Chapter 1 Introduction

Welcome to MOXA EtherDevice Switch EDS-408A/405A Series, the world’s first intelligent Ethernet Device Switch specially designed for connecting Ethernet-enabled devices in industrial field applications.

The following topics are covered in this chapter:

 Inside the Future of Industrial Ethernet Technology  MOXA EtherDevice™ Switch  Package Checklist  Optional Accessories  Features

EDS-408A/405A Series User’s Manual Introduction

Inside the Future of Industrial Ethernet Technology

The trend in industrial communications and automation applications

As the world’s network and information technology becomes more mature, the trend is to use Ethernet as the major communications interface in many industrial communications, and automation applications. In fact, a whole new industry has sprung up to provide Ethernet products that comply with the requirements of demanding industrial applications.

Industrial vs. Commercial

Users have found that when moving Ethernet equipment from the comfortable office environment to the harsh and less predictable industrial environment, the commercial Ethernet equipment available in today’s market simply cannot meet the high reliability requirements demanded by industrial applications. This means that a more robust type of network equipment, commonly

referred to as industrial Ethernet equipment, is required for these applications.

Informative vs. Passive

Since industrial Ethernet devices are often located at the endpoints of a system, such devices cannot always know what’s happening elsewhere on the network. This means that industrial Ethernet communication equipment that connects these devices must take responsibility for providing system maintainers with real-time alarm messages.

MOXA EtherDevice™ Switch

MOXA EtherDevice Switch comes with a suite of useful maintenance and monitoring functions, and is designed to provide smooth and reliable operation in harsh industrial environments. You will find that MOXA EtherDevice Switch establishes a new industrial Ethernet benchmark. It is excellent for keeping automation systems running continuously, is ideal for sending status reports to help prevent system damages and losses, is a great tool for mastering your industrial Ethernet networks, and is well-suited for use with industrial device control networks.

ATTENTION

Throughout this User’s Manual, we use EDS as an abbreviation for MOXA EtherDevice Switch:

EDS = MOXA EtherDevice Switch

Package Checklist

MOXA EtherDevice Switch EDS-408A/405A Series is shipped with the following items:

y 1 MOXA EtherDevice Switch EDS-408A/405A y Hardware Installation Guide y CD-ROM with User’s Manual and Windows Utility y Moxa Product Warranty y RJ45 to DB9 Console port cable y Protective caps for unused ports y Panel mounting kit (optional—must order separately)

NOTE: Notify your sales representative if any of the above items is missing or damaged.

1-2

EDS-408A/405A Series User’s Manual Introduction

Optional Accessories

y DR-4524—45W/2A DIN-Rail 24 VDC Power Supply with 85 to 264 VAC input y DR-75-24—75W/3.2A DIN-Rail 24 VDC Power Supply with 85 to 264 VAC input y DR-120-24—120W/5A DIN-Rail 24 VDC Power Supply with 88 to 132 VAC/176 to 264

VAC input by switch

y EDS-SNMP OPC Server Pro—CD with EDS-SNMP OPC Server Software and manual y ADP-SCm-STf-M—Multi-mode SC male to ST female duplex adapter, gray color y ADP-SCm-STf-S—Single-mode SC male to ST female duplex adapter, blue color y WK-46—Wall Mounting Kit

Features

Advanced Industrial Networking Capability

y MOXA Turbo Ring with Redundant Self-Healing Ethernet Ring Capability (recovery time <

300 ms at full load)

y Supports Port-Based VLAN to ease network planning y Supports QoS—IEEE 802.1p and TOS/DiffServ to increase determinism

Designed for Industrial Applications

y -40 to 75°C operating temperature range (for –T models) y Redundant, dual DC power inputs y IP 30, rugged high-strength case y DIN-Rail or panel mounting ability y Rate limiting to prevent unpredictable network status y Port mirroring for online debugging y Automatic warning by exception through email, relay output y Automatic recovery of connected device IP addresses y Line-swap fast recovery (patent pending)

Useful Utility and Remote Configuration

y Configurable by web browser, Telnet/serial console, and a proprietary Windows utility y Send ping commands to identify network segment integrity

1-3

Chapter 2 Getting Started

This chapter explains how to access MOXA EtherDevice Switch for the first time. There are three ways to access the switch: serial console, Telnet console, and web browser. The serial console connection method, which requires using a short serial cable to connect MOXA EtherDevice Switch to a PC’s COM port, can be used if you do not know MOXA EtherDevice Switch’s IP address. The Telnet console and web browser connection methods can be used to access MOXA EtherDevice Switch over an Ethernet LAN, or over the Internet.

The following topics are covered:

 Configuration using RS-232 Serial Console (115200, None, 8, 1, VT100)  Configuration using Telnet Console  Configuration using Web Browser  Disabling Telnet and Browser Access

EDS-408A/405A Series User’s Manual Getting Started

Configuration using RS-232 Serial Console (115200, None, 8, 1, VT100)

NOTE

Connection Caution!

1. You cannot connect to EDS using serial console and Telnet simultaneously.

2. You can connect to EDS using a web browser and serial console simultaneously, or using a

web browser and Telnet simultaneously.

3. Recommendation—when connecting to EDS using a web browser, do NOT simultaneously

connect using either a serial console or via Telnet.

4. By following this advice, you can maintain better control over how your MOXA

EtherDevice Switch is managed.

We recommend using MOXA PComm Terminal Emulator, which can be downloaded free of charge from Moxa’s website.

Before running PComm Terminal Emulator, use an RJ45 to DB9-F (or RJ45 to DB25-F) cable to connect MOXA EtherDevice Switch’s RS-232 Console port to your PC’s COM port (generally COM1 or COM2, depending on how your system is set up).

After installing PComm Terminal Emulator, do the following to access the RS-232 Console utility.

1. From the Windows desktop, click Start Æ Programs Æ PCommLite2.5 Æ Terminal

Emulator.

2. Select Open under Port Manager to open a new connection.

2-2

EDS-408A/405A Series User’s Manual Getting Started

3. The Communication Parameter page of the Property window opens. Select the appropriate

COM port for Console Connection, 115200 for Baud Rate, 8 for Data Bits, None for Parity, and 1 for Stop Bits.

4. Click the Terminal tab, and select VT100 for Terminal Type. Click OK to confirm.

5. Type 1 to select ansi/VT100 terminal type, and then press Enter.

2-3

EDS-408A/405A Series User’s Manual Getting Started

6. The Console login screen will be displayed. Press Enter to open the Account pop-up selector

and then select either admin or user. Use the keyboard’s down arrow to move the cursor to the Password field, enter the Console Password (this is the same as the Web Browser password; leave the Password field blank if a console password has not been set), and then press Enter.

7. MOXA EtherDevice Switch’s Main Menu will be displayed. (NOTE: To modify the

appearance of the PComm Terminal Emulator window, select Font… under the Edit menu,

and then choose the desired formatting options.)

8. After entering the Main Menu, use the following keys to move the cursor, and to select

options.

Key Function

Up/Down/Left/Right arrows, or Tab Move the onscreen cursor

Enter Display & select options

Space Toggle options

Esc Previous Menu

2-4

EDS-408A/405A Series User’s Manual Getting Started

Configuration using Telnet Console

You may use Telnet to access MOXA EtherDevice Switch’s console utility over a network. To be able to access EDS’s functions over the network (using Telnet or Web Browser) from a PC host that is connected to the same LAN as EDS, you need to make sure that the PC host and EDS are on the same logical sub network. To do this, check your PC host’s IP address and netmask. By default, EDS’s IP address is 192.168.127.253 and EDS’s netmask is 255.255.0.0 (for a Class B network). If you do not change these values, and your PC host’s netmask is 255.255.0.0, then its IP address must have the form 192.168.xxx.xxx. On the other hand, if your PC host’s netmask is

255.255.255.0, then its IP address must have the form 192.168.127.xxx.

NOTE

To use EDS’s management and monitoring functions from a PC host connected to the same LAN as EDS, you must make sure that the PC host and EDS are on the same logical sub network.

Before accessing the console utility via Telnet, first connect one of MOXA EtherDevice Switch’s RJ45 Ethernet ports to your Ethernet LAN, or directly to your PC’s Ethernet NIC. You can establish a connection with either a straight-through or cross-over Ethernet cable. If you have difficulty connecting, refer to the Auto MDI/MDI-X Connection section from the Hardware installation Guide for more information about the different types of Ethernet cables and ports.

MOXA EtherDevice Switch’s default IP is 192.168.127.253.

Perform the following steps to access the console utility via Telnet.

1. Telnet to MOXA EtherDevice Switch’s IP address from the Windows Run window (or from

the command prompt).

2. Type 1 to choose ansi/vt100, and then press Enter.

2-5

EDS-408A/405A Series User’s Manual Getting Started

3. The Console login screen will be displayed. Press Enter to open the Account pop-up selector

4. MOXA EtherDevice Switch’s Main Menu will be displayed. (NOTE: To modify the

appearance of the PComm Terminal Emulator window, select Font… under the Edit menu,

and then choose the desired formatting options.)

NOTE

The Telnet Console looks and operates in precisely the same manner as the RS-232 Console.

2-6

EDS-408A/405A Series User’s Manual Getting Started

Configuration using Web Browser

MOXA EtherDevice Switch’s web browser interface provides a convenient way to modify the switch’s configuration and access the built-in monitoring and network administration functions. You may use either Internet Explorer or Netscape to access EDS.

NOTE

To use EDS’s management and monitoring functions from a PC host connected to the same LAN as EDS, you must make sure that the PC host and EDS are on the same logical sub network.

Before accessing MOXA EtherDevice Switch’s web browser interface, first connect one of MOXA EtherDevice Switch’s RJ45 Ethernet ports to your Ethernet LAN, or directly to your PC’s Ethernet NIC. You can establish a connection with either a straight-through or cross-over Ethernet cable. If you have difficulty connecting, refer to the Auto MDI/MDI-X Connection section from the Hardware installation Guide for more information about the different types of Ethernet cables and ports.

MOXA EtherDevice Switch’s default IP is 192.168.127.253.

Perform the following steps to access MOXA EtherDevice Switch’s web browser interface.

1. Open Internet Explorer and type MOXA EtherDevice Switch’s IP address in the Address

field. Press Enter to establish the connection.

2. The web login page will be displayed. Select the login account (Admin or User) and enter the

Password (this is the same as the Console password), and then click Login to continue. Leave the Password field blank if a password has not been set.

NOTE

By default, MOXA EtherDevice Switch’s Password is not set (i.e., is blank).

2-7

EDS-408A/405A Series User’s Manual Getting Started

You may need to wait a few moments for the web page to be downloaded to your computer. Use the menu tree on the left side of the window to open the function pages to access each of MOXA EtherDevice Switch’s functions.

Disabling Telnet and Browser Access

NOTE

If you are connecting MOXA EtherDevice Switch to a public network, but do not intend to use its

management functions over the network, then we suggest disabling both Telnet Console and Web Configuration from the RS-232 Console’s Basic Settings Æ System Identification page, as

shown in the following figure.

If you are connecting MOXA EtherDevice Switch to a public network, but do not intend to use its

management functions over the network, then we suggest disabling both Telnet Console and Web Configuration.

2-8

Chapter 3 Featured Functions

This chapter explains how to access a MOXA EtherDevice Switch’s various configuration, monitoring, and administration functions. There are three ways to access these functions: serial console, Telnet console, and web browser. The serial console connection method, which requires using a short serial cable to connect MOXA EtherDevice Switch to a PC’s COM port, can be used if you do not know MOXA EtherDevice Switch’s IP address. The Telnet console and web browser connection methods can be used to access MOXA EtherDevice Switch over an Ethernet LAN, or over the Internet.

The Web Console is the most user-friendly way to configure a MOXA EtherDevice Switch. In this chapter, we use the Web Console interface to introduce the functions of a MOXA EtherDevice Switch. There are only a few differences between the Web Console, Serial Console, and Telnet Console access methods.

The following topics are covered in this chapter:

 Configuring Basic Settings  Configuring SNMP  Using Communication Redundancy  Using Traffic Prioritization  Using Virtual LAN  Using Rate Limiting  Using Auto Warning  Using Line-Swap-Fast-Recovery  Using Set Device IP  Using Diagnosis  Using the Monitor  Using the MAC Address Table  Using Event Log

EDS-408A/405A Series User’s Manual Featured Functions

Configuring Basic Settings

The Basic Settings group includes the most commonly used settings required by administrators to maintain and control a MOXA EtherDevice Switch.

System Identification

The system identification items are displayed at the top of the web page, and will be included in alarm emails. Setting system identification items makes it easier to identify the different switches connected to your network.

Switch Name

Setting Description Factory Default

Max. 30 Characters

This option is useful for specifying the role or application of different EDS units. E.g., Factory Switch 1.

Industrial Redundant

Switch [Serial No. of this switch]

Switch Location

Setting Description Factory Default

Max. 80 Characters

Switch Description

Setting Description Factory Default

Max. 30 Characters

Maintainer Contact Info

Setting Description Factory Default

Max.30 Characters

To specify the location of different EDS units. E.g., production line 1.

Use this to record a more detailed description of the EDS unit.

Use this to record contact information of the person responsible for maintaining this EDS-408A/405A.

Switch Location

None

3-2

EDS-408A/405A Series User’s Manual Featured Functions

Password

EDS-408A/405A provides two levels of access privileges: admin privilege gives read/write access to all EDS configuration parameters; user privilege provides read access only—you will be able to

view the configuration, but will not be able to make modifications.

ATTENTION

MOXA EtherDevice Switch’s default Password is not set (i.e., is blank). If a Password is already set, then you will be required to type the Password when logging into the RS-232 Console, Telnet Console, or Web Browser interface.

Account

Setting Description Factory Default

admin admin privilege allows the user to

modify all EDS configurations.

user user privilege only allows viewing

EDS configurations.

Password

Setting Description Factory Default

Old Password (Max. 16 Characters)

New Password (Max.

16 Characters)

Retype Password (Max. 16 Characters)

Type current password when changing the password

Type new password when changing the password

If you type a new password in the Password field, you will be required to retype the password in the Retype new password field before updating the new password.

admin

None

3-3

EDS-408A/405A Series User’s Manual Featured Functions

Accessible IP

Moxa EtherDevice Switches use an IP address-based filtering method to control access to EDS.

Accessible IP Settings allows you to add or remove Legal remote host IP addresses to prevent

unauthorized access. Access to EtherDevice Switch is controlled by IP addresses. That is, if a host’s IP address is in the accessible IP table, then the host will be allowed access to the EtherDevice Switch. You can allow one of the following cases by setting this parameter

y Only one host with the specified IP address can access the EDS-408A/405A

E.g., enter “192.168.1.1/255.255.255.255” to allow access to just the IP address 192.168.1.1.

y Any host on a specific sub network can access the EDS-408A/405A

E.g., enter “192.168.1.0/255.255.255.0” to allow access to all IPs on the sub network defined by this IP address/netmask combination.

y Any host can access the EDS-408A/405A

Disable this function by not selecting the Enable the accessible IP list checkbox.

The following table shows additional configuration examples:

Allowable Hosts Input format

Any host Disable

192.168.1.120 192.168.1.120 / 255.255.255.255

192.168.1.1 to 192.168.1.254 192.168.1.0 / 255.255.255.0

192.168.0.1 to 192.168.255.254 192.168.0.0 / 255.255.0.0

192.168.1.1 to 192.168.1.126 192.168.1.0 / 255.255.255.128

192.168.1.129 to 192.168.1.254 192.168.1.128 / 255.255.255.128

3-4

EDS-408A/405A Series User’s Manual Featured Functions

Port

Port settings are included to give the user control over Port Access, Port Transmission Speed,

Flow Control, and Port Type (MDI or MDIX). An explanation of each configuration item is given below. (NOTE: The user interface for EDS-408A shows 8 ports.)

Enable

Setting Description Factory Default

checked Allows data transmission through the port.

unchecked Immediately shuts off port access.

ATTENTION

If a connected device or sub-network is wreaking havoc on the rest of the network, the Disable option under Advanced Settings/Port gives the administrator a quick way to immediately shut

off access through this port.

Name

Setting Description Factory Default

Max. 63 Characters

Specify an alias for each port, and assist the administrator in remembering important information about the port. E.g., PLC 1

disabled

None

3-5

EDS-408A/405A Series User’s Manual Featured Functions

Port Transmission Speed

Setting Description Factory Default

Allows the port to use the IEEE 802.3u

Auto

100M-Full

100M-Half

10M-Full

10M-Half

FDX Flow Control This setting enables or disables the flow control capability of this port when the port transmission

speed setting is on auto mode. The final result will be determined by the auto process between the

EDS and the connected device.

Setting Description Factory Default

Enable

Disable

protocol to negotiate with connected devices. The port and connected devices will determine the best speed for that connection.

Choose one of these fixed speed options if the Ethernet device at the other end has trouble auto-negotiating for line speed.

Enables the flow control capability of this port when in auto-nego mode.

Disables the flow control capability of this port when in auto-nego mode.

Auto-nego

Disable

Network

Port Type

Setting Description Factory Default

Allows the port to auto detect the port type of

Auto

MDI

MDIX

The Network configuration allows users to modify the usual TCP/IP network parameters. An

explanation of each configuration item follows.

the Ethernet device at the other end and change the port type accordingly.

Choose the MDI or MDIX option if the Ethernet device at the other end has trouble auto-negotiating for port type.

Auto

3-6

EDS-408A/405A Series User’s Manual Featured Functions

Auto IP Configuration

Setting Descriptions Factory Default

Disable Set up EDS’s IP address manually.

EDS’s IP address will be assigned

By DHCP

By BootP

Switch IP Address

Setting Descriptions Factory Default

IP Address of the EDS

Switch Subnet Mask

Setting Descriptions Factory Default

Subnet mask of the EDS

automatically by the network’s DHCP server.

EDS’s IP address will be assigned automatically by the network’s BootP server.

Identifies the EDS on a TCP/IP network. 192.168.127.253

Identifies the type of network the EDS is connected to (e.g., 255.255.0.0 for a Class B network, or 255.255.255.0 for a Class C network).

Disable

255.255.255.0

Default Gateway

Setting Descriptions Factory Default

Default Gateway of the EDS

DNS IP Address

Setting Descriptions Factory Default

1st DNS Server’s IP Address

2nd DNS Server’s IP Address

The IP address of the router that connects the LAN to an outside network.

The IP address of the DNS Server used by your network. After entering the DNS Server’s IP address, you can input EDS’s URL (e.g., your browser’s address field, instead of entering the IP address.

The IP address of the DNS Server used by your network. EDS will try to locate the 2nd DNS Server if the 1st DNS Server fails to connect.

www.eds.company.com) in

None

3-7

EDS-408A/405A Series User’s Manual Featured Functions

Time

EDS has a time calibration function based on information from an NTP server or user specified Time and Date information. Functions such as Auto warning Email can add real-time information to the message.

NOTE

EDS does not have a real time clock. The user must update the Current Time and Current Date to set the initial time for EDS after each reboot, especially when the network doesn’t have an Internet connection for NTP server or there is no NTP server on the LAN.

Current Time

Setting Description Factory Default

User adjustable time.

Current Date

Setting Description Factory Default

User adjustable date.

System Up Time

Indicates EDS’s up time from the last cold start. The unit is seconds.

Time Zone

Setting Description Factory Default

User selectable time zone

The time parameter allows configuration of the local time in local 24-hour format.

The date parameter allows configuration of the local date in yyyy/mm/dd format.

The time zone setting allows conversion from GMT (Greenwich Mean Time) to local time.

None (hh:mm:ss)

None (yyyy/mm/dd)

GMT (Greenwich Mean Time)

NOTE

Changing the time zone will automatically correct the current time. You should configure the time zone before setting the time.

3-8

EDS-408A/405A Series User’s Manual Featured Functions

Time Server IP/Name

Setting Description Factory Default

1st Time Server IP/Name

2nd Time Server IP/Name

IP or Domain address (e.g., 192.168.1.1 or time.stdtime.gov.tw or time.nist.gov)

EDS will try to locate the 2nd NTP Server if the connection to the 1

NTP server failed.

None

Time Server Query Period

Setting Description Factory Default

Query Period

This parameter determines how frequently the time is updated from the NTP server.

600 seconds

Turbo Ring DIP Switch

EDS-408A/405A series are plug-and-play managed redundant Ethernet switches. The proprietary Turbo Ring protocol was developed by MOXA to provide better network reliability and faster recovery time. MOXA Turbo Ring’s recovery time is less than 300 ms—compared to a 3- to 5-minute recovery time for commercial switches—decreasing the possible loss caused by network failure.

A set of DIP Switches located on EDS-408A/405A’s outer casing can be easily used to configure the Turbo Ring settings in only a few seconds. Some users may wish to disable the Turbo Ring DIP Switches to avoid accidental changes to the configuration. To disable the DIP Switches, start

the user interface, and then click on Turbo Ring DIP Switch under Basic Settings. Next, select the checkmark from the Disable the Turbo Ring DIP Switch checkbox.

Turbo Ring DIP Switch

Setting Description Factory Def au l t

Enable the Turbo Ring DIP Switch

Disable the Turbo Ring DIP Switch

Unselect the “Disable the Turbo Ring DIP Switch” option to enable the entire set of Hardware DIP switches.

Select the “Disable the Turbo Ring DIP Switch” option to disable the entire set of

Unselect (Turbo Ring DIP Switch is enabled)

Hardware DIP switches.

EDS-408A/405A Series DIP Switches

The default setting for each DIP Switch is OFF. The following table

------

MASTER

COUPLER

TURBO RING

explains the effect of setting the DIP Switch to the ON position.

3-9

+ 54 hidden pages
