MRC 24CB10 Operating Manual

4 Litre Blender

24CB10 Operating Manual

Blender 4 Litre 120 volt - 230 volt

PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION

3, Hagavish st. Israel 58817

Tel: [phone], Fax: [phone] [e-mail]

MRC.7.15

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed including
the following:

1

1. READ ALL INSTRUCTIONS.

1

2. To protect against electrical hazards, do not immerse the Blender Base in water or other
liquid.

1

3. Close supervision is necessary when any appliance is used by or near children.

14. Unplug from outlet when not in use, before putting on or taking off parts, and before

cleaning.

1

5. Avoid contacting moving parts.

16. Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions

or is dropped or damaged in any manner. Return appliance to the nearest authorized service
facility for examination, repair or electrical or mechanical adjustment.

1

7. The use of attachments including canning jars not recommended by the appliance
manufacturer may cause hazards.

1

8. Do not use outdoors.

19. Do not let cord hang over edge of table or counter, or touch hot surfaces.

10. Keep hands and utensils out of container while blending to prevent the possibility of severe
personal injury and/or damage to the blender. A rubber scraper may be used but must be
used only when the blender is not running.

11. Blades are sharp. Handle carefully.

12. Always operate blender with cover in place.

13. When blending hot liquids, completely remove the stopper in the cover before turning on the
blender. See Hot Blending Instructions.

SAVE THESE INSTRUCTIONS

Specifications

❍ Capacity: 4 Litre Working Capacity
❍ Switch Setting: (3 speeds) POWER ON/OFF STOP LOW MED HIGH PULSE
❍ Revolutions Per Minute: 15,800 18,000 20,800 20,800

(free running-approximate)

❍ Rating: 120 Volts-60HZ-Single Phase AC -15.0 Amps. U.S. models only.

230 Volts-50HZ-Single Phase AC -1500 Watts.

❍ Base: Die-cast – grey coating
❍ Container: Stainless steel with stainless steel blades - clear polycarbonate

clamp-on lid, with gasket and stopper.

❍

Bearing: High performance ball bearing.

❍ Cord: 7 foot (2.44 m) - 3-conductor ground cord with strain relief in base.
❍ Overall Height: 26 inches (66 cm).
❍ Weight: 38 pounds (17.2 kg) net - Shipping Weight 41 pounds (18.6 kg).
❍ UL, NSF, CSA Listed (120 volts ONLY).
❍ Timer: Some models have a timer, adjustable from 10 seconds to 3 minutes

for automatic blending.

❍

Operating Cycle: 3 min ON/1 min OFF
