ALTAIR
Gas Detector
io360
THE FUTURE OF AREA MONITORING.
The Simple Usability of a Smart Home Product.
The Rugged, Reliable Performance You Expect from MSA.
You shouldn’t need IT skills and special equipment to set up your area monitoring network—
it should just work. ALTAIR io360 Gas Detectors are precongured and ready-to-go out of the box,
requiring less time for training and setup.
Guided setup, installation tips, and real-time feedback replace complex instructions, scrolling through
screens, and overwhelming menu selections. All you need are a few quick swipes on the Safety io Grid
mobile app to know you got it right the rst time.
Flexible Monitoring and Eortless Connectivity Make Your
Workers and Job Sites Safer
Gas detection and local
alarms for high-risk areas.
Just turn on your
ALTAIR io360 Gas Detectors
and deploy where needed.
The MSA HUB allows
up to 32 ALTAIR io360
Gas Detectors to form
a network you manage
locally via the
Safety io Grid mobile app.
3
Connecting your gas detection
network to Safety io Grid gives
you the power to remotely
manage and monitor your
eet of detectors, capture
data, and take action
to create safer sites.
MSAsafety.com
Monitor Along a Fenceline, Confined Space or Any
High-Risk Area Where a Gas Hazard Might Occur.
UpstreamMidstreamDownstream Chemical
Plants
Emergency
Response
Underground
& Vessels
Construction
GENERAL AREA
MONITORING
Place throughout your site
during a high-risk operation
or whenever you need
additional detection.
PERIMETER
MONITORING
Cover an entire fence line
or create smaller detection
perimeters around
a targeted work area.
CONFINED SPACE
MONITORING
Place detectors in a conned
space for continuous monitoring,
even in a Class 1,
Division 1 (zone 0) location.
The ALTAIR io360 Gas Detector Oers a Combination
of Runtime and Sensor Performance,
Unmatched in the Industry. No Compromises.
Most area monitors have runtimes measured in hours or days.
The ALTAIR io360 Gas Detector gives you months—
in a hand held, compact design. You spend less time maintaining, more time monitoring.
50–60 DAYS
4 GAS
Catalytic Bead Combustible, O₂, & CO/H₂S
80–85 DAYS
1–3 GAS
O₂ & CO/H₂S
When batteries near end-of-life, respond proactively and minimize unplanned downtime...
the ALTAIR io360 Gas Detector noties you locally and remotely.
Better Sensors Mean
Better Performance.
WITH MSA XCELL® SENSOR TECHNOLOGY, YOU GET:
The fastest response time.
Better stability and accuracy.
4 years of expected life for combustible and toxic sensors.
End-of-life warning to minimize downtime.
COMBUSTIBLE TOXIC
TOXIC
(PICK 1)
• CO/H₂S • H₂S • CO
5
O₂
ALTAIR io360 Gas Detector use XCell® Combustible and Toxic sensors
MSAsafety.com
The Rugged, Compact Design You Expect From MSA.
With an IP68 Rating.
You work in tough environments. Your gas detectors need to work in them too.
SUBMERGE IT*
6.6 ft. (2 m) for
up to 60 minutes.
STICK IT
50 lb. (220 Newton)
force magnet.
SPRAY IT*
Resistant to sprays.
HANG IT
Integrated D-ring.
WEATHER IT*
Withstands heavy rain,
wind, and dust.
DROP IT
Drop tested
at 10 ft. (3 m).
COMPACT
1.6 lb. (0.73 kg)
No external antennas or battery packs.
* consistent/pass with testing requirements of IP68.
PORTABLE
Carry multiple detectors at a time. Make fewer trips
when deploying. Save time and hassle.
Specifications
ALTAIR io360 Gas Detector Specification
WARRANTY 4 years
Oxygen Sensor: 2 years
Low-energy Combustible: 1 year
DURABILITY Drop Test: 10 ft. (3 m)
Ingress Protection: IP68
TEMPERATURE Normal Operating: –4° to 131° F (–20° to 55° C)
Extending Operating: –40° to 131° F (–40° to 55° C)
Storage: 32 to +95 °F (0 to 35 °C)
HUMIDITY Intermittent: 5%–95%
Non-condensing: 15%–90%
POWER Batteries: 3 replaceable lithium thionyl chloride batteries
Runtime: nominally 50-60 days 4-gas,
80-85 days without combustible sensor
PHYSICAL Weight: 1.6 lb. (0.7 kg)
Dimensions: 5.2” x 5.6” x 2.7” (132 x 142 x 69 mm)
ALARMS Audible: 90 dB @ 1 ft. (0.3 m)
Visual: RGB LED
DATA LOGGING Periodic, Event, Instrument, Calibration logs stored on
detector (at least 2 months) and sent to Safety io Grid.
RANGE Up to 1000 ft. (~300 m) line of site HUB to detector
2 mesh hops to extend range.
RADIO 915 MHz, Bluetooth, RFID
SENSORS Gas Range Resolution
LEL 0-100% 1%
O₂ 0-30% 0.1%
CO 0-1999 ppm 1 ppm
H₂S 0-200 ppm 1 ppm
Certifications
ALTAIR io360 Gas Detector
Certifications**
UL (U.S.)
DIVISION Class I, Division 1, Groups A, B, C, and D
ATEX
ZONE II 1G Ex da ia IIC T4 Ga
IEC
ZONE Ex da ia IIC T4
General
TEMPERATURE RATING T4, -40°C ≤ Ta ≤ +60°C
MSA HUB Certifications***
QPS/CSA
DIVISION Class I, Division 2, Groups A, B, C, and D
ZONE Ex ec IIC T4 Gc (Zone 2)
ATEX
ZONE II 3G ec [ic] IIC T4 Gc
IEC
ZONE Ex ec [ic] IIC T4
General
TEMPERATURE RATING -20°C ≤ Ta ≤ +60°C
** CSA & Inmetro Pending
*** Inmetro Pending
Additional certication information available at msasafety.com.
MSA HUB Specifications
WARRANTY 4 years
DURABILITY Ingress protection IP67
TEMPERATURE
RANGE
HUMIDITY 10 to 90% relative humidity, non-condensing
POWER Nominal: 24 V DC line power
PHYSICAL Weight: 3 lb. (1.4 kg)
RADIO 915 MHz, Bluetooth, Cellular 2G/3G/4G,
ETHERNET 10/100 mbit
–4° to 140° F (–20° to +60° C) for hazardous locations
Range: 6 V to 32 V
Dimensions: 7.5” x 7.7” x 3.9”
(190mm x 195mm x 99mm)
2.4 GHz Wi-Fi (a,b,g,n)
ENHANCE YOUR ALTAIR io360
GAS DETECTOR EXPERIENCE
FLEET
MANAGER
Assess, address, & share
your MSA eet status—
all from your browser.
LIVE
MONITOR
Know what’s going on
—and take action—
when seconds count.
For more information,
please visit safetyio.com.
MSAsafety.com
7
This is the Future
of Area Monitoring.
This is the ALTAIR io360
Gas Detector.
Both the detectors and the networks
can be quickly and easily recongured
for your changing needs.
ALTAIR io360 Gas Detector
UL (U.S.)
Congurations
LEL, O₂, CO/H₂S
H₂S
Basic Configurations*
Quantity
4 pack 10207176 10207459
Precongured Kits
with MSA HUB
Single Detector 1 pack 10207181 10207442
Precongured Kits
with MSA HUB
Single Detector 1 pack 10207419 10207406
8 pack 10207456 10207438
16 pack 10207467 10207460
32 pack 10207452 10207439
4 pack 10207435 10207407
8 pack 10207420 10207424
16 pack 10207421 10207403
32 pack 10207432 10207408
Color
Black Green
PRE-CONFIGURED KITS
4, 8, 16, OR 32 ALTAIR io360 GAS DETECTORS
+ 1 MSA HUB
For users who want one conguration
of gas detector. HUB and detectors are paired
as a network, for ready, out-of-the-box experience.
Detectors can be added, dropped, and/or recongured
using the Safety io Grid mobile app.
CUSTOM OPTIONS
ANY NUMBER OF ALTAIR io360 GAS DETECTORS
& MSA HUBS
For users whose needs may change
from job to job or who plan to have larger eets.
Order multiple detectors and HUBs, and easily
construct networks with the Safety io Grid mobile app.
Accessories*
10200411 MSA HUB, ALTAIR io360, 915 MHz
10195741SP MSA HUB ethernet cable
10205504 Sunshield, io360
Calibration*
10048890 58 L, Methane 2.5%, O₂-15%, CO-60 ppm, H₂S-20 ppm
10153845 58 L, H₂S-20 ppm
467895 Fixed ow regulator
Replaceables & Spares*
10201430 Replacement kit, battery, 3 pack, io360
10201438 Sensorshield, replacement, io360
10201439 Cap, calbiration, replacement, io360
10203709 Replacement kit, combustible sensor, io360
10203721 Replacement kit, comb-evo sensor, io360
10203724 Replacement kit, O₂ sensor, io360
10203710 Replacement kit, CO/H₂S sensor, io360
10201433 Replacement kit, horn, io360
10201434 Replacement housing front, black, io360
10201435 Replacement housing back, black, io360
10205505 Replacement housing front, green, io360
10205506 Replacement housing back, green, io360
10201437 Replacement kit, screws, io360
10205507 ALTAIR io360, sensor plug kit
10195720SP MSA HUB AC cord, NA (type B)
10208430SP MSA HUB AC cord, CH (type L)
10208431SP MSA HUB AC cord, AR (type I)
*Need something dierent? Visit www.msasafety.com or Contact MSA for more options.
Note: This Bulletin contains only a general description of the products shown. While product
uses and performance capabilities are generally described, the products shall not, under any
circumstances, be used by untrained or unqualied individuals. The products shall not be used
until the product instructions/user manual, which contains detailed information concerning the
proper use and care of the products, including any warnings or cautions, have been thoroughly
read and understood. Specications are subject to change without prior notice.
0800-104-MC / 01.2020
