Mpman MPQC-717 Instruction Manual

For Model No.

MPQC717

EN

User's manual

Tablet Part

Name function

1 Reset press RESET button,Tablet will force to

shutdown

2 Volume down Press the button to decrease the volume

3 Micro-SD slot Insert a micro SD card (up to 32GB)

4 Volume up

5 MIC Recording Voice

6 USB & OTG Connect to PC / connect peripheral devices(e.g

7 Earphone jack Connect earphone to this standard 3.5mm jack

8 Power Hold to turn the tablet on or off

Press the button to increase the volume

keyboard, USB flash drive)

Getting S

Battery Charging

The tablet has a built-in rechargeable Li-polymer battery.

1. To charge connect the AC power adapter to the micro USB jack on

the right side of the tablet.

2.

The battery icon shows the battery status and charging status

3. The tablet can be used even if the battery is being charged.

the above icons indicate the different level of electricity left in the battery

4. no replacement of battery without authorization, or the explosion

hazard might happen.

5. Recharge it for at least half hour if it has been idle for long time and

fails to start itself.

6. Regularly recharge it at least one time monthly

7. 40°—5° is the optimum temperature for the battery recharging or

the battery performance might deteriorate slightly

tarted

Disposal

the battery might contain the polluting material, please give it to the official

recycling-station before disposing the tablet pc, and don’t litter.

wer ON/OFF

Po

ON:

press the
OFF:

1.Press

2.Select OK to power off the tablet

Screen Lock

This feature locks the screen, at the same time turn OFF the screen’s

backlight after a few seconds.

Screen locks when:

1.

System is idle.

2.

Manually activated by pressing the Power button once

Scre

en unlock :

Hom

button for continuous 5 seconds until the tablet turns “ON”.

the button for continuous 5 seconds and it will appear

e screen

.

The Home screen will look similar to the picture below. It is actually five

screens, each of which can have a different layout of icons. To switch

between screens, simply slide your finger left or right across the display.

The status bar and navigation buttons are always visible, no matter which

Home screen you can currently viewing.
