For Model No.
M*%$
EN
User Manual
Page 1
This manual contains important safety precautions and information of correct use.
Please be sure to read this manual carefully before use so as to avoid any accidents.
Do not place the product in hot, wet or dusty environment, especially in summer, do not leave the product
inside a car with all windows closed.
Avoid dropping, impacting or shaking the product violently, otherwise it may cause damages or malfunctions.
Select a proper volume to avoid ear problem when using earphones.
Be sure to use the provided chargers and accessories in the package.
Be sure to charge the product when the following situations take place,
- The battery icon shows lower or empty.
- Operation keys do not respond properly.
- The device shows on the top right corner.
Hardware
Capacitive multi-touch (5 touch) point function
CPU: ARM cortex A8 processor
RAM : DDR3 512MB (3D accelerator possible for 3D games)
Wi-Fi (IEEE802.11 b/g/n) for internet connection
USB host for OTG function
G-sensor
Micro SD card slot recognizing up to 32GB
Built-in speaker & Built-in MIC
5V DC power adapter
Compatible with keyboard, mouse
Dimension : 1 x 1 x 1.mm
Andriod 4.0 ICS
Google browser
Wi-Fi connection
e-Book function (all e-book formats supported by application)
VoIP phone function with Wi-Fi connection
Video: AVI, RM/ RMVB, FLV, MPG4 – 1, MPEG – 2 etc.
Audio: MP3, WMA, AAC, WAV etc.
Photo: JPEG, BMP, GIF, PNG, TIFF
Page 2
specification
Software
Page 3
Name
Important Notice
- If the device is freezing or stuck, press the
reset button(a small hole) or long press
power button for 7 seconds.
- When the performance is slow after using
some applications, it is recommended to
close running application in setting menu.
Caution
- For charging, be sure to use the power
adapter(DC5V) that is provided in the package,
otherwise, the device may be damaged
and does not work.
- The device is equipped with high performance
processor. It may heat in case of using long or
while charging.
Charger
USB
Menu Home Back
Speaker
Power
Camera
MicroSD
Reset
Earphone
Page 4
1. Power On/Off
After turning on the device, desktop displays with shortcut icons and arrow panel at the right side
2. Desktop
Page 5
3. Standby mode(Screen off mode) /
Unlock the screen
After standby mode o, slide the lock icon in order to unlock the screen.
On the desktop, press menu button and select system settings.
4. System settings
Page 6
Press System Settings
1.Wireless & networks
Page 7
Wi-Fi settings - Press Wi-Fi settings, then the device
will automatically search the available Wi-Fi signals.
Select the network you want to connect with.
2. Sound
Set up each setting as you like.
Page 8
3. Display
Set up each setting as you like.
4. Storage
Check device memory and microSD card status.
Unmount SD card – Unmount the SD card for
safe removal.
Page 9
5. Battery
Check battery usage status.
6. Apps
Manage downloaded or running applications.
Downloaded
All installed application are listing.
Page 10
Keep pressing an application to manage.
Press Uninstall to uninstall the selected application.
Running services
View and control currently running services.
Page 11
7. Account & sync
Create your account. After connecting Wi-Fi network, the e-mailing system synchronizes your account
with the device. Emails are automatically downloaded into the device.
8. Location services
Google’s location service - Let apps use data from sources such as WiFi and mobile networks to determine
your approximate location
Page 12
9. Security
Screen lock – Protect your device from unauthorized use by creating a personal screen unlock pattern.
Make passwords visible – Show password as you type.
Unknown sources - If you want to allow installation of non-Market Applications,
Press Unknown sources and presses OK.
Install from SD card – Install encrypted certicates from SD card.
Page 13
10. Language & input
Language – Choose your preferable language.
Keyboard & input method – Change keyboard & keyboard settings.
On Language & input settings, if you need other languages besides English on keyboard,
press the relevant keyboard and enter the chosen Keyboard settings, select Keyboards,
press the language you need.
Page 14
11. Date & time
Set date & time and format
12. Developer options
Set options for application development
13. About tablet
See status, legal information, ETC
How to connect/disconnect the
device with/from the computer
On main desktop, connect the device with the PC,
touch right side of the status bar on the bottom of desktop
Page 15
Page 16
Press “USB connected”, select “Turn on USB storage”.
The device is recognized at Explorer of the computer.
Now you can use it as an external storage.
Note
You may only download adult applications if you are at least 18 years of age, or at least the age of majority in the jurisdiction where you reside or from
which you download adult applications. If you do not meet these requirements, then you do not have permission to download adult applications.
In case of any problems including legal issues from the breach by end-user’s own decision, the manufacturer shall not be responsible.
How to install Applications(.apk file) into the device
Method 1.
1. Connect the device with internet. See above [1.Wireless & networks] in order to connect internet.
2. Run “(FUKBS” and search the applications you want to install.
3. Follow the instruction on the screen for installation.
5. Run “File browser” and nd .apk le that was copied into the device.
Method 2.
3. Connect the device with your computer.
See above [How to connect/disconnect the device with/from the computer.]
Page 17
How to make desktop icons
Press the upper right side icon of desktop, the pop-up displays.
Page 18
Shortcuts
Long press your desired APK icon and put it
on the desktop.
Widgets
Press Widgets and press your desired icon to put it
on the desktop.
Wallpaper
Long press the desktop, press Wallpapers and select
one of categories of wallpaper.
Select one you desire and press Set wallpaper.
Page 19
Change Input Method
If your device was installed with other more input method, long press setting icon of keyboard,
and the pop-up displays.
Select the installed keyboard, then the keyboard will appear with your desired language you installed.
Page 20
Specification
OS
CPU
SDRAM
Display
Multi-touch screen
ㅤㅤㅤ
IO PORTS
ㅤ
ㅤ
ㅤ
Speaker
G-sensor
Camera
Wi-Fi
Power
Battery
Dimension
Charging time
Android 4.0 ICS
ARM cortex A8 processor
DDR3 512MB (3D accelerator possible for 4D games)
7" TFT 800*480 Capacitive touch panel
Yes : 5 point multi-touch
2 / 4 / 8 / 16GB
3.5ø earphones
1 x 5pin mini USB port (support USB host and OTG)
5V, 2A
Micro SD card
Same with USB port
Power, VOL-, VOL+, reset, 3 android function key
1.5W, Frequency response : 20Hz – 20k Hz, N/S : >85%
Yes
0.3M pixel (front)
802.11b/g/n
Adaptor 5V -2A
3.7V Li-Polymer
118 x 196 x 10.3mm
approx. 3~4hours
Audio port
USB port
DC port
Micro SD
OTG port
Button
by charger
Page 21
For more information please check our website
www.mpmaneurope.com
