The UPort 1100 Series of USB-to-serial adaptors provide an easy way to add COM ports to your
computer. The UPort 1110 provides one RS-232 port, the UPort 1130 provides one
RS-422/RS-485 port, and the UPort 1150 and UPort 1150I each provide one RS-232/422/485 port.
As a plug and play USB device, the adaptors are perfect for mobile, instrumentation, and point-of
sale applications.
The following topics are covered in this chapter:
Overview
Package Checklist
Product Features
Product Specifications
LED Indicators
¾ Adjustable Pull High/low, Terminator Resistors for the RS-485 Port
UPort 1100 Series User’s Manual Introduction
Overview
The UPort 1110, UPort 1130, and UPort 1150/1150I are part of Moxa’s UPort line of
USB-to-serial adaptors. The UPort line provides a range of easy-to-use solutions for adding COM
ports through a PC’s USB port. Simply install the drivers, connect the UPort to your computer,
plug in your serial devices, and you’re ready to go. Programming is not required, and you do not
need to worry about IRQs, configuring a board, power requirements, or connection schemes.
The UPort 1100 series provides single COM port expansion. The UPort 1110 adds one RS-232
port to your computer, which is the same type of COM port that is built into most PC
motherboards. The UPort 1130 adds one port that is configurable for RS-422, 2-wire RS-485, and
4-wire RS-485 modes. The UPort 1150/1150I adds one RS-232, RS-422, 2 wire RS-485, or 4 wire
RS-485 port to your computer. All of these models can operate at speeds of up to 12 Mbps, which
is much faster than the current maximum serial transfer rate.
The adaptor is bus-powered, so no external power supply is required.
Package Checklist
The following items are included in your UPort package:
y UPort 1100 Series USB-to-Serial Adaptor
y UPort Documentation and Software CD
y UPort 1100 Series Quick Installation Guide
y 5-year Warranty Statement
The UPort 1130/1150/1150I also comes with the following item:
y Mini DB9F-to-Terminal-Block Converter
NOTE: Notify your sales representative if any of the above items is missing or damaged.
Product Features
The UPort adaptor has the following features:
y Full-Speed USB operation at up to 12 Mbps
y Additional I/O or IRQ not required
y Serial transmission speed up to 921.6 Kbps
y 64-byte FIFO and built-in hardware and software flow control
y Built-in 15 KV ESD protection
y Support for RS-422, 2-wire RS-485, and 4-wire RS-485 (UPort 1130/1150/1150I)
y Terminal block adaptor (UPort 1130/1150/1150I)
y 2 KV Optical Isolation Protection (UPort 1150I only)
1-2
UPort 1100 Series User’s Manual Introduction
Product Specifications
USB
Version USB 1.1 (also compatible with USB 1.0 and 2.0)
Connector USB type B
Speed 12 Mbps
Serial Interface
No. of Ports 1
RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422 TxD+(B), TxD-(A), RxD+(B), RxD-(A),GND
RS-485 4-wire: TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND 2-wire:
Data+(B), Data-(A), GND
Connector Male DB9
FIFO 64 bytes
Serial line protection 15 KV ESD for all signals
Serial Communication Parameters
Parity None, Even, Odd, Space, Mark
Data bits 5, 6, 7, 8
Stop bits 1, 1.5, 2
Flow control RTS/CTS, XON/XOFF
Speed 50 bps to 921.6 Kbps
Power Requirements
Power Consumption 30 mA@5 VDC
Mechanical
Dimensions
Material
Gross Weight
Environmental
Operating Temperature 0°C to 55°C (32°F to 131°F)
Storage Temperature -20°C to 85°C (-4°F to 185°F)
Operating Humidity 5% RH to 95% RH
Regulatory Approvals
Warranty
UPort 1110/1130/1150: 37.5 x 20.5 x 60 mm (L x W x H)
UPort 1150I: 52 x 80 x 22 mm (L x W x H)
UPort 1110/1130/1150: ABS + PC
UPort 1150I: Metal
UPort 1110/1130/1150: 60 g (0.13 lb)
UPort 1150I: 80 g (0.17 lb)
EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, IEC
61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC
61000-4-8, FCC Part 15 Class B
5 years
1-3
UPort 1100 Series User’s Manual Introduction
LED Indicators
UPort 1110
Active
TxD
RxD
1110
USB-to-Serial Adaptor
Name Description
Active
UPort 1130
Active
TxD
RxD
1130
USB-to-Serial Adaptor
UPort 1150
Active
TxD
RxD
1150
RS-232/422/485
USB-to-Serial Adaptor
This LED indicates normal operation. If the driver is installed correctly and
the adaptor is plugged into a functioning USB port, the Active LED will light
up and remain on. If the LED does not light up, there may be a problem with
the adaptor, the driver installation, or PC configuration.
TxD This LED blinks when the adaptor transmits data through its COM port.
RxD This LED blinks when the adaptor receives data through its COM port.
1-4
UPort 1100 Series User’s Manual Introduction
1K
TR
ON DIP
21
3
150 KX
Adjustable Pull High/low, Terminator Resistors for the RS-485 Port
In some critical environments, you may need to add termination resistors to prevent the reflection
of serial signals. When using termination resistors, it is important to set the pull high/low resistors
correctly so that the electrical signal is not corrupted. The UPort uses DIP switches to set the pull
high/low resistor values for each serial port.
To set the pull high/low resistors to 150 KΩ, make sure both of the assigned DIP switches are in
the OFF position. This is the default setting.
To set the pull high/low resistors to 1 KΩ, make sure both of the assigned DIP switches are in
the ON position.
SW
ON
OFF
1 2 3
Pull High Pull Low Terminator
1KΩ 1KΩ 120 Ω
150 KΩ 150 KΩ Disable
1-5
