63/8"
(162)
Water Inlet
Control & Accessory
Connections
Steam Outlet
Safety Valve
Manual Drain Valve
2
3
/8"
(60)
251/8"
(638)
4"
(100)
57/8"
(150)
77/8"
(200)
2
3
/8"
(60)
9
3
/4"
(248)
11"
(279)
16
1
/2"
(419)
203/4"
(527)
1
3
/8"
(34)
1
7
/8
"
(48
)
Optional
AutoFlush
®
mr.steam
Technical Specifications
______________________________________________________
Model MX4E-6E
MrSteam Standard Features
• Stainless steel tank
• Industrial, large diameter,
serviceable heating element
• Modular Plug and Play connections
• Electronic water-level control system
• Full-port drain valve
• Limited lifetime steam generator
parts warranty
Safety Features
• Built-in, low-voltage 24-volt control
• ASME safety valve
• 60-minute electronic countdown shutdown
with 75-minute limiting safety back-up
Locating and Installing the Steam Generator Unit
• Select a location as near as practical
to the steam room, within 60 feet.
Typical locations include: closet,
heated attic or basement.
• Do not install steambath generator
inside the steam room.
• Do not install steambath generator
outdoors or wherever environmental
conditions may affect the safety and/
or performance of the generator.
• Do not install steambath generator or
plumbing lines in unheated attic or
any locations where water could
freeze.
• Do not install steambath generator near
flammable or corrosive materials or
chemicals or in areas having a high
concentration of chlorine.
• Install steambath generator on a solid and
level surface or securely mounted to a wall
using the keyhole slots provided.
• Install steambath generator in an upright
position only.
• Provide a minimum of 18 inches on the left
side and 21 inches at the top of the steam
generator or as required for servicing.
• The minimum clearance from combustible
surfaces is zero all around.
Required Plumbing
Steam Pipe (3/4" NPT) Drain (1" NPT)
Steam Head (1/2" NPT) Water Supply (3/8" NPT)
Safety Valve (3/4" NPT)
FOR ILLUSTRATIVE PURPOSES ONLY. IMPORTANT NOTE: FOR SAFE
AND TROUBLE FREE INSTALLATION
manual provided with the unit.
MODEL VOLTAGE* PHASE OPTIONS
MX4E
I
I
MX5E
I
I
MX6E
I
I
Location:
Architect:
Engineer:
Contractor:
Notes:
B=208
I
I
C=240
I
I
I F=480
I
I
1-Single Phase
I
I
3-Three Phase
I
I
*Contact Mr. Steam for other voltages
visit mrsteam.com or refer to the
Express
I
I
Steam
Date:
Submitted by:
Electrical
All electrical wiring to be installed by a qualified
licensed electrician in accordance with National
Electrical Code and local electrical code.
Power Wiring
1. Check power voltage. Use 240V rated unit when sup-
ply matches rating of unit before installation.
2. Use minimum 90° C/300 V rated insulated copper
conductors only, type THHN or equal sized in
accordance with National Electrical Code and local
electrical code for the Amps in Ampere Chart. If allowed by code, NM cable may require a larger wire size
than as listed on the chart.
3. Connect suitably sized equipment grounding wire to
ground terminal provided.
4. Install a separate circuit breaker between supply and
unit. Provide a power supply disconnect within sight of
the steam generator or one that is
locked
the
in
open position.
capable
AMPERE CHART
MODEL
NO.
MX4E
MX5E
MX6E
Required Equipment: iSteam3, AirTempo, iTempo, iTempoPlus
Controls Optional Equipment: iGenie, AudioWizard, ChromaSteam,
HomeWizard, Recessed Light, MS Light, MS Wallseat, AutoFlush,
Condensation Pan, AromaSteam
Vol
(CU. FT.)
678
822
964
KW
20
24
30
Volts
208
240
480
208
240
480
208
240
480
Amps
Phase
1 97 1
3 56 4
1 84 3
3 48 6
3 24 10
1 116 1/0
3 67 4
1 100 1
3 58 6
3 29 10
1 145 3/0
3 84 2
1 125 2/0
3 73 3
3 36 8
of being
Wire Size
(AWG) for
25oC
