Mpman MPQC-124i Instruction Manual

This manual contains important safety precautions and information of correct use.
Please be sure to read this manual carefully before use so as to avoid any accidents.

Do not place the product in hot, wet or dusty environment, especially in summer, do not leave the
product inside a car with all windows closed.
Avoid dropping, impacting or shaking the product violently, otherwise it may cause damages or
malfunctions.
Select a proper volume to avoid ear problem when using earphones.
Do not cross the road or drive vehicles, using headphones to avoid traffic accidents.
Be sure to use the provided chargers and accessories in the package.
Be sure to charge the product when the following situations take place,

- The battery icon shows lower or empty.

- System automatically shut down and it turns off soon after restart.

- Operation keys do not respond properly.

- The device shows on the top right corner.

Specification

Hardware

Software

10.1” High Definition IPS LCD Touch
Screen (800x1280 pixel)

Android 6.0

Capacitive multi-touch (5 touch) point

Google browser

CPU : Quad core Cortex MT8163 processor

Wi-Fi connection

RAM : DDR3L 1GB
(3D accelerator possible for 3D games)

e-Book function (all e-book formats
supported by application)

Wi-Fi (IEEE802.11 a/b/g/n, 2.4/5GHz dual
band) for internet connection

1080P HD file playback

USB host for OTG function

VOIP phone function with Wi-Fi connection

G-sensor

Possible to view/edit MS office files by
application

Micro SD card slot recognizing up to 32GB

Video : AVI, RM/RMVB, FLV, MPG4-1,
MPEG-2 etc.

Built-in speaker & Built-in MIC

Audio : MP3, WMA, AAC, WAV etc.

5V power adapter

Photo : JPEG, BMP, GIF, PNG, TIFF

Compatible with keyboard, mouse

Dimension : 264.5 x 164.5 x 10.8mm

Name

Important Notice

- If the device is freezing or stuck, press the reset button(a small hole) located at left side of microSD card slot. Another
way to turn off the device by force is to hold pressing power button for more than 10 seconds

- When the performance is slow after using some applications, it is recommended to close running application in setting
menu.

- Use”File Manager” at main menu to search files.

Charging

- Be sure to use the power adapter (5V) that is provided in the package, otherwise, the device may be damaged and does
not work.

- See the battery icon ( ) on the status bar to check charging.

- It takes approx. 5-6 hours to be fully charged from empty battery. Do not charge more than 10 hours to protect the
device.

Note

The device is equipped with high performance processor. It may be warm in case of using long or while charging,but not

the problem.

1. Power On/Off

Long press power button to turn on/off the device. It may take a minute to boot the device.
Short press power button to turn on/off the screen.
(Standby mode. Refer to 3. below)

2. Desktop

After turning on the device, desktop displays with shortcut icons and notification bar.
