Mr. Heater MH165FAET, MH360FAET OPERATING INSTRUCTIONS AND OWNERÊS MANUAL

OPERATING INSTRUCTIONS AND OWNERÊS MANUAL

Model #

ELECTRIC FORCE AIR HEATER

MH165FAET MH360FAET

READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has not read these instructions to assemble, adjust or operate the heater.

Languages included

• English

• Spanish

• French

WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

· This heater has hot or arcing parts inside. Do not use it in areas where gasoline, paint or other flammable liquids are used or stored.

· Service must be performed by a qualified service agency.

www.mrheater.com • 800-251-0001

2016

Definitions: Safety Guidelines IMPORTANT INSTRUCTIONS.

The definitions below describe the level of severity for each signal word. Please read the manual and pay attention to these symbols. Danger: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. Warning: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Caution: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in property damage.

WARNING: DO NOT OPERATE THIS HEATER UNTIL YOU READ AND UNDERSTAND THIS INSTRUCTION MANUAL FOR SAFETY, OPERATION, AND MAINTENANCE INSTRUCTIONS.

CAUTION: Use of this heater in any means not described in this manual may cause fire, electric shock, personal injury and/ or property damage. CAUTION: This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 6 feet ( 1.8 m) from the front of the heater and keep them at least 2 feet (.6 m) away from the sides and rear CAUTION: In order to avoid unintended cycling of the heater, always unplug or unit from power source when not in use. CAUTION: Do not cover the power supply wiring or run the wiring under any carpet or rugs. Arrange cord and connections away from traffic patterns so it is not a tripping hazard. CAUTION: Connect unit to only properly grounded outlets and adequately sized and grounded electrical systems. CAUTION: Do not use this unit with unapproved or under sized electrical connections or wiring. They may overheat and cause a risk of fire.

WARNING: UNIT NOT INTENDED FOR US IN INDOOR AREAS WHERE HEATER MAY BE EXPOSED TO WATER. AVOID USE IN BATHROOMS, LAUNDRY ROOMS OR ANY OTHER AREAS WHERE THE UNIT MAY COME IN CONTACT WITH WATER.

WARNING: Do not use the heater if the unit, plug or cord has visible damage or the unit has malfunctioned. Contact a reputable electrician before reusing. WARNING: Do not expose to wet conditions; unit is intended for indoor use only. WARNING: This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never locate heater where it may fall into a bathtub or other water container. WARNING: Do not insert or allow any foreign objects to enter the unit via the intake or exhaust vents on the unit. Failure to observe this warning may result in electric shock, fire or damage to the unit. WARNING: To prevent fire do not block either the air intake or exhaust in any manner. Do not use on soft surfaces like a bed, where openings may get blocked. WARNING: Unit is equipped with internal active electrical components that spark during use. Do not use in areas where fumes from gasoline, paint or other flammable liquids may be present. WARNING: Extreme caution must be used when any heater is used by or near children or invalids and whenever the heater is left operating and unattended. WARNING: Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has been dropped or damaged in any manner. Discard heater, or return to authorized service facility for examination and/or repair. WARNING: Do not use outdoors. WARNING: Use this heater only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons.

SAVE THESE INSTRUCTIONS.

CONTENTS

WARNINGS ................................................................................. 2

ASSEMBLY ..................................................................................3

OPERATING ................................................................................ 3

SPECIFICATIONS ..........................................................................3

CLEARANCES .............................................................................. 3

MAINTENANCE .......................................................................... 3

TROUBLE SHOOTING ..................................................................4

WIRING DIAGRAM Model MH165FAET ....................................... 4

PARTS LIST/EXPLODED VIEW Model MH165FAET ........................ 5

WIRING DIAGRAM Model MH360FAET ....................................... 6

PARTS LIST/EXPLODED VIEW Model MH360FAET ........................7

WARRANTY ................................................................................ 8

INSTRUCTIONS FOR ORDERING PARTS ........................................8

LANGUAGES

ENGLISH ............................................................................ 1-8

SPANISH ................................................................................. 1-8

FRENCH .................................................................................. 1-8

Mr. Heater Forced-Air Electric Construction Heater Operating Instructions and OwnerÊs Manual

GENERAL INFORMATION

RETAIN THIS MANUAL FOR FUTURE REFERENCE. FOR QUESTIONS, PROBLEMS, MISSING PARTS BEFORE RETURNING TO RETAILER PLEASE CALL

WITH MODEL NUMBER AND SERIAL NUMBER OF HEATER: 1-800-321-0001 MONDAY-FRIDAY 8-5 PM EASTERN TIME

OR E-MAIL USING THE MR. HEATER WEBSITE: WWW.MRHEATER.COM

In order to provide the best service possible Mr. Heater is now giving you more ways to get in touch with us:

FACEBOOK: Find us on Facebook TWITTER: Find us on twitter YouTube: There are now informational videos on YouTube. WEBSITE: Mr. HeaterÊs full line of product are now at WWW.MRHEATER.COM

SPECIFICATIONS

Model: MH165FAET MH360FAET

Heat Output BTU/WATTS 5118/1500 Airflow (CFM) 200 325 Electrical Supply 120Vac 240Vac Thermostat 32°F - 185°F 32°F - 185°F Power Cord Dimensions: (L‰xW‰xH‰) 13.18‰x12.2‰x13.97‰ 14.37‰x13.77‰x16.14‰ Weight (lbs.) 9.6 LBS. 12 LBS.

Outlet (M) 6Ê (1.8M) 6Ê (1.8M) Rear (M) 2Ê (.6M) 2Ê (.6M) Top (M) 2Ê (.6M) 2Ê (.6M) Bottom (M) Use only on non-combustible flooring

6Ê POWER CABLE INCLUDED 6Ê POWER CABLE INCLUDED

Clearance to Combustibles

12286/3600

Assembly

• Remove the heater and all of the packaging material from the box.

• Check all of the packing material for loose parts and set aside.

• Thoroughly inspect the heater for damage. If any is found do not contact the place of purchase. Please call the Manufacturer at 800-251-0001.

Operational Information

The Mr. Heater Electric forced air heaters are designed to be used by professionals.

Heat is created by electric current passing through coiled metal elements bringing them up to very high temperatures. The fan then passes room air over the hot elements exchanging cold air for warm.

The air moving over the coils keeps them from reaching temperatures that are not safe for the normal operation of the heater. However it is important to keep all combustible materials and any objects that may be sucked into the fan blades at a safe distance (please refer to the specification table for appropriate clearances). Make sure that the fan blades remain unobstructed at all times. Keep unit clean and dust free. Do not block unit intake or exhaust at any time.

These units are designed to be used only with the cord and plug supplied with the unit. Do not use any plug other than the one supplied by the manufacturer. For information on which receptacle is appropriate, Refer to Figure 1 and find the diagram that corresponds to your heater. If damage has occurred please refer to the parts listing in this manual and contact the manufacturer for a replacement. WARNING: Outlet must be properly grounded, failure to do

so may result in electric shock or property damage.

WARNING: Always plug heaters directly into a wall outlet/

receptacle. Never use with an extension cord or re-locatable power tap (outlet/power strip).

Starting Instructions

1. Place the heater on a stable and level surface. Insure clearance to

combustibles are observed (See clearances in the specification table).

2. Turn thermostat counter-clockwise to lowest setting.

3. Plug the heater into a properly grounded outlet.

4 Rotate the power knob to the heating position. These units are

equipped with a fan only option for circulating air. For heating be sure to rotate the knob to the appropriate setting.

Mr. Heater Forced-Air Electric Construction Heater

5. Turn thermostat knob up (clockwise) to the desired setting.

6. The Heating element and fan will remain on until the temperature setting is reached. The unit will cycle on and off as needed.

Figure 1

MH165FAET NEMA 5-15R

To Stop Heating

1. Rotate the thermostat knob to the lowest position.

2. Flip the power switch into the „off‰ position.

3. Disconnect plug from power supply.

NOTE: This heater is equipped with an overheat limit switch which may cause the heater to stop. This is indicated by a visual alarm when the power switch is in the „ON‰ position and the „fault‰ light comes on. Check and remove the cause of the overheating before restarting. This can take up to 10 minuets to cool before it can be restarted.

Maintenance

WARNING:

Never attempt to service the heater while the unit is hot,

In use, or plugged in. Only qualified service technicians should service these units.

• Thoroughly inspect the unit prior to use.

• Keep heater clean and free of dust and debris.

• The use of an air compressor can be used to blow out the dust

from the heater case. as to not damage any internal components.

• A soft dry cloth should be used for cleaning of outer shell

and handle.

• The fan motor is sealed and does not need to be lubricated.

Storage

When not in use, the heater must be disconnected from power source, dusted off and the cord should be loosely wound around the handle.

For service :

Please call Toll-Free 800-251-0001 www.mrheater.com Our office hours are 8:00 AM – 5:00 PM, EST, Monday through Friday. Please include the model number, date of purchase, and description of problem in all communication.

CONTROL

Operating Instructions and OwnerÊs Manual

OVERHEAT LIGHT

MH360FAET NEMA 6-20R

Be sure to only use moderate air pressure

FAN

OFF

THERMOSTAT KNOB

ONLY

HEAT

English

Troubleshooting

Unit does not work •Defective thermostat or wrong thermostat setting

•Open circuit breaker or fuse

•Thermal overload switch has been tripped

•Damaged or defective plug or outlet

Unit runs continuously •Defective thermostat or wrong thermostat setting

•Heat losses higher than unit capacity (unit undersized)

Elements are on but motor does not rotate

Enclosure is extremely hot •Defective thermal protection

Desired room temperature cannot be reached • One or more elements are defective

Overheating • Defective thermostat or blocked inlet or outlet (HLS tripped)

WARNING: USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR

DEATH. REPLACEMENT PARTS ARE ONLY AVAILABLE DIRECT FROM THE FACTORY AND MUST BE INSTALLED BY A QUALIFIED SERVICE AGENCY.

•Defective Motor

•Blocked fan blades

•Blocked air vents

•Defective motor

• Defective thermostat or wrong thermostat setting

• Voltage lower than that written on Rate tag

• Heat losses higher than unit capacity (unit undersized)

• Defective Motor (slow motor operation)

WIRING DIAGRAM MH165FAET

Mr. Heater Forced-Air Electric Construction Heater Operating Instructions and OwnerÊs Manual

WIRING DIAGRAM MH360FAET

Mr. Heater Forced-Air Electric Construction Heater Operating Instructions and OwnerÊs Manual

Model #

OPERATING INSTRUCTIONS AND OWNER’S MANUAL

MH165FAET MH360FAET

WARNING:

USE ONLY MANUFACTURERÊS REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH. REPLACEMENT PARTS ARE ONLY AVAILABLE DIRECT FROM THE FACTORY AND MUST BE INSTALLED BY A QUALIFIED SERVICE AGENCY.

PARTS ORDERING INFORMATION:

PURCHASING: Accessories may be purchased at any Mr. Heater local dealer or

direct from the factory

FOR INFORMATION REGARDING SERVICE

Please call Toll-Free 800-251-0001 www.mrheater.com

Our office hours are 8:00 AM – 5:00 PM, EST, Monday through Friday.

Please include the model number, date of purchase, and description of problem in all communication.

LIMITED WARRANTY

Mr. Heater, Inc. warrants its heaters and accessories to be free from defects in material and workmanship for a period of 1 year from date of purchase. Mr. Heater, Inc. will repair or replace this product free of charge if it has been proven to be defective within the 1-year period, and is returned at customer expense with proof of purchase to Mr. Heater, Inc. within the warranty period.

Mr. Heater, Inc. reserves the right to make changes at any time, without notice or obligation, in colors, specifications, accessories, materials and models.

MR. HEATER, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001 Mr. Heater is a registered trademarks of Mr. Heater, Inc.
