Page 1
BVMC-ECMP1000 / BVMC-ECMP1001C / BVMC-ECMP1001R / BVMC-ECMP1001W
QUICK START GUIDE
(
Flip book over for Recipe Guide
)
www.mrcoeebarista.com
© 2012 Sun beam Pro ducts , Inc. do ing busi ness as
Jarden Consumer Solutions. All rights reserved.
P.N. 161928 Rev. B MR C26251 C SDL072012
Page 2
Diagram of Parts
8
1
a
b
c
2
3
4
5
6
7
16
17
9
1
10
11
12
13
14
15
1 Control Panel
a Espresso/Custom Button
b Cappuccino/Froth Button
c Latte/Clean Button
2 Brew Head
3 Cup Height Adjusting Tray
4 Removable Drip Tray and Lid
5 Porta-Filter
6 Porta-Filter Retention Clip
7 Measuring Scoop/Tamper
8 Water Tank Lid
9 Removable Water Tank
10 On/O Switch “I/O”
11 Milk Reservoir Lid
12 Froth Control Knob
13 Frothing Tube Lever
14 Frothed Milk Dispensing Tube
15 Removable Milk Reservoir
16 Filter for Single Shot of Espresso (1 cup)
17 Filter for Double Shot of Espresso (2 cup)
Page 3
IMPORTANT
Your Mr. Coee® Café B arista must be PRIMED prior to first use.
Refer to your instruction manual on how to prime the appliance
and for other important safeguards.
Brewing
1 Choose your filter (single or double shot). To insert filter,
make sure to align the notch on the filter with groove on
the porta-filter. Once inserted, turn filter to left or right
to secure in place.
2 Fill the filter with espresso grounds. Tamp firmly and
level. Clean excess grounds from rim of porta-filter.
3 Attach porta-filter to brew head of unit by aligning
the handle with the “
handle is aligned with the “
” icon and turn to the right until
” icon.
Page 4
Brewing continued
4 Fill the removable water reservoir with water and place
on unit.
5 Fill the removable milk reservoir with your preferred milk
(whole, skim, soy, almond, etc) and place on unit. Be sure
to push the reservoir all the way into the unit.
6 Please make sure to select the right cup size according
to the following table:
BEVERAGE AMOUNT
Espresso
Cappuccino
Latte
Single (
Double (
Single (
Double (
Single (
Double (
)
)
)
)
)
)
1.25 oz
2.5 oz
6 oz
10 oz
12 oz
15 oz
Page 5
Brew Espressos
a Press the Espresso Button “ ” once to brew one single shot.
b Press the Espresso Button “ ” twice to brew a double shot.
c To customize the amount of espresso brewed, press and hold the
Espresso Button “ ” for 3 seconds. When desired amount is reached,
press the Espresso Button “ ” once again to stop brewing. For safety,
unit will automatically stop after brewing 5 ounces.
NOTE: For a single shot, use the single shot filter. For a double shot,
use the double shot filter. Pull out the cup height adjusting tray
if you are using a small “demitasse” cup to brew espresso.
Prepare Cappuccinos
a Press the Cappuccino Button “
b Press the Cappuccino Button “ ” twice to brew a large cappuccino.
c Adjust the amount of froth to your preference by turning the Froth
Control Knob to the right for more froth and to the left for less froth.
For Cappuccino, it is recommended that the Froth Control Knob be
turned to the Cappuccino setting.
NOTE: Be sure to aim the frothed milk dispensing tube towards the center
of your cup by using the frothing tube lever. For a small cup, use
the single shot filter. For a large cup, use the double shot filter.
” once to brew a small cappuccino.
Create Lattes
a Press the Latte Button “
b Press the Latte Button “ ” twice to brew a large latte.
c Adjust the amount of froth to your preference by turning the Froth
Control Knob to the right for more froth and to the left for less froth.
For Latte, it is recommended that the Froth Control Knob be turned
to the Latte setting.
NOTE: Be sure to aim the frothed milk dispensing tube towards the center
of your cup by using the frothing tube lever. For a small cup, use
the single shot filter. For a large cup, use the double shot filter.
” once to brew a small latte.
Page 6
Customizing / Preparing additional frothed milk
Adding more froth to your beverage is easy. Place your
beverage under the porta-filter and press and hold the
Cappuccino Button “ ” for 3 seconds and the Café Barista
will begin dispensing more frothed milk. Press the Cappuccino
button again to stop. To make frothed milk separately, follow
the same instructions but place an empty cup under the
porta-filter.
Cleaning your Café Barista
Once you are done preparing your beverage with
milk, you can either store the unit’s milk reservoir
with leftover milk directly in the refrigerator (ready
to be used for the next time) or dispose of the
leftover milk.
a Clean the Frothed Milk Dispensing Tube after
each use. First, place an empty cup on the
unit’s drip tray. Aim the Frothed Milk Dispensing
Tube into the empty cup. Next, adjust the Froth
Control Knob to Clean “
the Latte/Clean button for 3 seconds. The unit
will run the clean cycle for 30 seconds. Once
completed, throw the contents in the cup away.
”. Then press and hold
b Once you are done preparing your beverage
with milk and/or cleaning the Frothed Milk
Dispensing Tube, you can
either store the unit’s milk
reservoir with milk directly
in the refrigerator or dispose
of the leftover milk.
NOTE: For more cleaning
instructions, refer to
the instruction manual.
Porta-filter is not
dishwasher safe.
Page 7
Recipe
Guide
www.mrcoffeebarista.com
(
Flip book over for Quick Start Guide
)
Page 8
Espre
Café Sakerat
Brew:
Large espresso
Fill a cocktail shaker half full with:
Ice cubes
Add to the ice:
Brewed espresso
1 tablespoon vanilla syrup
Shake until foamy, about 30
seconds; strain into a martini glass.
Café Cuban
Place in a small cup:
1/2 teaspoon sugar
Brew in the cup:
Small espresso
Stir to dissolve sugar.
Espre co Pann
If desired, place in a cup:
1/2 teaspoon sugar
Brew in the cup:
Small espresso
Stir to dissolve sugar,
then fill cup with:
Sweetened whipped cream
Café Bombo
Place in a small heavy glass:
1-1/2 to 2 tablespoons sweetened
condensed milk
Brew in the glass:
Small espresso
Serve with a spoon to stir
just before drinking.
Page 9
Espre Marni
For Adults
Brew:
Large espresso
Mu Pie Milkshake
Brew, then refrigerate until chilled:
Large espresso
Place in a blender:
2 cups (about 4 scoops)
cookies ‘n cream ice cream
1/4 cup whole or other milk
Cold brewed espresso
Cover and process
until blended,
stopping to stir
if needed.
Aogat a Café
Brew:
Small espresso
Place in a dessert dish:
1/2 cup (about 1 scoop)
vanilla ice cream
Top with:
Hot brewed espresso
Fill a cocktail shaker half full with:
Ice cubes
Add to the ice:
Brewed espresso
1-1/2 ounces (3 tablespoons) vodka
1-1/2 ounces (3 tablespoons)
Kahlúa (coee liqueur)
1/4 teaspoon sugar
Shake until foamy, about
30 seconds; strain into a
martini glass.
Serve immediately
with a spoon.
Page 10
Ice Lae
Lae
Pumpki Spice Lae
Place in a cup:
2 teaspoons
brown sugar
Pinch of pumpkin
pie spice
Brew in the cup:
Small latte
Stir to blend.
Hone-Vanill Lae
Place in a cup:
2 to 3 teaspoons honey
Brew in the cup:
Small latte
Add and stir until blended:
Drop of vanilla extract
Place in a large cup:
1 tablespoon sugar
Brew in the cup:
Large espresso
Stir in:
1 cup ice cubes
1/2 cup whole
or other milk
Toee Lae
Place in a cup:
1 tablespoon caramel syrup
1 to 2 teaspoons toee bits
Brew in the cup:
Small latte
Stir to dissolve toee bits.
Cinnamo
Sugar Lae
Place in a cup:
2 teaspoons sugar
Pinch of ground
cinnamon
Brew in the cup:
Small latte
Nutell Lae
Place in a cup:
1 tablespoon Nutella
(chocolate hazelnut spread)
Brew in the cup:
Small latte
Stir to blend.
Page 11
Cappuccin
Café Moch
Place in a cup:
2 teaspoons chocolate syrup
1/2 teaspoon sugar
Brew in the cup:
Small cappuccino
Stir to blend.
Top with additional foam
if desired.
See Cappuccin
Place in a cup:
1/2 teaspoon sugar
Brew in the cup:
Small cappuccino
Stir to dissolve sugar.
Top with additional foam
if desired.
Raspbe Cappuccin
Place in a cup:
1 tablespoon raspberry syrup
Brew in the cup:
Small cappuccino
Stir to blend.
Top with additional foam
if desired.
Carame Cappuccin
Place in a cup:
1 tablespoon caramel syrup
1/4 teaspoon sugar
Brew in the cup:
Small cappuccino
Stir to blend.
Top with additional foam
if desired.
Page 12
Café Conquistad
For Adults
Place in a cup:
1 ounce (2 tablespoons)
Kahlúa (coee liqueur)
Coconu Cappuccin
Place in a cup:
2 teaspoons cream of coconut
(not coconut milk)
Brew in the cup:
Small cappuccino
Stir to blend.
Top with additional foam
if desired.
Cappuccin Royale
For Adults
Place in a cup:
1 ounce (2 tablespoons)
Frangelico (hazelnut liqueur) or
Amaretto (almond liqueur)
Brew in the cup:
Small cappuccino
Stir to blend.
Top with additional foam
if desired.
Brew in the cup:
Small cappuccino
Stir to blend.
Top with additional foam
if desired.
