Mpman PH340 User Manual

1

GSM DUAL BAND GPRS DIGITAL MOBILE

TELEPHONE

Manual

2

Preface

We sincerely appreciate you for buying our product！
The mobile conform to the law of the People's Republic of communication industry
standard, also accord with the European standards, the approval applies to GSM network.
GSM network is an international standard of global cellular communication system.The
mobile can connect to a variety of international network. With her, you may call,
receiving international telephone, just like in your hometown. But to use these advanced
function of this network, you need to apply for necessary service.
In order to better use the mobile, we recommend that you read this manual in details, so
you can make full use of all sorts of functions provided by the moblie.
Note: If some function of the mobile is not available for reasons of network configuration
and services , we refer you to distributors or network operators.
Caveat: If the user does not abide by the above advice or does not use the mobile
properly, the manufacturer shall not be liable for any.
Note: We‟ll upgrades the product version without any notice. The company has the
power of final interpretation of this manual.

Safety

Never attempt to disassemble your phone. You alone are responsible for how you use
your phone and any consequences of its use.
As a general rule, always switch off your phone wherever the use of a phone is prohibited.
Use of your phone is subject to safety measures designed to protect users and their
environment.

Do not use your phone in damp areas (bathroom, swimming pool…). Protect it from

liquids and other moisture.
Do not expose your phone to extreme temperatures lower than - 10°C and higher than +
55°C.
The physicochemical processes created by chargers impose temperature limits when
charging the battery. Your phone automatically protects the batteries in extreme
temperatures.
Do not leave your phone within the reach of small children (certain removable parts may
be accidentally ingested).

Electrical safety: Only use the chargers listed in the manufacturer‟s catalogue. Using

any other charger may be dangerous; it would also invalidate your warranty. Line voltage

must be exactly the one indicated on the charger‟s serial plate.
Aircraft safety: When traveling by plane, you will need to switch your phone off when

so instructed by the cabin crew or the warning signs.Using a mobile phone may be
dangerous to the operation of the aircraft and may disrupt the phone network.Its use is

3

illegal and you could be prosecuted or banned from using cellular networks in the future
if you do not abide by these regulations.
Explosive materials: Please comply with warning signs at petrol station asking you to
switch your phone off. You will need to comply with radio equipment usage restrictions
in places such as chemical plants, fuel depots and at any location where blasting
operations are under way.
Electronic equipment: To avoid the risk of demagnetization, do not let electronic
devices close to your phone for a long time.
Electronic medical equipment: Your phone is a radio transmitter which may interfere
with electronic medical equipment or implants, such as hearing aids, pacemakers, insulin
pumps, etc. It is recommended that a minimum separation of 15 cm be maintained
between the phone and an implant. Your doctor or the manufacturers of such equipment
will be able to give you any advice you may need in this area.
Hospitals: Always make sure that your phone is switched off in hospitals when so
instructed by warning signs or by medical staff.
Road safety: Do not use your phone when driving. In order to give your full attention to
driving, stop and park safely before making a call. You must comply with any current
legislation.
Distance of operation: This phone model has been tested and meets radiofrequency
exposure guidelines when used as follows:

• Against the ear: Place or receive a phone call and hold the phone as you would a wire

line telephone.

• Body worn: When transmitting, place the phone in a carry accessory that contains no
metal and positions the phone a minimum of 2.5 cm form your body. Use of other
accessories may not ensure compliance with radiofrequency exposure guidelines. If you
do not use a body worn accessory and are not holding the phone at the ear, position the
phone a minimum of 2.5 cm from your body,

• Data operation: When using a data feature, position the phone a minimum of 2.5 cm

from your body for the whole duration of the data transmission.

• Children: Please put the mobile out of the reach of children.

Key configuration

Power key (right side) : To startup or shutdown, long press this button. Click this button

lock the mobile in common conditions.
Up and down side key (left side) : In call, press this button to control call volume. In
Audio players or Video player, press this button to adjust the volume.

Buttons under the screen(from left to right):
Set up key: Click to popup a context menu.
HOME key: in any non standby interface, this button is used to retain or pause the

program interface, or return to standby interface.

4

Return key: in non standby interface, click to return to previous interface.

icon

description

SIM card not ready
No signal

The more Vertical stripes is filled,

the stronger the signal is.

Flight mode activated.

Missed calls.

In a call

New sms or mms arrived.

Alarm started.

Earphone plugged.

Icons

5

Silent mode activated.

wi-fi network available.

Bluetooth activated.

downloading

Connected via USB cable .

The more this icon is filled， the

more battery power is available.

Getting Started

You need to remove the back cover before you can install the SIM card and battery. Also,
make sure to always turn off the power before installing or replacing the SIM card and
battery.

To remove the back cover :

1. Make sure your device is turned off.

2. Firmly hold the device with both hands and the front panel facing down.

3. Push the back cover up with your thumbs until it disengages from the device and then
slide it up to remove.

To install the SIM card

The SIM card contains your phone number, service details, and phonebook/ message
memory.

1. Remove the battery if it is installed.

6

2. Locate the SIM card slot, and then insert the SIM card with its gold contacts facing
down and its cut-off corner facing out the card slot.

3. Slide the SIM card completely into the slot.
Note: Some legacy SIM cards may not function with your device. You should consult
with your service provider for a replacement SIM card. There may be fees for this

service.

To install the battery

Your device comes with a rechargeable Lithium-ion battery and is designed to use only
manufacturer-specified original batteries and accessories. Battery performance depends
on many factors, including network configuration, signal strength, and usage patterns.
Warning: To reduce risk of fire or burns:

• Do not attempt to open, disassemble, or service the battery pack.

• Do not crush, puncture, short external contacts, or dispose of in fire or water.

• Do not expose to temperatures above 60°C (140°F).

• Replace only with the battery pack designated for this product.

• Recycle or dispose of used battery as stipulated by local regulations.

1. Align the battery‟s exposed copper contacts with the battery connectors at the bottom

part of the battery compartment.

2. Insert the contacts side of the battery first and then gently push the battery into place.

3. Replace the back cover.

To remove the battery

1. Make sure your device is turned off.

2. Remove the back cover.

3. The bottom of the phone has a notch. Lift the battery by the notch to remove it.

To install a memory card

To have additional storage for your images, videos, music, and files, you can purchase a
memory card and install it into your device.

1. Make sure that your device is turned off, and then remove the back cover.

2. Locate the memory card slot on the upper part of the exposed right panel.

3. Insert the memory card into the slot with its gold contacts facing down until it clicks
into place.
Note: To remove the memory card, press it to eject it from the slot.

Charging the Battery

New batteries are shipped partially charged. Before you start using your device, it is
recommended that you install and charge the battery. Some batteries perform best after
several full charge/discharge cycles.
Note: Only the AC adapter and USB sync cable provided with your device must be used
to charge the device.
Connect the USB connector of the AC adapter to the sync connector on your device, and

7

then plug in the AC adapter to an electrical outlet to start charging the battery.
As the battery is being charged while the device is on, a charging icon appears in the title
bar of the Home screen. After the battery has been fully charged, a full battery icon
appears in the title bar of the Home screen.

Warning: • Do not remove the battery from the device while you are charging it using the

AC or car adapter.

• As a safety precaution, the battery stops charging before it overheats.

Security code

·PIN code: A personal identification number of the SIM card, provided by the network

operators.

·PIN2 code：PIN2 code is also provided by network operators.If you consecutive input
the wrong PIN code (SIM card will be lock) and PIN2 code for three times, you need to
input corresponding PUK code and PUK2 code to unlock. For details, please contact
with your network operator.

·PUK code：To change the PIN code, the PUK code is needed (that is private unlock
password). PUK code and SIM card are also provided by network operators. If the PUK
code is missed, please contact with your network operator.

Commonly used functions

Power on / off

1.Long press power button to turn on or off you mobile.

2.The machine supports two GSM network SIM cards. When two SIM card inserted, and
the SIM card PIN code is activated, you should input the correct PIN code to log in.

3. Right after the mobile is power on, it will automatically search the network, if
authorized network is founded, the network name and signal strength will be displayed,
or you can only use some emergency call or other non communication function.

Make a call

In home screen, click the icon at the left bottom to start a virtual keyboard, click on the
numeric button to input the number, click the delete button to delete a number, long time
click the delete button to delete all numbers, click on the dial key to make the call.
During calling process, you can pull up the [dialing keyboard] at the bottom to bring up
the dialing interface, in which you can make a new call.

1.Dial fixed telephone extension: some fixed telephone extension cannot be direct
connected, you need to dial the operator, and press the left side of the mobile phone
[menu button] to go to the options menu, then select "P/W" (pause/wait), and then dial
the extension number.

2. Make an international call: to make an international call, long time click number key

8

[0] until international telephone prefix symbol "+" is displayed, this will allow you select
an international telephone prefix number (for example, China is 0086) , with this code,
you can make the call.
Answer a call
When you receive a phone call, the incoming voice call screen will appear, allowing you
to either answer or ignore the call.

1. To answer an incoming call, slide „ANSWER‟ (Green icon) button rightward.

2.If earphone plugged, you can answer the call by pressing button on the earphone.

3. During the calling process, you may adjust the volume by pressing the side key.

4. To answer an incoming call, slide „ANSWER‟ (Green icon) button rightward.

5. When no SIM card inserted, you can make emergency calls. Different network uses
different emergency number. For details, please refer to your network operator.

Call Options

During a call, you may press the “menu” button to start a menu: Display dialing
keyboard, exchange calls, merge calls, add calls, hanging up, maintain, mute,
handset-free, bluetooth and recording.

USB Settings

You may connect your mobile to a PC with a USB cable,
when the mobile is off, it becomes a USB flash disk with which you can move or save
your data; if your mobile is on, a popup menu will be displayed, you can choose
“usb”(same function as above) or “return”(just charge) .
Caution: 1. When [storage device] mode selected, you will not be able to use U disk
related functions, such as multimedia. And if some settings (such as wall paper, ring, etc.)
use the original file in the U disk, the setting will reset to the default, and will not be
resumed until you remove the USB cable

Basic functions

ES file browser

Basic function

ES file browser is a new multi-functional file/procedures/process manager. The applied
characteristics 1. convenient toolbar operation. 2. manage files in mobile phone and local
area network computer. 3. search files in local or network. 4. install/uninstall / backup
program. 5. Play media files(audio and video), support stream media. 6. bluetooth

9

transmission.

STK

【 STK 】 A value-added service provided by China Mobile , such as weather
information, flight information, mobile phone news service.
The menu name differs base on the SIM card inserted. If you can't use this service, please
contact you're your service providers.

Note

A notepad in Android, your may add your schedule, arrangement, and affairs here.

Dialing

You can use "dialing" application make to a call(already described in previous section),
and you can also make a call through "call records" or "contacts".

Call records

"Call records" is a list which includes all your dial calls, received call and missed calls.
By touching the "voice dialing" icon on the right side of the record, you can make a call
using the number of the record.
By long pressing the record, you can re-dial, call back, redial through video, callback
through video, send text messages and add the number to "contact".

Contacts

You can find a person to contact with quickly throught " Contacts". When power on the

10

mobile the first time ,system will login your Google account, then download all Google
contacts to your phone. After that, the system will synchronize your contacts: any
modification with “Contact” through your mobile or Internet, will be revealed on both
sides via synchronization. The system will also synchronous Exchange ActiveSync
account of contact by this method.
By touching the "Contacts" icon, you can enter your contacts list, all your contacts will
be displayed in alphabetical order.
If it‟s first time you use “Contacts”, a message will be displayed, suggesting how you
add a contact.

Add contacts to the collection

1 open "Contacts".
2 touch a contact, and the details will be displayed.
3 touch the star icon on the ride of the contact name .
At this time, the star mark will turn into gold, then done.
Delete a contact in the collection
1 open "Contacts".
2 touch a contact, and the details will be displayed.
3 touch the star icon on the ride of the contact name .
At this time, the star mark will turn into grey, then done.

Search contacts

You can search contacts by name.
1 open "Contacts".
2 Press the “menu”, touch the "search" button.
3 input the name you need to find. While typing, all matched contacts will be displayed
in a search list.
4 touch the name in the search list, the "details" screen shows up. You can also touch the
magnifying glass icon to maximum the search list.

Edit contact details

1 open "Contacts" or "collection".
2 Long press the contact, select the “edit” menu, then edit.
3 Or you can entry the screen by touching the contact for details, then press “menu”,
select “edit contact”.

Email

Open “Email”

touch the "email" icon, and the Application will be launched. A wizard will help you
finish the Email setting the first time you use it.

After finish the setting, you‟ll return to previous screen; If you haven‟t use “Email”
