Mpman MP-2000 Quick Start Guide

For series
MP2000/MP948
EN
Internet Tablet
Quick Start Guide ................................................ Page 2
Please read carefully before use
THANK YOU ................................................... 3
Package Contents..........................................................3
Features ............................................................................4
GETTING TO KNOW THE MPMAN INTERNET TABLET5
About the Touchscreen................................................. 5
Protective Film...........................................................5
Touchscreen Actions............................................... 5
About the Orientation Sensor....................................... 6
Charging the Tablet .......................................................7
Inserting a Memory Card...............................................8
Resetting the Tablet........................................................8
GETTING STARTED.......................................... 9
Turning the Tablet on and off .....................................9
Turning the Screen On and Off (Standby) ........9
Unlocking the Screen ..............................................9
Home Screen at a Glance..........................................10
About Applications.......................................................11
Preinstalled Applications.......................................11
Installing Applications............................................12
About Menus .................................................................13
About Notifications.......................................................14
Using the USB Full-Size Adapter ..................................25
Connecting a Keyboard ......................................25
Connecting a Storage Device............................25
SETTING THE SYSTEM OPTIONS.................... 26
SPECIFICATIONS.......................................... 27
SAFETY NOTICES.......................................... 27
CONNECTING TO THE INTERNET ................. 15
Requirements................................ .......... ......... .......... ....15
Connect to a Wi-Fi network........................................16
BROWSING THE WEB.................................... 17
MANAGING APPLICATIONS ....................... 21
OPTIONAL CONNECTIONS ......................... 23
Connecting to a Computer........................................24
Connecting to a TV ......................................................24
Connecting Headphones.............................. .... ..... ....24
Thank You
Congratulations on your purchase of a MPMAN® Internet Tablet. This guide is provided to help you get started quickly with your player; please read it carefully and save it for future reference.
For detailed instructions, up-to-date information, and helpful tips, please visit the MPMAN website at www.mpmaneurope.com
.
This manual is available for download from the MPMAN website as a PDF file. To view PDF documents, download and install the free Adobe Acrobat reader from the Adobe website at www.adobe.com
.
Package Contents
Please make sure that the items shown below are included in the package. Should an item be missing, please contact the local retailer from which you purchased this product.
MPMAN Internet Tablet
Protective pouch
USB cable
USB host/keyboard adapter
Power adapter
This package may contain plastic bags or other materials that pose a hazard to children. Be sure to safely dispose of all packing materials after openin g.
Features
Browse the Web.
Visit your favorite websites
Check your e-mail
Keep in touch with friends and family
Watch YouTube™ videos
Browse the world’s most popular video-sharing community
Read your favorite books
Download thousands of books with the included E-book reader *
Discover thousands of apps for Android™
Games, applications, and more with the installed marketplace
HDMI™ output to your TV **
Enjoy videos, photos and more in the comfort of your living room
Connect to the Internet wirelessly
High-speed Wi-Fi 802.11 b/g/n networking
Enjoy your media library anywhere
Portable powerhouse plays popular music, video, and photo formats
microSDHC memory card reader
Increase your storage capacity (up to 32 GB supported)
Built-in camera
Convenient front-facing camera (2MP back camera optional *pls check with shop)
Automatic orientation detection
Read any way you want; the display adjusts automatically!
* Reading books in the ePub format requires the included E-book reader application.
Requires optional HDMI cable (Type A-to-Type C). 1080p HD video playback requires a video file encoded at 1080p. Streaming
**
video quality will be affected by the source, and the quality and condition of your network connection.
Getting to Know the Internet Tablet
play
Unit at a Glance
Name Description
1 Camera Front-facing camera
2 Back key Press to return to the previous screen. If
the keyboard is on the screen, press to close the keyboard.
3 Volume +
key
4 Volume –
key
5 Power key Press to turn the unit on, or to turn the
6 Speaker Speaker output is automatically muted
7 Power jack
(DC input)
8 microSDHC
card slot
9 USB 2.0
Hi-speed port
Press to increase the volume level.
Press to decrease the volume level.
screen on and o.
Press and hold to access the Power O menu.
when using headphone Jack.
Charge and power the tablet with the included power adapter.
Load external microSDHC memory cards here.
Connect to a computer to transfer data (e.g., music, videos, photos, les).
10 HDMI jack
(mini Type C)
11 Headphone
jack
Connect to a TV or other display.
Audio output connection for head-phones.
Note: Speaker output is automatically disabled when headphones are connected to the
er.
About the Touchscreen
Your tablet comes equipped with an easy-to-use touchscreen.
Our capacitive multi-touchscreen requires gentle fingertip touch on the glass screen to activate tablet’s functions. Multiple fingers may be used to perform gestures (e.g. 2-finger picture zoom).
Please note: Your finger tips must not be covered. A stylus may be used. Make sure it is for capacitive touchscreens.
To avoid damaging the screen, do not touch it with excessive force or with any object other than your finger. Fo r
best response, make sure your hands are clean before using the touchscreen controls.
Protective Film
A thin film has been applied to the touchscreen to protect it during shipping. The protective film should be removed before use. To remove it, simply take a corner of the film and peel it away from the screen.
Touchscreen Actions
You can control the functions of the tablet by using the touchscreen in combination with the three touch keys located on the bezel. To control the tablet with the touchscreen, use your fingertip to manipulate icons, buttons, menu items, the on-screen keyboard, and other items displayed on the screen.
You can perform the following actions on the touchscreen using your fingertip or appropriate stylus.
Touch:
Touch and Hold:
Drag:
Swipe:
Double-tap:
To activate an on-screen item (e.g., application icons, buttons, menu items, and the letter/symbols of the on-screen keyboard), simply touch them with your fingertip.
Some on-screen items have an alternate action if you touch and hold it (e.g., opening an alternate menu, or to activate the drag function). To touch and hold an item, touch the item and do not lift your fingertip until the action occurs.
Drag an on-screen item to change its position (e.g., an application icon on the home screen). To drag an item, touch and hold it for a moment, then without lifting your fingertip, move your fingertip on the screen until the item reaches its target destination.
Swipe up/down on the screen to scroll through a list. On some screens, you may be able to swipe left/right to change the view.
To swipe, touch the screen and then quickly move your fingertip across the screen without lifting your fingertip. Do not pause on the screen with your fingertip at the initial point of contact or you may accidentally drag an item instead.
Quickly tap the screen twice on a webpage or other application screen to zoom (the application must support the double-tap/zoom function). Within the browser, double-tapping a webpage section will cause the browser to zoom and fit that section to the width of the screen.
About the Orientation Sensor
The tablet contains a sensor that will automatically change the orientation of most screens as you rotate the tablet. The sensor works best when the tablet is rotated perpendicular to the ground (i.e., when the tablet is held upright and not fat on its back).
The orientation sensor can be turned on and off in the
Display
settings menu.
Charging the Tablet
The tablet comes with a built-in rechargeable lithium-polymer battery.
Before using the tablet, the battery should be charged fully. The Status Indicator will light blue when the battery is charged fully.
To charge the battery:
Plug one end of the included power adapter into an AC 100-240V outlet.
Plug the other end of the included power adapter into the Power jack on the tablet.
Disconnect the power adapter when the tablet is fully charged.
The battery used in this device may present a fire or chemical burn if mistreated. Do not disassemble, incinerate, or
heat the device. Do not leave the de-vice in a place subject to direct sun light, or in a car with its windows closed. Do not connect the device to a power source other than that which is indicated here or on the label as this may result in the risk of fire or electric shock.
Inserting a Memory Card
The tablet accepts microSDHC memory cards. Insert a memory card into the microSDHC card slot to:
Increase the memory capacity of your tablet
Play media files stored on the memory card (e.g., music, video, or photo files).
To insert a memory card:
Align the memory card with the card slot. The metal contacts of the memory card should face down away from the LCD
screen.
Slide the card into the spring-loaded slot. Push the card in until it clicks into place.
Do not attempt to insert objects other than a microSDHC memory card into the card slot. A compatible memory
card should fit easily into the card slot; if you encounter resistance, check the alignment of the card. Do not attempt to force the card in.
Avoid touching the gold contacts of the memory card.
To release and remove a memory card: UNMOUNT the memory card.
a. From the home screen, tap the
b. Touch
c. Touch
Storage Unmount SD card
Launcher Tab
to show the storage settings.
to prepare the memory card for safe removal.
, and then touch
Settings
to show the settings menu.
Push the card further into the slot until you hear a click. The card will spring out of the slot.
Grasp the card by its edge to remove it.
To avoid damage and data corruption, do not remove a memory card while data is being written to or read from the
card. For example, do not remove a card while playing a music file stored on the card.
Resetting the Tablet
Reset the tablet if it should freeze and not respond or otherwise malfunction.
1. Disconnect your tablet if it is connected to a computer.
2. Press and hold the POWER key for about 8 seconds to turn off the tablet, and then press and hold the POWER key about 3 seconds to turn on the tablet.
Getting Started
Turning the Tablet on and off
To turn the tablet on:
Press and hold the
ready for use.
To turn the tablet off:
1. Press and hold the
2. To uch OK to turn off the tablet.
Power
key until the LCD screen turns on. Wait until the Home screen appears; the tablet is now
Power
key until the confirmation message appears.
Turning the Screen On and Off (Standby)
When the tablet is on, you can turn off the screen to conserve battery power. Simply press the screen off. Press the
key again to turn the screen back on.
Power
key once to turn the
Power
Unlocking the Screen
When the screen turns off, you will have to unlock the screen when you turn it back on.
To unlock the screen, touch and drag the
To conserve battery power, the screen can be set to tur n off automatically when the tablet is not in use (betwee n
15 seconds and 30 minutes). This
icon to the edge of the circle that appears.
lock
option can be found in the
Sleep
Display
menu.
If a password has been set, enter the password to finish unlocking the screen. The Screen Unlock password can be set in the
Security
WARNING: Please write down your password lock pattern/PIN/Password. Misplacing or forgetting this method will
settings menu.
lock the user out. Recovering the unit will reset the device back to factory defaults.
PROGRAMS WILL BE LOST
.
ALL YOUR DATA &
Home Screen at a Glance
The home screen is the starting point for all of the features of your tablet.
Name Description
Google Search
1
Home
2
3
4 Recent Apps
5 Launcher Tab Open the Launcher to view the list of all Applications and Widgets installed on the tablet.
6 Widgets
Back
icon
icon
Touch to search with Google browser.
Touch to back to the central Home Screen.
Touch to back to the previous screen.
Touch to display the list of thumbnail images of apps you have worked recently.
Touch an App to open it.
Touch the Launcher tab to open the Launcher.
Widgets are small applications that you can use directly from the home screen. For
more information, refer to the “Widgets” section on page xx.
Name Description
more information, refer to the “Widgets” section on page xx.
7 Icons Touch an icon to open an application or folder.
8 Notification bar Shows notification icons such as time, battery level, and the network signal strength; touch
the bar to open the full Notifications panel. Touch a Notification icon to display more detail.
About Applications
To open an application, touch the application icon on the home screen or in the Launcher.
Launcher screen:
The screen shown above is for illustrative purposes only. MPMAN reserves the right to modify and improve the
final list of applications available on the tablet.
Preinstalled Applications
Some applications have been installed on your tablet for your convenience. These applications include:
Download and read thousands of e-books. Supports the ePub standard.
Browse the web.
Display the calendar or record events and appointments to manage your schedule.
Perform simple mathematical operations.
Take pictures or videos with the front-facing camera (or 2MP back camera).
View the current time, or set an alarm.
Get $10 of music from eMusic.
Check your e-mail.
View and manage files stored on the tablet.
View photos and videos, plus edit photos.
Access to thousands of apps with GetJar Marketplace.
Play music.
Access the Settings menu to adjust the tablet’s options.
Launch the mobile YouTube™ browser page to watch internet videos.
Installing Applications
You can also download an install additional applications from the device’s applications marketplace, the web browser, or other sources.
The tablet must be set to allow installation of applications from non-Market sources. The Unknown sources option can be set in the
responsible for the behavior of these applications; please review the description and terms of use provided by third-party developers carefully before installing applications on your tablet.
Application settings
Support for third-party applications is provided by their respective applications developers. Mpman is not
menu.
About Widgets
Widgets are self-contained applications that you can place on the Home screens to access your favorite features.
Adding Widgets to a Home Screen
Navigate to the Home screen which you want to place the Widget on.
Touch the
Touch
WIDGETS
Launcher Tab
to show all widgets, and then hold on a widget icon to add it to the Home screen.
.
Removing Widgets
Touch and hold the Widget until Remove icon appears at the top side of the screen, then drag the Widget to the Remove icon to remove it.
About Notifications
The icons that appear in the Notification bar at the bottom right corner of the screen alerts you when new messages arrive or alarms or other application events occur.
View and respond to the notifications by opening the full Notifications panel.
Touch the
To respond to a notification:
Touch a notification in the list; the Notifications panel will close and the application associated with the notification will
Notification
launch.
bar to open the Notifications panel.
To close the Notifications panel:
Touch any other area of screen except the Notifications panel , or;
Touch the Back icon.
Connecting to the Internet
This tablet can utilize Wi-Fi data networks to connect to the Internet.
Wireless Wi-Fi technology can provide Internet access at distances of over 300 feet; however, this distance can be
affected by your surrounding environment and Wi-Fi router.
Requirements
In order to connect to the Internet, you will need either of the following:
A wireless router or access point with a broadband Internet connection
The wireless router must support Wi-Fi 802.11b/g connections. If the router supports 802.11n, make sure that it has been configured to acc qept 802.11b/g connections as well.
A minimum connection speed of 64 Kbps is recommended. Faster speeds will enable a better Internet experienc e.
You will need to know the name of your network (SSID), as well as the password or other credentials if your network is secured. These settings can usually be found on the administration webpage of your wireless router.
Please refer to your wireless router’s documentation for help, or ask your network administrator for details.
You may encounter open Wi-Fi networks, or “hot spots.” These networks are usually configured so that you can
simply connect to them without needing to know its settings; the tablet will obtain all the information it needs from the router automatically.
Connect to a Wi-Fi network
The Notification bar displays icons that indicate your tablet’s Wi-Fi status.
Connected to a Wi-Fi network (waves indicate connection strength).
[no icon] There are no Wi-Fi networks in range, or the Wi-Fi radio is off.
1. Turn on the Wi-Fi radio if it is not already on. To turn on Wi-Fi:
a. Go to the Home screen:
Touch the
b. Open the Launcher screen:
Touch the
c. Open the Wireless & networks menu:
Touch
WIRELESS & NETWORKS
d. Open the Wi-Fi settings menu:
Touch
WiFi
e. Make sure that the Wi-Fi option box is setted to ON: Touch and slide the block right to enable the
connection.
icon.
Home
Launcher Tab
.
, then touch
.
Settings
.
Wi-Fi
When Wi-Fi is on, the tablet will look for and display a list of available Wi-Fi networks.
If a network that you have connected to previously is found, the tablet will connect to it. If you don’t see your network in the list, you can force the tablet to re-scan. To scan for networks, tap the
icon that located on the top right corner of the screen.
2. Select an available Wi-Fi network to connect to:
In the same Wi-Fi settings menu above, touch a network in the list.
If the network is open, the tablet will prompt you to confirm connection to the network. Touch
If the network is secured (as indicated by a Lock icon), the tablet will prompt you to enter a password or other credentials. Touch the Wireless password box to show the on-screen keyboard and then use it to enter the password. Touch to confirm.
When you have successfully connected to a Wi-Fi network, the Notifications bar at the bottom of the screen will show a Wi-Fi signal indicator.
To learn about how to add a Wi-Fi network when it is not in range or when the router is set to obscure the network
name (SSID); or to configure advanced Wi-Fi options, please refer to the m anual.
Connect
to confirm.
SCAN
Connect
Browsing the Web
The Browser application lets you visit webpages and find information on the web. Keep up with the news, your friends, or enjoy video from YouTube™, the world’s most popular video-sharing community.
To use Browser, the tablet must be connected to the Internet. Read the section “Connecting to the Internet” to learn how to connect to the Internet.
To open Browser, touch the Browser icon on the Home screen or in the Launcher.
Name Description
1 Address bar Displays the address (URL) of the current page. Touch the bar to enter a new address or to
search the web.
Goto Bookmarks
2
icon
Search
3
Add Bookmark
4
icon
5 New Window (+) Creates new browser window.
Some common Browser actions are described below.
To go to a webpage.
icon Touch to search with Google browser.
Touch to view bookmarks, to view your most visited sites, or to view your browser history.
Touch to add bookmarks.
1. Touch the
at the top of the
bar
Browser screen. The
keyboard will open
automatically. (If the
Address
Address bar is not visible, drag the page down to return to the top of the Browser screen.)
2. Use the keyboard to enter the ad-dress (URL) of the webpage (e.g., www.mpmaneurope.c om).
3. To uch open the webpage.
To bookmark a webpage
Bookmark your favorite webpages in order to visit them quickly without entering a URL.
1. Go to the webpage that you want to bookmark
2. To uch the
Bookmark
Enter
Add
icon.
key to
.
3. If desired, you can modify the name of the bookmark or its location (URL address). Otherwise, touch OK to finish adding the book-mark.
To go to a bookmarked webpage.
1. To uch the
Bookmark
2. Touch a bookmark tile to open it.
To delete a bookmarked webpage.
1. To uch the
Bookmark
Goto
icon.
Goto
icon.
2. Touch and hold a bookmark tile to open the option menu.
3. T ouch “Delete bookmark“.
4. Touch “OK” to confirm.
Browser menu
While viewing a webpage, touch the icon show as right to open the Browser Menu, the icon is locate on the top right corner
of the screen, the options are:
Refresh: Refresh the current webpage.
Forward: Go to the next webpage.
New tab: Open the webpage in a new window, under a new tab.
New incognito tab: Open the webpage in a new window, under a new tab, and the pages you view in the new
window will not appear in your browser history or search history. See the on-screen explanation of going incognito.
Share page: Use Email to send the webpage URL.
Find on page: Search for content on the current page.
 Request desktop site:
Save for offline reading: Save this page onto the internal memory, then you can read it when the internet
connection is disable.
Page info: View information about the current page, including the URL.
Settings: Customize the Browser.
Managing Applications
Downloading and installing new applications to your tablet can extend its functionality in many ways.
You can download and install applications from the included Applications store. To open the Applications store:
1. To uch the
2. To uch the
When installing an application, it will tell you what functions it needs to control and if it needs access to your data. Make sure you review these access requirements carefully before completing the installation.
Launcher Apps Marketplace
icon.
icon.
Be especially cautious with applications that request access to many functions or to a significant amount of your data. You are responsible for the results of applications installed on your tablet.
You can learn more about GetJar, and browse for applications by visiting their website at www.getjar.com
Some developers allow you to download and install applications directly from their website. Support for third-party applications is provided by the respective application developer. Mpman is not responsible for the
behavior o f th ese applications; ple ase review th e de scription an d terms of use provided by th ird-party d evelopers carefully before installing applications on your tablet.
To uninstall an application:
1. From the Home screen, touch the
2. Touch Settings to open the
Settings
Launcher Tab
menu.
.
.
3. To uch
, a list of all applications installed on the tablet will display on screen.
Apps
4. Touch the name of the application you want to uninstall; the Application Info screen will open.
5. To uch
Uninstall
. The tablet will prompt you to confirm.
6. To uch OK to uninstall the application.
Or you can uninstall an application from the Launcher screen directly. Touch and hold an application icon until the
Uninstall
icon
appears, drage the application icon to the
Uninstall
icon to uninstall the
application.
Optional Connections
Connecting to a Computer
Connect the tablet to a computer to transfer files.
1. Connect your tablet to the computer.
With the included USB cable: Plug the small end of the cable into the USB 2.0 Hi- speed connector of the tablet.
Plug the large end of the cable into an available USB 2.0 Hi-speed port on the computer.
When your tablet is connected, a USB icon will appear in the Notification bar.
Touch the Notification bar to open the notifications panel.
The Tablet’s “mass storage mode” is compatib le with many operat ing systems includ ing: Microsoft
Vista, 7 or higher and Mac OS or Linux.
2. Mount the storage driv e.
To uch
prompted to confirm. When mounted, you can copy files to/from your computer to it.
Your tablet will be recognized by the computer as a Removable Storage drive. Drag and drop files between your tablet and the computer. To learn more about copying files, please refer to the documentation included with your computer or operating system.
USB connected
to mount the tablet’s built-in storage, then touch “Turn on USB storage” and “OK” when
®
Windows® XP,
Connecting to a TV
Connect to a TV to enjoy your tablet from the comfort of your living room. An HDMI cable (Type A-to-Type C) is required to connect the tablet to a TV.
The tablet will recoginze and match the capabilities of the TV automatically.
To connect the tablet to the TV:
1. Plug the small end of the HDMI cable into the mini HDMI connector of the tablet.
2. Plug the large end of the HDMI cable into the HDMI port on the TV.
3. Turn on the TV, and set its display mode to the HDMI port that the tablet is connected to.
The tablet’s display will be output to the TV screen.
If you need help setting the display mode of the TV, please refer to the documentation provided by the TV
manufacturer.
Connecting Headphones
Connect a pair of headphones (or earphones) to the tablet to enjoy media in private.
Lower the volume level of the tablet before connecting headphones, and then slowly raise the volume to a comfortable listening level.
The headphones must have a 3.5 mm (1/8 in) plug.
When headphones are connected, speaker output will be disabled automatically.
Hearing experts advise against the constant use of personal stereos played at high volume. Constant exposure to
high volumes can lead to hearing loss. If you should experience ringing in the ears or hearing loss, discontinue use and seek medical advice.
Hearing experts advise against the constant use of personal stereos played at high volume. Constant exposure to
high volumes can lead to hearing loss. If you should experience ringing in the ears or hearing loss, discontinue use and seek medical advice.
Using the USB Full-Size Adapter
The USB full-size adapter can be used to connect and use USB devices with the tablet. The adapter converts the mini USB port on the tablet into a USB On-the-Go (OTG) connector.
Connecting a Keyboard
For times when you want to type for an extended period of time, you may want to connect a full-size keyboard to the tablet.
Use the included USB full-size (Type A) adapter to connect a keyboard to the tablet.
You may also use this connection to add a mouse to the tablet. The adapter supports one connection at a time. To use a keyboard and
mouse simultaneously, you will need to add an external USB hub.
Connecting a Storage Device
Use the included USB full-size (Type A) adapter to connect a storage device to the tablet (e.g., a USB flash memory drive).
This connection supports a maximum storage size of 16 GB. For additional storage capacity, a microSDHC card
can be added to the tablet.
Setting the System Options
Open the system settings menu to adjust how the tablet looks and functions.
Many applications will have their own settings; refer to the documentation
provided by the application developer to learn more.
To open the Settings menu:
1. From the Home screen, touch the
2. To uch
The settings are grouped by category. Touch a category to open and adjust its settings on the right side.
Please refer to the manual for a description of the items in the S ettings menu.
Settings
to open the Settings menu.
Launcher Tab
.
Specifications
Please visit www.mpmaneurope.com for the latest product information. Design, specifications, and manual are subject to change without notice.
Processor
RAM
Storage
Display
Networking
Video Output
Audio Output
PC Interface
Additional Features
Operating System
Front-facing camera (2MP back camera optional *pls check with shop)
Cortex A8 (1 GHz)
1GB
4GB Flash built-in (8GB optional *pls check with shop)
microSDHC card slot (max. 32GB supported)
9.7” TFT LCD (1024 x 768), capacitive touchscreen
Wi-Fi IEEE 802.11 b/g/n
Mini HDMI, type C (1080p and 720p supported)
3.5 mm headphone
USB 2.0 Hi-speed
Built-in microphone
Stereo speaker
Android™ 4.0
Power
Playback Time (hours) *
Music was tested with a 128 kbps MP3 file; video was tested with a 1920 x 1080 MPEG-4/AVC file; browsing was tested with the screen brightness set to default. Actual playback results may vary.
Rechargeable Li-poly battery Power Adapter (DC 5V)
Up to 25 hours music, 5 hours video, 6 hours web browsing
For more information please check our website
www.mpmaneurope.com
Loading...
