Product Overview

Chapter 1

Product Overview

Thank you for choosing the IM-GME965 (MS-9821 v1.
X) Mini ITX mainboard from MSI.

Based on the innovative Intel® GME965 & ICH8M con­trollers for optimal system efficiency, the IM-GME965
accommodates the latest Intel® Penryn/Core 2 Duo/
Core Duo/Celeron M processors in Socket P and
supports two DDR2 533/667MHz SO-DIMM slots to pro­vide the maximum of 4GB memory capacity.

In the entry-level and mid-range market segment, the
IM-GME965 can provide a high-performance solution
for today’s front-end and general purpose workstation,
as well as in the future.

1-1

MS-9821 Mainboard

Mainboard Specifications

Processor

- Intel Penryn/Core 2 Duo/Core Duo/Celeron M CPU in Socket P

- Supports 3-pin CPU fan pin-header with Fan Speed Control

- Supports Intel Dual Core Technology to 533/667/800MHz and up

Supported FSB

- 533/667/800MHz

Chipset

- North Bridge: Intel GME965 chipset

- South Bridge: Intel ICH8M chipset

Memory

- Unbuffer Non-ECC DDR2 533/667 SDRAM (4GB Max)

- 2 DDR2 SO-DIMM slots (200pin / 1.8V)

LAN

- Supports Gagabit Ethernet by Intel 82566DC

Audio

- HDA Codec by Realtek ALC888 7.1 channel

- Compliant with Azalia 1.0 specs

- 6 watt amplifier

IDE

- 1 IDE port by ICH8M

- Supports Ultra DMA 66/100 mode

- Supports PIO, Bus Master operation mode

SATA

- SATA II ports by ICH8M

- Supports two SATA II devices

- Supports storage and data transfers at up to 3Gb/s

Connectors

Back Panel

- 1 RJ-45 LAN jack

- 4 USB 2.0 ports

- 1 D-Sub VGA connector

- 1 serial port

1-2

- 1 PS/2 keyboard port

- 1 PS/2 mouse port

- 6 audio jacks

Onboard Connectors

- 2 USB 2.0 connectors (4 ports)

- 1 parallel port connector

- 1 SPI Flash ROM connector (for debugging)

- 1 LVDS connector

- 1 TV-out connector

- 3 serial port connectors

- 1 chassis intrusion switch connector

- 1 amplifier connector

Slots

- 1 PCI Express x16 slot

- 1 Mini PCI-E slot

- 1 32-bit/33MHz PCI slot

- 1 CF socket (optional)

Form Factor

- Mini ITX: 170mm x 170mm

Mounting

- 4 mounting holes

Environmental

Storage Temperature

- Temperature: -20oC ~ 80oC

- Humidity: 0% RH ~ 95% RH

Operation Temperature

- Temperature: 0oC ~ 55oC

- Humidity: 0% RH ~ 85% RH

Product Overview

1-3

MS-9821 Mainboard

Block Diagram

1-4

Mainboard Layout

SATA1

SATA2

F_USB2

F_USB1

J2

COM3

JCF_SEL1

BATT

DIMM1

JINV1

DIMM2

JLPT1

C
F
1

JCOMP1

JCOMP2

GME965

SYSFAN1

CPUFAN1

Product Overview

J1

Top: Mouse
Bottom:
Keyboard

Top: Serial Port
Bottom: VGA Port

Top: LAN Jack
Bottom: USB Ports

USB Ports

T:

Line-In

M:

Line-Out

B:

Mic
T:RS-Out
M:CS

-Out
B:SPDIF­ Out

J4

Audio

JSPD1

Intel

JLVDS1

JTV1

CON1

Intel

ICH8M

J3

JSPI1

+

PCIE1

JBAT1

COM1

COM2

JAMP1

PCI1

JPW1

IDE1

JFP1

JCASE1

JSPWR 1

J5

IM-GME965 (MS-9821 v1.X) Mini ITX Mainboard

1-5

MS-9821 Mainboard

Board Dimension

1-6

Back Panel & I/O Shield Drawing

Product Overview

1-7

MS-9821 Mainboard

Power Consumption

Component Description

CPU Intel Core 2 Duo T7500 processor
Memory Transcend 1G DDR2-667 x1
Add-On VGA NA
Hard Disk Maxtor 40G IDE 7200rpm HDD x1
Operating System Microsoft® Windows XP® Professional SP2

MS-9821 12V input

Enter DOS(Stable) 3.07/11.861
Enter BIOS(Stable) 2.67/11.899
Idle
CPU Stress 100%
Windows
stress(3dMARK2006)
Windows Desktop
Standby S1 without
two LANs connected
(stable)
Windows Desktop
Standby S3 without
two LANs connected
(stable)
Windows Desktop
Hibernate S4 without
two LANs connected
(stable)
Windows Desktop
Soft Off S5 without
two LANs connected
(stable)

Current(A) & Voltage Current(A) & Voltage

2.09/11.940

5.09/11.692 3.30/19.043

4.35/11.74

1.30/12.01

0.110/12.144

0.085/12.149

0.075/12.150

19V input

2.03A/19.069

1.81/19.092

1.39/19.131

2.63/19.04

0.76/19.178

0.052/19.249

0.038/19.251

0.045/19.251

1-8

Safety Compliance & MTBF

Limits for harmonic current

emission

Limitation of voltage

voltage supply system

Product Overview

Certification Title of standard

RFI

CE

ImmunityEN 55024:1998+A1:2001+A2:2003 Product family standard

BSMI

CNS 13438 乙類(1997年版)
AS/NZS CISPR 22:2004

C-Tick

FCC CFR Title 47 Part 15 Subpart B: 2005 Class B

FCC

CISPR 22: 2005
VCCI V-3:2004, Class B

VCCI

VCCI V-4:2004, Class B

Standard number

EN 55022:1998+A1:2000+A2:2003 Class BProduct family standard
EN 6100-3-2:2000 Class D

EN 6100-3-3:1995+A1:2001

fluctuation and flicker in low-

MTBF - Reliability Prediction

Calculation

Model

Telcordia Issue

1

Operation

Temperature (°C)

25

Operating

Environment

GB, GC - Ground

Benign,

Controlled

Duty Cycle

(FITs.)

4,564.28 219,093

MTBF(hr.)

1-9

MS-9821 Mainboard

1-10

Hardware Setup

Chapter 2

Hardware Setup

This chapter provides you with the information about
hardware setup procedures. While doing the installation,
be careful in holding the components and follow the
installation procedures. For some components, if you
install in the wrong orientation, the components will not
work properly.

Use a grounded wrist strap before handling computer
components. Static electricity may damage the
components.

2-1

MS-9821 Mainboard

Quick Components Guide

Back Panel
I/O, p.2-7

JSPI1, p.2-11

PCI-E Slot,

p.2-18

JSPD1, p.2-11

PCI Slot, p.2-18

JLVDS1, p.2-14

DIMM Slots, p.2-3

JAMP1, p.2-11

JCOMP1~2, p.2-17

JTV1, p.2-13

Mini PCI-E
Slot, p.2-18

JBAT1,

p.2-17

COM1~2, p.2-16

F_USB1~2, p.2-15

CPU, p.2-4

JPW1, p.2-6

SYSFAN1, p.2-12

CPUFAN1, p.2-12

JCF_SEL1, p.2-19

IDE1, p.2-9

SATA1~2, p.2-10

J2, p.2-17

JLPT1, p.2-16

JFP1, p.2-12

J5, p.2-17

COM3, p.2-16

JCASE1, p.2-9

JSPWR1, p.2-6

2-2

Hardware Setup

Memory

The DIMM slots are intended for system memory modules.

DDR2 SO-DIMM Slot

200-pin, 1.8V

Installing Memory Modules

1. Locate the SO-DIMM slots on the mainboard.

2. Align the notch on the DIMM with the key on the slot. Insert the DIMM vertically into
the SO-DIMM slot. Then push it in until the golden finger on the DIMM is deeply
inserted in the SO-DIMM slot.

3. Manually check if the DIMM has been locked in place by the retaining clips at the
sides.

Important

1. Make sure that you install the memory modules first before installing
the CPU and cooler set.

2. Always insert the memory module into the DIMM1 first.

2-3

MS-9821 Mainboard

CPU (Central Processing Unit)

The mainboard supports Intel® Penryn/Core 2 Duo/Core Duo/Celeron M proces­sors in Socket P. When you are installing the CPU, make sure the CPU has a heat
sink and a cooling fan attached on the top to prevent overheating. If you do
not have the heat sink and cooling fan, contact your dealer to purchase and install
them before turning on the computer.

Important

1. Overheating will seriously damage the CPU and system. Always make
sure the cooling fan can work properly to protect the CPU from overheating.

2. Make sure that you apply an even layer of heat sink paste (or thermal tape)
between the CPU and the heatsink to enhance heat dissipation.

3. While replacing the CPU, always turn off the power supply or unplug the
power supply’s power cord from the grounded outlet first to ensure the
safety of CPU.

2-4

Hardware Setup

Socket P CPU Installation

1. Locate the CPU socket on the
mainboard.

2. Place the CPU on top of the socket. Make sure that you align the gold arrow on the
CPU with the arrow key on the socket.

3. Push the CPU down until its pins securely fit into the socket.

4. On the front end of the CPU socket is a locking mechanism designed into the form
of a screw head. Make sure that you actuate or deactuate this mechanism with
a screwdriver before and after installing the CPU.

Important

Mainboard photos shown in this
section are for demonstration only
and may differ from the actual look
of your mainboard.

2-5

MS-9821 Mainboard

Power Supply

System/CPU Power Connector: JPW1

This connector provides power to the system and CPU.

2

1

JPW1 Pin Definition

PIN SIGNAL

1 GND
2 GND
3 12V or 14~24V
4 12V or 14~24V

4
3

JPW1

HDD Power Connector: JSPWR1

The connector provides power to the hard disk drives.

GND

GND

+1 2V

VCC5

JSPWR1

Important

Power supply of 120watts (and above) is highly recommended for system
stability.

2-6

Back Panel

Hardware Setup

Mouse

Keyboard USB Ports

Mouse/Keyboard

The standard PS/2® mouse/keyboard DIN connector is for a PS/2® mouse/keyboard.

Serial Port
The serial port is a 16550A high speed communications port that sends/ receives 16
bytes FIFOs. You can attach a serial mouse or other serial devices directly to the
connector.

VGA Port
The DB15-pin female connector is provided for monitor.

USB Port
The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard,
mouse, or other USB-compatible devices.

LAN
The standard RJ-45 LAN jack is for con­nection to the Local Area Network (LAN).
You can connect a network cable to it.

LED Color LED State Condition

Left Green On (steady state) LAN link is established.

Green Off 10 Mbit/sec data rate is selected.

Right On 100 Mbit/sec data rate is selected.

Orange On 1000 Mbit/sec data rate is selected.

Serial Port

VGA Port

Off LAN link is not established.

On (brighter & pulsing)The computer is communicating with another computer on the LAN.

LAN

USB Ports

Line-In

Line-Out

MIC

Link IndicatorActivity Indicator

RS-Out

CS-Out

Optical

SPDIF-Out

2-7

MS-9821 Mainboard

Audio Ports
These audio connectors are used for audio devices. You can differentiate the color
of the audio jacks for different audio sound effects.

Line-In (Blue) - Line In / Side-Surround Out in 7.1 channel mode, is used

Line-Out (Green) - Line Out, is a connector for speakers or headphones.
Mic (Pink) - Mic, is a connector for microphones.
RS-Out (Black) - Rear-Surround Out in 4/ 5.1/ 7.1 channel mode.
CS-Out (Orange) - Center/ Subwoofer Out in 5.1/ 7.1 channel mode.

Optical S/PDIF-Out
This SPDIF (Sony & Philips Digital Interconnect Format) connector is provided for
digital audio transmission to external speakers through an optical fiber cable.

for external CD player, tapeplayer or other audio
devices.

2-8

Hardware Setup

Connector

Chassis Intrusion Connector: JCASE1

This connector connects to the chassis intrusion switch cable. If the chassis is
opened, the chassis intrusion mechanism will be activated. The system will record
this status and show a warning message on the screen. To clear the warning, you
must enter the BIOS utility and clear the record.

1

CINTRU

2

GND

JCASE1

IDE Connector: IDE1

This connector supports IDE hard disk drives, optical disk drives and other IDE devices.

IDE1

Important

If you install two IDE devices on the same cable, you must configure the drives
separately to master / slave mode by setting jumpers. Refer to IDE device’s
documentation supplied by the vendors for jumper setting instructions.

2-9

MS-9821 Mainboard

Serial ATA II Connector: SATA1, SATA2

This connector is a high-speed Serial ATA II interface port. Each connector can
connect to one Serial ATA II device.

SATA1

SATA2

Important

Please do not fold the Serial ATA cable into 90-degree angle. Otherwise,
data loss may occur during transmission.

2-10

Hardware Setup

Audio Amplifier Connector: JAMP1

The JAMP1 is used to connect audio amplifiers to enhance audio performance.

Pin Definition

JAMP1

1

PIN SIGNAL

1 AMP_L­2 AMP_L+
3 AMP_R­4 AMP_R+

S/PDIF-Out Connector: JSPD1 (Optional, for HDMI graphics card
only)

This connector is used to connect S/PDIF (Sony & Philips Digital Interconnect Format)
interface for digital audio transmission to the HDMI graphics card.

SPDIF-Out

GND

JSPD1

SPI Flash ROM Connector: JSPI1

This connector is used to flash SPI flash ROM.

JSPI1

1

2

10

9

Pin Definition

Pin Description Pin Description

1 VCC3_SB 2 VCC3_SB
3 SPI_MISO_F 4 SPI_MOSI_F
5 SPI_CS0_F# 6 SPI_CLK_F
7 GND 8 GND
9 SPI_HOLD# 10 NC

2-11

MS-9821 Mainboard

Fan Power Connectors: CPUFAN1, SYSFAN1

The fan power connectors support system cooling fan with +12V. When connecting
the wire to the connectors, always note that the red wire is the positive and should
be connected to the +12V; the black wire is Ground and should be connected to GND.
If the mainboard has a System Hardware Monitor chipset onboard, you must use a
specially designed fan with speed sensor to take advantage of the CPU fan control.

GND
+12V
SENSOR
CONTROL

CPUFAN1

SYSFAN1

GND
+12V
SENSOR

Important

Please refer to the recommended CPU fans at Intel® official website or consult
the vendors for proper CPU cooling fan.

Front Panel Connector: JFP1

The mainboard provides one front panel connector for electrical connection to the
front panel switches and LEDs. The JFP1 is compliant with Intel® Front Panel I/O
Connectivity Design Guide.

JFP1

910

-

2-12

Power
Switch++

Power
LED

JFP1 Pin Definition

PIN SIGNAL DESCRIPTION

1 HD_LED + Hard disk LED pull-up
2 FP PWR/SLP MSG LED pull-up
3 HD_LED - Hard disk active LED
4 FP PWR/SLP MSG LED pull-up
5 RST_SW - Reset Switch low reference pull-down to GND
6 PWR_SW + Power Switch high reference pull-up
7 RST_SW + Reset Switch high reference pull-up
8 PWR_SW - Power Switch low reference pull-down to GND
9 RSVD_DNU Reserved. Do not use.

+

Reset

-

Switch

-

HDD
LED

2

1

Hardware Setup

port

PCI-E x16 port

XXX

X

TV-Out Connector: JTV1 (Optional)

This connector is for you to attach an optional TV-Out bracket that offers two types
of TV-Out connectors: S-Video and RCA Composite connectors. Select the appropri­ate one to connect the standard television or the HDTV (High-Definition TeleVision).

Display Matrix

CRT LVDS TV-OUT SDVO

CRT V V V X

LVDS V V V X

TV-OUT V V V X

SDVO V V V X

V : Support X : No Support

TV-Out Bracket (Optional)

Connect to JTV1

PCI-E x16

5

1

2

JTV1

Pin Definition

Pin Description Pin Description

1 GND 4 GND
2 LCVBS 5 LC
3 LY 6 NC

HDTV-Out Connector

(RCA Composite)

Standard TV-Out

Connector (S-Video)

Important

Please note that the TV-Out bracket can connect to one TV only. Users have
to choose either the RCA Composite or the S-Video to connect. Simulta­neously connecting two TVs to this bracket is prohibited and may lead to the
malfunction of the TVs.

2-13

MS-9821 Mainboard

port

PCI-E x16 port

XXX

X

LVDS Flat Panel Connector: JLVDS1

The LVDS (Low Voltage Differential Signal) connector provides a digital interface
typically used with flat panels. After connecting an LVDS interfaced flat panel to the
JLVDS1, be sure to check the panel datasheet and set the J7 LVDS Power Selec-

tion Jumper (p. 2-18) to a proper voltage.

Display Matrix

JLVDS1

1

2

39

40

CRT LVDS TV-OUT SDVO

CRT V V V X

LVDS V V V X

TV-OUT V V V X

SDVO V V V X

V : Support X : No Support

SIGNAL PIN SIGNAL

+12V 2 1 +12V
+12V 4 3 +12V

GND 6 5 +12V
GND 8 7 VCC3/VCC5

LCD_VDD 10 9 LCD_VDD

LDDC_DATA 12 11 LDDC_CLK

LVDS_VDDEN 14 13 L_BKLTCTL

GND 16 15 L_BKLTEN
LA_DATA0 18 17 LA_DATA0#
LA_DATA1 20 19 LA_DATA1#
LA_DATA2 22 21 LA_DATA2#

LA_CLK 24 23 LA_CLK#

LA_DATA3 26 25 LA_DATA3#

GND 28 27

GND
LB_DATA0 30 29 LB_DATA0#
LB_DATA1 32 31 LB_DATA1#
LB_DATA2 34 33 LB_DATA2#

LB_CLK 36 35 LB_CLK#

LB_DATA3 38 37 LB_DATA3#

GND 40 39

GND

PCI-E x16

2-14

Hardware Setup

Front USB Connector: F_USB1, F_USB2

This connector, compliant with Intel® I/O Connectivity Design Guide, is ideal for con­necting high-speed USB interface peripherals such as USB HDD, digital cameras,

MP3 players, printers, modems and the like.

Pin Definition

9
10

F_USB1/2

1

2

PIN SIGNAL PIN SIGNAL

1 VCC 2 VCC
3 USB0- 4 USB1­5 USB0+ 6 USB1+
7 GND 8 GND
9 Key (no pin) 10 NC

USB 2.0 Bracket

(Optional)

Important

Note that the pins of VCC and GND must be connected correctly to avoid
possible damage.

2-15

MS-9821 Mainboard

Serial Port Connector: COM1, COM2, COM3

This connector is a 16550A high speed communications port that sends/receives 16
bytes FIFOs. You can attach a serial device to it through the optional serial port
bracket.

10

COM1/2

2 10
1 9

COM3

19

2

Pin Definition

PIN SIGNAL DESCRIPTION

1 DCD Data Carry Detect
2 SIN Serial In or Receive Data
3 SOUT Serial Out or Transmit Data
4 DTR Data Terminal Ready
5 GND Ground
6 DSR Data Set Ready
7 RTS Request To Send
8 CTS Clear To Send
9 VCC_COM3 Power Source

Parallel Port Connector: JLPT1

The mainboard provides a 26-pin header for connection to an optional parallel port
bracket. The parallel port is a standard printer port that supports Enhanced Parallel
Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.

Pin Signal Name Pin Signal Name
1 RSTB# 2 AFD#

JLPT1

25
26

3 PRND0 4 ERR#
5 PRND1 6 PINIT#

1

7 PRND2 8 LPT_SLIN#

2

9 PRND3 10 GND
11 PRND4 12 GND
13 PRND5 14 GND
15 PRND6 16 GND
17 PRND7 18 GND
19 ACK# 20 GND
21 BUSY 22 GND
23 PE 24 GND
25 SLCT 26 GND

Parallel/Serial Port Bracket (Optional)

2-16

Hardware Setup

Jumper

LVDS Power Selection Jumper: J2

Use this jumper to specify the operation voltage of the LVDS interfaced flat panel.

1

J2

COM Port Power Jumpers: J5, JCOMP1, JCOMP2

These jumpers specify the operation voltage of the onboard serial ports.

1

+3V

1

+5V

1

+12V

1

J5,

JCOMP1,

JCOMP2

Clear CMOS Jumper: JBAT1

There is a CMOS RAM onboard that has a power supply from external battery to keep
the data of system configuration. With the CMOS RAM, the system can automatically
boot OS every time it is turned on. If you want to clear the system configuration, set
this jumper to clear data.

JBAT1

1

+12V +5V

1

Keep Data Clear Data

1

1

1

Important

You can clear CMOS by shorting 1-2 pin while the system is off. Then return
to 2-3 pin position. Avoid clearing the CMOS while the system is on; it will
damage the mainboard.

2-17

MS-9821 Mainboard

Slot

PCI (Peripheral Component Interconnect) Express Slot

The PCI Express slot supports PCI Express interface expansion cards.
The PCI Express x 16 slot supports up to 4.0 GB/s transfer rate.
The CON1 is Mini PCI-E connector for wireless LAN, TV tuner, and Robson NAND
Flash.

PCI Express x16 Slot

Mini PCI-E Slot

PCI (Peripheral Component Interconnect) Slot

The PCI slot supports LAN card, SCSI card, USB card, and other add-on cards that
comply with PCI specifications.

32-bit PCI Slot

PCI Interrupt Request Routing

The IRQ, acronym of interrupt request line and pronounced I-R-Q, are hardware lines
over which devices can send interrupt signals to the microprocessor. The PCI IRQ
pins are typically connected to the PCI bus pins as follows:

DEVICE INT Pin IDSEL CLOCK REQ# / GNT#

32-bit PCI Slot PIRQA AD17 PCICLK 0 REQ#0 / GNT#0
32-bit PCI Riser PIRQC AD18 PCICLK 1 REQ#1 / GNT#1
32-bit PCI Riser PIRQD AD19 PCICLK 2 REQ#2 / GNT#2

Important

When adding or removing expansion cards, make sure that you unplug the
power supply first. Meanwhile, read the documentation for the expansion card
to configure any necessary hardware or software settings for the expansion
card, such as jumpers, switches or BIOS configuration.

2-18

Hardware Setup

CompactFlash Card Slot: CF1 (Optional)

This CompactFlash slot shares one channel of the IDE controller. You can install one
CompactFlash typeI / type II device.

CF1

CF Mode Selecting Jumper:
JCF_SEL1 (Optional)

This jumper is used to select Master/
Slave mode of the CF device.

1

JCF_SEL1

1

Master

1

Slave

Important

* The CF1 slot and the IDE1 connector shares and uses the same channel. CF1

and IDE1 can support up to 2 IDE devices without CF device or 1 IDE device
with 1 CF device.

* If you install two IDE devices, you must configure the second drive to Slave

mode by setting its jumper. Refer to the hard disk documentation supplied by
hard disk vendors for jumper setting instructions.

* If you install one IDE device with ATA133 IDE cable and one CF device, you

must configure the CF drive to Master mode by setting jumper JCF_SEL1.
CF only supports Master mode by using ATA133 IDE cable. CF only supports
Slave mode by using ATA33 IDE cable.

2-19

MS-9821 Mainboard

2-20

Chapter 3

BIOS Setup

This chapter provides information on the BIOS Setup
program and allows you to configure the system for
optimum use.
You may need to run the Setup program when:

An error message appears on the screen during the
system booting up, and requests you to run SETUP.

You want to change the default settings for cus­tomized features.

BIOS Setup

3-1

MS-9821 Mainboard

Entering Setup

Power on the computer and the system will start POST (Power On Self Test) process.
When the message below appears on the screen, press <Del> key to enter Setup.

Press Del to enter SETUP

If the message disappears before you respond and you still wish to enter Setup,
restart the system by turning it OFF and On or pressing the RESET button. You may
also restart the system by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys.

Important

1.The items under each BIOS category described in this chapter are under
continuous update for better system performance. Therefore, the descrip­tion may be slightly different from the latest BIOS and should be held for
reference only.

2.Upon boot-up, the 1st line appearing after the memory count is the BIOS
version. It is usually in the format:

A9821IMS V1.0 031508 where:

1st digit refers to BIOS maker as A = AMI, W = AWARD, and P =
PHOENIX.
2nd - 5th digit refers to the model number.
6th digit refers to the chipset as I = Intel, N = nVidia, and V = VIA.
7th - 8th digit refers to the customer as MS = all standard customers.
V1.0 refers to the BIOS version.
031508 refers to the date this BIOS was released.

3-2

BIOS Setup

Control Keys

<↑> Move to the previous item
<↓> Move to the next item
<←> Move to the item in the left hand
<→> Move to the item in the right hand

<Enter> Select the item
<Esc> Jumps to the Exit menu or returns to the main menu from a

<+/PU> Increase the numeric value or make changes
<-/PD> Decrease the numeric value or make changes
<F6> Load Optimized Defaults
<F7> Load Fail-Safe Defaults
<F10> Save all the CMOS changes and exit

submenu

Getting Help

After entering the Setup menu, the first menu you will see is the Main Menu.

Main Menu

The main menu lists the setup functions you can make changes to. You can use the
arrow keys ( ↑↓ ) to select the item. The on-line description of the highlighted setup
function is displayed at the bottom of the screen.

Sub-Menu

If you find a right pointer symbol (as shown in the right view) appears to the left of
certain fields that means a sub-menu can be launched from this
field. A sub-menu contains additional options for a field parameter.
You can use arrow keys ( ↑↓ ) to highlight the field and press
<Enter> to call up the sub-menu. Then you can use the control keys to enter values
and move from field to field within a sub-menu. If you want to return to the main
menu, just press the <Esc >.

General Help <F1>

The BIOS setup program provides a General Help screen. You can call up this screen
from any menu by simply pressing <F1>. The Help screen lists the appropriate keys
to use and the possible selections for the highlighted item. Press <Esc> to exit the
Help screen.

3-3

MS-9821 Mainboard

The Menu Bar

Main

Use this menu for basic system configurations, such as time, date etc.

Advanced

Use this menu to set up the items of special enhanced features.

Boot

Use this menu to specify the priority of boot devices.

Security

Use this menu to set supervisor and user passwords.

Chipset

This menu controls the advanced features of the onboard Northbridge and Southbridge.

Exit

This menu allows you to load the BIOS default values or factory default settings into
the BIOS and exit the BIOS setup utility with or without changes.

3-4

BIOS Setup

Main

BIOS Information, Processor, System Memory

These items show the firmware and hardware specifications of your system. Read
only.

System Time

The time format is <Hour> <Minute> <Second>.

System Date

The date format is <Day>, <Month> <Date> <Year>.

3-5

MS-9821 Mainboard

Advanced

CPU Configuration

3-6

BIOS Setup

Hardware Prefetcher

The processor has a hardware prefetcher that automatically analyzes its re­quirements and prefetches data and instructions from the memory into the
Level 2 cache that are likely to be required in the near future. This reduces the
latency associated with memory reads. When enabled, the processor's hard­ware prefetcher will be enabled and allowed to automatically prefetch data and
code for the processor. When disabled, the processor's hardware prefetcher
will be disabled.

Adjacent Cache Line Prefetch

The processor has a hardware adjacent cache line prefetch mechanism that
automatically fetches an extra 64-byte cache line whenever the processor
requests for a 64-byte cache line. This reduces cache latency by making the
next cache line immediately available if the processor requires it as well. When
enabled, the processor will retrieve the currently requested cache line, as well
as the subsequent cache line. When disabled, the processor will only retrieve
the currently requested cache line.

Max CPUID Value Limit

The Max CPUID Value Limit BIOS feature allows you to circumvent problems
with older operating systems that do not support the Intel Pentium 4 processor
with Hyper-Threading Technology. When enabled, the processor will limit the
maximum CPUID input value to 03h when queried, even if the processor sup­ports a higher CPUID input value. When disabled, the processor will return the
actual maximum CPUID input value of the processor when queried.

Intel(R) Virtualization Tech

Virtualization enhanced by Intel Virtualization Technology will allow a platform
to run multiple operating systems and applications in independent partitions.
With virtualization, one computer system can function as multiple “virtual ” systems.

Execute Disable Bit Capability

Intel's Execute Disable Bit functionality can prevent certain classes of malicious
"buffer overflow" attacks when combined with a supporting operating system.
This functionality allows the processor to classify areas in memory by where
application code can execute and where it cannot. When a malicious worm
attempts to insert code in the buffer, the processor disables code execution,
preventing damage or worm propagation.

Core Multi-Processing

CMP (Core Multi Processing) is the ability to have many independent processing
cores on a single die, each with their own L1 Code & Data caches, Local APICs
& thermal controls, while having a shared L2 cache, power management & bus
interface. Intel multi-core architecture has a single Intel processor package that
contains two or more processor "execution cores," or computational engines to
enable enhanced performance and more-efficient simultaneous processing of
multiple tasks.

3-7

MS-9821 Mainboard

IDE Configuration

ATA/IDE Configuration

This setting specifies the modes of the PATA & SATA ports.

Configure SATA ass

This setting specifies the function of the on-chip SATA controller.

Primary/Secondary/Third/Fourth IDE Master/Slave

3-8

BIOS Setup

[Type] Press PgUp/<+> or PgDn/<-> to select

[LBA/Large Mode] Enabling LBA causes Logical Block Ad-

[Block(Multi-Sector Transfer)]Any selection except Disabled determines

[PIO Mode] Indicates the type of PIO (Programmed Input/

[DMA Mode] Indicates the type of Ultra DMA
[S.M.A.R.T.] This allows you to activate the S.M.A.R.T.

[32 Bit Data Transfer] Enables 32-bit communication between

[Manual], [None] or [Auto] type. Note that the
specifications of your drive must match with
the drive table. The hard disk will not work
properly if you enter improper information for
this category. If your hard disk drive type is
not matched or listed, you can use [Manual] to
define your own drive type manually.

dressing to be used in place of Cylinders,
Heads and Sectors

the number of sectors transferred per block

Output)

(Self-Monitoring Analysis & Reporting
Technology) capability for the hard disks. S.
M.A.R.T is a utility that monitors your disk sta
tus to predict hard disk failure. This gives you
an opportunity to move data from a hard disk
that is going to fail to a safe place before the
hard disk becomes offline.

CPU and IDE controller

3-9

MS-9821 Mainboard

Super IO Configuration

Serial Port 1 / 2 Address

Select an address and a corresponding interrupt for the serial port 1/2.

Serial Port2 Mode

This setting allows you to specify the operation mode for the serial port 2.

Parallel Port Address

This setting specifies the I/O port address and IRQ of the onboard parallel port.

Parallel Port Mode

This setting allows you to specify the operation mode for the parallel port.

Parallel Port IRQ

Select a corresponding interrupt for the parallel port.

Serial Port 3 / 4 Address

Select an address for the serial port 3/4.

Serial Port 3 / 4 IRQ

Select a corresponding interrupt for the serial port 3/4.

Chassis Intrusion

The field enables or disables the feature of recording the chassis intrusion
status and issuing a warning message if the chassis is once opened. To clear
the warning message, set the field to [Reset]. The setting of the field will
automatically return to [Enabled] later.

3-10

BIOS Setup

Audio Amplifier Control

This setting enables/disables the onboard audio amplifier.

Hardware Health Configuration

These items display the current status of the monitored hardware devices/compo­nents such as voltages and temperatures.

Smart Fan Configuration

This setting controls the Smart Fan feature. Smart Fan is an excellent feature
which will adjust the CPU/system fan speed automatically depending on the
current CPU/system temperature.

3-11

MS-9821 Mainboard

CPU FAN Pin Select

This setting selects the pin numbers of the CPU fan power connector.

SYSFAN Mode Setting, CPUFAN Mode Setting

These settings specify the operation mode of the CPU & system fans.

SYSFAN PWM Control, CPUFAN PWM Control

These settings control the PWM duty cycle of the CPU & system fans.

ACPI Configuration

Suspend Mode

This item specifies the power saving modes for ACPI function. If your operating
system supports ACPI, you can choose to enter the Standby mode in S1 (POS)
or S3 (STR) fashion through the setting of this field.

USB Device Wakeup From S3

This setting allows the activity of the USB device to wake up the system from
the S3 sleep state.

3-12

AHCI Configuration

AHCI Port 0, AHCI Port 1, AHCI Port 2

These settings specify the operation modes of the onboard SATA ports.

BIOS Setup

3-13

MS-9821 Mainboard

APM Configuration

Power Management/APM

Setting to [Enabled] will activate an Advanced Power Management (APM) de­vice to enhance Max Saving mode and stop CPU internal clock.

Power Button Mode

This setting controls the operation of the power button.

Resume On LAN

This field specifies whether the system will be awakened from power saving
modes when activity or input signal of onboard LAN is detected.

Resume On PME#

When setting to [Enabled], this setting allows your system to be awakened from
the power saving modes through any event on PME (Power Management Event).

Resume On RTC Alarm

When [Enabled], your can set the date and time at which the RTC (real-time
clock) alarm awakens the system from suspend mode.

3-14

BIOS Setup

Intel Robson Configuration

Intel Robson

Robson is the code name for a new Intel platform technology that uses non­volatile memory (Flash memory) to increase system responsiveness, make
multi-tasking faster, and extend battery life. Intel Robson technology is poised
to eliminate many of the bottlenecks associated with HDD latency. By enabling
the majority of application workload to be written and read from a system cache
instead of the HDD, Robson will offer users of mobile computers built on the
Santa Rosa platform significantly increased performance -- particularly in appli­cation load and run time, the speed in which systems resume operation after
hibernation or boot, and in system-level power usage.

3-15

MS-9821 Mainboard

MPS Configuration

MPS Revision

This field allows you to select which MPS (Multi-Processor Specification) ver­sion to be used for the operating system. You need to select the MPS version
supported by your operating system. To find out which version to use, consult
the vendor of your operating system.

3-16

BIOS Setup

Trusted Computing

TCG/TPM Support

This setting controls the Trusted Platform Module (TPM) designed by the Trusted
Computing Group (TCG). TPMs are special-purpose integrated circuits (ICs)
built into a variety of platforms to enable strong user authentication and machine
attestation—essential to prevent inappropriate access to confidential and sen­sitive information and to protect against compromised networks.

3-17

MS-9821 Mainboard

USB Configuration

Legacy USB Support

Set to [Enabled] if you need to use any USB 1.1/2.0 device in the operating
system that does not support or have any USB 1.1/2.0 driver installed, such as
DOS and SCO Unix.

USB 2.0 Controller Mode

This setting specifies the operation mode of the onboard USB 2.0 controller.

Hotplug USB FDD Support

Set to [Enabled] if your need to use a hotplug USB-interfaced FDD in the operat­ing system that does not support or have any USB driver installed, such as DOS
and SCO Unix.

3-18

Boot

Boot Settings Configuration

BIOS Setup

3-19

MS-9821 Mainboard

Quick Boot

Enabling this setting will cause the BIOS power-on self test routine to skip some
of its tests during bootup for faster system boot.

Quiet Boot

This BIOS feature determines if the BIOS should hide the normal POST mes­sages with the motherboard or system manufacturer's full-screen logo.
When it is enabled, the BIOS will display the full-screen logo during the boot-up
sequence, hiding normal POST messages.
When it is disabled, the BIOS will display the normal POST messages, instead of
the full-screen logo.
Please note that enabling this BIOS feature often adds 2-3 seconds of delay to
the booting sequence. This delay ensures that the logo is displayed for a
sufficient amount of time. Therefore, it is recommended that you disable this
BIOS feature for a faster boot-up time.

AddOn ROM Display Mode

This item is used to determine the display mode when an optional ROM is
initialized during POST. When set to [Force BIOS], the display mode used by AMI
BIOS is used. Select [Keep Current] if you want to use the display mode of
optional ROM.

Bootup Num-Lock

This setting is to set the Num Lock status when the system is powered on.
Setting to [On] will turn on the Num Lock key when the system is powered on.
Setting to [Off] will allow users to use the arrow keys on the numeric keypad.

PS/2 Mouse Support

Select [Enabled] if you need to use a PS/2-interfaced mouse in the operating
system.

Wait For ‘F1’ If Error

When this setting is set to [Enabled] and the boot sequence encounters an
error, it asks you to press F1. If disabled, the system continues to boot without
waiting for you to press any keys.

Hit ‘DEL’ Message Display

Set this option to [Disabled] to prevent the message as follows:

It will prevent the message from appearing on the first BIOS screen when the
computer boots. Set it to [Enabled] when you want to run the BIOS Setup Utility.

Interrupt 19 Capture

Interrupt 19 is the software interrupt that handles the boot disk function. When
enabled, this BIOS feature allows the ROM BIOS of these host adaptors to
"capture" Interrupt 19 during the boot process so that drives attached to these
adaptors can function as bootable disks. In addition, it allows you to gain ac-

Hit Del if you want to run setup

3-20

BIOS Setup

cess to the host adaptor's ROM setup utility, if one is available.
When disabled, the ROM BIOS of these host adaptors will not be able to "cap­ture" Interrupt 19. Therefore, you will not be able to boot operating systems
from any bootable disks attached to these host adaptors. Nor will you be able to
gain access to their ROM setup utilities.

Boot Device Priority

1st Boot Device, 2nd Boot Device

The items allow you to set the sequence of boot devices where BIOS attempts
to load the disk operating system. First press <Enter> to enter the sub-menu.
Then you may use the arrow keys ( ↑↓ ) to select the desired device, then
press <+>, <-> or <PageUp>, <PageDown> key to move it up/down in the
priority list.

Hard Disk Drives, Removable Drives

1st Drive

This setting allows users to set the priority of the available hardware devices.
First press <Enter> to enter the sub-menu. Then you may use the arrow keys (
↑↓ ) to select the desired device, then press <+>, <-> or <PageUp>, <PageDown>
key to move it up/down in the priority list.

3-21

MS-9821 Mainboard

Security

Supervisor Password / Change Supervisor Password

Supervisor Password controls access to the BIOS Setup utility. These settings allow
you to set or change the supervisor password.

User Password / Change User Password

User Password controls access to the system at boot. These settings allow you to
set or change the user password.

3-22

Chipset

BIOS Setup

3-23

MS-9821 Mainboard

North Bridge Configuration

Boot Graphics Adapter Priority

This item specifies which VGA card is your primary graphics adapter.

Internal Graphics Mode Select

The field specifies the size of system memory allocated for video memory.

PEG Port

This setting allows you to select whether to use the onchip graphics processor
or the PCI Express card. When set to [Auto], the BIOS checks to see if a PCI
Express graphics card is installed. If it detects that a PCI Express graphics card
is present, the motherboard boots up using that card. Otherwise, it defaults to
the onboard graphics processor.

PEG Force X1

This BIOS feature allows you to convert a PCI Express X16 slot into a PCI
Express X1 slot. When [Enabled], the PCI Express X16 slot will be forced to run
in the PCI Express X1 mode. When [Disabled], the PCI Express X16 slot will be
allowed to run in its normal PCI Express X16 mode.
If you have a PCI Express X16 graphics card installed in your system, you
should disable this BIOS feature. This allows for optimal performance of the
card by ensuring maximum transfer rates between the graphics card and the
motherboard.
But if you need to install a PCI Express X1 card into the PCI Express X16 slot,
you should enable this BIOS feature to ensure maximum compatibility.

3-24

BIOS Setup

Video Function Configuration

DVMT Mode Select

Intel's Dynamic Video Memory Technology (DVMT) allows the system to dy­namically allocate memory resources according to the demands of the sys­tem at any point in time. The key idea in DVMT is to improve the efficiency of
the memory allocated to either system or graphics processor.
It is recommended that you set this BIOS feature to DVMT Mode for maximum
performance. Setting it to DVMT Mode ensures that system memory is dy­namically allocated for optimal balance between graphics and system
performance.

DVMT/FIXED Memory

When set to DVMT/FIXED Mode, the graphics driver will allocate a fixed
amount of memory as dedicated graphics memory, as well as allow more
system memory to be dynamically allocated between the graphics pro­cessor and the operating system.

Boot Display Device

Use the field to select the type of device you want to use as the display(s)
of the system.

Flat Panel Type

This setting allows you to set your preferences for the boot display device.

3-25

MS-9821 Mainboard

South Bridge Configuration

USB Functions

This setting specifies the function of the onboard USB controller.

USB 2.0 Controller

Set to [Enabled] if you need to use any USB 2.0 device in the operating system
that does not support or have any USB 2.0 driver installed, such as DOS and
SCO Unix.

GbE Controller

This setting disables/enables the onboard Gigabit Ethernet controller.

GbE LAN Boot

When [Enabled], the BIOS attempts to boot from a LAN boot image before it
attempts to boot from a local storage device.

GbE Wake Up From S5

This field specifies whether the system will be awakened from the S5 power
saving mode when activity or input signal of onboard LAN is detected.

HDA Controller

This setting controls the High Definition Audio interface integrated in the
Southbridge.

Restore on AC Power Loss

This setting specifies whether your system will reboot after a power failure or
interrupt occurs. Available settings are:

[Off] Leaves the computer in the power off state.
[On] Leaves the computer in the power on state.
[Last State] Restores the system to the previous status before power

3-26

failure or interrupt occurred.

BIOS Setup

Exit

Save Changes and Exit

Save changes to CMOS and exit the Setup Utility.

Discard Changes and Exit

Abandon all changes and exit the Setup Utility.

Discard Changes

Abandon all changes and continue with the Setup Utility.

Load Optimal Defaults

Use this menu to load the default values set by the mainboard manufacturer specifi­cally for optimal performance of the mainboard.

Load Failsafe Defaults

Use this menu to load the default values set by the BIOS vendor for stable system
performance.

3-27

MS-9821 Mainboard

3-28

System Resources

Chapter 4

System Resources

This chapter provides information on the following
system resources:

1. Watch Dog Timer Setting (p.4-2);

2. AMI POST Code (p.4-3);

3. Resource List (p.4-7).

4-1

MS-9821 Mainboard

Watch Dog Timer Setting

Software code

SIO_IDX equ 2EH
SIO_DTA equ 2FH
Timer equ 10; reset after 10 seconds

1.Enter configuration mode
mov dx,SIO_IDX
mov al,87h
out dx,al
out dx,al

2.Set to LDN 08
mov dx,SIO_IDX
mov al,07h
out dx,al
mov dx,SIO_DTA
mov al,08h
out dx,al

3.Set WatchDog Timer
mov dx,SIO_IDX
mov al,0f6h
out dx,al
mov dx,SIO_DTA
mov al,Timer
out dx,al

4.Exit configuration mode
mov dx,SIO_IDX
mov al,0AAh
out dx,al

4-2

AMI POST Code

System Resources

4-3

MS-9821 Mainboard

4-4

System Resources

4-5

MS-9821 Mainboard

4-6

System Resources

Resource List

Generic I/O Ports

(I) ICH8M GPIO

Pin GPIO Typ Multi Power Connection.

AG12 0 I/O BMBUSY# 3.3v PM_BMBUSY#

AG22 11 I/O SMBALERT# 3.3v SMB_ALERT#

AE20 15 I/OD STP_PCI# 3.3v PM_STP_PCI#

AG18 3 I/OD STP_CPU# 5v PM_STP_CPU#

AH11 32 I/OD CLKRUN# 3.3v P_CLKRUN#

AJ8 1 I/OD TACH1 3.3v NC

AJ9 6 I/O TACH2 3.3v NC

AH9 7 I/O TACH3 3.3v NC

AE16 8 I/O GPIO8 3.3v SIO_PME#

AC19 12 I/O GPIO12 3.3v SPI_HOLD_GPO#

AG8 17 I/O TACH0 3.3v SPI_WP#

AH12 18 I/O GPIO18 3.3v SLPBTIN#

AE11 20 I/O GPIO20 3.3v ATADET0

AG10 22 I/O SCLOCK 3.3v NC

AH25 27 I/O QRT_STATE0 3.3v EL_STATE0

AD16 28 I/O QRT_STATE1 3.3v EL_STATE1

AG13 35 I/O SATACLKREQ# 3.3v CLK_SATA_OE#

AF9 38 I/O SLOAD 3.3v NC

AJ11 39 I/O SDATAOUT0 3.3v NC

AD10 48 I/O SDATAOUT1 3.3v NC

AJ12 21 I/O SATA0GP 3.3v RESISTOR

AJ10 19 I/O SATA1GP 3.3v RESISTOR

AF11 36 I/O SATA2GP 3.3v RESISTOR

AG11 37 I/O SATA3GP 3.3v RESISTOR

AH27 26 I/O S4_STATE# 3.3v NC

AJ27 24 I/O NCMEM_LED 3.3v LAN_EN

AJ24 10 I/O ME_EC_ALERT 3.3v PHY_DIS#

AF22 14 I/O EC_ME_ALERT 3.3v NC

AG19 9 I/O WOL_EN 3.3v NC

AG16 40 I/O OC1# 3.3v OC0#

AG15 41 I/O OC2# 3.3v OC0#

AE15 42 I/O OC3# 3.3v OC0#

AF15 43 I/O OC4# 3.3v OC1#

AG17 29 I/O OC5# 3.3v OC1#

AD12 30 I/O OC6# 3.3v OC1#

AJ18 31 I/O OC7# 3.3v OC1#

4-7

MS-9821 Mainboard

(Ⅱ) SIO GPIO

Pin GPIO Typ Multi Power Connection.

121 17 I/O VID7 VCC5 NC

122 16 I/O VID6 VCC5 NC

123 15 I/O VID5 VCC5 NC

124 14 I/O VID4 VCC5 NC

125 13 I/O VID3 VCC5 NC

126 12 I/O VID2 VCC5 NC

127 11 I/O VID1 VCC5 NC

128 10 I/O VID0 VCC5 NC

120 20 O CPUFANOUT1/GP20 VCC CFAN_PWM

119 21 I/O CPUFANN1/GP21 VCC CPU_FAN

89 33 I/O RSTOUT3#/GP33/SDA VSB NC

90 32 I/O RSTOUT2#/GP32/SCL VSB NC

91 31 I/O GP31 VSB NC

92 30 I/O GP30 VSB NC

67 57 O GP57/PSOUT# VSB PWRBTN#

68 56 I GP56/PSIN# VSB IO_PWRBTN#

64 37 I/O GP37 VSB NC

72 53 I/O GP53/PSON# VSB PS_ON#

73 52 I GP52/SUSB# VSB SLP_S3#

77 50 I/O WDTO#GP50 VSB GP50

2 23 I/O SCK/GP23 VCC NC

88 34 O RSTOUT4#GP34 VSB NC

69 36 I/O GP36 VSB NC

87 35 I/O GP35 VSB NC

75 51 O RSMRST# VSB VCC3

56 61 I DCDA# VCC DCDA#

50 66 I DDSRA# VCC DDSRA#

53 63 I SINA VCC SINA

51 65 I/O RTSA# VCC RTSA#

54 62 O SOUTA VCC SOUTA

49 67 I CTSA# VCC CTSA#

52 64 O DTRA# VCC DTRA#

57 60 I RIA# VSB RIA#

84 41 I DCDB# VSB DCDB#

4-8

79 46 I DSRB# VSB DSRB#

82 43 I SINB VSB SINB

80 45 O RTSB# VSB RTSB#

83 42 O SOUTB VSB SOUTB

78 47 I CTSB# VSB CTSB#

81 44 O DTRB# VSB DTRB#

85 40 I RIB# VSB RIB#

63 26 I/O KBDAT# VSB KBDAT#

62 27 I/O KBCLK# VSB KBCLK#

66 24 I/O MSDAT# VSB MSDAT#

65 25 I/O MSCLK# VSB MSCLK#

70 55 I/O SUSLED VSB GND

71 54 I/O PWROK VSB NC

System Resources

4-9

MS-9821 Mainboard

I/O Map

I/O Port Description

0000-000F DMA Controller 1
0020-0021 Interrupt Controller 1
002E-002F SIO Port
0040-0043 System Timer
004E-004F TPM Port
0060, 0064 Keyboard Controller
0070-0073 RTC and CMOS
0080-0090 DMA Controller Page Registers
0092 Port 92h
00A0-00A1 Interrupt Controller 2
00B2-00B3 APM Register
00C0-00DF DMA Controller 2
00F0-00FF Numeric Data Processor
01F0-01F7 Primary IDE Controller
02F8-02FF COM2
0376 Secondary IDE Controller
0378-037F LPT1
03F6 Primary IDE Controller
03F8-03FF COM1
0400-045F ACPI I/O Space
0500-050F SMBus I/O Space
0CF8-0CFF PCI Configuration Port

4-10

PCI Devices

PCI Device

Device

Ven. ID

Dev. ID

Bus#

Dev#

Func#

Host Bridge

8086

2A00000000VGA-compatible Controller

8086

2A02000200Other Display Controller

8086

2A030002

01

Ethernet Controller

8086

104B001900UHCI USB Controller

8086

2834001A00UHCI USB Controller

8086

2835001A

01

Unknown Device

8086

283A001A07Unknown Device

8086

284B001B00PCI-to-PCI Bridge

8086

283F001C

00

UHCI USB Controller

8086

2830001D00UHCI USB Controller

8086

2831001D01UHCI USB Controller

8086

2832001D

02

Unknown Device

8086

2836001D07Subtractive Decode P2P Bridge

8086

2448001E

00

ISA Bridge

8086

2815001F00IDE Controller

8086

2850001F01IDE Controller

8086

2828001F02Smbus

8086

283E001F

03

System Resources

4-11

MS-9821 Mainboard

ISA Interrupt Allocation

IRQ

Description

IRQ0

System Timer

IRQ1

Keyboard Controller

IRQ2

Cascade Interrupt

IRQ3

COM2

IRQ4

COM1

IRQ5

PCI Device

IRQ6

PCI Device

IRQ7

LPT1

IRQ8

RTC

IRQ9

ACPI Controller Interrupt

IRQ10

PCI Device

IRQ11

PCI Device

IRQ12

PS/2 Mouse

IRQ13

Numeric Data Processor

IRQ14

Primary IDE Controller

IRQ15

Secondary IDE Controller

SMBus Resource Allocation

Device

Address

Description

MS-7

0101 111X

MSI ACPI Controller

DIMM Slot

1010 0000

SPD

SMBus Resource Allocation

ISA Interrupt Allocation

ISA DMA Channel Allocation

4-12
