Mpman MP10 WOM User Manual

For M ode l No.

MP1 0WOM

Use r Manua l

EN

1. Features Overview

● Classic appearance design and suitable
hand feel.

● Only support MP3 music playing format.

● USB 1.1 interface, free driver U-disk

function.
You can directly through the "Removable
Disk" operation documents in the "My
Computer", and in Windows 2K over the
system is without installing the driver.

: Play/ Pause / Power On/Off

1
2 +: Volume Increasing

: Rewind /Previous Music

3
4 -: Volume Decreasing

: Fast-forward / Next Music

5
6 On/Off: Power On/Off.
7 Earphone Jack
8 USB Slot
9 Micro SD card

2. Indicator light

1. USB be used to charge MP3, when
connected PC, the indicator red light flash a
few seconds fast.

2. When playing music, the indicator light will

1

flash rhythmically slowly..

3. when low power, the indicator light will
flash fast for a second and then shutdown.

3. Battery

Make sure the power switch is being ON to
charge, or the player could not be charged
properly. Disconnect the player and USB,if
you want to stop charging.
Turn OFF the player when you do not use it.
Warni ng: Please make sure the player is fully
charged before not using for a long time. Pls
switch OFF the machine when didnot use the
player more than 6 months and please
remember to recharge it again.

4. Trouble Shooting

No Power Check to see if battery is low.

Check to see if the player is ON

No sound

Check to see Volume is set “0”

from

and connect the earphone

earphone.

connects properly.
Make sure earphone is clean and
in good status.
Damaged MP3 file may make
noise and could not be played
Make sure that the music files are
not damaged.

Failu re of

Check to see if USB cable is

music

damaged and connected

download

properly.
Check to see if driver is installed
correctly.
Check to see if memory space is
enough.

2

5.Technical Specifications

Dimensions 41mm x 28mm x 12mm
Weight 16g
Solution AC1083
Mirco SD card Support(up to 32 GB)
Connecting to
PC
Battery Type Li-Polymer Rechargeable

Play time approx. 5hours
Supported
Music Formats
Earphones
output power
Worki ng
temperature
Operating
System
Please note: Design and characters may
change without prior notice.

USB 1.1

(3.7V) , 110mAh

MP3

(L)10mW +
(R)10mW(32Ohm)

-5 to 40 degree

Windows / Mac

3

This is to certify this MP3 Player is in
accordance with:
EN55022:2010
EN55024:2010
EN61000-3-2:2006+A1:2009+A2:20
09
EN61000-3-3:2008

For more information please
check our website

www.mpmaneurope.com

4

Pro Model. č.

MP1 0WOM

Uživatelská příručkal

CZ
