Getting Started

This chapter provides you with the information on hardware setup procedures� While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity�

IMPORTANT

•

The illustrations are for reference only� Your monitor may vary in appearance�

•

Do not use any sharp objects on the monitor�

Package Contents

1� Monitor

2� Stand

3� Stand Base with Screw

4� Power Cord

5� HDMI Cable

6� DisplayPort Cable (for MAG271CQR)

7� USB Upstream Cable (to enable the USB ports on the monitor)

8� Quick Start Guide

9� Warranty Card

10� VESA Cover Screws

* Contact your place of purchase or local distributor if any of the items is damaged or

missing�

* Package contents may vary by country�
