MSA ULTIMA XL, ULTIMA XT Operating Manual
Operating Manual
ULTIMA XL
®
Series
ULTIMA XT
®
Series
Gas Monitors
Order No.: 10092331/00
MSA AUER GmbH
Thiemannstrasse 1
D-12059 Berlin
Germany
© MSA AUER GmbH. All rights reserved
Declaration of ConformityMSA
ULTIMA XL/ULTIMA XT
GB
3
Declaration of Conformity
Manufactured by: Mine Safety Appliances Company
1000 Cranberry Woods Drive
Cranberry Township, PA 16066 USA
European authorized representative:
MSA AUER GmbH
Thiemannstrasse 1
D-12059 Berlin
We declare that the product
ULTIMA XL Control Unit
based on the EC-Type Examination Certificates:
FM07ATEX0001X and FM07ATEX0004X
complies with the ATEX directive 94/9/EC, Annex III. Quality Assurance Notification
complying with Annex IV of the ATEX Directive 94/9/EC has been issued by INERIS of
France , Notified Body number: 0080
The product is in conformance with the EMC directive 89/336/EC, changed by
Directive 91/263/EC, 92/31/EC, 93/68/EC, with the following harmonized norms or normative documentation:
EN 50270 Type 2 EN 61000-6-3 EN 61000-6-4
We further declare that the product complies with the provisions of LVD
Directive 73/23/EC as amended by Directives 93/68/EC, with the following harmonized
norms or normative documentation:
EN 61010-1
MSA AUER GmbH
Dr. Axel Schubert
R&D Instruments
Berlin, July 2007
MSADeclaration of Conformity
ULTIMA XL/ULTIMA XT
4
GB
Declaration of Conformity
The manufacturer or his in the community established authorized representative
MSA AUER GmbH
Thiemannstrasse 1
D-12059 Berlin
declares that the product
ULTIMA XT
complies with the EMC directive 89/336/EC, changed by Directive 91/263/EC,
92/31/EC, 93/68/EC, with the following harmonized norms or normative documentation:
EN 50270 Type 2 EN 61 000 - 6 – 3
MSA AUER GmbH
Dr. Axel Schubert
R&D Instruments
Berlin, July 2007
Declaration of ConformityMSA
ULTIMA XL/ULTIMA XT
GB
5
Declaration of Conformity
Manufactured by: Mine Safety Appliances Company
1000 Cranberry Woods Drive
Cranberry Township, PA 16066 USA
European authorized representative:
MSA AUER GmbH
Thiemannstrasse 1
D-12059 Berlin
We declare that the product
ULTIMA XIR Sensor
A-UltX - Sens - a - b – 0
a = Gas Type: 38, 39, 58 or 59
b = Enclosure Type: 9 or 10
based on the EC-Type Examination Certificate: FM07ATEX0032X
complies with the ATEX directive 94/9/EC, Annex III. Quality Assurance Notification
complying with Annex IV of the ATEX Directive 94/9/EC has been issued by INERIS
of France , Notified Body number: 0080
The product is in conformance with the EMC directive 89/336/EC, changed by
Directive 91/263/EC, 92/31/EC, 93/68/EC, with the following harmonized norms or normative documentation:
EN 50270 Type 2 EN 61000-6-3 EN 61000-6-4
We further declare that the product complies with the provisions of LVD
Directive 73/23/EC as amended by Directives 93/68/EC, with the following harmonized
norms or normative documentation:
EN 61010-1
MSA AUER GmbH
Dr. Axel Schubert
R&D Instruments
Berlin, July 2007
MSADeclaration of Conformity
ULTIMA XL/ULTIMA XT
6
GB
Declaration of Conformity
Manufactured by: Mine Safety Appliances Company
1000 Cranberry Woods Drive
Cranberry Township, PA 16066 USA
European authorized representative:
MSA AUER GmbH
Thiemannstrasse 1
D-12059 Berlin
We declare that the product
ULTIMA XE Sensor
A-UltX - Sens - a - b – 0
a = Gas Type: 31, 32, 33, 51, 52 or 53
b = Enclosure Type: 1 or 8
based on the EC-Type Examination Certificate: FM07ATEX0031X
complies with the ATEX directive 94/9/EC, Annex III. Quality Assurance Notification
complying with Annex IV of the ATEX Directive 94/9/EC has been issued by INERIS of
France , Notified Body number: 0080
The product is in conformance with the EMC directive 89/336/EC, changed by
Directive 91/263/EC, 92/31/EC, 93/68/EC, with the following harmonized norms or normative documentation:
EN 50270 Type 2 EN 61000-6-3 EN 61000-6-4
We further declare that the product complies with the provisions of LVD
Directive 73/23/EC as amended by Directives 93/68/EC, with the following harmonized
norms or normative documentation:
EN 61010-1
MSA AUER GmbH
Dr. Axel Schubert
R&D Instruments
Berlin, July 2007
Table of ContentsMSA
ULTIMA XL/ULTIMA XT
GB
7
Table of Contents
1 Safety Regulations ................................................................................................. 9
1.1 Correct Use .................................................................................................. 9
1.2 Liability Information ....................................................................................... 9
1.3 Safety and Precautionary Measures to be Adopted ................................... 10
1.4 MSA Permanent Instrument Warranty ........................................................ 12
2 Introduction .......................................................................................................... 14
2.1 General Description .................................................................................... 14
2.2 Identifying Your Unit ................................................................................... 14
2.3 Installing Your Gas Monitor ........................................................................ 19
2.4 Installing the ULTIMA XT Gas Monitor ....................................................... 20
2.5 Installing the ULTIMA XL Gas Monitor ....................................................... 21
2.6 Installing the ULTIMA XIR Gas Monitor ...................................................... 22
2.7 Electrical Connections for ULTIMA X Gas Monitors ................................... 23
2.8 Wiring for all Models ................................................................................... 23
2.9 ULTIMA XIR ............................................................................................... 26
2.10 Installing the ULTIMA X Remote Sensor Module ....................................... 29
2.11 Electrical Connections for the ULTIMA X Series Remote Sensor Module .. 29
3 Start-up and Calibration ...................................................................................... 31
3.1 Initial Start-up ............................................................................................. 31
3.2 Calibration Basics ....................................................................................... 33
3.3 ULTIMA X Series Gas Monitor Calibration Procedure ............................... 35
3.4 Span Gas Values ........................................................................................ 36
3.5 ULTIMA X Series Gas Monitor Calibration ................................................. 46
3.6 Standard Calibration ................................................................................... 47
3.7 Oxygen Calibration ..................................................................................... 50
3.8 XIR Calibration ........................................................................................... 51
3.9 Optional Push-button Calibration ................................................................ 52
MSATable of Contents
ULTIMA XL/ULTIMA XT
8
GB
3.10 Calibration Using a HART® Communicator ............................................... 52
3.11 Standard Calibration Procedures ............................................................... 55
3.12 Initial Calibration Procedures ...................................................................... 58
3.13 User [Stepped] Calibration Procedures ...................................................... 58
3.14 Sample Calibration Display Screens .......................................................... 61
3.15 Troubleshooting .......................................................................................... 74
4 Specifications ....................................................................................................... 80
4.1 HART Field Device Specification ................................................................ 89
4.2 Product Overview ....................................................................................... 90
4.3 Product Interfaces ...................................................................................... 91
4.4 Universal Commands ................................................................................. 96
4.5 Common-Practice Commands ................................................................... 96
4.6 Performance ............................................................................................. 121
4.7 Capability Checklist .................................................................................. 123
4.8 Default Configuration ................................................................................ 124
4.9 Marking, Certificates and Approvals according to the
Directive 94/9/EC [ ATEX ] ....................................................................... 125
5 Maintenance ....................................................................................................... 131
5.1 General ..................................................................................................... 131
5.2 ULTIMA XIR Cleaning Procedure ............................................................. 131
6 Ordering Information ......................................................................................... 136
7 Appendix ............................................................................................................. 141
7.1 Installation Drawings ............................................................................... 141
Safety RegulationsMSA
ULTIMA XL/ULTIMA XT
GB
9
1 Safety Regulations
1.1 Correct Use
The ULTIMA XL/ULTIMA XT Series are fixed gas monitors for measuring toxic and
combustible gases as well as oxygen. They are suitable for outdoor and indoor applications without limitations, e.g. offshore industry, chemical and petrochemical industry, water and sewage industry. Using sensors, the instruments test the ambient
air and trigger the alarm as soon as the gas exceeds a specific concentration level.
It is imperative that this operating manual be read and observed when using the
ULTIMA XL/ULTIMA XT Series of gas monitors. In particular, the safety instructions, as well as the information for the use and operation of the apparatus, must be
carefully read and observed. Furthermore, the national regulations applicable in the
user's country must be taken into account for a safe use.
Alternative use, or use outside this specification will be considered as non-compliance. This also applies especially to unauthorised alterations to the apparatus and
to commissioning work that has not been carried out by MSA or authorised persons.
1.2 Liability Information
MSA accepts no liability in cases where the product has been used inappropriately
or not as intended. The selection and use of the product are the exclusive responsibility of the individual operator.
Product liability claims, warranties also as guarantees made by MSA with respect
to the product are voided, if it is not used, serviced or maintained in accordance with
the instructions in this manual.
Danger!
This product is supporting life and health. Inappropriate use, maintenance or servicing may affect the function of the device and thereby seriously compromise the user’s life.
Before use the product operability must be verified. The product must
not be used if the function test is unsuccessful, it is damaged, a competent servicing/maintenance has not been made, genuine MSA spare
parts have not been used.
MSASafety Regulations
ULTIMA XL/ULTIMA XT
10
GB
1.3 Safety and Precautionary Measures to be Adopted
(1) The ULTIMA X Series Gas Monitors described in this manual must be in-
stalled, operated and maintained in strict accordance with their labels, cautions, warnings, instructions, and within the limitations stated.
(2) The ULTIMA X Series Gas Monitor is designed to detect gases or vapors in
air. It cannot measure the concentration of gases or vapors in steam or inert
or oxygen-deficient atmospheres. The oxygen sensor can measure oxygendeficient atmospheres.
(3) Electrochemical sensors are sealed units which contain a corrosive electro-
lyte. Should a sensor develop leakage, it must be immediately removed from
service; then, remove it from the sensing head and discard it properly. Caution
must be exercised so that the electrolyte does not contact skin, eyes, clothing
or circuitry; otherwise, serious personal injury [burns] and/or equipment damage may result.
(4) Use only genuine MSA replacement parts when performing any maintenance
procedures provided in this manual. Failure to do so may seriously impair instrument performance. Repair or alteration of the ULTIMA X Series Gas Monitor, beyond the scope of these maintenance instructions or by anyone other
than an authorized MSA service personnel, could cause the product to fail to
perform as designed and persons who rely on this product for their safety
could sustain serious personal injury or loss of life.
(5) General-purpose [GP] ULTIMA X Series Gas Monitors can be a source of ig-
nition. Install, locate, and operate GP models in a non-hazardous area and in
accordance with all applicable codes. If a hazardous area must be monitored,
use only an explosion-proof/ flameproof ULTIMA X Series Gas Monitor model.
(6) The ULTIMA XIR Infrared combustible gas monitor detects the presence of
most combustible gases by identifying the difference in the amount of infrared
light energy absorbed during the presence of these gases. This monitor, however, does NOT detect the presence of hydrogen gas and must never be used
to monitor for hydrogen gas.
(7) The standard ULTIMA XIR Infrared Combustible Gas Monitor does not detect
the presence of acetylene gas and the presence of acetylene gas will degrade
sensor performance. Custom-built acetylene sensors are available through
your MSA representative.
Attention!
The following safety instructions must be observed implicitly. Only in this
way can the safety and health of the individual operators, and the correct
functioning of the instrument, be guaranteed.
Safety RegulationsMSA
ULTIMA XL/ULTIMA XT
GB
11
(8) As with all gas monitors of these types, high levels of, or long exposure to, cer-
tain compounds in the tested atmosphere could contaminate the sensors. In
atmospheres where an ULTIMA X Series Gas Monitor may be exposed to
such materials, calibration must be performed frequently to ensure that operation is dependable and display indications are accurate.
(9) The ULTIMA X Series Gas Monitor must not be painted. If painting is done in
an area where a Monitor is located, care must be exercised to ensure that
paint is not deposited on the sintered, metal flashback arrestor in the inlet fitting of the ULTIMA X Series Gas Monitor, if so equipped. Such paint deposits
would interfere with the diffusion process, whereby a sample of the atmosphere being monitored diffuses into the Monitor.
(10) The only absolute method to ensure proper overall operation of an ULTIMA X
Series Monitor is to check it with a known concentration of the gas for which it
has been calibrated. Consequently, calibration checks must be included as
part of the routine inspection of the system.
(11) Protect the ULTIMA X Series Gas Monitor from extreme vibration. Do not
mount the sensing head in direct sunlight as this may cause overheating of the
sensor.
MSASafety Regulations
ULTIMA XL/ULTIMA XT
12
GB
1.4 MSA Permanent Instrument Warranty
Warranty
Seller warrants that this product will be free from mechanical defect or faulty workmanship for
- Gas monitor: eighteen [18] months from date of shipment or one [1] year from
installation, whichever occurs first;
- Oxygen, Toxic or Catalytic Combustible Sensor: eighteen [18] months from date
of shipping or one [1] year from installation, whichever occurs first;
- IR sensor source, ten [10] years from date of shipment. All other IR components: Two [2] years from date of shipment.
This warranty is applicable provided the product is maintained and used in accordance with Seller's instructions and/or recommendations. This warranty does not apply to expendable or consumable parts, whose normal life expectancy is less than
one [1] year.
The Seller shall be released from all obligations under this warranty in the event repairs or modifications are made by persons other than its own or authorized service
personnel or if the warranty claim results from physical abuse or misuse of the product. No agent, employee or representative of the Seller has any authority to bind the
Seller to any affirmation, representation or warranty concerning the goods sold under this contract. Seller makes no warranty concerning components or accessories
not manufactured by the Seller, but will pass onto the Purchaser all warranties of
manufacturers of such components. THIS WARRANTY IS IN LIEU OF ALL OTH-
ER WARRANTIES, EXPRESSED, IMPLIED OR STATUTORY, AND IS STRICTLY LIMITED TO THE TERMS HEREOF. SELLER SPECIFICALLY DISCLAIMS
ANY WARRANTY OF MERCHANTABILITY OR OF FITNESS FOR A PARTICULAR PURPOSE.
Safety RegulationsMSA
ULTIMA XL/ULTIMA XT
GB
13
Exclusive Remedy
It is expressly agreed that Purchaser's sole and exclusive remedy for breach of the
above warranty, for any tortious conduct of Seller, or for any other cause of action,
shall be the repair and/ or replacement at Seller's option, of any equipment or parts
thereof, which after examination by Seller is proven to be defective. Replacement
equipment and/ or parts is provided at no cost to Purchaser, F.O.B. Seller's Plant.
Failure of Seller to successfully repair any nonconforming product shall not cause
the remedy established hereby to fail of its essential purpose.
Exclusion of Consequential Damage
Purchaser specifically understands and agrees that under no circumstances will
seller be liable to purchaser for economic, special, incidental or consequential damages or losses of any kind whatsoever, including but not limited to, loss of anticipated profits and any other loss caused by reason of non-operation of the goods. This
exclusion is applicable to claims for breach of warranty, tortious conduct or any other cause of action against seller.
MSAIntroduction
ULTIMA XL/ULTIMA XT
14
GB
2 Introduction
2.1 General Description
The ULTIMA X Gas Monitor is designed to sample the environment where mounted
and alert you to potentially dangerous levels of your target gas, depending on your
particular model. The unit is factory-calibrated and shipped ready for installation.
2.2 Identifying Your Unit
The ULTIMA XT Gas Monitor is housed in a rugged, plastic general-purpose enclosure [Æ Fig. 1].
Fig. 1 General-Purpose ULTIMA XT Monitor
The ULTIMA XL Gas Monitor is housed in a 316 stainless steel explosion-proof/
flameproof enclosure [Æ Fig. 2].
IntroductionMSA
ULTIMA XL/ULTIMA XT
GB
15
Fig. 2 Flameproof ULTIMA XL Monitor
MSAIntroduction
ULTIMA XL/ULTIMA XT
16
GB
The ULTIMA XIR Gas Monitor is housed in a 316 stainless steel flameproof enclosure [Æ Fig. 3].
Fig. 3 Flameproof ULTIMA XL with IR Monitor
Remote Sensor Models are shown in Æ Fig. 4, Æ Fig. 5 and Æ Fig. 6.
IntroductionMSA
ULTIMA XL/ULTIMA XT
GB
17
Fig. 4 General-Purpose XT Remote Sensor Model
MSAIntroduction
ULTIMA XL/ULTIMA XT
18
GB
Fig. 5 Flameproof XL Remote Sensor Model
Fig. 6 Flameproof XIR Remote Sensor Model'
IntroductionMSA
ULTIMA XL/ULTIMA XT
GB
19
To determine your sensor type and options, check the shipping carton. Checked
items are included in the carton. Also check the sensor ID label located on the sensor module. The carton label identifies:
- Type of unit supplied [Gas Monitor, Gas Monitor Less Sensor, or
Sensing Module]
- Type of gas [combustible gas, toxic gas or oxygen]
- Range [% LEL, PPM [parts per million], or %]
- Output [3 wire, 4 to 20 mA]
2.3 Installing Your Gas Monitor
Generally, the ULTIMA X Series Gas Monitors or remote sensing module should be
mounted close to the area where a leak is likely to occur or where the gas is expected. Install the ULTIMA X Series Gas Monitors or the remote sensing module at a
high level [ceiling] or low level [floor], depending on the density of the gas most likely
to be found.
For further information see installation drawings in the appendix.
Attention!
Mount the ULTIMA Gas Monitor or the remote sensor module with the
sensor inlet fitting [Æ Fig. 1, Æ Fig. 2, Æ Fig. 4 or Æ Fig. 5] pointed
downward; otherwise, the inlet may become clogged with particulate
matter or liquids.
Mount the ULTIMA XIR Gas Monitor or Remote Sensing Module with the
sensor inlet fitting extended horizontally from the main enclosure
Æ Fig. 3 and Æ Fig. 6] to help prevent the build-up of particulate or liquid
matter on the monitor's optical surfaces.
Do not paint the ULTIMA X Series Gas Monitors. If painting is done in an
area where a sensor is located, exercise CAUTION to ensure paint is not
deposited on the sensor inlet fitting. Such paint deposits would interfere
with the diffusion process, whereby a sample of the monitored atmosphere diffuses into the sensor. In addition, solvents in the paint may
cause an alarm condition to occur.
Protect the ULTIMA X Series Gas Monitors from extreme vibration. Do
not mount sensing head in direct sunlight as this may cause overheating
of the sensor.
MSAIntroduction
ULTIMA XL/ULTIMA XT
20
GB
2.4 Installing the ULTIMA XT Gas Monitor
Remove lid and drill enclosure for power/signal cable entry. Use one of the following
methods to mount the general-purpose ULTIMA XT Gas Monitor/Less Sensor or
the ULTIMA XT Gas Monitor.
- Using customer-installed wiring holes, install the ULTIMA XT Gas Monitor to the
end of rigid conduit.
- Use mounting holes in the corners of the ULTIMA XT enclosure to mount directly to a wall.
Warning!
Do not locate the general-purpose enclosure models in an area which
may contain a flammable mixture of gas and air; otherwise, an explosion
may occur. The general-purpose ULTIMA X Series Gas Monitors can be
a source of ignition and must not be mounted in an area where a flammable mixture of combustible gas and air may become present; otherwise, an explosion may occur. If such a location must be monitored, use
a flameproof gas monitor.
IntroductionMSA
ULTIMA XL/ULTIMA XT
GB
21
2.5 Installing the ULTIMA XL Gas Monitor
Fig. 7 Flameproof XIR Remote Sensor Model
- The ULTIMA XL Gas Monitor main enclosure can be rotated 360° and mounted
to ensure easy access to any of the three entryways. The electronics assembly
can be installed in any of the four self-aligning positions to allow proper sensor
orientation.
- The ULTIMA XL Gas Monitor sensor is not shipped attached to the main enclosure. Mount the sensor module with the applicable conduit only. Ensure the sensor wiring harness is through the entry and the sensor is pointing downward
[except IR, which mounts to the side]. Tighten with a strap wrench.
MSAIntroduction
ULTIMA XL/ULTIMA XT
22
GB
2.6 Installing the ULTIMA XIR Gas Monitor
Fig. 8 ULTIMA XIR
- Use the optional mounting strap [P/N 10047562] that can be attached to the rear
holes of the ULTIMA XL Gas Monitor [Æ Fig. 7].
- The ULTIMA XL Gas Monitor main enclosure can be rotated 360° and mounted
to ensure easy access to any of the three entryways. The electronics assembly
can be installed in any of the four self-aligning positions to ensure the sensor is
properly oriented.
Warning!
The ULTIMA XIR Combustible Gas Monitor contains no user- or fieldserviceable parts and must be returned to the factory for repair. Any attempt to open the monitor will damage the unit and void the warranty.
Attention!
Under no circumstances should a tool or excessive force be applied to
the two legs that support the unit's reflectors during installation or removal of the sensor [Æ Fig. 8]. Applying force to the legs can permanently
damage the monitor.
It is recommended that the monitor's environmental guard be installed
on the unit at all times. If the monitor is to be operated without the guard,
frequent checks should be made to ensure particulate or liquid matter
has not collected on the windows.
IntroductionMSA
ULTIMA XL/ULTIMA XT
GB
23
2.7 Electrical Connections for ULTIMA X Gas Monitors
This assembly is marked to identify power, ground and signal connections.
A three-wire connection is required for all:
- Combustible Gas models
- Toxic and Oxygen Models with 4 to 20 mA output.
2.8 Wiring for all Models
Installation
General Information
Installation Instructions for Following the EMC Directives
The devices of MSA have been developed and tested in accordance with the EMC
Directives 89/336/EEC, 91/263/EEC, 92/31/EEC, and 93/68/EEC and the corresponding standards EN 50270. The requirements of the EMC Directives can only
be met by following the manufacturer’s installation instructions. This applies only to
tested devices and systems of the manufacturer.
General Instructions on the Installation of Tested Devices and Systems of
MSA to ensure that the EMC Directives are followed
- For the connection of the various devices to the power supply system a faultfree ground or fault-free equipotential bonding must be provided
- An appropriate supply voltage free of feedback to the external source in accordance with the EMC Directives must be used.
- If the devices are supplied from a direct voltage [DC] source, the supply cable
must be screened.
- Screened cable is to be used to connect the sensors.
Warning!
Before wiring the ULTIMA X Series Gas Monitors, disconnect power
source supplying the monitor; otherwise, electrical shock could occur.
For ULTIMA XL and XIR installations, the internal grounding terminal
must be used for equipment grounding. The external grounding terminal
is only to be used as a supplemental bonding connection where local authorities permit or require such a connection.
MSAIntroduction
ULTIMA XL/ULTIMA XT
24
GB
- Control cables must be screened [reset, acknowledge, measurement current
output, printer, etc.].
- Screened cable must have at least 80 % coverage by the screening.
- Control and sensor cables must be laid physically apart from power supply cables.
- Screened cables must be laid in one piece. If it should prove necessary to extend a cable by way of a terminal box, the terminal box must be screened, and
the connections in the box must be kept as short as possible.
- Unscreened cables and cables from which the insulation has been stripped
must be as short as possible and must be laid without loops to the appropriate
terminal posts.
- External devices that are operated by the gas warning units [horns, contactors,
pumps, motors, etc.] must be radio-screened and follow the EMC Directives.
- If the EMC filters of the device are physically remote, the power supply cable
between the filter and the device must be screened.
- If additional high-voltage surge protection measures are required an appropriate high-voltage protection filter, approved by MSA, must be installed in the sensor cable.
Instructions on Meeting the EMC Requirements on the ULTIMA XL
To meet the EMC product standard EN 50270 [Electromagnetic Compatibility], the
following points must be observed:
General:
- A clean grounding point must be provided for the equipotential bonding.
- Power supply cables are to be kept away from remote measurement/data lines
[> 30 cm].
- All cables, unless otherwise specified, must be screened [> 80% coverage];
they are to be connected to the rack.
- The rack is to be equipped with separate equipotential bonding.
- The connection of the cable screen should be as short as possible.
- Cables for data transmission must be screened. There must not be any potential
difference between the interface of the cable screen and ground. The cable
screen must have good contact with the housings of the plug connectors.
For further information see installation drawings in the appendix.
IntroductionMSA
ULTIMA XL/ULTIMA XT
GB
25
Conduit may also be needed in areas where large amounts of electrical noise is expected.
Use caution when selecting a cable size. The following tables express the maximum cable length when only using the ULTIMA X Series Gas Monitors.
ULTIMA X Series options may take additional power which requires a heavier cable
or a short cable run.
When selecting cable size, consider future needs [i.e., addition of sensors and/or
options available with the ULTIMA X Series Monitors]. See Chapter 4, "Specifications" for proper input voltage.
Ensure that water and dirt are not able to enter the unit via the wire or conduit. If the
unit is installed in a location known to be wet or damp, it is good practice to loop or
bend the entry into the unit that prevents water incursion.
Use of External Controllers
The ULTIMA X Series Gas Monitors may be connected to any device capable of
accepting 4 to 20 mA analog signals such as:
- Gasgard XL
- Model 9010/9020 Controller unit
- Suprema Controller
- Programmable controllers
- DCS's, etc.
An external power supply is required. [For power requirements, see Chapter 4,
"Specifications".] All connections should be made by following appropriate wire
code procedures.
- See following tables for typical cable length and wire size for installation.
Warning!
When using any of the ULTIMA X Series accessories with the 4 to 20 mA
output ULTIMA X Series Gas Monitor, a three-wire connection must be
used. Failure to use a three-wire connection could damage the electronics within the ULTIMA X Series Gas Monitor.
Be sure to install your ULTIMA X Series Gas Monitor according to National and local procedural codes. Failure to do so can result in an unsafe condition.
MSAIntroduction
ULTIMA XL/ULTIMA XT
26
GB
ULTIMA XL and XT Maximum Cable Length and 4-20 mA Signal Load
2.9 ULTIMA XIR
Maximum Cable Length and 4-20 mA Signal Load
- The ULTIMA XL/XT Gas Monitors operate in the current source mode
[Æ Fig. 10 for general-purpose]
[Æ Fig. 11 for explosion-proof/flameproof].
Power Supply 24 Volts
Cable Size
1.00 mm2 Cable [18 AWG] 762 m [2500 ft]
1.50 mm
2
Cable [16 AWG] 1280 m [4200 ft]
2.50 mm
2
Cable [12 AWG] 3048 m [10000 ft]
Max. Load on 4-20 mA Signal 500 Ohms
Power Supply 24 Volts
CONFIGURATION
1.00 mm
2
Cable [18 AWG] 610 m [2000 ft]
1.50 mm2 Cable [16 AWG] 1070 m [3500 ft]
2.50 mm
2
Cable [12 AWG] 1524 m [5000 ft]
Max. Load on 4-20 mA Signal 500 Ohms
The HART communications require the load on the 4-20 mA to be
between 230 to 500 ohms.
IntroductionMSA
ULTIMA XL/ULTIMA XT
GB
27
Fig. 9 Circuit Board
(1) Connect 24 VDC power lead to J1-1 [Æ Fig. 9].
(2) Connect J1-2 to 4 to 20 mA input on remote system.
(3) Connect the signal ground to J1-3.
(4) Connect the sensor module to labeled connector J-3 on the main pc board.
(5) Assemble lid on enclosure.
MSAIntroduction
ULTIMA XL/ULTIMA XT
28
GB
Fig. 10 General-Purpose Three-Wire 4-20 mA Operation
Fig. 11 Flameproof Three-Wire 4-20 mA Operation
IntroductionMSA
ULTIMA XL/ULTIMA XT
GB
29
2.10 Installing the ULTIMA X Remote Sensor Module
The Remote Sensor Module is used with the ULTIMA X Gas Monitor/less sensor.
The Remote Sensor Module can be mounted in a manner similar to the gas monitor
installation in the preceding procedure and at a maximum distance outlined in
“Remote Module Wiring and Placement“.
Permanently connect 6 mm [1/4"] ID tubing to the post on the environmental guard.
Route this tubing to the ULTIMA X Gas Monitor, ensuring that there are no kinks,
leaks or other obstructions. Secure this tubing near the monitor; it is used to deliver
check gas to the sensor module during calibration.
2.11 Electrical Connections for the ULTIMA X Series Remote
Sensor Module
Five conductors are required for the ULTIMA XL and ULTIMA XT Remote Sensor
Modules to operate catalytic or electrochemical sensor modules of the ULTIMA XE
type. Four conductors are required for the ULTIMA XIR Remote Sensor Module.
The ULTIMA X Series Monitor has a five-wire terminal to accommodate up to
1.50 mm
2
[16 AWG] conductors.
For open wiring, shielded wire or cable should be used to minimize the possibility
of noise interference and contact with other voltages. Selection of this shielded cable must comply with local requirements.
Warning!
Before wiring the ULTIMA X Series Remote Sensor Module, disconnect
the power source feeding the Remote Sensor Module and the ULTIMA X
Series Gas Monitor/Less Sensor; otherwise, electrical shock could occur.
Attention!
When installing an ULTIMA X Series Remote Sensor Module with its
mating ULTIMA X Series Gas Monitor/Less Sensor, follow National
Electrical and local procedural Codes for US, or relevant codes for country of installation; failure to do so can result in an unsafe condition.
MSAIntroduction
ULTIMA XL/ULTIMA XT
30
GB
Remote Module Wiring and Placement
At the ULTIMA X Series Remote Sensor Location:
(1) Open the ULTIMA X Series Remote Sensor cover by removing lid.
For the ULTIMA XT Gas Monitor, route the cable from the Gas Monitor
through a customer-supplied opening in the enclosure and wire it to the terminal block [Æ Fig. 4].
For the ULTIMA XL or XLIR Gas Monitor, route the cable from the Gas Mon-
itor through a wire entry hole in the enclosure and wire it to the terminal block
[Æ Fig. 5 or Æ Fig. 6].
(2) Verify the identity of each conductor of the cable and connect the wire to the
terminal block.
(3) Re-install the cover of the ULTIMA X Series Remote Sensor.
Gas Type Minimum Wire Size Maximum Distance
Toxic, Oxygen and
Catalytic Combustible
1.00 mm
2
[18 AWG] 15.2 m [50 ft]
1.50 mm2 [16 AWG] 30.5 m [100 ft]
*IR Combustible 1.50 mm
2
[16 AWG] 15.2 m [50 ft]
2.50 mm2 [12 AWG] 30.5 m [100 ft]
CE-Approved instruments have a maximum 15 m [50 ft.]
distance.
Incoming power and signal cable shield should be earth grounded at the
power source. Connect power and remote sensor cable shields together
in the main housing.
Loading...
