Moxa Technologies EDS-518A User Manual

MOXA EtherDevice™ Switch

EDS-518A Series User ’s Manual

www.moxa.com/product

First Edition, April 2006

MOXA Networking Co., Ltd.

Tel: [phone]
Fax: [phone]

Web:

MOXA Technical Support

Worldwide:
The Americas

www.moxa.com

[e-mail]
[e-mail]

MOXA EtherDevice™ Switch

EDS-518A Series User’s Manual

The software described in this manual is furnished under a license agreement and may be used only in

accordance with the terms of that agreement.

Copyright Notice

Copyright © 2006 MOXA Networking Co., Ltd.

All rights reserved.

Reproduction without permission is prohibited.

Trademarks

MOXA is a registered trademark of the MOXA Group.

All other trademarks or registered marks in this manual belong to their respective manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not represent a commitment on the
part of MOXA.

MOXA provides this document “as is,” without warranty of any kind, either expressed or implied, including, but
not limited to, its particular purpose. MOXA reserves the right to make improvements and/or changes to this
manual, or to the products and/or the programs described in this manual, at any time.

Information provided in this manual is intended to be accurate and reliable. However, MOXA assumes no
responsibility for its use, or for any infringements on the rights of third parties that may result from its use.

This product might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of the
publication.

Table of Contents

Chapter 1 Introduction ...............................................................................................1-1

Overview .............................................................................................................................. 1-2

Package Checklist................................................................................................................. 1-2

Features ................................................................................................................................ 1-2

Industrial Networking Capability.............................................................................. 1-2

Designed for Industrial Applications......................................................................... 1-2

Useful Utility and Remote Configuration ................................................................. 1-3

Recommended Software and Accessories................................................................. 1-3

Chapter 2 Getting Started ..........................................................................................2-1

RS-232 Console Configuration (115200, None, 8, 1, VT100) ............................................. 2-2

Configuration using a Telnet Console .................................................................................. 2-5

Configuration using a Web Browser..................................................................................... 2-6

Disabling Telnet and Browser Access .................................................................................. 2-8

Chapter 3 Featured Functions...................................................................................3-1

Configuring Basic Settings................................................................................................... 3-2

System Identification................................................................................................. 3-2

Password ................................................................................................................... 3-3

Accessible IP............................................................................................................. 3-4

Port ............................................................................................................................ 3-5

Network..................................................................................................................... 3-6

Time .......................................................................................................................... 3-8

System File Update—By Remote TFTP ................................................................... 3-9

System File Update—By Local Import/Export....................................................... 3-10

Factory Default........................................................................................................ 3-11

Using Port Trunking ............................................................................................................3-11

The Port Trunking Concept..................................................................................... 3-11

Configuring Port Trunking...................................................................................... 3-12

Configuring SNMP............................................................................................................. 3-14

SNMP Read/Write Settings..................................................................................... 3-14

Trap Settings ........................................................................................................... 3-16

Private MIB information ......................................................................................... 3-16

Using Communication Redundancy................................................................................... 3-16

Gigabit Ethernet Redundant Ring Capability (< 300 ms) ....................................... 3-17

The Turbo Ring Concept......................................................................................... 3-17

Configuring Turbo Ring.......................................................................................... 3-20

The STP/RSTP Concept.......................................................................................... 3-21

Configuring STP/RSTP........................................................................................... 3-26

Using Traffic Prioritization................................................................................................. 3-29

The Traffic Prioritization Concept .......................................................................... 3-29

Configuring Traffic Prioritization ........................................................................... 3-31

Using Virtual LAN ............................................................................................................. 3-34

The Virtual LAN (VLAN) Concept ........................................................................ 3-34

Sample Applications of VLANs using MOXA EDS-518A .................................... 3-36

Configuring Virtual LAN........................................................................................ 3-37

Using Multicast Filtering.................................................................................................... 3-40

The Concept of Multicast Filtering ......................................................................... 3-40

Configuring IGMP Snooping .................................................................................. 3-43

Add Static Multicast MAC...................................................................................... 3-44

Configuring GMRP................................................................................................. 3-45

GMRP Table ........................................................................................................... 3-45

Using Bandwidth Management .......................................................................................... 3-46

Configuring Bandwidth Management..................................................................... 3-46

Broadcast Storm Protection..................................................................................... 3-46

Traffic Rate Limiting Settings................................................................................. 3-46

Using Port Access Control.................................................................................................. 3-47

Configuring Static Port Lock .................................................................................. 3-49

Configuring IEEE 802.1X....................................................................................... 3-49

Using Auto Warning........................................................................................................... 3-52

Configuring Email Warning.................................................................................... 3-53

Event Type .............................................................................................................. 3-53

Email Setup ............................................................................................................. 3-55

Configuring Relay Warning .................................................................................... 3-56

Event Setup ............................................................................................................. 3-56

Warning List............................................................................................................ 3-57

Using Line-Swap-Fast-Recovery........................................................................................ 3-57

Configuring Line-Swap Fast Recovery................................................................... 3-58

Using Set Device IP............................................................................................................ 3-58

Configuring Set Device IP ...................................................................................... 3-59

Using Diagnosis.................................................................................................................. 3-59

Mirror Port .............................................................................................................. 3-59

Ping ......................................................................................................................... 3-60

Using Monitor .................................................................................................................... 3-60

Monitor by Switch................................................................................................... 3-60

Monitor by Port ....................................................................................................... 3-61

Using the MAC Address Table ........................................................................................... 3-62

Using Event Log................................................................................................................. 3-62

Using HTTPS/SSL ............................................................................................................. 3-63

Chapter 4 EDS Configurator GUI...............................................................................4-1

Starting EDS Configurator ................................................................................................... 4-2

Broadcast Search .................................................................................................................. 4-2

Search by IP address............................................................................................................. 4-3

Upgrade Firmware................................................................................................................ 4-3

Modify IP Address................................................................................................................ 4-4

Export Configuration............................................................................................................ 4-5

Import Configuration............................................................................................................ 4-6

Unlock Server....................................................................................................................... 4-7

Appendix A MIB Groups...............................................................................................A-1

Appendix B Specifications...........................................................................................B-1

Appendix C Service Information..................................................................................C-1

MOXA Internet Services ......................................................................................................C-2

Problem Report Form...........................................................................................................C-3

Product Return Procedure.....................................................................................................C-4

Chapter 1 Introduction

Welcome to MOXA EtherDevice Switch EDS-518A Series, the Gigabit Managed Redundant
Ethernet Switch designed specially for connecting Ethernet-enabled devices in industrial field
applications.

The following topics are covered in this chapter:

 Overview
 Package Checklist
 Features

1

1

EDS-518A Series User’s Manual Introduction

Overview

As the world’s network and information technology becomes more mature, the trend is to use
Ethernet as the major communications interface in many industrial communications and
automation applications. In fact, a whole new industry has sprung up to provide Ethernet products
that comply with the requirements of demanding industrial applications. EDS-518A is designed
for Gigabit-speed, high port density, ultra-reliable operation in rugged industrial environments,
and is therefore the best choice for each industrial application.

Package Checklist

MOXA EtherDevice Switch EDS-518A Series is shipped with the following items. If any of these
items are missing or damaged, please contact your customer service representative for assistance.

y 1 MOXA EtherDevice Switch EDS-518A
y Hardware Installation Guide
y CD-ROM with User’s Manual and Windows Utility
y MOXA Product Warranty booklet
y RJ45 to DB9 Console port cable
y Protective caps for unused ports
y Panel mounting kit (optional—must order separately)

Features

Industrial Networking Capability

y Redundant Gigabit Ethernet Ring Capability (recovery time < 300 ms at full load)
y IGMP Snooping and GMRP for filtering multicast traffic from industrial Ethernet Protocols
y Supports IEEE 802.1Q, Tag-based VLAN, GVRP, and Port-based VLAN to ease network

planning

y Supports QoS—IEEE 802.1p/1Q and TOS/DiffServ to increase determinism
y Supports 802.3ad, LACP for optimum bandwidth utilization

y Supports IEEE 802.1X and SSL to enhance network security
y SNMP V1/V2c/V3 for different levels of network management security
y RMON for efficient network monitoring and proactive capability

Designed for Industrial Applications

y Bandwidth management prevents unpredictable network status
y Support ABC-01 (Automatic Backup Configurator) for system configuration back up
y Long-haul transmission distance of 40 km or 80 km
y Redundant, dual 12-45 VDC power inputs
y IP 30, rugged high-strength metal case
y DIN-Rail or panel mounting ability
y Bandwidth management to prevent unpredictable network status
y Lock port for authorized MAC address access only
y Port mirroring for online debugging
y Automatic warning by exception through email, relay output
y Digital inputs to integrate a sensor and alarm with an IP network
y Automatic recovery of connected device IP addresses
y Line-swap fast recovery

1-2

EDS-518A Series User’s Manual Introduction

Useful Utility and Remote Configuration

y Configurable using a Web browser, Telnet/Serial console, and Windows utility
y Send ping commands to identify network segment integrity

Recommended Software and Accessories

y EDS-SNMP OPC Server Pro
y DR-4524, DR-75-24, DR-120-24 DIN-Rail 24 VDC Power Supply Series

1-3

2

2

Chapter 2 Getting Started

This chapter explains how to access EDS-518A for the first time. There are three ways to access
the switch: serial console, Telnet console, and web browser. The serial console connection method,
which requires using a short serial cable to connect EDS-518A to a PC’s COM port, can be used if
you do not know EDS-518A’s IP address. The Telnet console and web browser connection
methods can be used to access EDS-518A over an Ethernet LAN, or over the Internet.

The following topics are covered:

 RS-232 Console Configuration (115200, None, 8, 1, VT100)
 Configuration using a Telnet Console
 Configuration using a Web Browser
 Disabling Telnet and Browser Access

EDS-518A Series User’s Manual Getting Started

RS-232 Console Configuration (115200, None, 8, 1, VT100)

NOTE

NOTE

Connection Caution!

1. You cannot connect to EDS-518A simultaneously by serial console and Telnet.

2. You can connect to EDS-518A simultaneously by web browser and serial console, or by web

browser and Telnet.
However, we strongly suggest that you do NOT use more than one connection method at the
same time. Following this advice will allow you to maintain better control over the
configuration of your EDS-518A.

We recommend using MOXA PComm Terminal Emulator, which can be downloaded free of
charge from MOXA’s website.

Before running PComm Terminal Emulator, use an RJ45 to DB9-F (or RJ45 to DB25-F) cable to
connect EDS-518A’s RS-232 Console port to your PC’s COM port (generally COM1 or COM2,
depending on how your system is set up).

After installing PComm Terminal Emulator, perform the following steps to access the RS-232

Console utility.

1. From the Windows desktop, click Start Æ Programs Æ PCommLite2.5 Æ Terminal

Emulator.

2. Select Open under Port Manager to open a new connection.

2-2

EDS-518A Series User’s Manual Getting Started

3. The Communication Parameter page of the Property window opens. Select the appropriate

COM port for Console Connection, 115200 for Baud Rate, 8 for Data Bits, None for Parity,
and 1 for Stop Bits.

4. Click the Terminal tab, and select VT100 for Terminal Type. Click OK to continue.

5. Type 1 to select ansi/VT100 terminal type, and then press Enter.

2-3

EDS-518A Series User’s Manual Getting Started

6. The Console login screen will appear. Press Enter to open the Account pop-up selector and

then select either admin or user. Use the keyboard’s down arrow to move the cursor to the
Password field, enter the Console Password (this is the same as the Web Browser password;
leave the Password field blank if a console password has not been set), and then press Enter.

7. EDS-518A’s Main Menu will be displayed. (NOTE: To modify the appearance of the

PComm Terminal Emulator window, select Font… under the Edit menu, and then choose the

desired formatting options.)

8. After entering the Main Menu, use the following keys to move the cursor, and to select

options.

Key Function

Up/Down/Left/Right arrows, or Tab Move the onscreen cursor

Enter Display & select options

Space Toggle options

Esc Previous Menu

2-4

EDS-518A Series User’s Manual Getting Started

Configuration using a Telnet Console

You may use Telnet to access EDS-518A’s console utility over a network. To be able to access
EDS’s functions over the network (by Telnet or Web Browser) from a PC host that is connected to
the same LAN as EDS-518A, you need to make sure that the PC host and EDS-518A are on the
same logical subnet. To do this, check your PC host’s IP address and subnet mask. By default,
EDS-518A’s IP address is 192.168.127.253 and EDS-518A’s subnet mask is 255.255.0.0 (for a
Class B network). If you do not change these values, and your PC host’s subnet mask is

255.255.0.0, then its IP address must have the form 192.168.xxx.xxx. On the other hand, if your
PC host’s subnet mask is 255.255.255.0, then its IP address must have the form 192.168.127.xxx.

NOTE

NOTE

NOTE

To use EDS-518A’s management and monitoring functions from a PC host connected to the same
LAN as EDS-518A, you must make sure that the PC host and EDS-518A are on the same logical
subnet.

Before accessing the console utility via Telnet, first connect one of EDS-518A’s RJ45 Ethernet
ports to your Ethernet LAN, or directly to your PC’s Ethernet NIC. You can establish a
connection with either a straight-through or cross-over Ethernet cable.

EDS-518A’s default IP is 192.168.127.253.

Perform the following steps to access the console utility via Telnet.

1. Click Start Æ Run, and then telnet to EDS-518A’s IP address from the Windows Run

window. (You may also issue the telnet command from the MS-DOS prompt.)

2. Type 1 to choose ansi/vt100, and then press Enter.

2-5

EDS-518A Series User’s Manual Getting Started

3. The Console login screen will appear. Press Enter to open the Account pop-up selector and

then select either admin or user. Use the keyboard’s down arrow to move the cursor to the
Password field, enter the Console Password (this is the same as the Web Browser password;
leave the Password field blank if a console password has not been set), and then press Enter.

4. When the Main Menu of EDS-518A’s console utility opens, click Terminal Æ

preferences… from the menu at the top of the window.

5. When the Terminal Preferences window opens, make sure that the VT100 Arrows option is

selected.

NOTE

The Telnet Console looks and operates in precisely the same manner as the RS-232 Console.

Configuration using a Web Browser

MOXA EDS-518A’s web browser interface provides a convenient way to modify the switch’s
configuration and access the built-in monitoring and network administration functions. You may
use either Internet Explorer or Netscape to access EDS-518A.

NOTE

NOTE

To use EDS-518A’s management and monitoring functions from a PC host connected to the same
LAN as EDS-518A, you must make sure that the PC host and EDS-518A are on the same logical
subnet.

If EDS-518A is configured for other VLAN settings, you must make sure your PC host is on the
management VLAN.

2-6

EDS-518A Series User’s Manual Getting Started

NOTE

NOTE

Before accessing EDS-518A’s web browser interface, first connect one of its RJ45 Ethernet ports
to your Ethernet LAN, or directly to your PC’s Ethernet NIC. You can establish a connection
with either a straight-through or cross-over Ethernet cable.

MOXA EDS-518A’s default IP is 192.168.127.253.

Perform the following steps to access EDS-518A’s web browser interface.

1. Open Internet Explorer and type EDS-518A’s IP address in the Address field. Press Enter to

establish the connection.

2. The web login page will open. Select the login account (Admin or User) and enter the

Password (this is the same as the Console password), and then click Login to continue. Leave
the Password field blank if a password has not been set.

NOTE

By default, EDS-518A’s password is not set (i.e., is blank).

You may need to wait a few moments for the web page to be downloaded to your computer. Use
the menu tree on the left side of the window to open the function pages to access each of MOXA
EtherDevice Switch’s functions.

2-7

EDS-518A Series User’s Manual Getting Started

Disabling Telnet and Browser Access

If you are connecting EDS-518A to a public network, but do not intend to use its management

functions over the network, we suggest disabling both Telnet Console and Web Configuration
from the RS-232 Console’s Basic Settings Æ System Identification page, as shown in the

following figure.

2-8

3

3

Chapter 3 Featured Functions

This chapter explains how to access EDS-518A’s various configuration, monitoring, and
administration functions. There are three ways to access these functions: RS-232 console, Telnet
console, and web browser. The serial console connection method, which requires using a short
serial cable to connect EDS-518A to a PC’s COM port, can be used if you do not know
EDS-518A’s IP address. The Telnet console and web browser connection methods can be used to
access EDS-518A over an Ethernet LAN, or over the Internet.

The Web Console is the most user-friendly way to configure EDS-518A. In this chapter, we use
the Web Console interface to introduce the functions. There are only a few differences between the
Web Console, Serial Console, and Telnet Console.

The following topics are covered in this chapter:

 Configuring Basic Settings
 Using Port Trunking
 Configuring SNMP
 Using Communication Redundancy
 Using Traffic Prioritization
 Using Virtual LAN
 Using Multicast Filtering
 Using Bandwidth Management
 Using Port Access Control
 Using Auto Warning
 Using Line-Swap-Fast-Recovery
 Using Set Device IP
 Using Diagnosis
 Using Monitor
 Using the MAC Address Table
 Using Event Log
 Using HTTPS/SSL

EDS-518A Series User’s Manual Featured Functions

Configuring Basic Settings

The Basic Settings group includes the most commonly used settings required by administrators to
maintain and control EDS-518A.

System Identification

The system identification items are displayed at the top of the web page, and will be included in
alarm emails. Entering the system identification information makes it easier to identify the
different switches connected to your network.

Switch Name

Setting Description Factory Default

Max. 30
Characters

This option is useful for specifying the role or
application of different EDS-518A units.
E.g., Factory Switch 1.

Managed Redundant Switch

[Serial No. of this switch]

Switch Location

Setting Description Factory Default

Max. 80
Characters

Switch Description

Setting Description Factory Default

Max. 30
Characters

Maintainer Contact Info

Setting Description Factory Default

Max. 30
Characters

To specify the location of different EDS-518A
units. E.g., production line 1.

Use this to enter a more detailed description of
the EDS-518A unit.

To provide information about whom to contact
in order to resolve problems. Use this to enter
contact information of the person responsible
for maintaining this EDS-518A.

Switch Location

None

None

3-2

EDS-518A Series User’s Manual Featured Functions

Password

EDS-518A provides two levels of access privileges: admin privilege gives read/write access to all
EDS-518A configuration parameters, and user privilege provides read access only. You will be

able to view the configuration, but will not be able to make modifications.

ATTENTION

EDS-518A’s default Password is not set (i.e., is blank). If a Password is already set, then you
will be required to type the Password when logging into the RS-232 Console, Telnet Console, or
Web Browser interface.

Account

Setting Description Factory Default

admin “admin” privilege allows the user to modify all

EDS-518A configurations.

user “user” privilege only allows viewing EDS-518A

configurations.

Password

Setting Description Factory Default

Old Password
(Max. 16 Characters)

New Password
(Max. 16 Characters)

Retype Password
(Max. 16 Characters)

Type current password when changing the
password

Type new password when changing the password None

If you type a new password in the Password field,
you will be required to retype the password in the
Retype new password field before updating the
new password.

admin

None

None

3-3

EDS-518A Series User’s Manual Featured Functions

Accessible IP

MOXA EDS-518A uses an IP address-based filtering method to control access to EDS-518A
units.

Accessible IP Settings allows you to add or remove “Legal” remote host IP addresses to prevent
unauthorized access. Access to EDS-518A is controlled by IP address. If a host’s IP address is in
the accessible IP table, then the host will be allowed access to the EDS-518A. You can allow one
of the following cases by setting this parameter:

y Only one host with the specified IP address can access the EDS-518A

E.g., enter “192.168.1.1/255.255.255.255” to allow access to just the IP address 192.168.1.1.

y Any host on a specific subnetwork can access the EDS-518A

E.g., enter “192.168.1.0/255.255.255.0” to allow access to all IPs on the subnet defined by
this IP address/subnet mask combination.

y Any host can access the EDS-518A

Disable this function by deselecting the Enable the accessible IP list option.

The following table shows additional configuration examples:

Allowable Hosts Input format

Any host Disable

192.168.1.120 192.168.1.120 / 255.255.255.255

192.168.1.1 to 192.168.1.254 192.168.1.0 / 255.255.255.0

192.168.0.1 to 192.168.255.254 192.168.0.0 / 255.255.0.0

192.168.1.1 to 192.168.1.126 192.168.1.0 / 255.255.255.128

192.168.1.129 to 192.168.1.254 192.168.1.128 / 255.255.255.128

3-4

EDS-518A Series User’s Manual Featured Functions

Port

Port settings are included to give the user control over Port Access, Port Transmission Speed,

Flow Control, and Port Type (MDI or MDIX). An explanation of each configuration item follows:

Enable

Setting Description Factory Defau l t

checked Allows data transmission through the port.

unchecked Immediately shuts off port access.

ATTENTION

If a connected device or sub-network is wreaking havoc on the rest of the network, the Disable
option under Advanced Settings/Port gives the administrator a quick way to shut off access

through this port immediately.

Description

Setting Description Factory Defau l t

Media type Displays the media type for each module’s port N/A

Name

Setting Description Factory Defau l t

Max. 63 Characters Specify an alias for each port, and assist the

administrator in remembering important
information about the port.
E.g., PLC 1

enabled

None

3-5

EDS-518A Series User’s Manual Featured Functions

Speed

Setting Description Factory Defau l t

Auto Allows the port to use the IEEE 802.3u protocol

to negotiate with connected devices. The port and
connected devices will determine the best speed
for that connection.

100M-Full

100M-Half

10M-Full

10M-Half

FDX Flow Ctrl

This setting enables or disables the flow control capability of this port when the “port transmission
speed” setting is in “auto” mode. The final result will be determined by the “auto” process
between EDS-518A and connected devices.

Setting Description Factory Defau l t

Enable Enables flow control for this port when in

Disable Disables flow control for this port when in

Choose one of these fixed speed options if the
opposing Ethernet device has trouble
auto-negotiating line speed.

auto-negotiate mode.

auto-negotiate mode.

Auto

Disable

Network

MDI/MDIX

Setting Description Factory Defau l t

Auto Allows the port to auto detect the port type of the

opposing Ethernet device and change the port
type accordingly.

MDI

MDIX

The Network configuration allows users to modify the usual TCP/IP network parameters. An

explanation of each configuration item follows.

Choose the MDI or MDIX option if the opposing
Ethernet device has trouble auto-negotiating port
type.

Auto

3-6

EDS-518A Series User’s Manual Featured Functions

Auto IP Configuration

Setting Description Factory Default

Disable Set up EDS-518A’s IP address manually.

By DHCP EDS-518A’s IP address will be assigned

automatically by the network’s DHCP server.

By BOOTP EDS-518A’s IP address will be assigned

automatically by the network’s BOOTP server.

Switch IP Address

Setting Description Factory Default

IP Address of the
EDS-518A

Switch Subnet Mask

Setting Description Factory Default

Subnet mask of the
EDS-518A

Default Gateway

Setting Description Factory Default

Default Gateway of the
EDS-518A

Identifies the EDS-518A on a TCP/IP network. 192.168.127.253

Identifies the type of network to which the
EDS-518A is connected (e.g., 255.255.0.0 for a
Class B network, or 255.255.255.0 for a Class
C network).

The IP address of the router that connects the
LAN to an outside network.

Disable

255.255.255.0

None

DNS IP Address

Setting Description Factory Default

1st DNS Server’s
IP Address

2nd DNS Server’s
IP Address

The IP address of the DNS Server used by your
network. After entering the DNS Server’s IP
address, you can input EDS-518A’s URL (e.g.,

www.eds.company.com) in your browser’s

address field, instead of entering the IP address.

The IP address of the DNS Server used by your
network. EDS-518A will try to locate the 2nd
DNS Server if the 1st DNS Server fails to
connect.

None

None

3-7

EDS-518A Series User’s Manual Featured Functions

Time

EDS-518A has a time calibration function based on information from an NTP server or user
specified Time and Date information. Functions such as Auto warning “Email” can add real-time
information to the message.

NOTE

NOTE

EDS-518A does not have a real time clock. The user must update the Current Time and
Current Date to set the initial time for EDS-518A after each reboot, especially when the network

does not have an Internet connection for an NTP server or there is no NTP server on the LAN.

Current Time

Setting Description Factory Default

User adjustable time. The time parameter allows configuration of the

local time in local 24-hour format.

Current Date

Setting Description Factory Default

User adjustable date. The date parameter allows configuration of the

local date in yyyy/mm/dd format.

System Up Time

Indicates EDS-518A’s up time from the last cold start. The unit is seconds.

Time Zone

Setting Description Factory Default

User selectable time zone The time zone setting allows conversion from

GMT (Greenwich Mean Time) to local time.

Changing the time zone will automatically correct the current time. You should configure the
time zone before setting the time.

None (hh:mm:ss)

None

(yyyy/mm/dd)

GMT (Greenwich
Mean Time)

3-8

EDS-518A Series User’s Manual Featured Functions

Time Server IP/Name

Setting Description Factory Default

1st Time Server IP/Name IP or Domain address (e.g., 192.168.1.1 or

time.stdtime.gov.tw or time.nist.gov).

2nd Time Server IP/Name

Time Server Query Period

Setting Description Factory Default

Query Period This parameter determines how frequently the

EDS-518A will try to locate the 2nd NTP
Server if the 1st NTP Server fails to connect.

time is updated from the NTP server.

None

600 seconds

System File Update—By Remote TFTP

MOXA EDS-518A supports saving your configuration file to a remote TFTP server or local host
to allow other EDS-518A switches to use the same configuration at a later time, or saving the Log
file for future reference. Loading pre-saved firmware or a configuration file from the TFTP server
or local host is also supported for easy upgrading or configuration of EDS-518A.

TFTP Server IP/Name

Setting Description Factory Default

IP Address of TFTP
Server

Configuration Files Path and Name

Setting Description Factory Default

Max. 40 Characters The path and file name of EDS-518A’s

Firmware Files Path and Name

Setting Description Factory Default

Max. 40 Characters The path and file name of EDS-518A’s firmware

The IP or name of the remote TFTP server. Must be
set up before downloading or uploading files.

configuration file in the TFTP server.

file.

3-9

None

None

None

EDS-518A Series User’s Manual Featured Functions

Log Files Path and Name

Setting Description Factory Default

Max. 40 Characters The path and file name of EDS-518A’s log file None
After setting up the desired path and file name, click Activate to save the setting, and then click

Download to download the prepared file from the remote TFTP server, or click Upload to upload

the desired file to the remote TFTP server.

System File Update—By Local Import/Export

NOTE

Configuration File

To export the configuration file of this EDS-518A, click Export to save it to the local host.

Log File

To export the Log file of this EDS-518A, click Export and save it to the local host.

Some operating systems will open the configuration file and log file directly in the web page. In

such cases, right click Export to save as a file.

Upgrade Firmware

To import the firmware file of this EDS-518A, click Browse to select the firmware file already
saved on your computer. The upgrade procedure will proceed automatically after clicking Import.

Upload Configuration Data

To import the configuration file of this EDS-518A, click Browse to select the configuration file

already saved on your computer. The upgrade procedure will proceed automatically after clicking

Import.

3-10

EDS-518A Series User’s Manual Featured Functions

Factory Default

The Factory Default function is included to give users a quick way of restoring EDS-518A’s
configuration settings to their factory default values. This function is available in the Console
utility (serial or Telnet), and Web Browser interface.

NOTE

After activating the Factory Default function, you will need to use the default network settings to
re-establish a web-browser or Telnet connection with your EDS-518A.

Using Port Trunking

Link Aggregation allows one or more links to be aggregated together to form a Link Aggregation
Group. A MAC client can treat Link Aggregation Groups as if they were a single link.

EDS-518A’s Port Trunking feature allows devices to communicate by aggregating up to 3 trunk
groups, with a maximum of 8 ports for each group. If one of the 8 ports fails, the other seven ports
will provide back up and share the traffic automatically.

Port trunking can be used to combine up to 8 ports between two EDS-518A switches. If all ports
on both switch units are configured as 100BaseTX and they are operating in full duplex, the
potential bandwidth of the connection will be 1600 Mbps.

The Port Trunking Concept

MOXA has developed a proprietary Port Trunking protocol that provides the following benefits:

y Gives you more flexibility in setting up your network connections, since the bandwidth of a

link can be doubled, tripled, or quadrupled.

y Provides redundancy—if one link is broken, the remaining trunked ports share the traffic

within this trunk group.

y Load sharing—MAC Client traffic may be distributed across multiple links.
y To avoid broadcast storms or loops in your network while configuring a trunk, first disable or

disconnect all ports that you want to add to the trunk or remove from the trunk. After you
finish configuring the trunk, enable or re-connect the ports.

3-11

EDS-518A Series User’s Manual Featured Functions

If all ports on both switch units are configured as 100BaseTX and they are operating in full duplex,
the potential bandwidth of the connection will be up to 1.6 Gbps on the EDS-518A. This means
that users can connect one EDS to another EDS by Port Trunking to double, triple, or quadruple
the bandwidth of the connection.

When configuring Port Trunking, note that:
Each EDS-518A can set a maximum of 3 Port Trunking groups (Trk1/Trk2, 2 trunk groups for

10/100M ports and Trk3 for Gigabi t port s )
When you activate Port Trunking settings, some advanced functions that you setup with the

original ports will either be set to factory default values, or disabled:

y Communication Redundancy will be set to the factory default
y Traffic Prioritization will be set to the factory default
y Port-based VLAN or 802.1Q VLAN will be set to the factory default
y Multicast Filtering will be set to the factory default
y Rate Limiting will be set to the factory default
y Port Access Control will be set to the factory default
y Email and Relay Warning will be set to the factory default
y Set Device IP will be set to the factory default
y Mirror Port will be set to the factory default

You can setup these features again on your Trunking Port.

Configuring Port Trunking

The Port Trunking Settings page is used to assign ports to a Trunk Group.

Step 1: Select Trk1, Trk2, or Trk3 from the Trunk Group drop-down box.
Step 2: Select Static, or LACP from the Trunk Type drop-down box.
Step 3: Under Member Ports and Available Ports, select the specific ports.
Step 4: Use the Up / Down buttons to add/remove designated ports to/from a trunk group.

3-12

EDS-518A Series User’s Manual Featured Functions

Trunk Group (Maximum of 3 trunk groups)

Setting Description Factory Default

Trk1, Trk2, Trk3 Display or designate the Trunk Type and Member

Ports for Trunk Group 1, 2, 3.

Trunk Type

Setting Description Factory Default

Static Designated MOXA proprietary trunking protocol Static
LACP

Available Ports/Member Port

Setting Description Factory Default

Member/Available
Ports

Check box Check to designate which ports to add or remove. Unchecked
Port Port number N/A
Port description Displays the media type for each module’s port N/A
Name Max. 63 Characters N/A

Speed

FDX Flow Control

Up

Down

Designated LACP (IEEE 802.3ad, Link
Aggregation Control Protocol)

Use Up/Down buttons to add/remove specific ports
from available ports to/from trunk group.

Indicates the transmission speed (100M-Full,
100M-Half, 10M-Full, or 10M-Half )

Indicates if the FDX flow control of this port is
“Enabled” or “Disabled.”

Add designated ports into trunk group from
available ports.

Remove designated ports from trunk group t o
available port.

Trk1

Static

N/A

N/A

N/A

N/A

N/A

Trunk Table

Setting Description

Trunk Group Displays the Trunk Type and Trunk Group.
Member Port Display which member ports belong to the trunk group.
Status Success means po rt trunking is working properly.

Fail means port trunking is not working properly.
Standby means port trunking is working as a standby port. When there

are more than eight ports trunked as a trunking group, the 9
be the standby port.

3-13

th

port will

EDS-518A Series User’s Manual Featured Functions

Configuring SNMP

EDS-518A supports SNMP V1/V2c/V3. SNMP V1, and SNMP V2c use a community string
match for authentication, which means that SNMP servers access all objects with read-only or

read/write permissions using the community string public/private (default value). SNMP V3,

which requires you to select an authentication level of MD5 or SHA, is the most secure protocol.
You can also enable data encryption to enhance data security.

SNMP security modes and security levels supported by EDS-518A are shown in the following
table. Select the security mode and level that will be used to communicate between the SNMP
agent and manager.

Protocol

Version

SNMP V1,
V2c

SNMP V3

These parameters are configured on the SNMP page. A more detailed explanation of each

parameter follows.

UI Setting

V1, V2c
Read
Community

V1, V2c
Write/Read
Community

No-Auth No No

MD5 or SHA

MD5 or SHA

Authentication

Type

Community
string

Community
string

Authentication
based on MD5
or SHA

Authentication
based on MD5
or SHA

Data

Encryption

No

No

No

Data encryption
key

Method

Use a community string match
for authentication

Use a community string match
for authentication

Use account with admin or user
to access objects

Provides authentication based on
HMAC-MD5, or HMAC-SHA
algorithms. 8-character
passwords are the minimum
requirement for authentication.

Provides authentication based on
HMAC-MD5 or HMAC-SHA
algorithms, and data encryption
key. 8-character passwords and a
data encryption key are the
minimum requirements for
authentication and encryption.

SNMP Read/Write Settings

SNMP Versions

Setting Description Factory Default

V1, V2c, V3, or
V1, V2c, or
V3 only

V1, V2c Read Community

Setting Description Factory Default

V1, V2c Read
Community

Select the SNMP protocol version used to
manage the switch.

Use a community string match with a
maximum of 30 characters for
authentication. The SNMP agent accesses
all objects with read-only permissions

using the community string public.

3-14

V1, V2c

public

EDS-518A Series User’s Manual Featured Functions

V1, V2c Write/Read Community

Setting Description Factory Default

Uses a community string match with a
V1, V2c
Read/Write
Community

For SNMP V3, there are two levels of privileges for different accounts to access the EDS-518A.

Admin privilege allows access, and authorization to read and write the MIB file. User privilege

only allows reading the MIB file, but does not have authorization to write.

Admin Auth. Type (for SNMP V1, V2c, V3, and V3 only)

Setting Description Factory Default

No-Auth

MD5­Auth

SHA­Auth

maximum of 30 characters for

authentication. The SNMP servers access

all objects with read/write permissions

using the community string private.

Use admin. account to access objects.
No authentication

Provide authentication based on the
HMAC-MD5 algorithms. 8-character
passwords are the minimum requirement
for authentication.

Provide authentication based on the
HMAC-SHA algorithms. 8-character
passwords are the minimum requirement
for authentication.

private

No

No

No

Admin Data Encryption Key (for SNMP V1, V2c, V3, and V3 only)

Setting Description Factory Default

8-character data encryption key is the

Enable

Disable No data encryption No

User Auth. Type (for SNMP V1, V2c, V3 and V3 only)

Setting Description Factory Default

No-Auth

MD5-Auth

SHA-Auth

minimum requirement for data encryption
(maximum of 30 characters)

Use admin account or user account to
access objects. No authentication.

Provides authentication based on the
HMAC-MD5 algorithms. 8-character
passwords are the minimum requirement
for authentication.

Provides authentication based on the
HMAC-SHA algorithms. 8-character
passwords are the minimum requirement
for authentication.

No

No

No

No

3-15
