B13

GND#B13

B14

HSOP0+

B15

HSOP0-

B16

GND#B16

B17

PRSNT2_#

B18

GND#B18

SLOT-PCI36_BLACK-2PITCH-RH-4

PRSNT1_#

12V#A2 12V#A3

GND#A4

JTAG2 JTAG3 JTAG4 JTAG5

3.3V#A9

3.3V#A10 PWRGD

GND#A12 REFCLK+

REFCLK-

GND#A15

HSIP0+

HSIP0-

GND#A18

X1

X2

A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 X1

A12 A13 A14 A15 A16 A17 A18 X2

VCC3

PCIE_RST2#

PCIE_RST2# 16,25

PE1_GPP_CLK0 15 PE1_GPP_CLK0# 15

GPP_RX0P 15 GPP_RX0N 15

+12V

VCC3

VCC3_SB

C477

C0.1u16X50402-2

C483

C0.1u16X50402-2

C489

Place close to Pin A3,B3

C480

C479

X_C0.1u16X50402-2

C485

X_C0.1u16X50402-2

C491

C480

C486

C478

X_C0.1u16X50402-2

C484

X_C0.1u16X50402-2

C490

C481

X_C0.1u16X50402-2

C487

X_C0.1u16X50402-2

C482

X_C0.1u16X50402-2

C488

X_C0.1u16X50402-2

C0.1u16X50402-2

X_C0.1u16X50402-2

B B

VCC3_SB

VCC3

SCLK1 SDATA1

PE_WAKE#

GPP_TXC_1P15

A A

GPP_TXC_1N15

8

PCI EXPRESS X1 Slot-2

+12V +12V

PCIE1X_2

B1

12V

B2

12V#B2

B3

RSVD

B4

GND

B5

SMCLK

B6

SMDATA

B7

GND#B7

B8

3.3V

B9

JTAG1

B10

3.3VAUX

B11

WAKE_#

B12

RSVD#B12

B13

GND#B13

B14

HSOP0+

B15

HSOP0-

B16

GND#B16

B17

PRSNT2_#

B18

GND#B18

SLOT-PCI36_BLACK-2PITCH-RH-4

7

PRSNT1_#

12V#A2 12V#A3

GND#A4

JTAG2 JTAG3 JTAG4 JTAG5

3.3V#A9

3.3V#A10 PWRGD

GND#A12 REFCLK+

REFCLK-

GND#A15

HSIP0+

HSIP0-

GND#A18

A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 X1

X1

A12 A13 A14 A15 A16 A17 A18 X2

X2

6

VCC3

PCIE_RST2#

PE1_GPP_CLK1 15 PE1_GPP_CLK1# 15

GPP_RX1P 15 GPP_RX1N 15

5

PCIE_RST2#

4

C492 X_C0.1u16X50402-2C492 X_C0.1u16X50402-2

X_C0.1u16X50402-2

3

MICRO-START INT'L CO.,LTD.

Title

PCIE X1 SLOTs

Size Document Number Rev

B

Date: Sheet

MICRO-START INT'L CO.,LTD.

Kaveri-VC 0A

2

of

24 40Tuesday, June 18, 2013

1

5

4

3

2

1

R263 X_10KR0402R263 X_10KR0402 R404 X_0R0402R404 X_0R0402

R405 0R0402R405 0R0402 R406 0R0402R406 0R0402

LED_WlLAN#

+3VAUX_WLAN

+1_5VRUN_WLAN

R407 0R0402R407 0R0402 R408 0R0402R408 0R0402

+1_5VRUN_WLAN

+3VAUX_WLAN

MINI_PWRON 16 PCIE_RST2# 16,24

+3VAUX_WLAN +1_5VRUN_WLAN

USB6-SBD6USB6+SBD6+

+3VAUX_WLAN

SCLK1 16,23,24,26,27 SDATA1 16,23,24,26,27

SBD6SBD6+

SBD6SBD6+ SBD6+

+3VAUX_WLAN

R411

4.7KR0402

LED_WlLAN#

MINI_PCIE1

PE_WAKE#16,23,24,27,34

MINI_CLKREQ#15 PE_MINI_CLK#15

D D

C C

PE_MINI_CLK15

MINI_TXC_N15 MINI_TXC_P15

+3VAUX_WLAN

SP2

Spacer

Support

E2B-1024030-RH

1

MINI_RXN15 MINI_RXP15

R403 0R0402R403 0R0402

R482 X_0R0402R482 X_0R0402

SP3

Spacer

Support

E2B-1024030-RH

1

MINI_PCIE1

1

WAKE#

3

COEX1

5

COEX2

7

CLKREQ#

9

GND

11

REFCLK-

13

REFCLK+

15

GND

KEY

17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49 51

53

KEY

Reserved*(UIM_C8) Reserved*(UIM_C4) GND PERn0 PERp0 GND GND PETn0 PETp0 GND GND +3.3Vaux +3.3Vaux GND Reserved1 Reserved2 Reserved3 Reserved4

GND

SLOT-MINIPCI52P_WHITE-RH

+3.3Vaux

GND

+1.5V

UIM_PWR

UIM_DATA

UIM_CLK

UIM_RESET

UIM_VPP

GND

W_DISABLE#

PERST#

+3.3Vaux

GND

+1.5V

SMB_CLK

SMB_DATA

GND

USB_D-

USB_D+

GND

LED_WWAN#

LED_WLAN# LED_WPAN#

+1.5V

GND

+3.3Vaux

GND

MEC1 MEC2

2 4 6 8 10 12 14 16

18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52

54

MEC1 MEC2

MINI_DIS#

MINI_SCLK MINI_SDATA

1 2

4 5

PCIE_RST2#

VCC5

L31

4 3

X_CMC-L12-9008044-RH

D20

R409

4.7KR0402

10

NC

9

NC

7

NC

6

NC

X_ESD-ESD3V3U4ULC-RH

3

8

C493 X_C0.1u16X50402-2C493 X_C0.1u16X50402-2

Q58

G2 D1 G1

NN-2N7002D

S1

USB6- 16 USB6+ 16

SBD6-

VCC5

R410

4.7KR0402

D2

S2

F_LED_WlLAN#

F_LED_WlLAN# 38

+3VAUX_WLAN POWER

B B

+3VAUX_WLAN

VCC3

VCC3_SB

A A

R414 X_0R0805R414 X_0R0805 R415 0R0805R415 0R0805

5

3.3V@1.5 A

C500

C495

C10u10X50805-HF-2

C496

C497

C0.1u16X50402-2

4

C499

C498

C0.1u16X50402-2

ATX_PWROK7,30,34,36,37,38

R413 X_10KR0402R413 X_10KR0402

VCC3

C502

3

X_C10u10X50805-HF-2

+1_5VRUN_WLAN POWER

VCC5_SB

R412 X_10RR412 X_10R

1

POK

2

EN

3

C503

X_C0.1u16X50402-2

Pd=( Vin - Vout] * Imax = (3.3 - 1.5) V * 0.5Amp = 0.9 W

VIN

5

NC

C494 X_C0.1u16X50402-2C494 X_C0.1u16X50402-2

U9

4

X_UP0105PSW8_PSOP8-HF

6

VOUT

CNTL

7

FB

0.8 V

GND8GND

9

PD=1.9 W

2

Vo=0.8*(R1+R2)/R1

Title

Size Document Number Rev

Custom

Date: Sheet

1.5V@0.5 A

R416

X_976R1%0402

C501

R2

R417

X_C0.1u16X50402-2

X_1.1KR1%0402

R1

MICRO-START INT'L CO.,LTD.

MINI PCIE SLOT

Kaveri-VC 0A

+1_5VRUN_WLAN

C504

+

12

EC23

EC23 X_CD100u16EL5-RH-1

X_CD100u16EL5-RH-1

X_C22u6.3X51206

25 40Tuesday, June 18, 2013

1

of

5

4

3

2

1

-12V

D D

PCI_INTF#15 PCI_INTH#15

PCI_CLK415,19

PREQ0#15

C C

IRDY#15 DEVSEL#15 LOCK#15

PERR#15 SERR#15

B B

PREQ0# AD31

AD29 AD27

AD25 C_BE#3

AD23 AD21

AD19 AD17

C_BE#2 IRDY# DEVSEL# LOCK#

PERR# SERR# C_BE#1

AD14 AD12

AD10

AD8 AD7

AD5 AD3

AD1 ACK#64

VCC5

VCC3

B10 B11 B12 B13 B14 B15 B16 B17 B18 B19 B20 B21 B22 B23 B24 B25 B26 B27 B28 B29 B30 B31 B32 B33 B34 B35 B36 B37 B38 B39 B40 B41 B42 B43 B44 B45 B46 B47 B48 B49

B52 B53 B54 B55 B56 B57 B58 B59 B60 B61 B62

B1 B2 B3 B4 B5 B6 B7 B8 B9

X1

PCI

-12V TCK GND TDO +5V +5V INTB# INTD# PRSNT#1 RESERVED3 PRSNT#2 GND GND RESERVED4 GND CLK GND#B17 REQ# +5V(I/O) AD31 AD29 GND AD27 AD25 +3.3V C/BE#3 AD23 GND AD21 AD19 +3.3V AD17 C/BE#2 GND IRDY# +3.3V DEVSEL# GND LOCK# PERR# +3.3V SERR# +3.3V C/BE#1 AD14 GND AD12 AD10 GND

X1 AD8 AD7 +3.3V AD5 AD3 GND AD1 +5V(I/O) ACK64# +5V +5V

SLOT-PCI-HF-2

TRST#

+12V

TMS

TDI +5V

INTA#

INTC#

+5V

RESERVED1

+5V(I/O)

RESERVED2

GND GND

3.3VAUX RST#

+5V(I/O)

GNT#

GND

PME#

AD30

+3.3V

AD28 AD26

GND

AD24

IDSEL

+3.3V

AD22 AD20

GND AD18 AD16

+3.3V

FRAME#

GND

TRDY#

GND

STOP#

+3.3V SMBCLK SMBDAT

GND

PAR

AD15

+3.3V

AD13 AD11

GND

AD9

C/BE#0

+3.3V

AD6 AD4

GND

AD2

AD0 +5V(I/O) REQ64#

+5V +5V

X2

A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 A16 A17 A18 A19 A20 A21 A22 A23 A24 A25 A26 A27 A28 A29 A30 A31 A32 A33 A34 A35 A36 A37 A38 A39 A40 A41 A42 A43 A44 A45 A46 A47 A48 A49

X2 A52 A53 A54 A55 A56 A57 A58 A59 A60 A61 A62

+12V

VCC5

VCC3

PCI_PME# AD30

AD28 AD26

AD24 ID1

AD22 AD20

AD18 AD16

FRAME# TRDY# STOP#

PAR AD15

AD13 AD11

AD9

C_BE#0 AD6

AD4 AD2

AD0 REQ#64

PCI_INTE# 15 PCI_INTG# 15

VCC3_SB

PCIRST#_R

R418 33R0402R418 33R0402

PGNT0# 15 PCI_PME# 16

R419 100R0402R419 100R0402

FRAME# 15

TRDY# 15

STOP# 15 SCLK1 16,23,24,25,27

SDATA1 16,23,24,25,27 PAR 15

AD16

PCIRST# 15

VCC5 VCC3 VCC5

PCI slot

+3VSB +3VSB

3.3V

+12V

+

12

EC24

EC24 CD1000U6.3EL11.5

CD1000U6.3EL11.5

PCI PULL-UP / DOWN RESISTORS

R883 8.2KR0402R883 8.2KR0402

REQ#64

R884 8.2KR0402R884 8.2KR0402

(wake) - 375mA (no wake)

- 20mA

- 7.6A

- 5A5V

- 0.5A

+

12

EC25

EC25 X_CD1000U6.3EL11.5

X_CD1000U6.3EL11.5

C506

0.1u6.3X

VCC3

C507

C507 X_0.1u6.3X

X_0.1u6.3X

PCIRST#_RACK#64

C505

C150p25N0402

VCC3 VCC3_SB

C510

C508

0.1u6.3X

C509

C509 X_0.1u6.3X

X_0.1u6.3X

C510

0.1u6.3X

C511

C511 X_0.1u6.3X

X_0.1u6.3X

AD[31..0]

A A

C_BE#[3..0]

AD[31..0] 15

C_BE#[3..0] 15

5

IDSEL = AD16 MASTER = PREQ#0 PIRQ#A

4

3

+12V

C512

C512 X_C0.1u16X0402

X_C0.1u16X0402

C513

C513 C0.1u16X0402

C0.1u16X0402

MICRO-START INT'L CO.,LTD.

Title

PCI Slot

Size Document Number Rev

Date: Sheet of

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

Kaveri-VC

1

of

26 40Tuesday, June 18, 2013

0A

5

4

3

2

1

Gigabit LAN RTL8111E-VC Co-lay RTL8111GN

RTL8111E-VC is pin to pin compatible with RTL8111GN. The two chips can change each other without any component change.

+LAN_3VSB

R420

R421

2.49K/1%

200R0402

C527

AVDD3348AVDD33

DVDD10

13

C0.1u16X0402

LAN_SMBCLK

LAN_RSET

47

SMBCLK14SMBDATA15CLKREQB

LAN_SMBDATA

C528

46

124847423927

200R0402

LAN_XTLI

LAN_XTLO

45

43

RSET

AVDD10

CKXTAL244CKXTAL1

HSIP17HSIN18REFCLK_P19REFCLK_N20EVDD1021HSOP22HSON

16

C0.1u16X0402

U29_P40

41

39

42

40

AVDD33

DVDD10

DVDD33

LED0/SPICS

LAN_RXC_P

12

D22

X_ESD-MLVS0402M04-EM

D D

+LAN_3VSB

+V_1P0_LAN

U11

49

GND

TR_D0+ TR_D0-

TR_D1+ TR_D1-

TR_D2+ TR_D2-

TR_D3+

+V_1P0_LAN

TR_D3-

SCLK116,23,24,25,26

SDATA116,23,24,25,26

+LAN_3VSB

C C

R434

0R0402

C1u16X5

1 2 3 4 5 6 7 8

9 10 11 12

C521

R439 0R0402R439 0R0402 R440 0R0402R440 0R0402

MDIP0 MDIN0 AVDD10 MDIP1 MDIN1 AVDD10 MDIP2 MDIN2 AVDD10 MDIP3 MDIN3 AVDD33

V_1P0_LAN_R

C522

C0.1u16X0402

Place Near Pin

+LAN_3VSB

C526

C525

C0.1u16X0402

B B

C530

C529

C0.1u16X0402

R422

R422 1KR0402

1KR0402

200R0402

U29_P38

LAN_EESK

37

38

GPO

REGOUT VDDREG

LED1/EESK/SPICK

VDDREG

ENSWREG

EEDI/SDA/SPIDI

LED3/EEDO/SPIDO

EECS/SCL

DVDD10

LANWAKEB

DVDD33

ISOLATEB

PERSTB

GND

24

23

LAN_CLKEREQ#

C523 C0.1u16X0402C523 C0.1u16X0402

LAN_RXC_N

C524 C0.1u16X0402C524 C0.1u16X0402

LED0_LINK100#

R423

LED_LINK1000#

36 35 34 33 32 31 30 29 28 27 26 25

RTL8111GN-CG-RH

R435 10KR0402R435 10KR0402 C520 X_C0.1u16X0402C520 X_C0.1u16X0402

LAN_REGOUT

LAN_EEDI LAN_EEDO LAN_EECS

PE_WAKE# LAN_ISO

LAN_RST#

LAN_TXC_P 8 LAN_TXC_N 8 PE_LAN_CLK 15

PE_LAN_CLK# 15

LAN_RXP 8 LAN_RXN 8

C515

C0.1u16X0402

R426 10KR0402R426 10KR0402 R427 510R0402R427 510R0402 R428 X_10KR0402R428 X_10KR0402

+V_1P0_LAN

PE_WAKE# 16,23,24,25,34

+LAN_3VSB

R429 33R0402R429 33R0402

C518

X_C470p50N0402-HF

+LAN_3VSB

LAN Connector

USB_LANB

X_RJ45_USBX2_LEDX2_TX-RH-73

C516

C4.7u6.3X50805

LAN_ACT_LED3

PCIE_RST# 15,23

PWR

PWR TD1+

TD1+ TD1-

TD1TD2+

TD2+ TD2-

TD2TD3+

TD3+ TD3-

TD3TD4+

TD4+ TD4-

TD4-

GND

+LAN_3VSB

19 20 13 18 12 17 11 16 10 15 9 14 21 22

LED_LINK1000# LED0_LINK100# LAN_TCT TR_D0+_R TR_D0-_R TR_D1+_R TR_D1-_R TR_D2+_R TR_D2-_R TR_D3+_R TR_D3-_R LAN_RCT_GND LAN_LED_P LAN_ACT_LED3

LAN_EECS LAN_EESK LAN_EEDI LAN_EEDO

LAN_XTLI

LAN_XTLO

LAN_SMBCLK

LAN_SMBDATA

R441 0R0402R441 0R0402 R442 0R0402R442 0R0402 R443 0R0402R443 0R0402 R444 0R0402R444 0R0402 R445 0R0402R445 0R0402 R446 0R0402R446 0R0402 R447 0R0402R447 0R0402 R448 0R0402R448 0R0402

U10

1 2 3 4

R438 X_10KR0402R438 X_10KR0402

8

CS

VCC

7

SK

DC

6

DI

ORG

5

DO

GND

X_AT93C66A-10SU-2.7-RH

C517

C27p50N0402

12

Y3

Y3 25MHZ18P_D-4

25MHZ18P_D-4

C519

C27p50N0402

R436 X_1KR0402R436 X_1KR0402

R437 X_1KR0402R437 X_1KR0402

TR_D0+ TR_D0TR_D1+ TR_D1TR_D2+ TR_D2TR_D3+ TR_D3-

+LAN_3VSB

+LAN_3VSB +LAN_3VSB

C514

C514 X_C0.1u16X0402

X_C0.1u16X0402

(58mA+289mA)

VCC3

R424 1KR1%0402R424 1KR1%0402

ESD

TR_D3-_R

1

TR_D3+_R

2

TR_D2-_R

4

TR_D2+_R

5

TR_D0+_R

1

TR_D0-_R

2

TR_D1+_R

4

TR_D1-_R TR_D1-_R

5

LAN_ISO

R425

R425 15KR1%0402

15KR1%0402

EMI solution: can be unmounted if LAN connector has surge protect

D21

10 9

7 6

3

8

D23

10 9

7 6

3

8

TR_D3-_R TR_D3+_R

TR_D2-_R TR_D2+_R

X_ESD-PDY050003-2510-RH

TR_D0+_R TR_D0-_R

TR_D1+_R

X_ESD-PDY050003-2510-RH

Place Near Pin

+V_1P0_LAN

CHOKE8

LAN_REGOUT

A A

CHOKE8

1 2

CH-4.7u0.75A190mS-RH

Close To Choke11 Modify 3/1

C531

3451913 41 6 9

C535

C534

C0.1u16X0402

C4.7u6.3X50805

C532

C533

C0.1u16X0402

5

C536

C538

C537

C0.1u16X0402

C539

C0.1u16X0402

ESD

+LAN_3VSB

C0.1u16X0402

4

R449 75R0402R449 75R0402

12

LAN_LED_P

12

D24

ESD-MLVS0402M04-EM

LAN_RCT_GND

D27

ESD-VPORT0603102MV05-RH

R451

R451 0R0402

0R0402

LAN_ACT_LED3

12

D25

ESD-MLVS0402M04-EM

LED0_LINK100#

12

D28

ESD-MLVS0402M04-EM

3

LAN_TCT

LED_LINK1000#

12

D29

ESD-MLVS0402M04-EM

12

D26

ESD-VPORT0603102MV05-RH

R450 X_510R0402R450 X_510R0402

TP50TP50

TP51TP51

TP52TP52 TP53TP53

TP54TP54

+LAN_3VSB

+V_1P0_LAN PCIE_RST# PE_LAN_CLK

PE_LAN_CLK# +LAN_3VSB

2

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Date: Sheet of

Date: Sheet

MICRO-START INT'L CO.,LTD.

LAN-RTL8111GN/RTL8111E-VC

Kaveri-VC

1

0A

of

27 40Tuesday, June 18, 2013

5

Audio Codec ALC892 (Co-Lay 662)

Default is ALC892

JD resistors should be placed as close as possible to the sense pin of CODEC.

HP_SNS

R454 39.2KR1%0402R454 39.2KR1%0402

MIC_SNS

R456 20KR1%0402R456 20KR1%0402

CEN_JD

Sense_A

C544

C543

C10u10X50805-HF-2

FPAUD_PRESENCE#

REGREF

GPIO1

D40

S-BAT54A_SOT23

Z

D41

X_S-BAT54A_SOT23

R458 10KR1%0402R458 10KR1%0402

ALC888S/892:stuff ALC662: NC

45 46 47

SPDIFO

48 13

HP_OUT-L

14

HP_OUT-R

15

MIC_IN-L

16

MIC_IN-R

17 18 19

20

C545

C0.1u10X0402

R483 X_0R0402R483 X_0R0402 R486 X_0R0402R486 X_0R0402

ALC662-VC:stuff ALC888S/892/662-VD:NC

Y X

MIC_R_1 MIC_L_1

HP_R_1 HP_L_1

R492

R492 1KR0402

1KR0402 R494

R494 1KR0402

1KR0402 R495

R495 51R0402

51R0402 R496

R496 51R0402

51R0402

D42

D42 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH

D43

D43 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH

D44

D44 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH

FRONT-L

Sense_B

35

33

34

U12

NC

Sense B

SIDE-L SIDE-R SPDIFI/EAPD SPDIFO

Sense A LINE2-L LINE2-R MIC2-L MIC2-R CD-L CD-GND

CD-R

DVDD11GPOI0/DMIC-CLK2GPIO1/DMIC-DATA3DVSS14SDATA-OUT5BCLK6DVSS27SDATA-IN8DVDD-IO9SYNC10RESET#11PCBEEP

R488 4.7KR0402R488 4.7KR0402 R489 4.7KR0402R489 4.7KR0402

R490 X_4.7KR0402R490 X_4.7KR0402 R491 X_4.7KR0402R491 X_4.7KR0402

12

D45

D45 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH

D D

FRONT-JD

R468 5.1KR1%0402R468 5.1KR1%0402

LINE1-JD

R471 10KR1%0402R471 10KR1%0402

MIC1-JD

R472 20KR1%0402R472 20KR1%0402

SURR_JD

R475 39.2KR1%0402R475 39.2KR1%0402

ALC888S/892:stuff ALC662: NC

VCC3

C C

ALC892 ALC888S-VC ALC662-VD

Pin 3

REGREF GPIO0

Pin 4

GPIO1 GPIO1

ALC662-VC

GPIO1

DVSS

Front Audio Jack

MIC2-VREFO

LINE2-VREFO

B B

MIC_IN-R

C554 C4.7u10X50805-HFC554 C4.7u10X50805-HF

MIC_IN-L

C555 C4.7u10X50805-HFC555 C4.7u10X50805-HF

+

HP_OUT-R HP_OUT-L

+

EC36 CD100u16EL5-RH-1

1 2

+

EC37 CD100u16EL5-RH-1

1 2

Audio Power

ALC892 PART

ALC662-VC/88S:NC ALC892/662-VD:stuff

A A

VCC5_SB

Digital Area

Analog Area

21

L32

5.1V

L32

D48

60n900mA_0805-RH-2

MMSZ5231BT1G-RH

AVDD5_R LDOVDD

R503 0RR503 0R

PIN 29:Reference for integrated regulator

AVDD5_R

C567

C0.1u10X0402

Layout:place close to Pin 3 ASAP

5

Layout: C568 place close to R503

X5R

C568

ALC 662/888S/892 : stuff

C10u10X50805-HF-2

REGREF

Reference resistor for Jack Detection(close to the codec)

Spilt by DGND

AVDD5

C578 C10u10X50805-HF-2C578 C10u10X50805-HF-2

C0.1u10X0402

C0.1u10X0402 C540

C540

FRONT-R

SURR_L

SURR_R

CENO

LFE

R463 20KR1%0402R463 20KR1%0402

36

37

FRONT-L

FRONT-R

REALTEK

AL892/662

12

44

39

40

42

43

38

41

LFE

JDREF

AVSS2

AVDD2

SURR-L

SURR-R

CENTER

PIN37-VREFO

AZ_SDIN_R

REGREF

FPAUD_PRESENCE#

R487 0R0402R487 0R0402

ALC662-VC:NC ALC892/888S/662-VD:stuff

1/16W, 2.5V, max:25mA

MIC_R MIC_L HP_R HP_L

11 13

H2X7[14]M_ORANGE-RH

R497

R499

22KR0402

X_22KR0402

R500

R498

X_22KR0402

22KR0402

Analog Area Digital Area

C574

C574 C10u10X50805-HF-2

C10u10X50805-HF-2

MIC1-L MIC1-R

LINE1-L

LINE1-R

AVDD1 AVSS1

MIC1-VREFO-L

LINE1-VREFO

MIC2-VREFO

LINE2-VREFO

MIC1-VREFO-R

12

F_AUDIO

3 5 7

21 22

23 24

25 26

27

VREF

28 29 30 31

32

ALC892-CG,A2

R481 22R0402R481 22R0402

C550

291

HP_SNS

4

MIC_SNS

6 8 10 12

FPAUD_PRESENCE#

3.3V Level GPIO Codec GPIO1

4

Layout Follow Route

PIN.36

PIN.46

PIN.47

PIN.1 PIN.12

MIC1-IN-L MIC1-IN-R

LINE1-IN-L LINE1-IN-R

C541 C22u6.3X5-HFC541 C22u6.3X5-HF

C542 C10u10X50805-HF-2C542 C10u10X50805-HF-2

LDOVDD

C551

15p50N0402

C22p50N0402

MIC1-VREFO-L

MIC2-VREFO LINE2-VREFO

MIC1-VREFO-R

C552

15p50N0402

VCC3

C556

C556 X_C0.1u16X50402-2

X_C0.1u16X50402-2

4

PIN.25

AZ_RST#

C553

C270P50N0402

X_JUMPER-1X2A_GREEN-RH-1

R493

R493 10KR0402

10KR0402

PIN.24PIN.37

PIN.13PIN.48

Analog Area Digital Area

AVDD5

AZ_RST# 16 AZ_SYNC 16 AZ_SDIN 16 AZ_BIT_CLK 16 AZ_SDOUT 16

F_AUDIO_X1

6.0

Short Pin3 & Pin5

Rear Phone Jack 3 IN 1

R455

L_INR_0

F_R_0FRONT-R F_R_1

C4.7u10X50805-HF

M_INL_0MIC1-IN-L M_INR_0MIC1-IN-R

C4.7u10X50805-HF

1*3 N54-13F0331-K06

R455 75R0402

75R0402

R457

R457 75R0402

75R0402

R466

R466 75R0402

75R0402

R467

R467 75R0402

75R0402

R476 2.2KR0402R476 2.2KR0402 R477 2.2KR0402R477 2.2KR0402

1KR0402

1KR0402 R479

R479 R480

R480

1KR0402

EC28

CD10u16EL5

+

LINE1-IN-L L_INL_0

1 2

+

LINE1-IN-R

1 2

EC29

CD10u16EL5

EC32

EC32 CD100u16EL5-RH-1

CD100u16EL5-RH-1

+

FRONT-L F_L_0

1 2

+

1 2

EC33

EC33 CD100u16EL5-RH-1

CD100u16EL5-RH-1

MIC1-VREFO-L MIC1-VREFO-R

X_CD10u16EL5

+

EC34

1 2

C547

C547 C548

C548

+

EC35

1 2

X_CD10u16EL5

ALC888S/892: 4.7uX5R,1KR,22KR reserved ALC662: 10u EL,75R,22KR stuffed

In order to meet Vista Premium requirement, ALC892/888S:MLCC input cap MUST use X5R dielectric material and 10V DC rated voltage. ALC662:10uF DIP caps and 22K pull-down resistors

2*3 N58-25F0191-K06

A=SURR B=CEN/BAS C=SPDIFOUT D=LINE IN E=LINE OUT F=MIC

L_INR_1

F_L_1

M_INL_1 M_INR_1

3

L_INL_1

3

R461

R461 22KR0402

22KR0402 R462

R462 22KR0402

22KR0402

D32

D32 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH D33

D33 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH

12

R473

R473 22KR0402

22KR0402 R474

R474 22KR0402

22KR0402

D37

D37 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH D36

D36 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH

R484

R484 X_22KR0402

X_22KR0402 R485

R485 X_22KR0402

X_22KR0402

D38

D38 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH D39

D39 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH

Tied at one point only under the codec or near the codec

LINE1-JD

12

FRONT-JD

12

MIC1-JD

12

CP13CP13

1 2

CP14CP14

1 2

CP15CP15

1 2

C557 C0.1u16X50402-2C557 C0.1u16X50402-2 C558 C1000p50X0402C558 C1000p50X0402 C559 C1000p50X0402C559 C1000p50X0402 C560 C1000p50X0402C560 C1000p50X0402

LIN_IN

AUDIO1D

D4 D1 DP DQ

X_AUDIOJACKX5_SPDIFX1-RH

4

LIN_OUT

AUDIO1E

E4

E1 EP EQ

X_AUDIOJACKX5_SPDIFX1-RH

2

MIC1

AUDIO1F

F5

F4

F1 FP FQ

X_AUDIOJACKX5_SPDIFX1-RH

2

Rear Phone Jack 6 IN 1

+

SURR_L SURR_L_0 SURR_R SURR_R_0

+

EC26 CD10u16EL5

1 2

+

EC27 CD10u16EL5

1 2

+

EC30 CD10u16EL5

1 2

+

EC31 CD10u16EL5

1 2

ALC888S/892:stuff ALC662: NC

EMI

For EMI Placement close to Codec chip

LINE1-IN-R

C561 X_C100p50N0402C561 X_C100p50N0402

LINE1-IN-L

C562 X_C100p50N0402C562 X_C100p50N0402

FRONT-R

C563 X_C100p50N0402C563 X_C100p50N0402

FRONT-L

C564 X_C100p50N0402C564 X_C100p50N0402

MIC1-IN-R

C566 X_C100p50N0402C566 X_C100p50N0402

MIC1-IN-L

C569 X_C100p50N0402C569 X_C100p50N0402

SURR_R

C570 X_C100p50N0402C570 X_C100p50N0402

SURR_L

C571 X_C100p50N0402C571 X_C100p50N0402

LFE

C572 X_C100p50N0402C572 X_C100p50N0402

CENO

C573 X_C100p50N0402C573 X_C100p50N0402

Sense_B

C575 X_C0.1u16X50402-2C575 X_C0.1u16X50402-2

2

LFE_0LFE LFE_1

SPDIFO SPDIFO_C

R478 10R0402R478 10R0402

LINE1-JD L_INR_1

L_INL_1

MIC1-JD M_INR_1

M_INL_1

AVDD(5V)

1

75R0402

SURR_L_1

R452

SURR_R_1

R453

R453 75R0402

75R0402

75R0402 R464

R464 R465

R465 75R0402

75R0402

CENO_1CENO CENO_0

C0.1u16X0402

VCC5

R459

R459 22KR0402

22KR0402 R460

R460 22KR0402

22KR0402

D30

D30 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH D31

D31 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH

R469

R469 22KR0402

22KR0402 R470

R470 22KR0402

22KR0402

D34

D34 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH D35

D35 ESD-VPORT0603102MV05-RH

ESD-VPORT0603102MV05-RH

C546

C549

C549 C100p50N0402

C100p50N0402

12

A

DRIVE

B

IC

C

SURR_JD

X_AUDIOJACKX5_SPDIFX1-RH

CEN_JD

AUDIO1C

TX

LED

X_AUDIOJACKX5_SPDIFX1-RH

Colay Jack 3 in 1 footprint

AUDIO2A

3 11 12 10 13

X_JACK-AUDIOF_PK/LIME/BU-RH

AUDIO2C

2

4

1

5

X_JACK-AUDIOF_PK/LIME/BU-RH

ALC892 ALC888S-VC ALC662-VD

45.8mA 61mA

11mA 41mA

16 14 15

18 17

ALC662-VC

40.5mA

41.5mA

23.4mADVDD(3.3V)

10.8mA

Title

Size Document Number Rev

Custom

Date: Sheet

FRONT-JD

F_R_1 F_L_1

TP55TP55

MICRO-START INT'L CO.,LTD.

ALC892/662

Kaveri-VC 0A

1

SURR

AUDIO1A

5 A4 A1 AP AQ

3

CEN/BAS

AUDIO1B

B4 B1 BP BQ

X_AUDIOJACKX5_SPDIFX1-RH

1

AUDIO2B

7 8 6 9

X_JACK-AUDIOF_PK/LIME/BU-RH

AVDD5

of

28 40Tuesday, June 18, 2013

E

NEAR USB CONNECTOR

D

REAR PANEL USB CONNECTOR

C

B

A

USB 2.0 trace length REAR side within 18''; FRONT side within 6''

4 4

3 3

SBD0+ SBD0-

USB1+ USB1USB0+

SVCC1

52

6 1

R510 0R0402R510 0R0402 R511 0R0402R511 0R0402 R512 0R0402R512 0R0402 R513 0R0402R513 0R0402

D50

D50 X_ESD-AOZ8902CIL-HF

X_ESD-AOZ8902CIL-HF

SBD1+

4

SBD1-

3

SBD1+ SBD1SBD0+ SBD0-USB0-

L33

4

USB1+16

USB1-16

USB0+16

USB0-16

1

3

2

X_CMC-L12-9008044-RH

L34

4

1

3

2

X_CMC-L12-9008044-RH

SBD1+ SBD1-

SBD0+ SBD0-

SBD1SBD1+

SBD0SBD0+

SVCC1

C576 X_C0.1u16XC576 X_C0.1u16X

USB_LANA

5

PWR

6

USB-

7

USB+

8

GND

UP

1

PWR

2

USB-

3

USB+

DOWN

4

GND

X_RJ45_USBX2_LEDX2_TX-RH-73

23

GND

24

GND

25

GND

26

GND

27

GND

28

GND

29

GND

30

GND

FRONT USB PIN HEADER

SVCC2

L35

D49

D49 X_ESD-AOZ8902CIL-HF

X_ESD-AOZ8902CIL-HF

52

SBD4-

6

SBD4+

1

USB5+

R504 0R0402R504 0R0402

USB5- SBD5-

2 2

USB4+ USB4-

R505 0R0402R505 0R0402 R506 0R0402R506 0R0402 R507 0R0402R507 0R0402

SBD5+

4

SBD5-

3

SBD5+ SBD4+

SBD4-

USB4+16

USB4-16

USB5+16

USB5-16

L35

4

1

3

2

X_CMC-L12-9008044-RH

L36

4

1

3

2

X_CMC-L12-9008044-RH

SBD4+

SBD4-

SBD5+ SBD5-

SBD4SBD4+

SVCC2

F_USB2

1 2 3 4

6

5 7 8 9 10

12

H2X6[11]M_YELLOW-RH

SBD5SBD5+

SVCC3

D51

D51 X_ESD-AOZ8902CIL-HF

X_ESD-AOZ8902CIL-HF

E

52

6 1

R516 0R0402R516 0R0402 R517 0R0402R517 0R0402 R518 0R0402R518 0R0402 R519 0R0402R519 0R0402

SBD3+

4 3

SBD3+ SBD3SBD2+ SBD2-

USB3+16

USB3-16

USB2+16

USB2-16

D

SBD2+

SBD2- SBD3-

USB3+ USB3USB2+ USB2-

1 1

L37

4

1

3

2

X_CMC-L12-9008044-RH

L38

4

1

3

2

X_CMC-L12-9008044-RH

SBD3+ SBD3-

SBD2+ SBD2-

C

SVCC3

F_USB1

1 2

SBD2- SBD3-SBD3SBD2+

3 4

6

5 7 8 9 10

12

H2X6[11]M_YELLOW-RH

Title

USB POWER/CONNECTORS

Size Document Number Rev

Custom

Kaveri-VC 0A

Date: Sheet

B

SBD3+

MICRO-START INT'L CO.,LTD.

of

29 40Monday, June 17, 2013

A

5

Rear USB Connnector For USB 3.0

5VSBDRV1 5VDRV1_PMOS

R527 X_0R0402R527 X_0R0402

5VSBDRV131,36

VCC5_SB

C585

C585 X_C10u16X50805-HF

X_C10u16X50805-HF

5VDRV1_PMOS 5VDRV1

VCC5

D D

5VDRV131,36

C589

X_C0.1u16X0402

USB charger port power discharge circuit

R539

R539 X_10KR0402

X_10KR0402

SYS5VSB_OFF34,38

USB_SS_TX0N_C16 USB_SS_TX0P_C16

USB_SS_RX0N16 USB_SS_RX0P16

USB_SS_TX0P_C

R543 0R0402R543 0R0402

USB_SS_TX0N_C

R544 0R0402R544 0R0402

USB_SS_RX0N

R545 0R0402R545 0R0402

USB_SS_RX0P

R546 0R0402R546 0R0402

C C

USB_SS_TX1P_C USB_SS_TX1N_C

USB_SS_RX1N USB_SS_RX1P

USB_SS_TX1N_C16 USB_SS_TX1P_C16

USB_SS_RX1N16 USB_SS_RX1P16

R549 0R0402R549 0R0402 R550 0R0402R550 0R0402

R551 0R0402R551 0R0402 R552 0R0402R552 0R0402

RUSB3_CHARGE

NP-APM4532KC-TRL_SOP8-RH

4 5 3

6

2

871

Q61

5VDRV1_PMOS

R534 137KR1%0402R534 137KR1%0402

R536

C590

120KR1%0402

X_C0.1u16X0402

RUSB3_CHARGE

RN8

1

2

3

4

5

6

7

8

Q63

X_8P4R-270R

D

G

S

X_N-2N7002P_SOT23-3-HF

USB_SS_TX0N_C USB_SS_TX0P_C

USB_SS_RX0N USB_SS_RX0P

USB_SS_TX0P_R USB_SS_TX0N_R

USB_SS_RX0N_R USB_SS_RX0P_R

USB_SS_TX1N_C USB_SS_TX1P_C

USB_SS_RX1P USB_SS_RX1P_R

USB_SS_TX1P_R USB_SS_TX1N_R

USB_SS_RX1N_R USB_SS_RX1P_R

C587

C587 C0.1u16X0402

C0.1u16X0402

R538

2KR

L41

431

2

X_CMC-L12-9008044-RH

L42

431

2

X_CMC-L12-9008044-RH

USB_SS_TX1N_R

1

USB_SS_TX1P_R USB_SS_TX1P_R

2

USB_SS_TX0N_R

4

USB_SS_TX0P_R

5

L43

431

2

X_CMC-L12-9008044-RH

L44

431

2

X_CMC-L12-9008044-RH

U17

USB_SS_RX0N_R

1

USB_SS_RX0P_R USB_SS_RX0P_R

2

USB_SS_RX1N_R

4

USB_SS_RX1P_R

5

USB_SS_TX0N_R USB_SS_TX0P_R

USB_SS_RX0N_R USB_SS_RX0P_R

U15

3

USB_SS_TX1N_R USB_SS_TX1P_R

USB_SS_RX1N_RUSB_SS_RX1N

NC

NC NC

NC

NC NC

NC

ESD-ESD3V3U4ULC-RH

3

8

10

NC

9

NC

7

NC

6

NC

ESD-ESD3V3U4ULC-RH

8

USB_SS_RX0N_R

10 9

USB_SS_RX1N_R

7

USB_SS_RX1P_R

6

RUSB3_CHARGE

USB_SS_TX1N_R

USB_SS_TX0N_R USB_SS_TX0P_R

4

ILIM_SEL_116

R535 30KR1%0402R535 30KR1%0402

C0.1u16X0402

SLP_S3#16,34,36,37

ATX_PWROK7,25,34,36,37,38

5VDRV1_EN31,36

C584

C591

C1u16X50402-HF

OC#416,31

USB_EN31,34

RUSB3_CHARGE

USB11-16

USB11+16

ILIM_SEL_1

R537 10KR0402R537 10KR0402

R541

R541 10KR0402

10KR0402

OC#4

R547 100KR0402R547 100KR0402

32.4KR1%0402-1

CHARGE_EN_1

G

C0.1u16X50402-2

R522

17

TPAD

1

IN

2

DM_OUT

3

DP_OUT

4

ILIM_SEL

G

Q64

D

S

N-2N7002P_SOT23-3-HF

C596

U16

5

S3#

6

OC#

4

EN

C600

C1u16X50402-HF

ILIM0_LO_1

ILIM0_HI_1

15

16

ILIM_HI

ILIM_LO

5

CTL1_1

CTL1_116CTL2_116CTL3_1

Q62

D

S

N-2N7002P_SOT23-3-HF

1

2

5VSB

5VCC

GND

UP7550PMA8_SOT23-8-HF

3

R523

32.4KR1%0402-1

14

GND

CTL2_1

Q65

VOUT

3

13

FAULT#

OUT

DM_IN

DP_IN

STATUS#

CTL38CTL27CTL16EN

CTL3_1

D

G

S

VCC5_SBVCC5

C597

C597 C10u16X50805-HF

C10u16X50805-HF

7

8

R526 0R0402R526 0R0402

U14

TPS2546RTER

12

11

10

9

R540 X_0R0402R540 X_0R0402

R542 0R0402R542 0R0402

STATUS#_1

16

USBN11_CH

USBP11_CH

R548

R548 X_10KR0402

X_10KR0402

OC#3

RUSB3_SVCC2

OC#3 16,19,31

R53210KR1%0402 R53210KR1%0402

RUSB3_SVCC1

RUSB3_CHARGE

2

12

+

EC39

C583

C583 C22u6.3X50805-RH

C22u6.3X50805-RH

R529

R529 10KR0402

10KR0402

CD100u16EL5-RH-1

USB10-16

USB10+16

USBN11_CH USBP11_CH

R524 0R0402R524 0R0402 R525 0R0402R525 0R0402

L39

2

X_CMC-L12-9008044-RH

R528 0R0402R528 0R0402 R530 0R0402R530 0R0402

L40

2

X_CMC-L12-9008044-RH

1

co-layout

SBD10-

431

SBD10+

co-layout

SBD11-

431

SBD11+

RUSB3_CHARGE

C592

C592 X_C0.01u16X0402

X_C0.01u16X0402

52

D52

SBD11-

SBD10+

614

SBD11+

SBD10-

3

ESD-AOZ8902CIL-HF

CTL1_1

CTL2_1

RUSB3_SVCC1

C595

X_C0.1u16X

19

USB1A

USB_SS_TX1P_R

9

SSTX2+

GND

1

SBD11SBD11+

RUSB3_SVCC2

SBD10SBD10+

C598

X_C0.1u16X

VBUS2

8

SSTX2-

2

D2-

4

GND

3

D2+

6

SSRX2+

7

GND_D

5

SSRX2-

GND

USBAX2M_BLUE-RH-7

USBAX2M_BLUE-RH-7 20

21

USB1B

18

SSTX2+

GND

10

VBUS2

17

SSTX2-

11

D2-

13

GND

12

D2+

15

SSRX2+

16

GND_D

14

SSRX2-

GND

USBAX2M_BLUE-RH-7

USBAX2M_BLUE-RH-7 22

USB_SS_TX1N_R

USB_SS_RX1P_R USB_SS_RX1N_R

12

+

EC40

CD1000U6.3EL11.5

USB_SS_TX0P_R USB_SS_TX0N_R

USB_SS_RX0P_R USB_SS_RX0N_R

Front Panel USB Connnector For USB 3.0

5VDRV1_PMOS5VSBDRV1

R557 X_0R0402R557 X_0R0402

5VSBDRV131,36

VCC5_SB

C604

C604 X_C10u16X50805-HF

X_C10u16X50805-HF

5VDRV1_PMOS 5VDRV1

VCC5

B B

5VDRV131,36

X_C0.1u16X0402

C608

USB charger port power discharge circuit

SYS5VSB_OFF34,38

USB_SS_TX2N_C16 USB_SS_TX2P_C16

USB_SS_RX2P USB_SS_RX2P_R

USB_SS_RX2P16

USB_SS_RX2N

USB_SS_RX2N16

USB_SS_TX2P_C

R574 0R0402R574 0R0402

USB_SS_TX2N_C

R575 0R0402R575 0R0402

USB_SS_RX2N

R576 0R0402R576 0R0402

USB_SS_RX2P

R577 0R0402R577 0R0402

USB_SS_TX3P_C16

USB_SS_TX3P_C USB_SS_TX3N_C

USB_SS_RX3N USB_SS_RX3P

USB_SS_TX3N_C16

USB_SS_RX3N16

USB_SS_RX3P16

R580 0R0402R580 0R0402 R581 0R0402R581 0R0402

R582 0R0402R582 0R0402 R583 0R0402R583 0R0402

5

A A

NP-APM4532KC-TRL_SOP8-RH

NP-APM4532KC-TRL_SOP8-RH 4 5

3

6

2

871

Q66

R565 137KR1%0402R565 137KR1%0402

R567

120KR1%0402

RN9

2 4 6 8

R570

R570 X_10KR0402

X_10KR0402

Q68

X_8P4R-270R

D

G

S

X_N-2N7002P_SOT23-3-HF

USB_SS_TX2P_C USB_SS_TX2P_R

USB_SS_TX2P_R USB_SS_TX2N_R

USB_SS_RX2N_R USB_SS_RX2P_R

USB_SS_TX3P_C USB_SS_TX3N_C USB_SS_TX3N_R

USB_SS_TX3P_R USB_SS_TX3N_R

USB_SS_RX3N_R USB_SS_RX3P_R

FUSB3_CHARGE

5VDRV1_PMOS

C609

C609 X_C0.1u16X0402

X_C0.1u16X0402

FUSB3_CHARGE

1 3 5 7

C606

C606 C0.1u16X0402

C0.1u16X0402

2

USB_SS_TX3P_R USB_SS_TX3N_R

USB_SS_TX2N_R USB_SS_TX2P_R

USB_SS_RX3N_R

R569

2KR

L47

X_CMC-L12-9008044-RH

L48

X_CMC-L12-9008044-RH

L49

2

X_CMC-L12-9008044-RH

L50

2

X_CMC-L12-9008044-RH

FUSB3_CHARGE

USB_SS_TX2N_RUSB_SS_TX2N_C

431

USB_SS_RX2N_R

U19

USB_SS_TX3P_R

1

10

NC

USB_SS_TX3N_R

2

9

NC

USB_SS_TX2N_R

4

7

NC

USB_SS_TX2P_R

6

5

NC

ESD-ESD3V3U4ULC-RH

3

8

USB_SS_TX3P_R

431

USB_SS_RX3N_RUSB_SS_RX3N

431

USB_SS_RX3P_RUSB_SS_RX3P

U21

USB_SS_RX2N_RUSB_SS_RX2N_R

1

10

NC

USB_SS_RX2P_RUSB_SS_RX2P_R

2

9

NC

USB_SS_RX3P_RUSB_SS_RX3P_R

4

7

NC

USB_SS_RX3N_R

6

5

NC

ESD-ESD3V3U4ULC-RH

3

8

4

ILIM_SEL_216

R566 30KR1%0402R566 30KR1%0402

C0.1u16X0402

ATX_PWROK7,25,34,36,37,38

SLP_S3#16,34,36,37

C603

C610

C1u16X50402-HF

FUSB3_CHARGE

USB12-16

USB12+16

ILIM_SEL_2

R568 10KR0402R568 10KR0402

R572

R572 10KR0402

10KR0402

32.4KR1%0402-1

CHARGE_EN_2

R553

17

TPAD

1

IN

2

DM_OUT

3

DP_OUT

4

ILIM_SEL

Q69

D

G

S

N-2N7002P_SOT23-3-HF

R554

32.4KR1%0402-1

ILIM0_HI_2

ILIM0_LO_2

15

16

ILIM_HI

ILIM_LO

5

CTL1_2

CTL1_216CTL2_216CTL3_2

Q67

D

G

S

N-2N7002P_SOT23-3-HF

3

R558 0R0402R558 0R0402

14

13

U18

TPS2546RTER

GND

FAULT#

12

OUT

11

DM_IN

10

DP_IN

STATUS#_2

9

STATUS#

CTL38CTL27CTL16EN

CTL3_2

CTL2_2

16

R571 X_0R0402R571 X_0R0402

Q70

D

R573 0R0402R573 0R0402

G

S

USBN12_CH

USBP12_CH

FUSB3_SVCC1

OC#5 16,31

OC#5

12

+

EC41

C602

C602 C22u6.3X50805-RH

C22u6.3X50805-RH

R560

R560 10KR0402

10KR0402

CD100u16EL5-RH-1

R56310KR1%0402 R56310KR1%0402

FUSB3_CHARGE

R555 0R0402R555 0R0402 R556 0R0402R556 0R0402

L45

USB13-16

2

USB13+16

X_CMC-L12-9008044-RH

R559 0R0402R559 0R0402 R561 0R0402R561 0R0402

L46

USBP12_CH SBD12+

2

X_CMC-L12-9008044-RH

co-layout

SBD13-USB13-

431

SBD13+USB13+

co-layout

431

SBD12-USBN12_CH

FUSB3_CHARGE

C611

C611 X_C0.01u16X0402

X_C0.01u16X0402

52

D53

SBD13-

SBD12+

614

SBD13+

SBD12-

3

ESD-AOZ8902CIL-HF

CTL1_2

CTL2_2

2

USB_SS_RX2N_R USB_SS_RX2P_R

USB_SS_TX2N_R USB_SS_TX2P_R

C614

X_C0.1u16X50402-2

SBD13+

FUSB3_SVCC1 FUSB3_SVCC2

B18 B17 B16 B15 B14 B13 B12

B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1

X2

A18

RSVD

A17

RSVD

A16

RSVD

A15

VBUS

A14

VBUS

A13

GND

A12

GND

X1

A11

GND

A10

STDA SSRX-

A9

STDA SSRX+

A8

GND

A7

STDA SSTX-

A6

STDA SSTX+

A5

GND

SBD12+

A4

D+

SBD12-SBD13-

A3

D-

A2

GND

A1

RSVD

SLOT-PCI36P-2PITCH-RH-3

SLOT-PCI36P-2PITCH-RH-3 F_USB3

F_USB3

MICRO-START INT'L CO.,LTD.

Title

Front / Rear USB Connectors

Size Document Number Rev

Kaveri-VC

Date: Sheet of

Date: Sheet

1

C616

X_C0.1u16X50402-2

USB_SS_RX3N_R USB_SS_RX3P_R

USB_SS_TX3N_R USB_SS_TX3P_R

0A

of

30 40Tuesday, June 18, 2013

8

Rear USB 2.0 0.5A pert port

VCC5

D D

5VDRV1_EN30,36

OC#016,19

R584 20KR1%0402R584 20KR1%0402

USB_EN30,34

C630

C1u6.3X50402-HF

U22

5

S3#

6

OC#

4

EN

2

1

5VSB

5VCC

GND

UP7550PMA8_SOT23-8-HF

3

Front USB 2.0 0.5A pert port

VCC5_SB

VOUT

7

C624

C624 C10u16X50805-HF

C10u16X50805-HF

7

8

+

12

R876

R876 X_10KR0402

X_10KR0402

EC43

SVCC1

CD1000u6.3EL11.5-RH-1

C631

6

C0.1u16X50402-2

5

VCC5

C621

C0.1u16X50402-2

SVCC1 SVCC3 RUSB3_SVCC1SVCC2 RUSB3_SVCC2

4

Place close to UP7536 pin1

C622

C627

C0.1u16X50402-2

3

2

Lenovo Consumer MB common spec V0 2: Must reserve ESD protection diode on USB front header 5V_Dual power.

1

SVCC2 SVCC3

12

FUSB3_SVCC2FUSB3_SVCC1

D56

D55

X_ESD-VPORT0603102MV05-RH

FUSB3_SVCC1 FUSB3_SVCC2

12

C632

C633

C634

C635

C636

C637

C638

12

D59

D60

VCC5_SB

C639

C639 X_C10u16X50805-HF

X_C10u16X50805-HF

Q71

5VSBDRV1 5VDRV1

C C

VCC5

C0.1u16X50402-2

5VSBDRV130,36

5VDRV130,36

FUSB2_VCC

B B

Q71

4 5 3 2 1

NP-APM4532KC-TRL_SOP8-RH

C641

5VSBDRV1

5VDRV1

F4

1 2

F-SMD1812P260TFT-HF

F5

1 2

F-SMD1812P260TFT-HF

F6

1 2

F-SMD1206P350SLR-HF

FUSB2_VCC

6 7 8

C640

C640 C0.1u16X0402

C0.1u16X0402

SVCC2

12

+

SVCC3

+

EC44

CD1000U6.3EL11.5

+

12

EC45

CD1000U6.3EL11.5

Front USB 2.0 header

SLP_S5#16,34,36,37

C647

C647 C0.1u16X0402

C0.1u16X0402

C650

C650 C0.1u16X0402

C0.1u16X0402

FUSB3_SVCC2

C726

C726 C0.1u16X0402

C0.1u16X0402

+

12

CD1000U6.3EL11.5

Front USB 3.0 header

EC79

C0.1u16X50402-2

For EMI Placement close to ESD doide power pin.

X_C0.1u16X50402-2

USB power discharge circuit

R589 10KR0402R589 10KR0402

ATX_5VSB

R590 8.2KR0402R590 8.2KR0402

C649

X_C0.1u16X50402-2

C0.1u16X50402-2

X_C0.1u16X50402-2

SVCC_DIS

C648

Q72

C

X_C0.1u16X50402-2

B

E

NPN-MMBT2222A-7-F_SOT23-RH

C0.1u16X50402-2

1 3 5 7

D

Q73

G

S

N-2N7002P_SOT23-3-HF

RN10

8P4R-270R

ESD-VPORT0603102MV05-RH

Use low-pass filter to prevent glitches duringplug/unplug events.

OC#0

C642 C0.1u16X50402-2C642 C0.1u16X50402-2

OC#1

OC#116,19 OC#216,19

OC#516,30 OC#616

C643 C0.1u16X50402-2C643 C0.1u16X50402-2

OC#2

C644 C0.1u16X50402-2C644 C0.1u16X50402-2

OC#5

C645 C0.1u16X50402-2C645 C0.1u16X50402-2

OC#6

C646 C0.1u16X50402-2C646 C0.1u16X50402-2

SVCC1

2 4 6 8

SVCC1

SVCC2

SVCC3

RUSB3_SVCC1

RUSB3_SVCC2

FUSB3_SVCC1

FUSB3_SVCC2

R586 10KR1%0402R586 10KR1%0402 R585 15KR1%0402R585 15KR1%0402

R789 10KR1%0402R789 10KR1%0402 R797 15KR1%0402R797 15KR1%0402

R625 10KR1%0402R625 10KR1%0402 R587 15KR1%0402R587 15KR1%0402

R782 10KR1%0402R782 10KR1%0402 R783 15KR1%0402R783 15KR1%0402

R107 10KR1%0402R107 10KR1%0402 R106 15KR1%0402R106 15KR1%0402

R626 10KR1%0402R626 10KR1%0402 R588 15KR1%0402R588 15KR1%0402

R772 10KR1%0402R772 10KR1%0402 R777 15KR1%0402R777 15KR1%0402

OC#0

OC#1

OC#2

OC#3

OC#4

OC#5

OC#6

OC#3 16,19,30

OC#4 16,30

VCC5_SB

R591

RUSB3_SVCC2

R591 X_4.7KR0402

R592

R592 10KR0402

10KR0402

A A

SLP_S5#_R77136,37

R593 8.2KR0402R593 8.2KR0402

R594

10KR0402

B

C652

C652 C1u10X5-RH

C1u10X5-RH

CE

Q81

X_4.7KR0402

DS

G

Q80

N-2N7002P_SOT23-3-HF

USB_EN

C651

X_C0.1u16X50402-2

RN15

1

2

3

4

5

6

7

8

Q78

8P4R-270R

N-2N7002P_SOT23-3-HF

MICRO-START INT'L CO.,LTD.

Title

FUSB2_VCC

RN16

1

2

3

D

G

S

D

G

S

4

5

6

7

8

8P4R-270R

Q79

Q79 N-2N7002P_SOT23-3-HF

N-2N7002P_SOT23-3-HF

Title

Size Document Number Rev

Custom

Date: Sheet

MICRO-START INT'L CO.,LTD.

USB POWER/DISCHARGE

Kaveri-VC 0A

31 40Tuesday, June 18, 2013

of

N-SST3904_SOT23

8

7

6

5

4

3

2

1

iSATA CONNECTOR

Multiple eSATA function

SATA_RX0+17 SATA_RX0-17

SATA_TX0-17 SATA_TX0+17

D D

SATA_RX1+17 SATA_RX1-17

SATA_TX1-17 SATA_TX1+17

5

SATA_RX0+

C655 C0.01u16X0402C655 C0.01u16X0402

1 2

SATA_RX0-

C659 C0.01u16X0402C659 C0.01u16X0402

1 2

SATA_TX0-

C662 C0.01u16X0402C662 C0.01u16X0402

1 2

SATA_TX0+ ST_TX0

C665 C0.01u16X0402C665 C0.01u16X0402

1 2

SATA_RX1+

C656 C0.01u16X0402C656 C0.01u16X0402

1 2

SATA_RX1-

C666 C0.01u16X0402C666 C0.01u16X0402

1 2

SATA_TX1-

C668 C0.01u16X0402C668 C0.01u16X0402

1 2

SATA_TX1+ ST_TX1

C667 C0.01u16X0402C667 C0.01u16X0402

1 2

ST_RX0 ST_RX#0

ST_TX#0

ST_RX1 ST_RX#1

ST_TX#1

Layout:For Gen 3.0,trace length within 3''

SATA1

X1

7

RX+

6

RX-

5

GNDGND

4

TX-

3

TX+

2

GND

1

X2

SATA7PM_RED-ST-RH-1

SATA2

X1

7

RX+

6

RX-

5

GNDGND

4

TX-

3

TX+

2

GND

1

X2

SATA7PM_RED-ST-RH-1

4

SATA_RX2+

SATA_RX2+17 SATA_RX2-17

SATA_TX2-17 SATA_TX2+17

SATA_RX3+17 SATA_RX3-17

SATA_TX3-17 SATA_TX3+17

C653 C0.01u16X0402C653 C0.01u16X0402

SATA_RX2-

C657 C0.01u16X0402C657 C0.01u16X0402

SATA_TX2-

C660 C0.01u16X0402C660 C0.01u16X0402

SATA_TX2+

C663 C0.01u16X0402C663 C0.01u16X0402

SATA_RX3+

C777 C0.01u16X0402C777 C0.01u16X0402

SATA_RX3-

C798 C0.01u16X0402C798 C0.01u16X0402

SATA_TX3-

C810 C0.01u16X0402C810 C0.01u16X0402

SATA_TX3+ ST_TX3

C809 C0.01u16X0402C809 C0.01u16X0402

1 2 1 2

ST_RX2 ST_RX#2

ST_TX#2 ST_TX2

ST_RX3 ST_RX#3

ST_TX#3

SATA3

X1

7

RX+

6

RX-

5

GNDGND

4

TX-

3

TX+

2

GND

1

X2

SATA7PM_RED-ST-RH-1

SATA4

X1

7

RX+

6

RX-

5

GNDGND

4

TX-

3

TX+

2

GND

1

X2

SATA7PM_RED-ST-RH-1

3

eSATA Conn. WO re-driver

Layout:For onboard eSATA conn. without redriver IC,trace length within 6''

C654 C0.01u16X0402C654 C0.01u16X0402

ST_TX4 ST_TX#4

ST_RX#4 ST_RX4

1 2

C658 C0.01u16X0402C658 C0.01u16X0402

1 2

C661 C0.01u16X0402C661 C0.01u16X0402

1 2

C664 C0.01u16X0402C664 C0.01u16X0402

1 2

D61

1 2

4 5

3

SATA_RX4+17 SATA_RX4-17

SATA_TX4-17

SATA_TX4+17

ST_TX4

10

NC

ST_TX#4

9

NC

ST_RX#4

7

NC

ST_RX4

6

NC

X_ESD-PDY050003-2510-RH

8

2

ST_RX4 ST_RX#4

ST_TX#4 ST_TX4

X1

7 6 5 4 3 2 1

X2

ESATA

X1

GNDGND

GND

X2

SATA_7P-4

RX+

RX-

TX-

TX+

1

CPUFAN/SYSTEMFAN/POWE

R

FAN

VCC5

R595

R600

4.7KR0402

G

Q83

Q83 N-2N7002P_SOT23-3-HF

N-2N7002P_SOT23-3-HF

R595

4.7KR0402

D

Q82

Q82 N-2N7002P_SOT23-3-HF

N-2N7002P_SOT23-3-HF

S

R601 100R0402R601 100R0402

VCC5

C C

CPUFAN_PWM

CPUFAN_PWM34

VCC5

R599

D

4.7KR0402

G

S

VCC5

R603

R608

4.7KR0402

Q85

Q85 N-2N7002P_SOT23-3-HF

N-2N7002P_SOT23-3-HF

R603

4.7KR0402

D

Q84

G

S

N-2N7002P_SOT23-3-HF

R609 100R0402R609 100R0402

VCC5

SYSFAN_PWM

SYSFAN_PWM34

B B

VCC5

R607

4.7KR0402

D

G

S

VCC5

R611

R616

4.7KR0402

Q87

Q87 N-2N7002P_SOT23-3-HF

N-2N7002P_SOT23-3-HF

R611

4.7KR0402

D

Q86

G

S

N-2N7002P_SOT23-3-HF

R618 100R0402R618 100R0402

VCC5

PWRFAN_PWM34

VCC5

R615

4.7KR0402

D

G

S

VCC5

D62

X_1N4148W-F_SOD123-RH

VCC5

D65

X_1N4148W-F_SOD123-RH

VCC5

D68

X_1N4148W-F_SOD123-RH

CPU FAN

+12V

R598 4.7KR0402R598 4.7KR0402

CPUFAN_PWM1

C669

C669 C0.1u16X50402-2

C0.1u16X50402-2

+

12

EC46

EC46 CD100u16EL5-RH-1

CD100u16EL5-RH-1

SYSTEM FAN

+12V

D67 1N4148W-F_SOD123-RHD67 1N4148W-F_SOD123-RH R606 4.7KR0402R606 4.7KR0402

SYSFAN_PWM1

C674

C674 C0.1u16X50402-2

C0.1u16X50402-2

+

12

EC47

EC47 CD100u16EL5-RH-1

CD100u16EL5-RH-1

POWER FAN

+12V

D70 1N4148W-F_SOD123-RHD70 1N4148W-F_SOD123-RH R614 4.7KR0402R614 4.7KR0402

PWRFAN_PWM1

R619

R619 0R1206

0R1206

AUX_12VAUX_12V

C675 C0.1u16X50402-2C675 C0.1u16X50402-2

+

12

EC48

EC48 CD100u16EL5-RH-1

CD100u16EL5-RH-1

R597 27KR0402R597 27KR0402D64 1N4148W-F_SOD123-RHD64 1N4148W-F_SOD123-RH

CPU_FAN

4 3 2 1

BH1X4B_brown-RH

R605 27KR0402R605 27KR0402

SYS_FAN1

4 3 2 1

BH1X4B_white-RH

R613 27KR0402R613 27KR0402

PWR_FAN

4 3 2 1

BH1X4B_white-RH

0 to +3 V amplitude fan tachometer input.

CPUFAN_TAC 34

R602

R602 10KR0402

10KR0402

SYSFAN_TAC 34

R610

R610 10KR0402

10KR0402

PWRFAN_TAC 34

R617

R617 10KR0402

10KR0402

N32-1030451-H06 3pin fan

CPUFAN_PWM1 SYSFAN_PWM1 PWRFAN_PWM1

C670 X_C0.1u16X50402-2C670 X_C0.1u16X50402-2 C671 X_C0.1u16X50402-2C671 X_C0.1u16X50402-2 C672 X_C0.1u16X50402-2C672 X_C0.1u16X50402-2

HDD FAN

+12V

D71

R622

A A

5

4

HDD_FAN

4 3 2 1

BH1X4B_white-RH

R622

4.7KR0402

+12V

+

12

EC49

EC49 CD100u16EL5-RH-1

CD100u16EL5-RH-1

1N4148W-F_SOD123-RH

R621 27KR0402R621 27KR0402

3

R620

R620 10KR0402

10KR0402

TP56TP56

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Custom

Date: Sheet

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

SATA//eSATA/PS2/ FAN

Kaveri-VC 0A

32 40Tuesday, June 18, 2013

1

of

TPM

5

4

3

2

1

D D

U24

LPC_AD0 TPM_LAD0

LPC_AD015,34 LPC_AD115,34 LPC_AD215,34 LPC_AD315,34

LPC_FRAME#15,34

A_RST#15,34

SERIRQ15,34

TPM_CLK15,19

C C

FCH_GPIO7317

FCH_GPIO7417

B B

R628 0R0402R628 0R0402 R631 0R0402R631 0R0402

LPC_AD1 LPC_AD2

R629 0R0402R629 0R0402

LPC_AD3

R634 0R0402R634 0R0402

R636 33R0402R636 33R0402

A_RST# TPM_LPCPD# TPM_CLKRUN#

CLKRUN#15

TPM_LAD1 TPM_LAD2 TPM_LAD3

TPMRST#

TPM_BADD

TPM_GPIO

R641 X_0R0402R641 X_0R0402

R643 X_0R0402R643 X_0R0402

R645 X_0R0402R645 X_0R0402

26

LAD0

23

LAD1

20

LAD2

17

LAD3

22

LFRAME#

16

LRESET#

28

LPCPD#

15

NC9

27

SERIRQ

21

LCLK

9

VNC2

8

VNC1

1

NC1

2

NC2

ST33ZP24AR28PVSC-RH

VCC3

R640

4.7KR0402

TPM_LPCPD# TPM_CLKRUN#

TPM_GPIO

TPM_CLKRUN#

R647

X_0R0402

NC10 VPS2

NC6 NC4

GND

NC11

GND

NC3

VPS1

GND

NC7 NC8

NC5

PP

NCT_VDD1

19 24

NCT_VBAT

12

NCT_VSB

5 18

NCT_VSS

25 4

3

ST_VDD

10

ST_VSS

11 13 14

TPM_PP

7 6

VCC3

R642 X_10KR0402R642 X_10KR0402

TPMRST# TPM_PP TPM_BADD

C687 C470p50N0402-HFC687 C470p50N0402-HF R644 X_10KR0402R644 X_10KR0402 R646 X_10KR0402R646 X_10KR0402

NCT:stuff ST:unstuff

R630 X_0R0402R630 X_0R0402

R635 X_0R0402R635 X_0R0402

R637 X_0R0402R637 X_0R0402

R638 0R0402R638 0R0402 R639 0R0402R639 0R0402

NCT:unstuff ST:stuff

VCC3

Reserve For Winbond

R632 X_0R0402R632 X_0R0402 R633 X_0R0402R633 X_0R0402

VCC3

VBAT VCC3_SB

TPM chip

VCC3

C677

VCC3_SB

C681

C679

C678

C0.1u25X50402-HF

X_C0.1u25X50402-HF

C682

C1U6.3Y0402-RH

C0.1u25X50402-HF

C683

C680

C1U6.3Y0402-RH

C0.1u25X50402-HF

C684

C0.1u25X50402-HF

X_C10u6.3X5-HF

A A

MICRO-START INT'L CO.,LTD.

Title

TPM

Size Document Number Rev

B

Date: Sheet

5

4

3

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

Kaveri-VC ci20313 0A

Kaveri-VC 0A

1

of

33 40Tuesday, June 18, 2013

5

C689 X_C0.1u16X50402-2C689 X_C0.1u16X50402-2 C690 C22p50N0402C690 C22p50N0402

C691 C22p50N0402C691 C22p50N0402 C692 15p50N0402C692 15p50N0402

SERIRQ15,33

LPC_AD[3..0]15,33

D D

A_RST#15,33

PCI_CLK_SIO15 LPC_FRAME#15,33

SIO_48M_CLK15

PWRFAN_TAC32

PWRFAN_PWM32

CPUFAN_TAC32

CPUFAN_PWM32

SYSFAN_TAC32

SYSFAN_PWM32

C704 C4.7u6.3X5C704 C4.7u6.3X5

C C

SIO_GP41_SMI#16

R708 4.7KR0402R708 4.7KR0402

VCC3

B B

PCI_CLK_DEBUG15

SUPER I/O STRAPPING RESISTOR

VCC3

A A

VCC3_ALW

A_RST# PCI_CLK_SIO

LPC_FRAME# SIO_48M_CLK

R658 0R0402R658 0R0402

LPC_AD0

R660 0R0402R660 0R0402

LPC_AD1

R663 0R0402R663 0R0402

LPC_AD2

R665 0R0402R665 0R0402

LPC_AD3

R667 0R0402R667 0R0402

A_RST# PCI_CLK_SIO SERIRQ_SIO LPC_FRAME#

SIO_48M_CLK LPC_AD0_SIO LPC_AD1_SIO LPC_AD2_SIO LPC_AD3_SIO

VIN_VDDP/VDDR

VIN_VDIMM VIN_CPUCORE SIO_VREF VR_TEMP_DA EXT_SYS_TEMP

SIO_GP41_SMI#

RIA# DCDA#

SOUTA

SINA

DTRA# RTSA#

DSRA# CTSA#

SIO_WAKE

AMDPWR_EN

SIO_GP41_SMI#

LPC Debug

LPC_DEBUG1

1 2

A_RST#

3

5

LPC_AD1 LPC_AD2

9

LPC_AD3

11

LPC_FRAME#

13

BH2X7[10]-2PITCH_BLACK-RH-1

2E_4E_SEL

R702 1KR0402R702 1KR0402 R703 X_1KR0402R703 X_1KR0402

R704 1KR0402R704 1KR0402 R705 X_1KR0402R705 X_1KR0402

R706 1KR0402R706 1KR0402

R764 4.7KR0402R764 4.7KR0402

R713 X_47KR1%0402-RHR713 X_47KR1%0402-RH

RTSA#

24M_48M_SEL

DTRA#

TEST_MODE1

SOUTA

AMDPWR_EN

Pull High &Reserved

SERIRQ_SIOSERIRQ LPC_AD0_SIO LPC_AD1_SIO LPC_AD2_SIO LPC_AD3_SIO LPC_FRAME#

U25

10

LRESET#

2

PCICLK

3

SERIRQ

9

LFRAME#

1

IOCLK

7

LAD0

6

LAD1

5

LAD2

4

LAD3

64

GP04/AUXFANIN0

59

GP00/AUXFANOUT0

60

CPUFANIN

61

CPUFANOUT

62

SYSFANIN

63

SYSFANOUT

48

VIN2/VLDT

49

VDIMM/VIN3

51

CPUVCORE

52

VREF

53

VIN4/AUXTIN0

54

CPUTIN

22

MSDA/SDA/GP42/BEEP

23

MSCL/SCL/GP41

20

GP87/RIA#

19

GP86/DCDA#

18

GP85/SOUTA(TEST MODE1)

17

GP84/SINA

16

(24M_48M_SEL)DTRA#/GP83

15

(2E_4E_SEL)RTSA#/GP82

14

DSRA#/GP81

13

CTSA#/GP80

43

CIRRX/GP24/IRRX1

44

GP25/CIRTX1/IRTX1(AMDPWR_EN)

NCT5533D-RH

VCC3

4

LPC_ID0LPC_AD0

6 87

12

R699

14

10KR0402

15

16 VCC

18

VCC3

R661X_4.7KR0402 R661X_4.7KR0402

R664X_4.7KR0402 R664X_4.7KR0402 R666X_4.7KR0402 R666X_4.7KR0402 R668X_4.7KR0402 R668X_4.7KR0402 R669X_4.7KR0402 R669X_4.7KR0402

Wakeupevent

VCC5

SIO_WAKE

NCT5533D POWER ON STRAPPING PIN

Name 0 PowerPIN

24M_48M_SEL

TEST_MODE1

44

5

VCC3

KBRST#

GA20M

KDAT/GP20

KCLK/GP21 MDAT/GP22 MCLK/GP23

PSIN#

PSOUT#

RSMRST#

SLP_S3# SLP_S5# ATXPGD

PSON#/AMD_PSON#

PWROK/AMD_PWROK

RSTOUT0#/GP74 RSTOUT1#/GP75

GP26/TSIC

PECI/TSID

GP56/VCORE_EN

GP57/VLDT_EN

DPWROK#

GP54/SLP_SUS#

PCHVSB

DEEP_S5/3VSBSW

AVCC

3VSB VBAT

CPUD-/AGND



C714 X_C0.01u16X0402C714 X_C0.01u16X0402

R700 0R0402R700 0R0402

2E2E_4E_SEL

24MHz

TEST MODE 1 DSISABLE

AMD PWR SEQ

R648 X_10KR0402R648 X_10KR0402 R650 X_10KR0402R650 X_10KR0402

12 11 27 26 25 24

29 28 47 31 38 36 30 37 35 34

56 58 57

VTT

40 39 33 41 45 32

8

VCC

50

21 46

55

42

VSS

VCC3_ALW

R697

X_4.7KR0402

B

Q91

Q91 X_N-SST3904_SOT23

X_N-SST3904_SOT23

C E

5VDIMM

KBRST#

A20GATE KBDATA KBCLK MSDATA MSCLK

PSOUT#

IO_RSMRST#

SIO_AMD_PWRGD PWR_LED LANPWR_EN

SIO_TSI_CLK SIO_TSI_DAT

SIO_VCORE_EN SIO_VLDT_EN

R683 X_10KR0402R683 X_10KR0402

PCHVSB_DETECT DEEP_S5

SIO_AVCC

16 mil

SIO_HWM_AGND

VCC3_ALW

4E

48MHz

TEST MODE1 ENABLE

ENABLE AMD PWR SEQ

4

A20GATE KBRST#

R656

4.7KR0402

USB_EN 30,31

KBRST# 16 A20GATE 16

PSIN# 38 PSOUT# 16 IO_RSMRST# 16

SLP_S3# 16,30,36,37

SLP_S5# 16,31,36,37

ATX_PWROK 7,25,30,36,37,38 PS_ON# 35,38

PWR_LED 38

LANPWR_EN 36

R679 0R0402R679 0R0402 R680 0R0402R680 0R0402

USB_EN

R684 4.7KR0402R684 4.7KR0402

R685 0R0402R685 0R0402

VBAT_IO

R698

10KR0402

PE_WAKE# 16,23,24,25,27

1

4

VCC3_SB

APU_SIC 10 APU_SID 10

VCCP

SYS5VSB_OFF 30,38

C709

X_C1u10X

VCC

VSB

VSBAMDPWR_EN DISABLE

R652 4.7KR0402R652 4.7KR0402 R655 1KR1%0402R655 1KR1%0402

R689

1KR0402

VCC3

L52 600L500mA-300_0805L52 600L500mA-300_0805

SIO_HWM_AGND

Description

I/O Configuration Address

Clock Source Selection

1K Pull Low Recommend

AMD SEQ FUNCTION

IO_RSMRST#

PSOUT#

C180p50N0402

VBAT

C694

C711

VCC3

C706 C0.1u10X0402C706 C0.1u10X0402

C705 C10u6.3X50805C705C10u6.3X50805

VCC3_ALW

C708C10u6.3X50805C708C10u6.3X50805

C707 C0.1u10X0402C707 C0.1u10X0402

VCCP

VCC_DDR

CPU_VDD

C712

C0.1u10X0402

C10u6.3X50805

L53

600L500mA-300_0805

3

TEMP SENSOR

SIO_VREF

External Thermal diode Mode Current mode

VR_TEMP_DA

SIO_HWM_AGND VR_TEMP_DC

CHASSIS_ID216 CHASSIS_ID116

MB_ID116 MB_ID016

Voltage Divider

9 voltage sensors (including VCC, AVCC, VSB, VBAT)

R691 10KR1%0402R691 10KR1%0402

R694 10KR1%0402R694 10KR1%0402

R786 10KR1%0402R786 10KR1%0402

VIN 0~2.048V

SIO_AVCC

R693 X_4.7KR0402R693 X_4.7KR0402

R695 X_4.7KR0402R695 X_4.7KR0402

R785 X_4.7KR0402R785 X_4.7KR0402

SERIAL PORT 1

VCC5

C713

C0.1u16X50402-2

NRTSA NDSRA# NCTSA# NRIA

NDCDA# NSOUTA NSINA NDTRA

Stuff When COM Port unstuff

SINA DSRA# DCDA# CTSA# RIA#

3

NRIA NCTSA# NDSRA# NSINA NDCDA#

RTSA# DTRA# SOUTA

C717 C330p50XC717 C330p50X C718 C330p50XC718 C330p50X C719 C330p50XC719 C330p50X C720 C330p50XC720 C330p50X

C721 C330p50XC721 C330p50X C722 C330p50XC722 C330p50X C723 C330p50XC723 C330p50X C724 C330p50XC724 C330p50X

R707 X_4.7KR0402R707 X_4.7KR0402 R709 X_4.7KR0402R709 X_4.7KR0402 R710 X_4.7KR0402R710 X_4.7KR0402 R711 X_4.7KR0402R711 X_4.7KR0402 R712 X_4.7KR0402R712 X_4.7KR0402

C2200p50X0402

CP16 X_CPCP16 X_CP

CHASSIS_ID2 CHASSIS_ID1

MB_ID1 MB_ID0

VIN_CPUCORE SIO_HWM_AGND VIN_VDIMM SIO_HWM_AGND

VIN_VDDP/VDDR SIO_HWM_AGND

U26

20

VCC

2

RA1

3

RA2

4

RA3

7

RA4

9

RA5

16

DA1

15

DA2

13

DA3

11

GND

GD75232_SSOP20

Place Within APU solder side area

R651

X_10KR1%0402

C696

R649 X_0R0402R649 X_0R0402

R653 0R0402R653 0R0402

R657 0R0402R657 0R0402 R678 X_0R0402R678 X_0R0402

CHASSIS_ID1

CHASSIS_ID2

MB_ID0

MB_ID1

CHASSIS_ID1 CHASSIS_ID2

Place close to VRM VDDNB MOSFET(Q37)

VR_TEMP_DA2

C697

C2200p50X0402

VR_TEMP_DC2

External Thermal diode Mode Current mode

EXT_SYS_TEMP

R670 10KR0402R670 10KR0402 R671 X_10KR0402R671 X_10KR0402

R672 10KR0402R672 10KR0402 R673 X_10KR0402R673 X_10KR0402

R674 X_10KR0402R674 X_10KR0402 R675 1KR0402R675 1KR0402

R676 X_10KR0402R676 X_10KR0402 R677 X_10KR0402R677 X_10KR0402

C702 X_C0.1u16X50402-2C702 X_C0.1u16X50402-2 C703 X_C0.1u16X50402-2C703 X_C0.1u16X50402-2

SIO AMD POWER SEQUENCE

The timing delay between each step is 10~15 mS

PIN 38 SLP_S5# PIN 31 SLP_S3# PIN 30 PSON# DESCRETE VDIMM_EN CIRCUIT PIN 49 VDIMM_IN PIN 40 VCORE_EN

SIO_VCORE_EN

PIN 51 VCORE_IN

PIN 39 VLDT_EN

SIO_VLDT_EN

PIN 48 VLDT_IN

PIN 37 AMD_PWRGD

SIO_AMD_PWRGD

SIO_PWRGD INCLUDES TRADITIONAL VCC3 POWER READY CONDITION

VDD

RY1 RY2 RY3 RY4 RY5

DY1 DY2 DY3

VSS

VCC3

1 19 18 17 14 12

5 6 8 10

NDCDA# NSINA NSOUTA

NRIA

S-BAT54C_SOT23

C710 C0.1u25XC710 C0.1u25X

+12COM_1 RIA# CTSA# DSRA# SINA DCDA#

NRTSA NDTRA NSOUTA

-12COM_1

C716 C0.1u25XC716 C0.1u25X

D76

R690 0R0402R690 0R0402

R692 0R0402R692 0R0402

R696 0R0402R696 0R0402

10

X

Y

2

CE

B

Q89

N-SST3904_SOT23

C699 C2200p50X0402C699 C2200p50X0402 SEN_HEADER1

SEN_HEADER1

1 2

CP17 X_CPCP17 X_CP

3

L51

L51 X_120L600mA-250

X_120L600mA-250

D73 1N4148W-F_SOD123-RHD73 1N4148W-F_SOD123-RH

D74 1N4148W-F_SOD123-RHD74 1N4148W-F_SOD123-RH

1 2 3 4 5

VCC3_SB

+12V

COM1

1211

6 7 8 9

DSUB-COMM_GREEN-RH-16

Z

N_RI 16

H2X3[4]M_BLACK-RH

VCC3_SB

VCORE_EN_R 7,37

CPU_VDDP_VDDR_EN 37

FCH_PWRGD 16,37

-12V

NDSRA# NRTSA NCTSA# NRIANDTRA

2

RT5

X_10KRT1%

65

CHASSIS TYPE 25L 17L 13L 10L

MB_ID0 MB_ID1

SIO_HWM_AGND

DEFAULT

0

VR_TEMP_DA1

CE

C758

X_C2200p50X0402

CHASSIS_ID2

CHASSIS_ID1

C700 X_C0.1u16X50402-2C700 X_C0.1u16X50402-2 C701 X_C0.1u16X50402-2C701 X_C0.1u16X50402-2

1

00

0B1.0 1

CHASSIS_ID2CHASSIS_ID1

Q90

X_N-SST3904_SOT23

11 0 10

PS2 Mouse /Keyboard

C0.1u16X0402

MSDATA MSCLK

KBDATA KBCLK

MS_DT_C MS_CK_C

B

VR_TEMP_DC1

RUSB3_SVCC1

C715

RUSB3_SVCC1

D75

614

ESD-AOZ8902CIL-HF

1

RT6

X_10KRT1%

246

8

RN17

RN17 8P4R-2.7KR0402

8P4R-2.7KR0402

135

7

FB2 33RFB2 33R FB3 33RFB3 33R

FB4 33RFB4 33R FB5 33RFB5 33R

C725

C725 X_C0.1u16X0402

X_C0.1u16X0402

52

KB_DT_C KB_CK_C

3

Title

SUPER I/O NCT5533D

Size Document Number Rev

Custom

Kaveri-VC 0A

Date: Sheet

MS_DT_C

7 8

MS_CK_C

11 12

KB_DT_C

1 2

KB_CK_C

5 6

C730 C220p50N0402C730 C220p50N0402

C728 C220p50N0402C728 C220p50N0402

C727 C220p50N0402C727 C220p50N0402

C729 C220p50N0402C729 C220p50N0402

MICRO-START INT'L CO.,LTD.

1

131415

KB/MS

16

17

10

9

MS

4

3

KB

34 40Tuesday, June 18, 2013

of

5

4

3

2

1

VCC3&VCC5 Power

CHOKE9

+12V+12V_VCC

+12V +12V

R715

30KR0402

C736

R726

47KR0402

C744 C47p50NC744 C47p50N

R729

4.12KR1%0402-RH

R734

47KR0402

C753 C47p50NC753 C47p50N

R738

6.98KR1%0402-RH

+5V_LDO

5V_LDOEN

R719

11KR1%0402

5VCC_COMP_RC

5VCC_FB

3VCC_COMP_RC

3VCC_FB

D D

+5V_LDO VCC5

C4.7U10X5-HF

R725

VCC5

C C

VCC3

X_COPPER

CP25

1 2

X_COPPER

100R0402

5VCC_COP

R733

100R0402

3VCC_COP

R725

CP21

1 2

C742

5VCC_FB_RC

C2200p50X0402

R727 22KR1%0402-RH-1R727 22KR1%0402-RH-1

C750

3VCC_FB_RC

C2200p50X0402

R736 22KR1%0402-RH-1R736 22KR1%0402-RH-1

C737

C1u16X50402-HF

VCC5_EN

C0.01u25X0402

5VCC_COMP

VCC3_EN

C0.01u25X0402

3VCC_COMP

X_1KR0402

R716

1R0805

U23_VIN

11 22 26 27 28

C735

C1u16X5

10

C743

9

8

12

C751

13

14

R739

10KR0402

PG VIN 5V_LDOEN 5V_LDOOUT 5V_LDOBYP

EN2/SS2

COMP2

FB2

EN1/SS1

COMP1

FB1

R740

X_0R

R717

U23_SKIP

LDO2_EN

NCP81038

QFN28_SMDQ102

+12V

R714

X_10KR0402

24

23

LDO2_EN

U27

SKIP25E_PAD

29

BOTTOM PAD CONNECT TO GND Through 5 VIAs

LDO2_OUT

PGND2

GL1/FSET

PGND1

SWN2

CSN2

SWN1

CSN1

BST2

GH2

GL2

CSP2

BST1

GH1

CSP1

C733

X_C4.7U10X5-HF

VCC5_BOOT

2

VCC5_HG

1

VCC5_PHASE

3

VCC5_LG

4 5 7

R723 14.7KR1%0402R723 14.7KR1%0402 C741 C0.1u16X50402-2C741 C0.1u16X50402-2

6

VCC3_BOOT

20

VCC3_HG

21

VCC3_PHASE

19

VCC3_LG_FSET

18 17 15

R735 21KR1%0402-HER735 21KR1%0402-HE C754 C0.1u16X50402-2C754 C0.1u16X50402-2

16

VCC5_BOOT_R

R718

2.2R0805

R720 1R0805R720 1R0805

X_COPPER

1 2

VCC5_CSP

R728

2.2R0805

R730 1R0805R730 1R0805

X_COPPER

1 2

VCC3_CSP

CP20

VCC3_BOOT_R

CP22

VCC3_LG_FSET

R741

9.1KR1%0402

C734

C0.22u25X5-HF

VCC5_HG_R

R721 10KR0402R721 10KR0402

VCC5_LG_C

C740 X_C0.1u16X50402-2C740 X_C0.1u16X50402-2

R724 16.2KR1%0402R724 16.2KR1%0402

Reserve 0.1uf cap for RT8127

C747

C0.22u25X5-HF

VCC3_HG_R

R731 10KR0402R731 10KR0402

VCC3_LG_C

C752 X_C0.1u16X50402-2C752 X_C0.1u16X50402-2

R737 11.3KR1%0402R737 11.3KR1%0402

Working Freq 400KHZ

5

Q92

4 3 2 1

N-PK516BA_PDFN8-HF

5

Q93

4 3 2 1

N-PK510BA_PDFN8-HF

VCC5_CS_N VCC5_CS_P

+12V_VCC

5

Q95

4 3 2 1

N-PK516BA_PDFN8-HF

5

Q96

4 3 2 1

N-PK510BA_PDFN8-HF

VCC3_CS_P VCC3_CS_N

Reserve 0.1uf cap for RT8127

C732

C731

C10u16X50805-HF

C1u16X5

5

Q94

4 3 2 1

N-PK510BA_PDFN8-HF

C745

C746

C1u16X5

C10u16X50805-HF

5

Q97

4 3 2 1

N-PK510BA_PDFN8-HF

+

12

EC50

CD100u16SO-HF-1

R722

2.2R1206

VCC5_PH_RC

C739

C739 C2200p50X0402

C2200p50X0402

R732

2.2R1206

VCC3_PH_RC

C749

C749 C2200p50X0402

C2200p50X0402

+

12

EC51

CD100u16SO-HF-1

1 2

CH-1.2u15A1.7m-RH-2

CHOKE10

1 2

CH-1.1u35A1.7m-RH-1

CP18

12

X_COPPER

CHOKE11

1 2

CH-1.1u35A1.7m-RH-1

12

CP23

CP23 X_COPPER

X_COPPER

5V/18A OCP:27~36A 300KHz

VCC5

EC52

C738

EC53

C560u6.3SO-RH

C10u6.3X5-HF

X_C560u6.3SO-RH

+

12

+

CP19

12

X_COPPER

12

CP24

X_COPPER

12

3.3V/17A OCP:26~34A 300KHz

VCC3

C748

EC54

C10u6.3X5-HF

C560u6.3SO-RH

+

12

B B

VCC3&VCC5 Power Enable VCC3&VCC5 Power Output Connector

+5V_LDO

HDD_PWR1

+12V

HDD_PWR1

PWRCONN4P_WHITE-RH-3

2

1

C757

C0.1u16X50402-2

2

1

C854

C0.1u16X50402-2

4

12V

3

12V

GND GND

5

ODD_PWR1

X_PWRCONN4P_WHITE-RH-3

4

12V

3

12V

GND GND

5

C855

C0.1u10X0402

3

VCC5

C759

C0.1u10X0402

VCC5

VCC3

C853

C0.1u10X0402

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Date: Sheet of

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

VCC3 & VCC5

Kaveri-VC

0A

of

35 40Tuesday, June 18, 2013

1

R742

30KR0402

VCC3_EN

D

5

Q51_G

C756

C756 X_C1u10X5-RH

X_C1u10X5-RH

+5V_LDO

R745

10KR0402

C761

C761 X_C1u10X5-RH

X_C1u10X5-RH

R748 X_0R0402R748 X_0R0402

R744

G

30KR0402

S

Q98

N-2N7002ET1G_SOT23-3-HF

VCC5_EN

D

R747

G

10KR0402

S

Q99

N-2N7002ET1G_SOT23-3-HF

C755

C755 C1U6.3Y0402-RH

C1U6.3Y0402-RH

C760

C760 C1U6.3Y0402-RH

C1U6.3Y0402-RH

4

R743 0R0402R743 0R0402

PS_ON#34,38

PS_ON# Q49_G

R746 0R0402R746 0R0402

A A

VCC5_EN VCC3_EN

5

4

3

2

1

+LAN_3VSB POWER

VCC3_SB VCC3_SB

5VDIMM FOR DDR

R750 510R0402R750 510R0402

D D

C C

VCC5

R752 10KR0402R752 10KR0402

ATX_PWROK7,25,30,34,37,38

SLP_S3#_R769

VCC5_SB

CRB: MODE Low support S0/S3 Hi support S0/S3/S5

SLP_S5#_R771

R758 X_4.7KR0402R758 X_4.7KR0402

SLP_S3#16,30,34,37 SLP_S5#16,31,34,37

5VDIMM_5V

C767 X_C0.1u16X50402-2C767 X_C0.1u16X50402-2

U29

S3#55VSB_DRV

6

S5#

MODE

4

MODE

R759

0R0402

R769 15R0402R769 15R0402 R771 100R0402R771 100R0402

R753 10R0402R753 10R0402 C768 X_C0.1u16X50402-2C768 X_C0.1u16X50402-2

1

2

5VSB

5VCC

5VCC_DRV

GND

3

UP7501M8_SOT23-8-RH

SLP_S3#_R769 SLP_S5#_R771

5VSBDRV1

7

5VDRV1

8

+12V

SLP_S5#_R771 31,37

VCC5_SB

R760

1.5KR-RH

C770 C0.018u16X0402-RHC770 C0.018u16X0402-RH

C773

C0.022u50X

G

R761

200KR0402

R763

56KR1%0402

5VDRV1

5VSBDRV1

VCC5_SB

G

VCC5

Q100

D S

P-P06P03LCGA_SOT89-3-HF

D

Q103

S

N-45N02_TO252-RH

5VDRV1_EN 30,31

5VDRV1 30,31

5VSBDRV1 30,31

5VDIMM

C772

X_C0.1u16X50402-2

ATX_5VSB

R755

4.7KR0402

4.7KR0402 R756

R756

56KR1%0402

LANPWR_EN34

VCC3_SB +LAN_3VSB

56KR1%0402

R762

X_0R0805

R754 X_0R0402R754 X_0R0402

C771 C1u16X5-RHC771 C1u16X5-RH

N-SST3904_SOT23

R749

4.7KR0402

B

Q102

CE

Q101

G

P-P06P03LCGA_SOT89-3-HF

D S

C769

C769 X_C1u6.3X50402-HF

X_C1u6.3X50402-HF

12

+

EC55

EC55 CD100u16EL5-RH-1

CD100u16EL5-RH-1

C22u6.3X50805-RH

+LAN_3VSB

C774

C775

C1u6.3X50402-HF

ATX_5VSB

C762

C10u10X50805-HF-2

Pd=( Vin - Vout] * Imax = (5 - 2.5) V * 0.2 Amp = 0.5 W

VCC3_ALW POWER

C763

C0.1u16X50402-2

mach@Stuff when turn off VCC3_WAKE on S5 state

U28

VDD1VOUT

3

EN

5

GND

ADJ

GS7116S5-ADJ-R_SOT23-5-RH

2

4

0.8 V

C764

C0.1u16X50402-2

R751

3.16KR1%0402-RH

R2

R757

1KR1%0402

Vo=0.8*(R1+R2)/R1

R1

VCC3_ALW

C766

C765

C22u6.3X51206

C10u10X50805-HF-2

VCC3_SB POWER

VCC5_SB

VCC3_SB

VCC5_SB

R774 0R0402R774 0R0402

CPU VDDA_25 POWER

VCC5_SB

R778 10RR778 10R

R780 10KR0402R780 10KR0402

ATX_PWROK7,25,30,34,37,38

VCC3

B B

C789

C787

C10u10X50805-HF-2

X_C0.1u16X50402-2

U32

1

POK

2

EN

3

VIN

5

NC

Pd=( Vin - Vout] * Imax = (3.3 - 2.5) V * 0.75Amp = 0.6 W

C785 X_C0.1u16X50402-2C785 X_C0.1u16X50402-2

4

VDD

VOUT

FB

0.8 V

GND8GND

GS7133SO-R_PSOP8-HF

9

PD=1.9 W

6

7

Layout:Route 50 mils AND 500 mils LONG (USE 2x25 mil TRACES TO EXIT BALL FIELD)

2.5V@0.75 A

R781

R781 2KR1%0402

2KR1%0402

C788

VDDA_25_FB

Vo=0.8*(R1+R2)/R1

R2

R784

X_C0.1u16X50402-2

1.6KR1%/4

R1

VDDA_25

C790

+

12

C10u10X50805-HF-2

EC58

EC58 CD100u16EL5-RH-1

CD100u16EL5-RH-1

C783

C10u10X50805-HF-2

R770 10RR770 10R

R773

X_10KR0402

U31

X_C0.1u16X50402-2

U31

1

POK

2

EN

3

VIN

5

NC

VCC3_SB_POK

VCC3_SB_EN

C784

1.1VDUAL POWER

4

VDD

GND8GND

C780 C1u10X5-RHC780 C1u10X5-RH

6

VOUT

7

FB

GS7133SO-R_PSOP8-HF

9

S0,S1,S3

C781

C0.015u16X0402-RH

1.V@1.3A----D3

0.6A----D2

R775

R775 10KR1%0402

10KR1%0402

R779

3.09KR1%0402-RH

VCC3_SB

+

12

EC57

C782

C10u10X50805-HF-2

CD100u16EL11-HF-2

VCC3

12

+

EC63

CD1000u6.3EL11.5-RH-1

VDDA_25_FB

R790

2.21KR1%0402-RH

Q108

D

N-2N7002

D

G

S

4

VCC3_SB

VOLT_SELECT10,14,20,21,37

VOLT_SELECT 1---VDDA_25:2.5V 0---VDDA_25:1.8V

A A

5

VOLT_SELECT

VCC3_SB

R792 X_0R0402R792 X_0R0402 R793 0R0402R793 0R0402

12

+

EC59

X_CD100u16EL5-RH-1

VCC5_SB

R791 10RR791 10R

VCC3_SB_POK

C794C10u10X50805-HF-2C794C10u10X50805-HF-2

C795 X_C0.1u16X50402-2C795X_C0.1u16X50402-2

Pd=( Vin - Vout] * Imax = (3.3 - 1.1) V * TBD Amp

4

U34

1

POK

VOUT

VDD

2

EN

3

VIN

NC

GND8GND

GS7133SO-R_PSOP8-HF

9

3

FB

PD=1.9W

5

C791 X_C0.1u16X50402-2C791 X_C0.1u16X50402-2

6

C792

7

C0.015u16X0402-RH

0.8 V

Vo=0.8*(R1+R2)/R1

For option

R796 0R0805R796 0R0805

+1.1VDUAL

R794

R2

1KR1%0402

R795

R1

2.61KR1%0402

+1.1VDUAL+1.1VDUAL_D3

C793

C10u10X50805-HF-2

12

+

EC60

CD100u16EL5-RH-1

2

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Custom

Date: Sheet

MICRO-START INT'L CO.,LTD.

ACPI UPI & SYS POWER

Kaveri-VC 0A

1

36 40Tuesday, June 18, 2013

of

POWER EN & PWRGD LOGIC CIRCUIT

5

D D

MEM_1V35#16

MEM_1V35# 1---VCC_DDR:1.35V 0---VCC_DDR:1.5V

VCC_DDR

R825

R825 X_4.7KR0402

X_4.7KR0402

APU_FM2R17,10

OD,10KR PU TO 5V

VRM_PWRGD7

C C

NB_VCC1P1

R842 X_8.2KR0402R842 X_8.2KR0402

FCH_PWRGD_R

B B

A A

VCC3_SBVCC3_SB

R815

R814

X_4.7KR0402

4.7KR0402

Q116D_Q115G

Q116

D

MEM_1V35#

G

S

X_N-2N7002ET1G_SOT23-3-HF

R820 0R0402R820 0R0402

VCC5_SB

R821

R821 10KR0402

10KR0402

VCORE_EN_R

R822

R822 X_4.7KR0402

X_4.7KR0402

DS

Q117

CE

B

Q118

Q118 X_N-SST3904_SOT23

X_N-SST3904_SOT23

D13 S-RB751V-40_SOD323-RHD13 S-RB751V-40_SOD323-RH

D80

S-RB751V-40_SOD323-RH

D81

S-RB751V-40_SOD323-RH

D82 X_S-RB751V-40_SOD323-RHD82 X_S-RB751V-40_SOD323-RH D83 X_S-RB751V-40_SOD323-RHD83 X_S-RB751V-40_SOD323-RH D84 X_S-RB751V-40_SOD323-RHD84 X_S-RB751V-40_SOD323-RH

X_4.7KR0402

B

C819

C819 X_C1u10X5-RH

X_C1u10X5-RH

VCC3_SB

C824 X_C0.1u16X50402-2C824 X_C0.1u16X50402-2

53

U38

VCC

1

A

Y

2

B

GND

X_AHCT1G126GV_SOT23-5-RH

5

Q117

G

X_N-2N7002P_SOT23-3-HF

NBCORE_ENVRM_PWRGDVRM_PWRGD

SYS_PWRGD

CE

Q123

Q123 X_N-SST3904_SOT23

X_N-SST3904_SOT23

Rise time ≤ 50-ms. Fall time ≤ 1-ms Deasserted at least 80-ns before VDDCR_11 drops below 5% of its nominal value

FCH_PWRGD

4

R823

R823 X_4.7KR0402

X_4.7KR0402

C811

C4.7u6.3X50805

VRM_PWRGD CPU_VDDP_VDDR_EN

VRM_PWRGD

SLP_S3#16,30,34,36

ATX_PWROK7,25,30,34,36,38

FP_RST#16,38

VCC5_SB

R837

R843

R843 X_10KR0402

X_10KR0402

R848 X_33R0402R848 X_33R0402

VCC3_SB

G

VCC3_SB

G

D

S

C807

C0.1u16X50402-2

FCH_PWRGD 16,34

R850 10KR0402R850 10KR0402

R812 51.1KR1%0402R812 51.1KR1%0402

Q115

N-2N7002ET1G_SOT23-3-HF

TO VCORE_EN CONTROL

VCORE_EN_R 7,34

R835

R835 X_10KR0402

X_10KR0402

FCH_PWRGD_R

DS

Q122

Q122 X_N-2N7002P_SOT23-3-HF

X_N-2N7002P_SOT23-3-HF

FCH_PWRGD

DDR_FB_R

CPU_VDDP_VDDR_EN 34

4

DDRIII DIMM Power

Vout = 0.8[(R254+R246)/R254]

R934 7.5KR1%0402R934 7.5KR1%0402

VCC5_SB

C776 X_C1000p50X0603C776 X_C1000p50X0603

R932

VCC5_SB

100KR0402

0.75V 2A

VTT_DDR

+

12

C778

EC38

X_CD100u16EL11-HF-2

C800

C10u25X51206-H

C588 X_C10p50N0402C588 X_C10p50N0402

C581 X_C10p50N0402C581 X_C10p50N0402

SLP_S5#16,31,34,36

SLP_S3#16,30,34,36

CPU_VDD Power

R828

20KR0402-2

CPU_VDD_FB_COMP

C813

C0.1u16X0402

VOLT_SELECT

VOLT_SELECT10,14,20,21,36

VOLT_SELECT 1---CPU_VDD:1.2V 0---CPU_VDD:1.05V

NB_VCC1P1 POWER

NBCORE_EN

3

VCC5_SB

R933

5.11R1%0805

C410

C410 C1u16X0603

C1u16X0603

U13

VDIMM_CS

13

CS

EN_DDR3_PWR

10

PGOOD

20

VTT

C580

2

VTTSNS

X_C1u10X

VTT_REF

4

VTTREF

C797

C797 C33000p16X0603

C33000p16X0603

DDR_SLP_S3#

7

S3

DDR_SLP_S5#

8

S5

R681

DDR_SLP_S5#

0R0402

0R0402 R686

R686

DDR_SLP_S3#

0R0402

C812

C1u16X5

10

CPU_VDDP_VDDR_EN CPU_VDD_HG

C814

C22p50N0402

R832

3.16KR1%0402-RH

CPU_VDD_FB

R836

5.36KR1%0402-RH

Q121

D

G

S

N-2N7002

1.1V@4A

VCC3

R844

R844 10KR0402

10KR0402

C825

X_C0.1u16X50402-2

R945

R944

0R0603

VDIMM_VDD

VDIMM_VDDP

11

12

VDD

VDDP

9

TON

18

BOOT

17

UGATE

16

PHASE

15

LGATE

PGND

19

VLDOIN

5

VDDQ

6

FB

VTTGND1GND

PGND

PGND-1

RT8207MZQW_WQFN20-HF

3

14

21

+12V

R824

2.2R0805

U36

PGOOD

7

COMP/EN

8

FB

CPU_VDD_FB

2.2R0805

CPU_VDD_VCC

9

R829

2.2R0805

CPU_VDD_BOOT

6

1

BOOT

3

UG

VCC

CPU_VDD_PH

2

LX

4

LG

GND

GND_EP

VOUT

CPU_VDD_LG

NCP1589L

5

11

R623

19.1KR1%0402

CPU_VDD_SEN

R432 0R0402R432 0R0402

C601

R433

X_C0.01u16X0402

X_13KR

R834

1KR1%0402

C818

CPU_VDD_FB_RC

C6800p25X0402-HF

VDDR&VDDP IS COMBINED BY DEFAULT VDDP_PWMONLY FOR NORMAL OPERATION(VDDR/VDDP COMBINED MODE) VDDR_PWMIS FOR DEBUG/OC MODE (SEPERATE VDDR/VDDP)

U37

1

EN

VCC

2

DRV

GND FB3SS

0.8 V

APL5611CI-TRG_SOT23-6-HF

R847

2.55KR1%0402

3

C416

C416 C1u16X50603

C1u16X50603

VDIMM_TON

VDIMM_BST

VDIMM_HG

VDIMM_PHASE

VDIMM_LG

VDIMM_VDDQ

DDR_FB

+12V

D77

D77 BAT54C_SOT23

BAT54C_SOT23

YZX

CPU_VDD_BOOT_R

R431 1R0805R431 1R0805

R833

75R1%0402

6 5 4

R935

1MR1%0402-2

C579

X_C1u25X5-HF

R943

0R0603

R947

0R1206

C593

C593 X_C1u10X

X_C1u10X

C586

C586 X_C1u10X

X_C1u10X

R682

R682 X_0R0402

X_0R0402

C612 C0.1u16X0402C612 C0.1u16X0402

C815

C0.22u25X5-HF

R826

2.2R0805

R827 10KR0402R827 10KR0402

Stuff 1K for ISl6341Stuff 1.1K for ISl6341

+12V

NB_VCC1P1_SS

C827

1 2

R604 0R0402R604 0R0402

C822

C822 C1u16X5

C1u16X5

C0.01u16X0402

VDIMM_HG_R

VDIMM_BST_RC

C779

C779 C0.1u25X

C0.1u25X

R948

0R1206

R596

R596 X_0R0402

X_0R0402

VCC5_SB

CPU_VDD_HG_R

CPU_VDD_LG_R

C607

X_C22p50N0402

R845 100R1%0805R845 100R1%0805

R846

R846 10KR1%0402

10KR1%0402

C828

C828 C100p50N0402

C100p50N0402

N-PK516BA_PDFN8-HF

5

Q114

4 3 2 1

VDIMM_LG_R

N-PK510BA_PDFN8-HF

R612

R612 X_2.2R1206

X_2.2R1206

VDIMM_PHASE_RC

R659 X_0R0402R659 X_0R0402 C565

C565

X_C1u25X5-HF

DDR_FB_R

R654 0R0402R654 0R0402

CPU_VDD_VIN

5

Q119

4 3 2 1

N-PK516BA_PDFN8-HF

5

Q120

4 3 2 1

N-PK510BA_PDFN8-HF

CPU_VDD_SEN_COP

CPU_VDD_FB_COP

VDDP and VDDR support two separate power planes with single regulator

CPU_VDDP POWER

CPU_VDD CPU_VDDP CPU_VDDRCPU_VDD

R838 0R0805R838 0R0805 R840 0R0805R840 0R0805

VCC_DDR

C823X_C1500p50X0402C823X_C1500p50X0402

Q124

D

NB_VCC1P1_DRV_RNB_VCC1P1_DRV

G

S

N-45N02_TO252-RH

Pd=33 W@Tc=100

C826 C0.022u50XC826 C0.022u50X

°C

R849 1KR1%0402R849 1KR1%0402

2

5

Q110

4 3 2 1

N-PK510BA_PDFN8-HF

C582

X_C1u10X

R936

10KR0402

R938

12.4KR1%0402

VDDIOFB+10

+

12

C808

EC71

C1u16X5

C470u6.3SO-RH-3

CHOKE15

1 2

R830

CH-0.5u40A0.81m-RH

2.2R1206

CPU_VDD_PH_RC

C817

C817 C2200p16X0603

C2200p16X0603

1.2 V@5A

C820

C1u16X5

C821 C10u10X50805-HF-2C821 C10u10X50805-HF-2

C829

2

4 3 2 1

R898 0R0402R898 0R0402

+

12

EC72

12

X_C10u10X50805-HF-2

5VDIMM_VIN

5

Q130

CHOKE14

1 2

CH-1.2u15A1.7m-RH-2

C470u6.3SO-RH-3

CP28

CP28 X_COPPER

X_COPPER

1 2

CPU_VDDR POWER

NB_VCC1P1

+

C851

EC76

CD1000u6.3EL11.5-RH-1

+

12

C617

C1u16X5

CH-0.5u40A0.81m-RH

CP29

X_COPPER

1 2

R839 0R0805R839 0R0805 R841 0R0805R841 0R0805

C10u10X50805-HF-2

CHOKE12

1 2

+

12

EC65

EC42

CH-1.2u15A1.7m-RH-2

CD100u16SO-RH-1

CHOKE7

1 2

C804

CP27

X_COPPER

1 2

VCC3

1.2V 15A OCP:23~30A 200~500KHz

CPU_VDD

+

12

+

12

EC74

C816

EC73

C1u10X

C560u6.3SO-RH

1.2 V@5A

Title

FCH CORE & DDR Power

Size Document Number Rev

Custom

Date: Sheet

1

5VDIMM

1.35V/1.5V 22A OCP 33~44A 200~500KHz

VCC_DDR

+

12

+

12

+

12

EC80

EC77

EC75

C1u10X

Kaveri-VC 0A

C560u6.3SO-RH

MICRO-START INT'L CO.,LTD.

of

37 40Tuesday, June 18, 2013

1

5

4

ATX Power Connector / Front Panel / LED/DSW

3

2

1

14 Pin ATX Power Connector

ATX_5VSB

D D

C830

C1u6.3X50402-HF

TP57TP57

ATX_PWROK ATX_PSON#

ATX_POWER

1

8

1

8

2

9

2

9

3

10

3

10

4

11

4

11

5

12

5

12

6

13

6

13

7

14

7

14

PWRCONN14P_NATURE-RH-1

-12V

C831

+12V

C832

C0.1u25X50402-HF

VCC5

R851

R851 10KR0402

10KR0402

C833

C833 C1000p50X0402

C1000p50X0402

ATX_PWROK 7,25,30,34,36,37

LENOVO Front Panel Connector

R799,R776 Pmax=(5*5)/330=0.076W

VCC5

F_LED_WlLAN# 25

C835

C835 C0.1u16X0402

C0.1u16X0402

Pspec=0.1W

VCC3

C836

C4.7U10X5-HF

PSIN# 34

D86

BAV99

Y

X

Z

FP_RST# 16,37

Buzzer Circuit

RN22

BZ1

1 2

BUZZER-LF

VCC5

SPK1

RN22

1 3 5 7

8P4R-150R0402

C839

C839 C0.1u16X0402

C0.1u16X0402

F_PANEL

SLED#

R855 330RR855 330R

VCC5

C C

5VDIMM

YELLOW Green

R856 330RR856 330R

PWRLED_G PWRLED+ PWRSW+ PWRSW-

R859

0R0402

1

HDD+

3

GNDL

5

SLED2

7

PLED1

9

PWSW+

11

PWSW-

NC13

H2X7[13]_black-2.6mm-RH

HDD-

SPK+

SPK-

RESET

GNDR

HDD-

2 4 6

NC1

R857 330RR857 330R

8

NC2

SPK1

10

FP_RST#

12 14

Power Button

R866

100R0402

C0.01u16X0402

VCC3_ALW

C840

R863

R863 10KR0402

10KR0402

VCC3_ALW

D87

BAV99

Y

X

Z

R865

B B

PWRSW+

R865

75R0402

D87_Z

EMI solution

5VSB Power Switch

Tune ATX_5VSB inrush current to 2A from 4A

1KR0402

SYS5VSB_OFF30,34

ATX_5VSB

D85

R853

D85

BAS32L_LL34

R854 20KR0402-2R854 20KR0402-2

change for 3VSB drop issue (0110) when system status changes from G3 to S5 without battery

VCC3&VCC5 Discharge Schematic

VCC3

RN18

1 3 5 7

X_8P4R-10R

X_8P4R-10R RN20

RN20

1 3 5 7

X_8P4R-10R

Q126_G Q127_G

Q128_B

B

SPKR 16

Q131_B

B

R858 X_1KR0402R858 X_1KR0402

R861 X_1KR0402R861 X_1KR0402

C837

X_C0.1u16X0402

R867 1KR0402R867 1KR0402

VCC5_SB

VCC_DDR

VCC5

D88

D88 1N4148W-F_SOD123-RH

1N4148W-F_SOD123-RH

Q131_C

2 4 6 8

CE

Q131

Q131 NPN-MMBT2222A-7-F_SOT23-RH

NPN-MMBT2222A-7-F_SOT23-RH

+

12

EC78

EC78 X_C10u10SO-RH

X_C10u10SO-RH

Q125_GSYS5VSB_OFF

2 4 6 8

D

G

S

CE

Q128

Q128 X_N-SST3904_SOT23

X_N-SST3904_SOT23

HDD-

VCC5_SB

DS

Q125

Q125 P-P06P03LCGA_SOT89-3-HF

P-P06P03LCGA_SOT89-3-HF

G

C834

+VCC5_SB Trace Width 80mils

C1u16X5

Change to VCCP power for guardband test issue

Q126

X_N-2N7002ET1G_SOT23-3-HF

VCCP

HDD LED

Y X

R864 X_4.7KR0402R864 X_4.7KR0402

SATA_LED#

D78

S-BAT54A_SOT23

Z

Cap For EMI

VCC5_SB

R862 X_1KR0402R862 X_1KR0402

X_C0.1u16X0402

VCC5

R860 X_1KR0402R860 X_1KR0402

Q129_B

C838

VCC3

SATA_LED# 17

RN19

Q127_DQ126_D

1

2

3

4

5

6

7

8

X_8P4R-10R

X_8P4R-10R RN21

RN21

1

2

3

4

5

6

7

8

X_8P4R-10R

D

G

S

CE

B

Q129

Q129 X_N-SST3904_SOT23

X_N-SST3904_SOT23

Lenovo EMC suggestion for 144MHz harmonic wave

SATA_LED#

Q127

X_N-2N7002ET1G_SOT23-3-HF

C841

C841 X_C0.1u16X0402

X_C0.1u16X0402

4

Power LED

PWRLED_G

X_C0.1u16X0402

C846

CE

B

Q132

Q132 N-SST3904_SOT23

N-SST3904_SOT23

R871 4.7KR0402R871 4.7KR0402

5VDIMM

R869

R869 300R

300R

3

SLED#

C843

VCC5_SB

C850

C850 X_C0.1u16X0402

X_C0.1u16X0402

C843 X_C0.1u16X0402

X_C0.1u16X0402

C842

X_C0.1u16X0402

C848

X_C0.1u16X0402

VCC5

2

C849

C849 X_C0.1u16X0402

X_C0.1u16X0402

PWR_LEDQ132_B

PWR_LED 34PS_ON#34,35

PWRLED+

C844

C844 X_C0.1u16X0402

X_C0.1u16X0402

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Date: Sheet of

Date: Sheet

MICRO-START INT'L CO.,LTD.

ATX/F_Panel/EMI/LED

Kaveri-VC

SPK1HDD-

C845

C845 X_C0.1u16X0402

X_C0.1u16X0402

PWRSW-

C852

C852 X_C0.1u16X0402

X_C0.1u16X0402

0A

of

38 40Tuesday, June 18, 2013

1

ATX Power On

ATX_5VSB

R868

10KR0402

R870 100R0402R870 100R0402

change for ATX_PSON# ring issue when it falls

A A

10KR0402

C0.1u16X0402

5

D89

1N4148W-F_SOD123-RH

C847

ATX_PSON#

8

HEAT SINK

7

6

5

4

3

2

1

HDMI_LOGO1

HDMI Logo

D D

HS1

4 3

HS-0405611-RH

1 2

HDMI Logo

X_Y01-RHDMI03-000

RUBBER2

RUBBER1

PCB

rubber1/2

FRU_LABLE1

FRU Lable

X_GD1-MB10010-F32/L31

DPK1

WIN8 DPK

X_Y04-ML2MW02-MYP

MANUAL PART

C C

AVL: D06-0100161-F52 D06-0100101-K26

BAT1_X1

BAT-CR2032-RH

PCB1

P30-077020C-E36

ELLINGTON ( P80-078720A-G37 )

B B

USB_LAN

USB_LAN CONN

CONN

RJ45_USBX2_LEDX2_TX-RH-73

RJ45_USBX2_LEDX2_TX-RH-73 AUDIO1

AUDIO1

AUDIO JACK

AUDIO 2X3

HDMI_DP1

AUDIO JACK

X

6KV Giga 15u N58-22F1261-I60

2*3 N54-26F0091-K06

10/100M

1*3 N54-13F0331-K06 N54-13F0211-S42

MH1

7 6

5

981

X_MH001

4

981

MH2

2 3

MH2

7 6

5

X_MH001

4

2 3

VCC5 VCC5 +12V_VCC VIN VIN

C693

7 6

MH3

C693

X_C0.1u16X50402-2

C862

X_C0.1u16X50402-2

981

X_MH001

5

4

VCCP VCCPVCCP

C695

X_C0.1u16X50402-2

C860

X_C0.1u16X50402-2

2 3

C857

X_C0.1u16X50402-2

C861

X_C0.1u16X50402-2

C858

X_C0.1u16X50402-2

VCC5 VCCP VCCP VCCP

C799

C859

X_C0.1u16X50402-2

C799

X_C0.1u16X50402-2

C863

X_C0.1u16X50402-2

C864

X_C0.1u16X50402-2

C865

X_C0.1u16X50402-2

Optics Orientation Holes

FM2

8

FM2

X_FM120

FM4

X_FM120

FM6

X_FM120

FM8

X_FM120

Simulation

X_JS1

SIM2

X_JS1

SIM1

X_PIN1*2

X_JS2

X_PIN1*2

7

VCC5

6

FM1

X_FM120

FM3

X_FM120

FM5

A A

X_FM120

FM7

X_FM120

MH4

7 6

MH7

7 6

5

981

X_MH001

4

981

X_MH001

4

5

2 3

MH5

7 6

MH8

7 6

5

981

X_MH001

4

981

X_MH001

4

2 3

4

7 6

MH6

5

981

X_MH001

4

2 3

MICRO-START INT'L CO.,LTD.

Title

Auto BOM Mnaual

Size Document Number Rev

B

Date: Sheet

3

Date: Sheet

MICRO-START INT'L CO.,LTD.

Kaveri-VC 0A

2

of

39 40Wednesday, June 19, 2013

1

5

D D

C C

4

3

2

1

B B

A A

MICRO-START INT'L CO.,LTD.

Title

Size Document Number Rev

Custom

Date: Sheet

5

4

3

2

Date: Sheet

MICRO-START INT'L CO.,LTD.

HISTORY

Kaveri-VC 0A

1

40 40Monday, June 17, 2013

of

MSI MS-7872 Schematic 0A

Specifications and Main Features

Frequently Asked Questions

User Manual
