MSA 3S, 3S small, 3S-V, 3S-Vg, 3S-EZ Operating Manual

...
MSAsafety.com
Operating Manual
3S Full Face Mask – Positive Pressure
Order No.: 10090494/03
MSA Europe GmbH Schlüsselstrasse 12 8645 Rapperswil-Jona Switzerland info.ch@MSAsafety.com www.MSAsafety.com
©
MSA 2018 All rights reserved
3S Full Face Mask – Positive Pressure
3
GB
Contents
1 Safety Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Correct Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Liability Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Mask Versions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Special Versions for using until -40°C. . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 Marking/Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Special Versions for using until -40°C. . . . . . . . . . . . . . . . . . . . . . . . . 7
Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 Donning the Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 Leak Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3.3 Removing the Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
4 Cleaning, Disinfection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 Cleaning/Disinfection with a Washing Machine . . . . . . . . . . . . . . . . 12
4.2 Cleaning/Disinfection with an Ultrasonic Cleaner . . . . . . . . . . . . . . . 12
4.3 Cleaning by Hand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.4 Disinfection by Hand. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.1 Maintenance Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.2 Maintenance Intervals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.3 Maintenance of the Exhalation Valve . . . . . . . . . . . . . . . . . . . . . . . . 14
5.4 Replacing the Speech Diaphragm . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.5 Tightness Test of the Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.6 Visual Test and Function Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6 Safekeeping and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7.1 Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7.2 Full Face Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7.3 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7.4 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3S Full Face Mask – Positive Pressure
4
Safety Regulations
GB
1 Safety Regulations
1.1 Correct Use
Series 3S Full Face Mask with positive pressure connection according to EN 148-3 or special manu­facturer type are not complete respiratory protective devices by themselves, but serve as facepieces [EN 136 CL3+] for use with respiratory filters, compressed air breathing apparatus, fresh air hose breathing apparatus and compressed air line breathing apparatus.
The mask as part of a respiratory protective device ensures an appropriately tight fit of the user’s face against the ambient atmosphere.
It is imperative that this operating manual be read and observed when using the device. In particular, the safety instructions, as well as the information for the use and operation of the device, must be care­fully read and observed. Furthermore, the national regulations applicable in the user's country must be taken into account for a safe use.
WARNING!
This product is supporting life and health. Inappropriate use, maintenance or servicing may affect the function of the device and thereby seriously compromise the user's life.
Before use the product operability must be verified. The product must not be used if the function test is unsuccessful, it is damaged, a competent servicing/maintenance has not been made, genuine MSA spare parts have not been used.
Alternative use, or use outside this specification will be considered as non-compliance. This also applies especially to unauthorized alterations to the product and to commissioning work that has not been carried out by MSA or authorized persons.
1.2 Liability Information
MSA accepts no liability in cases where the product has been used inappropriately or not as intended. The selection and use of the product are the exclusive responsibility of the individual operator.
Product liability claims, warranties also as guarantees made by MSA with respect to the product are voided if it is not used, serviced, or maintained in accordance with the instructions in this manual.
Changes and modifications not expressly approved by the manufacturer will void the user’s authority to operate the equipment.
3S Full Face Mask – Positive Pressure
5
Description
GB
2 Description
The face blank is made of a special soft rubber compound and assures a snug, comfortable fit and a tight seal. The face blank is also available in yellow silicone. Some versions of the mask are also avail­able in small size.
The inhalation air flows from the connector of the mask past the inhalation valve to the inside of the lens [thus keeping the lens largely fog-free] and then through the check valves into the nose cup.
The exhalation air passes through the exhalation valve directly to the ambient air.
Fig. 1 Overview full face mask
1 Face blank 5 Industrial harness
2 Head strap 6 Lens
3 Buckle 7 Connector with inhalation valve
4 Rubber harness 8 Exhalation valve
1
2
3
6
7
8
4
5
3S Full Face Mask – Positive Pressure
6
Description
GB
2.1 Mask Versions
Special Versions for using until -40°C
Standard Thread Connector M45 x 3
3S-PF Standard version with polycarbonate lens 3S-PF-Vg as standard version, with Triplex [laminated] glass
3S-PF-Si
as standard version, face blank, inner mask and harness made from silicone
3S-PF-Vg-Si
as standard version, face blank, inner mask and harness made from silicone, with Triplex [laminated] glass
MSA Plug-in Connector
3S-PS Standard version with polycarbonate lens 3S-PS-Vg as standard version, with Triplex [laminated] glass
3S-PS-Si
as standard version, face blank, inner mask and harness made from silicone
3S-PS-Vg-Si
as standard version, face blank, inner mask and harness made from silicone, with Triplex [laminated] glass
AutoMaXX Plug-in Connector
3S-PS-MaXX Standard version with polycarbonate lens
3S-PS-MaXX-Si
as standard version, face blank, inner mask and harness made from silicone
ESA Plug-in Connector
3S-PF-ESA Standard version with polycarbonate lens
3S-PF-ESA-Si
as standard version, face blank, inner mask and harness made from silicone
3S-PF-ESA-Vg as standard version, with Triplex [laminated] glass
3S-PF-ESA-Vg-Si
as standard version, face blank, inner mask and harness made from silicone, with Triplex [laminated] glass
Standard Thread Connector M45 x 3
3S-PF-IH Basic
as standard version, with basic industrial harness, polycarbonate lens with silicate coating
3S-PF-IH Basic small
as standard version, with small size face blank, basic industrial harness, polycarbonate lens with silicate coating
MSA Plug-in Connector
3S-PS-IH Basic
as standard version, with basic industrial harness, polycarbonate lens with silicate coating
3S-PS-IH Basic small
as standard version, with small size face blank, basic industrial harness, polycarbonate lens with silicate coating
3S-PS-V-MaXX (CIS) as standard version, with polycarbonate lens with silicate coating 3S-PS-V-MaXX small (CIS)
as standard version, with small size face blank, polycarbonate lens with silicate coating
