Moxa EtherDevice Switch
EDS-208 Series Hardware Installation Guide
Second Edition, June 2008
© 2008 Moxa Inc., all rights reserved.
Reproduction without permission is prohibited.
P/N: 1802002080000
Overview
The EDS-208 series of Moxa EtherDevice™ Switches are entry-level 8-port
Ethernet Switches that provide a cost-effective solution for industrial Ethernet
connections. EDS-208 provides a choice of 12 to 45 VDC power input or 18 to
30 VAC. The switches can operate reliably in a temperature range of -10 to
60°C, and the rugged hardware design makes EDS-208 perfect for ensuring
that your Ethernet equipment can be used in demanding industrial
environments.
Package Checklist
Moxa EDS-208 is shipped with the following items. If any of these items is
missing or damaged, please contact your customer service representative for
assistance.
y 1 EDS-208 or EDS-208-M-SC or EDS-208-M-ST
y Hardware Installation Guide
y Moxa Product Warranty booklet
Features
High Performance Network Switching Technology
y 10/100BaseT(X) (RJ45), 100BaseFX (SC/ST type, Multi mode)
y IEEE 802.3/802.3u/802.3x
y Store and Forward switching process type, 1024 address entries
Industrial Design
y Operating temperature ranges from -10 to 60°C
y Power inputs: 12 to 45 VDC or 18 to 30 VAC at 47 to 63 Hz
y IP30, plastic case
y DIN-Rail mounting ability
- 2 -
Panel Layout of EDS-208
1
2
3
Top View
V-
V+
24 VDC/VAC
Front View
P
7
5
3
1
8
6
4
100
2
10
1. Heat dissipation orifices
2. Terminal block for power input
and grounding
3. Moxa Logo
4. Power input LED
2
5. 10/100BaseT(X) Port
6. TP port’s 100 Mbps LED
7. TP port’s 10 Mbps LED
8. DIN-Rail kit
4
5
6
7
Rear View
8
- 3 -
Panel Layout of EDS-208-M-SC/ST
1
2
3
8
9
Top View
V-
V+
24 VDC/VAC
Front View
P
100M
Rx
7
Tx
5
3
1
8
6
4
100
2
10
1. Heat dissipation orifices
2. Terminal block for power input
and grounding
3. Moxa Logo
4. Power input LED
2
5. 10/100BaseT(X) Port
6. TP port’s 100 Mbps LED
7. TP port’s 10 Mbps LED
8. FX port’s 100 Mbps LED
9. 100BaseFX Port
10. DIN-Rail kit
4
5
6
7
Rear View
10
- 4 -
